Sanyo Electric Co NVM-4070 PND (Personal Navigation Device) User Manual NVM 4070 Manual EN

Sanyo Electric Co Ltd PND (Personal Navigation Device) NVM 4070 Manual EN

Contents

User Manual 1

FOR SERVICE ASSISTANCE, CALL
Customer Information 1-800-421-5013
Weekdays 7:30 AM – 5:00 PM Pacific Time
NVM-4070
Instruction Manual
NVM-4070 Portable Navigation System
NVM-4070 Portable Navigation System 2 Introduction
Contents Index
FCC COMPLIANCE
* This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC WARNING
Changes or modifications not expressly approved by the party responsible for
compliance could void the users authority to operate the equipment.
CANADIAN ICES-003 COMPLIANCE
This Class B digital apparatus complies with Canadian ICES-003.
NOTICE
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a res-
idential installation.
This equipment generates uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is encouraged to try to cor-
rect the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This transmitter must not be co-located or operated in conjunction with any
other antenna or transmitter.
NVM-4070 Portable Navigation System 3 Introduction
Contents Index
Precautions
Copyright
SANYO NVM-4070 Portable Navigation System Instruction Manual
Original issue: Jun 2007
SANYO and the SANYO logo are registered trademarks of SANYO. Other
products or system names appearing in this document are trademarks or regis-
tered trademarks of their respective owners. Further, the © or TM symbols are
not used in the text.
No part of this publication may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronic, mechanical, photocopy,
recording, or otherwise, without the prior written permission of SANYO.
You have acquired a device (“DEVICE”) that includes software licensed by
SANYO from an affiliate of Microsoft Corporation (“MS”). Those installed
software products of MS origin, as well as associated media, printed materials,
and “online” or electronic documentation (“SOFTWARE”) are protected by
international intellectual property laws and treaties. Manufacturer, MS and its
suppliers (including Microsoft Corporation) own the title, copyright, and other
intellectual property rights in the SOFTWARE. The SOFTWARE is licensed,
not sold. All rights reserved.
Microsoft, Windows is registered trademarks or trademarks of the Microsoft
Corporation in the United States and/or other countries.
Adobe and Reader are registered trademarks or trademarks of Adobe Systems
Incorporated in the United States and/or other countries.
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and
any use of such marks by Sanyo is under license.
All other brand or product names mentioned in this manual are trademarks or
registered trademarks of their respective companies.
Maintenance
Keep your device away from excessive moisture and extreme tempera-
tures.
Avoid exposing your device to direct sunlight or strong ultraviolet light for
extended periods of time.
Do not drop your device or subject it to severe shock.
Do not subject your device to sudden and severe temperature changes.
This could cause moisture condensation inside the unit, which could dam-
age your device. In the event of moisture condensation, allow the device to
dry out completely before use.
Do not leave your device in plain sight when you leave your vehicle. Take
your device with you or remove it from view to avoid theft.
The screen surface can be easily scratched. Sharp objects may scratch the
screen. You may use non-adhesive generic screen protectors designed spe-
cifically for use on portable devices with LCD panels to help protect the
screen from minor scratches.
Never clean your device with it powered on.
Never use organic solvents such as benzene or paint thinner to clean your
device. Use of these solvents can cause deformation or discoloration.
Use a soft, clean, lint-free cloth to clean the display screen. Moistened
LCD screen wipes could also be used as required.
Never attempt to disassemble, repair or make any modifications to your
device. Disassembly, modification or any attempt at repair could cause
damage to your device and even bodily injury or property damage and will
void any warranty.
NVM-4070 Portable Navigation System 4 Introduction
Contents Index
Storage precautions
Do not store your device anywhere it may be exposed to water or in condi-
tions of high humidity.
When the device is not in use for an extended period of time, bring it
indoors and store it in cool dry area.
Accessories and repair precautions
Only authorized accessories should be use with the device. The use of
incompatible accessories could result in bodily injury and/or damage to
the device.
The use of unauthorized accessories will also void your warranty.
Never attempt to disassemble, repair or make any modification to your
device.
DISCLAIMER AND LIMITATION OF LIABILITY
SANYO and its subsidiaries makes no representations or warranties, either
expressed or implied, with respect to the contents hereof and specifically dis-
claims the implied warranties of merchantability or fitness for a particular pur-
pose. SANYO and its subsidiaries assume no responsibility for any damage or
loss resulting from the use of this SANYO NVM-4070 Portable Navigation
System.
Revision: 1.00
Jun 2007
NOTE: Record the device ID, serial number, purchase date, and place of pur-
chase information in the space provided below. The serial number is indicated
on the label affixed to your NVM-4070. All correspondence concerning your
unit should include the serial number, device ID, and purchase information.
NOTE: Information in this manual is subject to change without notice.
NVM-4070 Portable Navigation System 5 Introduction
Contents Index
WARNINGS AND NOTICES
For your safety, do not operate the controls of the product while driving.
