IDT Technology BG201 SmartChip User Manual
IDT Technology Limited SmartChip
User Manual
![](/img.php?id=2272800&img=bg1.png)
Wireless
SmartClip
forCoaguChek®XS
meter
User
Manual
INTRODUCTION
Thank you for selecting our Wireless SmartClip for your
Roche®
Coagulation Meter, which is a transmission Wireless
SmartClip
accessory that can help you expand the meter from Infrared (IR)
to
Bluetooth Low Energy (BLE) transmission. This means the
testing
values can be transferred to a counterpart station, such as
2net
TM
Hub or some mobile devices through BLE technology. From now
on,
you can systematically monitor and manage your PT values
via
wireless
technology.
Mobile device with this logo is compatible with the
Wireless
SmartClip to achieve reliable transmission
linkage.
IMPORTANT Please thoroughly read this user manual for all
the
necessary information to operate your Wireless
SmartClip.
OVERVIEW
1. LED
light
2. Battery
compartment
3. ON/OFF
switch
4.
Clip
5. Non-slippery
pads
![](/img.php?id=2272800&img=bg2.png)
BATTERY
INSTALLATION
Battery is pre-installed in your BLE transmission Wireless
SmartClip
when you purchase. Please regularly check the battery and
replace
battery promptly as it may affect the transmission (refer to
LED
indicator table on page.
X).
To replace the
battery:
INSTALLATION
• Align the coagulation meter with the Wireless SmartClip
and
insert the meter into the Wireless SmartClip with
some
pressure until it clips into
place.
UNINSTALLATION
1. Unscrew the battery compartment cover using a
coin.
2. Remove the old battery and insert a new CR2032, 3V
lithium
battery. Make sure to place the battery in the
compartment
following the polarity
+
/
-
.
3. Return the compartment cover and screw it
tightly.
![](/img.php?id=2272800&img=bg3.png)
Status
Normal
Battery
Low
Battery
Critical
Battery
Power
on
On in
green
for
1
second
On in
green
for
1
second
Flashes in
red
three times
per
minute.
Start
mode
(pinging for
the
meter)
OFF
OFF
Flashes in
red
three times
per
minute.
Communicating
with
Meter/Hub
Flashes
in
green
once
per
second
Flashes
in
green and
red
alternatively
Flashes in
red
three times
per
minute.
Transmission
completed
Blue is on
for
5
seconds
Flashes
in
blue and
red
alternatively
Flashes in
red
three times
per
minute.
Transmission
fails
/
Lost
Flashes
in
red
Flashes in
red
very
quickly
Flashes in
red
three times
per
minute.
• Hold the Wireless SmartClip and pull the meter from the
left-
hand side with some
pressure.
OPERATION
After the Wireless SmartClip is installed onto the meter, you need
to
turn on the Wireless SmartClip to ensure the transmission
works.
Make sure you power up the coagulation meter in priority of
turning
on the Wireless
SmartClip.
The effective distance between a counterpart station, such
as
a
hub, and the coagulation meter should be not far from each
other
more than 10 meters or 32.8
feet
data from the Wireless SmartClip. Please wait until
the
connection has been re-established
automatically.
• Note: If you measured your prothrombin time (PT)
without
data transmission, the collected PT values will
be
automatically transmitted once a data connection will
be
established
again.
Turn off the Wireless
SmartClip:
• Slide the switch to OFF after having ensured a
successful
data
transmission
.
The effective distance between a counterpart station,
such
TM
Turn on the Wireless
SmartClip:
as a
2net
hub, and the Wireless SmartClip should be not far
from
• Slide the switch to ON. LED indicator lights up briefly
in
green (given a normal battery
status).
• Run a prothrombin time (PT) measurement with the
Roche
CoaguChek XS meter, as described in the operating
manual
of the
meter.
• Once the PT measurement result is shown on the display
of
the CoaguChek XS meter, please do not turn off the
meter,
until the data transmissions will start automatically (within
60
seconds), which will be indicated by a green flashing
LED.
• Ensure that the blue LED indicates that data
transmission
was successful (steady or flashing according to the
table
below).
• Once you saw the blue LED, your PT data has
been
transmitted
successfully.
• If there is no blue LED, please make sure that the
receiving
device (e.g. 2netTM hub) is turned on and able to receive
the
each other more than 10
meters.
LED
INDICATOR
![](/img.php?id=2272800&img=bg4.png)
connection
SPECIFICATIONS
Dimension
(L x W x
H)
84.5 x 131.5 x 36.6
mm
(3.3 x 5.2 x 1.5
inches)
Power
1 x CR2032 3V lithium
battery
Weight
52.8 g (1.86
oz)
Operating
temperature
10˚C to 40˚C (50˚F to
104˚F)
Storage
temperature
-25˚C to 70˚C (-13˚F to
158˚F)
CARE
INSTRUCTIONS
To ensure you use your product correctly and safely, read
these
warnings and the entire user manual before using the
product:
• Do not wrap the Wireless SmartClip in a wet towel, nor with
other
wet materials. Use a soft, slightly moistened
cloth.
• Do not place or wash the Wireless SmartClip under
running
water instead clean it with a wet
cloth.
