QUICK START GUIDE
Instructions en français ............ 11
Instrucciones en español .........22
PARTY SYSTEM
HEX ENCOREPRO™
![](/img.php?id=3855975&img=bg2.png)
2
Get ready for huge, booming sound!
The 808 Hex Encore Pro Party System has what you need to
take your party to the next level!
+ Multiple audio inputs that let you play music via USB,
Bluetooth, even the radio or a direct input.
+ Two microphone inputs that let you (and a friend!) sing
along, with one mic included. The second input even lets
you plug in your guitar!
+ Preset EQ settings that let you get exactly the sound you
want.
+ Bass boost that gives your music an extra kick!
+ Built-in multi-mode lighting that creates the ultimate
portable light show.
This guide takes you through the steps to get started!
Press Me and See!
What can a single button do? Press the BASS
button on the top of the Encore Pro to find out
for yourself—a big punch to your music, and a
light show with some serious wattage! Just play, press, and
pump it up!
![](/img.php?id=3855975&img=bg3.png)
3
Press and hold the button on the top of the
speaker to turn it on.
Step 2: Plug in the speaker
Step 3: Turn the speaker on
Step 1: Unpack
Make sure the following items came in this package.
• Speaker
• Microphone
• 4ft Audio Cable
• AC Power Cord
Attach one end of the AC power cord to the AC
MAINS jack on the back of the speaker.
Plug the other end of the power cord into a
working outlet or surge protector.
Speaker top
![](/img.php?id=3855975&img=bg4.png)
4
Step 4: Choose your audio source
Speaker top
Press the SOURCE button on the top of the
speaker to cycle through the available inputs:
USB “ _USB ”
RADIO “_TUN”
3.5mm “_AU_””
RCA “LINE”
BT “_BT_”
The display on the front of the speaker shows
you which audio source is currently playing.
To set up Bluetooth: Follow the instructions
below.
Note: You can also select the Bluetooth and FM
sources directly with the BT and FM buttons on
the top of the speaker.
_USB
Setting up Bluetooth
1. Press the BT button on the speaker. The display says “BT,”
then “NOBT” (if you haven’t paired it yet).
2. Enable Bluetooth on your phone or other audio device
If it isn’t already on, turn on the Bluetooth function of your device.
3. Select 808 Encore Pro from the list of devices
The display on the front of the speaker says “BT CONNECTD” when it’s
finished connecting to your phone.
Notes: If you don’t see 808 Encore Pro in the list of Bluetooth devices on your phone,
choose “Scan” from your phone’s Bluetooth menu.
The process of enabling Bluetooth and connecting varies from device to device. See
your device’s owners manual for more information and specific instructions.
![](/img.php?id=3855975&img=bg5.png)
5
4. Start playing music on your device
The speaker starts streaming your music wirelessly.
Note: Make sure your device’s volume is set to at least 75%.
Bluetooth Wireless Connection Tips
• Make sure the Bluetooth capability of your device is turned on.
• Make sure Bluetooth is the source selected on the Encore Pro.
• Make sure there’s nothing plugged into the speaker’s Aux In or RCA In jacks when
you’re trying to use Bluetooth.
• The Bluetooth wireless connection works up to a range of roughly 33 feet (10 meters).
This range may vary, however, based on other factors, such as room layout, wall
material, obstacles, your device’s Bluetooth performance, etc. If you’re having problems
connecting to the speaker, move closer to it.
• If your device asks you for a password to connect, use “0000”.
Using EQ
This speaker has an EQ button that lets you select one of the preset
equalization settings (Rock, Jazz, Samba, Pop, Balance, and Funk) that
automatically adjust the equalization to enhance the sound for each type
of music.
To use one of the preset EQ settings: Press the EQ button to cycle
through the presets until you reach the setting you want to use. The front
display tells you the current setting.
Activating Bass Boost and Light Show
The Encore Pro speaker oers a Bass Boost feature that gives your music
a volume lift and bass punch. Press the BASS button on the top of the
speaker to toggle Bass Boost on and o. The BASS button also triggers
the Encore Pro light show eects on the speaker’s front.