GPS satellite signals cannot typically pass through solid materials (except
glass). GPS location information is not typically available inside buildings, tun-
nels, or underground parking lots.
A minimum of 4 GPS satellite signals is needed to calculate your GPS position.
Signal reception can be affected by weather events or overhead obstacles (e.g.
dense foliage and tall buildings).
Other wireless devices in the vehicle may interfere with the reception of satel-
lite signals and cause the reception to be unstable.
Adaptor
Do not attempt to service the unit. There are no serviceable
parts inside. Replace the unit if it is damaged or exposed to
excess moisture.
Do not use the adaptor if the cord becomes damaged.
Connect the adaptor to the proper power source. The voltage
requirements are found on the product case and/or packaging.
Battery
This unit contains a non-replaceable internal Lithium Ion
battery. The battery can burst or explode, releasing haz-
ardous chemicals. To reduce the risk of fire or burns, do
not disassemble, crush, puncture, or dispose of in fire or
water.
To charge the battery, connect the AC adaptor or Car Adaptor to the main unit.
Under high temperatures, however, the protection circuit may be activated and
charging may not be possible.
Do not connect any accessory (car battery adaptor, AC power adaptor, etc.)
other than those supplied or optional.
FOR AMERICAN USERS
The following advisory is included in accordance with the laws of the State of
California (USA):
WARNING: This product contains chemicals, including lead, known to the
State of California to cause cancer, and birth defects or other reproductive
harm. Wash hands after handling.
NOTICE TO DRIVERS IN CALIFORNIA AND MINNESOTA: State law pro-
hibits drives in California and Minnesota from using suction mounts on their
windshields while operating motor vehicles. SANYO does not take any
responsibility for any fines, penalties, or damages that may be incurred as a
result of disregarding this notice.
NOTICE TO DRIVERS IN CALIFORNIA: Signs, stickers, or other materials
which are displayed in a 7-inch square in the lower corner of the windshield
farthest removed from the driver, signs, stickers, or other materials which are
displayed in a 7-inch square in the lower corner of the rear window fartherst
removed from the driver, or signs, stickers, or other materials which are dis-
played in a 5-inch square in the lower corner of the windshield nearest the
driver.
NVM-4070 Portable Navigation System 6 Introduction
Contents Index
READ CAREFULLY BEFORE USE!!!
User license agreement
IMPORTANT! — BY INSTALLING, COPYING, ACCESSING, DOWN-
LOADING, AND/OR USING THIS THE SOFTWARE, YOU ARE CON-
SENTING TO BE BOUND BY AND ARE BECOMING A PARTY TO THIS
AGREEMENT AS A LICENSEE. IF YOU DO NOT AGREE TO ALL OF
THE TERMS OF THIS AGREEMENT, TERMINATE THIS INSTALLATION
PROCESS OR, IF THE SOFTWARE IS ALREADY INSTALLED, IMMEDI-
ATELY UNINSTALL IT.
THIS USER LICENSE AGREEMENT (“this Agreement”) shall serve as a
legally binding instrument between you (as “Licensee”, whether an individual
or a corporation, regardless) and SANYO Electric Co., Ltd. (“Licensor”) con-
cerning the Licensee's use of a single SANYO SOFTWARE PRODUCT (“the
Software”) under the terms and conditions set forth herein. The Software shall
include, but without limitation, computer software and related media materials,
printed materials (documents such as user manuals), and electronic documents
whether or not retrieved by licensee “on-line”, and shall include any updates
and upgrades thereof supplied by Licensor having additional features and func-
tions.
Where a separate User License Agreement is attached to any the Software sup-
plied by Licensor, the terms and conditions of that User License Agreement
shall also apply in addition to the terms and conditions set forth in this Agree-
ment.
If you are unable to agree to any of the terms and conditions set forth herein,
Licensor is unable to grant you the license to install, use or copy the Software.
The Software covered under this Agreement is protected under the international
conventions and treaties on copyright and the related laws and regulations. This
license shall constitute a grant of a license to Licensee for a single use of the
Software and may not be deemed under any circumstances to constitute a sale
of the Software itself.
1. Grant of License
Licensor shall grant Licensee a non-exclusive, non-sublicensable, non-trans-
ferable license for the use of the Software under the terms and conditions set
forth herein:
System Software
Licensee may use the Software only in a single computer or on a computer
network (“the Computer”, including without limitation, workstation, ter-
minal, and/or other digital or electronic device) in binary executable form.
2. Other rights and limitations
Reverse engineering, etc.
Except as expressly provided herein, Licensee shall not copy, modify
reproduce, display, decompile, reverse engineer, reverse assemble, store,
translate, sell, lease or otherwise transfer, distribute the Software, in whole
or in part, nor may Licensee use the Software with the intent to clone any
proprietary product to Licensor.
