Tsunami MP.11 Model 954-R
Features and Specifications
PN 73865 1
Introduction
The Tsunami MP.11 Model 954-R Base Station and Subscriber Units (BSUs and SUs) are flexible wireless outdoor
routers that let you design solutions for point-to-point links and point-to-multipoint networks. The 954-R operates in the
900 MHz band.
The 954-R is part of the Tsunami MP.11 product family, which is comprised of several additional products, including:
• The 5054 Base Station (BSU) and the 5054 Subscriber Unit (SU) for indoor installation
• The 2454-R, 5054-R, and 4954-R Base Station and Subscriber Station Units for outdoor installation
• The 5054 Base Station (BSU), the 5054 Subscriber Unit (SU), and the 5012-SUI Subscriber Unit for indoor installation
• The 5012-SUR Subscriber Unit for outdoor installation
Key Features
Key features of the MP.11 product family include:
• The use of a highly optimized protocol for outdoor applications
• Routing and bridging capability
• Asymmetric bandwidth management
• Management through a Web Interface, a Command Line Interface (CLI), or Simple Network Management Protocol
(SNMP)
• Software and configuration upgrade through file transfer (TFTP)
• Outdoor placement, close to the antenna, for significantly improved range and ease of installation
• VLAN support
![](/img.php?id=793928&img=bg2.png)
Tsunami MP.11 Model 954-R
Features and Specifications
PN 73865 2
Technical Specifications
Part Numbers
Radio Units
Base Station Unit
Subscriber Unit
Accessories
Surge Arrestors/Cables
Power Injector
Outdoor Ethernet Cables
Part Number Description
954-BSUR-US Tsunami MP.11 Model 954-R Base Station Unit with Type-N Connector – US/CAN
Part Number Description
954-SUA-US Tsunami MP.11 Model 954-R Subscriber Unit with Type-N Connector – US/CAN
Part Number Description
5054-SURGE Surge Arrestor 0-6 GHz - Standard-N Female to Female
848 274 171 20 ft Low Loss Antenna Cable St-N - Male-Male LMR 200
848 332 789 20 ft Low Loss Antenna Cable St-N - Male-Male LMR 400
5054-ULA400-50 50 ft Low Loss Antenna Cable St-N - Male-Male LMR 400
848 274 205 75 ft Low Loss Antenna Cable St-N - Male-Male LMR 400
69828 6 ft Low Loss Antenna Cable St-N - Male-Male LMR 600
5054-LMR600-50 50 ft Low Loss Antenna Cable St-N - Male-Male LMR 600
70251 PoE (Power over Ethernet) Surge Arrestor for Tsunami MP.11 and QuickBridge.11
Part Number Description
69823 Spare Power DC Injector for Tsunami MP.11 or QB.11 (-R model ONLY)
Part Number Description
69819 25m outdoor, terminated CAT5 cable for Tsunami MP.11 or QB.11 with three RJ-45
and one weather-proof Ethernet port cap
69820 50m outdoor, terminated CAT5 cable for Tsunami MP.11 or QB.11 with three RJ-45
and one weather-proof Ethernet port cap
69821 75m outdoor, terminated CAT5 cable for Tsunami MP.11 or QB.11 with three RJ-45
and one weather-proof Ethernet port cap
![](/img.php?id=793928&img=bg3.png)
Tsunami MP.11 Model 954-R
Features and Specifications
PN 73865 3
External 900 MHz Antennas
TBD
Regulatory Approvals and Frequency Ranges
OFDM Modulation Rates
NOTE: Maximum packet size: 1526 Bytes
Wireless Protocol
Interfaces
Region/Country Country MHz Number of
Channels
Certification
North America USA 902 - 928 2 In Process
Canada 902 - 928 2 In Process
Modulation Rate
BPSK 6 and 9 Mbps
QPSK 12 and 18 Mbps
16-QAM 24 and 36 Mbps
64-QAM 48 and 54 Mbps
Category Specification
Wireless Protocol Worp (Wireless Outdoor Router Protocol)
Category Specification
Wired Ethernet Auto-sensing 10/100BASE-TX Ethernet
Serial Connector RJ11 port built-into the unit, DB9 Female via a converter
included
Antenna Connector for BSU and
SU with Type-N Connector
Standard Type-N Female
![](/img.php?id=793928&img=bg4.png)
Tsunami MP.11 Model 954-R
Features and Specifications
PN 73865 4
Receive Sensitivity
NOTE: BER=10-6
• Rx Sensitivity values will have a tolerance of +/- 2 dB
Maximum Throughput
NOTE: Actual throughput performance in the field may vary.
