1. INTRODUCTION
Thank you for choosing the Sena SMH3, Motorcycle Bluetooth Headset and Intercom. With the SMH3, you can call
handsfree on your Bluetooth mobile phone, listen to stereo music or voice instructions of GPS navigation by Bluetooth
wirelessly, and have intercom conversations in full duplex with a passenger or other riders.
The SMH3 is compliant with the Bluetooth Specification 3.0 supporting the following profiles: Headset Profile, Hands-Free
Profile (HFP), Advanced Audio Distribution Profile (A2DP), and Audio Video Remote Control Profile (AVRCP). Please
check with the manufacturers of other devices to determine their compatibility with this headset.
Please read this user’s guide carefully before using the headset. Also check www.SenaBluetooth.com for the latest
version of the user’s guide and additional information related to Sena Bluetooth products.
The SMH3 features:
● Bluetooth handsfree for Bluetooth mobile phones
● Bluetooth stereo headset for Bluetooth stereo devices such as MP3 players
● Bluetooth stereo headset for Bluetooth GPS navigations
● Bluetooth intercom
● Easy operation by two-button
● Installation friendly unibody design
● Firmware upgradeable
Key Specifications:
● Bluetooth 3.0
● Supporting profiles: Headset Profile, Hands-Free Profile (HFP), Advanced Audio Distribution Profile (A2DP), Audio
Video Remote Control Profile (AVRCP)
-------------
*In open terrain
![](/img.php?id=2378420&img=bg6.png)
| SMH3
6
2. PACKAGE CONTENTS
SMH3 Headset Unit
Microphone Sponges
USB Power & Data Cable
Velcro Pads for Speakers
![](/img.php?id=2378420&img=bg7.png)
| SMH3
7
3. INSTALLING THE SMH3 ON YOUR HELMET
1. [picture 3-1]
2. [picture 3-2] 3. [picture 3-3]
Remove the left and right side
cheekpads from the helmet.
Place the speaker-microphone unit
along with the velcro pad to the left
inside surface of the external shell,
centered to your ear.
The boom microphone should be
positioned to face properly towards
your mouth. Please make sure that
the microphone is located close to
your mouth when you wear the
helmet.
4. [picture 3-4]
5. [picture 3-5] 6. [picture 3-6]
Place the speaker unit along with the
velcro pad to the right inside surface
of the external shell, centered to your
year in the ear pockets of the helmet
Lift up the helmet top padding from
the back of the helmet and rout the
speaker wires beneath the padding.
Replace the cheeckpads in the
helmet making sure the speaker
wiring is hidden beneath the padding
![](/img.php?id=2378420&img=bg8.png)
| SMH3
8
4. POWERING ON/OFF AND CHARGING
4.1 Powering On
Press the (+) Button and the (-) Button at the same time for 1 second to power on. The blue LED turns on and you will
hear ascending beeps and “Hello”.
4.2 Powering Off
Tap the (+) Button and the (-) Button simultaneously. The red LED turns on for about 2 seconds until it turns off completely
and you will hear “Goodbye” and descending beeps.
4.3 Charging
● To charge the SMH3, use the USB Power Cable included in the package by plugging into computer’s USB port or
USB wall charger. USB wall charger is not included in the package, but you can use any USB wall charger in the
market.
● The USB Power Cable is also used for firmware upgrade of the SMH3.
● You can use any of the standard micro-USB cables which is mostly adopted by smartphones and general Bluetooth
headsets manufacturers.
● The LED turns on red while charging, and turns to blue when the headset is fully charged. It takes about 2.5 hours to
be fully charged.
● A cigarette charger for the SMH3 is separately available as an optional accessory but you can use any micro-USB
car charger in the market.*
4.4 Low Battery Warning
When the battery is low, the blinking blue LED in stand-by mode turns to red and you will hear mid-tone triple beeps and a
voice prompt saying “Low battery”.
--------------------------------
*please contact Sena regarding locally approved agencies Sena accepts.
![](/img.php?id=2378420&img=bg9.png)
| SMH3
9
5. CHECKING THE BATTERY LEVEL
You can check the battery level in two different ways when the headset is powering on.
5.1 LED Indicator
When the headset is powering on, the red LED flashes rapidly indicating the battery level.
4 flashes = High, 70~100%
3 flashes = Medium, 30~70%
2 flashes = Low, 0~30%
5.2 Voice Prompt Indicator
When you power on the headset, keep pressing the (+) Button and (-) Button simultaneously for about 3 seconds until
you hear three high tone beeps. Then you will hear a voice prompt indicating the battery level. However, if you release the
buttons as soon as the headset turns on, you will not hear the voice prompt for the battery level.
