Peltor™ WS™ ProTac™ XP
MT15H7*WS5**
The Sound Solution
(B:1)
(B:5)
(B)
(B:2)
(B:3)
(B:4)
(B:9)
(B:6)
(B:7)
(B:8)
(B:8)
(B:7)
(B:8)
(B:11)
(B:10)
(B:10)
13
2
(C)
13
2
(D)
(E)
(F) MT15H7P3*WS5**
SNR=31 db H=32 db M=29 db L=22 db
Frequency (Hz) 2) 63 125 250 500 1000 2000 4000 8000
Mean attenuation (dB) 3) 17.2 18.6 23.2 30.8 35.4 35.5 37.0 34.2
Std deviation (dB) 4) 3.8 2.7 2.7 4.4 2.5 4.2 3.2 3.7
Assumed Protection Value (dB) 5) 13.4 15.9 20.4 26.3 32.9 31.2 33.8 30.5
1) 352g
1) 352g
MT15H7A*WS5**
MT15H7B*WS5**
SNR=31 db H=32 db M=29 db L=22 db
SNR=30 db H=32 db M=27 db L=19 db
Frequency (Hz) 2) 63 125 250 500 1000 2000 4000 8000
Mean attenuation (dB) 3) 19.2 17.4 24.0 31.9 34.4 35.1 37.0 35.1
Std deviation (dB) 4) 4.0 2.8 2.9 3.0 2.6 4.3 4.0 3.2
Assumed Protection Value (dB) 5) 15.2 14.5 21.1 28.9 31.9 30.8 33.1 32.0
Frequency (Hz) 2) 63 125 250 500 1000 2000 4000 8000
Mean attenuation (dB) 3) 17.0 15.6 21.8 30.8 32.7 33.6 36.4 34.9
Std deviation (dB) 4) 3.8 3.8 3.5 2.9 2.9 2.5 3.3 2.4
Assumed Protection Value (dB) 5) 13.2 11.8 18.2 27.9 29.8 31.1 33.1 32.4
1) 345g
Input signal / usage time
Standards & Approval
2
1
G
x2x 8x4x
2
4
6
8
0
16x
h
R&TTE
EN 300 328 v1.7.1
EN 60950-1 :2006 + A1:2010 + A11:2009 + A12:2011
EN 301 489-1 v1.8.1
EN 301 489-17 v2.1.1
FCC
FCC 15.247 (Title 47 CFR chapter I part 15 subpart C)
FCC 15b (Title 47 CFR chapter I part 15 subpart B)
IC
RSS-210
ICES-103
Bluetooth
V. 2.1
K
1) Helmet Manufacturer 2) Helmet Model 3) Test Report 4) Attachment 5) Electronic protectors
Size ranges: S=small, N=medium, L=large
MT15H7P3*WS5**
Auboueix Brennus 95484T01 FSNL
Auboueix Fondelec 95484T01 FSNL
Auboueix Iris 95484T01 ENL
Auboueix Iris 2 26276T02 E NL
Sofop Taliaplast Oceanic 95484T01 ENL
Sofop Taliaplast Opus 95484T01 ENL
Berendsen Safety, Balance HD 26103T01
26104T01
26105T01
26106T01
NSNL
Centurion 1125/ARCO plus 95484T01 HSNL
Centurion 1100/ARCO type 2 95484T01 HNL
Centurion 1540/ARCO 95484T01 ANL
Evert Larsson Robust 95484T01 ESNL
Evert Larsson Balance 95484T01 ENL
Evert Larsson Balance AC/3M 1465 95484T01 ENL
Kemira Top Cap 95484T01 ASNL
LAS LP2002 95484T01 ESNL
LAS LP2006 95484T01 ESNL
MSA Super V-Gard II 95484T01 ESNL
MSA V-Gard 95484T01 ESNL
Peltor G2000 95484T01 K, E SNL
Peltor G22 (BASIC SET) 95484T01
22004T01
21361T01
21331T01
ESNL
Peltor G3000 26276T01 E SNL
Petzl Vertex 26099T01
26100T01
26101T01
26102T01
ESNL
Protector Style 300 21046T01 ESNL
Protector Style 600 21046T01 GSNL
Protector Tuffmaster II 21046T01 E, G NL
Römer Bravo 2 Nomaz 95484T01 BSNL
Römer Marcus Top 2 Atlas
Nomaz
95484T01 BSNL
Römer N2 Atlas Nomaz 95484T01 BB SNL
Römer Pro Expo 95484T01 ESNL
Römer Pro Nomaz 95484T01 ESNL
1) Helmet Manufacturer 2) Helmet Model 3) Test Report 4) Attachment 5) Electronic protectors
Size ranges: S=small, N=medium, L=large
MT15H7P3*WS5**
Römer Top Expo Atlas 95484T01 BSNL
Schuberth BEN 95484T01 BB SNL
Schuberth BER80/WPC80 95484T01 EA SNL
Schuberth BER S 26276T02 E SNL
Schuberth BOP R 95484T01 BSNL
Schuberth PIONIER 95484T01 BSNL
Schuberth SH 91/WPL 91 95484T01 EB SNL
Schuberth SW1 26099T01 EB NL
UVEX Airwing 95484T01 ESNL
Voss Inap 88 95484T01 ESNL
Voss Inap Master 95484T01 ENL
Voss Inap Star 26276T01 E NL
Voss Inap PCG 95484T01 GNL
IS 130-137
