Intended use
Generic air-conduction hearing instruments are wearable sound-amplifying devices intended to compen-
sate for impaired hearing. The fundamental operating principle of hearing instruments is to receive, amplify,
and transfer sound to the ear drum of a hearing impaired person.
The products are in compliance with the following regulatory requirements:
• In EU: the device conforms to the Essential Requirements according to Annex I of Council Directive
93/42/EEC for medical devices (MDD) and essential requirements and other relevant provisions of Direc-
tive 1999/5/EC (R&TTE).
• The declaration of conformity may be consulted at www.resound.com
• In US: FCC CFR 47 Part 15, subpart C.
• Other identified applicable international regulatory requirements in countries outside EU and US. Please
refer to local country requirements for these areas.
• In Canada: these hearing instruments are certified under the rules of IC.
• Japanese Radio Law and Japanese Telecommunications Business Law Compliance. This device is
granted pursuant to the Japanese Radio Law (電波法) and the Japanese telecommunications Business
Law (電気通信事業法) This device should not be modified (otherwise the granted designation number
will become invalid)
• Patents
US 7,593,537 US 8,00,849
400344000-GB-14.11-Rev.A.indd 3 10-12-2014 11:22:24
![](/img.php?id=2482662&img=bg4.png)
4
Prescription use of this TSG hearing instrument
The TSG module should be used as prescribed by your doctor, audiologist or hearing healthcare profes-
sional. In order to avoid permanent hearing damages, the maximum daily usage depends on the level of
the generated sound.
Should you develop any side effects from using the sound generator, such as dizziness, nausea, head-
aches, perceived decrease in auditory function or increase in tinnitus perception, you should discontinue
use of sound generator and seek medical evaluation.
The target population is primarily the adult population over 18 years of age. This product may also be used
with children 5 years of age or older. However, children and physically or mentally challenged users will re-
quire training by a doctor, audiologist, hearing healthcare professional or the guardian for the insertion and
removal of the hearing instrument containing the TSG module.
Important notice for prospective sound generator users
A tinnitus masker is an electronic device intended to generate noise of sufficient intensity and bandwidth to
mask internal noises. It is also used as an aid in hearing external noises and speech.
Good health practice requires that a person with a tinnitus condition have a medical evaluation by a licensed
physician (preferably a physician who specializes in diseases of the ear) before using a sound generator.
Licensed physicians who specialize in diseases of the ear are often referred to as otolaryngologists, otolo-
gists or otorhinolaryngologists.
The purpose of medical evaluation is to assure that all medically treatable conditions that may affect tinnitus
are identified and treated before the sound generator instrument is used. The sound generator instrument is
400344000-GB-14.11-Rev.A.indd 4 10-12-2014 11:22:24
![](/img.php?id=2482662&img=bg5.png)
5
ReSound is a registred trade mark of ReSound A/S
a tool to generate sounds to be used with appropriate counselling and/or in a tinnitus management program
to relieve patients suffering from tinnitus.
Introduction
Congratulations on the purchase of your new hearing instruments. ReSound’s innovative sound technology
and design, combined with the customised device programming selected by your hearing care profes-
sional, will make hearing a more enjoyable experience. Hearing instruments will enable you to hear sounds
that you may not have heard in years because of your hearing loss. Practice and a positive attitude are
important in learning to use hearing instruments. Your ReSound instruments have been adjusted according
to your individual hearing loss and needs. Some people adjust quickly to wearing hearing instruments in
their ears and hearing new sounds; other people may need more time.
Please read this manual carefully in order to wholly benefit from the use of your hearing instruments. With
proper care, maintenance, and usage, your hearing instruments will aid you in better communication for
many years. Ask your hearing care professional if you have any questions.
400344000-GB-14.11-Rev.A.indd 5 10-12-2014 11:22:24
![](/img.php?id=2482662&img=bg6.png)
6
Hearing instrument model:
Model 61: Battery size 312
Model 62: Battery size 13
Receiver tube length:
Dome size:
Left serial number:
Right serial number:
400344000-GB-14.11-Rev.A.indd 6 10-12-2014 11:22:24
![](/img.php?id=2482662&img=bg7.png)
7
Mini Receiver In-the-Ear (RIE) hear-
ing instruments of type VE312 with FCC ID:
X26VE312, IC number 6941C-VE312 and size
312 battery are available in the following vari-
ants:
LS961-DRW, LS761-DRW, LS561-DRW
Receiver-in-the-ear (RIE) hearing instru-
ments of type BRIE with FCC ID X26BRIE, IC
number 6941-BRIE and size 13 battery are
available in the following variants:
LS962-DRW, LS762-DRW, LS562-DRW
The identification number for the BRIE and VE312
device models can be found at location “15” as indi-
cated in the illustrations on page 7.
400344000-GB-14.11-Rev.A.indd 7 10-12-2014 11:22:25
![](/img.php?id=2482662&img=bg8.png)
8
Contents
Statement: .............................2
Intended use ...........................3
Prescription use of this TSG hearing instrument ...4
Important notice for prospective
sound generator users ....................4
Introduction.............................5
Contents ...............................8
Getting started .........................12
SmartStart ............................12
Inserting/Replacing the battery.............12
Low battery indicator ....................13
Low battery indicator when paired with
wireless accessories only .................13
Sports lock ............................14
Inserting/Removing hearing instruments......14
Program and Multi-Function buttons ........16
Flight mode* (Wireless models only) . . . . . . . . . 19
Telephone use..........................20
Listen to radio or TV .....................21
Using ReSound Hearing Instruments with
iPhone®, iPad®, and iPod touch®
(ReSound LiNX2)........................21
Cellular phones.........................21
PhoneNow ............................22
Telecoil (optional)........................24
Tele-loop systems .......................24
Direct audio input (optional) ...............24
Connecting/Disconnecting audio boots ......25
Care and maintenance ...................26
Daily maintenance.......................27
The receiver tube .......................28
Cleaning the receiver tubes and domes ......28
Cleaning RIE or moulds ..................28
Changing wax guard for receiver tube .......29
How to apply domes.....................30
Using ReSound hearing instruments with
smart phone apps.......................31
General precautions .....................32
400344000-GB-14.11-Rev.A.indd 8 10-12-2014 11:22:25
![](/img.php?id=2482662&img=bg9.png)
9
General warnings .......................32
Tinnitus Sound Generator (TSG) module .....34
User instructions for the TSG module ........34
The scientific concepts that form the basis
for the device ..........................36
Technical Specifications ..................36
TSG warnings ..........................37
TSG precautions........................37
TSG warning to hearing healthcare
professionals...........................38
Battery warning information ...............39
Hearing instrument expectations ...........39
Warning to hearing aid dispensers (US Only) ..40
Important notice for prospective
hearing aid users (US Only)................40
Children with hearing loss (US Only) ........41
Troubleshooting Guide ...................42
Troubleshooting Guide ...................44
Technical data..........................46
Warranty and repairs ....................54
Temperature test, transport and
storage information......................54
400344000-GB-14.11-Rev.A.indd 9 10-12-2014 11:22:25
![](/img.php?id=2482662&img=bga.png)
9, 10
1
8
2
714
91
82
15
10
1. Receiver tube
2. Receiver Open Dome
3. Receiver Tulip Dome
4. Receiver Power Dome
5. RIE mould
6. Sports lock
7. Battery compartment
8. Receiver
9. Push button
10. Volume Control (optional)
11. LP receiver tube
12. MP receiver tube
13. HP receiver tube
14. Model, and serial number (in battery chamber)
15. UP Receiver/Mould
62 models (type BRIE)
61 model (type VE312)
400344000-GB-14.11-Rev.A.indd 10 10-12-2014 11:22:25
![](/img.php?id=2482662&img=bgb.png)
36
5
13 15
4
11 12
11
61 model (type VE312)
400344000-GB-14.11-Rev.A.indd 11 10-12-2014 11:22:26
![](/img.php?id=2482662&img=bgc.png)
2
1
3
12
Getting started
On/Off function
1. When the battery door is closed, the hearing instrument turns on,
and the default program will be activ ated.
