User’s Manual
Switch Assy Immobilizer Antenna
Model No.: TWK1A001
There is no User’s Manual because this equipment will not be sold to end-
user directly.
The connector is arran
g
ed as shown in the fi
g
ure below
.
■CAUTION■
DC6.5V～16V
A
C/DC Suppl
y
Operating voltag
e
DC6.5～16V(Inner:DC 5V)
DC12V
Range of voltage
Consumption curren
t
Under 0.7mA（Standby current）
W45xL72xH45（mm）
FCC WARNING
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Size
・Give a shock.
・Get it wet. If it got wet, wipe and dry up.
・Disassembly and modification.
This device complies with Part 15 of FCC Rules and RSS-Gen of IC
Rules. Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of
this device.
Operation of frequenc
y
125kH
z
User's Manual
It communicates with IC used both as Transponder and Passive RKE
through LF ANT(Z axis) of I-key H/U, and operates as ANT to exchange
communication data depending on community signal with BCM.
The immobilizer antenna communicates with the transponder in the
hand unit when the hand unit is brought close, and receives the code of
the key. The immobilizer is used by bringing the hand unit close as shown
in figure.
Product name : Switch Assy Immobilizer Antenna
Type : TWK1A001
Please DO NOT the following. Engine is not started by failure of
electronic parts. (Product can not receive the signal correctly)
Pay attention to the following.
(The operation range might be changed by the environment. )
・Do not contact and bring metals close to the engine SW and the
key.
・It may not be operated when using the equipment of the same
frequency band in the vicinity.
Operating temperatur
e
range
-40~＋85 degree C
MAX 0.7mA(@12.5V 25℃) at standby
Weight 0.04kg
Consumption curren
t
s
p
ec
MAX 150mA(@12.5V 2
5
℃) at operation
HUND UNIT SWITCH ASSY IMMOBILIZER