![](/img.php?id=3855975&img=bg6.png)
6
Using the Microphone Inputs
Speaker top
The Encore Pro comes with a microphone you can use to sing along or
make announcements! Simply plug this provided microphone into the MIC1
jack on the top of the speaker and control the microphone volume with the
MIC1 VOLUME knob on the top of the speaker. You can add an echo eect
using the MIC1 ECHO knob under the volume knob. Start playback on any
of the audio sources and sing along!
The Encore Pro can accommodate a second microphone or a guitar as well
(not provided). Use the MIC2/GUITAR VOLUME knob to control this jack.
Using Two Encore Pros (BT Stereo)
If you have two Encore Pro speakers, you can use them together in stereo,
either with Bluetooth Wireless Stereo, or through a wired connection.
To set up a 2 Encore Pros via Bluetooth Stereo: Make sure the second
speaker is on. Press the BT STEREO button on the both speakers. The
displays on the speakers will say “HOST” and “SL” when connected. (Press
and hold BT STEREO on one speaker to disconnect.)
To set up a 2 Encore Pros via wired connection: Connect an RCA stereo
cable (not included) to the OUT L/R jacks on the back of one Encore Pro.
Connect the other end of this cable to the IN L/R jacks on the back of the
other Encore Pro. Press the SOURCE button on the second Encore Pro to
select the LINE IN input.
![](/img.php?id=3855975&img=bg7.png)
7
Using Dynamic Lighting
The LIGHTING dial on top of the speaker gives
you control over the built-in dynamic lighting on
the speaker’s front.
Press the LIGHTING dial to cycle through the
multiple lighting modes:
Always on: Turn the LIGHT dial to change
colors.
Dance: The light pulses and changes color to
the beat of your music.
Pulse: The light pulses to the beat of your
Speaker top
music (you might need to turn your music up!). Turn the LIGHT dial to
change colors.
Party: The light changes colors to the beat of the music.
Breath: The light gradually intensifies and diminishes. Turn the LIGHT
dial to change colors.
Chill: The light slowly goes through all the colors.
O: Turns the front lighting o.
Turn the LIGHTING dial to cycle through the available colors for the Always
On, Pulse, and Breath modes.
In addition to the light modes available through the LIGHTING dial, the
speaker also features a “light show” mode, triggered by the BASS button.
![](/img.php?id=3855975&img=bg8.png)
8
Tour of the Encore Party System
MIC 1 and MIC 2/GUITAR jacks let
you connect up to two microphones
(including the provided mic) or guitar
to use with the speaker, for karaoke or
announcements.
AUX IN jack lets you connect to an
external audio device with a 3.5mm
audio cable. The speaker switches
automatically to LINE when you insert
the cable.
BT button switches to the Bluetooth
source (press) or starts the Bluetooth
pairing process (press and hold).
BT STEREO button switches to the
multi-speaker Bluetooth Stereo (press)
or starts the multi-speaker Bluetooth
Stereo setup process (press and hold).
MIC1 VOLUME dial adjusts the volume of
the MIC1 in microphone.
MIC1 ECHO dial adjusts the reverb eect
added to the microphone audio.
BASS button activates the bass boost
volume lift and light show. Press to turn
bass boost on/o.
and buttons go to the previous
or next track during USB or Bluetooth
playback (press and hold for USB to scan
through a track). In radio mode, press to
go to the next frequency, or hold to go to
the next strong station.
Volume dial adjusts the speaker’s
volume. The display shows the
current level as you adjust (from 0,
minimum, to 40, max).
button starts or pauses playback
in USB or Bluetooth modes. In radio
mode, scans for stations and stores
presets (press and hold).
![](/img.php?id=3855975&img=bg9.png)
9
USB-A PLAYBACK port connects to a
USB storage device for MP3 playback.
To play music from this device, press
SOURCE until the display reads “USB.”
USB-B CHARGING port provides
charging power to a USB-powered
device. This jack does not support
playback.
EQ button cycles through the speakers’s
preset equalization settings (Rock,
Jazz, Samba, Pop, Balance, and Funk)
to enhance the sound for each type of
music.
FM button switches to the FM Radio
source.