2. To turn off the hearing instrument, open the battery door. Use your
fingernail to pull it open.
SmartStart
Hearing instruments can be turned on once you have placed them on your ears. If you prefer to turn them on
just prior to placing them on your ear, your hearing care professional can activate a function called Smart-
Start. This function will delay the time in which the hearing instruments turn on after the battery compart-
ment is closed. With SmartStart, a beep will be heard for each second of the delay period.
Inserting/Replacing the battery
1. Open the battery door completely by using your fingernail. Remove the used
battery if present.
2. Prepare the new battery (please refer to page 7 for information on appropriate
battery type/size for your hearing instrument). Remove the protective foil and
wait 2 minutes before inserting the battery into the hearing instrument to
allow activation of the battery.
3. Insert the new battery with the positive side in the correct position.
4. Gently close the battery door.
On
Off
400344000-GB-14.11-Rev.A.indd 12 10-12-2014 11:22:28
![](/img.php?id=2482662&img=bgd.png)
13
i Tip:
1. Always use new Zinc-Air batteries that have a minimum remaining shelf life of one year.
2. Whenever the hearing instruments are not in use, remember to turn them off to avoid unnecessary
battery consumption.
Low battery indicator
Your hearing care professional can set your hearing instrument to give an acoustical indication when the bat-
tery is reaching its end of life. The hearing instrument will reduce amplification and emit a melody if battery
power gets too low. This signal will recur every five minutes (every 15 minutes for the LiNX models) until the
hearing instrument automatically switches off. It is recommended that you keep spare batteries on hand.
Low battery indicator when paired with wireless accessories only
Active usage of the ReSound Unite accessories (Remote Control 2, Phone Clip+, TV Streamer 2 and Mini
Microphone) requires more battery power from the hearing instruments than when these are working on
their own meaning that battery life is highly dependent on the amount of wireless accessory usage. When
the battery in the hearing instrument has depleted to a level at which use of the ReSound Unite TV Streamer
2, Phone Clip+ and Mini Microphone cannot be supported, the hearing instrument will play two sets of
descending tones. After this, your hearing instrument and ReSound Unite Remote Contro 2l will continue
to work as usual, but you will not be able to use your ReSound Unite TV Streamer 2, Phone Clip+ and Mini
Microphone. At some point the battery level will not support the remote control either and you will once
again hear the descending tones. The hearing instruments will continue to work as usual. Once a new bat-
tery is inserted, full operation of the accessories will resume.
400344000-GB-14.11-Rev.A.indd 13 10-12-2014 11:22:28
![](/img.php?id=2482662&img=bge.png)
14
Sports lock
The sports lock will be applied or adjusted by your hearing care professional.
Inserting/Removing hearing instruments
Insertion (custom RIE and UP moulds)
1. Hold the RIE mould between your thumb and index finger and position its sound
outlet in your ear canal.
2. Slide the RIE mould all the way into your ear with a gentle, twisting movement.
3. Move the RIE mould up and down and gently press to ensure it is positioned correctly
in the ear. Opening and closing your mouth can ease insertion.
4. Make sure the hearing instrument is seated behind the ear.
By experimenting, an easier method may be discovered. With proper insertion, hearing
instruments should fit snugly but comfortably. If hearing instruments cause irritation of
the ears, contact your hearing care professional.
i Never attempt to modify the shape of the hearing instrument, RIE moulds, or tubing yourself.
i Tip: It may be helpful to pull the top of your ear back with your opposite hand during insertion to open
the ear canal.
400344000-GB-14.11-Rev.A.indd 14 10-12-2014 11:22:29
![](/img.php?id=2482662&img=bgf.png)
15
Insertion (domes)
1. Hold the receiver tube where it bends, and
gently place the dome into the ear canal.
Push the dome far enough into the ear canal
so that the receiver tube lies flush with the
side of the head.
2. It is important that the tube and the dome fit
correctly into your ear.
3. When the dome is placed correctly, you should not be able to see the receiver tube sticking out when
facing a mirror.
i Note: You should never attempt to bend or modify the shape of the receiver tube.
Removal (RIE moulds)
1. Grasp the removal string and pull the RIE or UP mould outward.
2. Consult your hearing care professional if you have difficulties removing the hearing instrument.
Removal (domes)
1. Hold the receiver tube with your thumb and forefinger and remove the tube.
2. Consult your hearing care professional if you have difficulties removing the
hearing instrument.
400344000-GB-14.11-Rev.A.indd 15 10-12-2014 11:22:29
![](/img.php?id=2482662&img=bg10.png)
16
Program and Multi-Function buttons
If you have a hearing aid with a program button or multi-function button, this will allow you to use up to four
different listening programs, each of them suitable for certain situations.
Program button (61 models only) Multi-function button (62 models only)
Your hearing care professional can fill out the following table for you.
Programme Description of when to use
1
2
3
4
400344000-GB-14.11-Rev.A.indd 16 10-12-2014 11:22:30
![](/img.php?id=2482662&img=bg11.png)
17
When using the program or multi-function buttons to switch programs, each press will move the instrument
to the next program. For example, if it was in program 1 it will switch to program 2, if it was in program 2 it
will switch to program 3 etc.
When you close the battery door and switch the instrument on, it will start in program 1. Press the program
or multi-function buttons if you want to move to a different listening program.
If you have two hearing instruments with the synchronization function enabled, program changes to one
instrument will automatically repeat in the second instrument. When a program change is made in one
instrument, you will hear the same amount of confirmation beeps in the second instrument.