Separation or division of the Software prohibited
This license hereby is granted for a single use only. In no circumstances
shall Licensee separate, divide or compartmentalize any constituent por-
tion(s) of the Software into multiple parts, sections, or compartments for
use in multiple computers.
Rental, lease or loan prohibited
Licensee shall not lend, lease or loan the Software to any party(ies).
User support service by Licensor
Licensor may choose to provide user support service in accordance with
the Licensor's policy set out in User Manual, On-line documents, or other
printed matters made available by Licensor from time to time (the “Sup-
port Service”). All additional software code made available to Licensee as
a part of the Support Service shall be deemed to constitute a part of the
Software hereof to which all the terms and conditions of this Agreement
shall apply. Licensor shall be entitled to use for commercial purposes or
otherwise any and all technical information (the “Technical Information”)
provided by Licensee to Licensor, provided, however, that Licensor shall
ensure that the identity of the Licensee shall remain undisclosed in the
Licensor's use of all such Technical Information.
NVM-4070 Portable Navigation System 7 Introduction
Contents Index
3. Other Intellectual Proprietary Rights
Licensor or its supplier is the owner of all right, title and interest in and to
the Software and its documents such as user manual and any and all copies
thereof. The proprietary ownership of all data operated using this Software
shall remain with the respective owner(s) and shall be protected by the inter-
national conventions and treaties and other intellectual proprietary rights.
Licensee shall not be deemed, by anything contained in or done pursuant to
this Agreement to acquire any right, title, or interest in any trademark, copy-
right, patent or other intellectual property of Licensor, and shall do nothing
to prejudice the value or validity of the respective owner's rights therein or
ownership thereof. Licensor shall preserve the proprietary ownership of any
and all rights and titles in the Software not specifically provided herein.
4. Backup copy
After having installed a copy of the Software pursuant to this Agreement,
Licensee may make a single copy of the Software for backup and archival
purposes only, provided that any copy must contain all proprietary notices
included in the original. If another original medium becomes necessary to
use the Software on a computer under this Agreement, Licensee may make a
single copy of the Software. Except as specifically provided herein, Licensee
shall refrain from making copy of the Software or its incidental documents
such as user manual in any manner whatsoever.
5. DISCLAIMER OF WARRANTY:
THE SOFTWARE IS DEEMED ACCEPTED BY LICENSEE UPON IT'S
USE BY LICENSEE. THE SOFTWARE IS PROVIDED TO LICENSEE
AS IS, WITHOUT WARRANTY OF ANY KIND. TO THE MAXIMUM
EXTENT PERMITTED BY APPLICABLE LAW. LICENSOR FURTHER
DISCLAIMS ALL WARRANTIES, INCLUDING WITHOUT LIMITA-
TION, ANY IMPLIED WARRANTIES OF MERCHANTABILITY, FIT-
NESS FOR A PARTICULAR PURPOSE, AND NON INFRINGEMENT.
THE ENTIRE RISK ARISING OUT OF THE USE OR PERFORMANCE
OF THE PRODUCT AND DOCUMENTATION REMAINS WITH LIC-
ENSEE. IN NO EVENT SHALL LICENSOR OR ITS SUPPLIERS BE
LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, DIRECT, INDI-
RECT, SPECIAL, PUNITIVE OR OTHER DAMAGES WHATSOEVER
(INCLUDING WITHOUT LIMITATION, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSI-
NESS INFORMATION, OR OTHER PECUNIARYLOSS) ARISING OUT
OF THIS AGREEMENT OR THE USE OF OR INABILITY TO USE THE
PRODUCT, EVEN IF LICENSOR HAS BEEN ADVISED OF THE POS-
SIBILITY OF SUCH DAMAGES. LICENSOR DOES NOT WARRANT
THAT THE SOFTWARE DOES NOT INCLUDE ANY VIRUS OR
DEFECTS, THE SOFTWARE ROUTINE OR OTHER SOFTWARE
DESIGNED TO RESTRICT UNAUTHORIZED ACCESS; OR TO DIS-
ABLE, ERASE OR OTHERWISE HARM THE SOFTWARE, HARD-
WARE, OR DATA; OR TO PERFORM ANY OTHER SUCH ACTIONS
AND LICENSOR HEREBY EXPRESSLY DISCLAIMS ANY AND ALL
LIABILITIES TO RESTORE ANY SUCH DEFECTS.
6. Indemnification:
Licensor will not have any liability to Licensee for, and Licensee will defend
and hold Licensor harmless against, any claim, expense, judgment, liability,
or loss (including attorneys' fees and expert witnesses' expenses) based on
Licensee's use of any content of the Software, arising from any intellectual
property claim (including patent, trademark, copyright, or trade secret
infringement), any right of publicity or privacy claim, or any defamation or
unfair competition claim.
