CR-H500NT
AM/FM Stereo Receiver
OWNER’S MANUAL
MODE D’EMPLOI
MANUAL DEL USUARIO
EN_CR-H500NT_T_C.indb 1EN_CR-H500NT_T_C.indb 1 09.9.24 6:50:36 PM09.9.24 6:50:36 PM
![](/img.php?id=1188841&img=bg2.png)
2
10) Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand,
tripod, bracket, or table specified
by the manufacturer, or sold with
the apparatus. When a cart is
used, use caution when moving
the cart/apparatus combination
to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or
when unused for long periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
The lightning flash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the presence
of uninsulated “dangerous voltage” within
the product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
IMPORTANT SAFETY
INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
< Do not expose this apparatus to drips or splashes.
< Do not place any objects filled with liquids, such as
vases, on the apparatus.
< Do not install this apparatus in a confined space such
as a bookcase or similar unit.
< The apparatus draws nominal non-operating power
from the AC outlet with its POWER or STANDBY/ON
switch not in the ON position.
< The apparatus should be located close enough to the
AC outlet so that you can easily grasp the power cord
plug at any time.
< The mains plug is used as the disconnect device, the
disconnect device shall remain readily operable.
< If the product uses batteries (including a battery pack
or installed batteries), they should not be exposed to
sunshine, fire or excessive heat.
< Caution should be taken when using earphones or
headphones with the product because excessive
sound pressure (volume) from earphones or
headphones can cause hearing loss.
EN_CR-H500NT_T_C.indb 2EN_CR-H500NT_T_C.indb 2 09.9.24 6:50:39 PM09.9.24 6:50:39 PM
![](/img.php?id=1188841&img=bg3.png)
3
CAUTION
< DO NOT REMOVE THE EXTERNAL CASES OR CABINETS
TO EXPOSE THE ELECTRONICS. NO USER SERVICEABLE
PARTS ARE WITHIN!
< IF YOU ARE EXPERIENCING PROBLEMS WITH THIS
PRODUCT, CONTACT TEAC FOR A SERVICE REFERRAL.
DO NOT USE THE PRODUCT UNTIL IT HAS BEEN
REPAIRED.
< USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
WARNING: TO PREVENT FIRE OR
SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
MPEG Layer-3 audio coding technology licensed from
Fraunhofer IIS and Thomson.
Supply of this product does not convey a license nor imply
any right to distribute MPEG Layer-3 compliant content
created with this product in revenue-generating broadcast
systems (terrestrial, satellite, cable and/or other distribution
channels), streaming applications (via Internet, intranets and/
or other networks), other content distribution systems (pay-
audio or audio-on-demand applications and the like) or
on physical media (compact discs, digital versatile discs,
semiconductor chips, hard drives, memory cards and the like).
An independent license for such use is required. For details,
please visit http://mp3licensing.com.
This product is protected by certain intellectual property
rights of Microsoft Corporation. Use or distribution of such
technology outside of this product is prohibited without a
license from Microsoft.
“Made for iPod” means that an electronic accessory has
been designed to connect specifically to iPod and has been
certified by the developer to meet Apple performance
standards.
Apple is not responsible for the operation of this device or its
compliance with safety and regulatory standards.
iPod is a trademark of Apple Inc., registered in the U.S. and
other countries.
For U.S.A.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
< Reorient or relocate the equipment and/or the
receiving antenna.
< Increase the separation between the equipment
and receiver.
< Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
< Consult the dealer or an experienced radio/TV
technician for help.
CAUTION
Changes or modifications to this equipment not
expressly approved by TEAC CORPORATION for
compliance will void the user’s warranty.
This product has been designed and manufactured
according to FDA regulations “title 21, CFR, chapter 1,
subchapter J, based on the Radiation Control for Health
and Safety Act of 1968“, and is classified as class 1 laser
product. There is not hazardous invisible laser radiation
during operation because invisible laser radiation emitted
inside of this product is completely confined in the
protective housings.
The label required in this regulation is shown 1.
Optical pickup :
Type : SF-P101VZ
Manufacturer : Sanyo Electric Co., Ltd
Laser output : Less than 1mW on the objective lens
Wavelength : 790±30nm
1 For USA
EN_CR-H500NT_T_C.indb 3EN_CR-H500NT_T_C.indb 3 09.9.24 6:50:40 PM09.9.24 6:50:40 PM
![](/img.php?id=1188841&img=bg4.png)
4
Before Use
Read this before operations.
< When the unit is turned on, switching on the TV may
result in lines appearing on the TV screen, depending
on the condition of the electric waves of the TV
broadcast. This is not malfunction in the unit or the TV.
In this case, turn off the unit.
< As the unit may become warm during operation,
always leave sufficient space around the unit for
ventilation.
< The voltage supplied to the unit should match the
voltage as printed on the rear panel. If you are in any
doubt regarding this matter, consult an electrician.
< Choose the installation location of your unit carefully.
Avoid placing it in direct sunlight or close to a source
of heat. Also avoid locations subject to vibrations and
excessive dust, heat, cold or moisture.
< Do not place the unit on an amplifier/receiver.
< Do not open the cabinet as this might result in
damage to the circuitry or electrical shock. If a foreign
object should get into the set, contact your dealer or
service agency.
< When removing the power plug from the wall outlet,
always pull directly on the plug, never yank the cord.
< Do not attempt to clean the unit with chemical
solvents as this might damage the finish. Use a clean,
dry cloth.
< Keep this manual in a safe place for future reference.
< The operations are illustrated using the European
model for example in this manual.
Contents
Thank you for choosing TEAC. Read this manual
carefully to get the best performance from this
unit.
Before Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
MP3 and WMA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
iPod compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connecting Antennas (AM/FM) . . . . . . . . . . . . . . . . . . . . . . . . 7
Speaker Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Part names (main unit) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Part names (remote control unit) . . . . . . . . . . . . . . . . . . . . . 14
Remote Control Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Disc Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
USB Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
General Playback Opertions (disc/USB) . . . . . . . . . . . . . . . . 20
Folder Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Programmed Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Shuffle Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Repeat Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Before Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Recording to USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Deleting a file from USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Listening to iPod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Listening to FM/AM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Preset Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
RDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
PTY Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Internet Radio Initial Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Listening to Internet Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Radio Portal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Setting up Music Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Listening to Music Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Network Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Setting the Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Timer Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Sleep Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Using an External Component . . . . . . . . . . . . . . . . . . . . . . . . 52
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
EN_CR-H500NT_T_C.indb 4EN_CR-H500NT_T_C.indb 4 09.9.24 6:50:40 PM09.9.24 6:50:40 PM
![](/img.php?id=1188841&img=bg5.png)
ENGLISH
5
Discs
Discs which can be played on this unit:
M Conventional audio CDs bearing the COMPACT DISC
DIGITAL AUDIO logo on the label.
M Properly finalized CD-R and CD-RW discs
M MP3 CDs
Note:
< Depending on the quality of the disc and/or the
condition of the recording, some CD-R/CD-RW discs
may not be playable.
< Copy-protected discs and other discs which do
not conform to the CD standard may not play back
correctly in this player. If you use such discs in this
unit, TEAC Corporation and its subsidiaries cannot be
responsible for any consequences or guarantee the
quality of reproduction. If you experience problems
with such non-standard discs, you should contact the
producers of the disc.
< Always place the disc on the disc tray with the label
side uppermost. (Compact discs can be played or
recorded only on one side.)
< To remove a disc from its storage case, press down on
the center of the case and lift the disc out, holding it
carefully by the edges.
< If the disc becomes dirty, wipe the surface radially
from the center hole outward towards the outer edge
with a soft and dry cloth.
< Never use such chemicals as record sprays, antistatic
sprays or fluid, benzine or thinner to clean the discs.
Such chemicals will do irreparable damage to the
disc’s plastic surface.
< Discs should be returned to their cases after use to
avoid dust and scratches that could cause the laser
pickup to ”skip”.
< Do not expose discs to direct sunlight or high humidity
and temperature for extended periods. Long exposure
to high temperatures will warp the disc.
< Do not play any disc that is warped, deformed or
damaged. Playing such discs may cause irreparable
harm to the playing mechanisms.
< CD-R and CD-RW discs are more sensitive to the
effects of heat and ultraviolet rays than ordinary CDs.
It is important that they are not stored in a location
where direct sunlight will fall on them, and which is
away from sources of heat such as radiators or heat-
generating electrical devices.
< Printable CD-R and CD-RW discs aren’t recommended,
as the label side might be sticky and damage the unit.
< Do not stick papers or protective sheets on the discs
and do not use any protective coating spray.
< Use a soft oil-based felt-tipped pen to write the
information on the label side. Never use a ball-point
or hard-tipped pen, as this may cause damage to the
recorded side.
< Never use a stabilizer. Using commercially available CD
stabilizers with this unit will damage the mechanisms
and cause them to malfunction.
< Do not use irregular shape CDs (octagonal, heart
shaped, business card size, etc.). CDs of this sort can
damage the unit.
< If you are in any doubt as to the care and handling of
a CDR/CD-RW disc, read the precautions supplied with
the disc, or contact the disc manufacturer directly.
EN_CR-H500NT_T_C.indb 5EN_CR-H500NT_T_C.indb 5 09.9.24 6:50:41 PM09.9.24 6:50:41 PM
![](/img.php?id=1188841&img=bg6.png)
6
< This unit can play MP3 files recorded in various external
USB storage devices such as USB flash memory, MP3
player or HDD.
The HDD must be formatted FAT 16 or FAT 32, but not
NTFS.
< When more than 2000 files are recorded on the USB
memory, the unit might not be able to play them
correctly.
< File names of MP3 or WMA should be alphanumeric
characters. This unit cannot display symbols and full-
size or double-byte characters (such as Japanese,
Chinese, etc.) correctly. Also, be sure to use the file
extension. (“.mp3” for MP3 files, “.wma” for WMA files.)
< MP3 files are mono or stereo MPEG-1 Audio Layer 3
format. This unit can play MP3 files with a sampling
frequency of 44.1 kHz or 48 kHz, and a bit-rate of 320
kbps or less.
< This unit can play WMA files with a sampling frequency
of 44.1 kHz and a bit-rate of 192 kbps or less.
WMA stands for Windows Media Audio.
< Audio encoded at 128 kbps should sound close to
regular audio CD quality. Although this player will play
lower bit-rate MP3 files, the sound quality becomes
noticeably worse at lower bit-rates.
