User Manual
Model AQ-DM-2R
TM TM
Water/Dust Proof MP3/iPod Digital Media Locker
With
Floating RF LCD Wireless Remote Control
INSTRUCTION MANUAL
Please read this Instruction Manual
before installation and operation
MODEL: AQ-DM-1R
FILE NAME: IB-STI-IDK2-14, 080517.cdr
MHz
EXT
TM
iPod + MP3
iPod classic
80G, 160G
iPod nano 3G
4G, 8G
iPod touch
8G, 16G
iPod 5G
30G, 60G, 80G
TM
TMTMTM
TM
AQ-DM-1R
AQ-RFDM-1
Keep Dry
R
1
3
4
5
6
7
8
9
1
10
TM TM
MP3/iPod Water/Dust Proof Digital Media Locker
LOCATION OF CONTROLS
2
AQ-DM-1R
Keep Dry
1
2
3
4
5
6
7
8
9
10
Digital Media Locker Knob and Protective Door
ON/Off Power Button
Water/Dust Protection Inner Gasket
3.5mm Aux Input Jack for MP3 Devices
Water Retarding and Drainage Groove
ON/Off Power LED
TM
Security Strap for Digital Media Devices (MP3/iPod )
TM
iPod Connector
TM
iPod Cradle (totally 5 iPod Cradle adaptors)
Part Description
Auxillary Locker Knobs
TM
INSTALLATION
Cable Connection
CONTENTS:
Please make sure the following items are included.
TM
a) AQ-DM-1R Digital Media Locker
b) Water/Dust Proof RF Wireless Remote Control
c) Six (6) Finishing Covers for Stainless Mounting Screws
TM
d) Five (5) iPod Cradles
e) One (1) CR-2032 batteries
3
GETTING STARTED
12 pin
Harness Cable
RCA Output Jack
FM Radio
Antenna
Left Audio
Right Audio
FM Radio: The AQ-DM-1R has U.S. and Euro FM Frequency capability.
In both applications, make sure the FM Antenna is fully extended at the
highest possible level (Height) for best performance.
2.
Plug and Play Connector: The AQ-DM-1R incorporates a 12 pin "plug
and play" connector harness. Owner product application options may
require an "optional" connector option. Contact your dealer for details.
1.
3. RCA Inputs: The AQ-DM-1R was developed with flexibility to use RCA
based Audio Media. The AQ-DM-1R has 1 set of RCA Audio Auxiliary
Inputs so you can connect other RCA based devices.
For non-OEM use, wiring harness must be
ordered separately
Part number AQ-UNH-1 or AQ-UNH-2
AQ-DM-1R
Keep Dry
A
B
A
B
C
Remote Control LCD
Remote Control Buttons
Battery Door.
Part Description
C
2
RF LCD Wireless Remote Control
LOCATION OF CONTROLS
TM
if your music player is not an IPod,
You will only be able to use the volume and power control on the remote
MHz
EXT
Music Mode FM Radio Mode
Press once: Change from Operation mode to Standby mode.
Press and hold: Change from Standby mode to Operation mode.
Press once: Volume DOWN 3 decibels
Press and hold: Fast volume down
Press once: Volume UP 3 decibels
Press and hold: Fast volume up
Press once: Toggle external power
Press and hold: No change
Press once: Change to FM Radio Mode
Press and hold: No change
Press once: No change to Ipod/ MP3
Press and hold: No change to Ipod/ MP3
Press once: No change to memory
Press and hold: No change to memory
Press once: No change to memory
Press and hold: No change to memory
Press once: No change to memory
Press and hold: No change to memory
Press once: Last track
Press and hold: Fast Rewind
Press once: Toggle Play/Pause
TM
Press and hold: Turn iPod OFF
Press once: Next track
Press and hold: Fast Forward
Press once: No change
Press and hold: No change
Press once: Toggle to ipod/ Music Mode
Press and hold: No change
Press once: Decrease Memory Location
Press and hold: No change
Press once: Toggle to Memory Mode
Press and hold: No change
Press once: Increase Memory Location
Press and hold: No change
Press once: -50kHz
Press and hold: Scan backward
Press once: Mute
Press and hold: No change
Press once: +50kHz
Press and hold: Scan forward
Press once: Volume DOWN 3 decibels
Press and hold: Fast volume down
Press once: Volume UP 3 decibels
Press and hold: Fast volume up
Press once: Toggle external power
Press and hold: No change
Buttons
Power
12V
trigger
Volume
up
Volume
down
FM Radio
Memory +
Memory
Memory -
Music
Fast
Rewind
Pause/
Play
Fast
Forward
Control
AQ-RFDM-1
In order to prolong remote battery life the LCD will shut off in 10 seconds if no
other button is pressed. To turn remote back on press power once and then
press the command desired.
