ALPS ALPINE WK1A0028 Immobilizer base station User Manual 05
Alps Electric Co., Ltd. Immobilizer base station 05
(Short-Term Confidential) User Manual
The connector is arran
g
ed as shown in the fi
g
ure below
■CAUTION■
Operatin
g
temperatur
e
range -40~＋85 degree C
MAX 1.0mA(@12.5V 25℃) at standby
Weight
Please DO NOT the following. Engine is not started by failure of
electronic parts. (Product can not receive the signal correctly)
Pay attention to the following.
(The operation range might be changed by the environment. )
・Do not contact and brin
g
metals close to the en
g
ine SW and th
e
key.
・It may not be operated when using the equipment of the same
frequency band in the vicinity.
0.054kg
Consumption curren
t
spec MAX 200mA
(@
12.5V 2
5
℃
)
at operation
User's Manual
It communicates with IC used both as Transponder and Passive RKE
through LF ANT(Z axis) of I-key H/U, and operates as ANT to exchange
communication data depending on community signal with BCM.
The immobilizer antenna communicates with the transponder in the hand
unit when the hand unit is brought close, and receives the code of the key.
The immobilizer is used by bringing the hand unit close as shown in
Product name : Immobilizer base station
Type : TWK1A0028
FCC WARNING
Chan
g
es or modifications not expressl
y
approved b
y
the part
y
responsibl
e
for com
p
liance could void the user’s authorit
y
to o
p
erate the e
q
ui
p
ment
Size
・Give a shock.
・Get it wet. If it got wet, wipe and dry up.
・Disassembly and modification.
This device complies with Part 15 of FCC Rules and RSS-Gen of IC
Rules. Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of
Operation of frequency 125kHz
DC6V～16V
AC/DC Supply
Operating voltage DC6～16V(Inner:DC 5V)
DC12V
Range of voltage
Consumption current Under 1.0mA（Standby current）
W40.2xL70xH40.2（mm）
HUND UNIT Immobilizer base station
CONNECTORPINLAYOUT
