Sunrex Technology Corp Air mini BT Keyboard EBK 11CA
User Manual
![](/img.php?id=1746686&img=bg1.png)
Air mini BT Keyboard
EBK-11CA
User Manual
Important Information
System Requirements
Precondition for the use of the keyboard is that your device (PC, notebook, tablet,
handheld, etc.)
• is hardware-sided Bluetooth-enabled (e.g. by an integrated Bluetooth module or
external adapter)
• software-sided (Bluetooth) supports faultlessly the HID profile
• software-sided (operating system) supports faultlessly standard keyboard drivers
with corresponding country code
Hardware Installation
Ensure for the further procedure that the used Bluetooth driver software was installed
correctly on your PC.
In order to open up the battery case which is on the back side of the keyboard, apply
light pressure and pull the entire cover on the back of the keyboard downwards.
Now put in two type AAA 1.5V batteries, considering the right polarity in the battery
case.
Switch the on/off switch to On.
After connecting the Bluetooth adapter with your PC, the blue Bluetooth logo appears
at the bottom right corner of the screen.
ID Pairing Procedure
Press and hold the Fn-key together with the ESC/ -key for 2 seconds. This initiates
the pairing process and a synchronization signal is sent to the BT receiver.
The synchronization process can take up to 10 seconds. The LED (top, left corner)
will be blinking in green during this process. When it turns off, the pairing is complete,
the synchronization process is now complete.
PDF created with FinePrint pdfFactory Pro trial version http://www.pdffactory.com
![](/img.php?id=1746686&img=bg2.png)
A double click with the left mouse key on the Bluetooth logo opens the menu
Bluetooth devices.
Note:
-Make sure your PC is ON and running when doing the pairing procedure.
-You don’t have to pair ID again after changing batteries. If it can’t work, please follow
the steps above to pair ID.
Import Usage Information
Battery:
1. We recommend using alkaline batteries for a longer battery life.
2. Don’t mix different types of batteries or new and old batteries together. Always
replaced old batteries with new and same type batteries.
3. Remove batteries after long periods of non-use. Battery leakage or corrosion may
damage the device quality and cause danger.
Rating:
Keyboard: 3VDC 50mA
Max. operating temperature: 40
C
CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the authority to operate equipment.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
PDF created with FinePrint pdfFactory Pro trial version http://www.pdffactory.com
![](/img.php?id=1746686&img=bg3.png)
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Industry Canada Notice
Operation is subject to the following two conditions: (1) this device may
not cause interference and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
