ARRIS AW500 WiFi 802.11AC 2x2 5GHz Wireless Adapter User Manual
Pace Americas WiFi 802.11AC 2x2 5GHz Wireless Adapter
ARRIS >
User Manual
BRINGING TECHNOLOGY HOME
www.pace.com
USER GUIDE
Pace Mi3
IPW9001
2
Mi3 (IPW9001) USER GUIDE (501-2C14501)
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of
Dolby Laboratories.
HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of
HDMI Licensing LLC in the United States and other countries.
TiVo and the TiVo logo are trademarks or registered trademarks of TiVo Inc. or its subsidiaries worldwide.
Other trademarks listed herein are the property of their respective owners.
© 2015 Pace plc. All rights reserved. Pace and are trademarks and/or registered trademarks of Pace plc
This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights.
Use of this copyright protection technology must be authorized by Rovi corporation, and is intended for home and other limited
pay-per-view uses only unless otherwise authorized by Rovi corporation. Reverse engineering or disassembly is prohibited.
SAFETY INFORMATION ..................................................................................................3
IMPORTANT SAFETY INSTRUCTIONS ...........................................................................3
Safety aspects of connections ...................................................................................5
Regulatory information .............................................................................................. 5
REAR PANEL .................................................................................................................. 6
CONNECTING THE EQUIPMENT.....................................................................................7
Possible setups .........................................................................................................7
Connecting your equipment .......................................................................................8
Connecting the power supply unit to your set-top box ..............................................9
Connecting equipment to the wall AC outlets ............................................................9
Turning your set-top box on and off ..........................................................................9
Lightning storms .......................................................................................................9
Front panel.................................................................................................................9
OPTIONAL WIFI ADAPTER ...........................................................................................10
Regulatory information ............................................................................................ 10
Having a WiFi adapter fitted .....................................................................................10
Starting the WiFi connection ....................................................................................10
Disconnecting your WiFi adapter ............................................................................. 10
Reconnecting your WiFi adapter ..............................................................................11
APPENDIX FOR PROFESSIONAL FITTERS ...................................................................12
TERMS AND CONDITIONS FOR USE OF SOFTWARE (“TERMS”) ................................13
CONTENTS
3
Mi3 (IPW9001) USER GUIDE (501-2C14501)
This digital set-top box has been manufactured and tested with your safety
in mind. However, improper use can result in potential electric shock,
property damage or fire hazards. To avoid defeating the safeguards that
have been built into your set-top box, please observe the precautions
discussed in this document.
To ensure correct operation, use this set-top box only with the Pace-
approved power supply unit provided. If you use an unapproved
alternative, you will invalidate the warranty.
Other warnings
To reduce the risk of electric shock, do not remove the cover of your set-
top box. There are no user-serviceable parts inside it.
Do not perform any servicing unless you are qualified to do so. Refer all
servicing to qualified service personnel. Servicing the set-top box yourself
will invalidate the warranty.
To reduce the risk of fire or electric shock, do not expose this set-top box
to rain or moisture.
On the rear panel of your set-top box there is a tamper-evident label that
states ‘Warranty void if broken or removed’.
Caution
Do not attempt to modify your set-top box without written authorization
from the manufacturer. Unauthorized modification could void your
authority to operate your set-top box.
Failure to heed the Safety Information provided by failing to connect to a
properly wired outlet may void the manufacturer’s warranty.
Installation
The installation of your set-top box should be carried out by a qualified
installer and should conform to local codes.
Note to the installer
This reminder is provided to call the attention of the cable-TV-system
installer to Section 820 of the National Electrical Code (USA), which
provides guidelines for proper grounding and, in particular, specifies
that the cable ground shall be connected to the grounding system of the
building, as close to the point of cable entry as is practical.
IMPORTANT SAFETY INSTRUCTIONS
Before you install or use the apparatus, you must read and
understand these Important Safety Instructions.
At all times when using the apparatus you must follow
these Important Safety Instructions to reduce the risk of fire,
electrical shock and injury to persons.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit into the outlet,
consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
Service address:
Pace Americas Inc.