Your instrument has a fully automatic volume control. Therefore, it should not be necessary to control the
volume manually.
However, in addition to controlling listening programs, the multi-function button (62 models only) provides
you with the ability to adjust the amplification to your liking.
400344000-GB-14.11-Rev.A.indd 17 10-12-2014 11:22:30
![](/img.php?id=2482662&img=bg12.png)
18
If you have two hearing instruments with the synchronization function enabled and you have the Multifunc-
tion Button set for volume control functionality, volume adjustments to one instrument will automatically
repeat in the second instrument. When a volume control adjustment is made in one instrument, you will hear
a confirmation beep. A beep in the second instrument will follow.
The multi-function button is designed to change the volume or listening programs of the hearing instrument,
based on different ways it is pressed.
If necessary, your hearing care practitioner can change these settings and fill in the following table to indi-
cate the new settings:
Multi-function button action Default setting New setting
Short press up Increases volume
Short press down Decreases volume
Long press up (3 seconds) Changes programs
Long press down (3 seconds Activates streaming
400344000-GB-14.11-Rev.A.indd 18 10-12-2014 11:22:30
![](/img.php?id=2482662&img=bg13.png)
19
i Flight mode* (Wireless models only)
When boarding a flight or entering an area where RF transmitters are prohibited, wireless functionality must
be deactivated, as it is not allowed to radiate radio signals during flights or in otherwise restricted areas.
It is possible to disable wireless operation by opening and closing the battery compartment three times
within a ten second period (open-close, open-close, open-close). Your instruments will now be in flight
mode.
If the hearing instrument is in flight mode, the hearing instrument must have been operating in flight mode
for at least 10 seconds before attempting to enable wireless again. it is possible to re-enable wireless opera-
tion by opening and closing the battery door once. 10 seconds after this operation is completed, wireless
operation will begin again.
i Note: It is important to wait an additional 15 seconds after wireless function resumes before open-
ing and closing the battery compartment again for any reason. If the battery compartment is opened and
closed during this 15 second window, flight mode will resume.
*For wireless models only
400344000-GB-14.11-Rev.A.indd 19 10-12-2014 11:22:30
![](/img.php?id=2482662&img=bg14.png)
20
Telephone use
If your hearing instruments are fit with a receiver open dome or receiver tulip dome, you can probably use
the telephone as you normally would by holding it up to your ear canal opening. If your hearing instruments
are fit with a receiver power dome or RIE or UP mould, finding the optimal position for holding a telephone
while using a hearing instrument may require practice for some individuals, and one or more of the following
suggestions may be helpful.
1. Hold the telephone as you would normally.
2. Hold the telephone towards the top of the ear (closer to where the
microphones are located).
3. If whistling occurs, it may take a brief moment of holding the telephone in
the same position before the hearing instrument adapts and reduces the
feedback.
4. Any whistling may also be decreased by holding the telephone slightly away
from the ear.
5. Depending on your individual needs, your hearing care professional may
activate a programme specifically for telephone use.
400344000-GB-14.11-Rev.A.indd 20 10-12-2014 11:22:30
![](/img.php?id=2482662&img=bg15.png)
21
Listen to radio or TV
When listening to the TV or the radio, start out by listening to news commentators since they usually speak
clearly, then try other programmes.
If you find it difficult to listen to TV or radio, your hearing care professional will be able to give you advice on
available wireless accessories to enhance your listening capabilities for TV and radio.
Using ReSound Hearing Instruments with iPhone®, iPad®, and iPod touch®
(ReSound LiNX2)
ReSound LiNX2 is a Made for iPhone instrument and allows for direct communication and control with an
iPhone, iPad, or iPod touch. For assistance in pairing and using these products with your ReSound LiNX2
device, please contact your hearing care professional or visit our support site at www.resound.com/linx.
Cellular phones
Your hearing instrument is designed to comply with the most stringent Standards of International Electro-
magnetic Compatibility. However, not all cell phones are hearing instrument compatible. The varying de-
gree of disturbance can be due to the nature of your particular cellular phone or of your wireless telephony
service provider.
If you find it difficult to obtain a good result while using your cellular phone, your hearing care professional
will be able to give you advice on available wireless accessories to enhance listening capabilities.
400344000-GB-14.11-Rev.A.indd 21 10-12-2014 11:22:30
![](/img.php?id=2482662&img=bg16.png)
22
PhoneNow
The PhoneNow function, allows your hearing instrument to automatically
switch to your tele phone programme when a telephone receiver is raised
to the ear. When the telephone receiver is removed from the ear, the hear-
ing instrument automatically returns to the previous listening programme.
Placement of PhoneNow magnets
Place PhoneNow magnet on your telephone receiver to allow operation
of the PhoneNow function. In order to place PhoneNow magnet properly:
1. Clean the telephone receiver thoroughly.
2. Hold the telephone vertically, in a position similar to when making a telephone call.
3. Place the magnets just below the telephone receiver. Make sure not to cover the microphone openings.
If necessary, move the magnet to another position to improve ease of use and comfort while speaking.
4. If you are not satisfied with the strength of PhoneNow, you can reposition the PhoneNow magnet or add
additional PhoneNow magnets.PhoneNow usage
Telephones can be used in a normal manner. A short melody will indicate that the PhoneNow feature has
automatically switched the hearing instrument to your telephone programme. Initially, you may need to
move the telephone receiver slightly to find the best position for reliable PhoneNow activation and good
hearing on the telephone.
If you have two hearing instruments with the synchronization function enabled, the volume of hearing instru-
ment on the non-phone ear will be turned down.
i Only use recommended cleaning agent to clean the telephone prior to placing the magnet on the
phone in order to obtain best possible adherence.
400344000-GB-14.11-Rev.A.indd 22 10-12-2014 11:22:30
![](/img.php?id=2482662&img=bg17.png)
23
i PhoneNow warnings
1. Keep magnets out of reach of pets, children and mentally challenged persons. If a magnet is swallowed,
please seek advice from a medical practitioner.
2. The magnet may affect some medical devices or electronic systems. The manufacturer of any
magnetically sensitive devices (e.g. pacemakers) should advise you regarding appropriate safety
precautions when using your hearing instrument and magnet in close proximity to the medical device
or electronic system in question.If the manufacturer cannot issue a statement, we recommend keeping
the magnet or a telephone equipped with the magnet 30 cm (12”) away from magnetically sensitive
devices (e.g. pacemakers).
i PhoneNow precautions
1. High distortion during dialing or phoning may mean that the magnet is not in the optimal position relative
to the telephone receiver. To avoid the issue, please move the magnet to another place on the telephone
receiver.