7. Termination.
Without prejudice to any other rights, Licensor may terminate this Agree-
ment if Licensee fails to comply with the terms and conditions herein. Lic-
ensee may also terminate this Agreement at any time by destroying the
Software and Documentation and all copies thereof. The provisions of sec-
tions 2, 3, 4, 5, 6 and 7 shall survive any termination of this Agreement.
NVM-4070 Portable Navigation System 8 Contents
Contents Index
Contents
Chapter 1 NVM-4070 Features and Specifications ...................... 10
1.1 SANYO NVM-4070 Feature ................................................. 10
1.2 NVM-4070 Specifications ..................................................... 10
Chapter 2 Getting Started .............................................................. 12
2.1 Hardware Overview .............................................................. 12
2.1.1 Packing List .............................................................................12
2.1.2 External Features .....................................................................12
2.2 Mounting the NVM-4070 in your vehicle .............................. 14
2.3 Set up TMC antenna unit in your vehicle ............................. 17
Chapter 3 System ........................................................................... 19
3.1 NVM-4070 Operating Basics ................................................ 19
3.2 To turn on and calibrate the device: ..................................... 19
3.3 System Settings ................................................................... 21
3.3.1 Language .................................................................................21
3.3.2 Date & Time ............................................................................21
3.3.3 Brightness ................................................................................22
3.3.4 Volume ....................................................................................22
3.3.5 FM Transmitter .......................................................................22
3.3.6 Power ......................................................................................23
3.3.7 System Information .................................................................23
Chapter 4 Communications ........................................................... 25
4.1 Connection ........................................................................... 25
4.1.1 Mobile Phone Connection (New) ...........................................25
4.1.2 Mobile Phone Connection (Reconnect) ..................................26
4.2 Hands-free Calling ............................................................... 27
4.2.1 Making a Call ..........................................................................27
4.2.2 Receiving a Call ......................................................................28
4.3 Contacts ...............................................................................28
4.3.1 Create new entry .....................................................................28
4.3.2 Call-out ...................................................................................29
4.3.3 View ........................................................................................29
4.3.4 Delete ......................................................................................30
4.4 Data Transfer ........................................................................30
4.4.1 File Transfer ............................................................................30
4.4.2 Import Phonebook ...................................................................31
4.4.3 Export Contacts to SD ............................................................31
4.4.4 Import Contacts from SD ........................................................31
4.5 SMS (Short Message Service) .............................................32
4.5.1 Inbox .......................................................................................32
4.5.2 Outbox .....................................................................................33
4.5.3 Write SMS ..............................................................................33
4.5.4 Draft ........................................................................................34
Chapter 5 Multimedia Players ........................................................35
5.1 Music Player .........................................................................35
5.1.1 Features ...................................................................................35
5.1.2 Using the Music Player ...........................................................35
5.1.3 Background Music Mode ........................................................36
5.2 Photo Viewer ........................................................................36
5.2.1 Features ...................................................................................36
5.2.2 Using the Photo Viewer ..........................................................36
5.2.3 Full-screen Display / Slide-show ............................................37
5.3 Video Player .........................................................................37
5.3.1 Features ...................................................................................37
5.3.2 Using the Video Player ...........................................................37
5.3.3 Full Screen Display .................................................................38
5.3.4 Fast Forward / Backward Play Mode ......................................39
5.4 USB Mass Storage ...............................................................39
NVM-4070 Portable Navigation System 9 Contents
Contents Index
Chapter 6 Accessary Disc ............................................................. 40
6.1 Companion CD ..................................................................... 40
6.2 DVD Map Software (update DVD) ....................................... 41
Chapter 7 Troubleshooting ........................................................... 43
7.1 Your device does not turn on. .............................................. 43
7.2 The internal battery cannot be charged. .............................. 43
7.3 System stops responding; is “frozen” or “locked up.” ........... 43
7.4 If your device still does not respond after performing
“soft reset”, try a “hard reset.” .............................................. 43
7.5 Users can also perform a “system reset.” ............................ 43
7.6 Screen is not displayed normally. ........................................ 43
7.7 The touch screen does not respond well. ............................ 43
7.8 Connection Problems with PC. ............................................ 43
7.9 No GPS connection .............................................................. 43
7.10 No sound coming from the device. ..................................... 43
7.11 Getting a GPS fix takes longer time than normal. .............. 44
7.12 Factory reset does not mean a GPS reset. ........................ 44
7.13 Bluetooth functions do not work. ........................................ 44
7.14 Unavailable functions ......................................................... 44
Index ............................................................................................... 45
NVM-4070 Portable Navigation System 10 Chapter 1 Features and Specifications
Contents Index
Chapter 1 NVM-4070 Features and Specifications
1.1 SANYO NVM-4070 Feature
The SANYO NVM-4070 Portable Navigation System is a powerful multifunc-
tion GPS navigation and entertainment device.
