Miwa Lock ALFH Hotel Card Lock User Manual 03 ALFH
Miwa Lock Co., Ltd Hotel Card Lock 03 ALFH
User Manual
![](/img.php?id=804858&img=bg1.png)
Version 1.0
Miwa Lock Co., Ltd.
User Manual
Product Name Hotel Card Lock
Model ALFH
![](/img.php?id=804858&img=bg2.png)
1. Range of Application
1. Range of Application
1-1. Card Lock
This Specifications Manual applies to the ALFH card lock that is used as a key for the contactless IC
card “FeliCa” issued by special issuing machines.
* FeliCa® is a registered trademark of the Sony Corporation.
![](/img.php?id=804858&img=bg3.png)
2. Outline of Devices
2. Outline
2-1. Cards
The ALFH hotel card lock is used as a card key for the contactless IC card FeliCa.
* Please refer to “6. Appendix” for a list of the types of cards available.
(1) The FeliCa card issued by special issuing machines protects all the key data contained, so
the data is very difficult to copy, alter or forge.
(2) It is possible to combine various applications that utilize the features of FeliCa.
* Please inquire separately when uploading other applications.
2-2. Outline of Functions
2-2-1. Data Verification
(1) Unlocking can be performed simply by holding up the card near the Lock Antenna.
(2) Unlocking will occur only when the input data set up beforehand in the hotel card lock (room
number and time, etc) and the key data in the card key are compared and found to match the
information within the lock.
(3) When a re-issued card key is used in the lock, it becomes no longer possible to use the card.
* In the event of a lost card, once a re-issued card is used in the lock there is no chance of
use by somebody else trying to use the old card.
(4) When a valid card key is used, the “Decoding Lamp” will light up orange and the “Verification
OK” lamp will light up green, whereupon the door will be unlocked only for a previously set
time. If the card does not match the lock, the “Verification NG” lamp will light up red, and
the door will stay locked.
![](/img.php?id=804858&img=bg4.png)
2. Outline of Devices
2-2-2. Record of Use
(1) Up to 600 lock-opening operations using the card key are recorded from the most recent
date. Once 600 operations are recorded, new operations are recorded over old ones from
the beginning.
(2) Operations that show a verification error are also recorded up to 40 times in order of the
most recent date, as per the lock-opening operation.
2-2-3. Battery Power/Buzzer
(1) Four triple-A alkaline dry batteries are used, which will last about one and a half years (if
used 10 times per day).
(2) If the Master Card/Sub Master Card is used when the battery power runs low, the LED and
buzzer will inform the user that the batteries need replacing.
(3) The buzzer can be set in the “On” or “Off” position.
* Card Key Verification OK/NG needs to be set.
Conditions Alarm sound Initial setting
Card Key Verification OK Pi…
Card Key Verification NG Pi, pi… Off
Low Battery Power Pi, pi, pi… On
2-2-4. Other Functions
(1) IrDA communication function (infrared light communication) can be used when lock-setting
data entry/confirmation or record-of-use data confirmation is performed using a data input
unit.
(2) Lock-setting data and record-of-use data are stored in the flash memory so data will never
be lost even if the batteries within the lock run out.
(3) The lock clock will be backed up for about 5 minutes when the batteries are replaced.
![](/img.php?id=804858&img=bg5.png)
3. Regulatory Compliance
3. Regulatory Compliance
3-1. USA-Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference
received, including interference that may cause undesired operation.
Caution:
Any changes or modifications not expressly approved by the party responsible for product compliance
could void the user's authority to operate the equipment.
Labelling
MIWA LOCK Hotel Card Lock ALFH is labelled as below.
FCC ID: VBU -ALFH
The proposed FCC ID label format is to be placed on the module. If FCC ID is not visible when the
module is installed into the system, “Contains FCC ID: VBU -ALFH” shall be placed on the outside of final
host system.
![](/img.php?id=804858&img=bg6.png)
3-2. Europe
European Community Declaration of Conformity with Regard to the R&TTE Directive 1999/5/EC
The following standards were applied: (R&TTE Directive 1999/5/EEC)
- EN 301 489-1 V1.6.1 (2005-09) & EN 301 489-3 V1.4.1 (2002-08)
- EN 300 330-2 V1.3.1 (2006-04)
- EN 60950-1: 2001
The following CE mark is affixed to the device:
Declaration of Conformity with Regard to the R&TTE Directive 1999/5/EC
Hereby, MIWA LOCK CO., LTD. declares that this HOTEL CARD LOCK; ALFH is in compliance
with the essential requirements and other relevant provisions of Directive 1999/5/EC.