![](/img.php?id=2378420&img=bga.png)
| SMH3
10
6. PAIRING THE SMH3 WITH BLUETOOTH DEVICES
6.1 Mobile Phone Pairing
1. Turn on the SMH3 and press the (+) Button for 5 seconds until the LED flashes red and blue alternately and you hear
multiple beeps. You will hear a voice prompt saying “Phone pairing”.
2. Search for Bluetooth devices on your mobile phone. Select the Sena SMH3 in the list of the devices detected on the
mobile phone.
3. Enter 0000 for the PIN. Some mobile phones may not ask for the PIN.
4. The mobile phone confirms that pairing has completed and the SMH3 is ready to use. You will hear a voice prompt
from the SMH3 saying “Your headset is paired”.
5. If the pairing process is not completed within three minutes, the SMH3 will return to stand-by mode.
6.2 Multipoint Mobile Phones Pairing
You can simultaneously use two mobile phones which use the mobile phone profile.
1. You can pair the first mobile phone to the SMH3 by following the simple procedures in “6.1 Mobile Phone Pairing”.
2. To pair the second mobile phone, press the (-) Button for 5 seconds until the red LED is rapidly flashing and you hear
multiple beeps.
3. Within 2 seconds, press the (+) Button for 1 second, then the LED turns to blue flashing and the beeps turn to high
tone double beeps. You will hear a voice prompt saying “Multipoint pairing”.
4. Search for Bluetooth devices on your mobile phone. Select the Sena SMH3 in the list of the devices detected on the
mobile phone.
5. Enter 0000 for the PIN. Some mobile phones may not ask for the PIN.
6. The mobile phone confirms that pairing has completed and the SMH3 is ready to use. You will hear a voice prompt
from the SMH3 saying “Your headset is paired”.
6.3 Bluetooth Stereo Device Pairing
1. If the Bluetooth stereo device is integrated with the mobile phone such as smartphones, you don’t need to pair the
SMH3 with it separately. When the SMH3 is paired with the mobile phone, it is also paired as a stereo music device.
2. If you have a stand alone Bluetooth stereo device, follow the pairing procedure separately. The procedure is the
same as the procedure of “6.1 Mobile Phone Pairing”.
Note:
![](/img.php?id=2378420&img=bgb.png)
| SMH3
11
1. If Bluetooth connection between the headset and a mobile phone is disconnected, press the (+) Button for 3 seconds
to recover the Bluetooth connection immediately.
2. If Bluetooth connection between the headset and any other Bluetooth devices is disconnected, tap the (+) Button to
recover the Bluetooth connection.
6.4 Bluetooth GPS Navigation Pairing
You can listen to voice instruction from Bluetooth GPS navigation. Some GPS systems use mobile phone profile (HFP,
Hands-Free Profile) and others use stereo music profile (A2DP, Advanced Audio Distribution Profile). Most motorcycle
specific GPS systems use mobile phone profile for turn-by-turn voice instruction. You can simultaneously use a mobile
phone and a GPS which uses mobile phone profile by one of the following procedures.
6.4.1 Multipoint GPS Pairing
If you use GPS only for turn-by-turn voice instructions, not for Bluetooth stereo music streaming, multipoint pairing is
recommended for the GPS connection. Multipoint Bluetooth pairing allows the SMH3 to connect two HFP devices at the
same time: mobile phone and GPS navigation. Follow the steps below to pair the GPS using the multipoint pairing.
1. Turn on the headset and press the (-) Button for 5 seconds until the red LED is rapidly flashing and you hear multiple
beeps.
2. Within 2 seconds, press the (+) Button for 1 second, then the LED turns to blue flashing and the beeps turn to high
tone double beeps. You will hear a voice prompt saying “Multipoint pairing”.
3. Search for Bluetooth devices on the GPS navigation screen. Select the Sena SMH3 in the list of the devices
detected on the GPS.
4. Enter 0000 for the PIN.
5. The GPS confirms that pairing has completed and the SMH3 is ready to use. You will hear a voice prompt from the
SMH3 saying “Your headset is paired”.
6. If the pairing process is not completed within three minutes, the SMH3 will return to stand-by mode.
The pairing diagram for multipoint GPS pairing is shown in the figure below.
7. PAIRING WITH OTHER SMH3 HEADSETS FOR INTERCOM
CONVERSATION
The SMH3 can be paired with up to three other headsets for Bluetooth Intercom conversation.
1. Turn on the two SMH3 headsets (A and B) that you would like to pair with each other.
2. Press and hold the (-) Button of the headset A and B for 5 seconds until red LEDs of the both units start to flash
rapidly. You will hear a voice prompt saying “Intercom pairing”.
![](/img.php?id=2378420&img=bgc.png)
| SMH3
12
3. Wait until the LEDs of both headsets turn to blue and intercom connection is automatically established. The two
SMH3 headsets A and B are paired with each other for intercom conversation. If the pairing process is not completed
within one minute, the SMH3 will return to stand-by mode.