LIGHTING dial controls the speaker’s
multi-mode lighting. Press to cycle
through the six light modes: Dance, O,
Always On, Pulse, Party, Breath, and
Chill. Turn the dial in Always On, Pulse,
and Breath mode to change the color of
the light.
MIC2/GUITAR VOLUME dial adjusts
the volume of the MIC2/GUITAR IN
microphone or guitar.
button turns the speaker on and o.
.
SOURCE button cycles through
the dierent audio sources
available: USB, LINE IN, RCA
IN, BLUTOOTH, and RADIO. The
dislpay shows the current audio
source.
Display (front) shows the
current audio source as well
as information about the
source (radio station frequency,
for example) and Bluetooth
connection status.
Volume dial adjusts the speaker’s
volume. The display shows the
current level as you adjust (from 0,
minimum, to 40, max).
button starts or pauses playback
in USB or Bluetooth modes. In radio
mode, scans for stations and stores
presets (press and hold).
![](/img.php?id=3855975&img=bga.png)
10
12 Month Limited Warranty
Voxx Accessories Corporation (the “Company”) warrants to the original retail purchaser of this product that should this product
or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from
the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product (at the Company’s
option) without charge for parts and repair labor. To obtain repair or replacement within the terms of the warranty, the product
is to be delivered with proof of warranty coverage (e.g. dated bill of sale), specification of defect(s), transportation prepaid, to an
approved warranty station. For the location of the nearest warranty station to you, call toll-free to our control oce:
1-800-645-4994.
This Warranty is not transferable and does not cover product purchased, serviced or used outside the United States or Canada.
The warranty does not extend to the elimination of externally generated static or noise, to costs incurred for the installation,
removal or reinstallation of the product. The warranty does not apply to any product or part thereof which, in the opinion of the
company, has suered or been damaged through alteration, improper installation, mishandling, misuse, neglect, accident or
exposure to moisture. This warranty does not apply to damage caused by an AC adapter not provided with the product, or by
leaving non-rechargeable batteries in the product while plugged into an AC outlet.
THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT
PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S LIABILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER
FOR THE PRODUCT.
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO DURATION OF THIS
WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY HEREUNDER, INCLUDING ANY IMPLIED WARRANTY, MUST BE
BROUGHT WITHIN A PERIOD OF 24 MONTHS FROM THE DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY
BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES WHATSOEVER. No person or representative is authorized to
assume for the Company any liability other than expressed herein in connection with the sale of this product.
Some states/provinces do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental
or consequential damage so the above limitations or exclusions may not apply to you. This Warranty gives you specific legal
rights and you may also have other rights which vary from state/province to state/province.
Speaker back
AUDIO OUT L/R jacks connect to a
second Encore Pro speaker for wired
stereo.
AUDIO IN L/R jacks connect to external
audio source.
FM antenna extends to improve FM
radio reception.
![](/img.php?id=3855975&img=bgb.png)
Important Information for 808 Model SP491
CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric
shock, do not perform any servicing other than that contained in the operating instructions unless you are qualified to
do so.
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10.Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. WARNING: Only use attachments/accessories specified
by the manufacturer.
12. Use only with the cart, stand,
tripod, bracket, or table specified
by the manufacturer, or sold with
the apparatus. When a cart is used,
use caution when moving the cart/
apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
Care and Maintenance
• Always use a soft cloth to clean the speaker and transmitter. Never use any product containing alcohol or other
solvents as they may damage the surface.
• Use caution when plugging the power transformers in an AC outlet to avoid the risk of electric shock.
• If the speaker is used outside on a deck or patio, make sure you take it indoors in the event of a rainstorm to prevent
possible damage.
The apparatus shall not be exposed to dripping or
splashing. No objects filled with liquids, such as vases,
shall be placed on the apparatus.
No naked flame sources, such as lighted candles, should
be placed on the apparatus.
WARNING: The mains plug/appliance coupler is used as
disconnect device, the disconnect device shall remain
readily operable.
Do not install this equipment in a confined space such as
a book case or similar unit. The ventilation should not be
impeded by covering the ventilation openings with Items
such as newspaper, table-cloths, curtains etc.
