Pantech TX-180 Dual-Mode CDMA Cellular Phone User Manual
Pantech Co., Ltd. Dual-Mode CDMA Cellular Phone
Pantech >
Contents
User Manual
User ’s Guide
TX-180
TX-180 2004.9.3 7:32 PM 페이지1
TABLE OF CONTENTS
1
Chapter 1
Chapter 2
Chapter 3
Chapter 4
CHAPTER 1. BEFORE USING YOUR PHONE .................................5
INSIDE THE PACKAGE .....................................................................................6
HANDSET DESCRIPTION.................................................................................7
THE FUNCTION KEYS.............................................................................................8
DISPLAY INDICATORS ...........................................................................................9
BATTERY USAGE ...........................................................................................11
BATTERY INSTALLATION....................................................................................11
BATTERY REMOVAL.............................................................................................11
BATTERY CHARGING...........................................................................................12
POWER CONNECTION ......................................................................................12
PCS AND 1X BATTERY TIMES ...........................................................................13
BATTERY LIFE (FOR NEW BATTERY) ................................................................13
BATTERY HANDLING INFORMATION..........................................................14
DOs.........................................................................................................................14
DON’Ts...................................................................................................................14
CHAPTER 2. BASIC OPERATION ..................................................15
TURNING THE PHONE ON / OFF ..................................................................16
TURNING THE PHONE ON...................................................................................16
TURNING THE PHONE OFF..................................................................................16
ACCESSING THE MENU................................................................................17
MENU SUMMARY .........................................................................................18
BASIC FUNCTIONS ........................................................................................21
MAKING A CALL ...................................................................................................21
SPEAKER PHONE..................................................................................................22
PAUSE FEATURE ..................................................................................................22
ANSWERING A CALL............................................................................................23
3-WAY CALLING ...................................................................................................23
CALLER ID FUNCTION..........................................................................................24
CALL WAITING FUNCTION ..................................................................................24
ADJUSTING VOLUME..........................................................................................24
ETIQUETTE............................................................................................................25
KEY GUARD...........................................................................................................25
DURING A CALL .............................................................................................26
MESSAGING .........................................................................................................26
MUTE (UNMUTE)..................................................................................................26
SCRATCHPAD .......................................................................................................26
SEND MY PHONE # ..............................................................................................26
MY PHONE # .........................................................................................................27
VOICE PRIVACY.....................................................................................................27
LOCATION .............................................................................................................27
PHONE INFO..........................................................................................................27
MAKING AN EMERGENCY CALL ..................................................................28
911 IN LOCK MODE ..............................................................................................28
911 USING ANY AVAILABLE SYSTEM ...............................................................28
CHAPTER 3. MEMORY FUNCTION...............................................29
STORING A PHONE NUMBER ......................................................................30
ENTERING LETTERS, NUMBERS & SYMBOLS ...........................................31
STANDARD INPUT MODE....................................................................................32
T9 INPUT MODE....................................................................................................33
NUMERIC MODE...................................................................................................34
SYMBOL MODE ....................................................................................................34
MAKING A CALL THROUGH THE PHONE BOOK ........................................35
ONE-TOUCH/TWO-TOUCH DIALING...................................................................35
ONE-TOUCH DIALING:.......................................................................................35
TWO-TOUCH DIALING: ......................................................................................35
CHAPTER 4. MENU FUNCTION ....................................................37
PHONE BOOK .................................................................................................38
FIND .......................................................................................................................38
ADD NEW ..............................................................................................................39
GROUP...................................................................................................................39
ADD NEW GROUP .............................................................................................39
CHANGE GROUP NAME ....................................................................................40
ERASE GROUP ...................................................................................................40
SPEED DIAL ...........................................................................................................41
W E L C O M E
Thank you for choosing the up-to-date TX-180, our new
model, developed by top researchers to support the
CDMA2000 1X system through Qualcomm-manufactured
MSM6050 chips and CDMA technologies. This product allows
for high speed communication services, such as web browsing,
data services, and a GUI animation menu.
T9 input mode makes it much easier to enter text, while VR
(Voice Recognition) makes the TX-180 more user friendly.
Other proven technologies include:
Full graphic display of 9 text input lines and 1 icon line with
variable font size.
Easy to dial through the VR feature.
Easy to enter letters through the T9 text input mode.
Enhanced for web browsing & data services (i.e.; wireless
internet access, UP browser)
GUI & Animation display compliant with CDMA2000 1X.
CSTN 65K Color LCD.
Navigation Key and 21 keys aligned for more convenience.
Sophisticated features of speaker phone, and voice
recognition.
Additional services of text messaging and Web browsing on
top of authentication, call forwarding, call transfer, call
waiting.
IMPORTANT INFORMATION
This TX-180 user guide contains very important information
about how to handle and use the product.
Please read this manual thoroughly, pay attention to the
warranty on the back page and be alert to the exclusions and
limitations of your warranty, which are related with the
unauthorized use of components.
TX-180 2004.9.3 7:32 PM 페이지2
TABLE OF CONTENTS TABLE OF CONTENTS
3
2
Chapter 4
Chapter 6
Chapter 5
Chapter 4
SYSTEM.................................................................................................................77
SET MODE..........................................................................................................77
NAM SETTING ....................................................................................................77
PRL ID.................................................................................................................78
ERI BANNER.......................................................................................................78
PHONE INFO..........................................................................................................79
S/W VERSION.....................................................................................................79
H/W VERSION ....................................................................................................79
GET IT NOW VERSION.......................................................................................79
UTILITIES ........................................................................................................80
SCHEDULE.............................................................................................................80
ADD NEW PLAN.................................................................................................80
VIEW PLAN.........................................................................................................81
ALARM...................................................................................................................81
MEMO PAD............................................................................................................83
ADD MEMO........................................................................................................83
VIEW MEMO ......................................................................................................83
SETTINGS ...........................................................................................................83
CALCULATOR........................................................................................................84
WORLD CLOCK .....................................................................................................84
STOP WATCH........................................................................................................85
CHAPTER 5. VOICE SERVICE ........................................................87
VOICE TOOLS MENU .....................................................................................88
VOICE MEMO ........................................................................................................88
VOICE DIAL............................................................................................................89
TRAIN WORDS......................................................................................................90
YES .....................................................................................................................90
NO.......................................................................................................................90
WAKE-UP............................................................................................................91
UNDO TRAIN ALL...............................................................................................91
VOICE SETTING ....................................................................................................92
SET ACTIVE ........................................................................................................92
HFK MODE .........................................................................................................92
VOICE RECOGNITION MODE ........................................................................93
NAME.....................................................................................................................93
CHAPTER 6. VOICE MAIL AND TXT MESSAGING......................95
WHEN A NEW MESSAGE ARRIVES .............................................................96
VOICE MAIL ....................................................................................................96
NEW TXT MSG .........................................................................................................97
INBOX ........................................................................................................................98
REPLY .................................................................................................................98
REPLY WITH COPY ............................................................................................98
FORWARD..........................................................................................................99
SAVE MEDIA ......................................................................................................99
SAVE TO CONTACT............................................................................................99
SAVE TO SAVED.................................................................................................99
SAVE TO QUICK TEXT........................................................................................99
BLOCK SENDER .................................................................................................99
LOCK & UNLOCK ...............................................................................................99
OUTBOX..................................................................................................................100
CHECKING SENT TXT MESSAGES ...................................................................100
RESEND............................................................................................................100
EDIT MESSAGE ................................................................................................100
SAVE TO CONTACT..........................................................................................101
SAVE TO SAVED...............................................................................................101
LOCK & UNLOCK .............................................................................................101
STATE ...............................................................................................................101
WEB ALERTS...........................................................................................................102
SAVED .....................................................................................................................103
QUICK TEXT............................................................................................................104
ERASE ALL ..............................................................................................................105
ERASE MESSAGES.............................................................................................105
SETTINGS................................................................................................................106
SAVE SENT MSG ................................................................................................106
MSG. GROUP ........................................................................................................42
ADD NEW MSG. GROUP ...................................................................................42
CHANGE MSG. GROUP NAME..........................................................................42
SEND TEXT MSG. GROUP .................................................................................43
ERASE MSG. GROUP .........................................................................................43
MY PHONE # .........................................................................................................44
RECENT CALLS ..............................................................................................45
ALL CALLS.............................................................................................................45
MISSED CALLS .....................................................................................................46
RECEIVED CALLS..................................................................................................47
DIALED CALLS ......................................................................................................48
CALL TIMERS ........................................................................................................49
LAST CALL..........................................................................................................49
ALL CALLS..........................................................................................................49
HOME CALLS .....................................................................................................49
ROAM CALLS .....................................................................................................50
CUMULATIVE CALLS .........................................................................................50
1X PACKET COUNTER..........................................................................................51
RECEIVED...........................................................................................................51
TRANSMITTED ...................................................................................................51
TOTAL.................................................................................................................51
GET IT NOW ...................................................................................................52
START GET IT NOW .............................................................................................52
DOWNLOADING APPLICATIONS ........................................................................52
DOWNLOADING MELODIES/WALLPAPERS.......................................................52
APPLYING MELODIES/WALLPAPERS.................................................................53
CHECKING DATA FOLDER MEMORY..................................................................53
ERASING AN APPLICATION ................................................................................53
MOBILE WEB 2.0 ............................................................................................54
CONNECT WEB.....................................................................................................54
MEDIA GALLERY............................................................................................55
IMAGES .................................................................................................................55
GRAPHICS ..........................................................................................................55
ANIMATIONS......................................................................................................55
TONES ...................................................................................................................56
SETTINGS .......................................................................................................57
SOUNDS ................................................................................................................57
RINGER TYPE .....................................................................................................57
VOLUME.............................................................................................................58
ALERT .................................................................................................................59
ROAM RINGER...................................................................................................60
TONE LENGTH ...................................................................................................60
ETIQUETTE .........................................................................................................61
DISPLAY.................................................................................................................62
MENU STYLE......................................................................................................62
GRAPHICS ..........................................................................................................62
SUB SCREEN......................................................................................................64
GREETING MESSAGE ........................................................................................65
CONTRAST .........................................................................................................65
BACKLIGHT ........................................................................................................66
DATA SVC..............................................................................................................67
CONNECTION.....................................................................................................67
SECURITY ..............................................................................................................68
PHONE LOCK .....................................................................................................68
RESTRICT ...........................................................................................................68
CHANGE CODE ..................................................................................................70
SPECIAL #’S .......................................................................................................71
ERASE ALL .........................................................................................................71
RESET PHONE....................................................................................................72
OTHERS .................................................................................................................73
ANSWER OPTIONS ............................................................................................73
AUTO RETRY ......................................................................................................74
LANGUAGE.........................................................................................................75
VOICE PRIVACY..................................................................................................75
TTY MODE..........................................................................................................76
LOCATION ..........................................................................................................76
TX-180 2004.9.3 7:32 PM 페이지2
BEFORE USING
YOUR PHONE
C
H
.
1
5
This chapter provides important information about using the
TX-180 including:
Chapter 1
INSIDE THE PACKAGE
HANDSET DESCRIPTION
BATTERY USAGE
BATTERY HANDLING INFORMATION
TABLE OF CONTENT
4
Chapter 7
Chapter 8
AUTO ERASE.......................................................................................................106
INBOX ...............................................................................................................106
OUTBOX ...........................................................................................................106
DEFAULT CALLBACK..........................................................................................107
EDIT VOICE CALLBACK ......................................................................................107
REMIND ...............................................................................................................108
EDIT SIGNATURE................................................................................................108
DIRECT VIEW.......................................................................................................109
ENTRY MODE......................................................................................................109
BLOCK OR UNBLOCK .........................................................................................110
CHAPTER 7. MOBILE WEB 2.0 ....................................................111
LAUNCHING MOBILE WEB 2.0 ...................................................................112
ACCESS THE INTERNET.....................................................................................112
BROWSER MENU.........................................................................................112
HOME...................................................................................................................112
BACK ....................................................................................................................112
FORWARD ...........................................................................................................112
REFRESH..............................................................................................................113
HISTORY ..............................................................................................................113
ADDRESS.............................................................................................................113
CLEAR MEMORY.................................................................................................113
SETTINGS............................................................................................................113
ADVANCED..........................................................................................................114
EXIT......................................................................................................................114
CHAPTER 8. SAFETY AND WARRANTY ....................................115
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES ..............116
DRIVING SAFETY................................................................................................117
ELECTRONIC DEVICES .......................................................................................118
OTHER SAFETY GUIDELINES............................................................................119
PRECAUTIONS....................................................................................................120
SAFETY INFORMATION FOR FCC RF EXPOSURE ....................................121
CAUTIONS...........................................................................................................121
SAR INFORMATION.....................................................................................122
FDA CONSUMER UPDATE ..........................................................................124
PROTECT YOUR WARRANTY .....................................................................128
12 MONTH LIMITED WARRANTY ...............................................................129
“Licensed by QUALCOMM Incorporated under one or more of the following Patents : U.S.Patent No.
4,901,307 U.S.Patent No. 5,056,109 U.S.Patent No. 5,099,204 U.S. Patent No. 5,101,501 U.S. Patent No.
5,103,459 U.S. Patent No. 5,107,225 U.S.Patent No. 5,109,390.”
TX-180 2004.9.3 7:32 PM 페이지4
HANDSET DESCRIPTION
C
H
1
This package should include all items pictured below.
If any are missing or different, immediately contact the retailer
where you purchased the phone.
7
INSIDE THE PACKAGE
C
H
1
6
Handstrap
User Manual
AC Travel Charger
Handset
Standard Battery
Antenna
Earjack
Camera Button
Volume Key LCD Screen
Function Keys
Send Key
END/
Power Key
Microphone
Earpiece
Navigation Key
The TX-180 weighs 3.7oz. The dimensions are 1.83” x 4.48” x 0.97”.
Camera Lens
TX-180 2004.9.3 7:32 PM 페이지6
C
H
1
DISPLAY INDICATORS
9
C
H
1
THE FUNCTION KEYS
8
Press to make or receive a call.
Press and hold to turn on VR mode.
Press to clear a digit from the display or to return
to the previous page.
Press and hold to enable speaker phone mode.
Press and hold to enter lock mode.
Press and hold to enter etiquette mode.
Press to turn the phone on/off, to terminate a call
or to return to the initial page.