3701 FAU Boulevard, Suite 200, Boca Raton, Florida 33431 U.S.A.
The lightning flash with arrowhead symbol, within a triangle,
is intended to alert you to the presence of uninsulated
“dangerous” voltages within your set-top box’s enclosure
that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within a triangle is intended to alert
you to the presence of important instructions in the literature
accompanying your set-top box.
Warnings on the power supply unit
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
SAFETY INFORMATION
4
Mi3 (IPW9001) USER GUIDE (501-2C14501)
In addition to the Important Safety Instructions, please read the Safety
Information below.
Power sources
The model number, serial number, and electrical rating of this set-top box
are on a label on its base.
You must operate your set-top box only from the type of power source
indicated on the marking label. If you are not sure of the type of power
supply to your home, consult your dealer or local power company. If you
move your set-top box between locations at different temperatures, allow it
to reach room temperature before you apply power to it.
Overloading
Do not overload wall AC outlets, extension cords or other power outlets as
this can result in a risk of fire or electric shock.
To avoid possible damage to your set-top box or to a connected TV or
component, all AC power cords must be plugged into properly wired
outlets. As with all electrical products, connection to faulty or defective
components, or the failure to connect your set-top box to a properly wired
outlet, may cause sparking, property damage or damage to any TV or other
component connected to your set-top box and pose a fire hazard.
Lightning
For added protection for your set-top box during a lightning storm, or when
it is left unattended and unused for long periods of time, disconnect your
set-top box from the power supply and disconnect the cable system from
your set-top box. See also item 13 in the Important Safety Instructions.
Ambient temperature
The operating temperature range of your set-top box is 32-104°F. If the
ambient temperature around your set-top box falls outside this range, you
must correct this in order for your set-top box to work correctly and safely.
For example, if the temperature is too high, make sure there is sufficient
ventilation (see below) and that your set-top box is not directly on top of or
underneath other equipment.
Ventilation
Slots and openings in the casing of your set-top box are provided for
ventilation, to ensure reliable operation of your set-top box and to protect it
from overheating.
• Never block the ventilation
openings by placing your set-top
box on a bed, sofa, rug, or other
similar surface. Place it on a
hard, flat surface.
• Never cover the ventilation
openings with items such as
newspapers, table-cloths, or
curtains.
• You can place your set-top box
near other consumer electronics
devices, such as stereo
amplifiers or televisions, but you
must not place it directly on top or underneath them.
3 in.
3 in.
3 in.
• Do not place your set-top box in a built-in installation such as a
bookcase or rack unless proper ventilation is provided and you have
adhered to the manufacturer’s instructions.
• Maintain a minimum distance of three inches around your
set-top box for sufficient ventilation.
See also item 7 in the Important Safety Instructions.
Water and moisture
Do not expose your set-top box to rain or moisture, dripping or splashing,
and ensure that no objects filled with liquids, such as vases, are placed on
your set-top box. See also item 5 in the Important Safety Instructions.
Entry of objects and liquids
Never push objects of any kind into your set-top box through openings
as they may touch dangerous voltage points or short-out parts that could
result in fire or electric shock. Never spill liquid of any kind on your set-
top box.
Transporting
Move the combination of set-top box and cart with care. Quick stops,
excessive force and uneven surfaces may cause the combination of
set-top box and cart to overturn. See also item 12 in the Important Safety
Instructions.
Placement and mounting
Do not place your set-top box on an unstable or uneven surface. Your
set-top box may fall, causing serious injury to a child or adult and serious
damage to your set-top box. If you mount your set-top box, for example
to a wall or ceiling, follow the manufacturer’s instructions and use a
mounting accessory recommended by the manufacturer. See also item 12
in the Important Safety Instructions.
Risk of fire or scorching
Never place naked flame sources, such as lighted candles, on or adjacent
to your set-top box.
Replacement parts
When replacement parts are required, be sure that the service technician
has used replacement parts specified by the manufacturer or that have
the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock or other hazards. See also item 14 in the
Important Safety Instructions.
Safety check
Upon completion of any servicing or repairs to your set-top box, ask the
service technician to perform safety checks to determine that your set-top
box is in its proper operating condition. See also item 14 in the Important
Safety Instructions.
