Safety and Regulatory Information
2
Copyright
© 2007 Proxim Wireless Corporation. All rights reserved. Covered by one or more of the following U.S. patents: 5,231,634; 5,875,179;
6,006,090; 5,809,060; 6,075,812; 5,077,753. This user’s guide and the software described in it are copyrighted with all rights reserved. No part
of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any
means without the written permission of Proxim Wireless Corporation.
Trademarks
Tsunami, Proxim, and the Proxim logo are trademarks of Proxim Wireless Corporation. All other trademarks mentioned herein are the property
of their respective owners.
Tsunami MP.11 5054, 954-R, 2454-R, 5054-R, and 5054-R-LR Safety and Regulatory Guide
P/N 73081 May 2007
Safety and Regulatory Compliance Information Safety and Regulatory Information
3
Safety and Regulatory Compliance Information
This document contains important safety and regulatory compliance information for the following products:
IMPORTANT!
Visit http://support.proxim.com for the latest safety and regulatory compliance information for this product.
Please read this document before installing and using your product, and save these instructions.
Product Family Base Station SKUs Subscriber Unit SKUs
Tsunami MP.11 Outdoor and Indoor Wireless
Point-to-Multipoint System
Model No. MP.11(-R)
954-BSUR-US
2411-BSU-AU
2411-BSU-BR
2411-BSU-EU
2411-BSU-JP
2411-BSU-UK
2411-BSU-US
5054-BSU-AU
5054-BSU-BR
5054-BSU-CN
5054-BSU-EU
5054-BSU-SK
5054-BSU-UK
5054-BSU-US(-WORLD)
2454-BSUR-AU
2454-BSUR-BR
2454-BSUR-CN
2454-BSUR-EU
2454-BSUR-SK
2454-BSUR-UK
2454-BSUR-US(-WORLD)
5054-BSUR-AU
5054-BSUR-BR
5054-BSUR-CN
5054-BSUR-EU
5054-BSUR-SK
5054-BSUR-UK
5054-BSUR-US(-WORLD)
5054-BSUR-LR-US
954-SUA-US
2411-SU-AU
2411-SU-BR
2411-SU-EU
2411-SU-JP
2411-SU-UK
2411-SU-US
5054-SU-AU
5054-SU-BR
5054-SU-CN
5054-SU-EU
5054-SU-SK
5054-SU-UK
5054-SU-US(-WORLD)
2454-SUA-AU
2454-SUA-BR
2454-SUA-CN
2454-SUA-EU
2454-SUA-SK
2454-SUA-UK
2454-SUA-US(-WORLD)
2454-SUR-AU
2454-SUR-BR
2454-SUR-CN
2454-SUR-EU
2454-SUR-SK
2454-SUR-UK
2454-SUR-US(-WORLD)
5054-SUR-LR-US
5054-SUA-AU
5054-SUA-BR
5054-SUA-CN
5054-SUA-EU
5054-SUA-SK
5054-SUA-UK
5054-SUA-US(-WORLD)
5054-SUR-AU
5054-SUR-BR
5054-SUR-CN
5054-SUR-EU
5054-SUR-SK
5054-SUR-UK
5054-SUR-US(-WORLD)
Safety and Regulatory Compliance Information Safety and Regulatory Information
4
Please see the following sections for more information:
•Safety Information (USA, Canada, & European Union)
•Federal Communications Commission (FCC) Compliance
–Modifications
–Warnings
•Information for Professional Installers
•Regulatory Compliance Certifications Summary
Safety Information (USA, Canada, & European Union) Safety and Regulatory Information
5
Safety Information (USA, Canada, & European Union)
These products have been evaluated to, and comply with, the U.S. and Canadian (Bi National) Standard for Safety of
Information Technology Equipment, including Electrical Business Equipment, CANCSA C22.2, No. 60950-00 * UL 60950
3rd edition and IEC60950:1999, the Standard for the Safety of Information Technology Equipment.
All products are intended to be installed, used, and maintained by experienced telecommunications personnel only.
When using this device, basic safety precautions should always be followed to reduce the risk of fire, electrical shock,
and injury to persons, including the following:
WARNING: These units are intended for installation in accordance with Articles 110-18, 110-26, and 110-27, 725,
800, and 810 of the United States National Electric Code ANSINFPA 70, and per the applicable
Articles in the Canadian National Electric Code.
• Operate and install these products as described in this manual. Equipment must be installed and used in strict
accordance with the manufacturer's instructions as described in the user documentation provided.
• Installation of these products in the end use must conform to local regulations and codes.
• Products are to be used with and powered by only the power injector provided.
• A 15-amp circuit breaker is required at the power source.
WARNING: This equipment is intended to be grounded. A 10 AWG earthing conductor at a minimum is to be
used for this purpose.
• Do not connect or disconnect the power cable to the equipment when the power injector is plugged into an AC power
outlet.
• Servicing of these products should be performed only by trained personnel. Do not disassemble. By opening or
removing any covers, you may expose yourself to hazardous energy parts. Incorrect reassembly of these products
can cause a malfunction and/or electric shock when the units are subsequently used. No user serviceable parts; all
repairs and service must be handled by a qualified service center.
• Do not insert any objects of any shape or size inside these products while powered on. Object may contact
hazardous energy parts that could result in a risk of fire or personal injury.
• Do not remove or alter the Marking label provided on these products.
• To avoid the risk of electric shock from lightning, do not use these products during an electrical storm.
• When using these products with an external antenna, see the installation documentation provided with the antenna
system.