Compact size and lightweight
Integrated GPS receiver for GPS navigation
USA/Canada/Alaska/Hawaii/Puerto Rico map preloaded into Internal
2GB Flash
Embedded SD/MMC card slot ensuring ample data storage
Incorporates high-performance GPS antenna
High-resolution color LCD
4" wide touch screen with 16:9 scale
Bluetooth v1.2 supported with hands-free, profile
Multimedia functionality with high performance processor
1.2 NVM-4070 Specifications
General Specification
Overall dimension (w/o
antenna) 5.1" x 3.1" x 1.1" (130 mm x 79 mm x 28 mm)
Weight (incl. battery) 9.2 oz (260 g)
Certificates FCC
Operating Temperature 32 ºF to 122 ºF ( 0 ºC to 50 ºC)
Storage Temperature short period: -4 ºF to 140 ºF (-20 ºC to 60 ºC)
long period: -4 ºF to 95 ºF (-20 ºC to 35 ºC)
Charging battery
Temperature 32 ºF to 104 ºF ( 0 ºC to 40 ºC)
Hardware Main unit
Display 4" Touch screen, 480 x 272 pixel, TFT, 16.7M
colors
Memory NAND Flash 2GB
Indicators Green/Red/Orange for power, Blue for Bluetooth
Speaker 1.2 W, 8 Ω
Connectors MiniUSB (B type), SD/MMC memory slot, DC
in, Headphones, TMC
(Headphones jack) 3.5mm, stereo, More than 32 Ω
(TMC antenna jack) 2.5mm
Bluetooth Bluetooth v1.2 compatible class 2
Bluetooth Profile HFP, DUN, FTP, SPP
FM transmitter ON/OFF, Frequency setting
Microphone Bluetooth Hands-free
USB Interface USB ver. 2.0
Main Battery
Type Rechargeable Li-ion
Voltage/Capacity 3.7V, 2400 mAh
Runtime (MP3 mode,
default settings) Up to 4 hours
Charge time 3.5 hours
GPS
Type internal
Chipset SiRF GSC3
NVM-4070 Portable Navigation System 11 Chapter 1 Features and Specifications
Contents Index
Car Adaptor
Input rating 12-24V
Output rating 5.0V, 2A
Certificates CE, e-mark, C-Tick
AC Adaptor
AC Input 100-240V, 50-60Hz
DC Output 5.0V, 2A
Certificates CE,UL,TUV-GS,CCC,BSMI,K mark, C-Tick,
Singapore Safety
USB Cable
Length 4' (120 cm)
SD Card
Support Capacity Maximum 4GB (SDHC Support)
MMC (Multi Media Card)
Support Capacity Maximum 2GB
NVM-4070 Portable Navigation System 12 Chapter 2 Getting Started
Contents Index
Chapter 2 Getting Started
This chapter describes the hardware interface of the SANYO NVM-4070 and
its peripherals. Instructions for setting up the device and some basic system
operations are also discussed.
2.1 Hardware Overview
This section introduces the NVM-4070 external features and hardware compo-
nents.
2.1.1 Packing List
The SANYO NVM-4070 box contains all of the items listed below:
NVM-4070 Portable Navigation System
Dashboard Mounting Disc
Windshield & Dashboard Car Mounting kit
Car Power Adaptor
AC Power Adaptor
USB cable
Quick Start Guide
CD Instruction Manual
•Warranty
DVD Map Software
TMC antenna unit
2.1.2 External Features
Figure 1: Front Panel View
NOTE: Although the NVM-4070 rechargeable Li-ion battery comes approxi-
mately 40-80% charged, before using, it is best to connect the AC adaptor and
plug to power socket and fully charge the battery. The ON/OFF button will
glow orange when charging.
Table 1: Front panel controls
No. Function Description
1 Power / Menu button
Normal ON/OFF power button and change menu
2 Microphone Microphone (directional Microphone)
3 LED Glows blue when Bluetooth connected
4 Speaker Speaker
NOTE: Power / Menu button : Press the button for long interval as Normal
ON/OFF power button.
Press and hold the button for 2 seconds to turn
power off.
While unit power is on, press and immediately
release the button to display Main Menu.
2 3
1
4
NVM-4070 Portable Navigation System 13 Chapter 2 Getting Started
Contents Index
Figure 2: Top and Bottom view Figure 3: Left and Right side view
Table 2: Top and Bottom controls
No. Function Description
1 Microphone (nondirectional Microphone)
2 USB input Connects to the USB cable.
3 ON/OFF The main power/battery cut off switch.
4 Reset Restarts your device with (a soft reset).
4
123
Table 3: Left and Right panel controls
No. Function Description
1 Headphones Standard stereo headphones jack.
2DC Power
input For AC Adaptor or Car Adaptor
3SD/MMC
slot
Accepts a SD (Secure Digital) or MMC (MultiMediaCard)
for data storage.
4TMC antenna
jack Standard TMC antenna jack.