Care is required with the use of this apparatus in
moderate climates.
See marking on the back of the product.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference, and 2) This device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Changes or modifications not expressly approved by VOXX Accessories Corporation could void the user’s
authority to operate the equipment.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator & your body.
Industry Canada Regulatory Information
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions:
1) this device may not cause interference and 2) this device must accept any interference, including interference that
may cause undesired operation of the device.
Industry Canada Regulatory Information Avis d’Industrie Canada
CAN ICES-3 (B)/NMB-3 (B) CAN ICES-3 (B)/NMB-3 (B)
IC Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by VOXX Accessories Corporation is under license. Other trademarks and trade names are those of their
respective owners.
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the
serial and model numbers in case you need them. These numbers are located on the product.
Model No.: _____________________________________________________________________________________________
Purchase Date: _________________________________________________________________________________________
Dealer/Address/Phone: __________________________________________________________________________________
Information importante pour 808 Modèle SP491
Instructions de sécurité importantes
1. Lire ces instructions.
2. Conserver ces instructions.
3. Respecter tous les avertissements.
4. Suivre toutes les instructions.
5. Ne pas utiliser cet appareil près de l’eau.
6. Nettoyer seulement avec un chiffon sec.
7. Ne bloquer aucune ouverture de ventilation. Installer
conformément aux instructions du fabricant.
8. Ne pas installer près d’une source de chaleur, par exemple
des radiateurs, des registres de chaleur, des poêles ou autres
appareils (amplificateurs, par exemple) qui produisent de la
chaleur.
9. Ne pas contourner le dispositif de sécurité de la fiche
polarisée ou de la fiche de type mise à la terre. Une fiche
polarisée est munie de deux lames, dont l’une est plus large
que l’autre. Une fiche de mise à la terre est munie de deux
lames et d’une troisième broche de mise à la terre. La lame
large ou la troisième broche sont fournies pour garantir la
sécurité. Si la fiche fournie n’entre pas dans la prise, consulter
un électricien pour le remplacement de la prise obsolète.
10. Protéger le cordon d’alimentation de manière à ne pas
marcher dessus ni le pincer, surtout au niveau de la fiche,
de la prise ou de la sortie du cordon de l’appareil.
11. AVERTISSEMENT : Utiliser uniquement des accessoires
spécifiés par le fabricant.
12. Utiliser seulement avec le chariot, le socle,
le trépied, le support ou la table spécifiés
par le fabricant, ou le dispositif vendu avec
l’appareil. Quand un chariot est utilisé, faire
preuve de prudence lors du déplacement
de l’ensemble chariot/appareil afin d’éviter
toute blessure provoquée par un basculement éventuel.
13. Débrancher cet appareil pendant les orages électriques
ou s’il n’est pas utilisé pendant de longues périodes.
14. Confier l’entretien de l’appareil à un technicien agréé.
Faire réparer l’appareil s’il a été endommagé de
quelque manière que ce soit, par exemple si le cordon
d’alimentation, ou la fiche, est endommagé(e), si du liquide
a été renversé sur l’appareil ou si des objets sont tombés
sur l’appareil, s’il a été exposé à la pluie ou à l’humidité,
s’il ne fonctionne pas normalement ou s’il est tombé.
L’appareil ne doit être exposé ni à un égouttement ni à des
éclaboussures. Aucun objet rempli de liquide, par exemple un
vase, ne doit être placé sur l’appareil.
Aucune source de flamme nue, comme une chandelle allumée,
ne doit être déposée sur l’appareil.
AVERTISSEMENT : La prise électrique ou le coupleur est
utilisé comme dispositif de déconnexion, celui-ci doit rester
facilement accessible.
Ne pas installer ce matériel dans un espace confiné comme
une bibliothèque ou un meuble similaire. La ventilation ne doit
pas être gênée par l’obstruction des ouvertures de ventilation
avec des objets tels que journaux, nappes, rideaux, etc.
Des précautions sont nécessaires pour l’utilisation de cet
appareil dans des climats modérés.
Se reporter aux inscriptions au dos du produit.