Federal Communications Commission (FCC) Compliance Safety and Regulatory Information
6
Federal Communications Commission (FCC) Compliance
These products operate at the following frequencies in compliance with Part 15 of the FCC rules:
•Model 954-R: 902 MHz - 928 MHz
•Model 2454-R: 2.4 GHz
•Model 5054, 5054-R, 5054-R-LR: 5.25 GHz - 5.35 GHz and 5.75 - 5.85 GHz
•Model 5054-R only: 5.47-5.725GHz
Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device
must accept any interference received, including interference that may cause undesired operation.
To comply with the FCC radio frequency exposure requirements, the following antenna installation and device operating
configurations must be satisfied:
• Product models using external antennas require professional installation. The antennas used for professional
installation must be fixed-mounted on indoor/outdoor permanent structures with a separation distance from all
persons of at least 20 cm (approximately 8 inches) for the 954-R, 46 cm (approximately 18 inches) for 2454-R models,
and 112 cm (approximately 44 inches) for 5054-R/-LR models.
• Model 5054 must be used indoors only and must be installed to provide a separation distance of at least 20 cm (8
inches) from all persons.
• Antennas must not be co-located and must not operate in conjunction with any other antenna or transmitter.
Modifications
The FCC requires the user to be notified that any changes or modifications to this device that are not expressly approved
by the manufacturer may void the user’s authority to operate the equipment. The correction of interference caused by
unauthorized modification, substitution or attachment will be the responsibility of the user. The manufacturer and its
authorized resellers or distributors are not liable for any damage or violation of government regulations that may arise
from failing to comply with these guidelines.
Warnings
This equipment generates, uses, and can radiate radio frequency energy; and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the distance between the equipment and the receiver
• Connect the equipment to an AC outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
In some situations or environments, the use of wireless devices may be restricted by the proprietor of the building or
responsible representatives of the organization. These situations may, for example, include the use of wireless
equipment on board airplanes, or in any other environment where the risk of interference to other devices or services is
perceived or identified as harmful.
If you are uncertain of the policy that applies on the use of wireless equipment in a specific organization or environment
(such as airports), you are encouraged to ask for authorization to use this device prior to turning on the equipment.
Information for Professional Installers Safety and Regulatory Information
7
Information for Professional Installers
All products must be professionally installed, and the transmit power of the system must be adjusted by the professional
installers to ensure that the system EIRP is in compliance with the limit specified by the regulatory authority of the country
of application.
See the following sections for more information:
•Adjusting Tx Output Power
•Antenna Types and Maximum Gain
Adjusting Tx Output Power
NOTE: When the system is set to transmit at the maximum power, professional installers must ensure that the maximum
EIRP limit is not exceeded. To achieve this, they may have to add attenuation between the device and the
antenna when a high gain antenna is used.
Use the following formula in combination with the table of EIRP limits in US and EU countries to calculate system transmit
power (based on EIRP limits) of these countries:
Tx Power (dBm) = EIRP Limit (dBm) + FL (dB) – G (dB)
where:
Tx Power = Output power measured at the antenna input
EIRP Limit = EIRP limits specified below
FL = Feeder loss including loss of connectors
G = Antenna Gain
Transmit output power can be reduced by using the Transmit Power Control (TPC) field on the Configure > Interfaces
> Wireless screen. Refer to the Installation and Management Guide for more information.
Band EIRP Limit (dBm)
USA and Canada EU
902 - 928 MHz 36 NA
2.4 - 2.4835 GHz (Point-to-Multipoint) 36 20
2.4 - 2.4835 GHz (Point-to-Point) When G < 6: 36
When G ≥ 6, use the following
equation:
36 -
20
5.15 - 5.25 GHz 23 23
5.25 - 5.35 GHz 30 23
5.47 - 5.725 GHz 30 30
5.725 - 5.850 GHz (Point-to-Multipoint) 36 14
5.725 - 5.850 GHz (Point-to-Point) No limit 14
G6–
3
--------------
Information for Professional Installers Safety and Regulatory Information
8
Antenna Types and Maximum Gain
Professional installers should select only the antenna types listed in the following table, with gain not exceeding the listed
maximum gain for each type.
Frequency Band Antenna Type Maximum Gain (dBi)
900 MHz Omni 10
Panel 12.5
Sector 17
2.4 GHz Omni 10
Panel 17
Yagi 14
Parabolic 24
5 GHz Omni 10
Panel 28.2
Sector 17
Parabolic 33.4
Regulatory Compliance Certifications Summary Safety and Regulatory Information
9
Regulatory Compliance Certifications Summary
Model 954-R
Model 2454-R, 5054-R, and 5054
Model 5054-R-LR
Country Certification/Reference No.
USA In Process
Country Certification/Reference No.
Australia & New Zealand N11394
Brazil ANATEL Cert. No.:0267-05-1641
Canada IC Cert. No.: 1856A-MP11RABG
Safety: UL File No.: E243498
China CMII ID: 2005AJ0190
European Union CE 1313!
Japan Radio Cert. Nos.: 003NY04140 0000
Mexico COFETEL Cert. Nos.:
RCPPR2405-077, TCPPR5005-040
Philippines Radio Cert. Nos.:
ESD-05021571, ESD-0502158C
Safety - CB Report CB Lic. No.: US/8788/UL
South Korea Radio Cert. No.: R-LARN-05-0042
Taiwan DGT Cert. No: ETC094LPD0074
USA FCC ID: HZB-MP11R-ABG
Safety: UL File No.: E243498
Country Certification/Reference No.
Canada IC Cert. No.: 1856A-5054LR
USA FCC ID: HZB-5054-LR