Latency
Modulation Rate
64QAM ¾ -70 dBm @ 54 Mbps
64QAM ½ -73 dBm @ 48 Mbps
16QAM ¾ -79 dBm @ 36 Mbps
16QAM ½ -82 dBm @ 24 Mbps
QPSK ¾ -86 dBm @ 18 Mbps
QPSK ½ -87 dBm @ 12 Mbps
BPSK ¾ -89 dBm @ 9 Mbps
BPSK ½ -90 dBm @ 6 Mbps
Data Rate Throughput
54 Mbps 30 Mbps
48 Mbps 28 Mbps
36 Mbps 18 Mbps
24 Mbps 14 Mbps
18 Mbps 12 Mbps
12 Mbps 9 Mbps
9 Mbps 7 Mbps
6 Mbps 5 Mbps
Category Specification
Typical at Max Throughput 10 ms (as measured with test equipment under controlled lab conditions and
best performing packet size)
![](/img.php?id=793928&img=bg5.png)
Tsunami MP.11 Model 954-R
Features and Specifications
PN 73865 5
Transmit Power Settings
• Output Power Attenuation: 0 - 18 dB, in 1 dB steps
• Output Power Values will have a tolerance of +/- 1 dB
Range Information
Hardware Specifications
Software Features
Frequency 6-24 Mbps @ 20 MHz
16QAM ½; QPSK ¾;
QPSK ½; BPSK ¾;
BPSK ½
36 Mbps @ 20 MHz
16QAM ¾
48 Mbps @ 20 MHz
64QAM ½
54 Mbps @ 20 MHz
64QAM ¾
902-928 MHz 28 dBm 26 dBm 24 dBm 23 dBm
Frequency 54 Mbps 36 Mbps 6 Mbps
902 - 928 MHz 4 mi. 8 mi. 12 mi.
Category Specification
Processor 166 MHz Motorola 8241 processor
Memory Flash: 8 MB; RAM: 16 MB
Category Specification
Key Features • WORP protocol
• Transmit Power Control
• Antenna Alignment (CLI output)
• Integrity Check for Software Upload
• QoS Support; up to 8 classes of service, up to 8 service flows per class (BSU
only)
• Satellite Density
• Enhanced Dynamic Frequency Selection (Configured on BSU)
• Redundancy
• Spanning Tree (802.1D)
Bridging and Routing • Bridge (802.1d)
• IP/ RIPv1 (RFC 1058)
• IP/ RIPv2 (RFC 1388)
• CIDR (RFC 1519)
• ICMP (RFC 792)
• IP (RFC 791)
• ARP (RFC 826)
![](/img.php?id=793928&img=bg6.png)
Tsunami MP.11 Model 954-R
Features and Specifications
PN 73865 6
Management
LEDs
Filtering • Ethernet protocol (Ethertype)
• Static MAC
• Storm threshold
• IP address
• Broadcast protocol
• Intra Cell Blocking (Configured on BSU)
Services • DHCP Server (RFC 2131)
• DHCP Client (RFC 2131)
• Bi-Directional Bandwidth Control
• NAT (RFC 3022) (Configured on SU)
• DHCP Relay (RFC 2131) (Configured on SU)
VLAN • 802.1Q (Configured on BSU)
Security Features • Critical feature support via WORP for secure long-range wireless deployments
in unlicensed frequency spectrum
• MD5 (embedded in WORP) authentication between BSU and SU
• Filter based on packet information such as unicast/multicast/ broadcast MAC or
IP
• MAC Authentication (Configured on BSU)
• Secure “over the air encryption” with WEP, WEP+, and AES, and AES-CCB
• RADIUS MAC Access Control (Configured on BSU)
• RADIUS (RFC 2138)
• Intra-cell blocking to allow the BSU to act as the central policy enforcer for SU
to SU communications
Category Specification
Local RS-232 Serial port (RJ11 port built-into the unit; DB9 female via a converter,
included)
Remote HTTP Server (RFC 2616); Telnet (RFC 855), TFTP Client (RFC 783), Link Test,
SU/BSU Statistics, temperature logging, remote reboot/reset
SNMP SNMPv1/v2 (RFC 1157); SNMPv2c (RFC 1907); MIB-II (RFC 1213); Ethernet-like
MIB (RFC 1643); BridgeMIB (RFC 1483); 802.3MAU (RFC 2668); 802.11 MIB;
Private MIB; ORiNOCO MIB
Category Specification
Types Two indicators on RJ45 connector to indicate:
• Power
• Wireless Activity
• Ethernet Activity
Category Specification
![](/img.php?id=793928&img=bg7.png)
Tsunami MP.11 Model 954-R
Features and Specifications
PN 73865 7
Power Requirements
Physical and Environmental Specifications
MTBF and Warranty
Category Specification
Power-over-Ethernet • Custom Power over Ethernet (802.3af compatible)
• Input: Voltage 110 to 250 VAC (47-63Hz)
• Output: 48V @ 420mA MAX (injected into the Cat-5 Cable)
Outdoor Radio Unit • Power Consumption: 7.5W typical. Up to 20 Watts across full operating
temperature range.
• Input: Voltage 42 to 60 VDC
Category Specification
Physical
Dimensions (unpackaged) 10.5 in x 10.5 in x 3.25 in (267 mm x 267 mm x 83 mm)
Weight (unpackaged) 5.5 lbs (2.49 kg) Unit-only; .45 lbs (.20 kg) for power supply
Environmental
Storage Temperature -55° to 80ûC (-41° to 176° Fahrenheit)
Operating Temperature -33° to 60ûC (-27.5° to 140° Fahrenheit)
Humidity 100%
Wind Loading 125 m.p.h
Category Specification
MTBF >100,000 hours
Warranty 1 year parts and labor