IT 138-145
KZ 146-153
LT 154-161
LV 162-169
NL 170-177
NO 178-185
PL 186-193
PT 194-201
RO 202-209
RU 210-217
SE 218-225
SI 226-233
SK 234-241
TR 242-249
UA 250-257
WS ProTac XP
Declaration of Conformity 258-259
GB 2-9
AF 10-17
AR 18-25
BG 26-33
BLR 34-41
CZ 42-49
DE 50-57
DK 58-65
EE 66-73
ES 74-81
FI 82-89
FR 90-97
GR 98-105
HE 106-113
HR 114-121
HU 122-129
2 3
GB
WS ProTac XP
The product(s) described in this user instruction is in conformity with the provisions set out in the Personal protective
euqipment (PPE) directive 89/686/EEC and the Radio equipment and Telecommunications terminal equipment directive
(R&TTE) 1999/5/EC. Thereby it fulls the requirements for CE marking.
1. WHAT IS WHAT
(B:1) Headband wire (stainless steel)
(B:2) Two-point fastener (headband wire)
(B:3) Ear cushion (PVC foil and Polyester foam)
(B:4) Microphone for surround sound
(B:5) Headband padding (Thermoplastic Elastomer or Leather)
(B:6) Flex audio input
(B:7) On/Off/Mode
(B:8) VOL+, VOL –
(B:9) Speech microphone
(B:10) Bluetooth button
(B:11) PTT button (Flex Headset)
2. FITTING AND ADJUSTMENT
Over-the-head band (Fig. C)
Slide the cups out and place the headset over your ears so that the ear cushions t snugly. (1)
Adjust the height of the cups by sliding them up or down whilst holding the headband in place. (2)
The headband should be positioned across the top of the head. (3)
Helmet attachment (Fig. D)
Snap the helmet attachment into the slot on the helmet (1).
The cups can be set in two positions: Ventilation position (2) or working position (3).
When in use, the cups must be placed in working position!
Press the headband wires inwards until you hear a click on both sides and ensure that the shell or the headband wires do
not press against the lining or edge of the helmet, which could cause noise leakage.
Notice! Never place cups with humid foam on the helmet! (4)
Helmet mounted version approved combinations (Fig. K)
1. Helmet brand
2. Helmet model
3. Test report
4. Helmet attachment
5. Electronic protectors. (Size ranges: S=small, N=medium, L=large)
3. USAGE/FUNCTIONS
3:1 Switching the headset on and off
Press and hold the On/Off/Mode button (B:7) for two seconds to switch the headset on or off.
3:2 Bluetooth pairing
The headset can be paired with and connected to Bluetooth units that support the proles: A2DP, HFP or HSP.
NOTE that you can only stream stereo sound/music from a unit (mobile phone, computer, etc.)
that supports the A2DP Bluetooth prole.
• Ensure that the headset is charged and switched off.
• Press and hold the On/Off/Mode button (B:7) for ve seconds.
This puts the headset into pairing mode, which is conrmed by repeated voice message: “Bluetooth pairing mode”.
• Activate your telephone’s Bluetooth function and search for new units. After a few seconds “Peltor WS5” will appear on
the screen.
• Select “Peltor WS5”.
3
GB
• If the phone asks you for a password, enter: 0000
• Pairing is conrmed when you hear the voice message: “pairing complete”.
Once the Bluetooth pairing function is activated it will automatically establish connection with the headset next time it is
used with a conrmation voice message “connecting Bluetooth”, and then: “connected” when the units are connected.