Open
Close
I
I
5
Remove the Water/Dust Proof RF Wireless Remote control from the Digital
TM
Media Locker . Unscrew the waterproof cap on the back of the remote control ,
place the CR-2032 in the RF Remote control and replace the waterproof cap.
Always activate the on-off button when operating the Digital Media
TM
Locker . By doing so, your battery life will be extended.
The remote control LCD will display " - -" whenever it is turned ON.
TM
This display will remain until Radio mode or iPod mode is selected.
The LCD will also display " - -" if it is out of its 20ft range.
This remote control use state-of-art technology and will inform you if the
dock is receiving the command from the remote control. In any case,
if the LCD display "- -" again in either mode, this means that your
remote control is out of range of reception. Please try the feature again.
Important Notes on the Use of Remote Control
GETTING STARTED
Power ON Button
TM
To activate the Digital Media Locker , press the on/off button. On will be
indicated by a RED LED.
TM
For applications where normal Digital Media Locker operation requires an
independent 12V battery (Boat, RV), power down the AQ-DM-1R via the RF
remote control. This will insure against independent battery drain. Other
applications using 12V power converters are compatible with the AQ-DM-1R.
RF Wireless Remote Control Synchronizing
If you loose your remote control and buy another new remote control, please follow the
above to start pairing before normal usage.
Always ensure to connect and disconnect your media player
with dry hands.
MHz
EXT
TM
Each Digital Media Locker comes with a matching RF Wireless LCD Remote
control to maximize wireless performance. For all newly purchased remote
controls, you will need to activate/Synchroize those remote controls to the
AQ-DM-1R by following the steps below:
a. Press and hold the button (Memory) on the remote control and then
press the Power button simultaneously for 2 seconds.
The LCD will display "Pair".
TM
b. Turn on the Digital Media Locker by pressing the power button on the
AQ-DM-1R within 10 seconds after the remote is paired.
(A Red LED light will turn on under the power button to indicate the unit is
turned on.)
c. Once synchronizing is complete, the LCD will return to the
original screen setting.
MHz
EXT
Once the mounting hole is complete, make sure
the outside surface is clear of debris. The
AQ-DM-1R has an external water/dust proof
gasket, but it needs a clean surface for best
performance.
2.
Mounting templates are included. Aquatic Av
recommends to utilize the "measure twice, cut
once" Method.
1.
Review all outside surfaces of the AQ-DM-1R to insure proper water/dust
seal. This is important for the long term environmental protection
performance for iPod or MP3 devices.
4.
The AQ-DM-1R has six (6) front loading mounting
points with "smart locking" Media Locker clamps.
Each will deploy as you begin the installation.
During final mounting, apply equal pressure to
all points for best water/dust outer seal performance.
3.
After the installation is complete, install the finishing covers over the
stainless screws with silicone. We recommend a marine grade silicone as
an adhesive.
5.