SAVE THIS INFORMATION FOR FUTURE REFERENCE
SAFETY INFORMATION (cont.)
5
Mi3 (IPW9001) USER GUIDE (501-2C14501)
Safety aspects of connections
Full details of the rear panel are on page 6.
Connecting
Do not connect your set-top box (or any other equipment such as a TV or
DVD player) to the power supply until you have properly connected all the
other cables.
Your set-top box is designed for use only with the power supply unit provided.
On the power supply unit there is a label that specifies the correct AC
power supply input for it. Do not connect the power supply unit to any
supply other than this.
Always connect the 5 volt DC cord from the power supply unit to your set-
top box before you insert the power supply unit into the wall AC outlet.
Disconnecting
To disconnect power from your set-top box, always detach the power
supply unit from the wall AC outlet (rather than remove the 5 volt cord
from your set-top box).
Therefore you must install your set-top box near to the wall AC outlet,
which should be easily accessible.
If you are in any doubt about the power supply cord, its plug or its
connection, or are not certain that the electrical outlets you are using
are properly wired and grounded, consult a qualified electrician before
proceeding any further.
SAFETY INFORMATION (cont.)
The Cable In connector is designed for
connection to a cable network only.
You must not connect any other
equipment, such as a VCR, to this input.
Power Input
Regulatory information
NOTE
Part 15 of FCC rules
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC RF Radiation Exposure Statement
MPE/SAR/RF Exposure Information.
This equipment complies with FCC RF radiation exposure limits set
forth for an uncontrolled environment.
This equipment was verified for RF exposure and found to comply with
Council Recommendation 1999/519/EC and FCC OET-65 RF exposure
requirements.
WARNING: While this equipment is in operation, a separation distance
of at least 20 centimeters (equal to 8 inches) must be maintained
between the antenna inside the equipment and the bodies of all
persons exposed to the antenna in order to meet the FCC RF exposure
guidelines. Making changes to the antenna or the equipment is not
permitted. Doing so may result in the equipment exceeding the FCC
RF exposure guidelines. This equipment must not be co-located or
operated in conjunction with any other antenna or radio transmitter.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Changes or modifications not expressly approved by the
party responsible for compliance could void your authority to operate
this equipment. Failure to heed the Safety Information provided by
failing to connect to a properly wired outlet may void the manufacturer’s
warranty.
5 volt power
supply unit
To ensure correct operation, use
this set-top box only with the Pace-
approved power supply unit provided.
If you use an unapproved alternative,
you will invalidate the warranty.
6
Mi3 (IPW9001) USER GUIDE (501-2C14501)
REAR PANEL
CABLE IN
From cable
service-provider
POWER
(Make this
connection
last of all)
ETHERNET
For future use
COMPONENT
Video output for
analog HDTV
USB
For future use
HDMI
Video and audio output
for digital HDTV
CABLE IN Connect the cable service here.
TO TV Connect to the RF/antenna input on your TV.
COMPONENT If your HDTV does not have an HDMI connector, but has component video (YPbPr) inputs, connect your HDTV here.
AV Combined standard-definition (SD) video and stereo audio output. Connect to the composite video and analog audio
inputs on your SDTV.
HDMI Connect to the HDMI input on your HDTV.
DIGITAL AUDIO Connect to the optical digital audio input on optional digital audio equipment, such as an audio decoder or home
theater receiver.
ETHERNET For future use.
USB For future use.
+5.0V DC IN 3A MAX. POWER Connect your set-top box’s power supply unit here. Make this connection last of all.
AV
Combined SD
video and stereo
audio output
DIGITAL AUDIO
Optical S/PDIF
audio output
TO TV
RF output to TV
7
Mi3 (IPW9001) USER GUIDE (501-2C14501)
WARNINGS
Do not connect your set-top box
(or any other equipment such as
a TV or DVD player) to the power
supply until you have properly
connected all the other cables.
Disconnect your set-top box’s
power supply unit from the
AC power supply before you
disconnect any other equipment
from its rear panel.
The only way to disconnect your
set-top box from the AC power
supply is to remove the power
supply unit from the wall AC outlet
(or switch the wall AC outlet switch,
if present, to its OFF position).