You can pair and store up to 3 units. The headset will automatically try to connect to the most recently connected unit rst.
3:3 Managing phone calls
To manage phone calls, the headset must be paired with and connected to a mobile phone
with Bluetooth capability, see Bluetooth pairing.
Answering calls
Incoming phone calls are indicated with a voice message “incoming call” in the headset.
Answer by pressing briey on the Bluetooth button (B:10).
Rejecting a call
Reject a call by pressing and holding the Bluetooth button for 2 seconds (B:10).
Voice dial
Press briey on the Bluetooth button (B:10).
Redial
Press and hold the Bluetooth button for 2 seconds (B:10).
3:5 Adjusting surround-sound volume
Increase volume. Press the (upper) + button (B:8).
Decrease volume. Press the (lower) – button (B:8).
3:6 Adjusting call volume ( mobile phone)
You can adjust volume during a call by pressing the (+) or (–) buttons (B:8).
Press the On/Off/Mode button (B:7) and then (+) or (–) buttons (B:8) to adjust the surround-sound volume during a call.
3:7 Adjusting streamed-music volume
You can adjust volume while streaming music by pressing the (+) or (–) buttons (B:8). Press briey on the On/Off/Mode button
(B:7) and then (+) or (–) buttons (B:8) to adjust the surround-sound volume during music streaming.
3:8 Adjusting communication volume (Peltor WS Adapter)
You can adjust the communication volume by pressing the (+) or (–) buttons (B:8). Press the On/Off/Mode button (B:7) and
then (+) or (–) buttons (B:8) to adjust the surround-sound volume during a call.
3:9 Adjusting Remote volume (Peltor WS Ground Mechanic Adapter)
You can adjust volume to the pilot by pressing the (+) or (–) buttons (B:8).
3:10 Changing settings in the Congure menu
The headset has a Congure menu where you can adjust settings.
To access the menu, press and hold the (–) and (+) buttons (B:8) for 2 seconds (with the headset switched on).
Access to the Congure menu is conrmed by a voice saying: “menu”. To change the settings, use the (–) and (+) buttons (B:8).
To move on through the Congure menu, press briey on the On/Off/Mode button (B:7).
See quick guide for information on how the menu is set up and where the functions are located.
VOX
Voice-operated transmit
ON
OFF
Battery type
2xAA Alkaline, 1,5 V
Rechargeable (NiMH, 1,2 V)
4 5
Reset to Factory Default
Resets all functions to the factory settings.
Hold Bluetooth button to conrm (B:10)
3:11 Connecting external equipment via a cord (Flex -77 version)
External equipment can be connected via the Flex audio input (B:6)
For information on various cords, see Spare Parts/Accessories.
4. OTHER FUNCTIONS
• The last settings are stored when the headset is switched off.
• Low battery level is indicated by a voice message: “low battery”.
• Digital noise reduction on the boom microphone
5. IMPORTANT USER INFORMATION
The headset must be worn, adjusted, cleaned and maintained in accordance with this manual. As with any hearing protector,
incorrect use or failure to follow the instructions supplied with this product could result in permanent disability due to exposure
to noise.
This ear-muff is provided with level-dependent attenuation.
The wearer should check correct operation before use. If distortion or failure is detected, please refer to the instructions for
replacement of the battery.
Warning! - Performance may deteriorate with battery usage.
Warning! - The output of the level-dependent circuit of this hearing protector may exceed the external sound level.
This hearing protector provides an entertainment audio facility. The the entertainment audio signal is limited to 82 dB(A)
effective to the ear for a maximum input signal level over the Bluetooth protocol.
Warning! The audibility of warning signals may be impaired while using the entertainment facility.
NOTICE! 100% use of a proper hearing protector is the only certain protection from hearing loss.
In environments with more than 82 dB A-weighted noise level, you need to protect your hearing. The hearing receptors in
your inner-ears may be irreparably damaged if you lift a cup of your hearing protectors for even a very short time in a noisy
environment.
The use of a comfortable hearing protector, designed for the specic noise level in which it is used, is the best guarantee to
that you will wear the hearing protector 100% of the time to protect yourself from permanent hearing loss.
For best protection, brush aside excess hair around your ears so the cushions t snugly on your head. The arms/bands of any
spectacles or goggles worn should be as thin as possible to allow the hearing protector to t closely to the head.
IMPORTANT! For the best protection, brush aside hair around the ears so the ear cushions t snugly against the head.