![](/img.php?id=2378420&img=bgd.png)
| SMH3
13
8. SMH3 CONFIGURATION SETTING
You can set the configuration of the SMH3 by the voice menu instruction as below.
1. To enter into voice configuration menu, press and hold the (+) Button for 10 seconds until the LED shows solid blue
and you hear high tone double beeps. You will hear a voice prompt saying “Configuration menu”.
2. Tap the (+) Button to navigate between menus. You will hear voice prompts for each menu items as below.
3. You can enable or disable the feature or execute the command by tapping the (-) Button.
4. If any button is not pressed within 10 seconds, the SMH3 will exit the configuration and goes back to standby.
5. If you want to exit the configuration immediately, press the (+) Button until you hear a voice prompt, “Exit
configuration”, and tap the (-) Button.
The voice prompt for each menu item is as below:
(1) VOX phone
(2) Voice prompt
(3) Delete all pairings
(4) Factory reset
(5) Exit configuration
[picture 10-1]
8.1 Enabling/Disabling Voice Activated Phone Answering
Voice Prompt “VOX phone”
Factory Default Enable
Enable / Disable Tap the (-) Button
If this feature is enabled, you can answer incoming calls by simply saying a word loudly enough, unless you are
connected to intercom. For example, when you hear a series of beeps for an incoming call, you can answer the phone by
saying “Hello” or any other word loudly. However, the phone VOX feature does not work if you are connected to intercom.
This is enabled from the factory but you can disable this. If this mode is disabled, you have to tap the (+) Button to answer
an incoming call.
8.2 Enabling/Disabling Voice Prompts
![](/img.php?id=2378420&img=bge.png)
| SMH3
14
Voice Prompt “Voice prompt”
Factory Default Enable
Enable / Disable Tap the (-) Button
You can disable voice prompts by configuration setting, but the following voice prompts are always on.
- Voice prompts for configuration setting menu
- Voice prompts for battery level Indicator
- Voice prompts for factory reset
8.3 Delete All Bluetooth Pairing Information
Voice Prompt “Delete all pairings”
Factory Default N/A
Execute Tap the (-) Button
To delete all Bluetooth pairing information of the SMH3, press the (+) Button until you hear a voice prompt, “Delete all
pairings”, and tap the (-) Button to confirm.
8.4 Reset to Factory Default Setting
Voice Prompt “Factory reset”
Factory Default N/A
Execute Tap the (-) Button
To restore factory default settings on the SMH3, tap the (+) Button until you hear a voice prompt, “Factory reset”. Tap the
(-) Button to confirm. The SMH3 powers off with a voice prompt, “Headset reset, goodbye”.
8.5 Exit Voice Configuration Menu
Voice Prompt “Exit configuration”
Factory Default N/A
![](/img.php?id=2378420&img=bgf.png)
| SMH3
15
Execute Tap the (-) Button
To exit voice configuration menu and get back to stand-by mode, tap the (+) Button until you hear a voice prompt, “Exit
configuration”. Tap the (-) Button to confirm.
Tap (+) Button Tap (-) Button
“Vox phone” Enable / disable
“Voice prompt” Enable / disable
“Delete all pairings” Execute
“Factory reset” Execute
“Exit configuration” Execute
Voice Configuration Menu & Button Operations
![](/img.php?id=2378420&img=bg10.png)
| SMH3
16
9. USING THE SMH3
9.1 Volume Adjustment
You can easily adjust the volume by tapping the (+) Button or the (-) Button. You will hear a beep when the volume
reaches maximum or minimum level. The volume is set and maintained independently at different levels for each audio
source even when you turn off and on the headset. For example, once you set the volume for mobile phone handsfree, it
will not change even if you adjust the volume when you hear Bluetooth MP3 music. So you can always maintain the
preferred optimum volume level for each audio source.
9.2 Mobile Phone Call Making and Answering
1. When you have an incoming call, simply tap the (+) Button to answer the call.
2. You can also answer the incoming call by loudly speaking any word of your choice if Voice Activated Phone
Answering, VOX phone is enabled. (Refer to the next section for details.)
3. To end a call, press the (+) Button for 2 seconds until you hear a mid-tone single beep, or wait for the called person
to end the call.
4. To reject a call, press the (+) Button for 2 seconds until you hear a beep while the phone is ringing.
5. There are several ways to make a phone call:
- Enter numbers on your mobile phone keypad and make a call. Then the call is automatically transferred to the headset.
- Press the (+) Button for 3 seconds in stand-by mode until you hear a high tone single beep to activate the voice dialing
of your mobile phone. For this, the voice dialing feature must be available on the mobile phone. Refer to your mobile
phone manual for further instruction.
- To redial the last number, press the (-) Button for 3 seconds in stand-by mode until you hear a high tone single beep.