Entretien et maintenance
• Toujours utiliser un chiffon doux pour nettoyer le haut-parleur et l’émetteur. Ne jamais utiliser un produit qui contient de
l’alcool ou d’autres solvants, car il risque d’endommager la surface.
• Faire preuve de prudence lors du branchement des transformateurs dans une prise de courant alternatif, afin d’éviter les
risques de choc électrique.
• Si les haut-parleurs sont utilisé à l’extérieur, sur une terrasse ou sur un patio, veiller à les rentrer à l’intérieur en cas d’orage
pour éviter de les endommager.
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ AND SAVE FOR FUTURE REFERENCE IMPORTANTES INSTRUCTIONS DE SECURITE
BIEN LIRE ET CONSERVER POUR RÉFÉRENCE ULTÉRIEURE
This is class II equipment designed with double or reinforced insulation so it does not require a safety
connection to electrical earth (US: ground).
Plugging in for power AC OUTLET POWER SUPPLY: 100–240 V ~ 50/60 Hz
Cet appareil de classe II est doté d’une isolation double ou renfermée et ne requiert pas de mise à la terre de
sécurité.
Branchement ALIMENTATION COURANT ALTERNATIF : 100–240 V ~ 50/60 Hz
MISE EN GARDE : Les consignes de maintenance de cette notice sont destinées uniquement aux techniciens qualifiés. Afin
de réduire les risques d’électrocution, n’effectuez aucune tâche d’entretien autre que celles décrites dans les consignes de
fonctionnement si vous n’êtes pas qualifié.
![](/img.php?id=3855975&img=bgc.png)
Déclaration FCC sur l’exposition aux radiations
Cet équipement est conforme aux normes d’exposition de la FCC en matière de radiations définies pour un environnement non
contrôlé. Cet équipement doit être installé et utilisé en respectant une distance minimale de 20 cm entre l’émetteur de radiations
et vous-même.
Information sur la réglementation d’Industrie Canada
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
Information sur la réglementation d’Industrie Canada
CAN ICES-3 (B)/NMB-3 (B)
Déclaration IC sur l’exposition aux radiations : cet équipement est conforme aux limites d’exposition stipulées par IC pour un
environnement non contrôlé.
Le mot servant de marque et les logos de Bluetooth® sont des marques déposées et sont la propriété de Bluetooth SIG, Inc.
et toute utilisation de telles marques par VOXX Accessories Corporation est effectuée sous licence. Toutes les autres marques
de commerce et dénominations commerciales sont celles de leurs propriétaires respectifs.
Information sur le produit
Conserver la facture comme preuve d’achat, ainsi que pour obtenir des pièces et toute réparation couverte par la garantie.
Attacher la facture ici et inscrire le numéro de série et de modèle comme référence en cas de besoin. Ces numéros se trouvent
sur le produit.
Numéro de modèle : ____________________________________________________________________________________________
Date d’achat : __________________________________________________________________________________________________
Adresse/téléphone du revendeur : ________________________________________________________________________________
Información Importante para 808 modelo SP491
Importantes Instrucciones de Seguridad
1. Lea estas instrucciones.
2. Guarde estas instrucciones.
3. Preste atención a todas las advertencias.
4. Acate todas las instrucciones.
5. No use este aparato cerca de agua.
6. Limpie sólo con un trapo seco.
7. No obstruya ningún orificio de ventilación. Instale en
conformidad con las instrucciones del fabricante.
8. No instale cerca de fuentes térmicas, como radiadores,
reguladores de calefacción, cocinas y otros aparatos
que generen calor (incluidos los amplificadores).
9. No anule el propósito de seguridad que tiene el enchufe
polarizado o puesto a tierra. Un enchufe polarizado tiene
dos paletas, una más ancha que la otra. Un enchufe puesto
a tierra tiene dos paletas y una clavija de conexión a
tierra. La paleta más ancha o la clavija se incluyen por su
seguridad. Si el enchufe proporcionado no encaja en su
tomacorriente, solicite a un electricista que reemplace el
tomacorriente obsoleto.