MP3 and WMA
This unit can be connected to and used with the
following iPod models.
iPod (5th generation)
iPod classic
iPod nano (1st generation)
iPod nano (2nd generation)
iPod nano (3rd generation)
iPod nano (4th generation)
iPod nano (5th generation)
iPod touch
iPod touch (2nd generation)
iPod touch (3rd generation)
< You cannot use following models in “Direct Mode” of
Display mode and for the timer:
iPod (5th generation,) iPod nano (1st/2nd generation)
(See page 29 for information about Display mode.)
< This unit cannot output video from a connected iPod.
< To connect the iPod, use the USB cable supplied with
iPod.
< It cannot be played if you connect an iPod shuffle to
this port.
Compatible iPod Software
In case your iPod will not work with the CR-H500NT
or with the remote control unit, software update may
solve the problem.
Visit the Apple website and download the latest iPod
software.
iPod compatibility
EN_CR-H500NT_T_C.indb 6EN_CR-H500NT_T_C.indb 6 09.9.24 6:50:42 PM09.9.24 6:50:42 PM
![](/img.php?id=1188841&img=bg7.png)
ENGLISH
7
FM Indoor Antenna
Connect the lead-type FM antenna to the FM 75Ω socket,
extend the lead and tune in your favourite station (see
page 30). Adjust the antenna in a suitable location like a
window frame or wall until the reception is best and then
affix the antenna in that position using thumb tacks, push
pins or any other suitable means.
FM Outdoor Antenna
In an area where FM signals are weak, it may be necessary
to use an FM outdoor antenna.
Generally, a 3-element antenna will be sufficient; if you
live in an area where the FM signals are particularly weak,
it may be necessary to use one with 5 or more elements.
< Disconnect the FM indoor antenna when using an
outdoor antenna.
AM Indoor Loop Antenna
The high-performance AM loop antenna provided with
this unit is sufficient for good reception in most areas.
To stand the loop antenna on a surface, fix the claw to the
slot in the antenna base.
Connect the loop antenna’s wires to the AM antenna
terminals.
Place the antenna on a shelf or hang it on a window
frame, etc., in the direction which gives the best
reception. Keep all other wires such as power cords,
speaker wires or interconnect wires as far away as possible
from the antenna.
< If the AM loop antenna provided does not deliver
sufficient reception (often due to being too far from
the transmitter or in a concrete building, etc.), it may
be necessary to use an AM outdoor antenna.
Use either a high quality commercially available AM
antenna or, if not available, an insulated wire more
than 5 m long. Strip one end, and connect this to the
terminal as shown.
The antenna wire should be fitted outdoors or indoors
near a window. For better reception, connect the GND
terminal to a reliable ground.
Note:
Even when using an AM outdoor antenna, do not
disconnect the AM loop antenna.
Connecting Antennas (AM/FM)
AM Outdoor
Antenna
Make sure to connect
the black wire to the
GND terminal.
EN_CR-H500NT_T_C.indb 7EN_CR-H500NT_T_C.indb 7 09.9.24 6:50:42 PM09.9.24 6:50:42 PM
![](/img.php?id=1188841&img=bg8.png)
8
LINE
IN
B
A
SUBWOOFER
SPEAKER
Speaker Connections
EN_CR-H500NT_T_C.indb 8EN_CR-H500NT_T_C.indb 8 09.9.24 6:50:43 PM09.9.24 6:50:43 PM
![](/img.php?id=1188841&img=bg9.png)
ENGLISH
9
A Speaker Connections
CR-H500NT’s + (positive) terminals are red ( for the
right speaker) and white (for the left speaker.) The _
(negative) terminals are black.
The + side of the speaker cable is marked to make it
distinguishable from the negative side of the cable.
Connect this marked side to the red and white +
terminals and the unmarked side to the black _
terminals of CR-H500NT and speakers.
CAUTION
< To avoid damaging the speakers with sudden high-
volume sound, be sure to switch the power off
before connecting the speakers.
< Check the impedance of your speakers. Connect
speaker with an impedance of 6 ohms or more.
< Prepare the speaker cables for connection by
stripping off approximately 10 mm or less (no more
as this could cause a short-circuit) of the outer
insulation. Twist the wires tightly together to avoid
tangles:
How to connect
1. Turn the terminal cap counter-clockwise to loosen it.
The speaker terminal caps cannot be fully removed
from the base.
2. Insert the wire into the terminal fully and turn the
terminal cap clockwise to securely connect it:
3. Make sure it is fastened firmly by pulling the cable
lightly.
For European customers
In accordance with European safety regulations, it is
not possible to connect banana plugs into the speaker
terminals on European models. The holes into which
banana plugs are inserted have been covered with black
caps. Connect the speakers using spades or bare wires.
If the black caps become separated from the terminals,
return them to their original position.
B SUBWOOFER OUT jack
Connect a commercially available powered
subwoofer.
EN_CR-H500NT_T_C.indb 9EN_CR-H500NT_T_C.indb 9 09.9.24 6:50:43 PM09.9.24 6:50:43 PM
![](/img.php?id=1188841&img=bga.png)
10
Connections
LINE
OUT LINE
IN
LRLR
FE
C D
A B
Turntable
Cassette deck,
CD recorder, etc.
CAUTION
< Turn off the power of all the equipment before making connections.
< Read instructions of each component you intend to use with this unit.
< Be sure to insert each plug securely. To prevent hum and noise, do not bundle the connection cables with the power
cord or speaker cable.
EN_CR-H500NT_T_C.indb 10EN_CR-H500NT_T_C.indb 10 09.9.24 6:50:44 PM09.9.24 6:50:44 PM
![](/img.php?id=1188841&img=bgb.png)
ENGLISH
11
A AC Power Cord
Plug this cord into an AC wall socket.
< Unplug the power cord when you are not going to
use the unit for long periods of time.
B Wireless LAN antenna
If you can use a wireless LAN in your installation site,
the unit connects to the LAN using the wireless LAN
antenna. Stand the antenna up to use it.
C ETHERNET port
To use a wired Internet connection, connect the
Ethernet port of this unit to the Ethernet network
using a commercially available Ethernet cable.
D AUX 1 jacks
These jacks transmit an analog 2-channel audio
signal. Connect the components using RCA cables.
Make sure to connect the cables as follows:
white plug w white jack
(L: left channel)
red plug w red jack
(R:right channel)
White (L)
Red (R)
White (L)
Red (R)
If you want to use a recorder (ex. a cassette deck or a
CD recorder, etc.) with the CR-H500NT, connect the
output jacks of the recorder to the AUX 1 IN jacks
of the CR-H500NT, connect the input jacks of the
recorder to the AUX 1 OUT jacks of the CR-H500NT.
< Be sure to insert each plug securely. To prevent
noise and humming, avoid bundling the signal
interconnection cables together with the AC power
cord or speaker cables.
E PHONO jacks
Connect the turntable’s RCA pin cable to the PHONO
jacks.
Make sure to connect the cables as follows:
white plug w white jack
(L: left channel)
red plug w red jack
(R:right channel)
< Be sure to insert each plug securely. To prevent
noise and humming, avoid bundling the signal
interconnection cables together with the AC power
cord or speaker cables.
< Moving Magnet (MM) cartridges can be used for this
unit.
F SIGNAL GND
Connect the ground lead of the turntable to this
terminal.
< This is not a safety earth.
< If the turntable’s ground lead is not connected to this
terminal, hum noise may be heard.
EN_CR-H500NT_T_C.indb 11EN_CR-H500NT_T_C.indb 11 09.9.24 6:50:44 PM09.9.24 6:50:44 PM
![](/img.php?id=1188841&img=bgc.png)
12
Part names (main unit)
AB
E
CD
F G H I J L NMK
EN_CR-H500NT_T_C.indb 12EN_CR-H500NT_T_C.indb 12 09.9.24 6:50:45 PM09.9.24 6:50:45 PM
![](/img.php?id=1188841&img=bgd.png)
ENGLISH
13
A MULTI JOG
In TUNER mode, use this knob to tune in stations or
select the preset stations.
In iPod mode, use this knob to scroll up and down the
menu.
In CD/USB mode, use this knob to skip tracks/files
during playback or in the stop mode.
B Remote sensor
When operating the remote control unit, point it
towards the remote sensor.
C Display
D VOLUME
Turn this knob to adjust the volume.
< The volume level is memorized even if the unit turns
off.
E STANDBY/ON
Press this switch to turn the unit on or off.
The standby indicator turns red when the unit is in
the standby mode. When the unit is turned on, the
indicator turns blue.
F PHONES
For private listening, insert the headphones plug
into this jack, and adjust the volume by turning the
VOLUME knob.
G AUX 2 IN
Connect equipment such as a portable audio player
using a 3.5 mm stereo mini plug cable.
H USB port
Connect an iPod or external USB storage device.
I SOURCE
Use this button to select a source.
J MENU/FM MODE
Use this button to go back to previous menu of iPod.
This button is equivalent to the MENU button on your
iPod.
In FM mode, use this button to select stereo or
monaural.
K skip (.m/,/)
In CD/USB mode, use these buttons to skip tracks/files
during playback or in the stop mode of the CD or USB.
In iPod mode, use these buttons to skip songs during
playback or in pause mode of the iPod.
During playback, hold down these buttons to search
for a track/file/song.
L TUNING MODE, ENTER, open/close (L)
In FM or AM mode, use this button to select the
tuning mode.
Use this button to set the time while setting the timer
or the clock.
In iPod mode, use this button to confirm selection in
menus.
In CD mode, use this button to open and close the
disc tray.
M INFO/RDS, stop (H) (For Europe)
INFO, stop (H) (For North America)
While listening to the Internet Radio or Music Player,
use this button to change the information on the
second line of the display.
Only for Europe, use this button to select an RSD
mode in FM mode.
In USB/CD mode, use this button to stop playback.
N BAND, play/pause (y/J)
Use this button to select FM, AM.
In USB/iPod mode, use this button to start or pause
playback of the iPod or USB.
In CD mode, use this button to start or pause playback
of the CD.
EN_CR-H500NT_T_C.indb 13EN_CR-H500NT_T_C.indb 13 09.9.24 6:50:45 PM09.9.24 6:50:45 PM
![](/img.php?id=1188841&img=bge.png)
14
a
j
w
m
l
k
b
cd
o
n
ef
gh
q
v
s
u
r
t
i
p
a STANDBY/ON
Press this button to turn the unit on or standby.
b TUNER, CD, iPod/USB, AUX 1/2, PHONO
Use these buttons to select a source.
c TIME SET
Use this button to adjust the clock and to set a timer.
d TONE
Use this button to adjust bass and treble together with
scroll button (˙ or ¥).
e TIMER
Use this button to turn on or off the timer function.
f FM MODE
In FM mode, use this button to select stereo or
monaural.
g REPEAT 1/ALL
In USB/iPod mode, use this button to set the repeat
playback of the iPod or USB.