• Do not store the Wireless SmartClip in a hot (about 50°C)
and
humid (about 90%)
environment.
• Do not subject the product to excessive force, shock,
dust,
temperature changes, or humidity. Never expose the product
to
direct sunlight for extended periods. Such treatment may
result
in malfunction. Do not tamper with the internal
components.
Doing so will terminate the product warranty and may
cause
damage. The main unit contains no user-serviceable
parts.
• Take precautions when handling the
battery.
• Remove the battery whenever you are planning to store
the
product for a long period of
time.
• When replacing the battery, use a new battery as specified
in
this user
manual.
• The product is a precision instrument. Never attempt to take
this
device apart. Contact the retailer or our customer
service
department if the product requires servicing (depends on
service
concept).
• Do not touch the exposed electronic circuitry, as there is
a
danger of electric
shock.
• Check all major functions following the User Manual if the
device
has not been used for a long
time.
• When disposing of this product, ensure that this is
done
according to the local
guidelines..
• Due to printing limitations, the displays shown in this
manual
may differ from the actual
display.
• The contents of this manual may not be reproduced without
the
permission of the
manufacturer.
The technical specifications for this product and the contents
of
the
user manual are subject to change without
notice.
CLEANING THE
SLEEVE
It is important to follow the procedures below to clean and
disinfect
the sleeve. Failure to follow these procedures may
cause
malfunction of the
sleeve.
Cleaning/Disinfecting the
Exterior
Use only the following items for cleaning/disinfecting the
Wireless
SmartClip for a contact time of >1
minute:
![](/img.php?id=2272800&img=bg5.png)
• 70% isopropyl
alcohol
• 10% Sodium hypochlorite solution (1 part bleach to 9
parts
deionized water, made fresh every 24
hours)
Do not use any other disinfectants/cleaning solutions
on
the
Wireless
SmartClip.
1. Clean/Disinfect the
Exterior
With the SmartClip powered off, wipe the SmartClip’s
exterior
clean.
• Do not let liquid accumulate near any opening. Make sure
that
no liquid enters the
SmartClip.
2. Dry the
Exterior
With a lint-free tissue, dry the
SmartClip.
• Wipe away residual moisture and fluids after cleaning
the
SmartClip.
• Allow wiped areas to dry for at least 10 minutes
before
performing a
test.
and Electronic Equipment). If you have any queries,
please
refer to the local authorities responsible for waste
disposal.
Used, fully discharged batteries must be disposed
of
in a specially labeled collection container, at
toxic
waste collection points or through an
electrical
retailer. You are under legal obligation to dispose
of
batteries
correctly.
You will find these markings on batteries containing
harmful
substances : Pb = battery containing lead, Cd =
battery
containing cadmium, Hg = battery containing mercury.
Please
dispose of the device in accordance with the
directive
2006/66/EC.
EU-DECLARATION OF
CONFORMITY
Hereby, we declare that BLE Wireless SmartClipor Roche
CoaguChek
XS® Coagulation Meter (model: BG201) is in compliance with
the
essential requirements and other relevant provisions of
Directive
1999/5/EC. A copy of the signed and dated Declaration of Conformity
is
available on request via our Roche Customer
Service.
DISPOSAL
If you need to dispose of the Wireless SmartClip, do so
in
accordance with the statutory regulations. Contact your
town
administration or a disposal
company.
Please dispose of the device in accordance with
the
directive 2002/96/EC – WEEE( Waste
Electrical
FCC / IC
STATEMENT
This device complies with Part 15 of the FCC Rules. Operation
is
subject to the following two conditions: (1) This device may not
cause
![](/img.php?id=2272800&img=bg6.png)
harmful interference, and (2) This device must accept any
interference
received, including interference that may cause undesired
operation.
WARNING Changes or modifications not expressly approved by
the
party responsible for compliance could void the user's authority
to
operate the
equipment.
NOTE This equipment has been tested and found to comply with
the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules.
These limits are designed to provide reasonable protection
against
harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio frequency
energy
and, if not installed and used in accordance with the instructions,
may
cause harmful interference to radio communications. However, there
is
no guarantee that interference will not occur in a particular installation.
If
this equipment does cause harmful interference to radio or
television
reception, which can be determined by turning the equipment off and
on,
the user is encouraged to try to correct the interference by one or
more
of the following
measures:
Reorient or relocate the receiving
antenna.
Increase the separation between the equipment and
receiver.
Connect
the equipment into an outlet on a circuit different from that
to
which the receiver is
connected.
Consult the dealer or an experienced radio / TV technician for
help.
DECLARATION OF CONFORMITY
The
following information is not to be used as contact for support
or
sales. Please visit our website at www.oregonscientific.com for
all
enquiries. (depends on service
concept)
We
Name: IDT Technology
Limited
declare that the
product
Product
No.:BG201
Product Name: BLE Wireless
SmartClip
for Roche® CoaguChek XS
Meter
Manufacturer: IDT Technology
Limited
Address: Block C, 9/F, Kaiser
Estate,
Phase 1, 41 Man Yue St., Hung Hom,
Kowloon,
Hong
Kong
