CONTACTLESS READER MODULE C150
INSTALLATION GUIDE
![](/img.php?id=1779234&img=bg2.png)
1. IN THE BOX
C150 (Figure 1) with USB, RS232 and custom cable
If it’s a RS232 cable, the power jack is on the rear of the DB9 connector. Connect the power cord
of the adaptor with the power jack on the rear of the cable (Figure 2)
If it’s a USB cable (Figure 3), it will get the power from USB connected Host
If it’s a custom cable (Figure 4), it will get the power from custom’s device.
Figure 1 Figure 2 Figure 3 Figure 4
2. SETTING CONNECTION
USB interface
Plug the USB connector into any of the USB port of the terminal.
RS232 interface
Connect the RS232 connector with the COM port of the terminal.
3. INSTALLING THE SAM CARD
Loosen the screw and open the SAM gate (Figure 4), insert the SAM card in the slot (Figure 5).
Figure 4 Figure 5
4. USING CONTACTLESS CARD READER
Contactless reader antenna is around the display. It will light up and blinking the 1st LED when
C150 is powered on and that means reader is working normally.
Place contactless card near the display (Figure 6). The contactless antenna should detect the card
and read the card data.
Figure 6