Your set-top box must therefore be
installed near to the wall AC outlet,
which should be easily accessible.
The cable input is designed for
connection to a cable network only.
You must not connect any other
equipment, such as a VCR, to this
input.
Possible setups
In order for you to view programs broadcast in high-definition, your set-top box must be connected to a
suitable HDTV or computer monitor.
Your equipment should have been connected up by your installer. However, if you need to disconnect and
reconnect your equipment, read page 8.
The setups shown on page 8 make efficient use of the connectors on your set-top box. However, depending
on your other equipment and the connectors on it, the person who installed your system may have chosen to
connect things differently.
Room 1 shows a typical media-server setup, with a media server connected to a high-definition TV via an
HDMI cable. Rooms 2, 3, and 4 show three different setups for your IPW9001 set-top. For each IPW9001
set-top, choose the setup that best matches the equipment you have.
Room 2: HDTV using an HDMI connection
This setup uses an HDMI connector to connect to the HDTV. This displays the highest quality picture on the
HDTV and also means there will be no picture degradation on any copy-protected programs (provided the link
remains secure – see below).
Room 3: HDTV using component video and digital audio connections
This setup uses a component video connection to connect to the HDTV. This displays a high definition picture
on your HDTV. To hear audio, there must also be a connection from your set-top’s DIGITAL AUDIO connector
to your HDTV (or optional home theater).
Room 4: SDTV using composite video and audio connections
This setup uses a composite video and audio (AV) connection to connect to an standard-definition TV. An
optional RF connection is also shown.
Note that some cable service providers may not enable the RF connection and/or other
features of your set-top box. The functionality depends on your service provider.
CONNECTING THE EQUIPMENT
NOTE
Copy protection via an HDMI secure link
The HDMI link between your set-top box and your HDTV should be a secure link. When your set-top
box is attached via an HDMI cable to an HDCP-compliant (High-bandwidth Digital Content Protection)
HDTV, the HDTV and set-top box negotiate a secure link, which allows your set-top box to transmit full
resolution video (picture) to your HDTV.
Not all HDTVs support HDCP. If your set-top box is connected to an HDTV that does not support it, the
HDMI output is then disabled, so no picture is transmitted from this connector.
8
Mi3 (IPW9001) USER GUIDE (501-2C14501)
CONNECTING THE EQUIPMENT (cont.)
VIDEO
IN
MEDIA SERVER
ROOM 1:
MEDIA SERVER
IPW9001
SET-TOP
AUDIO IN
L R
HDMI
COMPONENT IN
DIGITAL
OPTICAL
AUDIO
ANTENNA/RF
IN
CABLE
INPUT
WALL CABLE
OUTLET
ROOM 3:
ANALOG HD with
DIGITAL AUDIO
SDTV
WALL
CABLE
OUTLET
ROOM 4:
SD VIDEO with
OPTIONAL RF
WALL
CABLE
OUTLET
IPW9001
SET-TOP
HDTV
ROOM 2:
HDMI
WALL
CABLE
OUTLET
IPW9001
SET-TOP
HDTV
HDTV
HDMI
Connecting your equipment
The diagram below shows several possible setups for your set-top. Choose the setup that best matches the equipment you have. For further information, see page 7.
9
Mi3 (IPW9001) USER GUIDE (501-2C14501)
CONNECTING THE EQUIPMENT (cont.)
WARNINGS
Do not connect your set-top box (or any other equipment such as a TV or VCR) to the power supply until
you have properly connected all the other cables.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety.
Connecting the power supply unit to your set-top box
Before you insert the power supply unit into the wall AC outlet, connect the 5 volt DC cord from the power
supply unit to the socket labeled “+5.0V DC IN 3A MAX. POWER” on your set-top box’s rear panel.
Connecting equipment to the wall AC outlets
Connect your set-top box’s power supply unit, and the plugs on the power cords from your TV, DVD player,
and any other equipment, into wall AC outlets. If these outlets have switches, switch them ON.
Turning your set-top box on and off
After you have connected your set-top box’s power supply unit to the wall AC outlet (and switched this outlet
ON, if it has a switch), the Power light around the Power button should light up red, to show that your
set-top box is in standby. Press the Power button on your set-top box’s front panel to turn it on. The Power
light around the Power button should light up blue, to show that your set-top box is on.