In CD mode, use this button to set the repeat playback
of the CD.
h SHUFFLE
In USB/iPod mode, use this button to start shuffle
playback of the iPod or USB.
In CD mode, use this button to start shuffle playback
of the CD.
i stop (H)
In USB mode, use this button to stop playback of the
USB.
In CD mode, use this button to stop playback of the
CD.
j PROGRAM
In USB/iPod mode, use this button to enter the
programme mode of the USB.
In CD mode, use this button to enter the programme
mode of the CD.
In programme mode, use this button to enter the
selection.
In TUNER mode, use this button to preset stations.
Part names (remote control unit)
EN_CR-H500NT_T_C.indb 14EN_CR-H500NT_T_C.indb 14 09.9.24 6:50:46 PM09.9.24 6:50:46 PM
![](/img.php?id=1188841&img=bgf.png)
ENGLISH
15
k
play/pause (y/J)
In USB/iPod mode, use this button to start or pause
playback of the iPod or USB.
In CD mode, use this button to start or pause playback
of the CD.
l MUTING
Use this button to mute the sound.
m MENU
Use this button to go back to previous menu of iPod.
This button is equivalent to the MENU button on your
iPod.
n ENTER
Use this button to set the time while setting the timer
or the clock.
o skip (.//)
In CD/USB mode, use these buttons to skip tracks/files
during playback or in the stop mode of the CD or USB.
In iPod mode, use these buttons to skip songs during
playback or in pause mode of the iPod.
p RECORD
Use this button to start recording to an USB device.
q DIMMER
Use this button to dim the display.
r SLEEP
Use this button to set sleep timer.
s INFO/RDS, stop (H) (For Europe)
INFO, stop (H) (For North America)
While listening to the Internet Radio or Music Player,
use this button to change the information on the
second line of the display.
Only for Europe, use this button to select an RSD
mode in FM mode.
In FM mode, use this button to select an RDS mode.
t DISPLAY
Use this button to change what information is
displayed during USB/iPod playback.
u CLEAR
Use this button to clear tracks/files in programme
mode.
v VOLUME
Use these buttons to adjust the volume level.
w scroll (˙/¥)
In USB/iPod mode, use these buttons to select a folder
or file of USB.
Or use these buttons to scroll menu of the iPod.
After pressing the TONE button these buttons are
used to adjust treble and bass.
EN_CR-H500NT_T_C.indb 15EN_CR-H500NT_T_C.indb 15 09.9.24 6:50:46 PM09.9.24 6:50:46 PM
![](/img.php?id=1188841&img=bg10.png)
16
Remote Control Unit
The provided remote control unit allows the unit to be
operated from a distance.
When operating the remote control unit, point it towards
the remote sensor on the front panel of the unit.
< Even if the remote control unit is operated within the
effective range, remote control operation may be
impossible if there are any obstacles between the unit
and the remote control unit.
< If the remote control unit is operated near other
appliances which generate infrared rays, or if other
remote control devices using infrared rays are used
near the unit, it may operate incorrectly.
Conversely, the other appliances may operate
incorrectly.
Battery Installation
1. Remove the battery compartment cover.
2. Insert two “AAA” dry batteries. Make sure that the
batteries are inserted with their positive “+” and
negative “_” poles positioned correctly.
3. Close the cover.
Battery Replacement
If the distance required between the remote control unit
and main unit decreases, the batteries are exhausted. In
this case replace the batteries with new ones.
< For more information about collection of batteries,
please contact your local municipality, your waste
disposal service or the point of sale where you
purchased the items.
Precautions Concerning Batteries
< Be sure to insert the batteries with positive “+” and
negative “_” polarities positioned correctly.
< Use batteries of the same type. Never use different
types of batteries together.
< Rechargeable and non-rechargeable batteries can be
used. Refer to the precautions on their labels.
< When the remote control unit is not to be used for a
long time (more than a month), remove the batteries
from the remote control unit to prevent them from
leaking.
< If the batteries leak, wipe away the liquid inside the
battery compartment and replace the batteries with
new ones.
< Do not use any other batteries not specified. Do not
mix new batteries with old ones or use different types
of batteries together.
< Do not heat or disassemble batteries and never throw
them in the fire or water.
< Do not carry or store batteries with other metallic
objects. The battery may short circuit, leak or explode.
< Never recharge a battery unless it is a verified
rechargeable type.
EN_CR-H500NT_T_C.indb 16EN_CR-H500NT_T_C.indb 16 09.9.24 6:50:47 PM09.9.24 6:50:47 PM
![](/img.php?id=1188841&img=bg11.png)
ENGLISH
17
AB
C
A How to turn the unit on or off
Press the STANDBY/ON switch to turn the unit on or
off.
When you use the system control function, set this
switch on, and turn the system on/standby using the
remote control unit.
The Standby/On indicator turns blue when the unit is
turned on.
< When you turn on the system, the source that was
selected last time will start playback automatically.
B How to select source
Every time the SOURCE button is pressed, the mode is
changed as follows:
TUNER USB/iPod PHONO
CD AUX2 AUX1
Or press the TUNER, iPod/USB, PHONO, AUX 1/2 or CD
button on the remote control unit to select the source
directly.
Basic Operation (1)
C Adjust the volume
To protect the speakers from a sudden high-volume
sound, gradually turn up the volume to the required
level with the VOLUME knob.
D Muting
To mute the sound temporarily, press the MUTING
button. To cancel muting, press the MUTING button
again or change the volume setting.
E Dimmer
Press the DIMMER button to dim the display.
Press the button again to cancel the dimmer function.
< This function will be cancelled when the unit is turned
off.
Standby/On indicator
EN_CR-H500NT_T_C.indb 17EN_CR-H500NT_T_C.indb 17 09.9.24 6:50:48 PM09.9.24 6:50:48 PM
![](/img.php?id=1188841&img=bg12.png)
18
F Listening through headphones
Insert the headphone plug into the PHONES jack,
and adjust the volume. The sound from speakers and
subwoofer will be cut off.
G How to adjust the bass and treble sound
You can change the bass and treble sound between
“-10” to “+10”.
Press the TONE button repeatedly to select BASS or
TREBLE. And then press the scroll buttons (˙/¥)
button to adjust the sound level within 5 seconds.
1 Press the STANDBY/ON button to turn the unit
on.
The Standby/On indicator turns from orange to blue.
“No disc“ will be displayed if no disc has been inserted.
2 Press SOURCE button to select “CD.”
3 Press the open/close button (L).
Standby/On indicator
Disc Playback
126
3 5
4
Basic Operation (2)
EN_CR-H500NT_T_C.indb 18EN_CR-H500NT_T_C.indb 18 09.9.24 6:50:49 PM09.9.24 6:50:49 PM
![](/img.php?id=1188841&img=bg13.png)
ENGLISH
19
4 Place a disc on the tray with the printed label
facing up.
< The disc must be loaded centrally into the disc tray. If
the disc is not correctly loaded, it may not be possible
to open the tray again once it has closed.
< Never place more than one disc on the tray.
< Do not stick labels or tapes on the disc.
< Do not use irregularly-shaped discs.
5 Press the open/close button (L) to close the tray.
< Keep fingers clear of moving tray to avoid trapping
them.
< It takes a few seconds for the unit to load a disc. No
buttons will work during loading. Wait until the total
number of the tracks/files and the total play time of
the disc are displayed.
Audio CD
The total number of the tracks and total play time of
the disc are displayed.
MP3/WMA disc
The total number of files of the disc is displayed.
CD/Stop
T016 72:00
CD/Stop
Total file 010
6 Press the play/pause button (y/J) to start
playback.
Disc playback starts from the first track/file.
Audio CD
MP3/WMA disc
< MP3/WMA files recorded out of folders are
automatically put in the “ROOT“’ folder, and playback
starts from the first file of the ROOT folder.
< If there are folders that has no MP3/WMA file, this unit
skips them.
< During playback of MP3/WMA file, “title_artist_album“
is scrolled across the display.
< The unit stops automatically when playback of all the
tracks/files has finished.
< If you load a disc, and then press the play/pause
button (y/J) (or the SHUFFLE button of the remote
control unit) without having first closed the disc tray,
the disc tray closes and playback starts.
CD/Play
T003 00:42 MP3
CD/Play
T003 00:42
current file number
current track number elapsed time of the current track
EN_CR-H500NT_T_C.indb 19EN_CR-H500NT_T_C.indb 19 09.9.24 6:50:49 PM09.9.24 6:50:49 PM
![](/img.php?id=1188841&img=bg14.png)
20
A To stop playback
Press the stop button (H) to stop playback.
To start playback again, press the play/pause button
(y/J).
Playback starts from the first track/file.
B To suspend playback temporarily (pause mode)
Press the play/pause button (y/J) during playback.
Playback stops at the current position.
To resume playback, press the play/pause button
(y/J).
C To eject the disc
When the open/close button (L) is pressed, playback
stops and the tray will open.
Afer the disc is ejected, close the tray by pressing the
open/close button (L).
< When CD is selected as the source, you can eject the
disc.
13
You can play MP3/WMA files by connecting various
external USB storage devices such as USB flash memory.
1 Press the SOURCE button repeatedly to select
“USB/iPod”.
“Not connected” will be displayed if no USB device is
connected.
2 Connect the external USB storage device to the
unit.
When an HDD device is connected to this unit, it may
take several minutes to display the number of files.
3 Press the play/pause button (y/J).
AC B
ED
USB Playback General Playback Operations
(disc/USB)
EN_CR-H500NT_T_C.indb 20EN_CR-H500NT_T_C.indb 20 09.9.24 6:50:50 PM09.9.24 6:50:50 PM
![](/img.php?id=1188841&img=bg15.png)
ENGLISH
21
D To skip to the next or a previous track/file
During playback, press the skip/scan buttons
(.m/,/) repeatedly until the desired track/
file is found. The selected track/file will be played from
the beginning.
On the remote control unit use the skip buttons
(.//).
In the stop or pause mode, press the skip/scan buttons
(.m/,/) repeatedly until the track/file you
want to listen to is found. Press the play/pause button
(y/J) to start playback the selected track/file.
< When the .button is pressed during playback,
the track/file being played will be played from the
beginning. To return to the beginning of the previous
track/file, press the .button twice.