You will hear a voice prompt saying “Last number redial”.
Note:
1. If you are using multipoint mobile phone connection and you have an incoming call from the second phone during the
call of the first phone, then you may still receive the call from second phone. In this case, the call from the first phone is
on waiting mode. If you end a call, then it will automatically guide you to the first phone call.
2. If you are using multipoint connection of mobile phone and GPS, you may not listen to the GPS voice instruction during
the phone call.
9.3 Intercom Conversation
1. You can start an intercom conversation with any of intercom friends by pressing the (-) Button for 1 second.
[picture 11-1]
![](/img.php?id=2378420&img=bg11.png)
| SMH3
17
2. To terminate an intercom conversation, press the (-) Button for 1 second again.
[picture 11-2]
9.4 Intercom and Mobile Phone Call
1. When you have an incoming mobile phone call during an intercom conversation, you will hear a ring tone. You can
choose whether to 1) answer the mobile phone call and stop the intercom conversation, or 2) reject the phone call and
stay on the intercom conversation.
● To answer the phone call and stop the intercom conversation, tap the (+) Button. When you hang up the phone
call, the intercom will automatically be recovered.
● To reject the phone call and stay on the intercom conversation, press the (+) Button for 2 seconds until you hear a
beep.
Unlike other motorcycle Bluetooth headsets, this prevents a user from being dropped out of an intercom conversation
by an incoming mobile call.
2. When you have an incoming intercom call during a mobile phone call, you will hear 4 high tone beeps, alerting you
that there is an incoming intercom call. You will also hear a voice prompt saying “Intercom requested”. In this case,
the intercom call does not override the mobile phone call because intercom has lower priority than mobile call. You
have to hang up the mobile phone call to make or receive an intercom call.
9.5 Intercom Failure
When you try to start an intercom conversation with an intercom friend who is already having a mobile phone call with
another person, you will hear a low tone double beep signifying a busy signal. You will also hear a voice prompt saying
“Intercom failed, try again later”. In this case, you have to try again later. On the other hand, the intercom friend will
hear 4 high tone beeps alerting them that there is an incoming intercom call.
9.6 Intercom Reconnection
If your intercom friend goes out of range while having an intercom conversation, you may hear static noise and eventually
the intercom will be disconnected. In this case, the SMH3 automatically tries to reconnect the intercom every 8 seconds.
You will hear high tone double beeps until the intercom is reestablished. If you don’t want to make a reconnection, tap the
(-) Button to stop the attempt.
9.7 Stereo Music
You can listen to stereo music by Bluetooth wireless stereo. The Bluetooth audio device must be paired with the SMH3 by
following the Bluetooth Stereo Device Pairing instructions described in the previous chapter. The SMH3 supports the
Audio/Video Remote Control Profile (AVRCP), so if your Bluetooth audio device also supports the AVRCP, you can use
![](/img.php?id=2378420&img=bg12.png)
| SMH3
18
the SMH3 to remotely control music playback. So, You not only can adjust the volume but also use the functions such as
play, pause, next track and previous track.
● To adjust the volume, tap the (+) Button or the (-) Button..
[picture 11-3]
● To play or pause music, press and hold the (+) Button for 1 second until you hear a double beep.
[picture 11-4]
● To track forward or track back, press and hold the (+) Button or the (-) Button for 2 seconds until you hear a
double beep.
[picture 11-5]
9.8 Function Priority
The SMH3 operates in the following order of priority:
(Highest) Mobile Phone,
Intercom, and
(Lowest) Bluetooth Stereo Music
A lower priority function is always interrupted by a higher priority function. For example, stereo music is interrupted by
intercom call, and intercom conversation is interrupted by incoming mobile phone call.
9.9 Fault Reset
When the SMH3 is not working properly or is in faulty status for any reason, you may reset by pushing the pin-hole reset
button on the left speaker unit. Insert a paper clip into the reset pin-hole and press the reset button for a second with light
pressure. The SMH3 will be switched off after which time, you have to turn the system back on and try again. However,
this will not restore the headset to factory default settings.
![](/img.php?id=2378420&img=bg13.png)
| SMH3
19
10. FIRMWARE UPGRADE
The SMH3 supports firmware upgrade function. Please visit Sena Bluetooth web site at www.SenaBluetooth.com to
check the latest software downloads.
![](/img.php?id=2378420&img=bg14.png)
| SMH3
20
SENA www.senabluetooth.com Users Guide for Firmware v1.0
![](/img.php?id=2378420&img=bg15.png)
| SMH3
21
FCC Information to User
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-nected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution
Modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
FCC Compliance Information
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation
IMPORTANT NOTE:
FCC RF Radiation Exposure Statement:
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of
20 centimeters between the radiator and your body.This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.
“This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation of the
device.”
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