To turn your set-top box on or off at any time, press the Power button on the front panel.
Never turn off your set-top box by simply disconnecting it from the power supply. If you need to disconnect
your set-top box, first turn it off by pressing the Power button on the front panel.
Lightning storms
Disconnect your set-top box’s power cord during lightning storms. A lightning storm may affect your set-top
box, if it is on during the storm. It may appear that it has stopped working, but you can easily restore its
operation as follows:
Unplug your set-top box’s power supply unit from the wall AC outlet. Then plug this power supply unit in
again at the wall AC outlet (and, if there is a switch by this outlet, switch it to its ON position).
Front panel
Your cable TV service-provider determines the digital channels, services, and screen information that you see
on your TV when you use your set-top box and its remote control.
Consult the information supplied by your cable service-provider for details on how to make the most of the
digital cable services. Also read the operating instructions that are supplied with your remote control.
Power button
To turn your set-top
box on/off.
Power light
Lights blue when your set-top
box is on and lights red when
your set-top box is in standby.
Remote light
Lights when you press a button
on your remote control.
Record light
Lights when a recording
is being made.
Data light
Lights when a message has
been received.
10
Mi3 (IPW9001) USER GUIDE (501-2C14501)
OPTIONAL WIFI ADAPTER
Regulatory information for WiFi
NOTE
Users should be advised that high-power radars are allocated as
primary users (i.e. priority users) of the bands 5250-5350 MHz and
5470-5725 MHz and that these radars could cause interference and/or
damage to the LE-LAN device.
The device for operation in the band 5150-5250 MHz is only for indoor
use to reduce the potential for harmful interference to co-channel
mobile satellite systems.
Having a WiFi adapter fitted
Your set-top box has been designed to work with an 802.11ac 5 GHz WiFi
adapter. Contact your service provider about availability and installation.
Your home must have a 5 GHz wireless router or access point that
supports Wi-Fi Protected Setup (WPS) so that the adapter can correctly
associate with your wireless network.
If you wish to have this optional adapter, it may have been fitted in
advance. Alternatively, you can send your set-top box to a repair/service
center for a WiFi adapter to be professionally fitted.
Starting the WiFi connection
Consult the instructions for your wireless router or access point to find out
what you need to do to initiate a WPS WiFi connection.
When you have activated the WPS system on your router or access point,
press the button on the top of your WiFi adapter until the light around this
button flashes green.
This automatically connects your adapter to your wireless network using
WPS. When the WiFi connection is established, the light will be steady
green.
Note: WPS will remain active for only a limited time to allow this pairing
process; please consult the instructions for your wireless router or access
point for information on the length of this limited time.
Disconnecting your WiFi adapter
You should not need to disconnect your WiFi adapter unless there is a
problem with it and you need to seek advice. In that case you need to see
the information on the label that is on your adapter.
WARNING: Before you attempt to disconnect your adapter, switch off
your set-top box by pressing the Power button on the front panel.
Then disconnect your power supply unit from the wall AC outlet
To remove your WiFi adapter from your set-top box you need a Philips
(cross-head) screwdriver of a suitable size.
Unscrew the Philips-head screw on the end of your WiFi adapter and
gently pull the adapter away from your set-top box.
The label is on the underside of your WiFi adapter.
WiFi adapter This cover is removed when the adapter is fitted.
WPS button on fitted WiFi adapter
Philips-head fixing screw on WiFi adapter
Pull adapter away from set-top box.
Part No: E4282C20400
Model No: AW500
Power: +5V DC 0.5A max.
Made in China
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including inteference that may cause undesired operation.
FCC ID: NQ8AW500
E222159
I.T.E.
35ZB
11
Mi3 (IPW9001) USER GUIDE (501-2C14501)
Reconnecting your WiFi adapter
WARNING: Before you attempt to reconnect your WiFi adapter, switch
off your set-top box by pressing the Power button on the front panel.
Then disconnect your power supply unit from the wall AC outlet
To reconnect your WiFi adapter, slide it into position, pushing gently but
firmly to engage the USB connector on your adapter with the USB port on
your set-top box.