10. Proteja el cable de alimentación de modo que no resulte
pisado ni aprisionado, especialmente en el enchufe, la
caja de contacto y el punto por donde sale del aparato.
11. ADVERTENCIA: Utilice sólo aditamentos o accesorios
especificados por el fabricante.
12. Use sólo con el carrito, base, trípode,
soporte o mesa especificados por el
fabricante o vendidos con el aparato. Si
usa un carrito, tenga cuidado al mover
el aparato y el carrito juntos para evitar
lesiones si se vuelcan.
13. Desenchufe este aparato en caso de
tormentas o de lapsos prolongados de inactividad.
14. Solicite al personal técnico calificado todo tipo de
mantenimiento del producto. Es necesario darle
mantenimiento al aparato si ha sido averiado de
alguna forma, por ejemplo, si se ha dañado el cable de
alimentación o el enchufe, si se le ha derramado algún
líquido encima, si han caído objetos en su interior, si ha
sido expuesto a la lluvia o la humedad, si no funciona
correctamente o si se ha dejado caer.
Cuidado y Mantenimiento
• Siempre utilice un paño suave para limpiar el altavoz y el transmisor. Nunca utilice productos que contengan alcohol u otros
solventes ya que estos podrían ocasionar daños a la superficie.
• Tenga precaución al enchufar los transformadores de potencia en un tomacorriente de CA para evitar el riesgo de choque
eléctrico.
• Si se utiliza el altavoz en una terraza o patio, asegúrese de almacenarlo en el interior en caso de tormentas para evitar
posibles daños.
Declaración sobre la exposición a radiaciones según la FCC
Este equipo cumple los límites de exposición a radiación de la FCC establecidos para un entorno no controlado. Este dispositivo
debe instalarse y operarse con una distancia mínima de 20 cm entre el radiador y su cuerpo.
Información Regulatoria de la Industria Canadiense
Este dispositivo cumple con las Normas de la Industria Canadiense para productos exentos de licencia. Su funcionamiento
está sujeto a las siguientes dos condiciones: 1) este aparato no debe causar interferencia y 2) este aparato debe aceptar toda
interferencia, incluida aquélla que puede causar un funcionamiento no deseado del dispositivo.
Información Regulatoria de la Industria Canadiense
CAN ICES-3 (B)/NMB-3 (B)
Declaración IC de exposición a la radiación: Este equipo cumple con los límites de exposición a la radiación establecidos por
IC para un entorno no controlado.
La marca denominativa y los logotipos de Bluetooth® son marcas registradas propiedad de Bluetooth SIG, Inc. y el uso de dichas
marcas por parte de VOXX Accessories Corporation se hace bajo licencia. Otras marcas comerciales y nombres de marcas son
aquellas de sus respectivos dueños.
Información sobre el Producto
Guarde el recibo como prueba de su compra y preséntelo para obtener repuestos o solicitar servicio bajo garantía.
Anéxelo aquí y anote los números de serie y de modelo para referencia en caso necesario. Estos números se encuentran
en el producto.
Número de modelo: ____________________________________________________________________________________________
Fecha de Compra: ______________________________________________________________________________________________
Distribuidor/Dirección/Teléfono: _________________________________________________________________________________
SP491 Safety and Warranty 01
IMPORTANTE INSTRUCCIONES DE SEGURIDAD
FAVOR DE GUARDAR ESTO PARA UNA REFERENCIA FUTURA
Déclaration de la FCC
Cet appareil est conforme à la partie 15 du règlement de la FCC. Le fonctionnement est sujet aux deux conditions suivantes :
1) Cet appareil ne doit pas provoquer de brouillage préjudiciable et (2) cet appareil doit accepter tout brouillage reçu, y compris le
brouillage susceptible de provoquer un fonctionnement indésirable.