Česky
[Czech]
MIWA LOCK CO., LTD. Tímto prohlašuje, že tento HOTEL CARD LOCK; ALFH je ve shodě se základními
požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES.
Dansk
[Danish]
Undertegnede MIWA LOCK CO., LTD. Erklærer herved, at følgende udstyr HOTEL CARD LOCK; ALFH
overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
Deutsch
[German]
Hiermit erklärt MIWA LOCK CO., LTD. Dass sich das Gerät HOTEL CARD LOCK; ALFH in Übereinstimmung
mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG
befindet.
Eesti
[Estonian]
Käesolevaga kinnitab MIWA LOCK CO., LTD. Seadme HOTEL CARD LOCK; ALFH vastavust direktiivi
1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.
Español
[Spanish]
Por medio de la presente MIWA LOCK CO., LTD. Declara que el HOTEL CARD LOCK; ALFH cumple con los
requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
Ελληνική
[Greek]
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ MIWA LOCK CO., LTD. ΔΗΛΩΝΕΙ ΟΤΙ HOTEL CARD LOCK; ALFH ΣΥΜΜΟΡΦΩΝΕΤΑΙ
ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
Français
[French]
Par la présente MIWA LOCK CO., LTD. Déclare que l’appareil HOTEL CARD LOCK; ALFH est conforme aux
exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE.
![](/img.php?id=804858&img=bg7.png)
Italiano
[Italian]
Con la presente MIWA LOCK CO., LTD. dichiara che questo HOTEL CARD LOCK; ALFH è conforme ai
requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
Latviski
[Latvian]
Ar šo MIWA LOCK CO., LTD. deklarē, ka HOTEL CARD LOCK; ALFH atbilst Direktīvas 1999/5/EK
būtiskajām prasībām un citiem ar to saistītajiem noteikumiem.
Lietuvių
[Lithuanian]
Šiuo MIWA LOCK CO., LTD. deklaruoja, kad šis HOTEL CARD LOCK; ALFH atitinka esminius reikalavimus ir
kitas 1999/5/EB Direktyvos nuostatas.
Nederlands
[Dutch]
Hierbij verklaart MIWA LOCK CO., LTD. dat het toestel HOTEL CARD LOCK; ALFH in overeenstemming is
met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG.
Malti
[Maltese]
Hawnhekk, MIWA LOCK CO., LTD. , jiddikjara li dan HOTEL CARD LOCK; ALFH jikkonforma mal-ħtiġijiet
essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC.
Magyar
[Hungarian]
Alulírott, MIWA LOCK CO., LTD. nyilatkozom, hogy a HOTEL CARD LOCK; ALFH megfelel a vonatkozó
alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
Polski
[Polish]
Niniejszym, MIWA LOCK CO., LTD. , deklaruję, że HOTEL CARD LOCK; ALFH spełnia wymagania
zasadnicze oraz stosowne postanowienia zawarte Dyrektywie 1999/5/EC.
Português
[Portuguese]
MIWA LOCK CO., LTD. declara que este HOTEL CARD LOCK; ALFH está conforme com os requisitos
essenciais e outras disposições da Directiva 1999/5/CE.
Slovensko
[Slovenian]
MIWA LOCK CO., LTD. izjavlja, da je ta HOTEL CARD LOCK; ALFH v skladu z bistvenimi zahtevami in
ostalimi relevantnimi določili direktive 1999/5/ES.
Slovensky
[Slovak]
MIWA LOCK CO., LTD. týmto vyhlasuje, že HOTEL CARD LOCK; ALFH spĺňa základné požiadavky a všetky
príslušné ustanovenia Smernice 1999/5/ES.
Suomi
[Finnish]
MIWA LOCK CO., LTD. vakuuttaa täten että HOTEL CARD LOCK; ALFH tyyppinen laite on direktiivin
1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.
Svenska
[Swedish]
Härmed intygar MIWA LOCK CO., LTD. att denna HOTEL CARD LOCK; ALFH står I överensstämmelse med
de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.