2. Only use magnets supplied by ReSound.
400344000-GB-14.11-Rev.A.indd 23 10-12-2014 11:22:30
![](/img.php?id=2482662&img=bg18.png)
24
Telecoil (optional)
If equipped, a telecoil can be activated by your hearing care professional and accessed through one of
the additional programmes. A telecoil picks up a telephone’s magnetic signal and converts it to sound. An
optional telephone programme may help to improve speech understanding on the telephone. When using
a telecoil programme, the receiver of the telephone may need to be held closer to the hearing instrument.
The handset of the telephone may need to be moved to slightly different positions in order to find the best
reception.
Tele-loop systems
Many places, such as theatres, houses of worship, and schools are equipped with tele-loop systems. When
using a telecoil programme with tele-loop systems, sound is picked up directly and may improve speech
understanding. If there is no sound from the hearing instruments in a tele-loop system and with a telecoil
programme activated, the tele-loop system may not be turned on or is not operating correctly. If a facility is
not equipped with a tele-loop system, sitting as close as possible to the front may be helpful.
Direct audio input (optional)
Use of direct audio input (DAI), which enables a direct connection of the hearing instruments to items such
as television, radio, and remote microphones, may increase speech understanding for some individuals.
The sound source is connected to the hearing instruments by a cable or a wireless FM system to the audio
boot. This accessory connects to the bottom of the hearing instruments, and once properly clicked into
place, the hearing instruments switch to DAI automatically.
400344000-GB-14.11-Rev.A.indd 24 10-12-2014 11:22:30
![](/img.php?id=2482662&img=bg19.png)
12
3
45
25
Connecting/Disconnecting audio boots
Connecting audio boots
1. Align the tip of the audio boot with the groove
just above the battery compartment and below
the model number.
2. Once in place, move the boot in the direction of
the battery compartment.Gently click the audio
boot onto the hearing instrument.
Disconnecting audio boots
3. Press and hold the button on the
front side of the audio boot.
4. Gently remove the audio boot
from the hearing instrument.
400344000-GB-14.11-Rev.A.indd 25 10-12-2014 11:22:32
![](/img.php?id=2482662&img=bg1a.png)
26
i Care and maintenance
Please follow the following instructions to prolong the durability of your hearing instruments:
1. Keep your hearing instrument clean and dry. Wipe the case with a soft cloth or tissue after use to remove
grease or moisture. Do not use water or solvents, as these can damage the hearing instrument(s).
2. Never immerse hearing instruments in water or other liquids, as liquids may cause permanent damage
to the hearing instruments.
3. Avoid rough handling of hearing instruments or dropping them on hard surfaces or floors.
4. Do not leave hearing instruments in or near direct heat or sunlight, such as in a hot, parked car, as
excessive heat can cause damage or deform the casing.
5. Do not wear your instrument while showering, swimming, in heavy rain or in a moist atmosphere such
as a steam bath or sauna.If your instrument does get wet, or if it has been exposed to high humidity
or perspiration, it should be left to dry out overnight with the battery out and the battery compartment
open. It is also a good idea to put the instrument and battery in a sealed container together with a drying
agent (desiccator) overnight. Do not use the instrument until it is completely dry. Consult your hearing
care professional as to which drying agent to use.
6. Remove your hearing instrument when applying such things as cosmetics, perfume, aftershave, hair
spray, and suntan lotion. These might get into the instrument and cause damage.
400344000-GB-14.11-Rev.A.indd 26 10-12-2014 11:22:32
![](/img.php?id=2482662&img=bg1b.png)
27
i Daily maintenance
It is important to keep your hearing instrument clean and dry.
On a daily basis, clean the hearing instruments using a soft
cloth or tissue.
400344000-GB-14.11-Rev.A.indd 27 10-12-2014 11:22:32
![](/img.php?id=2482662&img=bg1c.png)
28
The receiver tube
The receiver tube contains the wiring to the receiver which delivers the sound to the ear canal. It is important
that the receiver tube and the receiver dome/RIE mold fits correctly in your ear. If the receiver tube or the
receiver dome/RIE mould irritates your ear in any way and prevents you from wearing your hear ing instru-
ment, please contact your hearing care pro fessional. You should never attempt to modify the shape of the
receiver tube yourself. The receiver tube and the receiver dome/RIE mould should be cleaned regularly.
Please see instructions in the next section.
i Cleaning the receiver tubes and domes
The receiver tube and the receiver dome should be cleaned regularly. Use a damp cloth to clean the re-
ceiver tube and receiver dome on the outside. Do not use water when you are cleaning the receiver tubes
or the receiver domes. This process is also used to clean the UP receiver mould. Please see instruction on
page 30 or 31 for how to change the wax guard filter.
i Cleaning RIE or moulds
1. Separate the mould from the receiver tube.
2. Clean the RIE mould using a mild soap, and rinse with lukewarm
water.
3. After cleaning, dry RIE moulds thoroughly and remove any residual
water and debris from the tubing utilising an air bulb and wire loop.
400344000-GB-14.11-Rev.A.indd 28 10-12-2014 11:22:32
![](/img.php?id=2482662&img=bg1d.png)
29
Changing wax guard for receiver tube
For changing Cerustop (white) wax filters, the following steps are needed:
1. To remove the old wax guard, insert the removal side of the wax guard tool into the used wax guard so
that the shaft of the tool is touching the rim of the wax guard. Slowly pull the wax guard straight out.
2. To insert the new wax guard, gently press the replacement side of the wax guard tool straight into the
hole of the sound outlet until the outer ring lies flush with the outside of the receiver. Pull the tool straight
out -the new wax guard will remain in place.
400344000-GB-14.11-Rev.A.indd 29 10-12-2014 11:22:32
![](/img.php?id=2482662&img=bg1e.png)
12
30
How to apply domes
It is recommended that your hearing care
professional change domes, as incorrect
dome replacement could result in injury.
ReSound standard domes
1. Push the new dome over the receiver.
2. Make sure that the new dome is
properly and securely mounted.
ReSound tulip domes
Tulip domes are mounted in a similar manner to standard domes, but a few extra steps are required. Tulip
domes consist of two “petals”. It is important to note that the largest petal is the outermost petal. To ensure
this:
1. Push the largest petal away from
the receiver tube using a finger. This
bends the petal forward.
2. Then push the largest “petal” back,
and it will be placed on top of the
smaller petal.
400344000-GB-14.11-Rev.A.indd 30 10-12-2014 11:22:33
![](/img.php?id=2482662&img=bg1f.png)
31
Using ReSound hearing instruments with smart phone apps
i Intended use of smart phone apps:
GN ReSound smart phone apps are intended to be used with GN ReSound wireless hearing aids. GN Re-
Sound smart phone apps send and receive signals from the GN ReSound wireless hearing aids via smart
phones for which the apps have been developed.
