3M Scott Technologies 200396 Locator User Manual 595101 01
Scott Safety-Division of Scott Technologies, Inc. Locator 595101 01
Manual
DRAFT COPY
OPERATIONAL INSPECTION
Complete operational inspection of the Personal Trans-
mitter requires use of the Hand Held Receiver
1. To test the manual alarm, press either of the two
manual alarm buttons on the Personal Transmitter.
a) The Personal Transmitter shall sound a loud
almost continuous 2 tone chirp accompanied by
flashing of the red signal light.
NOTE
IF A LOW BATTERY INDICATION OCCURS AT ANY TIME
DURING REGULAR OPERATIONAL INSPECTION, DO
NOT USE THE EQUIPMENT. CHANGE THE BATTERIES
AS REQUIRED AND REPEAT THE REGULAR
OPERATIONAL TEST OR TAKE THE EQUIPMENT OUT
OF SERVICE UNTIL THE BATTERIES ARE CHANGED
AND THE REGULAR OPERATIONAL TEST IS
SUCCESSFULLY PERFORMED.
VISUAL INSPECTION
1. Visually inspect the Personal Transmitter enclosure
for cracks or other damage. If any damage is found,
remove the unit from service and tag for
replacement.
2. Verify that the label with the Personal Transmitter ID
Number is clear and legible.
3. Turn on the Personal Transmitter by removing the
lanyard. Verify that the unit sounds and lights properly.
The Personal Transmitter shall sound a loud almost
continuous 3 tone chirp accompanied by flashing of
the red signal light.
4. Battery Life – The Personal Transmitter will chirp once
every three seconds to indicate the batteries are low
and require changing. If the low battery indication
occurs during the REGULAR OPERATIONAL
INSPECTION, replace the batteries before
proceeding with the inspection. See the BATTERY
INSTALLATION section of this instruction.
REGULAR OPERATIONAL INSPECTION
WARNING
FOLLOW REGULAR OPERATIONAL INSPECTION PRO-
CEDURE EXACTLY. IF THE SCOTT PAK-TRACKER
LOCATOR SYSTEM DOES NOT ACTUATE, OR DOES NOT
OPERATE AS DESCRIBED OR IF ANY OTHER OPERA-
TIONAL MALFUNCTION IS NOTED, DO NOT USE THE
EQUIPMENT. FAILURE TO PROPERLY IDENTIFY MAL-
FUNCTIONS MAY RESULT IN SERIOUS INJURY OR
DEATH.
WARNING
FAILURE TO REGULARLY INSPECT THE SCOTT PAK-
TRACKER LOCATOR SYSTEM EQUIPMENT, AS
DESCRIBED IN THIS INSTRUCTION OR FAILURE TO IDEN-
TIFY DAMAGE TO THE EQUIPMENT, MAY IMPAIR THE
INTRINSIC SAFETY OF THE EQUIPMENT. THE INSTAL-
LATION OF INCORRECT BATTERIES OR SUBSTITUTION
OF ANY OTHER COMPONENTS MAY IMPAIR THE INTRIN-
SIC SAFETY OF THE EQUIPMENT. IF THE EQUIPMENT IS
USED IN AN EXPLOSIVE OR FLAMMABLE ATMOSPHERE,
IMPAIRING THE INTRINSIC SAFETY OF THE EQUIPMENT
MAY LEAD TO A FIRE OR AN EXPLOSION WHICH COULD
RESULT IN SERIOUS INJURY OR DEATH.
b) The Hand Held Receiver will sound an alert and
display the Identification Number of the Personal
Transmitter which appears on the label on the
transmitter battery cover.
c) Press the ENTER button ONCE on the Hand
Held Receiver to select the displayed ID number
d) Point the Hand Held Receiver directly at and in
close proximity to the Personal Transmitter. The
signal strength displayed will be at its highest
value.
2. Reset the manual alarm by pressing simultaneously
on both buttons located on the sides of the Personal
Transmitter
a) The unit will sound three chirps and the green
light will flash.
b) The Hand Held Receiver will reset to its non-
alarm state.
3. Repeat the test in step 1 using the other manual alarm
button.
4. To check the motion detector, leave the Personal
Transmitter motionless for thirty (30) seconds.
a) The Personal Transmitter shall sound a loud
almost continuous 2 tone chirp accompanied by
flashing of the red signal light after ten (10)
seconds.
b) The Hand Held Receiver will sound an alarm and
display the Identification Number of the Personal
Transmitter which appears on the label on the
transmitter battery cover.
c) Press the ENTER button ONCE on the Hand
Held Receiver to select the displayed ID number
d) Point the Hand Held Receiver directly at and in
close proximity to the Personal Transmitter. The
signal strength displayed will be at its highest
value.
4. Turn the Personal Transmitter OFF by re-inserting
the lanyard. The unit will sound a two tone chirp and
the green light will go out.