Remarque : cet équipement a été soumis à des essais et a été déclaré conforme aux limites stipulées pour un appareil numérique
de classe B, conformément aux spécifications de la partie 15 du règlement de la FCC. Ces limites ont pour but d’assurer une
protection raisonnable contre le brouillage nuisible dans une installation résidentielle. Cet équipement produit, utilise et peut
émettre de l’énergie en radio fréquence et, s’il n’est pas installé et utilisé conformément aux directives, il peut causer un brouillage
nuisible dans les communications radio. Cependant, il est impossible de garantir qu’aucun brouillage ne se produira dans une
installation particulière. Si cet équipement cause un brouillage de la réception de radio ou de télévision, ce qu’il est possible de
déterminer en éteignant puis en rallumant l’équipement, l’utilisateur est prié d’essayer de corriger le brouillage au moyen de l’une
ou de plusieurs des mesures suivantes :
• Réorienter ou déplacer l’antenne de réception.
• Augmenter la distance séparant l’équipement du récepteur.
• Brancher l’équipement dans une prise dont le circuit est différent de celui où est branché le récepteur.
• Consulter le revendeur ou un technicien expérimenté de radio/télévision.
Attention : les changements ou les modifications effectuées qui ne sont pas expressément approuvés par VOXX Accessories
Corporation peuvent annuler l’autorisation accordée à l’utilisateur de se servir de l’équipement.
Este es un equipo clase II diseñado con doble aislamiento o refuerzo de manera que no requiera una conexión de
seguridad a tierra eléctrica (EE.UU.: tierra).
Conexión a la red FUENTE DE ALIMENTACIÓN CA: 100 – 240 V ~ 50/60 Hz
Declaración de la Comisión Federal de Comunicaciones de los Estados Unidos
Este dispositivo cumple con la Parte 15 de las Reglas de la FCC. Su funcionamiento está sujeto a las siguientes dos condiciones:
1) Este dispositivo no debe causar interferencia y 2) Este dispositivo debe aceptar toda interferencia recibida, incluida aquélla que
puede causar un funcionamiento no deseado.
Aviso: Este equipo ha sido probado, y se consideró que cumple con los límites de los aparatos digitales de Clase B, de acuerdo con
las especificaciones de la Parte 15 de las Reglas de la FCC. El objetivo de estos límites es ofrecer una protección razonable contra
interferencias nocivas en una instalación residencial. Este equipo genera, utiliza y puede radiar energía de radiofrecuencia y, si no
se instala y utiliza de acuerdo con estas instrucciones, puede generar interferencia perjudicial para
las radiocomunicaciones. Sin embargo, no se garantiza que no se producirá interferencia en una instalación en particular.
Si su equipo causa interferencia perjudicial para la recepción de radio o televisión, que se puede averiguar apagando y
encendiendo el equipo, intente corregirla mediante uno o varios de los siguientes procedimientos:
• Vuelva a orientar o cambie de lugar la antena receptora.
• Aumente la separación entre el equipo y el receptor.
• Conecte este equipo a un tomacorriente en un circuito diferente al que esté conectado el receptor.
• Consulte al distribuidor o a un técnico experimentado de radio y televisión para solicitar asistencia.
Atención: Los cambios o modificaciones no aprobados expresamente por VOXX Accessories Corporation podrían anular la
autoridad del usuario conferida para utilizar este equipo.
El aparato no deberá exponerse a goteos ni salpicaduras. No
se debe colocar objetos que contengan líquidos como, por
ejemplo, floreros, sobre el aparato.
Ninguna fuente de flama abierta, tal como velas encendidas,
deberá colocarse sobre el aparato.
ADVERTENCIA: El acoplador del aparato o el enchufe de
la red eléctrica (MAINS) se utilizan como dispositivo de
desconexión; éste deberá estar siempre listo para funcionar.
No instale este equipo en un espacio confinado como, por
ejemplo, una estantería de libros o una unidad similar. Para
garantizar una ventilación adecuada, no cubra las aberturas
de ventilación con artículos como, por ejemplo, periódicos,
manteles, cortinas, etc.
Se debe tener cuidado siempre que se utilice este aparato en
climas moderados.
Consulte las indicaciones marcadas en la parte posterior del
producto.
PRECAUCIÓN: Estas instrucciones de servicio son para uso exclusivo del personal de servicio calificado. Para reducir el riesgo
de descarga eléctrica, no realice reparaciones que no se encuentren en las instrucciones de funcionamiento a menos que usted
está calificado para hacerlo.