Signal Strength - Current signal strength: the
more lines, the stronger the signal.
Battery
Battery charging level – the more blocks, the
stronger the charge.
Roaming
Phone is out of home area.
Message
New TXT or voice message.
Digital mode
Phone is operating in digital mode.
Mute
Phone is mute during a call.
Silent
Appears when Silent is selected as the ring mode.
Emergency Call
Blinks when an emergency call is in progress.
Auto Answer
Phone is in answering machine mode.
Etiquette
Phone will vibrate when call is received.
Schedule
Appears when either an event or an alarm is set.
In Idle Mode
- Press Up to access the Phone Book,
Down to access the Messaging, Right
for Get It Now and Left for Mobile Web.
Inside the menu
- Within a menu, use to scroll through
menu options, or to select a function
displayed on the screen.
(Left Soft Key) Press to access the menu or
function displayed on bottom line.
(Right Soft Key) Press to access contact menu
or function displayed on bottom line.
HANDSET DESCRIPTION HANDSET DESCRIPTION
Display Indicators
See page 9 for a list of icons.
Soft Key Indicators
Shows the functions currently
assigned to each soft key and
displays some icons.
Text & Graphic area
Menu
Messaging
Get It NowMobile Web
Phone Book
Ring Mode
Appears when a ringer is selected as the
ring mode.
Contacts
Service Indicator
Indicates call is in progress, indicates the
phone cannot receive a signal from the system.
Speaker phone
Phone is in speaker phone mode.
Data Only
Receives an async. call as a voice call.
TX-180 2004.9.3 7:32 PM 페이지8
C
H
1
11
C
H
1
10
HANDSET DESCRIPTION BATTERY USAGE
Scratch Pad
Displays when scratchpad is in use during a call.
Unread Web Message
Phone has new Web Alert message.
Web Message + Text Message
Phone has Web Alert Msg and Text Msg.
Web Message + Voice Message
Phone has Web Alert Msg and Voice Msg.
Web Message + Text Message + Voice Message
Phone has Web Alert Msg, Text Msg and
Voice Msg.
UP Browser
Phone is in the progress of UP Browser.
1X
Phone is in the 1x service area.
GPS Icon
Indicates the Location Service of your phone is
disabled/enabled.
Dormant
Indicates your phone is in a dormant state during a
data call. Your phone goes to Dormant mode
when you have no had any activity on a page for
some time - your connection is still active and now
you can make and receive calls.
BATTERY INSTALLATION
1
uPlace the battery on the back of the handset
and slide into place. vPush the battery down
until it locks into place.
BATTERY REMOVAL
1
uPull down the release latch, lift up the
battery and vremove the battery from the
handset.
If the battery is not correctly placed in the compartment, the
handset will not turn on and/or the battery may detach during use.
TX-180 2004.9.3 7:32 PM 페이지10
C
H
1
13
C
H
1
12
BATTERY USAGE BATTERY USAGE
BATTERY LIFE (FOR NEW BATTERY)
The operating time is subject to your handset usage and configuration.
PCS AND 1X BATTERY TIMES
The operating time is subject to your handset usage and configuration.
These times are for a new battery. Usage and Standby time may
decrease over time.
• When you charge the battery with the phone power off, you
will see a charging status screen. You cannot operate the
phone until it is powered on.
• The battery is not charged at the time of purchase.
• Fully charge the battery before use.
• It is more efficient to charge the battery with the handset
powered off.
• The battery must be connected to the phone in order to charge it.
• Battery operating time gradually decreases over time.
• If the battery fails to perform normally, you may need to replace
the battery.
1
Plug the AC Charger into a standard outlet.
2
Plug the other end of the AC Charger into the
bottom of your phone. The battery must be
installed onto the phone.
BATTERY CHARGING
POWER CONNECTION
P C S
Up to 190 m
Up to 330 m
D C S
Up to 195 m
Up to 330 m
STD 1000 mAh
Battery Capacity
EXT 1700 mAh
P C S
150~250 Hours
380~450 Hours
D C S
107~150 Hours
160~220 Hours
STD 1000 mAh
Battery Capacity
EXT 1700 mAh
TX-180 2004.9.3 7:32 PM 페이지12
BATTERY HANDLING INFORMATION
BASIC OPERATION
This chapter addresses and explains the basic features of your phone
including:
Chapter 2
C
H
2
15
C
H
1
14
TURNING THE PHONE ON / OFF
ACCESSING THE MENU
MENU SUMMARY
BASIC FUNCTIONS
DURING A CALL
MAKING AN EMERGENCY CALL
l Only use the battery and charger approved by the
manufacturer.
l Only use the battery for its original purpose.
l Try to keep batteries in a temperature between 41ºF
(5ºC ) and 95ºF (35ºC).
l If the battery is stored in temperatures above or
below the recommended range, give it time to warm
up or cool down before using.
l Completely drain the battery before recharging.
It may take one to four days to completely drain.
l Store the discharged battery in a cool, dark, and dry
place.
l Purchase a new battery when its operating time
gradually decreases after fully charging.
l Properly dispose of the battery according to local
laws.
l Don’t attempt to disassemble the battery –
it is a sealed unit with no serviceable parts.
l Don’t accidentally short circuit the battery by
carrying it in your pocket or purse with other
metallic objects such as coins, clips and pens.
This may critically damage the battery.
l Don’t leave the battery in hot or cold temps.
Otherwise, it could significantly reduce the capacity
and lifetime of the battery.
l Don’t dispose of the battery into a fire.
DOs
DON’Ts
TX-180 2004.9.3 7:32 PM 페이지14
ACCESSING THE MENU
C
H
2
Your phone can be customized via the menu. Each function can be
accessed by scrolling with the Navigation Key or by pressing the
number that corresponds with the menu item.
1
To access the menu in the idle mode,
press [MENU].
2
Use the Navigation Key to scroll through the
menu.
3
To return to the previous page, press [CLR].
To exit the current menu and return to the idle
mode, press .
4
Press the Navigation Key to enter a function
when its main page is displayed or press its
assigned number to have direct access to
the function.
17
C
H
2
TURNING THE PHONE ON
1
Press and hold until your “Power On” logo
appears and the tone sounds.
• To select a logo, refer to page 62 for more details.
(Settings>Display>Graphics) for more detail.
• If “Password” appears on the display enter your 4-digit
password to unlock your phone.
• The default password is the last 4 digits of your
phone number.
16
TURNING THE PHONE OFF
1
Press and hold until your “Power Off” logo
appears.
• Immediately change or recharge the battery when
“Low Battery Warning Power Off” appears on the display.
Memory may possibly be damaged if the phone turns off
due to the battery completely draining.
• Turn the phone off before removing or replacing the battery.
If the phone is on, unsaved data may be lost.
Hotkey
In idle mode, move the Navigation Key as follows to access
these functions:
• Upward movement : Phone Book
• Downward movement : Messaging
• Rightward movement : Get It Now
• Leftward movement : Mobile Web
TURNING THE PHONE ON / OFF
l To search through the menu in numerical order, press down.
Phone Book
Recent Calls
Messaging
Settings
Tools
Utilities
Media Gallery
Get It Now
Mobile Web
TX-180 2004.9.3 7:32 PM 페이지16
MENU SUMMARY MENU SUMMARY
C
H
2
19
C
H
2
18
1. Phone Book
2. Recent Calls
3. Messaging
4. Get It Now
5. Mobile Web
1. Find
2. Add New
3. Group
4. Speed Dial
5. Msg. Group
6. My Phone #
1. All Calls
2. Missed Calls
3. Received Calls
4. Dialed Calls
5. Call Timers
6. 1X Packet Counter
1. New Text M s g
2. Voice Mail
3. Inbox
4. Outbox
5. Web Alerts
6. Saved
7. Quick Text
8. Erase All
9. Settings
1. Get It Now
1. Connect web
1. Last Call
2. All Calls
3. Home Calls
4. Roam Calls
5. Cumulative Calls
1. Received
2. Transmitted
3. Total
1. Inbox
2. Outbox
3. Saved
1. Save sent MSG
2. Auto Erase
3. Default Callback
4. Edit Voice C.B
5. Remind
6. Edit Signature
7. Direct View
8. Entry Mode
9. Block or Unblock
Get It Now
Settings
Help
1. Old Inbox
2. Entire Inbox
1. Inbox
2. Outbox
1. Block
2. Unblock
3. View List of
Blocked Address
6. Media Gallery
7. Settings
1. Images
2. Tones
1. Sounds
2. Display
3. Data SVC.
4. Security
5. Others
1. Graphics
2. Animations
1. Ringer Type
2. Volume
3. Alert
4. Roam Ringer
5. Tone Length
6. Etiquette
1. Menu Style
2. Graphics
3. Sub Screen
4. Greeting Message
5. Contrast
6. Backlight
1. Connection
1. Phone Lock
2. Restrict
3. Change Code
4. Special #’s
5. Erase All
6. Reset Phone
1. Answer Options
2. Auto Retry
3. Language
4. Voice Privacy
5. TTY Mode
6. Location
1. Ringer
2. Messages
3. Voice Mail
1. Ringer
2. Key Tone
3. Voice Call
4. Speaker Phone
1. Minute
2. Roam
3. Connect
4. Fade
5. On/Off Tones
1. Wallpaper
2. Power On
3. Power Off
4. Received
5. Dialed
6. Screen Saver
1. Dialed
2. Recent Calls
3. Data Call
4. 900#s
5. Long Distance
1. Special #1
2. Special #2
3. Special #3
1. Call Answer
2. Active Flip
3. Auto Answer
TX-180 2004.9.3 7:32 PM 페이지18
MENU SUMMARY
C
H
2
21
C
H
2
20
8. Tools
9. Utilities
6. System
7. Phone Info
1. Voice Memo
2. Voice Dial
3. Train Words
4. Voice Setting
1. Schedule
2. Alarm
3. Memo Pad
4. Calculator
5. World Clock
6. Stop Watch
1. Set Mode
2. Nam Setting
3. PRL ID
4. ERI Banner
1. S/W Version
2. H/W Version
3. Get It Now Version
1. Record
2. Play
3. Play Speaker
4. Erase All
1. Record
2. Play
3. Play Speaker
4. Erase All
1. Yes
2. No
3. Wake-Up
4. Undo Train All
Set Active
HFK Mode
1. Add New Plan
2. View Plan
1. Alarm 1
2. Alarm 2
3. Alarm 3
1. Add Memo
2. View Memo
3. Settings
1. Auto NAM
2. Change NAM
BASIC FUNCTIONS
MAKING A CALL
1
Enter a phone number.
To modify the phone number you have entered :
• To erase one digit at a time press .
• To erase the entire number, press and hold .
2
Press .
The indicator, , appears on the display.
• If “CALL FAILED” appears on the display or the line is busy,
press or .
• If you activate the “AUTO RETRY” function, the phone will
automatically retry for the number of times you have
selected. (refer to page 74).
• When you place or receive a call from stored phone
numbers, both the name and phone number will be
displayed.
• There is another way to make a call through the VR mode,
which is called “VAD (Voice Activated Dialing)”.
Please refer to page 89 (Voice Service) for more details.
3
To end a call, press .
TX-180 2004.9.3 7:32 PM 페이지20
BASIC FUNCTIONS BASIC FUNCTIONS
C
H
2
Pauses are used for automated systems (i.e., voice mail, calling cards).
Insert a pause after a phone number then enter another group of
numbers. The second set of numbers is dialed automatically after the
pause. This feature is useful for dialing into systems that require a code.
The speaker phone feature lets you hear audio through the speaker and
talk without holding the phone.
PAUSE FEATURE
1
To insert a pause, enter a phone number then
press [MENU]. Select either a Hard Pause
(“P” appears) or a Timed Pause (“T” appears).
2
Press to dial or [SAVE] to store.
Please refer to page 30 for more details about
storing a phone number.
23
C
H
2
SPEAKER PHONE
1
To activate the speaker phone in idle, answering
or calling modes, press and hold .
2
The phone returns to normal (Speaker phone off)
after ending a call or when the phone is turned off
and back on.
22
ANSWERING A CALL
1
To answer a call, press any key except , ,
or .
2
To end the call, press .
In Auto Answer Mode a call is automatically answered after a
preset number of ring tones. See page 74 for more details.
If one of the people you called hangs up during your call, you
and the remaining caller stay connected. If you initiated the call
and are the first to hang up, all three callers are disconnected.
l By pressing , you can select either “Any
Key” or “Send Key” to answer a call. lf “Send Key” is selected,
the phone can only be answered by pressing .
See page 73 for more information.
With Three-Way Calling, you can talk to two people at the same time.
When using this feature, the normal airtime rates will be applied for
each of the two calls.
3-WAY CALLING
1
Enter a number you wish to call then press .
2
Once you have established the connection,
enter the second number you wish to call then
press .
3
When you’re connected to the second party,
press again to begin your three-way call.
TX-180 2004.9.3 7:32 PM 페이지22
BASIC FUNCTIONS BASIC FUNCTIONS
C
H
2
Notifies you of an incoming call when you are already on a call by
sounding a beep tone and displaying the caller’s phone number.
CALL WAITING FUNCTION
1
To answer another call while on the phone,
press . This places the first call on hold.
To switch back to the first caller, press
again.
25
C
H
2
24
Adjusts the volume of the ringer, key beep and speaker.
ADJUSTING VOLUME
1
Press [MENU] then select one
of the following.
2
Adjust volume then press [OK] to save it.
Mutes key tones and activates the vibration mode to alert you of an
incoming call or message.
The Key guard feature of your cellular telephone locks the keypad to
protect against accidental key presses when the phone is turned on
and no call is in progress. You can still answer or silence an incoming
call.
ETIQUETTE
1
To turn etiquette mode on/off, press and hold .
will be displayed to indicate etiquette mode
is active and an audible tone sounds when
etiquette mode is turned off.
Ringer : Controls the ringer volume.
Key Tone : Controls the key pad tone.
Voice Call : Controls the earpiece volume.
Speaker Phone : Controls the speaker volume.
l
l
l
l
To adjust earpiece volume during a call, press the
Navigation Key up or down.
Call Waiting is a system dependent feature. Please contact your
service provider for details.
Press 1, 2, 3 to unlock the key guard.
KEY GUARD
1
To lock the phone, press and hold .
2
To unlock the phone, press or then
input your password.