< During programmed playback, the next or previous
track/file in the program is played.
E Search for a part of a track/file
During playback, hold down the skip/scan buttons
(.m/,/) and release it when the part you
want to listen to is found.
< In USB mode, no sound is emitted while searching.
< The unit stops when the end of the last track/file is
reached.
Folder Search
You can select a folder and a file during playback or when
stopped.
1 Press the scroll buttons (˙/¥) to select a folder.
2 Press the ENTER button.
3 If you want to select a file, press the scroll
buttons (˙/¥).
< The selection moves within the folder.
4 Press the ENTER button.
Playback starts from the selected file.
EN_CR-H500NT_T_C.indb 21EN_CR-H500NT_T_C.indb 21 09.9.24 6:50:51 PM09.9.24 6:50:51 PM
![](/img.php?id=1188841&img=bg16.png)
22
Up to 32 tracks/files can be programmed in the desired
order.
1 Press the PROGRAM button in the stop mode.
When CD is selected
P-00 T000
T016 72:00
When USB is selected
P00 T0000
Total File 0130
2 Press the scroll buttons (˙/¥) to select a track/
file.
When CD is selected
P-01 T002
T016 72:00
When USB is selected
P01 T0012
Total File 0130
Programmed Playback
3 Within 5 seconds, press the PROGRAM button.
When CD is selected
P-01 T012
T016 72:00
When USB is selected
P01 T0012
Total File 0130
< Repeat steps 2 and 3 to programme more tracks/
files.
< If you made a mistake, press the CLEAR button.
The last programmed number will be deleted.
< Up to 32 tracks/files can be programmed. If you
attempt to programme more than 32 tracks/files, “P-
FULL (Programme is full)” is displayed and no more
tracks/files can be programmed.
4 When programming has finished, press the
play/pause button (y/J) to start programmed
playback.
When the playback of all the programmed tracks/files
has finished, or if the stop button (H) or the STANDBY/
ON button is pressed, the programme mode will be
cancelled.
< If the unit is disconnected from the power supply, the
programmed contents will be erased.
EN_CR-H500NT_T_C.indb 22EN_CR-H500NT_T_C.indb 22 09.9.24 6:50:52 PM09.9.24 6:50:52 PM
![](/img.php?id=1188841&img=bg17.png)
ENGLISH
23
To check the programmed order
In the stop mode, press the PROGRAM button
repeatedly. The track/file number and programme
number will be shown on the display.
To change or add a track/file to the
programme
In the stop mode, press PROGRAM button repeatedly
until the program number for which you want to
change the track/file appears on the display. Then
select a track/file using the scroll buttons (5/b). The
previous track/file is replaced with the newly selected
one.
If you want to add a track/file to the end of the
programme, press the PROGRAM button repeatedly
until “P-END” briefly appears on the display. Then
select a track/file using the scroll buttons (5/b). The
track/file is added to the programme.
To delete a track/file from the
programme
In the stop mode, press the PROGRAM button
repeatedly until the programme number appears
to be deleted on the display, then press the CLEAR
button. The selected track/file is deleted from the
programme.
To clear the programme
1. In the stop mode, press the PROGRAM button.
2. Hold down the CLEAR button for more than 4
seconds.
< In the following cases, the programmed contents will
also be cleared:
pressing the STANDBY/ON button
opening the disc tray
disconnecting the AC power cord
EN_CR-H500NT_T_C.indb 23EN_CR-H500NT_T_C.indb 23 09.9.24 6:50:53 PM09.9.24 6:50:53 PM
![](/img.php?id=1188841&img=bg18.png)
24
When the SHUFFLE button is pressed, the tracks/files on
the disc or USB device will be played randomly.
When CD is selected
CD/Random
T003 00:07
When USB is selected
USB/Random
T0003 00:07 WMA
< If you press the / button during shuffle playback,
next track/file will be randomly selected and played. If
you press the .button, the currently played track/
file will be played from the beginning. A track/file
cannot be replayed during shuffle playback.
< To cancel shuffle playback, press the SHUFFLE button.
< To stop shuffle playback, press the stop button (H).
Shuffle Playback
Every time the REPEAT 1/ALL button is pressed, the mode
is changed as follows:
< When the stop button (H) is pressed the repeat mode
is cancelled.
Repeat One Track/File (RPT 1)
The track/file being played will be played repeatedly.
If you select another track/file in “RPT 1” mode, the
track/file you selected will be played repeatedly.
If you select “RPT 1” mode in the stop mode and
select a track/file, the selected track/file will be played
repeatedly.
Repeat Folder (RPT Folder) (MP3/WMA files only)
All the files in the folder will be played repeatedly.
If you select another folder in “RPT Folder” mode, the
files in the folder will be played repeatedly.
< You can not select “RPT Folder” mode in the stop
mode.
Repeat All (RPT ALL)
All the tracks/files will be played repeatedly.
< In the program mode, the programmed contents are
played repeatedly.
Repeat Playback
RPT 1 (repeat one track/file)
RPT Folder (repeat folder)
(Only MP3/WMA files)
RPT ALL (repeat all the tracks/files)
(Repeat Off)
EN_CR-H500NT_T_C.indb 24EN_CR-H500NT_T_C.indb 24 09.9.24 6:50:54 PM09.9.24 6:50:54 PM
![](/img.php?id=1188841&img=bg19.png)
ENGLISH
25
During playback, press the DISPLAY button repeatedly to
change the information on the display.
Audio CD:
Display changes as follows:
MP3/WMA files:
Default display (scrolling):
Title - Artist Name - Album Name
Display changes as follows:
Before Recording
CAUTION
< Do not disconnect the USB storage device during
recording.
Do not disconnect the power cord during recording.
It may cause damage to the products.
< Adjust the volume of the external audio source to
suitable level before recording. If not, the recording
quality becomes poor.
Note
< The recorded files are saved in the AUDIO folder.
< The FILE NAME is fixed up automatically in regular
sequence like “Audio001.MP3”, “Audio002.MP3”, …….
For Example:
If there are “Audio004.MP3” and “Audio009.MP3” files
in the AUDIO folder, and you make a recording, a new
file will be “Audio010.MP3”.
< Before recording check the remaining capacity of the
USB storage device using your PC.
You cannot check the remaining memory capacity
with this unit.
< This unit can record up to 2000 files to the USB device.
< The maximum time of the recorded file is 90 minutes
and new file is created when the time exceeds 90
minutes. When a new file is created, recording will
pause for a few second.
< You cannot record music from an iPod.
< A track recorded onto a USB storage device is
converted to a MP3 file at a bit rate of 128 kbps.
Display
Default display (scrolling)
File Name
Title
Artist Name
Album Name
Current file number and elapsed time
CD/Play
T003 00:42
current track number and elapsed time of the current
track
CD/Play
T003 -03:02
current track number and remaining time of the current
track
EN_CR-H500NT_T_C.indb 25EN_CR-H500NT_T_C.indb 25 09.9.24 6:50:54 PM09.9.24 6:50:54 PM
![](/img.php?id=1188841&img=bg1a.png)
26
Recording to USB
You can record a source of radio broadcast and external
device to the external USB storage device as MP3 files.
1 Connect the external USB storage device to the
USB port of the CR-H500NT.
2 Select a source to be recorded.
< iPod/USB can not be selected.
3 Press the RECORD button.
Recording starts.
< You cannot record to an external USB storage device if
there is no free space or the device is locked.
To stop recording
Press the stop button (H).
Deleting a file from USB
You can delete a file on the external USB storage device.
1 In the stop mode, press the scroll buttons (˙/¥)
to select a folder.
2 Press the ENTER button.
3 Press the scroll buttons (˙/¥) to select the file
which you want to delete from the USB device.
4 Hold down the CLEAR button for more than 4
seconds.
“Delete?” is displayed.
EN_CR-H500NT_T_C.indb 26EN_CR-H500NT_T_C.indb 26 09.9.24 6:50:55 PM09.9.24 6:50:55 PM
![](/img.php?id=1188841&img=bg1b.png)
ENGLISH
27
1 Press the SOURCE button repeatedly to select
“USB/iPod”.
2 Connect your iPod using the USB cable supplied
with iPod.
The iPod automatically turns on and starts playback
from the iPod music list.
When the iPod is connected while the CR-H500NT is
set to other source, the iPod will turn on and enter the
pause mode.
< The iPod battery will be fully recharged when the iPod
is docked and the CR-H500NT is on.
< When the iPod is connected to the CR-H500NT, the
headphones jack of the iPod can not output the
sound.
If you want to listen to the sound from your
headphones, connect your headphones to the CR-
H500NT’s PHONES jack.
Listening to iPod (1)
5 Within 3 seconds, press the CLEAR button.
< The delete mode will be cancelled if you do not press
the CLEAR button within 3 seconds.
EN_CR-H500NT_T_C.indb 27EN_CR-H500NT_T_C.indb 27 09.9.24 6:50:56 PM09.9.24 6:50:56 PM
![](/img.php?id=1188841&img=bg1c.png)
28
To pause playback
During playback, press the play/pause button
(G/J) to pause playback. Playback stops at the
current position.
To resume playback, press the play/pause button
(G/J) again.
To skip to the next or a previous song
During playback or in pause mode, press the skip
buttons (.//) repeatedly until the desired song
is found.
< When the . button is pressed during playback, the
song being played will be played from the beginning.
If you want to play the previous songs, press the .
button twice or more.
Search for a part of a song
During playback, hold down the skip buttons
(.//) and release it when the part you want to
listen to is found.
To go back to the previous menu
Press the MENU button to go back to the previous
menu.
This button is equivalent to the MENU button on your
iPod.
Select the menu item
Press the scroll buttons (˙/¥) of the remote control
unit to scroll to the menu item you want, and then
press the ENTER button.
Listening to iPod (2)
EN_CR-H500NT_T_C.indb 28EN_CR-H500NT_T_C.indb 28 09.9.24 6:50:56 PM09.9.24 6:50:56 PM
![](/img.php?id=1188841&img=bg1d.png)
ENGLISH
29
Repeat playback
Every time the REPEAT 1/ALL button is pressed, the
mode is changed as follows:
Shuffle playback
During playback, press the SHUFFLE button to change
the shuffle mode.
RDM o
RDM Songs
RDM Album
When you select “RDM Songs”, the iPod shuffles songs
within the list you choose to play.
When you select “RDM Album”, the iPod plays all
the songs on an album in order, and then randomly
selects another album in the list and plays through it
in order.
