User Manual
![](/img.php?id=3395750&img=bg1.png)
HP Wireless Collaboration Keyboard & HP
Wireless Premium Keyboard
Model: HSA-S001K / HSA-S003K
User Manual
HP Wireless Collaboration Keyboard (HSA-S001K)
HP Wireless Premium Keyboard(HSA-S003K)
Important Information
For Windows® 8.1 operating system, you can use the keyboard immediately
after plugging the dongle (receiver) into the USB port.
Hardware Installation
![](/img.php?id=3395750&img=bg2.png)
Plug in the dongle into your available USB port.
Please turn on power switch.
ID Pairing Procedure
Keyboard and dongle has paired when ship out. If it can’t work, please follow the
steps to process the ID pairing procedure.
1. ID pairing/connect button location:
Keyboard ID pairing/connect button on the bottom of the keyboard.
2. After you plug the dongle into the USB port, please hold the keyboard close to the
dongle within 6cm and press the “
Connect
” button over 5 second.
3. If the pairing succeed Amber LED will flash 3 times
4. If the pairing fail Amber LED will turns on 10 sec then OFF
Note:
-Make sure your PC is ON and running when doing the pairing procedure.
-You don’t have to pair ID again after changing batteries. If it can’t work, please follow
the steps above to pair ID.
Specification
Interface: Wireless 2.4 GHz
Frequency band: 2406MHz-2475MHz
Maximum radio-frequency power transmitted: ≤10 mW
Power: Li-ion Battery
Ports: Micro USB Type B charge port
Key Module: Scissor type, leverage HP premium NB series
Others: Link 5 connect button, function lock switch, power switch
Item Specification
Operating Temperature 0 ~ +40℃
Storage Temperature -20 ~ +60℃
Compatibility USB interface
Operating system Windows 7/8.1/10
Dimension 433 (L) * 141 (W) * 11.80 (H) mm
Key specification
Key no US(105);UK(106);JP(110)
![](/img.php?id=3395750&img=bg3.png)
Key structure Scissor type
Switch mechanism Membrane
Key cap legend Printed (Lync Buttons Laser Printed)
LED
Number 8
Color Amber , White, Green
Indicator Battery Low:
- If battery voltage ≤ 3.4V indicator (Amber LED)
will turn on
Pairing:
- If the pairing succeed Amber LED will flash 3 times
(on/off: 100ms/400ms)
- If the pairing fail Amber LED will turns on 10 sec
then OFF
RF Specification
Frequency 2.4GHz`
Deviation +/-320KHz
Modulation mode GFSK
Channel 70CH
ID number 2^32
Connect Press “Connect” Button 5 sec (distance from Dongle
6 cm)
Effective operating
distance 10Meters
Antenna Specification
PCB Antenna
Power Specification
Battery Li-ion Battery
Power consumption DC 3.7V , ±5%
Battery life 3 month
Other Stop transmission after 5 min of idle or when key is
continuously pressed
Appearance
![](/img.php?id=3395750&img=bg4.png)
Bottom
Function
Funtion
System Sleep
Lock Computer
My Computer/File Explorer
Display Options
![](/img.php?id=3395750&img=bg5.png)
Brightness Decrement
Brightness Increment
Search Charm
Devices Charm
Lync Contacts
Lync Calendar
Share Screen
Mute
Volume decrement
Volume Increment
Call Answer(HSA-S003K Non)
Call End(HSA-S003K Non)
Video Mute(HSA-S003K Non)
![](/img.php?id=3395750&img=bg6.png)
Microphone Mute(HSA-S003K Non)
RF 2.4GHz frequency table
The channel selection algorithm produces a subset containing 13 of the possible 78 channels.
The channel selection algorithm is based on the network ID, with each channel in the subset
being six megahertz from the nearest neighboring channels in the subset. This algorithm
reduces the possibility of multiple bridges selecting the same channels in the same order at
the same time.
CH
Frequency CH
Frequency CH
Frequency CH
Frequency
1 2.406GHz 21
2.426GHz 41
2.446GHz 61
2.466GHz
2 2.407GHz 22
2.427GHz 42
2.447GHz 62
2.467GHz
3 2.408GHz 23
2.428GHz 43
2.448GHz 63
2.468GHz
4 2.409GHz 24
2.429GHz 44
2.449GHz 64
2.469GHz
5 2.410GHz 25
2.430GHz 45
2.450GHz 65
2.470GHz
6 2.411GHz 26
2.431GHz 46
2.451GHz 66
2.471GHz
7 2.412GHz 27
2.432GHz 47
2.452GHz 67
2.472GHz
8 2.413GHz 28
2.433GHz 48
2.453GHz 68
2.473GHz
9 2.414GHz 29
2.434GHz 49
2.454GHz 69
2.474GHz
10 2.415GHz 30
2.435GHz 50
2.455GHz 70
2.475GHz
11 2.416GHz 31
2.436GHz 51
2.456GHz
12 2.417GHz 32
2.437GHz 52
2.457GHz
13 2.418GHz 33
2.438GHz 53
2.458GHz
14 2.419GHz 34
2.439GHz 54
2.459GHz
15 2.420GHz 35
2.440GHz 55
2.460GHz
16 2.421GHz 36
2.441GHz 56
2.461GHz
17 2.422GHz 37
2.442GHz 57
2.462GHz
18 2.423GHz 38
2.443GHz 58
2.463GHz
19 2.424GHz 39
2.444GHz 59
2.464GHz
20 2.425GHz 40
2.445GHz 60
2.465GHz
Label Specification:
![](/img.php?id=3395750&img=bg7.png)
Manufacturer Name: HP Inc.
Corporate Address: 1501 Page Mill Road Palo Alto, CA 94304, USA
CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the authority to operate equipment.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Industry Canada Notice
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
