Portable Bluetooth® Speaker
Hot Joe II
user’s
manual
model #: PWS02
2014.10.2
3 17:04:45
+08'00'
![](/img.php?id=2433327&img=bg2.png)
What’s Included
Page 2 Page 3
Micro USB Cable
Thank you for purchasing
Hot Joe II [PWS02].
Portable Bluetooth® Speaker
Features
• Bluetooth 2.1 + A2DP, AVRCP
• Hands-free speakerphone
• Wireless range of up to 30 feet
• Stereo speakers with RealBass technology
• Easy USB charging
• Rechargeable Lithium Battery
• 3.5 mm auxilary input jack
Unpack the Hot Joe II and make sure all accessories are put
aside so they will not be lost.
Portable Speaker
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth
SIG, Inc.
hello.
2014.1
0.23
17:04:5
5
+08'00'
![](/img.php?id=2433327&img=bg3.png)
Page 5
Safety InformationContents
Page 4
Introduction
What’s Included
Safety Information
Getting Started
Location of Main Unit Controls
Operational Instructions
Charging the Unit
Power Up
Aux Input
Pairing Your Bluetooth Device
Music Playback Functions
Hands-free Speakerphone
Troubleshooting
Compliance with FCC Regulations
Warranty Information
Specifications
2
3
5
7
8
8
8
9
9
10
11
12
13
15
Important Safety Instructions
1. ATTACHMENTS - Do not use attachments not
recommended by the manufacturer.
2. WATER AND MOISTURE - The Hot Joe II should not
be used near water. For example: near a bathtub,
washbowl, kitchen sink, laundry tub, swimming pool or
in a wet basement.
3. VENTILATION - The Hot Joe II should be situated so
that its location or position does not interfere with
its proper ventilation. For example, it should not be
situated on a bed, sofa, rug or similar surface that
may block ventilation openings. Also, it should not be
placed in a built-in installation, such as a bookcase or
cabinet, which may impede the flow of air through the
ventilation openings.
4. OBJECTS AND LIQUID ENTRY - Care should be taken
so that external objects do not fall into and liquids are
not spilled onto any openings or vents located on the
product.
5. POWER SOURCE - The Hot Joe II should be connected
only to a power supply of the type described in the
operating instructions or as marked on the Hot Joe II.
If you are not sure, please consult the dealer or local
power company.
Please read all safety and operating instructions carefully
before installation and use, and keep these instructions
handy for future reference. Take special note of all warnings
listed in this user’s manual and on the Hot Joe II.
2014.10.
23
17:05:01
+08'00'
![](/img.php?id=2433327&img=bg4.png)
Page 6
Getting Started
Location of Main Unit Controls
1. LED indicators
2. Speakers
3. Hands-free / Power button
4. Previous song / Next song
5. Volume - / Volume +
6. Power ON/OFF switch
7. Micro USB charger
8. 3.5 mm AUX input
Page 7
Safety Information
6. HEAT - The Hot Joe II should be situated away from
heat sources such as radiators, heat registers, stoves
or other appliances (including amplifiers) that produce
heat.
7. SERVICING - The user should not attempt to service
the Hot Joe II beyond those methods described in the
user’s manual. Opening or removing covers will expose
you to dangerous voltage and other hazards. Service
methods not covered in the user’s manual should be
referred to qualified service personnel.
1
7
42
6
2
8
35
AUX IN
2014.10.23
17:05:08
+08'00'
![](/img.php?id=2433327&img=bg5.png)
Operational Instructions
Page 9
Page 8
Operational Instructions
AUX Input
Charging the Unit
Power Up
Pairing Your Bluetooth Device
Music Playback Functions
1. To Playback your music via the AUX IN port, plug
a standard stereo headphone cable (3.5mm, not
included) from your audio device to Hot Joe II and
begin playback on your audio device.
2. To increase or decrease the volume, press VOL + and
VOL – buttons.
Note: - The Skip/Hands-free button do not work with
external devices.
- The AUX input source will be automatically
selected when the auxiliary cable is connected.
- Once the auxiliary cable is disconnected, the unit
will switch back to Bluetooth mode.
1. Charge your Unit through any Micro USB Jack or wall
charger.
2. The LED indicator will turn red while charging.
3. Once the battery is fully charged the red indicator will
turn off.
Note: - Please charge the battery up to 4 hours before initial
use.
1. Slide the switch on the back of the speaker to the ON
position.
2. Press and hold the power button until you hear a sound
indicating the unit is ON and in Bluetooth pairing mode.
The LED indicator will turn blue and will be blinking.
3. To Power down your speaker, slide the button in the
back of the unit to OFF position.
1. Turn the unit ON on the unit. The Hot Joe II will beep
and the indicator will turn blue and will flash indicating
the unit is in pairing mode.
2. Navigate to the Bluetooth menu on your device and
begin searching for the available devices.
3. Select PWS02 from the list of results, and your device
will begin to pair. If the unit asks for a code, please enter
“0000”.
4. Once connected the speaker will beep and the blue
indicator will stop flashing.
• Press the Power button to Play and Pause the music.
• Press the Skip Buttons to skip to Next or Previous Song.
• Press the Vol+ or Vol - buttons to increase or decrease
the volume.
• Press and hold the Power button to turn the unit to
Standby mode.
2014.10.23
17:05:14
+08'00'
![](/img.php?id=2433327&img=bg6.png)
Troubleshooting
Page 10
Operational Instructions
Symptom
No power
Hands-free not
working
No sound
Solution
Raise the volume by
pressing the VOL +
button.
Make sure your device
is connected to the
speaker and playing
music.
Raise the volume level of
the connected device.
Set input source as AUX
IN or Bluetooth mode.
