QUICKSTART GUIDE
4GR
YOUR 4GR OUT OF THE BOX
1. Screw the four antennas onto the threaded ports extending from the 4GR.
2.
3. Wait a few minutes while the 4GR locates a cellular signal.
ˣ
1
NOTE: The broad antennas should be placed at the back of the 4GR.
![](/img.php?id=3427481&img=bg2.png)
[product photos/diagrams]
2
![](/img.php?id=3427481&img=bg3.png)
4GR LIGHT GUIDE
No lights: 4GR does not have power.
Single flashing green light: 4GR is powering on.
Changing flashing green lights: As the 4GR searches for a
signal, the lights will cycle back and forth (1,2,3,4,5; 5,4,3,2,1).
Solid green light: Indicates level of cellular signal.
1 light is a poor signal, 5 lights is a very strong signal.
All flashing red lights: 4GR cannot find a cellular signal.
3
![](/img.php?id=3427481&img=bg4.png)
CONFIGURE YOUR 4GR
1.
2.
Using a computer or mobile device,
connect to the 4GR’s Wi-Fi network.
Use the name (SSID) and password
printed on the label on the bottom
of the 4GR.
3. You will be prompted to login. Use the Admin. Password from the 4GR label.
4. You are now able to configure your 4GR!
5. To change your SSID and/or create a new password, select Network Configuration
from the drop-down menu.
6. For more information about configuring your 4GR,
see the complete User Guide at www.intwineconnect.com
Open an internet browswer and go to
the address https://192.168.10.1 to
access your 4GR Configuration Page.
4
NOTE: If you change this information, it will replace the information
on the label. Write it down and store it in a secure location.
NOTE: If you receive a security warning about the website’s security or
certificate, dismiss it.
![](/img.php?id=3427481&img=bg5.png)
CERTIFICATIONS, LICENSES, AND WARNINGS
!
CAUTION:
There is a risk of explosion if this device’s battery is replaced with an incorrect battery type.
Dispose of all used batteries according to applicable instructions and regulations.
COMPLIANCE:
This device complies with Part 15 of FCC rules. Operation is subject to the following conditions:
1. this device may not cause harmful interference, AND
2. this device must accept any interference received, including interference that may cause undesired operation.
FOR FCC 15B DEVICES:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interferences will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer of an experience radio/TV technician for help.
FCC PART 15.21 INFORMATION FOR USER:
You are cautioned that changes or modifications not expressly approved by the party responsible for compliance
could void your authority to operate the equipment.
5
![](/img.php?id=3427481&img=bg6.png)
FOR MOBILE DEVICES WITHOUT CO-LOCATION CONDITION (the transmitting antenna is installed or
located more than 20cm away from the body of user and near by person):
FCC RF Radiation Exposure Statement:
1. This Transmitter must not be located or operating in conjunction with any other antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and
your body.
FOR MOBILE DEVICES WITH CO-LOCATION CONDITION (the transmitting antenna is installed or located
more than 20cm away from the body of user and near by person):
FCC RF Exposure Statement:
1. This Transmitter has been demonstrated co-location compliance requirements with (Bluetooth model#). This
transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of 20c,m between the radiator and your
body.
!
CERTIFICATIONS, LICENSES, AND WARNINGS
6
For a complete list of warnings, warranties, and other useful information about your 4GR,
please visit www.intwineconnect.com.
Copyright © 2015, Intwine Connect, LLC.
8401 Chagrin Rd. Suite 10B
Chagrin Falls, OH 44023
(330) 405-8698
www.intwineconnect.com