Changing the display mode
You can select the iPod screen or CR-H500NT display to
show the menu.
When the iPod is connected, hold down the MENU
button for more than 4 seconds to select which
display to be used.
Direct Mode (default)
Select this to use the screen of the iPod.
Menu appears on the screen of the iPod.
The display of the CR-H500NT constantly shows
“Direct Mode”.
Extended mode
Select this to use the display of the CR-H500NT.
Information on the songs is displayed on the display of
the CR-H500NT.
< Song/Album/Artist names of songs should be
alphanumeric characters. This unit cannot display
symbols and full-size or double-byte characters (such
as Japanese, Chinese, etc.) correctly.
Play (normal playback)
RPT ALL (repeat all the songs in the list)
RPT 1 (repeat 1 song)
EN_CR-H500NT_T_C.indb 29EN_CR-H500NT_T_C.indb 29 09.9.24 6:50:57 PM09.9.24 6:50:57 PM
![](/img.php?id=1188841&img=bg1e.png)
30
Listening to FM/AM
1 Press the SOURCE button repeatedly to select
TUNER mode.
2 Select FM or AM by pressing the BAND button
repeatedly.
3 Select the desired tuning mode.
Each time the TUNING MODE button is pressed, the
tuning mode changes as follows:
Manual Tune
Auto Tune
Preset Tune
123
4
4 Select the station you want to listen to.
Manual tuning mode
Turn the MULTI JOG knob until the station you want to
listen to is found.
On the remote control, press the scroll buttons (˙/¥)
repeatedly.
The frequency changes by a fixed step (FM: 50 kHz
steps, AM: 9 kHz steps).
Auto tuning mode
Turn the MULTI JOG knob to start auto tuning.
When a station is found, the unit tunes in the station
automatically. Repeat this step until the station you
want to listen to is found.
< Press the ENTER button to stop the auto tuning.
Preset tuning mode
Turn the MULTI JOG knob to select a preset channel.
On the remote control, press the skip buttons
(.//) repeatedly.
The selected preset channel is tuned in.
EN_CR-H500NT_T_C.indb 30EN_CR-H500NT_T_C.indb 30 09.9.24 6:50:57 PM09.9.24 6:50:57 PM
![](/img.php?id=1188841&img=bg1f.png)
ENGLISH
31
FM Mode
You can select between Stereo and Mono by pressing
the FM MODE button when a stereo FM program is
tuned in.
Stereo:
FM stereo broadcasts are received in stereo and “ST” is
displayed.
When a broadcast signal cannot be tuned in, the
sound is muted.
FM/ST 10:00
108.00MHz
Mono:
Select this mode when the signal is weak. Reception
will be forced monaural, reducing unwanted noise.
When you try to listen to another broadcast but its
signal cannot be tuned in, the FM mode changes to
Stereo and the sound is muted.
EN_CR-H500NT_T_C.indb 31EN_CR-H500NT_T_C.indb 31 09.9.24 6:50:58 PM09.9.24 6:50:58 PM
![](/img.php?id=1188841&img=bg20.png)
32
Presetting Automatically (FM/AM)
1 Select FM or AM by pressing the TUNER button
repeatedly.
2 Hold down the PROGRAM button for more than
3 seconds.
Up to 30 of the best received stations in your area will
be stored automatically.
Presetting manually (AM/FM)
You can store up to 30 FM, 30 AM.
1 Select AM or FM by pressing the TUNER button
repeatedly.
2 Tune in the station you want to store.
See the previous page for the procedure of tuning.
3 Press the PROGRAM button.
FM
10:00
CH__ 108.00MHz
4 Within 4 seconds, select the preset number for
this station.
Press the scroll buttons (5/b).
FM
10:00
CH12 108.00MHz
Preset Tuning
5 Within 4 seconds, press the PROGRAM button.
The station is stored.
< To store more stations, repeat steps 2 to 5 .
< If you do not press the PROGRAM button within 4
seconds after selecting the preset number, presetting
will be cancelled.
EN_CR-H500NT_T_C.indb 32EN_CR-H500NT_T_C.indb 32 09.9.24 6:50:58 PM09.9.24 6:50:58 PM
![](/img.php?id=1188841&img=bg21.png)
ENGLISH
33
The Radio Data System (RDS) is a broadcasting service
which allows stations to send additional information
along with the regular radio programme signal.
RDS works on the FM waveband in Europe only.
1 Tune in an FM station (see page 30).
2 Press the RDS button.
Each time the RDS button is pressed, the RDS mode is
changed as follows:
PROGRAM SERVICE
When you select “PROGRAM SERVICE”, “PROGRAM
SERVICE” will blink for about 3 seconds and then the
programme service name or a station’s name will be
displayed. If there is no programme service data, the
frequency will be displayed.
PROGRAM TYPE
When you select “PROGRAM TYPE”, “PROGRAM
TYPE” will blink for about 3 seconds and then the
programme type will be displayed.
CLOCK TIME
Displays the information about times provided from
the station.
When you select “CLOCK TIME”, “RDS CLOCK TIME” will
blink for about 3 seconds and then the clock time will
be displayed.
RADIO TEXT
When you select “RADIO TEXT”, “RDS RADIO TEXT”
will blink for about 3 seconds and then the news
of stations composed of up to 64 symbols will be
displayed.
If there is no radio text data, RDS mode will be
automatically switched to PROGRAM SERVICE mode.
RDS
TRAFFIC ANNOUNCE
When you select “TRAFFIC ANNOUNCE”, “TRAFFIC
ANNOUNCE” will blink for 3 seconds and then the unit
searches for a traffic announcement.
< When a traffic programme is found, the TRAFFIC
ANNOUNCE mode is switched to PROGRAM SERVICE
mode.
If the station currently selected is transmitting a traffic
programme signal, the RDS mode will be switched
to PROGRAM SERVICE mode without searching for a
traffic programme.
The clock setting of this unit is automatically adjusted
according to the CLOCK TIME (CT) data.
If you tune in an RDS station broadcasting incorrect
CT data, the clock might be wrongly adjusted, and
that may eventually affect the timer operation.
When you do not want the clock of this unit to be
set according to the CT data, turn off the auto clock
adjustment.
< No matter which RDS mode is selected, the unit
receives CT data and adjusts the clock.
To turn off the auto clock adjustment, hold
down the RDS button for more than 8 seconds.
< To turn on the auto clock adjustment again, hold
down the RDS button for more than 8 seconds.
< When the auto clock adjustment is turned off,
CLOCK TIME is not displayed.
EN_CR-H500NT_T_C.indb 33EN_CR-H500NT_T_C.indb 33 09.9.24 6:50:59 PM09.9.24 6:50:59 PM
![](/img.php?id=1188841&img=bg22.png)
34
PTY Search
1
4
2
3
3
You can search for stations by programme type.
1 Select FM by pressing the BAND button
repeatedly.
2 Hold down the RDS button for more than 3
seconds.
3 Select the desired programme type (PTY).
Turn the MULTI JOG knob to select an item, and then
press the ENTER button.
Select your desired one from among 31 kinds of PTY
programmes.
The programme type will blink.
4 Turn the MULTI JOG knob within 3 seconds to
start searching.
< When the broadcast whose programme type you have
selected is found, searching stops and the programme
type will be displayed.
< If a broadcast of the selected programme type is not
found during PTY Search, it will stop at the very first
frequency.
< To stop searching, press the RDS button.
EN_CR-H500NT_T_C.indb 34EN_CR-H500NT_T_C.indb 34 09.9.24 6:50:59 PM09.9.24 6:50:59 PM
![](/img.php?id=1188841&img=bg23.png)
ENGLISH
35
News:
brief announcements, events, public opinion, reports,
actual situations.
Current Affairs:
a kind of suggestion including practical
announcements other than news, documents,
discussion, analysis and so on.
Information:
daily information or reference such as weather forecast,
consumer guide, medical assistance and so on.
Sport:
sports related programmes.
Education:
educational and cultural information.
Drama:
all kinds of radio concert and serial drama.
Cultures:
all aspects of national or local culture including
religious events, philosophy, social science, language,
theatre, and so on.
Science:
programmes on natural science and technology.
Varied Speech:
popular programmes such as quiz, entertainment,
private interview, comedy, satire and so on.
Pop Music:
programme on commercial, practical and popular
songs, and sale volume of discs, etc.
Rock Music:
practical modern music generally composed and
played by young musicians.
Easy Listening:
popular music usually lasting for less than 5 minutes.
Light Classics M:
classical music, instrumental music, chorus, and light
music favoured by non-professionals.
Serious Classics:
orchestra including great operas, symphony, chamber
music and so on.
Other Music:
other music styles (Rhythm & Blues, Reggae, etc.).
Weather & Meter:
weather reports, forecast.
Finance:
financial reports, commerce, trading.
Children’s Progs:
children’s programmes.
Social Affairs:
social affairs.
Religion:
religious programmes.
Phone In:
programme in which the public expresses its view by
phone.
Travel & Touring:
travel reports.
Leisure & Hobby:
programmes concerning recreational activities.
Jazz Music:
jazz music.
Country Music:
country music.
National Music:
national music.
Oldies Music:
music from the so-called golden age of popular music.
Folk Music:
folk music.
Documentary:
documentaries.
Alarm Test
Alarm-Alarm!:
a programme notifying an emergency or a natural
disaster.
EN_CR-H500NT_T_C.indb 35EN_CR-H500NT_T_C.indb 35 09.9.24 6:51:00 PM09.9.24 6:51:00 PM
![](/img.php?id=1188841&img=bg24.png)
36
Internet Radio Initial Setup
When you use the internet radio function for the first
time, the unit starts an initial setup procedure to connect
to the Internet.
1 Select “Internet radio” by pressing the BAND
button repeatedly.
Initial setup wizard starts.
2 Select your country/area.
Turn the MULTI JOG knob to select the item, and then
press the ENTER button.
›Most of Europe
USA
< To go back to the previous screen, press the BACK
button.
3 Select a network name you want to use.
Turn the MULTI JOG knob to select the item, and then
press the ENTER button.
›005AD904JM2
[Rescan]
< To use a wired Internet connection, select “[Wired]”.
4 Enter the correct password for the network if
required.
< See “How to input characters” below.
Now the unit starts to connect to the Internet.
When connection is established successfully, the
internet radio menu is displayed. See the next page to
select a station.
< If you have a problem connecting to the Internet, see
page 53.
How to input characters
1. Turn the MULTI JOG knob to select a set of
characters.
2. Press the BACK button and the FWD button to
select the character you want to input.