Use with smart phone apps:
• Notifications of app updates should not be disabled, and it is recommended that the user installs all
updates to ensure that the app will function correctly and will be kept up to date.
• The app must only be used with GN ReSound devices for which it is intended, and GN ReSound take
no responsibility if the app is used with other devices.
• If you would like a printed version of the user guide for a smart phone app please consult customer sup-
port or our website to obtain a printed user guide.
400344000-GB-14.11-Rev.A.indd 31 10-12-2014 11:22:33
![](/img.php?id=2482662&img=bg20.png)
32
i General precautions
1. When wireless function is activated, the device uses low-powered digitally coded transmissions in
order to communicate with other wireless devices. Although unlikely, nearby electronic devices may be
affected. In that case, move the hearing instrument away from the affected electronic device.
2. When using wireless functionality and the devices are affected by electromagnetic interference, move
away from the source.
3. Use only original GN ReSound consumables e.g. tubes and domes.
4. Never attempt to modify the shape of the hearing instrument, ear-moulds, or tubing yourself.
5. Do only connect ReSound hearing instruments to ReSound accessories intended and qualified to be
used with ReSound hearing instruments.
i General warnings
1. Special care should be exercised in selecting and fitting a hearing instrument(s) who’s maximum sound
pressure level exceeds 132 dB SPL (with an IEC 60711:1981 occluded ear simulator), because there
may be a risk of impairing the remaining hearing of the hearing instrument user
2. Consult a hearing care professional if you discover a foreign object in your ear canal, if you experience
skin irritation, or if excessive ear wax accumulates with the use of the hearing instrument.
3. Different types of radiation, from e.g. NMR, MRI, or CT scanners, may damage hearing instruments. It
is recommended not to wear hearing instruments during these or other similar procedures. Other types
of radiation, such as burglar alarms, room surveillance systems, radio equipment, mobile telephones,
contain less energy and will not damage hearing instruments. However, they have the potential to
momentarily affect the sound quality or temporarily create strange sounds from hearing instruments.
4. Do not wear hearing instruments in mines, oil fields, or other explosive areas unless those areas are
certified for hearing instrument use.
400344000-GB-14.11-Rev.A.indd 32 10-12-2014 11:22:33
![](/img.php?id=2482662&img=bg21.png)
33
5. Do not allow others to use your hearing instruments. This may cause damage to the hearing instruments
or to the hearing of the other individual.
6. Instrument usage by children or mentally challenged persons should be supervised at all times to
ensure their safety.The hearing instrument contains small parts that could be swallowed by children.
Please be mindful not to leave children unsupervised with this hearing instrument.
7. Hearing instruments should be used only as prescribed by your hearing care professional. Incorrect
use may result in hearing loss.
7. External devices connected to the electrical input must be safe according to the requirements of IEC
60601-1-1, IEC 60065, or IEC 60950-1, as appropriate (wired connection, f.ex. HI-PRO), SpeedLink).
8. If device is broken, do not use.
9. Be careful when boarding flights, to remember to deactivate the wireless functionality. Turn off your
wireless functionality by using the flight mode in areas where radio frequency emission is prohibited.
i Note:
* ReSound wireless devices operate in the frequency range of 2.4 GHz - 2.48 GHz.
* ReSound wireless devices include a RF transmitter that operates in the range of 2.4 GHz - 2.48 GHz.
* For use of wireless functionality only use ReSound Unite accessories. For further guidance regarding e.g.
pairing, please refer to the user guide of the relevant ReSound Unite accessory.
400344000-GB-14.11-Rev.A.indd 33 10-12-2014 11:22:34
![](/img.php?id=2482662&img=bg22.png)
34
Tinnitus Sound Generator (TSG) module
Intended use for the TSG module
Your ReSound hearing instruments may also include the Tinnitus Sound Generator function, a tool for gen-
erating sounds to be used in tinnitus management programmes to relieve suffering from tinnitus.
The Tinnitus Sound Generator can generate sounds adjusted to the specific therapeutic needs and your
personal preference as determined by your doctor, audiologist, or hearing care professional. Depending
on the selected hearing instrument program and the environment you are in, you will sometimes hear the
therapeutic sound resembling a continuous or fluctuating whistling.
User instructions for the TSG module
Description of the device
The Tinnitus Sound Generator (TSG) Module is a software tool that generates sounds to be used in tinnitus
management programmes to relieve suffering from tinnitus.
Explanation of how the device functions
The TSG module is a frequency and amplitude shaped white-noise generator. Noise signal level and fre-
quency characteristics can be adjusted to the specific therapeutic needs as determined by your doctor,
audiologist or hearing healthcare professional.
Your doctor, audiologist or hearing healthcare professional can modulate the generated noise with the
purpose of making it more pleasant. The noise can then resemble, for example, crushing waves on a shore.
Modulation level and speed can also be configured to your likes and needs.
If your tinnitus troubles you only in quiet environments, your doctor, audiologist or hearing healthcare pro-
400344000-GB-14.11-Rev.A.indd 34 10-12-2014 11:22:34
![](/img.php?id=2482662&img=bg23.png)
35
fessional can set the TSG Module so that it becomes audible exclusively in such surroundings. The overall
sound level can be adjusted via an optional volume control. Your doctor, audiologist or hearing healthcare
professional will review with you the need for having such a control.
TSG volume control
The sound generator is set to a specific loudness level by the hearing healthcare professional. When switch-
ing the sound generator on, the volume will have this optimal setting. Therefore, it might not be necessary
to control the volume (loudness) manually. However, the volume control provides the ability to adjust the
volume, or amount of stimulus, to the liking of the user.
400344000-GB-14.11-Rev.A.indd 35 10-12-2014 11:22:34
![](/img.php?id=2482662&img=bg24.png)
36
The scientific concepts that form the basis for the device
The TSG Module provides sound enrichment with the aim of surrounding the tinnitus sound with a neutral
sound which is easily ignored. Sound enrichment is an important component of most approaches to tin-
nitus management, such as Tinnitus Retraining Therapy (TRT). To assist habituation to tinnitus, this needs
to be audible. The ideal level of the TSG module, therefore, should be set so that it starts to blend with the
tinnitus, and so that you can hear both your tinnitus as well as the sound used.
In a majority of instances, the TSG module can also be set to mask the tinnitus sound, so to provide tem-
porary relief by introducing a more pleasant and controllable sound source.
Technical Specifications
Audio signal technology
Digital
Available sounds
White noise signal which can be shaped with the following configurations:
The white noise signal can be modulated in amplitude with an attenuation depth of up to 14dB.
High-pass filter Low-pass filter
500 Hz 2000 Hz
750 Hz 3000 Hz
1000 Hz 4000 Hz
1500 Hz 5000 Hz
2000 Hz 6000 Hz
400344000-GB-14.11-Rev.A.indd 36 10-12-2014 11:22:34
![](/img.php?id=2482662&img=bg25.png)
37
i TSG warnings
• Sound generators can be dangerous if improperly used.
