Voxx Accessories SP270 Wireless Speaker User Manual
Voxx Accessories Corp. Wireless Speaker
User manual
![](/img.php?id=2932479&img=bg1.png)
Q U I C K
S T A R T
G U I D E
Instructions en français ...........xx
Instrucciones en español ......... xx
SP270 QSG 00
![](/img.php?id=2932479&img=bg2.png)
2
Bluetooth wireless is a quick and easy way to connect a
smartphone to a speaker or a headset. There are basically
two steps to making Bluetooth work.
PAIRING: The two
devices get to know each
other.
CONNECTING: The two
devices do something
together (like play music).
“Hi. I’m a
phone.”
This guide takes you through the steps to get started.
Getting to know Bluetooth
“Hi phone.
I’m a speaker.”
![](/img.php?id=2932479&img=bg3.png)
3
Make sure the following items came in this package:
• the LXS speaker
• an AC adapter
Step 1: Unpack
Before you start using the LXS speaker for the first time,
it’s a good idea to charge it completely.
Step 2: Charge the LXS
To charge the speaker: Plug
the included AC adapter into
the DC IN jack on the speaker’s
back panel.
Plug the other end of the AC
adapter into an AC outlet or
surge protector.
The charging indicator next to
the DC IN jack is red while the
Speaker back
speaker is charging. It turns green when the speaker is fully
charged.
Note: You can use the speaker while it’s charging.
![](/img.php?id=2932479&img=bg4.png)
4
Enable Bluetooth on your
smartphone or other device.
Step 4: Pair + Connect
Wi-Fi
Bluetooth
Bluetooth Settings
VPN Settings
Wi-Fi Settings
8:45PM
Make sure the button on the
top of the speaker is blinking
rapidly. (If it isn’t, give a short
double-press on the button.
The speaker gives an audio
signal.)
Step 3: Turn on
Press and hold the button on
the top of the speaker.
The power-up tone sounds and
the button starts blinking.
After a few seconds, the
speaker goes to Bluetooth
pairing mode to set up with
your smartphone.
Speaker top
![](/img.php?id=2932479&img=bg5.png)
5
If you’ve previously paired your phone or other Bluetooth device with this
speaker, the speaker will automatically attempt to reconnect to that device
when you switch the speaker on. If you want to pair to a new device, give a
short double-press to the button. The speaker gives a signal and the button
starts blinking.
Choose 808 LXS from the pairing options on your
smartphone. (If it’s not in the list, choose “Scan” from your
phone’s Bluetooth menu.)
The speaker gives an audio signal when it’s finished pairing
and connecting to your smartphone. The button on the top
of the speaker turns solid blue.
Note: The process of enabling Bluetooth and connecting varies from device
to device. See your device’s owners manual for more information and specific
instructions.
Bluetooth Wireless Connection Tips
• Make sure the Bluetooth capability of your device is turned on.
• Make sure there’s nothing plugged into the speaker’s AUX IN jack when
you’re trying to use Bluetooth.
• The Bluetooth wireless connection works up to a range of roughly 33 feet (10
meters). This range may vary, however, based on other factors, such as room
layout, wall material, obstacles, your device’s Bluetooth performance, etc. If you’re
having problems connecting to this speaker, move closer to it.
• If your device asks you for a password to connect, use “0000”.
• If you’ve paired your device with the speaker before but you’re having trouble
reconnecting when you turn the speaker back on, give a short press to the
button while it’s flashing. The speaker will attempt to connect to a previously
paired device.
![](/img.php?id=2932479&img=bg6.png)
6
Press the VOLUME + and –buttons on the top of the
speaker (or use the volume controls on your phone).
Set your device’s volume for music
to 50%.
Note: This is to make sure the sound from the
speaker isn’t too loud when you start streaming.
Start playing music or other audio
on your device. Within seconds, the
speaker starts streaming the audio
wirelessly via Bluetooth.
To adjust the volume of your audio:
Step 5: Play music
8:45PM
Now playing
Media volume
8:45PM
Using Bass Boost
The LXS speaker has a Bass Boost feature that enhances
the lower frequencies in your music. Bass Boost is turned
on by default. Press the EQ button on the top of the
speaker to toggle Bass Boost on and o.
![](/img.php?id=2932479&img=bg7.png)
7
Use a 3.5mm audio cable (not
included) to connect the audio
output from your device to
the AUX IN audio input on the
speaker’s back panel.
The speaker automatically
switches to the AUX IN audio,
and the button on the top of
Using the Aux In input
the speaker turns solid blue.
To listen to Bluetooth audio again, unplug the cable from
the speaker’s AUX IN jack. The speaker will try to reconnect
to the last Bluetooth device.
Note: The EQ and VOLUME buttons stay lit while the AUX IN jack is in use—
these buttons work with an AUX IN source. The TRACK and PLAY/PAUSE
buttons do not work while the AUX IN jack is in use, so they are not lit.
Speaker back
![](/img.php?id=2932479&img=bg8.png)
8
Using the Speakerphone
This speaker has a built-in
microphone, so you can use
it for phone calls as well as
music. Your phone will ring
through the speaker when
you’re receiving a call.
To answer/end the call: Press the button on top of the
speaker. The button lights when you’re on the call.
Note: Make sure you’re close enough to the speaker’s built-in microphone so
that the other person can hear you!
IMPORTANT: Not all phones support playback control and phone answer/end
control. Check your phone’s user manual for more information if you’re having
trouble with these functions.
Speaker top
Microphone
Using the Power Bank
Speaker back
This speaker has a built-in power
bank, so you can use it to charge
and power your phone or other
portable device, even while you use
the speaker.
To charge your device: Plug your device’s charging cable
into the 5V USB jack on the back of the LXS speaker.
![](/img.php?id=2932479&img=bg9.png)
9
Tour of the speaker
Top
VOLUME – / + decrease or increase the volume of the
speaker’s audio.
EQ switches between bass boost and regular equalization.
POWER/PAIR button turns the speaker on/o (press and
hold) and puts the speaker into pairing mode (short double
press). It also shows the Bluetooth status of the speaker:
• fast blinking blue while pairing or reconnecting
• solid blue when paired or when the AUX IN jack is in use
• o when the speaker’s o.
CALL button answers or ends calls on a Bluetooth-
connected phone.
TRACK BACK, PLAY/PAUSE, and TRACK FWD buttons
control playback of a paired Bluetooth music source (not all
Bluetooth devices support this functionality; these buttons
do not control playback for an AUX IN source).
![](/img.php?id=2932479&img=bga.png)
10
Back
5V charges your mobile device when
the LXS battery has enough power.
Plug your device’s charging cable into
this jack to charge your device.
DC IN jack connects to the provided AC adapter to plug the
speaker into a wall outlet or surge protector.
Charge indicator shows the charging status of the speaker:
• solid red while charging
• green when fully charged
AUX IN jack lets you connect an audio device directly to the
speaker using a 3.5mm audio cable (not included).
Charge
indicator
If you have any questions about this product,
visit 808Audio.com or call our toll-free help line
at 1-800-732-6866.