Identifies caller by displaying their phone number. If the caller’s name
and number are already stored in your phone book, they both will
appear.
CALLER ID FUNCTION
The caller ID is stored in the call history.
The lock feature will deactivate when the phone is powered
off. Upon next power up, you will need to press to lock
phone again.
l
TX-180 2004.9.3 7:33 PM 페이지24
DURING A CALL DURING A CALL
C
H
2
Enables you to send a message (SMS) during a call.
To display menu options during a call, press [MENU].
MESSAGING
1
Press [MENU] .
Stores a new phone number during a call without the calling party
hearing the key pad tones.
SCRATCHPAD
1
Press [MENU] .
Automatically transmits your phone number to a pager during a call.
(Dependent on pager service)
SEND MY PHONE #
1
Press [MENU] .
27
C
H
2
26
To deactivate it, press [MENU] .
Displays the software and hardware version of your phone.
PHONE INFO.
1
Press [MENU] .
Increases security during a call.
VOICE PRIVACY
1
Press [MENU] .
Enables the network to locate your current location through Global
Positioning System (GPS). (Refer to page 76 for more details.)
LOCATION
1
Press [MENU] .
Displays your phone number.
MY PHONE #
1
Press [MENU] .
The caller cannot hear you or any sounds from your side but you can
still hear them.
MUTE (UNMUTE)
1
Press [MENU] .
To deactivate, press [MENU] .
The phone will automatically un-mute in Emergency
Call or Callback mode.
l
l
l
TX-180 2004.9.3 7:33 PM 페이지26
MEMORY FUNCTION
This chapter addresses memory functions including:
Chapter 3
C
H
3
29
MAKING AN EMERGENCY CALL
C
H
2
28
STORING A PHONE NUMBER
ENTERING LETTERS, NUMBERS & SYMBOLS
MAKING A CALL THROUGH THE PHONE BOOK
The 911 feature puts the phone in the Emergency Call Mode
when you dial the preprogrammed emergency number, 911. It also
operates in the lock mode and out of the service area.
The 911 call service is available even in the lock mode.
911 IN LOCK MODE
1
Enter “911” then press .
When the call ends, the phone returns to the Lock Mode.
2
The call connects.
3
The phone exits the Lock Mode for 5 minutes.
911 USING ANY AVAILABLE SYSTEM
1
Enter “911” then press .
The phone returns to the Lock Mode.
While the phone is in the emergency mode for 5 minutes,
the phone can receive an incoming call from any available
system. However, it can't make a call.
2
The call connects.
3
The phone maintains the Emergency Mode
for 5 minutes.
l
l
l
The 911 call is not recorded in the recent call list.
TX-180 2004.9.3 7:33 PM 페이지28
Enter a name then press [OK].
Please refer to page 31 for more details on
entering letters, numbers & symbols.
To change the input mode, press [Abc].
Press the Navigation Key down to select the
group. Press the Navigation Key down to select
other options (secret, email).
Input mode indicator
T9Word : T9 mode
Abc : Abc mode
NUM : Number mode
Symbols : Symbol mode
STORING A PHONE NUMBER
ENTERING LETTERS, NUMBERS & SYMBOLS
C
H
3
The input mode (Alpha editor) will automatically be activated when
necessary to enter letters and numbers. As shown below, there are 4
available modes ; Standard input mode (Abc), T9 input mode
(T9Word), Numeric mode (NUM), and Symbol mode (Symbols).
The following illustrates the function assigned to each key in the
Alpha Editor.
31
C
H
.
3
The phone book stores up to 300 entries.
1
Enter phone # then press [SAVE].
2
Choose “New Contact” or “Existing Contact”.
Press [OK] to select.
The input mode indicator appears on the upper right
of the display when letters and numbers are entered.
To select the desired input mode among the 4 modes
below, press [MODE], then enter letters and
numbers.
3
The Phone # will appear above a list of icons.
The name of the icon is displayed below the list.
Use the Navigation Key to choose the type of #
you’re adding, as indicated by the icon.
Press [OK] to select.
4
5
To store the entry, press [SAVE]. “New contact
added!” or “Contact edited!” will be displayed.
30
Mode
Next
Space
Caps Lock
Clear
Save
Press to change mode.
[T9Word][Abc][NUM][Symbols]
Press to view the next matching word if
the highlighted word is not the word you
intended.
Press to accept a word and add a space.
Press to select a letter case of the
standard text input or T9 text input mode.
[Abc], [ABC], and [abc] indicate the
standard text input.
[T9Word], [T9WORD], and [T9word]
indicate the predictive text input.
Press to delete a character to the left of
the cursor.
Store the letters and numbers you enter.
KEY FUNCTION
TX-180 2004.9.3 7:33 PM 페이지30
ENTERING LETTERS, NUMBERS & SYMBOLS ENTERING LETTERS, NUMBERS & SYMBOLS
C
H
3
The T9 input mode incorporates a built-in-dictionary to determine a
word based on the entered characters. A word can be entered more
quickly by pressing a key once per character.
T9 INPUT MODE
1
Select the T9Word mode by pressing [Abc].
2
Press a digit key once to enter the character
you want then enter all the characters to input
the word you want.
3
To view the next matching word, press .
To enter a compound word:
• Enter the first part of the word then press to accept it.
• Enter the last part of the word then press to enter the word.
Select Abc mode by pressing [Abc].
When you select this mode, the Abc icon appears as a visual
confirmation.
- Find the key that corresponds to the letter you want to enter.
- Press it as many times as needed for the letter to appear on the
screen.
- To enter the name “John”:
Press [ ] J
Press [ ] o
Press [ ] h
Press [ ] n
33
C
H
3
Use the digit keys to enter letters, numbers and characters.
STANDARD INPUT MODE
1
Enter letters using the key pad as follows:
2
To enter a space, press . The cursor will
automatically move to the next column.
3
Repeat until letters are entered.
There is a 16-letter limit.
4
To delete one digit, press . To delete the
entire entry, press and hold .
To change the input mode, press [Abc].
32
Key Pad
1
2ABC
3DEF
4GHI
:
9WXYZ
1
A
D
G
:
W
.
B
E
H
:
X
@
C
F
I
:
Y
-
2
3
4
:
Z
’
A
D
G
:
9
1
Time
Repetitions
2 times
Repetitions
3 times
Repetitions
4 times
Repetitions
5 times
4
To accept the matching word then enter a
space, press .
5
To change from lowercase to uppercase,
press .
To enter “Fun fare” in the T9 input mode.
- After you enter the 1st letter, press [Abc] to select T9 mode
and to choose the lower case (T9Word).
- Press and you will see “Fun” highlighted.
Press to select it.
- Press and until you see “ease” highlighted.
Press to select the next matching word, you will see “fare”
then enter a space.
TX-180 2004.9.3 7:33 PM 페이지32
ENTERING LETTERS, NUMBERS & SYMBOLS MAKING A CALL THROUGH THE PHONE BOOK
C
H
3
NUMERIC MODE
1
Press [Abc] and scroll to the input mode to
changes to “Symbols (Symbol mode)”.
35
C
H
3
34
1
Press [Abc] and scroll to the input mode to
changes to “NUM (Numeric mode)”.
2
To enter a number, press a digit key.
Press [ ],
or
Press [ ],
2
Select symbol you want to enter with the
Navigation Key.
lUse the Navigation Key to view a different line of symbols.
SYMBOL MODE
Allows you to enter numbers.
Allows you to enter symbols.
Ideal for frequently dialed numbers, this feature allows phone book
entries to be dialed via the keypad with only one or two key presses.
ONE-TOUCH/TWO-TOUCH DIALING
1-9 : Press and hold the corresponding memory
number for more than 1 second.
ONE-TOUCH DIALING:
10-20 : Press the first digit and second digits of the
memory number short and long respectively.
TWO-TOUCH DIALING:
• If no phone number is stored in the location entered,
“There is no number” will appear on the screen.
• If a phone number is stored in secret, you will have to enter
the password to make a call.
TX-180 2004.9.3 7:33 PM 페이지34
M E M O
MENU FUNCTION
This chapter addresses accessing the menu and using its functions
and features to customize your phone.
Chapter 4
C
H
4
37
C
H
3
36
PHONE BOOK
RECENT CALLS
GET IT NOW
MOBILE WEB
MEDIA GALLERY
SETTINGS
UTILITIES
TX-180 2004.9.3 7:33 PM 페이지36
C
H
4
39
C
H
4
38
Stores up to 300 entries, each of which can be assigned to a group.
Entries can be retrieved by name or group.
Retrieves an entry by name and calls by simply pressing .
You can review all the entries stored in your phone book list or
quickly find an entry by entering a name or its character string.
FIND
PHONE BOOK PHONE BOOK
1
2
3
4
5
Press [MENU] .
Enter a name or its character string or scroll
through the list with the Navigation Key.
Please refer to page 31 for more details on
entering letters, numbers & symbols.
Please refer to page 97 for more details on
“New Text Msg”.
The list of names in your phone book is
displayed alphabetically.
All matching entries will be displayed. Highlight
an entry. To edit the entry, press [OK].
Press [MENU] to 1. Send Text Msg, 2. Prefix
or 3. Erase.
To call the selected number, press .
If the entry is set to secret, you will be asked for your password.l
1
2
To add a new entry to the phone book,
press [MENU] .
Adds a new entry.
ADD NEW
To enter a name or number, use the Navigation
Key to select the phone book field.
Please refer to page 31 for more details on entering
letters, numbers & symbols.
3
3.1 To save the entry, press [SAVE].
3.2 To return to the previous page, press .
PHONE BOOK FIELDS :
Name/Mobile/Home/Office/Pager/Fax/E-Mail/ Wireless
Addr./Group/Ringer/Msg.Ringer/Graphic/Memo/
Set Secret.
l
GROUP
Allows you to classify phone entries into groups. Existing groups
include Personal, Business, Etc. and All. A maximum of seven groups
is allowed.
1
3
To add a new group, press [MENU] .
A maximum of seven groups is allowed.
ADD NEW GROUP
Input a new group name.
4
To save it, Press [OK].
2
To select “Add Group”, Press [MENU].
TX-180 2004.9.3 7:33 PM 페이지38
C
H
4
C
H
4
40
PHONE BOOK PHONE BOOK
41
CHANGE GROUP NAME
2
Select an existing group name that you have
added with the Navigation Key.
4
Input a new group name.
5
To save it, press [OK].
3
To select “Rename”, press [MENU].
ERASE GROUP
2
Use the Navigation Key to select, then delete
the group.
3
To delete it, press [ERASE].
4
To erase it, press [OK].
The default group names (All, Personal, Business, Etc.) cannot
be changed.
• The default group names (All, Personal, Business, Etc.)
cannot be erased.
• When executing erase group, the saved entries are moved
to the Etc. group.
1
Press [MENU] .
1
Press [MENU] .
In idle mode, calls can be placed to numbers stored in speed dial by
pressing & holding the location number on the key pad. For a 2-digit
location number, press the first number, then press and hold the
second number.
SPEED DIAL
1
Press [MENU] .
2
To assign a phone number to a location, select
the location then press [SET].
3
Select the entry with the Navigation Key and
press [OK].
If a phone number is already assigned to the
location, press [ERASE] and [OK] to delete.
l
If the entry is set to secret, you will be asked for your password.
l
4
“Speed dial # X edited” will be displayed.
• “Unassigned” appears if the location is available.
• If a phone number is set as Secret, you will have to enter the
password.
• To call an assigned number, press & hold the last digit of the
speed dial #.
TX-180 2004.9.3 7:33 PM 페이지40
C
H
4
43
C
H
4
42
PHONE BOOK PHONE BOOK
MSG. GROUP
Allows the user to group up to 10 phone number. The user can add,
change, and delete Msg.Group.
1
3
To add a new group, press [MENU] .
A maximum of five groups is allowed.
ADD NEW MSG. GROUP
Input a new group name.
4
To save it, press [OK].
2
To select “Add Group”, press [MENU].
CHANGE MSG. GROUP NAME
2
Select an existing group name with the
Navigation Key.
4
Input a new group name.
5
To save it, press [OK].
3
To select “Rename”, press [MENU].
1
Press [MENU] .
1
Press [MENU] .
1
Press [MENU] .
SEND TEXT MSG. GROUP
2
Select an existing group name with the
Navigation Key.
4
Input a “Message”, “Default CB#”, “Priority”,
and “Insert Signature”.
5
3
To select “Send Text Msg.”, press [MENU].
5.1. To send the text message, press [MENU]
then select the “Send” then press [OK].
5.2. To save the text message, press [MENU]
then select the “Save to Outbox” then
press [OK].
Please refer to page 97 for more details on
“New Text Msg”.
ERASE MSG. GROUP
2
Select an existing group name with the
Navigation Key.
3
To delete it, press [ERASE].
4
To erase it, press [OK].
TX-180 2004.9.3 7:33 PM 페이지42
C
H
4
45
C
H
4
44
PHONE BOOK RECENT CALLS
To display your phone number and service provider:
MY PHONE #
1
Press [MENU] .
2
To return to the previous page, press [OK].
Call details include type of call, date, time and phone number.
After the 20 received, dialed or missed calls, the oldest call will
automatically be erased from the history.
Displays information about the most recent incoming, outgoing and
missed calls.
In idle mode, you can access recent calls by pressing [MENU] .
ALL CALLS
1
To see a list of the 60 most recent incoming,
outgoing and missed calls, press [MENU] .
If the number is already stored in your phone book,
only the name appears. If the number is not stored,
only the phone number appears.
2
3
To view details, press [OK].
Save: To store the phone number in your phone book.
Prefix: The user may add the desired number before the number.
It is useful when you add “1” during a long distance call.
You may save it in the phone book after entering the Prefix.
Send TXT Msg: To send a TXT message, insert the phone number.
Erase All: To erase all recent calls list.
l
l
l
l
Press [MENU] and select “SAVE” to save it
or press [ERASE] to delete it.
TX-180 2004.9.3 7:33 PM 페이지44
C
H
4
47
C
H
4
46
RECENT CALLS RECENT CALLS
Displays information about the 20 most recently missed calls.
Place a call to a missed call number by simply pressing .
To see a list of the 20 most recently missed
calls, press [MENU] . If the number
is already stored in your phone book, only the
name appears. If the number is not stored,
only the phone number appears.