Install or replace batteries in the Personal Transmitter
as follows:
1. Using a #1 Phillips screwdriver, loosen the four screws
holding the battery cover. The screws are captive in
the cover. See FIGURE 1.
2. Remove the old batteries and dispose of in
accordance with state or local regulations.
3. Install three fresh batteries of the type designated.
Orient the plus “+” and minus “-” ends of the batteries
as illustrated inside the battery compartment.
4. Inspect the gasket on the inside of the battery cover
for cuts or damage that might cause a leak. If any
damage is found, remove the unit from service and
tag for repair by authorized personnel.
5. Replace the battery cover and thread the four screws
in alternately Place the Battery Cover with gasket onto
the Personal Transmitter housing and secure the four
(4) screws using the #1 Phillips screw driver. Evenly
tighten the four cover screws by moving across the
cover in an “X” pattern, turning each screw 1 to 2
times until cover is fully seated.
6. Test the operation of the Personal Transmitter
according to the REGULAR OPERATIONAL
INSPECTION section of this instruction.
BATTERY INSTALLATION
FOR THE PERSONAL TRANSMITTER
The Personal Transmitter requires three (3) AAA batteries
for operation. Use only three fresh batteries of the type
specified. Batteries must only be installed or changed in
an area known to be nonflammable.
WARNING
DISPOSE OF DAMAGED OR DEPLETED BATTERIES IN
ACCORDANCE WITH FEDERAL, STATE, AND LOCAL EN-
VIRONMENTAL REGULATIONS. DO NOT THROW AWAY
DAMAGED BATTERIES AS ORDINARY TRASH. FAILURE
TO HANDLE BATTERY PROPERLY MAY RESULT IN SERI-
OUS INJURY.
1 Duracell is a registered trademark of The Gillette Company, Boston, MA.
2 Energizer and Eveready are registered trademarks of Eveready Battery Company, Inc., St. Louis, MO.
NOTE
DO NOT MIX BATTERY TYPES IN THE PERSONAL
TRANSMITTER. ONLY USE THREE OF THE SAME
KIND OF BATTERY IN THE UNIT AT ONE TIME. MIXING
BATTERY TYPES MAY AFFECT THE PERFORMANCE
OF THE PERSONAL TRANSMITTER. DO NOT USE
RECHARGEABLE BATTERIES IN THE PERSONAL
TRANSMITTER.
Only use three of the following battery types:
– Duracell1 Type MX2400, MN2400, or PC2400
– Energizer2 Type X92, E92, or EN92
– Eveready2 Type 1212
WARNING
USE ONLY BATTERIES OF THE TYPE LISTED. USE OF
BATTERIES OTHER THAN THOSE SPECIFICALLY LISTED
MAY VOID THE INTRINSIC SAFETY APPROVAL AND MAY
LEAD TO A FIRE OR EXPLOSION WHICH COULD RE-
SULT IN SERIOUS INJURY OR DEATH.
WARNING
BATTERIES MUST ONLY BE CHANGED IN AN AREA
KNOWN TO BE NONFLAMMABLE. CHANGING THE BAT-
TERIES IN A FLAMMABLE ATMOSPHERE MAY CAUSE AN
IGNITION WHICH COULD RESULT IN SERIOUS INJURY
OR DEATH.
FIGURE 1
P/N 595101-01 Rev – 8/06
DRAFT COPY
STORAGE
When storing the SCOTT PAK-TRACKER LOCATOR
SYSTEM Personal Transmitter for an extended period
of time, remove the batteries to prevent damage to the
battery terminals.
The Personal Transmitter may be stored in temperatures
from -40°F to +185°C (-40°C to +85°C).
CLEANING
The SCOTT PAK-TRACKER LOCATOR SYSTEM Personal
Transmitter is factory sealed to protect the electronics from
dirt and moisture. The Unit should be cleaned when nec-
essary using a cloth dampened with a solution of mild
detergent and water. DO NOT IMMERSE the Personal
Transmitter.
Wash the lanyard in a solution of mild detergent and
water and dry thoroughly before reinstalling.
Perform a REGULAR OPERATIONAL INSPECTION be-
fore the next use of the equipment.
QUESTIONS OR CONCERNS
If you have any questions or concerns regarding use of
this equipment, contact your authorized SCOTT dealer
or distributor, or contact SCOTT at 1-800-247-7257 (or
704-291-8300 outside the continental United States), or
visit our web site at www.scotthealthsafety.com.
MAINTENANCE
NOTE
THE SCOTT PAK-TRACKER LOCATOR SYSTEM
PERSONAL TRANSMITTER HAS NO USER
SERVICEABLE PARTS EXCEPT AS INSTRUCTED IN
THIS MANUAL. ANY OPERATIONAL PROBLEMS
SHOULD BE REFERRED TO AN AUTHORIZED SCOTT
HEALTH AND SAFETY SERVICE CENTER FOR
REPAIR.
