ALPS ALPINE 9ZUA130 Bluetooth Module User Manual

User Manual

Installation Manual

This module board is to be installed only by the professional line operator and used only for

car audio produced by ALPINE ELECTRONICS, INC.. When this Bluetooth Module

Board is installed in the Car Audio, we shall consider the following points;

1. Since “IAM2.1 BT PWB US”owns its FCC ID/IC Number, we shall affix an exterior label on

the outside of the product if the FCC ID is not visible. The exterior label shall use wording such

as either ”Contains Transmitter Module Board FCC ID: A269ZUA130 / IC: 700B-IAM2101” or

“Contains FCC ID: A269ZUA130 / IC: 700B-IAM2101”.

2. “IAM2.1 BT PWB US” complies with requirements of sub-sections 15.19(a)(3) in FCC Rules

Part 15 Subpart C. The manual statement 15.19 (a)(3) is included User Guide of the product.

3. “IAM2.1 BT PWB US” is to be installed only by the professional line operator as shown in

following pictures. (Fig 1 and 2)

Fig 1. Front side of “IAM2.1 BT PWB US”

BT Part

Installation Manual

Fig 2. Front view of “IAM2.1 BT PWB US” to be equipped for a Car Audio (example)

here isn’t an official user manual for this Bluetooth Module Board “IAM2.1 BT PWB US”.

However, user manuals of final product, which have Bluetooth module board, must contain

notification corresponding to the following description.

Changes or modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

This device complies with Part 15 of FCC Rules and RSS-Gen of IC Rules. Operation is subject

to the following two conditions: (1) this device may not cause interference, and (2) this device

must accept any interference, including interference that may cause undesired operation of

this device.

This transmitter must not be co-located or operated in conjunction with any other antenna

or transmitter.

This equipment complies with FCC/IC radiation exposure limits set forth for uncontrolled

equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to

OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very

low levels of RF energy that it deemed to comply without maximum permissive exposure

evaluation (MPE). But it is desirable that it should be installed and operated with at least 20cm

and more between the radiator and person’s body (excluding extremities: hands, wrists, feet

and ankles).

IAM2.1 BT PWB U