MISSED CALLS
1
2
To view missed call details, press [OK].
Call details include date, time and phone number.
After 20 missed calls, the oldest call will automatically
be erased from the history.
Call details include date, time and phone number.
After 20 received calls, the oldest call will automatically
be erased from the history.
Displays information about the 20 most recently answered calls.
Place a call to a received call by simply pressing .
RECEIVED CALLS
1
To see a list of the 20 most recently answered
calls, press [MENU] . If the number is
already stored in your phone book, only the
name appears. If the number is not stored, only
the phone number appears.
2
To view incoming call details, press [OK].
3
Save: To store the phone number in your phone book.
Prefix: The user may add the desired number before the number.
It is useful when you add “1” during a long distance call.
You may save it in the phone book after entering the Prefix.
Send TXT Msg: To send a TXT message, insert the phone number.
Erase All: To erase all missed calls list.
l
l
l
l
Press [MENU] and select “SAVE” to save it
or press [ERASE] to delete it.
3
Save: To store the phone number in your phone book.
Prefix: The user may add the desired number before the number.
It is useful when you add “1” during a long distance call.
You may save it in the phone book after entering the Prefix.
Send TXT Msg: To send a TXT message, insert the phone number.
Erase All: To erase all received calls list.
l
l
l
l
Press [MENU] and select “SAVE” to save it
or press [ERASE] to delete it.
TX-180 2004.9.3 7:33 PM 페이지46
C
H
4
4948
C
H
4
RECENT CALLSRECENT CALLS
Call details include type of call, date, time and phone number.
After 20 dialed calls, the oldest call will automatically
be erased from the history.
Displays information about the 20 most recently dialed numbers.
Place a call to a dialed call by simply pressing .
DIALED CALLS
1
To see a list of the 20 most recently dialed
numbers, press [MENU] .
If the number is already stored in your phone
book, only the name appears. If the number is
not stored, only the phone number appears.
2
To view dialed call details, press [OK].
Checks the usage time and manages your calls within the limit you
set. The five timers include:
Displays usage time of last call.
CALL TIMERS
1
Press [MENU] .
2
To return to the previous page, press [OK].
LAST CALL
Displays usage time of all calls made within Home area.
HOME CALLS
1
Press [MENU] .
2
View the time of the following items:
3
To reset the timer, press [RESET].
To return to the previous page, press [OK].
Voice Call
Data Call
Displays usage time of all incoming and outgoing calls, excluding
web access calls.
ALL CALLS
1
Press [MENU] .
2
View the time of the following items:
3
To return to the previous page, press [OK].
Voice Call
Data Call
l
l
l
l
3
Save: To store the phone number in your phone book.
Prefix: The user may add the desired number before the number.
It is useful when you add “1” during a long distance call.
You may save it in the phone book after entering the Prefix.
Send TXT Msg: To send a TXT message, insert the phone number.
Erase All: To erase all dialed calls list.
l
l
l
l
Press [MENU] and select “SAVE” to save it
or press [ERASE] to delete it.
TX-180 2004.9.3 7:33 PM 페이지48
C
H
4
51
C
H
4
50
RECENT CALLS
50
RECENT CALLS
Displays usage time of all incoming and outgoing calls, excluding
web access calls.
1
2
View the time of the following items:
Press [MENU] .
CUMULATIVE CALLS
3
To reset the timer, press [RESET].
To return to the previous page, press [OK].
Voice Call
Data Call
Displays usage time of roaming calls.
ROAM CALLS
1
Press [MENU] .
2
View the time of the following items:
3
To reset the timer, press [RESET].
To return to the previous page, press [OK].
Voice Call
Data Call
l
l
l
l
Checks the log of all kilobyte data transmissions.
To show the received kilobyte usage on a user definable interval:
To show the transmitted kilobyte usage on a user definable interval:
To show the received or transmitted kilobyte usage on a user definable
interval:
1X PACKET COUNTER
1
Press [MENU] .
2
RECEIVED
To reset the counter, press [RESET].
To return to the previous page, press [OK].
TRANSMITTED
1
Press [MENU] .
2
To reset the counter, press [RESET].
To return to the previous page, press [OK].
TOTAL
1
Press [MENU] .
2
To return to the previous page, press [OK].
TX-180 2004.9.3 7:33 PM 페이지50
C
H
4
53
C
H
4
52
GET IT NOW
52
GET IT NOW
To select an option, press then press .
When a prompt appears, press to proceed or
to cancel.
Your phone provides a unique feature -Get It Now- that enables you
to download melody ringtones, wallpapers, games and more from
your network to your phone. Please contact your service provider for
the availability of these services.
START GET IT NOW
1
To launch “Get It Now ” from the standby
mode, press [MENU] or .
2
When three or more icons appear on the screen,
select an application with the Navigation Key.
4
To end the application, press .
The phone will return to the standby mode.
3
To start the application, press .
DOWNLOADING APPLICATIONS
1
Press [MENU] or .
2
Select “Get It Now ” with the Navigation Key
then press .
4
The phone will access your service provider’s
server.
Follow the prompt to download applications.
3
Select “Start” with the Navigation Key then
press .
Before downloading melody ringtones and wallpapers, you need to
download the dedicated downloader.
Please contact your service provider for details.
DOWNLOADING MELODIES/WALLPAPERS
l
l
Downloaded melody ringtones applies to several functions including
the incoming call alert, new text message alert, alarm clock and
scheduler alarm.
Downloaded wallpapers apply to the standby mode.
Downloaded melody ringtones, wallpapers and applications are
saved to the data folder in your phone.
APPLYING MELODIES/WALLPAPERS
CHECKING DATA FOLDER MEMORY
1
Press [MENU] or .
2
Select “Get It Now ” with the Navigation Key
then press .
4
Select “Information” with the Navigation Key then
press . The memory status will be displayed.
3
Select “Options” with the Navigation Key and
press .
5
To exit, press .
ERASING AN APPLICATION
1
Press [MENU] or .
2
Select “Get It Now ” with the Navigation Key
then press .
4
Select the application to be erased with the
Navigation Key then press .
3
Select “Options” with the Navigation Key and
press .
5
To remove it, press [OK].
TX-180 2004.9.3 7:33 PM 페이지52
You can use your phone to browse the Internet if you have obtained
phone Internet service from your service provider and if over-the air
Internet access is available in your area. This menu displays the list of downloaded still images.
This menu displays the list of downloaded/add as to images.
1
Press [MENU] or .
2
Follow the procedures for “Chapter 7 MOBILE
WEB 2.0” on page 111.
CONNECT WEB
C
H
4
55
C
H
4
54
MOBILE WEB 2.0
54
MEDIA GALLERY
IMAGES
1
Press [MENU] .
GRAPHICS
1
Press [MENU] .
ANIMATIONS
2
Scroll through the captured pictures to display the
picture you want to send then press [SEND].
3
Enter your picture message.
4
4.1 To send the pix message, press [MENU]
then select “Send” then press [OK].
4.2 To save the pix message, press [MENU]
then select “Save to Outbox” and
press [OK].
4
4.1 To send the pix message, press [MENU]
then select “Send” then press [OK].
4.2 To save the pix message, press [MENU]
then select “Save to Outbox” and
press [OK].
2
Scroll through the captured pictures to display the
picture you want to send then press [SEND].
3
Enter your picture message.
Press [MENU] to select 1.Erase, 2.Erase All, 3.Change Title.
Press [MENU] to select 1.Erase, 2.Erase All, 3.Change Title.
TX-180 2004.9.3 7:34 PM 페이지54
C
H
4
57
C
H
4
56
MEDIA GALLERY
56
S E T T I N G S
1
Press [MENU] .
TONES
2
Scroll to the saved voice memo you want to send
then press [SEND].
3
To write your picture message,
Sets Ringer Type, Volume, Alert, Roam Ringer, Tone Length and Etiquette.
To select a ringer type for incoming calls:
To select a ringer type for receiving messages:
To select a ringer type for receiving voice mail:
Customizes your phone and optimizes performance through a variety
of settings.
SOUNDS
RINGER TYPE
1
Press [MENU] .
2
Select your desired ringer type.
3
Select one of the available ring types.
To confirm, press [SELECT].
RINGER
2
Press the Navigation Key up or down to select
“Tone 1, 2, 3, 4, 5”.
3
To confirm, press [SELECT].
2
Press the Navigation Key up or down to select
“Tone 1, 2, 3, 4, 5”.
3
To confirm, press [SELECT].
1
Press [MENU] .
MESSAGES
1
Press [MENU] .
VOICE MAIL
Left or Right key : Select “Ring Tones”, “Music Bells” or
“Downloads.”
Up or Down key : Select “Ringer.”
Downloads : Downloaded ringer types and familiar music.
3.1 To send the pix message, press [MENU]
then select “Send” then press [OK].
3.2 To save the pix message, press [MENU]
then select “Save to Outbox” and
press [OK].
TX-180 2004.9.3 7:34 PM 페이지56
S E T T I N G S S E T T I N G S
C
H
4
59
C
H
4
58
Controls the Ringer, Key tone, Voice Call and Speaker Phone volume.
VOLUME
RINGER
1
Press [MENU] .
2
Select one of the following options by
pressing the Navigation Key to the right.
3
To confirm, press [OK].
1
Press [MENU] .
Silent : Mute the ringer, press (Min).
Ringer Off
Vibrate On
Ringer Mode : Up & Down (Level 1~5)
High & Vib : The ringer sounds after vibration,
press (Max).
To adjust key pad tone:
Controls the Ringer volume and alerts you to incoming calls in the
modes listed in the gray box below.
KEY TONE
2
Adjust the key pad tone with the Navigation Key.
3
To save, press [OK].
1
Press [MENU] .
To adjust earpiece volume:
VOICE CALL
2
Adjust the earpiece volume with the Navigation Key.
3
To save, press [OK].
Level 1 - 5 (Min- , Max- )
Off (Min- )
Level 1 - 5 (level 5, Max- )
When selected, this setting alerts you to the following handset changes:
Sounds an alert every minute during a call.
ALERT
MINUTE
2
Select “Off” or “On” with the Navigation Key then
press [OK] to save it.
1
Press [MENU] .
Sounds an alert when leaving a service area and entering a roaming
service area.
ROAM
2
Select “Off” or “On” with the Navigation Key then
press [OK] to save it.
1
Press [MENU] .
Notifies you that a call has been successfully placed.
CONNECT
2
Select “Off” or “On” with the Navigation Key then
press [OK] to save it.
1
Press [MENU] .
1
Press [MENU] .
To adjust speaker phone volume:
SPEAKER PHONE
2
Adjust the speaker phone volume using the
Navigation Key.
3
To save, press [OK].
Level 1 - 5 (Min- , Max- )
TX-180 2004.9.3 7:34 PM 페이지58
S E T T I N G S S E T T I N G S
C
H
4
61
C
H
4
60
Sounds an alert when entering an area where calls cannot be made
due to weak signal strength.
FADE
2
Select “Off” or “On” with the Navigation Key then
press [OK] to save it.
1
Press [MENU] .
Sounds a different ringer when you are in a roaming service area.
ROAM RINGER
1
Press [MENU] .
2
Select “Distinctive” or “Normal” with the
Navigation Key then press [OK] to save it.
Normal : Sounds the same ringer type as used in Home area.
Distinctive : Sounds a different ringer type.
l
l
On : Etiquette Mode on.
Off : Etiquette Mode off.
l
l
To adjust tone length:
To place the phone in Etiquette Mode so all phone sounds are muted:
TONE LENGTH
1
Press [MENU] .
2
Select “Normal” or “Long” with the Navigation
Key then press [OK] to save it.
ETIQUETTE
1
Press [MENU] .
2
Select “On” or “Off” with the Navigation Key,
then press [OK] to save it.
Allows you to activate/deactivate the power on/off tones.
ON/OFF TONES
2
Select “Off” or “On” with the Navigation Key then
press [OK] to save it.
1
Press [MENU] .
TX-180 2004.9.3 7:34 PM 페이지60
S E T T I N G S S E T T I N G S
C
H
4
63
C
H
4
62
Allows you to customize the display.
To select a display menu style:
DISPLAY
MENU STYLE
WALLPAPER
1
Press [MENU] .
2
Select “Fold”, “Grid” or “List” with the
Navigation Key then press [OK] to save it.
1
Press [MENU] .
To select an LCD display:
GRAPHICS
2
Select Default to choose a pre-installed display,
or Downloads to choose a display you have
downloaded to your phone.
3
Select a display from the Animation and the
Graphic list using the Navigation Key and
press [SELECT] to save it.
2
Select Default to choose a pre-installed display,
or Downloads to choose a display you have
downloaded to your phone.
3
Select a display from the Animation and the
Graphic list using the Navigation Key and
press [SELECT] to save it.
1
Press [MENU] .
POWER ON
1
Press [MENU] .
RECEIVED
1
Press [MENU] .
DIALED
2
Select “Default” with the Navigation Key.
3
Select a display from the Animation list using
the Navigation Key then press [SELECT] to
save it.
1
Press [MENU] .
POWER OFF
2
Select Default to choose a pre-installed display,
or Downloads to choose a display you have
downloaded to your phone.
3
Select a display from the Animation and the
Graphic list using the Navigation Key and
press [SELECT] to save it.
2
Select Default to choose a pre-installed display,
or Downloads to choose a display you have
downloaded to your phone.
3
Select a display from the Animation list using
the Navigation Key then press [SELECT] to
save it.
TX-180 2004.9.3 7:34 PM 페이지62
C
H
4
65
S E T T I N G S
C
H
4
64
S E T T I N G S
1
Press [MENU] .
SCREEN SAVER
2
Select “Time Setting” or “Screen Saver” with
the Navigation Key.
3
To save, press [SELECT].
Time Setting : Off, 5 Secs, 10 Secs, 20 Secs, 30 Secs.
Screen Saver : Select picture image.(Multimedia/Images).
By pressing [MENU], the user can choose from the following:
1. Erase: To erase pictures saved in the current album.
2. Erase All: To erase all pictures saved in the current album.
3. Change Title: To edit the title of a picture file.
l
l
SUB SCREEN
1
Press [MENU] .
Sets the time of Screen Saver and selects the images to be displayed
on the LCD.
2
Select “Digital” or “Analog” with the
Navigation Key.
3
To save, press [OK]. To adjust the display contrast:
CONTRAST
1
Press [MENU] .