Mounting the Unit
External
Trigger +12VDC (7)
DC Ground (10)
LR-(2) +12VDC(1)
LR+(3)
LF-(5)
LF+(6)
RF-(8)
RF+(9)
Not connected (4)
RR-(11)
RR+(12)
FUS E BOX
Left Rear Speaker
+
-
Left Front Speaker
+
-
+
-
+
-
Right Front Speaker
Right Rear Speaker
Please put a
fuse into the box
4
(Red color)
(Blue color)
(Green/Black color)
(Green color)
(White/Black color)
(White color)
(Gray/Black color)
(Gray color)
(Purple color)
(Purple/Black color)
(Black color)
12 Pin Harness Cable Connection
GETTING STARTED
Aquatic AV recommends the use of a optional "plug and play" connector for best
performa nce (AQ-UNH-1). This connector is not included.
For detailed information, please call the re-seller. If you choose
not to use the "plug and play" option, you can use the wiring schema tic below.
All open wire connections should be soldered, and protected against
Water/Dust for best long term performance.
8 ohm
8 ohm
8 ohm
8 ohm
Must use 8 ohm speaker or
damage may occur to the AQ-DM-1R
(Yellow color)
AQ-DM-1R
Keep Dry
6
TM
Power up the Digital Media Locker .
TM
Secure the iPod device with the anchor straps provided.
1.
4.
Press and hold (POWER) on the remote control to turn it
ON. The LCD will show "--" as shown on the right.
6.
TM TM
Attach your iPod device to the iPod 30 pin connector. 3.
Press (MUSIC) on the remote control to change to Music Mode. Use
below buttons for the features.
7.
SOURCE
Last Track
Press onceButton Press and Hold
Fast Rewind
Toggle Play and Pause
TM
Turn iPod Sleep
Next Track
Fast Forwarding
Listening to MP3
Adjusting Volume Level
Press (VOLUME UP) once to increase the volume by 3 decibels. 1.
Press (VOLUME DOWN) once to reduce the volume by 3 decibels. 2.
TM
Press and hold either UP or DOWN and the Digital Media Locker will
increase or decrease audio volume continuously.
3.
TM
Listening to iPod :
LISTENING TO PLAYERS
TM TM
If you are listening iPod and you change your mode to Radio or standby mode, the iPod will
automatically turned OFF. The Charging screen will appear.
TM
Secure the digital media locker water/dust protective door.
5.
TM
1. Power up the Digital Media Locker .
2. Attach the MP3 device to the 3.5mm connector.
3. Secure the MP3 with anchor straps provided.
TM
4. Secure the Digital Media Locker water/dust protective door.
5. RF Wireless remote Control of Volume only.
2. Take Plastic cover off 30 pin connector and replace when not in use. .
MHz
EXT
MHz
EXT
7
M+M+ M-M-
Saving Radio Channel to Memory
Press (MEMORY) once to toggle to memory mode.
MEMMEM
Press (MEMORY +) or (MEMORY-) to change
the location of memory.
1.
Press and hold (MEMORY) to save the previous
shown frequency to the location.
2.
MEMMEM
Press (MEMORY) once to toggle to manual mode.
3.
MEMMEM
If you want to save ths current frequency into memory.
MHz
4.
Press (FM RADIO) on remote control to change to
FM radio mode. If this is the first time you listen
to FM radio, the frequency will be 88.1MHz as a defualt as shown on the
remote LCD.
1. FMFM
MHz
EXT
Press (FAST REWIND) or (FAST FORWARD) change
channel in increments of 50kHz.
1.
M+M+ M-M-
MHz
Listening Saved Radio Memory
Press (MEMORY) once to toggle to memory mode. 1. MEMMEM
Press (MEMORY+) or (MEMORY-) to change the
location of memory.
2.
Press (MEMORY) once to toggle to manual mode. 3. MEMMEM
MHz
MHz
Press and hold either (FAST REWIND) or (FAST
FORWARD) will scan forward or back for the next station.
A "Scan" will appear on the LCD.
2.
Radio Mode
LISTENING TO FM RADIO
FM radio is only available when you are in the FM Radio Mode.
MHz
MHz
MHz
MHz
FM radio is only available when you are in the FM Radio Mode. FM radio is only available when you are in the FM Radio Mode.
