Copyright ¤ Siemens AG 2009
SIMATIC
Product Information
05/2009
For the operating instructions manual "ET 200pro Interface module IM 154-6 PN HF IWLAN,
Edition 02/2009, A5E01648493-02
This product information contains additional reference notes to approvals according to FCC
and RSS-210 of Industry Canada and is an extension of chapter 10.1 Standards and
approvals. The Product Information is part of the supplied product and the statements made
therein are binding in case of doubt.
Approval according to FCC
This device complies with Part 15 of the FCC Rules
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation.
IEEE802.11b or g operation of this product in the USA is firmware-limited to channels 1 through
11.
Notice
Changes or modifications made to this equipment not expressly approved by SIEMENS may
void the FCC authorization to operate this equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, wich can be determined by turning
the equipment off and on, the user encouraged to try to correct the interference by one or more
of the following measures:
x Reorient or relocate the receiving antenna.
x Increase the separation between the equipment and receiver.
x Connect the equipment into an outlet on a circuit different from that to wich the receiver
is connected.
.
Product Information
2A5E02574910 01
Consult the dealer or an experienced radio/TV technician for help.
Notice
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
enviroment. This equipment should be installed and operated with minimum distance 20 cm
between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Professional Installation Notice:
To comply with FCC Part 15 rules in the United States, the system must be professionally
installed to ensure compliance with the Part 15 certification. It is the responsibility of the
operator and professional installer to ensure that only certified systems are deployed in the
United States. The use of the system in any other combination (such as co-located antennas
transmitting the same information) is expressly forbidden.
RSS-210 of Industry Canada
"Operation is subjecte to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device."
"This device has been designed to operate with the antennas listed below, and having a
maximum gain of 18 dBi. Antennas not included in this list or having a gain greater than 18 dBi
are strictly prohibited for use with this device. The required antenna impedance is 50 ohms."
"To reduce potential radio interference to other users, the antenna type and its gain should be
so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that
permitted for successful communication."
That the device for the band 5150-5250 MHz is only for indoor usage to reduce potential for
harmful interference to co-channel mobile satellite systems."
"Users should also be cautioned to take note that high power radars are allocated as primary
users (meaning they have priority) of 5250-5350 MHz and 5650-5850 MHz and these radars
could cause interference and/or damage to LE-LAN devices."
2
2
Within the 5.15 -5.25 GHz band, this device is only for indoor use operations to reduce any
p
otential for harmful interference to co-channel MSS operations.