1
23
4
NVM-4070 Portable Navigation System 14 Chapter 2 Getting Started
Contents Index
2.2 Mounting the NVM-4070 in your vehicle
The NVM-4070 comes with a car Mounting kit and a car adaptor to help install
your device in your vehicle. The car Mounting kit uses a suction cup on the
windshield/dashboard to offer flexible mounting options for the NVM-4070.
This section shows how to install the car mount kit in your vehicle’s wind-
shield/dashboard using the suction cup. Below is the backside view of the
NVM-4070.
Figure 4: NVM-4070 Slot for Windshield & Dashboard Car Mounting kit
WARNING: Do not use the car mount kit under low temperatures. The cradle
may come off because of insufficient suction power.
WARNING: Make sure that the car mount kit does not obstruct the driver’s
view, or interfere with the operation of vehicle airbags and safety devices.
NOTICE TO DRIVERS IN CALIFORNIA AND MINNESOTA: State
law prohibits drives in California and Minnesota from using suction mounts
on their windshields while operating motor vehicles. SANYO does not take
any responsibility for any fines, penalties, or damages that may be incurred as
a result of disregarding this notice.
NOTE: Do attach the Car Adaptor to your device when you use it in vehicle.
Rechargeable batteries may sometimes not be chargeable in the vehicle.
Slots for Windshield & Dashboard Car Mounting kit
NVM-4070 Portable Navigation System 15 Chapter 2 Getting Started
Contents Index
Figure 5: Windshield & Dashboard Car Mounting kit
2
54
3
1
6
Table 4: The components of Windshield & Dashboard Car Mounting kit
No. Component Description
1Adjustable 4 prong ratch-
ing plate
Connects the device to the ratching plate
which can be adjustable horizontally and verti-
cally.
2 Tower unit Allows the device to be adjusted in 360°
3 Suction cup locking lever Secures the vacuum seal of the car mount.
4 Suction cup Fixes the car mount to the selected mounting
area.
5 Suction cup release tab Pull to release the vacuum seal of the suction
cup.
6Dashboard Mounting
Disc For Dashboard mounting usage
NVM-4070 Portable Navigation System 16 Chapter 2 Getting Started
Contents Index
Using the car Mounting kit
1. Clean and dry the mounting surface with a clean cotton cloth.
2. If the ambient temperature is below +60°F (15°C), you can warm the
mounting area and the suction cup (e.g. with a hair dryer) to ensure a
strong suction bond.
3. Install the car mount on the selected area.
On the Windshield
a. Fix the suction cup to the selected area with the locking lever facing
up for easier access.
b. Flip the locking lever away from you to create a vacuum between the
suction cup and the window surface.
On the Dashboard
Warning: The permanent mounting adhesive is extremely difficult to
remove after it is installed.
a. Remove the backing from the permanent mounting adhesive on the
bottom of the disc and place the mounting disc on the dashboard.
b. Fix the suction cup to top of the mounting disc with the locking lever
facing up for easier access.
c. Flip the locking lever away from you to create a vacuum between the
suction cup and the mounting disc.
Make sure that the suction is strong and stable before proceeding to the
next step.
4. After you are sure the mounting bracket is safe and secure, attach and slide
the NVM-4070 into its ratching plate. It snaps in easily with the quick
release connectors.
5. Adjust the car mount for the best viewing angle.
6. Connect the car adaptor into the cigarette lighter receptacle.
7. The car adaptor LED indicator will glow when powered.
8. Plug the car adaptor into the side of the NVM-4070 and position the cord
to an appropriate location.
Figure 6: Mounting on the windshield
NOTE: Your car may be required to switch the vehicle ignition into the
accessories position to power the cigarette lighter. Your NVM-4070 will not
charge with the ignition off.
New Photograph
NVM-4070 Portable Navigation System 17 Chapter 2 Getting Started
Contents Index
Figure 7: Mounting on the dashboard
9. Detach the NVM-4070 from the Car mounting kit (ratching plate)
Figure 8: Mounting on the dashboard
2.3 Set up TMC antenna unit in your vehicle
Figure 9: TMC antenna with take up reel
New Photograph
Press lock button
on ratching plate
No. Component Description
1 TMC antenna unit Main unit with take up reel
2 Take up lever Lever for taking plug and lead wire up
3 Suction cup Fix TMC antenna on Windshield
4 TMC plug and lead wire Connect with Navigation device
NOTICE TO DRIVERS IN CALIFORNIA: Signs, stickers, or other materials
which are displayed in a 7-inch square in the lower corner of the windshield
farthest removed from the driver, signs, stickers, or other materials which are
displayed in a 7-inch square in the lower corner of the rear window fartherst
removed from the driver, or signs, stickers, or other materials which are dis-
played in a 5-inch square in the lower corner of the windshield nearest the
driver.