MAIN LCD/SUB LCD
To save, press [OK].
2
3
Select “Main LCD” or “Sub LCD” then select one
of the following options with the Navigation Key.
Main LCD : Level 1~5.
Sub LCD : Level 1~5.
l
l
To input a personal greeting:
GREETING MESSAGE
1
Press [MENU] .
2
The msg field will be highlighted. Press the
Navigation Key left or right to choose between
on and off. Press the Navigation Key down to
move to the next field, font. Press the Navigation
Key left or right to choose a font color. Press the
Navigation Key down to move to the next field,
Bg. Press the Navigation Key left or right to
choose a Bg color. Repeat for both fields. Press
the Navigation Key down for the entry message
field. Enter your greeting.
To save, press [SAVE].
3
Msg : On/Off.
Font : White, Blue, Dark blue, Magenta, Gray, Black.
Bg : Transparent, White, Blue, Yellow, Gray, Black.
Entry Message : Enter message (Default-VERIZON).
l
l
l
l
TX-180 2004.9.3 7:34 PM 페이지64
C
H
4
67
S E T T I N G S
C
H
4
66
S E T T I N G S
Backlights the display and key pad and activates dimming for easy
viewing in dark places.
BACKLIGHT
3
To save, press [OK].
1
Press [MENU] .
LCD/KEY PAD/DIMMING
2
Select “LCD”, “Key Pad” or “Dimming” then
select one of the following options with the
Navigation Key.
LCD : 5 Secs/15 Secs/30 Secs/60 Secs/Always On.
Key Pad : 5 Secs/15 Secs/30 Secs/60 Secs/
Always On/Always Off.
Dimming : On/Off.
l
l
l
DATA SVC.
2
Select one of the following connection modes
with the Navigation Key.
3
To save it, press [OK].
Voice Call : To receive a voice call.
Data Only : To receive data when connected to PC.
l
l
This function is available only when the phone is connected
to a data cable.
CONNECTION
1
Press [MENU] .
Choose the connection mode for the usage of your phone.
TX-180 2004.9.3 7:34 PM 페이지66
C
H
4
69
S E T T I N G S
C
H
4
68
S E T T I N G S
Prevents unauthorized use of your phone. The following settings can
be restricted:
SECURITY
Prevents the phone from being used without entering the password
first.
1
Press [MENU] then enter your password.
PHONE LOCK
3
To save, press [OK].
2
Press then select “Lock Now”, “Lock On
Power Up” or “Unlock”.
Lock Now : Lock the phone now.
Lock On Power Up : Not locked, but it is automatically
locked when power is recycled.
Unlock : Do not lock the phone.
l
l
l
The default password is the last 4 digits of your phone number.
RESTRICT
Blocks all dialed calls – except emergency calls – but allows an
incoming call to be placed.
When you attempt to make a restricted call, “This phone is restricted”
appears on the screen.
1
Press [MENU] then enter your password.
2
Press then select “Allow” or “Restrict”
with the Navigation Key.
3
To save, press [OK].
DIALED
Allow : Allows a dialed call.
Restrict : Restricts a dialed call.
l
l
1
Press [MENU] then enter your password.
2
Press then select “Allow” or “Restrict”
with the Navigation Key.
3
To save, press [OK].
Allow : Allows a recent call.
Restrict : Restricts a recent call.
l
l
RECENT CALLS
Blocks access to Recent Call List.
1
Press [MENU] then enter your password.
2
Press then select “Allow” or “Restrict”
with the Navigation Key.
Restricts a data call from being placed.
3
To save, press [OK].
DATA CALL
Allow : Allows a data call.
Restrict : Restricts a data call.
l
l
Restricts calling 900 dial service numbers.
3
To save, press [OK].
900#S
Allow : Allows calls to a 900-dial service.
Restrict : Restricts calls to a 900-dial service.
l
l
1
Press [MENU] then enter your password.
2
Press then select “Allow” or “Restrict”
with the Navigation Key.
TX-180 2004.9.3 7:34 PM 페이지68
C
H
4
71
S E T T I N G S
C
H
4
70
S E T T I N G S
Restricts calling long distance numbers – the phone is limited to
calling numbers within the area.
3
To save, press [OK].
LONG DISTANCE
Allow : Allows a long distance call.
Restrict : Restricts a long distance call.
l
l
1
Press [MENU] then enter your password.
2
Press then select “Allow” or “Restrict”
with the Navigation Key.
Changes your 4-digit password.
CHANGE CODE
2
Press .
3
Enter a new password then press [OK].
4
Enter the new password again and
press [OK].
1
Press [MENU] then enter your password.
Stores 3 phone numbers that can be called even in the lock mode.
2
Press then select a location with the
Navigation Key.
3
Press [SET] and input a phone number,
press [OK] again to save.
SPECIAL #’S
1
Press [MENU] then enter your password.
1
Press [MENU] then enter your password.
Clears all phone book and downloads entries from your phone.
2
Press .
ERASE ALL
3
Press to check “Phonebook” or “Downloads”
then press [OK] to erase all the items in
those categories.
TX-180 2004.9.3 7:34 PM 페이지70
C
H
4
73
S E T T I N G S
C
H
4
72
S E T T I N G S
Resets phone to default settings.
RESET PHONE
3
Select “Yes” or “No” with the Navigation Key.
Press [OK].
When you select "Yes" and [OK], you will see “Reset
Phone! this will reset to default settings” on the display.
1
Press [MENU] then enter your password.
2
Press .
4
To reset the phone, press [OK].
OTHERS
1
Press [MENU] .
2
Select “Any Key” or “Send Key” with the
Navigation Key.
3
To save, press [OK].
ANSWER OPTIONS
Any Key : Press any key to answer an incoming call except
, , and .
Send Key : Press only to answer a call.
l
l
To select an answer mode:
CALL ANSWER
To select Active Flip Answer mode:
1
Press [MENU] .
2
Select “On” or “Off” with the Navigation Key.
3
To save, press [OK].
ACTIVE FLIP
When Active Flip On is selected, an incoming phone call can
be answered simply by opening the phone.
When Active Flip Off is selected, you will need to open the
phone and use the Answer mode you have selected.
l
l
TX-180 2004.9.3 7:34 PM 페이지72
C
H
4
75
S E T T I N G S
C
H
4
74
S E T T I N G S
Press [MENU] .
Automatically answers a call after a preset amount of time.
Auto Answer only works when the phone is open.
1
2
Select one of the following with the Navigation Key.
3
To save, press [OK].
AUTO ANSWER
Off/5 Secs/10 Secs/18 Secs.
l
This function will not be active when you select Vibrate, Silent,
Etiquette or Ringer off as a ringer mode.
1
Press [MENU] .
Automatically redials a call up to 5 times after a set time interval.
2
3
Retry time to field is shown. Press the Navigation
Key left or right to choose the amount of time.
(Off, 3 Secs, 5 Secs, 7 Secs or 10 Secs.)
When a time is chosen for retry time, the repeat
field is shown. Press the Navigation Key down to
highlight the repeat field. Press the Navigation
Key left or right to choose the number of
repeats. (1 time, 3 times or 5 times).
4
To save, press [OK].
AUTO RETRY
1
Press [MENU] .
2
Select either “English” or “Spanish” with the
Navigation Key.
3
To save, press [OK].
LANGUAGE
Selects the language in which letters are displayed on the screen.
3
To save, press [OK].
“Enhanced” : Makes it more difficult to wire tap.
l
Enhances voice privacy and avoids tapping during a call.
1
Press [MENU] .
2
Select “Standard” or “Enhanced” with the
Navigation Key.
VOICE PRIVACY
TX-180 2004.9.3 7:35 PM 페이지74
S E T T I N G S S E T T I N G S
C
H
4
77
C
H
4
76
3
To save, press [OK].
To determine whether or not the network system can detect your
position:
1
Press [MENU] .
2
Select “911 Only” or “Location On” with the
Navigation Key.
LOCATION
911 Only : Your location will be hidden from network
& application except 911.
Location On : Your location is now available to the network.
l
l
Your phone is able to operate with a TTY (Teletypewriter) device in
both analog and digital modes. This feature is system dependent and
may not be available in all areas.
1
Press [MENU] .
2
Select one of the following options (TTY Off /
TTY+TALK / TTY+HEAR / TTY Full) with the
Navigation Key then press [OK].
TTY MODE
Selects the Preferred System.
SYSTEM
Press [MENU] .
Select one of the following options (Automatic B
/Automatic A /Home only) with the Navigation
Key then press [OK].
Automatic B : Scan the radio channels based on the
Automatic B setting.
Automatic A : Scan the radio channels based on the
Automatic A setting.
Home only : Only within your home area or home affiliated
area.
SET MODE
1
2
l
l
l
1
2
Press [MENU] .
Select “Yes” or “No” then, press [OK] to
save it.
Enables Auto NAM (Number Assignment Modules) or manually selects
a NAM.
Automatically switches phone to proper NAM when you have multiple
NAM registrations.
AUTO NAM
NAM SETTING
TX-180 2004.9.3 7:35 PM 페이지76
S E T T I N G S S E T T I N G S
C
H
4
79
C
H
4
78
1
2
Press [MENU] .
Select “NAM1-VERIZON” or “NAM2-VERIZON”
then press [OK] to save it.
Changes the NAM used by the phone when you have multiple
registrations.
CHANGE NAM
Displays the phone’s PRL (Preferred Roaming List).
1
2
Press [MENU] .
To return to the previous page, press [OK].
PRL ID
Displays the version of your phone:
PHONE INFO.
1
Press [MENU] .
2
The software version appears.
3
Press [OK].
S/W VERSION
1
Press [MENU] .
2
The hardware version appears.
3
Press [OK].
H/W VERSION
1
Press [MENU] .
2
The “Get It Now” software version appears.
3
Press [OK].
GET IT NOW VERSION
1
Press [MENU] .
ERI BANNER
3
To save, press [OK].
2
Select “On” or “Off” with the Navigation Key.
TX-180 2004.9.3 7:35 PM 페이지78
C
H
4
81
U T I L I T I E S
C
H
4
80
U T I L I T I E S
SCHEDULE
1
Press [MENU] .
ADD NEW PLAN
Sets an event and reminds you of that event.
2
3
Move the Navigation Key left, right, up or down to
choose a date in the calendar then press [OK].
Use the keypad to change or enter the date
then press [OK].
Default : To set default ringer type.
Change : Choose a ringer type from the list.
DATE SETTING
Use the keypad to set a time and to select
“AM” or “PM” then press [OK].
TIME SETTING
Select an alert time interval option (On Time, 10 Min
Before, 30 Min Before, 1 Hour Before, No Alarm) by
pressing the Navigation Key left or right.
SETTING
To set a Ringer, press [MENU], then select
“Default” or “Change” using the Navigation Key.
To save it press [SELECT].
RINGER SETTING
Use the keypad to input a plan message then
press [OK].
PLAN SETTING
The date field is highlighted. Press the Navigation
Key down to set the alarm options.
You can set up to 3 alarms.
ALARM
To display alarm entries, press [MENU] .
1
1
To view the Event List,
press [MENU] .
VIEW PLAN
2
Move the Navigation Key to choose an event
then press [OK] or [ERASE].
Press [MENU], then select “Erase All” using
the Navigation Key, “Erase all plans?” Will
happen. Press [OK] to delete.
4
Press [SAVE] to save it or [CLR] to
return to the calendar.
5
The date of the event will be marked on your
calendar.
Select one of the entries using the Navigation Key.
To set a new alarm, choose alarm 1, 2 or 3.
To edit an existing alarm, select that alarm.
Press [OK].
2
The setting field will be highlighted. Press the
Navigation Key down to select alarm options.
3
Use the Navigation Key to select a setting for the
alarm (Once, Daily, Weekly, Monthly, Off).
SETTING
TX-180 2004.9.3 7:35 PM 페이지80
C
H
4
83
U T I L I T I E S
C
H
4
82
U T I L I T I E S
To save an alarm setting press [SAVE].
4
Default : To set default ringer type.
Change : To select a custom ringer from the list.
Once: Enter a date.
Daily: Select a time.
Weekly: To select “Monday”, “Tuesday”, “Wednesday”,
“Thursday”, Friday”, “Saturday”, “Sunday”.
Monthly: Select 1st – 31st
Off
To set a “Ringer” press [MENU], then select
“Default” or “Change” using the Navigation Key.
To save it, press [SELECT].
RINGER SETTING
Use the Navigation Key to select a Snooze setting
(Off, 1 time after 5 min, 1 time after 10 min, 3 times
by 5 min).
SNOOZE SETTING
Using the keypad, input an alarm message then
press [OK].
PLAN SETTING
Your phone includes an internal memo pad that can be used to
compose and store reminders and notes.
MEMO PAD
1
Press [MENU] .
ADD MEMO
2
Input a new text memo.
(Please refer to page 31 for more details on entering
letters, numbers & symbols.)
1
1.1. Press [MENU] .
VIEW MEMO
2
The list of all memos, in saved order, is displayed.
Select a memo then press [OK].
3
The selected memo will appear. To edit it,
press [MENU], select “Edit” and input a new
text memo, then press [OK] to save it.
1
Press [MENU] .
SETTINGS
2
Select (Paper/Pattern/Sea/Sky/Flower) by pressing
Navigation Key left or right then press [OK].
To compose a memo (there is an 80-letter limit):
To view a saved memo:
To select memo pad background image:
1.2. To erase a memo, press [ERASE].
1.3. To add a new memo, press [MENU]
“New Memo”.
1.4. To erase all memos, press [MENU]
“Erase All”.
3
To save memo, press [OK].
Use the keypad to set a time for the event and
to select “AM” or “PM”, then press [OK].
TIME SETTING
Use the keypad to change or enter the date for the
alarm then press [OK].
If weekly is chosen for setting, date field becomes
day of the week field.
DATE SETTING
TX-180 2004.9.3 7:35 PM 페이지82
C
H
4
85
U T I L I T I E S
C
H
4
84
U T I L I T I E S
1
Press [MENU] .
2
Follow the instructions below to calculate
8*6Ö4-2.5= 9.5
3
To reset, press [RESET].
1
Press [MENU] .
To access the calculator:
CALCULATOR
To display the time and date in pre-programmed cities:
WORLD CLOCK
Input 8.
