ARGtek Communication Inc. 802.11 b/g/n WLAN USB Adapter Data Sheet DOME BASE 1225

Manual 1

ARGtek Palm Plus WLAN USB Adapter which fully supports the features and functional compliance of IEEE 802.11 b/g/n
standards and operate in 2.4GHz bands. It enables the deployment the latest updated QoS–WMM, WMM-PS ,support
MIMO, connectivity at high throughput from an extended distance and giving end users the greatest performance
Features
■ Cisco CCX Suppotr up to v5.0
■ 2.4GHz unlicensed ISM frequency band
■ Support QoS – WMM, WMM-PS, MIMO
■ Support USB 2.0 interface
■ WEP 64/128-bit , WPA, WPA2 support
■ Multiple BSSID Support
■ Software AP mode
802.11 b/g/n WLAN USB adapter
(DOME BASE)
Specifications
Standard IEEE 802.11b, IEEE 802.11g, IEEE802.11n
Frequency Band 11b/g/n 2.4GHZ
Data Rate 802.11b: Up to 11 Mbps
802.11g: Up to 54 Mbps
802.11n: Up to 300Mbps
LED indicators Active/Power
Interface USB2.0
Antenna Internal printed antenna*1
7dBi RP-SMA panel antenna*1
Transmitter Power 802.11b 24 ± 2 dBm
802.11g 21 ± 2 dBm
802.11n 20 ± 2 dBm
Receive Sensitivity -75dBm@802.11n -73dBm@54Mbps
-86dBm@11Mbps -92dBm@1Mbps
Operating Range Up to 500M, depending on surrounding environment
Power Consumption Transmit:<500mA, Receive:<300mA
Security 64/128-bit WEP, WPA, WPA2
Operating System Windows XP/98SE/ME/CE/2000, Vista , Linux and Apple Mac
Operating Temperature
0~55 Celsius
Storage Temperature -10 ~ 70 Celsius
Humidity 5~90%(non-condensing)
Dimension 9.3(L) x 6.4(W) x 2.1 (H) cm