To Enter FM Radio Mode:
To Scan or Navigate Channels:
TM
iPod Charging
TM
When specified iPod devices are connected to the AQ-DM-1R 30 pin
TM
connector, iPod battery will charge.
8
Amplifier Sleep Mode
TM
The Digital Media Locker's power amplifier will automatically go into "Sleep"
mode in about 5 minutes of no audio sensing. For applications with the 12V
independent battery operation, this will extend the battery life. Maximum
power drain during "Sleep Mode" is 10mA.
In any operational mode, press the lightning bolt (12V
TRIGGER) key to activate. Press again to deactivate.
We strongly recommend you to speak with our tech service staff or your
dealer if you're are considering to activate this feature.
2.
External Trigger
1.
MHz
EXT
OTHER FEATURES
Aquatic AV understands the need for more flexible remote applications. With
the Digital Media Locker, Aquatic AV has provided an independent 12V
"accessory" trigger, activated by the RF Wireless Remote that provides user
to activate non-iPod, MP3 related devices. This could include any 12V based
devices like 12V lights or surveillance camera.
Remote Control LCD Auto OFF
To maximize battery life of the RF Wireless Remote Control, the LCD of the RF
Wireless Control remote will be OFF if no key is pressed in 10 seconds. To
re-activate the LCD display, press (POWER) once to bring the remote
control to normal operation.
Load on External Trigger should not exceed 300mA.
9
TM
iPod Cradles
TM
iPod Cradles and Replacing iPod 30pin Connectors
TM
There are 5 cradles included for docking below iPods :
TM
iPod classic 80GB;
TM
iPod 5G 30GB
TM
iPod classic 160GB;
TM
iPod 5G 60GB, 80GB
TM
iPod touch 8GB, 16GB
TM
iPod nano 3G, 4GB, 8GB
TM
iPod 30 pin Connector Replacement
1
2
2
3
4
5
5
1
2
35
4
iPhone
TM
Under harsh operation conditions, the iPod 30pin Connector may deteriorate.
TM
To ensure best performance, you can buy a new iPod 30pin Connector for
replacing the deteriorated 30pin connector.
TM
Inspect the 30pin iPod connector for deterioration, water, rust, or damaged
terminals before each use frequently to avoid operational problems or
TM
damage to the iPod . Check the connector each time before inserting the
TM
iPod . Always Replace the 30 pin connector cover after every use.
TM
Order iPod connectors
(408) 559-1668 or a
local dealer
Follow below steps to change for the 30pin connector.
1. Pull out the cradle.
2. Unscrew the two (2) mounting screws.
TM
3. Pull out the iPod 30pin connector.
4. Replace the new one.
5. Replace the cradle.
Keep Dry
Keep Dry
Keep Dry Keep Dry
Keep Dry
Technical Specification
Power Supply
Digital Amplifier Output
FM Radio Sensitivity
FM antenna
Remote Control Frequency
Remote Control Battery
External Trigger
12V 5A min.
50W rms per channel at 4Ohm Speaker
8uV
Pigtail antenna
2.4GHz
3.0V (1 pc CR3123)
12.0V, 300mA max.
:
:
:
:
:
:
:
TM
iPo d is a trademark of Ap ple Computer, Inc., registered in the U.S. and other countries.
SPECIFICATION
Auto Amplifier Standby Mode 5 minutes +/- 10 seconds
:
Current drain when OFF <1mA
:
Current drain in Standby Mode <10mA
:
FM Radio
Digital Amplifier
General
Distortion <0.1% THD at 1kHz
:
Frequency Response 20Hz - 20kHz
:
FM Radio Reception Stereo
:
Number of Preset 6
:
IP Rating
IP66
:
UV
500 hours of UV without degradation
:
Remote Water/Dust Rating IP66
:
10
FCC STATEMENT
10
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
NOTE:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment. Such
modifications could void the user authority to operate the equipment.
FCC ID: WBQAQPAVRFMPIP
MADE IN CHINA