Move the Navigation Key rightward.
Input 6 then press the Navigation Key.
Move it leftward.
Input 4 then press the Navigation Key.
Move it downward.
Input 2 then press the to input (.).
Press 5.
Then press and you will see the answer.
: X, : -, : /, : +, : ., : Reset, : =.
2
4
Select a city with the Navigation Key.
3
The world map appears with the city, its date
and time.
Use the Navigation Key to select another city.
As the daylight saving time is not applied, it may be different from
the actual time during DST.
1
Press [MENU] .
2
3
Simultaneously times up to six different events. To operate the
stop watch:
STOP WATCH
To measure a time period.
1. To start the stop watch, press [START].
2. To pause it, press [STOP].
3. To resume it, press .
To reset it, press [RESET].
To return to the previous page, press [EXIT].
To time up to six events at once:
1. To start, press [START].
2. To stop a time period and continue
measuring another one, press [CONT].
3. To stop the second and continue measuring
a third one, press [CONT].
4. To measure up to six time periods, repeat the
above steps.
5. To stop the stop watch, press [STOP].
6. To review the results, press [VIEW].
7. To return to the stop watch, press [OK].
8. To reset it, press [RESET].
To return to the previous page, press [OK].
TX-180 2004.9.3 7:35 PM 페이지84
VOICE SERVICE
This chapter addresses Voice Service, an advanced feature that
allows you to place calls using your voice. With Voice Memo (VM)
you can record voice messages and set the Answering Machine.
Topics include:
VOICE TOOLS MENU
VOICE RECOGNITION MODE
Chapter 5
87
86
C
H
5
87
M E M O
C
H
4
TX-180 2004.9.3 7:35 PM 페이지86
C
H
5
89
VOICE TOOLS MENU
C
H
5
88
VOICE TOOLS MENU
VOICE MEMO
Voice Memo allows you to record a reminder message that can be up
to 60 seconds. To record a memo:
1
To start Tools menu, press [MENU] .
2
To enter a voice memo, press .
3
1.1.To record a voice memo, press .
Instructions will be displayed and you will
hear “Please record at the tone.”
1.2.To stop recording a memo, press [STOP]
or [PAUSE/RESUME].
1.3. Press [MENU] after recording a voice memo
to “Review” or “Re-record.”
1.4. Press [SAVE] to input a “Voice Memo” title,
then press [OK]. (See page 31 for more
information on entering letters, numbers and
symbols.)
2.To play voice memo, press .
Select the message you want to play then
press [PLAY] or press [MENU] to
1. Edit Title.
Press [ERASE] to erase the memo.
3.To play speaker mode, press .
Select the message you want to play then
press [PLAY] or press [MENU] to
1. Edit Title.
Press [ERASE] to erase the memo.
4.To erase all voice memos, press .
“Erase all voice memos?” will be displayed.
Press [OK] to erase all voice memos.
VOICE DIAL
Voice Dial allows you to call a person by simply saying their name.
To access Voice Dial:
1
To start Voice Tools menu, press [MENU] .
2
To enter a voice dial, press .
3
1.1. To record a voice dial, press .
The phone book list will be displayed
alphabetically. Select a name then press
[OK]. Instructions will be displayed and you
will hear “Name Please”.
1.2. Say the name for the voice tag and repeat the
name when prompted. You will hear “Added”.
2. To play a voice dial, press .
Highlight the voice tag you want to play then
press [PLAY] or press [ERASE].
3. To play speaker mode, press .
Highlight the voice tag you want to play then
press [PLAY] or press [ERASE].
4. To erase all voice dials, press .
“Removing all voice tags Proceed?” will be
displayed.
Press [OK] to erase all voice dials.
TX-180 2004.9.3 7:35 PM 페이지88
C
H
5
91
VOICE TOOLS MENU
C
H
5
90
VOICE TOOLS MENU
TRAIN WORDS
Train allows you to use Control words to make a call without using the
keypad.
2
“Please listen closely to hear instructions”
will be displayed and you will hear “Now
training control words. Please say the word
yes”.
3
Say “Yes”. You will hear “Again”. Say “Yes”
again. You will hear “Training word successful”.
Use to train or untrain the Voice Recognition with the control word,
“Yes”.
YES
1
Press [MENU] .
2
“Please listen closely to hear instructions” will
be displayed and you will hear “Now training
control words. Please say the word no”.
3
Say “No”. You will hear “Again”. Say “No” again.
You will hear “Training word successful”.
Use to train or untrain the Voice Recognition with the control word,
“No”.
NO
1
Press [MENU] .
WAKE-UP
1
Press [MENU] .
UNDO TRAIN ALL
2
“Undo voice recognition for all procedures?”
will be displayed. Press [OK] to undo all
trained words.
Press [MENU] .
1
Use to train or untrain the Voice Recognition with the control word,
“Wake-Up”.
Undo Train All erases all “trained” words.
2
“Please listen closely to hear instructions” will
be displayed and you will hear “Now training
control words. Please say the word Wake-
Up”.
3
Say “Wake-Up”. You will hear “Again”.
Say “Wake-Up” again. You will hear “Training
word successful”.
TX-180 2004.9.3 7:35 PM 페이지90
C
H
5
93
VOICE RECOGNITION MODE
C
H
5
92
VOICE TOOLS MENU
VOICE SETTING
1
Press [MENU] .
1
Press [MENU] .
SET ACTIVE
HFK MODE
2
Select “Active Flip” or “Send Key” by
pressing the Navigation Key left or right.
3
To save, press [OK].
2
Scroll to HFK Mode. Select “On” or “Off” by
pressing the Navigation Key left or right.
3
To save, press [OK].
Allows the user to activate or deactivate voice dial service.
While using the Hands Free Kit, activates or deactivates the voice
recognition function.
NAME
Voice Recognition (VR) enables you to place calls using your voice
and to record voice memos.
Only phone numbers with saved voice tags can be called in VR mode.
See page 89 for more on creating voice tags.
1
Press and hold until your phone turns to
Voice Recognition mode.
2
“Please say the name after the
prompt tone” will be displayed
and you will hear “Name please”.
1
Press and hold until your phone turns to
Voice Recognition mode.
2
If you say a name or tag that is already in the
phone book, the number and name will be
displayed and you will hear “Calling (name).”
If no recorded voice dial, “No entries recorded” message
will be displayed.
TX-180 2004.9.3 7:35 PM 페이지92
VOICE MAIL AND TXT
MESSAGING
This chapter addresses Voice Mail and TXT Messaging functions
including:
WHEN A NEW MESSAGE ARRIVES
VOICE MAIL
NEW TXT MSG
INBOX
OUTBOX
WEB ALERTS
SAVED
QUICK TEXT
ERASE ALL
SETTINGS
Chapter 6
95
94
C
H
6
95
M E M O
C
H
5
TX-180 2004.9.3 7:35 PM 페이지94
1
To access your voice mail,
press [MENU] or .
Displays the number of voice mails and accesses them by pressing .
VOICE MAIL
C
H
6
97
C
H
6
96
WHEN A NEW MESSAGE ARRIVES NEW TXT MSG
1
The following display appears
when a new message arrives.
2
To display the message, press [READ].
1
Press [MENU] or .
To send a new message:
2
Under “Send To”, input the phone number and
press [OK].
3
Under “Message”, input a new TXT message
then press [OK].
By pressing [MENU], you can choose from the following:
1. Find : Search the phone number which is stored in the
phone book.
2. Save : Stores the phone number the message was sent to.
3. Msg. Group : Select all the phone numbers in a group.
4
The default call back number is automatically
included into the Default CB# field. You can
scroll to the number and edit it or simply
press [EDIT].
7
7.1. To send the TXT message press [MENU],
select “Send,” then press [OK].
7.2. To save the TXT message press [MENU],
select “Save to Outbox,” then press [OK].
5
Press the Navigation Key down for more fields.
Under “Priority”, select “Normal’ or “Urgent”.
6
Under “Insert Signature”, select “On” or “Off”.
By pressing [MENU], in the message input screen you can
choose from the following:
1. Insert Quick Text: Inserts canned text into a TXT Msg.
2. Insert Sound: Inserts sound in TXT Msg.
3. Insert Picture: Inserts picture in TXT Msg.
4. Insert Animation: Inserts Animation in TXT Msg.
5. Save to Quick Text: Saves the written sentences into
Quick TXT.
(Please refer to page 31 for more details on entering letters,
numbers and symbols.)
FIRST TIME USER
1
Dial *86 then press [SEND].
2
At the recording, press .
3
To set up your account follow the voice tutorial.
EXISTING USER
1
Dial *86 then press [SEND].
2
At the recording, enter your 4 digit password,
then press .
3
To listen to new messages, press .
TX-180 2004.9.3 7:35 PM 페이지96
I N B O X I N B O X
C
H
6
99
C
H
6
98
SAVE TO CONTACT
1
Select to save number to contacts.
SAVE MEDIA
1
To save a picture to the media gallery folder.
FORWARD
1
To forward the TXT message:
2
Input the phone number of the person you are
sending the message, then press [OK].
3
Input any text message to go along with the
forwarded message, then press [OK].
1
Press [MENU] or .
: Urgent New Msg (not read)
: Urgent Read Msg
: New Msg (not read)
: Old Msg (already read)
: Lock (already read and locked)
The Inbox manages received TXT messages. To access:
2
Select a message then press [OK].
The message is displayed. To delete a message,
press [ERASE].
Press [MENU].
3
REPLY
1
Type your reply then press [OK].
REPLY WITH COPY
1
2
3
4
5
To reply to a received message and include the
received message into the message:
The default call back number is automatically
included into the Default CB# field.
You can scroll to the number and edit it.
To send the text message, press [MENU] and
select “Send”, then press [OK].
To save the text message, press [MENU] and
select “Save to Outbox”, then press [OK].
Under “Insert Signature”, select “On” or “Off”.
SAVE TO SAVED
1
Select to save the TXT message to your phone.
SAVE TO QUICK TEXT
LOCK & UNLOCK
1
To lock or unlock the TXT message:
2
Select “Lock” to lock the message or “Unlock”
to unlock the message, then press .
1
Select to save received text msg to “Quick Text”.
BLOCK SENDER
1
Select to block all incoming messages from
addresses on block list.
“Save Media" menu appears only when you receive a pix message
or EMS message.
TX-180 2004.9.3 7:35 PM 페이지98
O U T B O X O U T B O X
C
H
6
101
C
H
6
100
CHECKING SENT TXT MESSAGES
1
Press [MENU] or .
RESEND
1
To resend a TXT message.
Manages sent text messages or messages waiting to be sent.
EDIT MESSAGE
1
3
Input the phone number then press .
2
Input a TXT message then press .
To send a message to another person:
: Auto resend
: Delivered
: Fail
: Not Sent
: Read
: Sent
2
2.1. Select a message, then press [OK].
The text message is displayed.
Press [MENU].
3
2.2. To erase message, press [ERASE].
STATE
1
Select to display the status of an outbox
message.
SAVE TO SAVED
1
Select to save the TXT message to your phone.
LOCK & UNLOCK
1
To lock or unlock the TXT message:
2
Select “Lock” to lock the message or “Unlock”
to unlock the message, then press [OK].
SAVE TO CONTACT
1
Select to save number to contacts.
"State" menu appears only when you receive a text message.
TX-180 2004.9.3 7:35 PM 페이지100
C
H
6
103
C
H
6
102
S A V E DWEB ALERTS
WEB ALERTS
1
Press [MENU] or .
2
To select GoTo, press .
To select Erase Message, press .
3
The Web Alerts message will be displayed.
• [ ] : Read Message.
• [ ] : Unread Message.
• [ ] : Displays the remaining text.
• GoTo : Connecting to Selected Site.
• Erase : Erase Selected Message.
V
Manages saved messages from the Inbox/Outbox.
SAVED
1
Press [MENU] or .
2
2.1. Select a TXT message then press [OK].
The TXT message is displayed.
2.2. To erase message, press [ERASE].
4
The following menu options will appear, if the
TXT message is saved from the “Inbox” menu.
3
Press [MENU].
The following menu options will appear, if the
TXT message is saved from the “Outbox” menu.
5
Select one by pressing [OK].
To select inbox menu : Reply, Reply With Copy, Forward,
Save Media, Save to Quick Text,
Block Sender,Save to Contact,
Lock & Unlock
To select outbox menu : Resend, Edit Message,
Save to Contact, Lock & Unlock,
State
• "Save Media" menu appears only when you receive a pix
message or EMS message.
• "State" menu appears only when you receive a text message.
TX-180 2004.9.3 7:36 PM 페이지102
C
H
6
105
C
H
6
104
ERASE ALLQUICK TEXT
1
Press [MENU] or .
To edit the Quick Text message you have saved:
QUICK TEXT
2
2.1. Select a message from the list.
Press [MENU].
2.2. To add a new Quick Text message,
press [ADD NEW]. To edit the Quick
Text message you have selected,
press [EDIT].
3
To erase the saved Quick Text message,
press [ERASE].
ERASE MESSAGES
1
Press [MENU] or .
2
1. To erase all the inbox messages, press .
3
Select “OK” or “Cancel” with [OK]
or [CANCEL].
2. To erase all the outbox messages, press .
3. To erase the saved messages, press .
Old Inbox : To erase all messages already read.
(However, the locked Message(s) will not be deleted).
Entire Inbox : To erase all messages.
TX-180 2004.9.3 7:36 PM 페이지104
C
H
6
107
C
H
6
106
S E T T I N G SS E T T I N G S
SAVE SENT MSG
Press [MENU] or .
Press .
Select either “Off”, “On” or “Prompt” with
the Navigation Key.
Press [OK].
Manages messaging features through various features.
1
2
3
DEFAULT CALLBACK
1
Press [MENU] or .
2
Press .
Input a callback number, then press [OK].
Edits a default callback number so that the recipient can callback or
reply.
You can look it up from the phone book by
pressing [FIND].
Press .
Select “Disable” or “Enable” with Navigation Key.
Press [OK].
OUTBOX
1
2
3
Press [MENU] or .
Press [MENU] or .
AUTO ERASE
Press .
Select “Disable” or “Enable” with Navigation Key.
Automatically erases inbox/outbox messages when new messages
arrive.
Press [OK].
INBOX
1
2
3
EDIT VOICE CALLBACK
1
2
Press .