3. Press the ENTER button to input the selected
letter.
Repeat steps 1 to 3 to input next characters.
<: Deletes the last character.
E: Enters your input.
C: Cancels the operation and goes back to the
previous screen.
Characters you can input
0123456789
ABCDEFGHIJKLMNOPQRSTUVWXYZ
abcdefghijklmnopqrstuvwxyz
(space)!”#¤%&’()*+,-./:;<=>?@[\]–_||`{|}¯
1
23
Key: Ge
0123456789<EC
BACK FWD
ENTER
MULTI JOG
EN_CR-H500NT_T_C.indb 36EN_CR-H500NT_T_C.indb 36 09.9.24 6:51:00 PM09.9.24 6:51:00 PM
![](/img.php?id=1188841&img=bg25.png)
ENGLISH
37
Listening to an internet radio station/
a podcast
1 Select “Internet radio” by pressing the BAND
button repeatedly.
2 Open the internet radio menu.
Press the MENU button.
The internet radio menu appears.
3 Select “Station list”.
Turn the MULTI JOG knob to select the item, and then
press the ENTER button.
< To go back to the previous screen, press the BACK
button.
Listening to Internet Radio (1)
›Last listened
Station list
›My Favourites
Stations
4 Select “Stations” for internet radio stations, or
“Podcasts” for Podcasts.
Turn the MULTI JOG knob to select the item, and then
press the ENTER button.
A list of search methods appears.
5 Select a search method.
Turn the MULTI JOG knob to select the item, and then
press the ENTER button.
Location:
Search by the location of the broadcaster.
Genre:
Search by the genre of music played on the station/
Podcast.
Search stations:
Search by the station’s name.
Search podcasts:
Search by the Podcast’s name.
Popular stations:
Select from a list of popular stations.
New stations:
Select from a list of recently added stations.
›Location
Genre
1
3 3 44 55 66 7 3 2
35 6 35 6 7
44
EN_CR-H500NT_T_C.indb 37EN_CR-H500NT_T_C.indb 37 09.9.24 6:51:01 PM09.9.24 6:51:01 PM
![](/img.php?id=1188841&img=bg26.png)
38
6 If you have selected “Location”, “Genre” or
“Search stations” in step 5, search for the
channel you want.
Turn the MULTI JOG knob to select the item, and then
press the ENTER button.
< For the operations of inputting characters, see “How
to input characters” on page 36.
A list of stations/Podcasts is displayed.
7 Select a station or a Podcast you want to listen
to.
Turn the MULTI JOG knob to select the item, and then
press the ENTER button.
Now you can listen to the station/Podcast.
Business News
›Celtic
Celtic Songs & D
Buffering
Celtic Songs & D
Opening...
Celtic Songs & D
Playing
Finding stations/Podcasts
The internet radio menu contains various ways of
finding stations and Podcasts.
Last listened
You can select the station/Podcast from the ones you
listened to recently.
Station list
My favourites
List of stations/Podcast you stored as favourite is
displayed. Select a station/Podcast you want to listen
to. Favourites are stored on the internet radio portal.
See page 39.
Stations
List of internet radio stations is displayed.
Podcasts
List of Podcasts is displayed.
My Added Stations
Even though the station list contains thousands of
stations, you may want to listen to stations not listed.
You can add your own stations via the internet radio
portal. See page 40.
Listening to Internet Radio (2)
EN_CR-H500NT_T_C.indb 38EN_CR-H500NT_T_C.indb 38 09.9.24 6:51:02 PM09.9.24 6:51:02 PM
![](/img.php?id=1188841&img=bg27.png)
ENGLISH
39
Changing the displayed information
Each time the INFO button is pressed, information on
the second line of the display changes.
< The types of information displayed may vary
depending on the stations/Podcasts.
Playing
Signal strength
(for wireless LAN)
Format
Reliability
Description
Genre
Location
Playing
Signal strength
(for wireless LAN)
URL
Description
Language
City
State
Country
Bookmark
Storing the current station/Podcast as
favourite
Press and hold the PROGRAM button until “Favourite
Added” is displayed.
< Your favourite stations can be easily accessed from
“My favourites” in “Station list”.
< You can also add to your favourite stations using the
internet radio portal. (See “Radio Portal” on the next
page.)
Internet radio: Podcast:
EN_CR-H500NT_T_C.indb 39EN_CR-H500NT_T_C.indb 39 09.9.24 6:51:02 PM09.9.24 6:51:02 PM
![](/img.php?id=1188841&img=bg28.png)
40
Radio Portal
Internet radio portal
Access the radio portal on the Internet using your
computer to fully enjoy the internet radio function of this
unit.
< You can create a list of your favourite stations/
Podcasts on the portal. This list can be viewed from
your unit, making it easier for you to find your usual
programmes.
You can see the list of your favourite stations in the
internet radio menu as follows:
Station list w My favourites
< If the station/Podcast you want to listen to is not in the
channel list, you can create your own list.
You can see the list of your added stations in the
internet radio menu as follows:
Station list w My Added Stations
Accessing the radio portal
1 Open your Internet browser and access
http://www.wifiradio-frontier.com.
2 Click on the “Register” link to start registration.
3 Input your own access code and log in.
Checking the “access code” of your
unit
Each unit of CR-H500NT has its own “access code”. This
code is required to log in the internet radio portal.
1 Select “Internet radio” by pressing the BAND
button repeatedly.
2 Open the internet radio menu.
Press the MENU button.
Access code
SGPD7DM
3 Select “Station list”, “Help”, and then “Get access
code”.
Turn the MULTI JOG knob to select the item, and then
press the ENTER button.
Repeat this operation until the menu you want
appears.
The access code of your unit is displayed.
EN_CR-H500NT_T_C.indb 40EN_CR-H500NT_T_C.indb 40 09.9.24 6:51:03 PM09.9.24 6:51:03 PM
![](/img.php?id=1188841&img=bg29.png)
ENGLISH
41
Setting up Music Player (1)
About the Music Player function
Using the Music Player function, you can play back the
music files in your computers through the LAN.
There are two ways of connecting to the computer:
using media sharing and using file sharing.
Media sharing
Media sharing allows this unit to play back a shared
media library on the computer, as well as browsing
the tracks using tag items such as artist names, genres
and album names.
You need a PC running on Windows XP or Windows
Vista, and Windows Media Player 10 or later on it.
File sharing
To use file sharing method, you need to configure your
music files open to access, so that other computers or
CR-H500NT can read those files.
This method is available both on Windows and on
Mac.
Preparations for Shared Media
1 Connect your computer to the LAN.
2 Connect the CR-H500NT to the LAN. (page 10)
< If you have a problem connecting to the LAN, see
page 48.
3 If the files you want to share are not yet added
to the media library of Windows Media Player,
add them to the media library.
< Refer to the manual of Windows Media Player for
details.
4 On Windows Media Player, open “Library”, then
“Media sharing”.
Media Sharing window opens.
5 Activate “Share my media to:”.
The CR-H500NT appears in the device list as “Unknown
Device”.
6 Select the “Unknown Device” and click “Allow”.
The CR-H500NT can now access to the shared library.
7 Click on “Settings...”, and configure detailed
sharing settings.
< To listen to music files regardless of their rating, set
“Star ratings” to “All ratings”.
< Ensure that “Music” is checked under the “Media types”
setting.
For the procedure of playback, see “Media Sharing”.
(page 45)
EN_CR-H500NT_T_C.indb 41EN_CR-H500NT_T_C.indb 41 09.9.24 6:51:03 PM09.9.24 6:51:03 PM
![](/img.php?id=1188841&img=bg2a.png)
42
Preparations for Shared Folders
(Windows Vista)
1 Check the name of the Domain or the
“Workgroup” your computer belongs to.
To enable Shared Folders, your computer needs to be
a member of a Domain or a “Workgroup”.
Usually, your computer belongs to a “Workgroup”
by default. To see the name of the Domain or the
“Workgroup” your computer belongs to, check the PC
setting as follows:
Control Panel w System and Maintenance w System
2 Check the user account name and its password.
To access the computer from CR-H500NT, you need
the user account name and the password of the
computer.
3 Open “Control Panel”, “Network and Internet”,
then “Network and Sharing Center”.
4 Set “Public folder sharing” to “On (read only)”.
5 Set “Password protected sharing” to “On”.
Preparations for Shared Folders
(Windows XP)
1 Check the name of the Domain or the
“Workgroup” your computer belongs to.
To enable Shared Folders, your computer needs to be
a member of a Domain or a “Workgroup”.
Usually, your computer belongs to a “Workgroup”
by default. To see the name of the Domain or the
“Workgroup” your computer belongs to, check the PC
setting as follows:
Control Panel w System w Computer Name
2 Check the user account name and its password.
To access the computer from CR-H500NT, you need
the user account name and the password of the
computer.
3 Right-click on the folder which contains the
music files you want to share, and select
“Sharing and Security”.
4 In the “Sharing” tab, check “Share this folder”.
Setting up Music Player (2)
EN_CR-H500NT_T_C.indb 42EN_CR-H500NT_T_C.indb 42 09.9.24 6:51:04 PM09.9.24 6:51:04 PM
![](/img.php?id=1188841&img=bg2b.png)
ENGLISH
43
6 Copy the music files you want to enjoy on CR-
H500NT into the “Public Music” folder in the
“Public” folder.
Preparations for Shared Folders
(Mac OSX 10.2.1 to 10.4.11)
1 Check the user account name and its password.
To access the computer from CR-H500NT, you need
the user account name and the password of the
computer.
2 In “System Preferences”, open “Sharing”.
3 Activate “Personal File Sharing” and “Windows
Sharing”.
4 Open “Directory access” in the “Utitlities” folder
in “Applications”, and check that the following
items are enabled in the “Services” tab.
< AppleTalk
< LDAPv3
< SLP
< SMB/CIFS
5 Select “SMB/CIFS”, and click on “Configure...”,
and select an appropriate workgroup.
EN_CR-H500NT_T_C.indb 43EN_CR-H500NT_T_C.indb 43 09.9.24 6:51:05 PM09.9.24 6:51:05 PM
![](/img.php?id=1188841&img=bg2c.png)
44
Preparations for Shared Folders
(Mac OSX 10.5.0 or higher)
1 Check the user account name and its password.
To access the computer from CR-H500NT, you need
the user account name and the password of the
computer.
2 In “System Preferences”, open “Sharing”.
3 Enable “File Sharing”, and then select “Read
Only” for “Everyone” in “Users” window. Then
Click “Options...”.