• Sound generators should be used only as advised by your doctor, audiologist, or hearing healthcare
professional.
• Sound generators are not toys and should be kept out of reach of anyone who might cause themselves
injury (especially children and pets).
i TSG precautions
• Should the user develop any side effects from using the sound generator, such as dizziness, nausea,
headaches, perceived decrease in auditory function or increase in tinnitus perception, the user should
discontinue use of the sound generator and seek medical evaluation.
• Children and physically or mentally challenged users will require guardian supervision while wearing the
TSG hearing instrument.
• The volume control is an optional feature in the TSG module used for adjusting the sound generator
output level. To prevent unintended usage by pediatric or physically or mentally challenged users, the
volume control must, if enabled, be configured to only provide a decrease of the sound generator output
level.
400344000-GB-14.11-Rev.A.indd 37 10-12-2014 11:22:34
![](/img.php?id=2482662&img=bg26.png)
38
i TSG warning to hearing healthcare professionals
A hearing healthcare professional should advise a prospective sound generator user to consult promptly
with a licensed physician (preferably an ear specialist) before getting a sound generator if the hearing
healthcare professional determines through inquiry, actual observation, or review of any other available
information concerning the prospective user that the prospective user has any of the following conditions:
(i) Visible congenital or traumatic deformity of the ear.
(ii) History of active drainage from the ear within the previous 90 days.
(IIi) History of sudden or rapidly progressive hearing loss within the previous 90 days.
(iv) Acute or chronic dizziness.
(v) Unilateral hearing loss of sudden or recent onset within the previous 90 days.
(vi) Audiometric air-bone gap equal to or greater than 15dB at 500 hertz (Hz), 1000 Hz, and 2000 Hz.
(vii) Visible evidence of significant cerumen accumulation or a foreign body in the ear canal.
(viii) Pain or discomfort in the ear.
i CAUTION: The maximum output of the sound generator falls into the range that can cause hearing
loss according to OSHA regulations. The user should not use the sound generator for more than eight (8)
hours a day when this is set below 90dB SPL. Above that level, the device should not be used for more than
two (2) hours per day. In no case should the sound generator be worn at uncomfortable levels.
400344000-GB-14.11-Rev.A.indd 38 10-12-2014 11:22:34
![](/img.php?id=2482662&img=bg27.png)
39
i Battery warning information
Batteries, although very small, contain dangerous substances, and should be disposed of carefully. This is
for the safety of you and the environment. Please note:
1. Do not attempt to recharge batteries (Zinc Air) which are not specifically designated as rechargeable
because they may leak or explode.
2. DO NOT attempt to dispose of batteries by burning them. Used batteries are harmful to the environment.
Please dispose of them according to local regulations or return them to your hearing care practitioner.
3. DO NOT place batteries in your mouth. Consult a physician immediately if a battery has been swallowed,
as they can be harmful to your health.
4. Keep batteries away from pets, children and mentallly challenged persons.
5. Remove the batteries to prevent leakage when the hearing instruments are not in use for an extended
period of time.
i Hearing instrument expectations
A hearing instrument will not restore normal hearing and will not prevent or improve a hearing impairment
resulting from organic conditions. Consistent use of the hearing instrument is recommended. In most cases,
infrequent use does not permit you to attain full benefit from it.
The use of a hearing instrument is only part of hearing rehabilitation and may need to be supplemented by
auditory training and instructions in lip-reading.
400344000-GB-14.11-Rev.A.indd 39 10-12-2014 11:22:34
![](/img.php?id=2482662&img=bg28.png)
40
i Warning to hearing aid dispensers (US Only)
A hearing aid dispenser should advise a prospective hearing aid user to consult promptly with a licensed
physician (preferably an ear specialist) before dispensing a hearing aid if the hearing aid dispenser de-
termines through inquiry, actual observation, or review of any other available information concerning the
prospective user, that the prospective user has any of the following conditions:
(i) Visible congenital or traumatic deformity of the ear.
(ii) History of active drainage from the ear within the previous 90 days.
(iii) History of sudden or rapidly progressive hearing loss within the previous 90 days.
(iv) Acute or chronic dizziness.
(v) Unilateral hearing loss of sudden or recent onset within the previous 90 days.
(vi) Audiometric air-bone gap equal to or greater than 15 decibels at 500 hertz (Hz),
1,000 Hz, and 2,000 Hz.
(vii) Visible evidence of significant cerumen accumulation or a foreign body in the ear canal.
(viii) Pain or discomfort in the ear.
Important notice for prospective hearing aid users (US Only)
Good health practice requires that a person with a hearing loss have a medical evaluation by a licensed
physician (preferably a physician who specializes in diseases of the ear) before purchasing a hearing aid.
Licensed physicians who specialize in diseases of the ear are often referred to as otolaryngologists, otolo-
gists or otorhinolaryngologists. The purpose of medical evaluation is to assure that all medically treatable
conditions that may affect hearing are identified and treated before the hearing aid is purchased.
Following the medical evaluation, the physician will give you a written statement that states that your hear-
ing loss has been medically evaluated and that you may be considered a candidate for a hearing aid. The
physician will refer you to an audiologist or a hearing aid dispenser, as appropriate, for a hearing aid evalu-
400344000-GB-14.11-Rev.A.indd 40 10-12-2014 11:22:34
![](/img.php?id=2482662&img=bg29.png)
41
ation. The audiologist or hearing aid dispenser will conduct a hearing aid evaluation to assess your ability
to hear with and without a hearing aid. The hearing aid evaluation will enable the audiologist or dispenser
to select and fit a hearing aid to your individual needs. If you have reservations about your ability to adapt
to amplification, you should inquire about the availability of a trial-rental or purchase-option program. Many
hearing aid dispensers now offer programs that permit you to wear a hearing aid for a period of time for a
nominal fee after which you may decide if you want to purchase the hearing aid.
Federal law restricts the sale of hearing aids to those individuals who have obtained a medical evaluation
from a licensed physician. Federal law permits a fully informed adult to sign a waiver statement declining the
medical evaluation for religious or personal beliefs that preclude consultation with a physician. The exercise
of such a waiver is not in your best health interest and its use is strongly discouraged.
Children with hearing loss (US Only)
In addition to seeing a physician for a medical evaluation, a child with a hearing loss should be directed to
an audiologist for evaluation and rehabilitation since hearing loss may cause problems in language develop-
ment and the educational and social growth of a child. An audiologist is qualified by training and experience
to assist in the evaluation and rehabilitation of a child with a hearing loss.