3
1
2
4
NVM-4070 Portable Navigation System 18 Chapter 2 Getting Started
Contents Index
Figure 10: TMC antenna recommended connection method
Using the TMC antenna unit
1. Clean and dry the suction cup surface with a clean cotton cloth.
2. Fix TMC antenna unit on Windshild as recommended connection method
3. Plug into Navigation device TMC jack
WARNING: Make sure that the TMC antenna does not obstruct the driver’s
view, or interfere with the operation of vehicle airbags and safety devices.
WARNING: When you reel off the TMC antenna real, you must do it holding
the plug, because reeling speed is very fast.
NOTE: SANYO is not responsible for the availability or quality of traffic
information provided by TMC.
New Photograph
NVM-4070 Portable Navigation System 19 Chapter 3 System
Contents Index
Chapter 3 System
3.1 NVM-4070 Operating Basics
You can now turn it on to calibrate the screen. After screen calibration, proceed
to system settings configuration.
3.2 To turn on and calibrate the device:
1. Turn on the Battery ON / OFF switch.
2. Tap the center of the target as it moves around the screen.
NOTE: If you turn on/off the device by using Battery switch, the clock will be
reset. At that time, please set Date & Time again.
NOTE: When you first turn on your device, you will be asked to calibrate the
screen. This process ensures the accuracy of the touchscreen when used.
NOTE: Calibration is repeated until it succeeds.
NVM-4070 Portable Navigation System 20 Chapter 3 System
Contents Index
3. To set the system language settings, tap the forward or backward arrow
until the language you want appears.
Tap the Return button to set the language and return to the System Menu.
4. To set the system date and time, tap “Date & Time” in System Menu.
When you tap “12H”, the time format changes to “24H” format.
5. Tap the correct Year, Month and Day.
Tap the Return button to set the Date and return to the “Date & Time”
Menu.
6. Tap the “Time” in the “Date & Time” Menu.
7. Tap the Return button to set the Time and return to the “Date & Time”
Menu.
NVM-4070 Portable Navigation System 21 Chapter 3 System
Contents Index
8. Next, tap “Time Zone” in the “Date & Time” Menu.
If you check “Automatic daylight saving time”, NVM-4070 adjusts clock
for daylight saving automatically.
9. After all settings are finished, the Main Menu opens.
3.3 System Settings
System setting can be used to view and adjust your device current preferences.
Navigate from the System Menu.
3.3.1 Language
Refer to Chapter 3.2.
3.3.2 Date & Time
Refer to Chapter 3.2.
12345
No. Description
1FM Transmitter Icon (This icon is displayed when FM-Transmitter is
ON)
2 Battery Status
3
Bluetooth Status
: Bluetooth is “ON”.
Mobile phone is not connected.
: Mobile phone is connected.
4 The name of the connected mobile phone
5Time
NVM-4070 Portable Navigation System 22 Chapter 3 System
Contents Index
3.3.3 Brightness
1. Tap the Brightness icon in the System Menu.
2. Tap + or - to set the Backlight brightness.
3. Tap the left or right arrow to set the LCD power-save of battery and AC
power drive modes.
4. Tap the Return button to return to the System Menu.
3.3.4 Volume
1. Tap the Volume icon in the System Menu.
2. Tap + or - to set default system sound volume.
3. Tap the Return button to save and return to the System Menu.
3.3.5 FM Transmitter
1. When tapping the bottom-left button in the Volume screen, the Check mark
is added.
2. NVM-4070’s Speaker output is set to OFF. Volume is changed to the max-
imum value automatically and FM Transmitter output is turned ON.
3. Tap the Frequency (XX.X MHz) button.
4. Input frequency using “FM Transmitter Frequency” screen and then tap
“Set”.
NVM-4070 Portable Navigation System 23 Chapter 3 System
Contents Index
5. Tap the bottom-left button again. FM Transmitter output is turned OFF.
3.3.6 Power
1. Tap the Power icon in the System Menu.
2. When AC adaptor or Car adaptor is disconnected, you can view the
remaining battery power in the Battery Level bar.
3. Tap the Return button to return to the System Menu.
3.3.7 System Information
1. Tap the Sys Info. icon in the System Menu.
2. You can view the OS version, GPS firmware version and other system
information.
3. Tap “Calibration” to open the Calibration screen of the touch panel.
Tap the center of the target as it moves around the screen.
NVM-4070 Portable Navigation System 24 Chapter 3 System
Contents Index
4. Tap “Factory Reset” to open a dialog box to select whether to reset the set-
tings. Tap “YES” to reset the settings and “NO” not to reset the settings.
5. Tap “GPS Reset” to open a dialog box to select whether to reset the GPS
satellite receiver. Tap “YES” to reset the receiver and “NO” not to reset the
receiver.
6. Tap the Return button to return to the System Menu.
NVM-4070 Portable Navigation System 25 Chapter 4 Communications
Contents Index
Chapter 4 Communications
“Communications” provides the various functions with the Bluetooth mobile
phone.