4 Activate “Share files and folders using AFP” and
“Share files and folders using SMB”. In the same
window, activate “On” for the account you want
to use for file sharing.
Setting up Music Player (3)
Preparation on the unit for Shared
Folders
(both Windows and Macintosh)
1 Connect your CR-H500NT to the LAN. (page 10)
< If you have a problem connecting to the LAN, see
page 48.
2 Enter the user name and the password required
to access the computer.
Enter the user name and the password following the
menu as follows:
Setup w System setup w Internet setup w PC
Setup w User Name / Password
For the procedure of playback, see “File Sharing”.
(page 46)
EN_CR-H500NT_T_C.indb 44EN_CR-H500NT_T_C.indb 44 09.9.24 6:51:06 PM09.9.24 6:51:06 PM
![](/img.php?id=1188841&img=bg2d.png)
ENGLISH
45
1 Select “Internet radio” by pressing the BAND
button repeatedly.
2 Open the internet radio menu.
Press the MENU button.
The internet radio menu appears.
3 Select “Main Menu”, then “Music Player”.
Turn the MULTI JOG knob to select the item, and then
press the ENTER button.
The Music Player function is activated.
1
345 6345 6 7 32
35 635 6 7
›Last listened
Station list
Music Playback
Mode
Media Sharing < If you turn off the unit or change the source while
playing back the Music Player, “Music Playback Mode”
will be cancelled.
4 Open the Music Player menu.
Press the MENU button.
The Music Player menu appears.
5 Select “Browse”, then “Shared Media”.
Turn the MULTI JOG knob to select the item, and then
press the ENTER button.
A list of shared media library appears.
< To go back to the previous screen, press the BACK
button.
›Browse
Main menu
Listening to Music Player (1)
EN_CR-H500NT_T_C.indb 45EN_CR-H500NT_T_C.indb 45 09.9.24 6:51:07 PM09.9.24 6:51:07 PM
![](/img.php?id=1188841&img=bg2e.png)
46
1 Select “Internet radio” by pressing the BAND
button repeatedly.
2 Open the internet radio menu.
Press the MENU button.
The internet radio menu appears.
3 Select “Main Menu”, then “Music Player”.
Turn the MULTI JOG knob to select the item, and then
press the ENTER button.
The Music Player function is activated.
< If you turn off the unit or change the source while
playing back the Music Player, “Music Playback Mode”
will be cancelled.
1
24
35 6 7
35 6 7
›Last listened
Station list
Music Playback
Mode
Listening to Music Player (2)
File Sharing
6 Select a media library you want to listen to.
Turn the MULTI JOG knob to select the item, and then
press the ENTER button.
The music index of the selected media library appears.
7 Select the track you want to listen to.
Turn the MULTI JOG knob to select the item, and then
press the ENTER button.
Playback of the selected track starts.
›Genre
All Artists
EN_CR-H500NT_T_C.indb 46EN_CR-H500NT_T_C.indb 46 09.9.24 6:51:08 PM09.9.24 6:51:08 PM
![](/img.php?id=1188841&img=bg2f.png)
ENGLISH
47
4 Open the Music Player menu.
Press the MENU button.
The Music Player menu appears.
5 Select “Browse”, then “Shared folder”.
Turn the MULTI JOG knob to select the item, and then
press the ENTER button.
The names of connected Domains and Workgroups
appear.
< To go back to the previous screen, press the BACK
button.
›Browse
Main menu
6 Select the Domain or the Workgroup your
computer belongs to, then select your
computer.
Turn the MULTI JOG knob to select the item, and then
press the ENTER button.
A list of shared folders on the selected computer
appears.
7 Select the file you want to listen to.
Turn the MULTI JOG knob to select the item, and then
press the ENTER button.
Playback of the selected track starts.
EN_CR-H500NT_T_C.indb 47EN_CR-H500NT_T_C.indb 47 09.9.24 6:51:08 PM09.9.24 6:51:08 PM
![](/img.php?id=1188841&img=bg30.png)
48
Network Configuration
Software update
The software of the unit can be updated via the Internet
connection, so that you are able to use the latest features
of the unit. Regularly check for updates.
1 Select “Internet radio” by pressing the BAND
button repeatedly.
2 Open the internet radio menu.
Press the MENU button.
3 Select “Main Menu”, “System setup”, and then
“Software update”.
Turn the MULTI JOG knob to select the item, and then
press the ENTER button.
Repeat this operation until the menu you want
appears.
If an update is available, the unit automatically starts
download and installation of the new software.
< You can check the current software version of your
unit using the internet radio menu. Follow the menu
items as follows:
“Main Menu” w “Info” w “SW version”
Internet setup
›Software update
›Last listened
Station list
Performing the setup wizard
If you have moved or modified your network
environment, or if you have a problem connecting
to the Internet, perform the initial setup wizard to
establish the Internet connection again.
Follow the menu items as follows:
”Main Menu” w ”System setup” w ”Internet setup”
w ”Wizard”
Setting the wireless network
If you are using a wireless network for the unit and you
have moved to a new location, change the area setting
so that network connection is established properly.
Follow the menu items as follows:
”Main Menu” w ”System setup” w ”Internet setup”
w ”Wlan region”
Manual Internet setup
You can check and modify detailed settings of the
Internet connection.
Follow the menu items as follows:
To check the current network settings
”Main Menu” w ”System setup” w ”Internet setup”
w ”View settings”
To configure settings
”Main Menu” w ”System setup” w ”Internet setup”
w ”Manual settings”
To delete a network profile
”Main Menu” w ”System setup” w ”Internet setup”
w ”Network profile”
To check the Radio ID of your unit
The Radio ID may be required when you contact our
customer support.
Follow the menu items as follows:
”Main Menu” w ”Info” w ”Radio ID”
EN_CR-H500NT_T_C.indb 48EN_CR-H500NT_T_C.indb 48 09.9.24 6:51:09 PM09.9.24 6:51:09 PM
![](/img.php?id=1188841&img=bg31.png)
ENGLISH
49
When you adjust the clock manually, follow the following
steps.
< The clock setting of this unit is automatically adjusted
according to the CLOCK TIME data of an RDS
broadcasting.
1 Press the TIME SET button.
Each time the TIME SET button is pressed, the mode is
changed as follows.
Current Time
On Time
Off Time
Source select
< For Europe, the unit uses the 24-hour “military” clock.
For North America, the unit uses the 12-hour clock.
< When no action is taken for 1 minute, the time adjust
mode will be cancelled.
< Press the stop button (H) to cancel the time setting.
2 Press the scroll buttons (˙/¥) to set the current
hour.
Setting the Clock
3 Press the ENTER button.
The “minute” value blinks.
4 Press the scroll buttons (˙/¥) to set the current
minute.
5 Press the ENTER button.
The clock starts from 00 seconds.
< The clock setting will not be saved when the AC
power cord is pulled out.
EN_CR-H500NT_T_C.indb 49EN_CR-H500NT_T_C.indb 49 09.9.24 6:51:09 PM09.9.24 6:51:09 PM
![](/img.php?id=1188841&img=bg32.png)
50
Setting the Timer
< Adjust the clock before setting the timer.
< Select “Direct mode” before using the iPod for the
timer; otherwise, the iPod will not be played back
when the On time is reached. See page 29.
< When no action is taken for 1 minute, the timer setting
mode will be cancelled.
1 Press the TIME SET button repeatedly until “On
time” is displayed.
“On time” appears on the display, and the “hour” value
blinks.
2 Press the scroll buttons (˙/¥) to set the hour
value, and press the ENTER button.
The “minute” value blinks.
3 Press the scroll buttons (˙/¥) to set the minute
value, and press the TIME SET button.
“Off time” appears on the display, and the “hour” value
blinks.
4 Repeat step 2 and 3 to set the Off time.
“Source select” appears on the display.
5 Press the scroll buttons (˙/¥) to select the
source, and press the ENTER button.
Now the timer setting is stored in memory.
< When you use iPod touch as the source for the timer,
do not turn it off. It will not be turned on when the On
time is reached.
EN_CR-H500NT_T_C.indb 50EN_CR-H500NT_T_C.indb 50 09.9.24 6:51:10 PM09.9.24 6:51:10 PM
![](/img.php?id=1188841&img=bg33.png)
ENGLISH
51
Every time you press the TIMER button on the
remote control unit, the timer mode changes as
follows.
Timer off
Timer daily
Timer REC once
Timer REC daily
Timer Playback
1 Select “Timer daily” by pressing the TIMER
button on the remote control unit.
The timer indicator “ ” lights on the display.
2 Prepare for the timer playback.
Adjust the volume, tune in a station, etc.
3 Press the STANDBY/ON button to put the unit in
standby mode.
Everyday when the On time is reached, the unit will
turn on and start playback, and when the Off time is
reached the unit will return to standby.
Timer Operation
Timer Recording
You can set the various external USB storage devices such
as USB flash memory to record programme at the desired
time.
Connect the external USB storage device to the unit
beforehand.
1 Select “Timer REC once” or “Timer REC daily”
by pressing the TIMER button on the remote
control unit.
The timer indicator “ ” and “ ” light on the display.
2 Prepare for the timer recording.
Tune in a station, etc.
3 Press the STANDBY/ON button to put the unit in
standby mode.
One minute before the set On time, the unit turns on
and starts recording at the On time.
When the Off time is reached the unit will return to
standby.
Timer off
When not using the timer, press the TIMER button
on the remote control unit to select “Timer off”.
The timer indicator “ ” disappears from the display.
EN_CR-H500NT_T_C.indb 51EN_CR-H500NT_T_C.indb 51 09.9.24 6:51:10 PM09.9.24 6:51:10 PM
![](/img.php?id=1188841&img=bg34.png)
52
Sleep Timer
The power can be switched off after a specified amount
of time.
Press the SLEEP button repeatedly until desired time
appears on the display.
SLEEP-90 (80, 70 ... 10)
The power will be switched off 90 (80, 70 ... 10)
minutes later.
SLEEP OFF
The sleep timer is off.
< The display is dimmed when you set the sleep timer.
< If you want to check the remaining time, press the
SLEEP button once. The remaining time will be
displayed for 3 seconds, and return to the normal
display.
Using an External Component
Listening to the Sound from the
External Component
You can listen to the sound from the external component
connected to the PHONO, AUX 1 IN, or AUX 2 IN jacks.
1 Press the SOURCE button to select “PHONO”,
“AUX 1” or “AUX 2”.