400344000-GB-14.11-Rev.A.indd 41 10-12-2014 11:22:34
![](/img.php?id=2482662&img=bg2a.png)
42
SYMPTOM CAUSE
No sound Not turned on
Dead battery
Battery door will not close
Blocked RIE mould or tube
Blocked wax filter
Not loud enough Incorrect RIE mould placement
Blocked RIE mould or dome
Change in hearing sensitivity
Excessive ear wax
Volume set too low
POSSIBLE REMEDY
Turn on by closing the battery door
Replace battery
Insert battery properly
Clean RIE mould or tube
Replace wax filter or consult your hearing care professional
Reinsert RIE mould
Clean RIE mould, replace dome, replace filter
Consult your hearing care professional
Consult your hearing care professional
Consult your hearing care professional
Troubleshooting Guide
400344000-GB-14.11-Rev.A.indd 42 10-12-2014 11:22:34
![](/img.php?id=2482662&img=bg2b.png)
43
SYMPTOM CAUSE
No sound Not turned on
Dead battery
Battery door will not close
Blocked RIE mould or tube
Blocked wax filter
Not loud enough Incorrect RIE mould placement
Blocked RIE mould or dome
Change in hearing sensitivity
Excessive ear wax
Volume set too low
POSSIBLE REMEDY
Turn on by closing the battery door
Replace battery
Insert battery properly
Clean RIE mould or tube
Replace wax filter or consult your hearing care professional
Reinsert RIE mould
Clean RIE mould, replace dome, replace filter
Consult your hearing care professional
Consult your hearing care professional
Consult your hearing care professional
400344000-GB-14.11-Rev.A.indd 43 10-12-2014 11:22:34
![](/img.php?id=2482662&img=bg2c.png)
44
SYMPTOM CAUSE
Excessive whistling /
feedback
Incorrect RIE mould placement
Incorrect dome placement
Excessive ear wax
Feedback control may need adjustment
RIE mould tubing worn or damaged
Hearing instrument settings not optimal
Sound distorted /
not clear
Weak battery
Improper RIE mould or dome fit
Hearing instrument damaged
Hearing instrument settings not optimal
Wireless does not work Possible Root Cause - Device is in flight mode
POSSIBLE REMEDY
Re-insert RIE mould carefully
Re-insert dome
Consult your hearing care professional
Consult your hearing care professional
Consult your hearing care professional
Consult your hearing care professional
Replace battery
Consult your hearing care professional
Consult your hearing care professional
Consult your hearing care professional
Open and close the battery compartment once. Wireless will reactivate 10 seconds later.
(If Root Cause is device in flight mode)
Troubleshooting Guide
400344000-GB-14.11-Rev.A.indd 44 10-12-2014 11:22:34
![](/img.php?id=2482662&img=bg2d.png)
45
SYMPTOM CAUSE
Excessive whistling /
feedback
Incorrect RIE mould placement
Incorrect dome placement
Excessive ear wax
Feedback control may need adjustment
RIE mould tubing worn or damaged
Hearing instrument settings not optimal
Sound distorted /
not clear
Weak battery
Improper RIE mould or dome fit
Hearing instrument damaged
Hearing instrument settings not optimal
Wireless does not work Possible Root Cause - Device is in flight mode
POSSIBLE REMEDY
Re-insert RIE mould carefully
Re-insert dome
Consult your hearing care professional
Consult your hearing care professional
Consult your hearing care professional
Consult your hearing care professional
Replace battery
Consult your hearing care professional
Consult your hearing care professional
Consult your hearing care professional
Open and close the battery compartment once. Wireless will reactivate 10 seconds later.
(If Root Cause is device in flight mode)
If there are any other problems not mentioned in this guide, please contact your hearing care professional.
400344000-GB-14.11-Rev.A.indd 45 10-12-2014 11:22:34
![](/img.php?id=2482662&img=bg2e.png)
46
Reference test gain (60 dB SPL input) HFA 31 dB
Full-on gain (50 dB SPL Input) Max
HFA
52
43
dB
dB
Maximum output (90 dB SPL input) Max
HFA
113
108
dB SPL
dB SPL
Total harmonic distortion
500 Hz
800 Hz
1600 Hz
0.3
0.5
0.7
%
%
%
Telecoil sensitivity (SPLIV @ 31,6 mA/m) 90 dB SPL
Equivalent input noise (w/o noise reduction) 23 dB SPL
Frequency range (DIN 45605) 100–
7060 Hz
Current drain (in test mode) 1.3 mA
RIE - LP receiver
Models: LS962-DRW, LS762-DRW, LS562-DRW
LS961-DRW, LS761-DRW, LS561-DRW
Frequency (Hz)
FULL-ON AND REFERENCE TEST GAIN
Gain
(dB)
Reference test gain
60 dB SPL input
Full-on gain
50 dB SPL input
2cc Coupler
MAXIMUM OUTPUT (OSPL 90)
Frequency (Hz)
Output
(dB SPL)
2cc Coupler
Data in accordance with ANSI S3.22–2009 and IEC 60118-7;
Supply Voltage 1.3 V, 2cc coupler
Note: Telecoil sensitivity only applicable for 62 RIE models
Technical data
400344000-GB-14.11-Rev.A.indd 46 10-12-2014 11:22:34
![](/img.php?id=2482662&img=bg2f.png)
47
FULL-ON AND REFERENCE TEST GAIN
MAXIMUM OUTPUT (OSPL 90)
MAXIMUM OUTPUT (OSPL 90)
Note: Telecoil sensitivity only applicable for 62 RIE models
Reference test gain (60 dB SPL input) HFA 37 dB
Full-on gain (50 dB SPL Input) Max
HFA
58
51
dB
dB
Maximum output (90 dB SPL input) Max
HFA
116
114
dB SPL
dB SPL
Total harmonic distortion
500 Hz
800 Hz
1600 Hz
0.5
0.6
1.2
%
%
%
Telecoil sensitivity (SPLIV @ 31.6 mA/m) 96
dB SPL
Equivalent input noise (w/o noise reduction) 23
dB SPL
Frequency range (DIN 45605) 100–
7000
Hz
Current drain (in test mode) 1.3 mA
RIE—MP receiver
Models: LS762-DRW, LS762-DRW, LS562-DRW
LS961-DRW, LS761-DRW, LS561-DRW
Frequency (Hz)
Gain
(dB)
Reference test gain
60 dB SPL input
Full-on gain
50 dB SPL input
2cc Coupler
Frequency (Hz)
Output
(dB SPL)
2cc Coupler
Data in accordance with ANSI S3.22–2009 and IEC 60118-7;
Supply Voltage 1.3 V, 2cc coupler
400344000-GB-14.11-Rev.A.indd 47 10-12-2014 11:22:35
![](/img.php?id=2482662&img=bg30.png)
48
Reference test gain (60 dB SPL input) HFA 42 dB