Re-insert the Philips-head screw (with its washer) and tighten the screw
using a suitable Philips screwdriver.
Re-apply power to your set-top box and then re-establish the WiFi
connection using WPS, as described on the preceding page.
OPTIONAL WIFI ADAPTER (cont.)
12
Mi3 (IPW9001) USER GUIDE (501-2C14501)
APPENDIX FOR PROFESSIONAL FITTERS
NOTE
This page of this guide is for professional fitters only and not for the
end-users of this set-top box.
Fitting a WiFi adapter
WARNING: Before you attempt to fit the WiFi adapter, ensure that the
set-top box is NOT powered up.
Removing the cover
Use a torx screwdriver of a suitable size to remove the screw from the end
of the cover. Slide the cover away from the set-top box.
Inserting the WiFi adapter
Slide the adapter into position, pushing gently but firmly to engage the
USB connector on the adapter with the USB port on the set-top box.
A Philips-head screw, with its washer, is supplied with the adapter
(attached to the adhesive on the bubble-wrap that protects the adapter).
Insert the Philips-head screw, with its washer, into the end of the adapter
and tighten it up using a Philips screwdriver.
Do NOT use the torx screw that you removed from the cover to
fix the adapter into position.
WiFi adapter Remove this cover to fit the adapter.
Torx fixing screw on cover
Pull cover away from set-top box.
Push adapter gently but firmly into position.
Philips-head fixing screw on WiFi adapter
13
Mi3 (IPW9001) USER GUIDE (501-2C14501)
TERMS AND CONDITIONS FOR USE OF SOFTWARE (“TERMS”)
THE PRODUCT TO WHICH THESE TERMS RELATE (THE “PRODUCT”) INCORPORATES SOFTWARE WHICH IS OWNED BY PACE
plc (“PACE”) OR ITS THIRD PARTY LICENSORS (THE “SOFTWARE”). BEFORE USING THE PRODUCT PLEASE READ THESE
TERMS. IF YOU DO NOT AGREE TO THESE TERMS YOU MAY NOT USE THE PRODUCT AND SHOULD IMMEDIATELY RETURN
THE PRODUCT TO YOUR SUPPLIER. THESE TERMS ALSO APPLY TO ANY MODIFICATIONS, UPDATES OR SUPPLEMENTS TO
THE SOFTWARE PROVIDED TO YOU. FOR PURPOSES OF THESE TERMS, “YOU” MEANS YOU, THE END USER, AND YOUR
PRODUCT SUPPLIER, UNLESS THE CONTEXT REQUIRES OTHERWISE.
A. License Grant and Conditions
1. Pace, or your supplier, if applicable, grants you a non-exclusive, non-transferable, limited license to use the Software solely
as integrated with, incorporated into, or provided for use in connection with the Product.
2. Pace reserves all rights not expressly granted to you under these Terms.
3. You may not transfer any of your limited rights in the Software without the prior written consent of Pace, and if consent
is provided then the Software shall only be transferred in conjunction with the transfer of the Product AND ONLY IF the
transferee has read and agreed to accept these Terms.
4. You must ensure that the copyright, trademark and other protective notices contained in the Software are maintained and not
altered or removed.
5. The Software is protected by copyright and other laws and international copyright and other treaties.
6. The Software provided hereunder is licensed (not sold). Pace is NOT transferring title or any ownership rights in the Software
to you.
7. All title and intellectual property rights in and to the Software and all modifications, updates, enhancements and derivative
works of the Software are owned exclusively by Pace or its licensors and you agree to execute any document reasonably
requested by Pace to evidence such ownership rights.
8. Certain third party software used in connection with the Product may be made directly available to you by operating system
or other third party providers. Use of such Software is also subject to the terms of any applicable agreement between you and
such third party.
B. License Restrictions
Except as expressly permitted herein or by statute you may not:
1. use the Software in conjunction with any other hardware or equipment other than the Product;
2. copy or modify all or any portion of the Software;
3. incorporate all (or any portion of) the Software into other programs developed or used by (or on behalf of) you;
4. reverse engineer, decompile, decrypt or disassemble the Software (or any portion of the Software); or
5. export, transfer or re-export the Software in violation of any applicable law.