Spectacle frames should be as thin as possible and t close to the head to minimise acoustic leakage.
6. TECHNICAL DATA
6:1 Attenuation values, SNR (F)
The attenuation values and noise levels for the headset are tested and approved according to EN 352-1:2002, EN 352-3: 2002,
EN 352-4: 2001, EN 352-6 : 2002, EN 352-8 2008. Testing performed and Certicate issued by Combitech AB, Box 168,
SE-73223 Arboga, Sweden, ID#2279.
Explanation of the attenuation data tables:
1. Weight
2. Frequency (Hz)
3. Mean attenuation (dB)
4. Standard deviation (dB)
5. Assumed Protective Value (dB)
GB
5
GB
6:2 Sound exposure when using the Flex jacket (G)
The earphone level for music is measured at:
Max AUX input signal level = 1,5 V rms
AUX input signal level: 52 mV rms = 82dB
6:3 Criterion levels
A criterion level is the amount of noise (measured as A-weighted sound pressure) outside the hearing protector that gives
85 dB(A) inside. The noise level depends on the type of noise. H is high-frequency dominated noise, M is noise that is not
dominated by any given frequency, and L is low-frequency dominated noise.
On WS ProTac XP the criterion levels that are dened in EN352-4 is: L = 98dBa M = 102dBa H = 116dBa
6:4 Battery type
Many types of AA 1.2–1.5V batteries can be used (NiMH, NiCd, Alkaline), but only NiMH and NiCd batteries can be recharged.
6:5 Battery life
The expected battery life may vary depending on the brand of batteries and the temperature in which the product is used. Low
battery level is indicated by a voice saying: “low battery”. The headset functions will not work optimally if the battery is low.
2*AA Alkaline Battery Life time
Surround + Bluetooth (active) > 24h
Surround only + Bluetooth Off > 150h
6:6 Bluetooth 2.1
A2DP 1.2
HSP 1.2
HFP 1.5
AVRCP 1.0
The headset is designed for Bluetooth standard V.2.1 (headset and handsfree proles + A2DP) and is tested in
accordance with: EN 300 328-17 (radio test), EN 301 489-1/-17 (EMC test), EN 60 950-1 (electric safety), FCC part 15.247
(US radio test) and I.C. (Canadian radio test).
Safety information
Your wireless transceiver contains low power transmitter. When the transmitter is activated it sends out radio frequency (RF)
signals. This device is authorized to operate at a duty factor not exceed 50%.Use only the supplied antenna. Unauthorized
antennas, modications, or attachments could damage the transmitter and violate FCC regulations
7. STORAGE
Do not store the hearing protector at temperatures exceeding +55°C, for example on a dashboard or windowsill. Do not
store the hearing protector at temperatures below –55°C.
NOTE: WHEN DAMP. Turn the shells outwards. Remove the ear cushions (E) so that the attenuation cushions can dry.
Remove the batteries when storing the hearing protector for a long time. Check the functioning of the unit after replacing
the batteries. The recommended maximum shelf life is 5 years from date of manufacturing.
8. MAINTENANCE / CLEANING / DISPOSAL
After prolonged use, or other situations in which the headset attracts moisture inside the cups, remove the cushions and
inserts to allow the hearing protector to dry before its next use.
Do not store the headset in temperatures exceeding +55°C, for example on a car dashboard/hat shelf or window sill.
The headset (especially the ear cushions) can eventually wear out. Inspect regularly for signs of any physical damage and
replace if necessary. Certain chemical substances may be harmful to this product. Contact 3M for more information.
Clean/disinfect the shells, headband and ear cushions regularly with soap and warm water.
Notice! Do not immerse in water or uids.
This product is covered by the WEEE directive 2002/96/EC and is recyclable. Dispose of the product in accordance with
national regulation. Use a local recycling system for electronic products.
6 7
GB
WARNING!
The sound from the active-volume circuit on the hearing protector may exceed the external sound level.
This product is covered by the WEEE directive 2002/96/EC and is recyclable. Dispose the product in accordance with
national regulation. Use local recycling system for electronic products.
8:1 CLEANING
Clean/disinfect the shells, headband and ear cushions regularly with soap and warm water.
Note: Do not immerse in water or uids.
8:2 REMOVING/REPLACING EAR CUSHIONS
(E) Slide your ngers under the edge of the ear cushion and pull straight out.
Insert a new ear cushion by pressing until it snaps into place.