Health & Safety Products
Monroe Corporate Center
PO Box 569
Monroe, NC 28111
Telephone 1-800-247-7257
FAX (704) 291-8330
www.scotthealthsafety.com
P/N 595101-01 Rev – 8/06 Printed in USA
Copyright © 2006, SCOTT, All Rights Reserved
RFI INTERFERENCE
The SCOTT PAK-TRACKER LOCATOR SYSTEM trans-
mitter or receiver may be susceptible to Radio
Frequency Interference (RFI) from a two-way radio.
Please hold your radio transmitter away from the SCOTT
PAK-TRACKER LOCATOR SYSTEM equipment when
transmitting. For complete details about RFI interfer-
ence, see the SCOTT PAK-TRACKER LOCATOR
SYSTEM User Instructions, P/N 595102-01.
PAK-TRACKER Locator System
PERSONAL TRANSMITTER
User Instructions
DESCRIPTION
The SCOTT PAK-TRACKER LOCATOR SYSTEM is a
two part electronic system consisting of a Personal
Transmitter, which is a small personally worn alarm/
Transmitter, and a Hand Held Receiver, which is a di-
rectional receiver or “sniffer” used to locate the signal
coming from the Personal Transmitter. This line of elec-
tronic accessories is for use by fire fighters, first
responders, domestic preparedness and law enforce-
ment officers, as well as haz-mat and industrial users.
These instructions (SCOTT P/N 595101-01) pertain only
to the Personal Transmitter.
Refer to the SCOTT PAK-TRACKER LOCATOR SYSTEM
User Instructions (SCOTT P/N 595102-01) for complete
instructions and warnings for use and maintenance of
the SCOTT PAK-TRACKER LOCATOR SYSTEM includ-
ing the Hand Held Receiver. Those instructions must be
used as the basis for training in use of the whole system.
They include an overview of the system operation and
limitations, as well as user level maintenance.
Training and practice in realistic emergency simulations
is required before use of this equipment. The users must
become thoroughly familiar with the operation and the
limitations of the system before entering a potentially haz-
ardous or life threatening situation.
WARNING
TRAINING IS REQUIRED BEFORE USE OF THIS EQUIP-
MENT IN A HAZARDOUS SITUATION. THE TRAINING MUST
INCLUDE EXTENSIVE PRACTICE WITH THE SYSTEM IN
A VARIETY OF ENVIRONMENTS. USE OF A TRACKING
SYSTEM WITHOUT PROPER TRAINING MAY PLACE THE
USER AT HIGHER RISK IN DANGEROUS SITUATIONS
WHICH COULD RESULT IN SERIOUS INJURY OR DEATH.
P/N 595101-01 Rev - 8/06
FCC COMPLIANCE
FCC Compliance Statement (Part 15.19)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired
operation.
FCC Warning (Part 15.21)
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s au-
thority to operate the equipment.
This portable transmitter with its antenna complies with
FCC’s RF exposure limits for general population / uncon-
trolled exposure.
The Locator Personal Transmitter has been assigned FCC
ID # T5E-200396.
INDUSTRY CANADA COMPLIANCE
Industry Canada Statement
The term “IC” before the certification / registration num-
ber only signifies that the Industry Canada technical
specifications were met.
Section 14 of RSS-210
The installer of this radio equipment must ensure that the
antenna is located or pointed such that it does not emit
RF field in excess of Health Canada limits for the general
population. Consult Safety Code 6, obtainable from Health
Canada’s web site: www.hc-sc.gc.ca/rpb.
INTRINSICALLY SAFE LISTING
The SCOTT PAK-TRACKER LOCATOR SYSTEM Per-
sonal Transmitter is listed by SGS U. S. TESTING
COMPANY, Inc. as intrinsically safe per ANSI/UL Std. UL-
913 for use in Class I Division 1 Groups A, B, C, and D
hazardous locations. To maintain the Intrinsic Safety List-
ing, the equipment must be inspected regularly per the
following Regular Operational Inspection procedures. Do
not tamper with or substitute components in any man-
ner. Use only batteries of the type indicated in the Battery
Replacement instructions. Open the battery compart-
ments only in an area known to be free of flammable or
explosive hazards.
WARNING – Substitution of Components May Impair In-
trinsic Safety. To reduce the risk of ignition of a flammable
atmosphere, batteries must only be changed in an area
known to be nonflammable, and do not mix old batteries
with unused batteries, or mix batteries from different manu-
facturers.
SAFETY LISTINGS
CLASS B DIGITAL DEVICE
Note: This equipment has been tested and found to com-
ply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television recep-
tion, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
– Reorient or relocate the receiving antenna
– Increase the separation between the equipment and
receiver.
– Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV
technician for help.