Recharge the battery.
Move the power switch to
ON position.
Set to Bluetooth mode
(Hands-free function
is only available in
Bluetooth mode)
Placing a Call
• To place a call simply initiate the call from your
Bluetooth connected phone and the call will
automatically be routed through your paired Hot Joe II
and the music will be stopped.
• When the call is terminated, the current music will be
resumed. The call can also be terminated by pressing
the Hands-free button.
Receiving a Call
• Press the Hands-free button to answer the call on your
speaker.
• Press and hold the Hands-free button to reject the call.
• To disconnect press the Hands-free button again.
Page 11
Hands-free Speakerphone
2014.10.23
17:05:19
+08'00'
![](/img.php?id=2433327&img=bg7.png)
Warranty Information
Page 13
Compliance with FCC Regulations
Page 12
The AT&T brands are used under license. Any repair,
replacement, or warranty service, and all questions about
this product should be directed to Concept 101 LLC at www.
att.com/electronics or call 1 (888) 920-8680 from the USA
or Canada.
Concept 101 LLC warrants to the original purchaser that the product will
be free from defects in material, parts and workmanship for the period
designated for this product. The warranty commences the day the
product is purchased and covers up to a period of one (1) year (90 days
of labor and 1 year parts). Concept 101 LLC agrees that it will, at its option,
replace the defective product with either a new or remanufactured
speaker equivalent to your original purchase during the warranty period.
Should the Parts warranty period exceed the Labor warranty period,
Concept 101 LLC will supply at no charge for the remainder of the Parts
warranty, any new or remanufactured replacement parts as required
by the product. During this period all labor and service charges will
become the responsibility of the customer.
Exclusions: This warranty does not apply to the appearance
or exterior of the product which may have been
damaged or defaced, altered or modified in design or
construction. This warranty does not apply if the serial
number is altered or removed, or if there is any damage
due to power line surge, user damage to the AC power
cord, connection to improper voltage source, general
misuse, accidents, or repair attempts by unauthorized
service agents. Other exclusions include ear pads,
rechargeable and non-rechargeable batteries.
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY
IS THE EXCLUSIVE REMEDY OF THE CUSTOMER; Concept
101 LLC SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY ON THIS PRODUCT, EXCEPT TO THE EXTENT
PROHIBITED BY APPLICABLE LAW. ANY IMPLIED WARRANTY OF
MERCHANTABILITY OF FITNESS FOR A PARTICULAR PURPOSE ON
THIS PRODUCT IS LIMITED TO THE DURATION OF THE WARRANTY.
Some states do not allow the exclusion or limitations of incidental
or consequential damages, or limitations on how long the warranty
lasts. In these cases the above exclusions or limitations may not
apply to you. This warranty gives you specific legal rights and you
may also have other rights which vary from state to state.
The user is cautioned that changes or modifications not expressly
approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
The equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can
radiate Radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
Radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to Radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver. -
Connect the equipment into an outlet on a circuit different from
which the receiver is connected.
- Consult the dealer or an experienced Radio/television technician
for assistance.
This equipment complies with FCC’s RF radiation exposure limits set
forth for an uncontrolled environment. The antenna(s) used for this
transmitter must be installed and operated to provide a separation
distance of at least 20 cm from all persons and must not be collocated or
operating in conjunction with any other antenna or transmitter. Installers
must ensure that 20 cm separation distance will be maintained between
the device (excluding its handset) and users.
THE SPECIFICATION AND EXTERNAL APPEARANCE OF THE
SPEAKERS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
Caution!
If at any time in the future you should need to dispose of
this product, please note that waste electrical products
should not be disposed of with household waste. Please
recycle where facilities exist. Check with your local
authority or retailer for recycling advice.
2014.1
0.23
17:05:2
5
+08'00'
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: 1) this device may not cause harmful interference, and
2) this device must accept any interference received, including interference that
may cause undesired operation.
![](/img.php?id=2433327&img=bg8.png)
Specifications
Page 15 Page 14
Warranty Information
- Bluetooth 2.1
- Bluetooth compatibility: Bluetooth 2.0 or above device
with A2DP/AVRCP
- Playing time: Up to 4 hours
- Charging time: 3 to 4 hours
- Impedance: 4 £
- Working distance: Up to 30 ft
Obtaining Service: To obtain service, product literature, supplies
or accessories please call 1 888-920-8680, or
visit our website, www.att.com/electronics,
to create a ticket for exchange/repair. Please
make sure to provide the date of purchase,
model number and a brief description of the
problem. Our customer service representative
will contact you or send detailed return
instructions.
Concept 101 LLC does not warrant that the Hot Joe II will work properly in all
environmental conditions, and makes no warranty and representation, either
implied or expressed, with respect to the quality, performance, merchantability, or
fitness for a particular purpose other than the purpose identified within this user’s
manual. Concept 101 LLC has made every effort to ensure that this user’s manual
is accurate and disclaims liability for any inaccuracies or omissions that may have
occurred. Information in this user’s manual is subject to change without notice
and does not represent a commitment on the part of Concept 101 LLC. Concept
101 LLC reserves the right to make improvements to this user’s manual and/or
to the products described in this user’s manual at any time without notice. If you
find information in this manual that is incorrect, misleading, or incomplete, please
contact us through our website.
2014.10.23
17:05:31
+08'00'
![](/img.php?id=2433327&img=bg9.png)
©2014 Concept 101 LLC. All Rights Reserved. AT&T and the AT&T logo are trademarks
of AT&T Intellectual Property licensed to Concept 101 LLC, New York, New York 10018.
Printed in China. Issue 2.0 AT&T 10/2014.
www.att.com/electronics
2014.10.23
17:05:36
+08'00'