9. SPARE PARTS/ACCESSORIES
HY79 Hygiene kit
Easily replaceable hygiene kit consisting of two attenuation cushions, two foam rings and snap-in ear cushions. Replace at
least twice a year to ensure consistent attenuation, hygiene and comfort!
HY100A Clean – single-use protectors
A single-use protector that is easy to apply to the ear cushions. Package contains 100 pairs.
HYM1000 Mike Protector
Moisture and wind-proof with hygienic tape. Protects the speech microphone and enhances its life span.
Package of 5 meters for about 50 replacements. Contains natural latex, not recommended for use by sensitive persons.
M40/1 Wind shield for MT7-type speech microphones
Effective protection from wind noise. Enhances the life span and protects the speech microphone.
One per package.
M60/2 Wind shield for ambient microphones
Effective protection from wind noise. One pair per package.
MT7 Dynamic microphone
Microphone boom with dynamic microphone.
ACK053 Rechargeable battery pack
Rechargeable NiMH Battery pack, 2500 mAh.
1180 SV Battery lid
Battery lid for the use of 1.5 V batteries type LR6 (AA) (One lid is included in the package on delivery.)
FR09 Battery charger
Battery charger for the Peltor ACK053 accumulator battery.
Flex Connecting cable
Please contact your 3M Peltor dealer!
7
GB
WARRANTY
The warranty does not cover any damage caused by neglected maintenance
or careless handling. For more information on maintenance, please see the user instruction.
For complete warranty condition, contact your dealer or local 3M ofce.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by 3M is under license. Other trademarks and trade names are those of their respective owners.
3M does not accept liability of any kind, be it direct or consequential (including, but not limited to, loss of prots, business
and/or goodwill) arising from reliance upon any information herein provided by 3M. The user is responsible for determining
the suitability of the products for their intended use. Nothing in this statement will be deemed to exclude or restrict 3M’s
liability for death or personal injury arising from its negligence.
8 9
Declaration of Conformity
9
Certicates
10 11
Australia
3M Australia Pty. Limited
Building A, 1 Rivett Road
North Ryde, N.S.W. 2113
+61 1800 024 464
Austria
3M Österreich GmbH
Brunner Feldstraße 63 2380 Perchtoldsdorf
+43 01 86686 0
Azerbaijan
3M (East) AG
”BRIDGE Plaza” 4th oor,
12 Bakikhanov street Baku AZ 1065
+994 12 404 5050
Belarus
3M Belarus Representation Ofce
Mogilevskaya str 18, ofce 4220007
Minsk
+375 172 22 97 90
Belgium
3M Belgium N.V. / S.A.
Hermeslaan 7
1831 Diegem
+32 2 722 53 10
Bulgaria
3M Bulgaria Representation Ofce
1715 Soa, Mladost 4Business Park, sgrada 4
+359 2 960 19 11
China
41/F, Maxdo Centre, No.8 Xing Yi Rd.,
Hong Qiao Development Zone Shanghai,
200336 China
+86 021 22103047
Croatia
3M Croatia Representation Ofce
Predstavništvo, Žitnjak bbHRA 10000
Zagreb
+385 1 2499 750
Czech Republic
3M Česko, spol. s r. o.
V Parku 2343/24
140 00 Praha 4
+420 261 380 111
Denmark
3M a/s
Fabriksparken 15
DK-2600 Glostrup
+45 43480100
Egypt
3M Egypt
Sotel Tower,
Corniche el-Nil St.
19th Floor, Maadi, Cairo
+2 02 2525 9007
Estonia
3M Eesti lial
Mustamäe tee 410621 Tallinn
+372 6 115 900
Finland
Suomen 3M Oy PL 90,
Lars Sonckin kaari 602601
Espoo
+358 9 52 521
France
3M France
Bd de l’Oise
95006 Cergy-Pontoise cédex
+33 0810 331300
Germany
3M Deutschland GmbH
Carl-Schurz-Str. 1
41453 Neuss
+49 2131 14 26 04
Great Britain
3M United Kingdom
PLC3M Centre, Cain Road Bracknell,
RG12 8HT
+44 870 60 800 60
Greece
3M Hellas Limited
Κηφισίας 20151 25 Μαρούσι,
Αθήνα-Μαρούσι
+30 210 68 85 300
Hungary
3M Hungária Kft.