Input a new voice call back number or edit
voice call back number.
3
Press [OK].
Press [MENU] or .
You can look it up from the phone book by
pressing [FIND].
TX-180 2004.9.3 7:36 PM 페이지106
C
H
6
109
C
H
6
108
S E T T I N G SS E T T I N G S
ENTRY MODE
1
2
Press .
Select “Alpha Mode” or “T9 Mode” with
the Navigation Key.
3
Press [OK].
Sets an Entry Mode as a default. For example, if T9 Mode is the
default, its icon will appear.
Press [MENU] or .
Create a signature that can be automatically inserted at the end of a
message.
EDIT SIGNATURE
1
Press [MENU] or .
2
Press .
To input “Signature”, put the cursor on Edit
Signature then enter Signature Edit window by
using right or left direction keys.
3
To activate Signature function, put the cursor on
Insert Signature then select “On” by using right
or left direction keys. To deactivate Signature
function, select “Off”.
4
Press [OK].
DIRECT VIEW
1
2
Press .
Select “On” or “Off” with the Navigation Key.
ON : Set to read msg without entering inbox in SMS menu.
OFF : Set to read msg after entering inbox in SMS menu.
3
Press [OK].
Press [MENU] or .
If the Direct View is set to on, the user will be able to view the
message by pressing the read key. If the Direct View is set to off,
the user can view the message by entering SMS Menu-> Inbox.
REMIND
1
Press [MENU] or .
2
3
Press .
Select “On” or “Off” with the Navigation Key.
Press [OK].
TX-180 2004.9.3 7:36 PM 페이지108
MOBILE WEB 2.0
This chapter addresses Internet services and web browsing.
For more detailed information contact your service provider.
LAUNCHING MOBILE WEB 2.0
BROWSER MENU
Chapter 7
C
H
7
111
C
H
6
110
S E T T I N G S
3
Press [OK].
BLOCK OR UNBLOCK
1
2
Then press .
Select “Block”, “Unblock” or “View List of
Blocked Addresses” with the Navigation Key.
Press [MENU] or .
BLOCK : Enter the address to block.
UNBLOCK : Enter the address to remove from block.
VIEW LIST OF BLOCKED ADDRESSES : Display the blocked
list on LCD.
TX-180 2004.9.3 7:36 PM 페이지110
LAUNCHING MOBILE WEB 2.0 BROWSER MENU
C
H
7
113
C
H
7
112
BACK
1
To return to the previous page, press [MENU]
or , then press .
ACCESS THE INTERNET
1
To start your Internet browser and access
websites through your wireless handset press
[MENU] or .
HOME
1
To display the homepage, press [MENU]
or , then press .
ADDRESS
1
To select “Address”, press [MENU]
or , then press .
REFRESH
1
To select “Refresh”, press [MENU]
or , then press .
BROWSER MENU
The browser menu lists the actions necessary to operate the browser.
press [MENU] or press .
When the history item is selected from the browser menu, the browser is
displayed with the browser version and copyright information.
The device layer version is also displayed.
When the home item is selected from the browser menu, the phone
displays the home page.
Selecting the “Address” action displays the URL of the current
page.
Selecting the refresh item from the browser menu refreshes the current
page.
HISTORY
1
To select “History”, press [MENU]
or , then press .
FORWARD
1
To forward to the next page, press [MENU]
or , then press .
CLEAR MEMORY
1
To clear browser memory, press [MENU]
or , then press .
SETTINGS
1
To select “Settings”, press [MENU]
or , then press .
TX-180 2004.9.3 7:36 PM 페이지112
BROWSER MENU
SAFETY AND
WARRANTY
This chapter addresses the safety guidelines and precautions to
follow when operating your phone. Before operating your phone,
please be aware of all the safety details.
This chapter contains the terms and conditions of services and the
warranty for your phone. Please review them thoroughly.
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
SAFETY INFORMATION FOR FCC RF EXPOSURE
SAR INFORMATION
FDA CONSUMER UPDATE
PROTECT YOUR WARRANTY
12 MONTH LIMITED WARRANTY
Chapter 8
115
C
H
7
C
H
8
114
ADVANCED
1
To select “Advanced”, press [MENU]
or , then press .
Selecting the advanced item in the browser menu displays the
advanced menu items.
To exit browser, press [MENU]
or , then press .
EXIT
1
TX-180 2004.9.3 7:36 PM 페이지114
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
117
C
H
8
C
H
8
116
Your wireless handheld portable telephone is a low power radio
transmitter and receiver. When it is ON, it receives and also sends out
radio frequency (RF) signals.
In August 1996, the Federal Communications Commissions (FCC)
adopted RF exposure guidelines with safety levels for handheld wireless
phones. Those guidelines are consistent with the safety standards
previously set by both U.S. and international standards bodies:
ANSI C95.1 (1992) *
NCRP Report 86 (1986) *
ICNIRP (1996) *
Those standards were based on comprehensive and periodic evaluations
of the relevant scientific literature. For example, over 120 scientists,
engineers, and physicians from universities, government health agencies,
and industry reviewed the available body of research to develop the ANSI
Standard (C951).
The design of your phone complies with the FCC guidelines (and those
s t a n d a r d s ) .
EXPOSURE TO RADIO FREQUENCY SIGNALS
Use only the supplied or an approved replacement antenna. Unauthorized
antennas, modifications, or attachments could damage the phone and
may violate FCC regulations.
ANTENNA CARE
Read This Information Before Using Your Handheld
Portable Cellular Telephone
Talking on the phone while driving is extremely dangerous and is illegal in
some states. Remember, safety comes first. Check the laws and regulations
on the use of phones in the areas where you drive. Always obey them.
Also, if using your phone while driving, please:
lGive full attention to driving. Driving safely is your first responsibility.
lUse hands-free operation, if available.
lPull off the road and park before making or answering a call, if driving
conditions so require.
If you must use the phone while driving, please use one-touch, speed dialing,
and auto answer modes.
An airbag inflates with great force. DO NOT place objects, including both
installed or portable wireless equipment, in the area over the airbag or in the
air bag deployment area. If in-vehicle wireless equipment is improperly
installed and the air bag inflates, serious injury could result.
DRIVING SAFETY
WARNING: Failure to follow these instructions may lead to serious
personal injury and possible property damage.
1* : American National Standards Institute.
2* : National Council on Radiation protection and measurements.
3* : International Commission on Nonionizing Radiation Protection.
TX-180 2004.9.3 7:36 PM 페이지116
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
119
C
H
8
C
H
8
118
The Health Industry Manufacturers Association recommends that a
minimum separation of six (6”) inches be maintained between a handheld
wireless phone and a pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent with the independent
research by and recommendations of Wireless Technology Research.
Persons with pacemakers :
lALWAYS keep the phone more than six inches from your
pacemaker when the phone is turned on.
lDo not carry the phone in a breast pocket.
lUse the ear opposite the pacemaker to minimize the potential for
i n t e r f e r e n c e .
lIf you have any reason to suspect that interference is taking place,
turn your phone OFF immediately.
PACEMAKERS
If you use any other personal medical device, consult the manufacturer of
your device to determine if they are adequately shielded from external RF
energy. Your physician may be able to assist you in obtaining this
i n f o r m a t i o n .
Turn your phone OFF in healthcare facilities when any regulations posted
in these areas instruct you to do so. Hospitals or healthcare facilities may
be using equipment that could be sensitive to external RF energy.
OTHER MEDICAL DEVICES
Turn your phone OFF where posted notices so require.
POSTED FACILITIES
ELECTRONIC DEVICES
Most modern electronic equipment is shielded from RF energy. However,
certain electronic equipment may not be shielded against the RF signals
from your wireless phone.
OTHER SAFETY GUIDELINES
FCC and Transport Canada Regulations prohibit using your phone while
in the air. Turn your phone OFF before boarding an aircraft.
AIRCRAFT
To avoid interfering with blasting operations, turn your phone OFF when in
a “blasting area” or in areas posted: “Turn off two-way radio.” Obey all
signs and instructions.
BLASTING AREAS
Turn your phone OFF when in any area with a potentially explosive
atmosphere and obey all signs and instructions. Sparks in such areas
could cause an explosion or fire resulting in bodily injury or even
death.
Areas with a potentially explosive atmosphere are often, but not
always, clearly marked. They include fueling areas such as gas
stations; below deck on boats; fuel or chemical transfer or storage
facilities; vehicles using liquefied petroleum gas (such as propane or
butane); areas where the air contains chemicals or particles, such as
grain, dust, or metal powders; and any other area where you would
normally be advised to turn off your vehicle's engine.
POTENTIALLY EXPLOSIVE ATMOSPHERES
TX-180 2004.9.3 7:36 PM 페이지118
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
SAFETY INFORMATION FOR
FCC RF EXPOSURE
121
C
H
8
C
H
8
120
PRECAUTIONS
Your Handheld Portable Telephone is a high quality piece of
equipment. Before operating, read all instructions and cautionary
markings on (1) AC Adaptor (2) Battery and (3) Product Using Battery.
DO NOT use this equipment in an extreme environment where
high temperature or high humidity exists.
DO NOT abuse the equipment. Avoid striking, shaking or
shocking. When not using, lay down the unit to avoid possible
damage due to instability.
DO NOT expose this equipment to rain or spilled beverages.
DO NOT use unauthorized accessories.
DO NOT disassemble the phone or its accessories. If service
or repair is required, return unit to an authorized Audiovox
cellular service center. If unit is disassembled, the risk of
electric shock or fire may result.
DO NOT short-circuit the battery terminals with metal items etc.
In August 1996 the Federal Communications Commission (FCC) of
the United States with its action in Report and Order FCC 96-326
adopted an updated safety standard for human exposure to radio
frequency electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the safety standard
previously set by both U.S. and international standards bodies. The
design of this phone complies with the FCC guidelines and these
international standards.
Use only the supplied or an approved antenna. Unauthorized
antennas, modifications, or attachments could impair call quality,
damage the phone, or result in violation of FCC regulations.
Do not use the phone with a damaged antenna. If a damaged
antenna comes into contact with the skin, a minor burn may result.
Please contact your local dealer for replacement antenna.
This device was tested for typical body-worn operations with the
b a c k o f t h e p h o n e k e p t 2 . 5 c m . f r o m t h e b o d y . T o m a i n t a i n
compliance with FCC RF exposure requirements, use only belt-clips,
hol st er s o r s im il ar a cc es so r ie s th a t ma in tai n a 2 .5 c m . se par a ti on
distance between the user’s body and the back of the phone,
including the antenna. The use of belt-clips, holsters and similar
accessories should not contain metallic components in its assembly.
The use of accessories that do not satisfy these requirements may
not comply with FCC RF exposure requirements, and should be
avoided.
BODY-WORN OPERATION
WARNING! Read this Information before using
CAUTIONS
For more information about RF exposure, please visit the FCC
website at www.fcc.gov
TX-180 2004.9.3 7:36 PM 페이지120
SAR INFORMATION SAR INFORMATION
123
C
H
8
C
H
8
122
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is designed
and manufactured not to exceed the emission limits for exposure to
radiofrequency (RF) energy set by the Federal Communications
Commission of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy
for the general population. The guidelines are based on standards that
were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the safety of all
persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted with the
phone transmitting at its highest certified power level in all tested
frequency bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone while operating
can be well below the maximum value. This is because the phone is
designed to operate at multiple power levels so as to use only the
power required to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be
tested and certified to the FCC that it does not exceed the limit
established by the government adopted requirement for safe exposure.
The tests are performed in positions and locations (e.g., at the ear and
worn on the body) as required by the FCC for each model. The highest
SAR value for this model phone when tested for use at the ear is 1.43
W/Kg and when worn on the body, as described in this user guide, is
0.289W /K g . (B ody -w orn mea su reme n ts d i ff er am ong p hon e mode ls ,
depending upon available accessories and FCC requirements). While
there may be differences between the SAR levels of various phones
and at various positions, they all meet the government requirement for
safe exposure.
The FCC has granted an Equipment Authorization for this model phone
with all reported SAR levels evaluated as in compliance with the FCC
RF exposure guidelines. SAR information on this model phone is on file
with the FCC and can be found under the Display Grant section of
http://www.fcc.gov/ oet/fccid after searching on PP4TX-180.
Additional information on Specific Absorption Rates (SAR) can be found
on the Cellular Telecommunications Industry Asso-ciation (CTIA) web-
site at http://www.wow-com.com.
* In the United States and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged over one gram of
tissue. The standard incorporates a sub-stantial margin of safety to give
additional protection for the public and to account for any variations in
measurements.
TX-180 2004.9.3 7:36 PM 페이지122
125124
FDA CONSUMER UPDATE FDA CONSUMER UPDATE
1. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health problems are
associated with using wireless phones. There is no proof, however, that wireless
phones are absolutely safe. Wireless phones emit low levels of radiofrequency
energy (RF) in the microwave range while being used. They also emit very low
levels of RF when in the stand-by mode. Whereas high levels of RF can produce
health effects (by heating tissue), exposure to low level RF that does not produce
heating ef-fects causes no known adverse health effects. Many studies of low level
RF exposures have not found any biological ef-fects. Some studies have
suggested that some biological ef-fects may occur, but such findings have not
been confirmed by additional research. In some cases, other researchers have had
difficulty in reproducing those studies, or in determining the reasons for
inconsistent results.
2. What is FDA’s role concerning the safety of wireless phones?
Under the law, FDA does not review the safety of radiation-emitting consumer
products such as wireless phones before they can be sold, as it does with new
drugs or medical de-vices. However, the agency has authority to take action if
wire-less phones are shown to emit radiofrequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could require the manufacturers of
wireless phones to notify users of the health hazard and to repair, replace or recall
the phones so that the hazard no longer exists. Although the existing scientific data
do not justify FDA regula-tory actions, FDA has urged the wireless phone industry
to take a number of steps, including the following:
• Support needed research into possible biological effects of RF of the type
emitted by wireless phones;
• Design wireless phones in a way that minimizes any RF ex-posure to the user
that is not necessary for device function;
and
• Cooperate in providing users of wireless phones with the best possible
information on possible effects of wireless phone use on human health.