2 Start playback on the external component.
Recording the Sound from the
CR-H500DNT on the Recorder
You can record the sound from the CR-H500NT on the
recorder connected to the AUX 1 OUT jacks (see page 10).
1 Press the SOURCE button on the CR-H500NT to
select the source to record.
2 Start recording on the recorder.
< Also start playback on the CR-H500NT when “CD”,
“USB” or “iPod” is selected as the source.
< The sound from the AUX 1 IN jacks cannot be
recorded.
EN_CR-H500NT_T_C.indb 52EN_CR-H500NT_T_C.indb 52 09.9.24 6:51:11 PM09.9.24 6:51:11 PM
![](/img.php?id=1188841&img=bg35.png)
ENGLISH
53
In case of trouble with the unit, please take the time
to look through this chart and see if you can solve the
problem yourself before you call your dealer or TEAC
service center.
Amplifier
No power.
e Check the connection to the AC power supply.
No sound from speakers.
e Check the connection to the speakers.
e Adjust the volume.
e Select proper source.
e Pull out the headphones plug from PHONES jack.
e If muting is on, press the MUTING button.
The sound is noisy.
e The unit is too close to a TV set or similar appliances.
Install the unit apart from them, or turn them off.
Clock goes wrong.
e The clock setting will not be saved when the unit is
turned off by unplugging the power cord. Do not
turn off the unit by unplugging the power cord.
Remote Control Unit
Remote control unit does not work.
e If the batteries are exhausted, change the batteries.
e Use remote control unit within the range (5 m) and
point at the front panel.
e Clear obstacles between the remote control unit and
the main unit.
e If a fluorescent light is near the unit, turn it off.
Tuner
Cannot listen to any station, or signal is too weak.
e Tune in the station properly.
e If a TV set is near the unit, turn it off.
e Install the antenna again after locating the best
reception position.
e An external antenna is recommended.
Though the broadcast is stereo, it sounds
monaural.
e Press the FM MODE button.
Internet radio
Cannot connect to the Internet.
e Check if your computer can connect to the Internet
using the same network.
e Enter a correct pass key to the network.
e Check the settings of your network’s firewall. The
unit needs access to the following UDP and TCP
ports as a minimum: 80, 554, 1755, 5000 and 7070.
Cannot listen to a station/Podcast.
e The broadcaster has a temporary trouble with
Internet connection.
e Check if your Internet connection is not temporarily
disconnected or disturbed.
Cannot find a station/Podcast in the station list.
e The station/Podcast may not be broadcast at the
moment.
e The link of the station/Podcast may be out of date.
e The allowed number of simulataneous listeners of
station/Podcast might have reached the maximum.
e The internet connection speed is too slow.
e
Add the station/Podcast to your own station list by
accessing the internet radio portal.
Music Player
Cannot connect to the LAN.
e Check the settings of your network’s firewall. The
unit needs access to the following UDP and TCP
ports as a minimum: 80, 554, 1755, 5000 and 7070.
e Check if your computer can connect to the Internet
using the same network.
e Enter a correct password to the network.
e Check if the computer is not shut down or in the
sleep mode. Set up the computer not to shut down
or turn into the sleep mode automatically.
e There may be a problem with the network
authentication. Press the SOURCE button or BAND
button to select the Music Player again.
Cannot find a track. (Shared Media)
e Add the track to the media library of Windows Media
Player.
e Set your CR-H500NT as a “Unknown Device” in the
device list of Windows. (page 41)
e Select “Allow” for CR-H500NT (“Unknown Device”)
(page 41).
e Check the file format. Playable formats are MP3 and
WMA.
e If you have antivirus security software enabled on
your computer, the unit may fail to connect.
Troubleshooting (1)
EN_CR-H500NT_T_C.indb 53EN_CR-H500NT_T_C.indb 53 09.9.24 6:51:11 PM09.9.24 6:51:11 PM
![](/img.php?id=1188841&img=bg36.png)
54
Cannot find a folder/file. (Shared Folders)
e Configure the folder/file sharing setting. (page 42 to
44)
e Add the file to the shared folder.
e Enter a correct password of the user account.
e Check the file format. Playable formats are MP3 and
WMA.
e If you have antivirus security software enabled on
your computer, the unit may fail to connect.
iPod Player
Will not play.
e Remove the iPod from the USB jack, wait a few
seconds, and insert it again.
e Software update may solve the problem. Visit
the Apple website and download the latest iPod
software.
Cannot operate the iPod.
e Make sure the HOLD switch of the iPod is not set to
HOLD.
MP3/WMA
There is no sound even if the play/pause button
(y/J) is pressed.
e Check if there are MP3 or WMA files on the USB.
e Non-playable file formats (e.g MPEG 1 LAYER 2 file)
cannot be played.
“No title”, “No artist”, and “No album” appears on
the display.
e There is no ID3 tag information for the music file.
Edit the title, artist, and album information of
the song on a PC using the MP3 or WMA making
application.
Some unknown characters are displayed on the
display panel.
e This unit cannot display symbols and full-size or
double-byte characters (such as Japanese, Chinese,
etc.) correctly. File name of MP3 or WMA should be
alphanumeric characters.
If normal operation cannot be recovered, unplug
the power cord from the outlet and plug it again.
Maintenance
If the surface of the unit gets dirty, wipe with a soft cloth
or use diluted neutral cleaning liquid. Be sure to remove
any fluid completely. Do not use thinner, benzine or
alcohol as they may damage the surface of the unit.
Troubleshooting (2)
Restoring factory settings
If the power supply is interrupted for 14 days or longer, all
the settings kept in memory (such as preset stations and
timer settings) will be erased.
It will take more than 3 days after plugging the power
cord into the outlet to charge enough electricity for the
memory backup function.
If you want to manually initialize the settings, hold
down the SOURCE button and play/pause button
(y/J) for more than 4 seconds in standby mode.
The unit will be turned on, and all the settings are reset to
the default settings.
EN_CR-H500NT_T_C.indb 54EN_CR-H500NT_T_C.indb 54 09.9.24 6:51:12 PM09.9.24 6:51:12 PM
![](/img.php?id=1188841&img=bg37.png)
ENGLISH
55
Specifications
AMPLIFIER Section
Output Power . . . . . . . . . 40 W/ch (6 ohms, 0.5 %,1 kHz)
Input Sensitivity . . . . . . . . . . . . . . . . PHONO: 2.5 mV 47 kΩ
AUX1, AUX2: 200 mV 47 kΩ
Frequency Response . . . . 20 Hz to 60,000 Hz (+1/–3 dB)
TUNER Section
FM Section
Tuning Range . . . . . . . . . . . . . . . 87.50 MHz to 108.00 MHz
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . . . 65 dB (Mono)
60 dB (Stereo)
AM Section
Tuning Range
522 kHz to 1,629 kHz (European Model)
530 kHz to 1720 kHz (North American Model)
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 dB
USB Section
Playback
Frequency Response . . . . . . . 20 Hz to 20,000 Hz (±2 dB)
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . more than 85 dB
Recording
Frequency Response . . . . . . . 20 Hz to 15,000 Hz (±2 dB)
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . more than 85 dB
Internet Radio
Format . . . . . . . . . . . . . . . . . . . . . . . . MP3, WMA, RealAudio
Internet connection
LAN terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 BASE-T
Wireless LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . IEEE 802.11b/g
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . WEP, WPA, WPA2
GENERAL
Power Requirements
230 V AC, 50 Hz (European Model)
120 V AC, 60 Hz (North American Model)
Power Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90 W
0.5 W (standby)
Dimension (W x H x D) . . . . . . . . . . . 290 x 115 x 385 mm
(11-7/16 x 4-9/16 x 15-3/16 inch)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.6 kg
(12.4 lbs)
Standard Accessories
Remote Control Unit (RC-1225) x 1
Batteries (AAA) x 2
AM Loop Antenna x 1
FM Lead-type Antenna x 1
Owner’s Manual x 1
Warranty Card x 1
< Design and specifications are subject to change
without notice.
< Weight and dimensions are approximate.
< Illustrations may differ slightly from production
models.
Information for Users on Collection and
Disposal of Old Equipment and used Batteries
These symbols on the products, packaging, and/or
accompanying documents mean that used electrical
and electronic products and batteries should not
be mixed with general household waste. For proper
treatment, recovery and recycling of old products
and used batteries, please take them to applicable
collection points, in accordance with your national
legislation and the Directives 2002/96/EC and
2006/66/EC.
By disposing of these products and batteries
correctly, you will help to save valuable resources
and prevent any potential negative effects on
human health and the environment which could
otherwise arise from inappropriate waste handling.
For more information about collection and recycling
of old products and batteries, please contact your
local municipality, your waste disposal service or the
point of sale where you purchased the items.
Information on Disposal in other Countries
outside the European Union
These symbols are only valid in the European
Union. If you wish to discard these items, please
contact your local authorities or dealer and ask
for the correct method of disposal.
Note for the battery symbol (bottom right two
symbol examples):
This symbol might be used in combination with a
chemical symbol. In this case it complies with the
requirement set by the Directive for the chemical
involved.
EN_CR-H500NT_T_C.indb 55EN_CR-H500NT_T_C.indb 55 09.9.24 6:51:12 PM09.9.24 6:51:12 PM
![](/img.php?id=1188841&img=bg38.png)
Z
0909.XX-XXXXA
This appliance has a serial number located on the rear panel. Please record the
model number and serial number and retain them for your records.
Model number Serial number
TEAC CORPORATION 1-47 Ochiai, Tama-shi, Tokyo 206-8530, Japan Phone: (042) 356-9156
TEAC AMERICA, INC. 7733 Telegraph Road, Montebello, California 90640 U.S.A. Phone: (323) 726-0303
TEAC CANADA LTD. 5939 Wallace Street, Mississauga, Ontario L4Z 1Z8, Canada Phone: (905) 890-8008
TEAC MEXICO, S.A. de C.V. Río Churubusco 364, Colonia Del Carmen, Delegación Coyoacàn, CP 04100, México DF, México Phone:
(5255)5010-6000
TEAC UK LIMITED Suites 19 & 20, Building 6, Croxley Green Business Park, Hatters Lane, Watford, Hertfordshire, WD18 8TE,
U.K. Phone: (0845) 130-2511
TEAC EUROPE GmbH Bahnstraße 12, D-65205 Wiesbaden-Erbenheim, Deutschland Phone: 0611-71580
EN_CR-H500NT_T_C.indb 56EN_CR-H500NT_T_C.indb 56 09.9.24 6:51:12 PM09.9.24 6:51:12 PM