Váci út 140 1136 Budapest
+36 1 270 7777
India
3M India Limited
Corporate Ofce, Concorde Block, UB City,
24 Vittal Mallya Road Bangalore - 560001
+91 80 665 95 759
Ireland
3M Ireland
3M House, Adelphi Centre,
Upper Georges Street Dun Loaghaire,
Co. Dublin
+353 1 800 320 500
Israel
םדוהיה תנידמ ’חר 3M מ”עב לארשי
הילצרה 2042 .ד.ת 91
Italy
3M Italia S.p.A.
Loc. San Felice-Via San Bovio 3
20090 Segrate (MI)
+39 800 802145
Kazakhstan
3M Kazakhstan Representation Ofce
140 Dostyk Av., 3-rd oor
050051 Almaty
+7 727 237 47 37
Latvia
3M pārstāvniecība LatvijāK.
Ulmaņa gatve 5
LV-1004 Rīga
+371 67 066 120
11
Lithuania
3M atstovybė
Švitrigailos g. 11b
LT-03228, Vilnius, Lietuva
+370 5 216 07 80
Morocco
3M Morocco La Colline II, N°33 Rdc,
Route de Nouasser, Sidi Maarouf
Casablanca
+212 22 977 977
Netherlands
3M Nederland B.V.
Industrieweg 24
2482 NW Zoeterwoude
+31 071 5 450 450
New Zealand
3M New Zealand Limited
94 Apollo Drive, Rosedale, AUCKLAND 0632
+64 (0)800 364 357
Norway
3M Norge A/S,
Avd. Verneprodukter,Postboks 100,
Hvamveien 6,2026 Skjetten
+47 63 84 75 00
Pakistan
3M Pakistan (PVT) Ltd.
Islamic Chamber of Commerce Building ST-2/A,
Block 9, KDA Scheme 5,
Clifton-Karachi 75600
+ 92 21 111 2255 36
Poland
3M Poland Sp. z o.o.
Aleja Katowicka 117, 05-830 Nadarzyn
Kajetany K. Warszawy
+48 22 739 60 00
Portugal
3M Portugal Lda
Rua do Conde de Redondo 98
1169-009 Lisboa
+351 21 313 45 00
Romania
3M România
Bucharest Business Park,
Str. Menuetului 12, Cladirea D, et.3,
013713 Bucharest
+40 21 202 8000
Russia
RUZAO “3M Russia”
Krylatsky Hills Business Park,
Krylatskaya st., 17, bldg. 3
121614 Moscow
+7 495 784 7474
Serbia
3M Representation Ofce
Beograd Milutina Milankovica 2311070
Novi Beograd
+381 11 3018459
Slovakia
3M Slovakia Representation Ofce
Obchodné zastupiteľstvo
Vajnorská 142, 831 04 Bratislava
+421 2 491 05 211
Slovenia
3M (East) AG
Podružnica v LjubljaniCesta v Gorice 8,
SI-1000 Ljubljana
+386 1 2003 630
South Africa
3M South Africa
146a Kelvin Drive, Woodmead Sandton
2128 Rivonia
+27 011 806 2355
Spain
3M España,
S.A.Juan Ignacio Luca de
Tena 19-25, 28027 Madrid
+34 91 321 60 00
Singapore
3M Singapore Pte Ltd
3M Technologies (Singapore) Pte Ltd
1 Yishun Avenue 7
Singapore 768923
(65) 6450 8888 (Yishun)
Sweden
3M Svenska AB
Bollstanäsvägen 3
191 89 Sollentuna
+46 8 92 21 00
Switzerland
3M (Schweiz) AG
Eggstrasse 93,
Postfach 8803 Rüschlikon
+41 1 724 92 21
Taiwan
3M Taiwan
6F, NO. 95, Dunhua S. Rd.,
Sec. 2 Taipei, Taiwan
886 2 27049011
Turkey
3M Sanayi ve Ticaret A.Ş
Şehit Sinan Eroğlu Cad
Suryapı Akel İş Merkezi No:6
A Blok Kavacık Beykoz
34805 İstanbul
(90) 216 538 07 77
Ukraine
3M Ukraine30-B,
Fizkultury St., Business center“Farenheit”
3rd oor, Kyiv, 03680,
+380 44 490 57 77
United Arab Emirates
3M Gulf Ltd
P.O. Box 20191 Building 11,
Third Floor, Dubai Internet City,
Deira
+ 971 4 367 0777
12 MB
3M Svenska AB
Box 2341
SE-331 02 Värnamo, Sweden
t: +46 (0) 370 65 65 65
f: +46 (0) 370 65 65 99
e: www.3M.com/peltorcomms

Navigation menu
