Sky Light Imaging HPC02 Parrot Cloud Camera User Manual
Sky Light Imaging Limited Parrot Cloud Camera
User Manual
![](/img.php?id=3142764&img=bg1.png)
Home+ Parrot
HPC02B
User Manual
Home+ Android Home+ iOS
Features
Stunning video quality.
109° wide field of view.
Set up your camera directly from your smart device.
Live stream via your smart device.
Specifications
Wireless....................................................802.11 b/g/n
Lens............................................................Wide angle
Video Resolution................................720p(1280x720)
..........................................................WVGA(848x480)
......................................................WQVGA (432X240)
Video Format......................................................H.264
Photo Resolution..................................................1MP
White Balance......................................................Auto
Night Vision........................................Around 5 meters
Microphone.......................................................Built-in
Speaker.........................................Built-in, 1W,8ohm
Sound Detection....................................................Yes
Motion Detection....................................................Yes
Power...................................................AC/DC adapter
Input Voltage............................AC:100-240V/50-60HZ
Output Voltage...........................................DC:5V/1.0A
Compatibility...................IOS 7.0/Android 4.3 or higher
CPU......................................................1GHz or above
RAM........................................................1GB or above
Operating Temperature.................................-10°-40°C
Storage Temperature....................................-40°-80°C
Specifications are subject to change and improvement
without notice. Actual product may vary from the images
found in this document.
Package Contents
• Home+ Parrot Cloud Camera
• AC Adapter with USB cable
• Wall insert x 2
• Screw x 2
• User Manual
Functional Parts
Troubleshooting
Camera disconnects from Wi-Fi network
• Check with your internet service provider.
• Move your camera closer to your router.
• Reduce the number of connected devices near the
camera.
Fail to view videos using your smart device
• Reconnect the camera to your Wi-Fi network.
• Check the USB cable and power connection.
Status LED lights up in Red
• Restart your router.
• Reset your camera and pair it again.
• Press and hold the RST hole for 7 seconds to factory
reset your camera and do setup again.
Status LED flashes in Red slowly
• Make sure your internet Connection is alright.
Camera cannot recognize QR Code
• Make sure the camera lens and the QR code are in
parallel.
• Adjust the scan distance properly per the screen size
of your mobile device.
• Avoid scanning in dark environment or strong
sunlight.
Camera cannot detect router
• Set the router’s channel within the range from 1 to 11.
FCC Statement
Warning: Changes or modifications to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to operate the
equipment.
FCC RF Radiation Exposure Statement Caution: To
maintain compliance with the FCC's RF exposure
guidelines, place the product at least 20cm from nearby
persons.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/ TV
technician for help.
Connect your Camera to an External
Power Supply
1. Connect the camera to the AC adaptor with the USB
cable and plug the adapter into an outlet. The
camera turns on automatically, the status LED
indicator shows stable purple for about 15 seconds,
then shows stable blue for about 20 seconds, then
blinks alternately in red and blue.
2. Place the camera wherever you want.
Set up your Camera
The camera can be set up and connected to an AP by
scanning a QR code and reading the AP information
through the Home+ Application.
Remark:
1. Search for Home+ app via the Play Store or App
Store with keywords (For Play Store: videocloud or
homeplus. For App Store: videocloud.). Download
and install the app to your smart device. Or to scan
QR code at the top page for downloading App
interface directly.
2. Plug it in and connect to your Wi-Fi network. You’re
ready to begin live streaming!
3. Please refer to the “Help” page of the home+ app to
download, operate, and utilize the full capabilities of
the App.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received,
including interference that may cause undesired
operation.
Recycling
This product bears the selective sorting symbol
for Waste electrical and electronic equipment
(WEEE). This means that this product must be
handled pursuant to European directive
2012/19/EU in order to be recycled of
dismantled to minimize its impact on the
environment.
User has the choice to give his product to a competent
recycling organization or to the retailer when he buys a
new electrical or electronic equipment.
AM-HPC02-GB-STD-7
Mount your Camera on a Wall or
Ceiling
You can place the camera on flat surface or mount it on
any wall or ceiling.
1. Attach the camera to your wall or ceiling by using
the including screws and wall insert.
2. Mount your camera by fitting the base into screws.
3. Plug it into a power outlet.
Microphone
For audio input
IR LED
Turn on/off night
vision automatically
Lens
Provide a clear, wide
angle sight
Status LED Indicator
Show the camera status.
Micro SD card slot
Store video inside the card
Swivel Joint
Pan the camera by
different location usage
Reset Hole
Reset the camera
Speaker
Micro USB port
Set button - Press to enter
the QR code scanning mode.
Rubber Base
Increase friction to fix
camera on smooth surface
Mounting Slot
Direct attach the
camera to screws