FDA belongs to an interagency working group of the federal agencies that have
responsibility for different aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this working group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
• Federal Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information Administration
The National Institutes of Health participates in some inter-agency working group
activities, as well. FDA shares regulatory responsibilities for wireless phones with
the Federal Communications Commission (FCC). All phones that are sold in the
United States must comply with FCC safety guidelines that limit RF exposure. FCC
relies on FDA and other health agencies for safety questions about wireless
phones. FCC also regulates the base stations that the wireless phone networks
rely upon. While these base stations operate at higher power than do the wireless
phones themselves, the RF expo-sures that people get from these base stations
are typically thousands of times lower than those they can get from wire-less
phones. Base stations are thus not the subject of the safety questions discussed in
this document.
3. What kinds of phones are the subject of this update?
The term “wireless phone” refers here to hand-held wireless phones with built-in
antennas, often called “cell,” “mobile,” or “PCS” phones.
U.S. Food and Drug Administration -Center for Devices and
Radiological Health Consumer Update on Wireless Phones
These types of wireless phones can expose the user to measurable radiofrequency
energy (RF) because of the short distance between the phone and the user’s head.
These RF exposures are limited by Federal Communications Commission safety
guidelines that were developed with the advice of FDA and other federal health and
safety agencies. When the phone is located at greater distances from the user, the
exposure to RF is drastically lower because a person’s RF exposure decreases
rapidly with increasing distance from the source. The so-called “cordless phones,”
which have a base unit connected to the telephone wiring in a house, typically
operate at far lower power levels, and thus produce RF expo-sures far below the
FCC safety limits.
4. What are the results of the research done already?
The research done thus far has produced conflicting results, and many studies
have suffered from flaws in their research methods. Animal experiments
investigating the effects of radiofrequency energy (RF) exposures characteristic of
wire-less phones have yielded conflicting results that often cannot be repeated in
other laboratories. A few animal studies, how-ever, have suggested that low levels
of RF could accelerate the development of cancer in laboratory animals. However,
many of the studies that showed increased tumor develop-ment used animals that
had been genetically engineered or treated with cancer-causing chemicals so as to
be pre-dis-posed to develop cancer in the absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day. These conditions are not
similar to the conditions under which people use wireless phones, so we don’t
know with certainty what the results of such studies mean for human health. Three
large epidemiology studies have been published since December 2000. Between
them, the studies investigated any possible association between the use of
wireless phones and primary brain cancer, glioma, meningioma, or acoustic neu-
roma, tumors of the brain or salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful health effects from wireless
phone RF exposures. However, none of the studies can answer questions about
long-term exposures, since the average period of phone use in these studies was
around three years.
5. What research is needed to decide whether RF expo-sure from wireless
phones poses a health risk?
A combination of laboratory studies and epidemiological stud-ies of people
actually using wireless phones would provide some of the data that are needed.
Lifetime animal exposure studies could be completed in a few years. However,
very large numbers of animals would be needed to provide reliable proof of a
cancer promoting effect if one exists. Epidemiological stud-ies can provide data
that is directly applicable to human popu-lations, but 10 or more years’ follow-up
may be needed to pro-vide answers about some health effects, such as cancer.
This is because the interval between the time of exposure to a can-cer- causing
agent and the time tumors develop - if they do -may be many, many years. The
interpretation of epidemiologi-cal studies is hampered by difficulties in measuring
actual RF exposure during day-to-day use of wireless phones. Many fac-tors affect
this measurement, such as the angle at which the phone is held, or which model of
phone is used.
6. What is FDA doing to find out more about the possible health effects of
wireless phone RF?
FDA is working with the U.S. National Toxicology Program and with groups of
investigators around the world to ensure that high priority animal studies are
conducted to address impor-tant questions about the effects of exposure to
radiofrequency energy (RF). FDA has been a leading participant in the World Health
Orga-nization International Electromagnetic Fields (EMF) Project since its inception
in 1996. An influential result of this work has been the development of a detailed
agenda of research needs that has driven the establishment of new research pro-
grams around the world.
C
H
8
C
H
8
TX-180 2004.9.3 7:36 PM 페이지124
127126
FDA CONSUMER UPDATE FDA CONSUMER UPDATE
C
H
8
C
H
8
Again, the scientific data do not demonstrate that wireless phones are harmful. But
if you are concerned about the RF exposure from these products, you can use
measures like those described above to reduce your RF exposure from wire-less
phone use.
10.What about children using wireless phones?
The scientific evidence does not show a danger to users of wireless phones,
including children and teenagers. If you want to take steps to lower exposure to
radiofrequency energy (RF), the measures described above would apply to children
and teenagers using wireless phones. Reducing the time of wire-less phone use
and increasing the distance between the user and the RF source will reduce RF
exposure. Some groups sponsored by other national governments have advised
that children be discouraged from using wireless phones at all. For example, the
government in the United King-dom distributed leaflets containing such a
recommendation in December 2000. They noted that no evidence exists that us-
ing a wireless phone causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use by children was strictly precautionary;
it was not based on scientific evi-dence that any health hazard exists.
11.What about wireless phone interference with medical equipment?
Radiofrequency energy (RF) from wireless phones can inter-act with some
electronic devices. For this reason, FDA helped develop a detailed test method to
measure electromagnetic interference (EMI) of implanted cardiac pacemakers and
defibrillators from wireless telephones. This test method is now part of a standard
sponsored by the Association for the Ad-vancement of Medical instrumentation
(AAMI). The final draft, a joint effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This standard will allow
manufacturers to ensure that cardiac pacemakers and defibrillators are safe from
wireless phone EMI. FDA has tested hearing aids for interference from handheld
wireless phones and helped develop a voluntary standard sponsored by the
Institute of Electrical and Electronic Engi-neers (IEEE). This standard specifies test
methods and per-formance requirements for hearing aids and wireless phones so
that that no interference occurs when a person uses a “com-patible” phone and a
“compatible” hearing aid at the same time. This standard was approved by the
IEEE in 2000. FDA continues to monitor the use of wireless phones for pos-sible
interactions with other medical devices. Should harmful interference be found to
occur, FDA will conduct testing to assess the interference and work to resolve the
problem.
12.Where can I find additional information?
For additional information, please refer to the following re-sources:
• FDA web page on wireless phones (http://www.fda.gov/cdrh/ phones/index.html)
• Federal Communications Commission (FCC) RF Safety Pro-gram
(http://www.fcc.gov/oet/rfsafety)
• International Commission on Non-Ionizing Radiation Protec-tion
(http://www.icnirp.de)
• World Health Organization (WHO) International EMF Project
(http://www.who.int/emf)
• National Radiological Protection Board (UK) (http://www.nrpb.org.uk/)
The Project has also helped develop a series of public information documents on
EMF issues. FDA and the Cellular Telecommunications & Internet Asso-ciation
(CTIA) have a formal Cooperative Research and De-velopment Agreement
(CRADA) to do research on wireless phone safety. FDA provides the scientific
oversight, obtaining input from experts in government, industry, and academic or-
ganizations. CTIA-funded research is conducted through con-tracts to
independent investigators. The initial research will include both laboratory studies
and studies of wireless phone users. The CRADA will also include a broad
assessment of additional research needs in the context of the latest research
developments around the world.
7. How can I find out how much radiofrequency energy exposure I can get by
using my wireless phone?
All phones sold in the United States must comply with Federal Communications
Commission (FCC) guidelines that limit radiofrequency energy (RF) exposures. FCC
established these guidelines in consultation with FDA and the other federal health
and safety agencies. The FCC limit for RF exposure from wire-less telephones is
set at a Specific Absorption Rate (SAR) of 1.6 watts per kilogram (1.6 W/kg). The
FCC limit is consistent with the safety standards developed by the Institute of
Electri-cal and Electronic Engineering (IEEE) and the National Council on Radiation
Protection and Measurement. The exposure limit takes into consideration the
body’s ability to remove heat from the tissues that absorb energy from the wireless
phone and is set well below levels known to have effects. Manufacturers of
wireless phones must report the RF expo-sure level for each model of phone to the
FCC. The FCC website (http://www.fcc.gov/oet/rfsafety) gives directions for
locating the FCC identification number on your phone so you can find your
phone’s RF exposure level in the online listing.
8. What has FDA done to measure the radiofrequency en-ergy coming from
wireless phones ?
The Institute of Electrical and Electronic Engineers (IEEE) is developing a technical
standard for measuring the radiofrequency energy (RF) exposure from wireless
phones and other wireless handsets with the participation and leader-ship of FDA
scientists and engineers. The standard, “Recom-mended Practice for Determining
the Spatial-Peak Specific Absorption Rate (SAR) in the Human Body Due to
Wireless Communications Devices: Experimental Techniques,” sets forth the first
consistent test methodology for measuring the rate at which RF is deposited in the
heads of wireless phone users. The test method uses a tissue-simulating model of
the human head. Standardized SAR test methodology is expected to greatly
improve the consistency of measurements made at different laboratories on the
same phone. SAR is the mea-surement of the amount of energy absorbed in
tissue, either by the whole body or a small part of the body. It is measured in
watts/kg (or milliwatts/g) of matter. This measurement is used to determine
whether a wireless phone complies with safety guidelines.
9. What steps can I take to reduce my exposure to radiofrequency energy
from my wireless phone?
If there is a risk from these products—and at this point we do not know that there
is—it is probably very small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to minimize your exposure to
radiofrequency energy (RF). Since time is a key factor in how much exposure a
person receives, reducing the amount of time spent using a wireless phone will
reduce RF exposure.
• If you must conduct extended conversations by wireless phone every day, you
could place more distance between your body and the source of the RF, since
the exposure level drops off dramatically with distance. For example, you could
use a headset and carry the wireless phone away from your body or use a
wireless phone connected to a remote an-tenna.
TX-180 2004.9.3 7:36 PM 페이지126
PROTECT YOUR WARRANTY 12 MONTH LIMITED WARRANTY
C
H
8
129
C
H
8
128
Read your Warranty carefully, with the special consideration to
paragraph seven of the Limited Warranty for your unit.
“Warranty does not apply to... or to any product or part
thereof which has suffered through alteration... mishandling
misuse, neglect or accident”.
Many companies are making look alike accessories and in some cases,
promoting that their product is equal to or better than the Audiovox
product. Be careful. Some of these products may not be compatible to
use with your Audiovox product and may damage the unit or cause it to
malfunction. If service is required on your unit and it is determined that
a non-Audiovox accessory has created the problem with your unit, the
Warranty will not apply. In addition, if the unit has already suffered
irreversible damage by reason of a non-compatible accessory, the
Warranty will be voided. To protect your Warranty, use only compatible
accessories which cannot damage or interfere with the functioning of
your Audiovox product.
AUDIOVOX COMMUNICATIONS CORP.
555 Wireless Blvd., Hauppauge, New York 11788, 800-229-1235
16808 Marquardt Avenue, Cerritos, California 90703, 562-802-5100
Audiovox Canada
5155 Spectrum Way, Unit #5, Mississauga, Ontario
Canada L4W 5A1, 800-465-9672
Audiovox Communications Corp. (the Company) warrants to the
original retail purchaser of this Audiovox handheld portable cellular
telephone, that should this product or any part thereof during normal
consumer usage and conditions, be proven defective in material or
workmanship that results in product failure within the first twelve (12)
months period from the date of purchase, such defect(s) will be
repaired or replaced (with new or rebuilt parts) at the Company’s
option, without charge for parts or labor directly related to the defect(s).
The antenna, key pad, display, rechargeable battery and battery
charger, if included, are similarly warranted for twelve (12) months from
date of purchase.
This Warranty extends only to consumers who purchase the product in
the United States or Canada and it is not transferable or assignable.
This Warranty does not apply to:
(a) Product subjected to abnormal use or conditions, accident,
mishandling, neglect, unauthorized alteration, misuse, improper
installation or repair or improper storage;
(b) Product whose mechanical serial number or electronic serial number
has been removed, altered or defaced.
(c) Damage from exposure to moisture, humidity, excessive
temperatures or extreme environmental conditions;
(d) Damage resulting from connection to, or use of any accessory or
other product not approved or authorized by the Company;
(e) Defects in appearance, cosmetic, decorative or structural items such
as framing and non-operative parts;
(f) Product damaged from external causes such as fire, flooding, dirt,
sand, weather conditions, battery leakage, blown fuse, theft or
improper usage of any electrical source.
The Company disclaims liability for removal or reinstallation of the
product, for geographic coverage, for inadequate signal reception by
the antenna or for communications range or operation of the cellular
system as a whole.
To obtain repairs or replacement within the terms of this Warranty, the
product should be delivered with proof of Warranty coverage (e.g.
dated bill of sale), the consumer’s return address, daytime phone
number and/or fax number and complete description of the problem,
transportation prepaid, to the Company at the address shown below or
to the place of purchase for repair or replacement processing.
TX-180 2004.9.3 7:36 PM 페이지128
12 MONTH LIMITED WARRANTY
C
H
8
130
In addition, for reference to an authorized Warranty station in your area,
you may telephone in the United States (800) 229-1235, and in Canada
(800) 465-9672 (in Ontario call 905-712-9299).
THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS
WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT
PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S
LAIBILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER
FOR THE PRODUCT.
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,
SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN
WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY MUST
BE BROUGHT WITHIN A PERIOD OF 18 MONTHS FROM DATE OF
ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE
LIABLE FOR AN SPECIAL CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY,
EXPRESS OR IMPLIED, WHATSOEVER. THE COMPANY SHALL NOT
BE LIABLE FOR THE DELAY IN RENDERING SERVICE UNDER THIS
WARRANTY OR LOSS OF USE DURING THE TIME THE PRODUCT IS
BEING REPAIRED OR REPLACED.
No person or representative is authorized to assume for the Company
any liability other than expressed herein in connection with the sale of
this product.
Some states or provinces do not allow limitations on how long an
implied warranty lasts or the exclusion or limitation of incidental or
consequential damage so the above limitation or exclusions may not
apply to you. This Warranty gives you specific legal rights, and you may
also have other rights which vary from state to state or province
to province.
IN USA : AUDIOVOX COMMUNICATIONS CORP.
555 Wireless Blvd.
Hauppauge, NY 11788
(800) 229-1235
IN CANADA : AUDIOVOX COMMUNICATIONS CANADA CO.
5155 Spectrum Way, Unit #5
Mississauga, Ontario L4W 5A1
(800) 465-9672
Model : CDM-8615VI
TX-180 2004.9.3 7:36 PM 페이지130