“Communications” main menu is as follows:
4.1 Connection
4.1.1 Mobile Phone Connection (New)
1. Set Bluetooth to “ON” in the “Settings”, and tap the “Connection” button
of the “Communications” screen.
2. Tap the “Search” button. NVM-4070 starts to search available mobile
phones.
3. The available phones are displayed on the phone list. Select one of the
mobile phones and tap the “Connect” button.
No. Description
1 The name of the connected mobile phone
2
Bluetooth Status
: Bluetooth is “ON”.
Mobile phone is not connected.
: Mobile phone is connected.
21
NOTE: Make sure the Bluetooth settings of your mobile phone.
- The Bluetooth switch is set to “ON” or “enable”.
- The visibility is set to “Discoverable”, “Show my phone”.
(For more detailed information, see your phone’s manual.)
NVM-4070 Portable Navigation System 26 Chapter 4 Communications
Contents Index
4. The mobile phone will often require you to enter a password to connect the
device. Enter “0000” on the mobile phone in this case.
5. When the connection completes, the screen returns to the “Communica-
tions” screen. The name of the connected phone is displayed on the title
bar. And the Bluetooth icon changes to green.
4.1.2 Mobile Phone Connection (Reconnect)
1. Set Bluetooth to “ON” on the “Settings”, and tap the “Connection” button
of the “Communications” screen. The mobile phones that have connected
in the past displays on the “Paired list” .
2. Select one of the mobile phones and tap the “Connect”.
3. The mobile phone will often require you to enter a password to connect the
device. Enter “0000” on the mobile phone in this case.
4. When the connection completes, the screen returns to the “Communica-
tions” screen. The name of the connected phone is displayed on the title
bar. And the Bluetooth icon changes to green.
NOTE: If the connected mobile phone has the Bluetooth auto-accept function,
set this function to “ON”.
(For more detailed information, see your phone’s manual.)
NVM-4070 Portable Navigation System 27 Chapter 4 Communications
Contents Index
4.2 Hands-free Calling
“Call-out” screen is as follows:
Call-out
Call-out (in a phone call)
4.2.1 Making a Call
1. Tap the “Call-out” button of the “Communications”, the Call-out screen
opens.
2. Input a phone number and tap .
NVM-4070 starts to make a call.
3. Tap , the phone call quits.
No. Name Description
1 Dial-up Start to make a call.
2 History Call-out from the history of the incoming / outgoing
call
3 Contacts Call-out from the contacts. In detail, refer to 4.3.
1
2
3
No. Name Description
4 Hang-up Close a phone call.
5Mute
Set the microphone muting.
:Set the microphone mute to ON.
:Set the microphone mute to OFF.
5
4
NVM-4070 Portable Navigation System 28 Chapter 4 Communications
Contents Index
4.2.2 Receiving a Call
1. When the connected mobile phone receives a call, the caller's phone num-
ber and two buttons are displayed on the screen.
(If the phone number exits in the entry of Contacts, the caller's name is also
displayed.)
2. To receive a call, tap . To quit a call, tap .
3. On a phone call, the “Hang-up” button and the “Mute ON/OFF” button are
displayed at the top-right of the screen.
4. On the “Settings”, you can do the setting of the automatic answer to phone
call.
4.3 Contacts
“Contacts”screen is as follows:
4.3.1 Create new entry
1. Tap “New” button. The “Input Entry” screen opens.
No. Description
1 Save: Save the entry
2 Category Up / Down
3 Item Up / Down
4 Keyboard (Alphabet, Numbers, and Symbols)
1
3
4
2
NVM-4070 Portable Navigation System 29 Chapter 4 Communications
Contents Index
2. Input each item. All categories and items are as follows:
3. Tap the “Save” button, the entry is added to the list of Contacts.
4.3.2 Call-out
1. Select the entry and tap the “Call-out” button.
2. Select one of the enabled buttons, NVM-4070 starts to make a call to the
selected number.
4.3.3 View
1. Select one of the entries and tap the “View” button, the “View Contacts”
screen opens.
You can see the detailed information of the selected entry.
Category Record
Name First
Last
Phone
Home
Work
Mobile
Other
Home Address Street City State
Zip Country —
Work Address Street City State
Zip Country —
Others Company
E-mail
NOTE: The maximum number of the saved entry is 400.
NVM-4070 Portable Navigation System 30 Chapter 4 Communications
Contents Index
2. Tap the “Edit” button, the “Input Entry” screen opens and you can edit the
entry.
3. About the “Call-out” button, see 4.3.2.
4.3.4 Delete
1. Select the entry and tap the “Delete” button.
2. Tap “YES” to delete.
4.4 Data Transfer
Tap “Data Transfer” button in “Communications” screen.
4.4.1 File Transfer
1. Tap “File Transfer” button.
2. Files and folders on mobile phone appears.
NOTE: Not all mobile phones support “File Transfer”.
moves to upper folder.
File display
scroll

Navigation menu
