BTT010
1
BTT010
Bluetooth Transmitter for iPod
User Manual
Before using
1. About the BTT010
2. Overview
Start to use
1. Switching on/off the transmitter
2. Pairing with Bluetooth devices
3. Music remote control
4. Indicator LED
Care and maintenance
FAQs
Specification
![](/img.php?id=1093911&img=bg2.png)
BTT010
2
Welcome to use this stereo Bluetooth transmitter, BTT010. Before using it,
please read this user manual carefully
Ƶ
ƵƵ
Ƶ
Before using
1. About BTT010
BTT010 is a Bluetooth transmitter. for iPod. It supports the following Bluetooth
profiles.
Profiles Description
A2DP (Advanced audio
distribution)
Stereo music play
AVRCP(Audio/video
remote control)
Music remote control(control the function of
pauseǃplayǃlast song and next song)
As long as you plug the transmitter into the iPod, and pair with your
stereo Bluetooth receiver(such as stereo Bluetooth headsets or Bluetooth
speakers),you can enjoy music wirelessly. Additionally , you can remote
control your iPod through operating the receiver if your Bluetooth receiver
also supports AVRCP ,.
Using it as soon as you plug it in, no need to charge. It is very
convenient.
2. Overview
1 iPod dock connector——using it to connect with iPod
2 Indicator LED——status indication
![](/img.php?id=1093911&img=bg3.png)
BTT010
3
Ƶ
ƵƵ
Ƶ
Start to use
ǃ
ǃǃ
ǃ
Switching on/off the transmitter
Function
Operation indicator light
Turn on Connect the transmitter with iPod
Indicator flashes quickly
Turn off Take out the transmitter from iPod
Indicator light is off
Note:please operate your iPod if the transmitter dose not work.
ǃ
ǃǃ
ǃPairing with Bluetooth devices
You can enjoy music wirelessly after pairing and connecting the transmitter
with Bluetooth receiver,. Before pairing, please make sure your
Bluetooth receiver supports A2DP profile. The steps are as follows:
1)ǃKeep the transmitter and your stereo Bluetooth receiver within 5 meters
2)ǃTurn on your Bluetooth receiver, and turn it to pairing mode.
3)ǃConnect the transmitter with iPod, make sure your iPod is on, the
indicator light will flash quickly..
4) ǃThe transmitter will search and pair with the Bluetooth receiver
automatically..
5)ǃAfter successful connecting the transmitter indicator LED will flash slower
than before. At this time, play music in the iPod .
Note
The transmitter can pair with stereo Bluetooth receivers which PIN Nos. are “0000”
“1234” “7777”or“8888”.
Connecting with the last paired device automatically when turn on the transmitter.So,.If
you want to pair with other devices, please turn off the current receiver, and then start to
pair with new device.
3ǃ
ǃǃ
ǃMusic remote control
You can remote control last songǃnext songǃpauseǃrevert to play through
operating the Bluetooth receiver. This function needs your Bluetooth receiver
to support AVRCP(audio/video remote control) profile. Please refer to your
user manual of Bluetooth receiver for further information.
4ǃ
ǃǃ
ǃIndicator LED
Indicator LED Status of transmitter
Blue LED flashes quickly Pairing mode or disconnect with
Bluetooth device
Blue LED flashes every 2 second connected with Bluetooth device
![](/img.php?id=1093911&img=bg4.png)
BTT010
4
Ƶ
ƵƵ
Ƶ
Care and maintenance
Before using the Bluetooth transmitter, please read the following
recommendations ,It will help you to enjoy the product for many year.
ƽKeep dry and don’t put it in the wet place, in case of effecting the
interior circuit of product.
ƽDon’t put the product under the sunlight or place in hot areas. High
temperature will shorten the life of electronic device and distort certain plastic.
ƽDon’t expose the transmitter to extreme temperatures, which may
damage the internal circuit board.
ƽDon’t try to take apart the product. It may damage the product if you are
not professional
ƽDon’t fall off on the floor, or knock the hard substance, it may damage
interior circuit.
ƽDon’t use intensify chemical or detergent to clean the product
ƽDon’t scrap the surface with sharp things
ƽIf the product can’t work normally, please send it to the regularly
asserted store, the staff will help you to solve problem warmly.
FAQs
1 Why can’t turn on the transmitter˛
a) Please make sure the transmitter connect with iPod wellDŽ
b) Please operate iPod to make sure iPod is on.
2 Why the transmitter can’t be paired and connected˛
a) Make sure Bluetooth receiver supports A2DP˗
b) Make sure Bluetooth receiver is placed within 5 meters˗
c Make sure Bluetooth receiver is in pairing mode.
3 Why no music from receiver˛
a) Make sure transmitter connects with iPod wellDŽ
b) Please make sure iPod is playing musicDŽ
![](/img.php?id=1093911&img=bg5.png)
BTT010
5
specification
Bluetooth version: Bluetooth V2.1
Bluetooth profiles: A2DP, AVRCP
Frequency range: 2.40GHZ-2.4835GHz
Effective range: Up to 10m
Dimension: 43.5*15*6.6mm
Weight: 4.5g
Rating: DC 3.3V, 50mA
Operating Temperature: -10ć - +45ć
Storage temperature: -20ć - +70ć
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