Full-on gain (50 dB SPL Input) Max
HFA
65
56
dB
dB
Maximum output (90 dB SPL input) Max
HFA
122
118
dB SPL
dB SPL
Total harmonic distortion
500 Hz
800 Hz
1600 Hz
0.6
1.2
0.7
%
%
%
Telecoil sensitivity (SPLIV @ 31.6 mA/m) 101 dB SPL
Equivalent input noise (w/o noise reduction) 23 dB SPL
Frequency range (DIN 45605) 100–
6030 Hz
Current drain (in test mode) 1.3 mA
RIE—HP receiver
Models: LS962-DRW, LS762-DRW, LS562-DRW
LS961-DRW, LS761-DRW, LS561-DRW
Frequency (Hz)
Gain
(dB)
Reference test gain
60 dB SPL input
Full-on gain
50 dB SPL input
2cc Coupler
Frequency (Hz)
Output
(dB SPL)
2cc Coupler
Data in accordance with ANSI S3.22–2009 and IEC 60118-7;
Supply Voltage 1.3 V, 2cc coupler
FULL-ON AND REFERENCE TEST GAIN
MAXIMUM OUTPUT (OSPL 90)
Note: Telecoil sensitivity only applicable for 62 RIE models
400344000-GB-14.11-Rev.A.indd 48 10-12-2014 11:22:35
![](/img.php?id=2482662&img=bg31.png)
49
Reference test gain (60 dB SPL input) HFA 47 dB
Full-on gain (50 dB SPL Input) Max
HFA
75
64
dB
dB
Maximum output (90 dB SPL input) Max
HFA
129
124
dB SPL
dB SPL
Total harmonic distortion
500 Hz
800 Hz
1600 Hz
1.3
2.1
0.1
%
%
%
Telecoil sensitivity (SPLIV @ 31.6 mA/m) 107
dB SPL
Equivalent input noise (w/o noise reduction) 23
dB SPL
Frequency range (DIN 45605) 100–
4910 Hz
Current drain (in test mode) 1.2 mA
RIE—UP receiver
Models: LS962-DRW, LS762-DRW, LS562-DRW
LS961-DRW, LS761-DRW, LS561-DRW
Frequency (Hz)
Gain
(dB)
-
Reference test gain
60 dB SPL input
Full-on gain
50 dB SPL input
2cc Coupler
Frequency (Hz)
Output
(dB SPL)
2cc Coupler
Data in accordance with ANSI S3.22–2009 and IEC 60118-7;
Supply Voltage 1.3 V, 2cc coupler
FULL-ON AND REFERENCE TEST GAIN
MAXIMUM OUTPUT (OSPL 90)
MAXIMUM OUTPUT (OSPL 90)
Note: Telecoil sensitivity only applicable for 62 RIE models
400344000-GB-14.11-Rev.A.indd 49 10-12-2014 11:22:36
![](/img.php?id=2482662&img=bg32.png)
50
Warranty and repairs
ReSound provides a warranty on hearing instruments in the event of defects in workmanship or materials,
as described in applicable warranty documentation. In its service policy, ReSound pledges to secure func-
tionality at least equivalent to the original hearing instrument. As a signatory to the United Nations Global
Compact initiative, ReSound is committed to doing this in line with environment-friendly best practices.
Hearing instruments therefore, at ReSound’s discretion, may be replaced by new products or products
manufactured from new or serviceable used parts, or repaired using new or refurbished replacement parts.
The warranty period of hearing instruments is designated on your warranty card, which is provided by your
hearing care professional.
For hearing instruments that require service, please contact your hearing care professional for assistance.
ReSound hearing instruments that malfunction must be repaired by a qualified technician. Do not attempt
to open the case of hearing instruments, as this will invalidate the warranty.
Temperature test, transport and storage information
GN ReSound Hearing Instruments are subjected to various tests in temperature and damp heating cycling
between -25 °C and +70 °C according to internal and industry standards. During transport or storage, the
temperature should not exceed the limit values of -20 °C to 60 °C and relative humidity of 90% RH, non
condensing (for limited time). The air pressure between 500 and 1100 hPa is appropriate.
400344000-GB-14.11-Rev.A.indd 50 10-12-2014 11:22:36
![](/img.php?id=2482662&img=bg33.png)
51
Be aware of information marked with the warning symbol
WARNING points out a situation that could lead to serious injuries,
CAUTION indicates a situation that could lead to minor and moderate injuries
i Advice and tips on how to handle your hearing instrument better.
Equipment includes RF transmitter
Please ask your local hearing care professional
concerning disposal of your hearing instrument
i
ReSound LiNX2 is compatible with iPhone 6, iPhone 6 Plus, iPhone 5s,
iPhone 5c, iPhone 5, iPad Air 2, iPad Air, iPad (4th generation), iPad mini 3,
iPad mini 2, iPad mini with Retina display, iPad mini and iPod touch (5th
generation) using iOS 7.X or later. Apple, the Apple logo, iPhone, iPad
and iPod touch are trademarks of Apple Inc., registered in the U.S. and
other countries.
i “Made for iPhone” means that an electronic accessory has been
designed to connect specifically to iPhone and has been certified by the
developer to meet Apple performance standards. Apple is not responsible
for the operation of this device or its compliance with safety and regulatory
standards. Please note that the use of this accessory with iPhone may
affect wireless performance.
400344000-GB-14.11-Rev.A.indd 51 10-12-2014 11:22:37
![](/img.php?id=2482662&img=bg34.png)
Worldwide Headquarters
ReSound A/S
Lautrupbjerg 7
DK-2750 Ballerup, Denmark
Tel.: +45 45 75 11 11
Fax: +45 45 75 11 19
www.resound.com
CVR no. 55082715
United Kingdom
GN ReSound Ltd.
Kirtlington Business Centre
Portway
Kirtlington
Oxon OX5 3JA
Tel.: +44 1869 352 800
Fax: +44 1869 343 466
www.gnresound.co.uk
Australia
GN ReSound Pty. Ltd.
Unit R1 Regents Park Estate
391 Park Road
Regents Park NSW 2143
Tel.: (free) 1800 658 955
Fax: +61 2 9743 7472
www.gnresound.com.au
New Zealand
GN ReSound (NZ) Ltd.
12 Parkway Drive
Mairangi Bay
Auckland
Tel.: (free) 0800 900 126
Fax: (free) 0800 007 695
www.gnresound.co.nz
Any issues relating to the EU Medical Device Directive
93/42/EEC, or Council Directive 1999/5/EC on Radio
Equipment and Tele communications terminal equipment
should be directed to ReSound A/S
400344000-GB-14.11-Rev.A
400344000-GB-14.11-Rev.A.indd 52 10-12-2014 11:22:37