C. Open Source Software
Certain components of the Software are subject to either:
(i) the GNU General Public License (“GPL”);
(ii) the GNU Lesser General Public License (“LGPL”); or
(iii) OpenSSL license.
The foregoing are not subject to the restrictions in Section B. In compliance with the GPL and LGPL Pace makes the source code
of the Linux software, libraries and associated utilities it uses, together with its modifications (if any), available to the public in
source code form at: http://www.pace.com/opensource/request.
You are free to use, modify and distribute the Linux software and any modifications as long as you comply with the terms of the
GPL or LGPL referred to above. The License terms applicable to (i) to (iii) above are available to you, as explained in the section
below entitled Open Source Licenses.
The Software also contains the following:
(iv) SHA library Copyright © 2000-2001, Aaron D. Gifford All rights reserved.
(v) Expat XML Parsing Library
Copyright © 1998, 1999, 2000 Thai Open Source Software Centre Ltd and Clark Cooper.
Copyright © 2001, 2002, 2003 Expat maintainers.
(vi) Expat++ This component of the Software is subject to the Mozilla Public License Version 1.0.
(vii) Base64 Algorithm Copyright © 2001 Bob Trower, Trantor Standard Systems Inc.
Certain additional license terms applicable to (iv) to (vi) above are available to you, as explained in the section below entitled Open Source
Licenses.
14
Mi3 (IPW9001) USER GUIDE (501-2C14501)
D. Termination
These Terms are effective until terminated. You may terminate these Terms by returning the Product to your supplier. These Terms
will terminate automatically without notice if you fail to comply with these Terms or any other written agreement between you and
Pace. Upon termination you must return the Product to your supplier.
E. Disclaimer
1. EXCEPT AS SET FORTH IN ANY WRITTEN AGREEMENT BETWEEN YOU AND PACE (OR YOUR SUPPLIER), THE SOFTWARE
IS (TO THE EXTENT PERMITTED BY LAW) SUPPLIED “AS IS” AND PACE AND ITS LICENSORS EXPRESSLY EXCLUDE
ALL WARRANTIES, EXPRESS OR IMPLIED, INCLUDING (BUT NOT LIMITED TO) WARRANTIES OF MERCHANTABILITY,
SATISFACTORY QUALITY, FITNESS FOR PURPOSE AND NON-INFRINGEMENT.
2. EXCEPT AS SET FORTH IN ANY WRITTEN AGREEMENT BETWEEN YOU AND PACE, IN NO CIRCUMSTANCE WILL PACE BE
LIABLE FOR ANY DIRECT, INDIRECT, CONSEQUENTIAL, SPECIAL, PUNITIVE OR INCIDENTAL DAMAGE (INCLUDING LOSS
OF PROFITS, BUSINESS INTERRUPTION, LOSS OF DATA OR THE COST OF PROCUREMENT OF SUBSTITUTE GOODS,
TECHNOLOGY OR SERVICES) ARISING OUT OF THE USE OR THE INABILITY TO USE THE SOFTWARE.
F. General
These Terms are governed by the laws of the State of New York and you may only bring claims exclusively in New York courts and
Pace shall be entitled to bring a claim in the courts of any jurisdiction. Any failure by Pace to enforce any of its rights hereunder
or applicable law shall not constitute a waiver of such rights. Pace’s licensors and suppliers shall be third party beneficiaries of
this License Agreement, as applicable.
YOUR USE OF THE PRODUCT CONSTITUTES YOUR ACKNOWLEDGEMENT THAT YOU HAVE READ THESE TERMS AND AGREE
TO BE BOUND HEREBY.
Open Source Licenses
The software contained in this product may be covered by certain components consisting of free software or open source software.
A list of these components and a copy of the relevant copyright notices and license term notices that are required by such licenses
are available at this web page:
http://www.pace.com/opensource/license
This list may change from time to time and may depend on the model of product or the version of software you have received. If
you are unable to access this web page and wish to have a copy of this list, please contact the Open Source Administrator at: 3701
FAU Boulevard, Suite 200, Boca Raton, Florida 33431 USA. To the extent the terms of these open source or free software licenses
prohibit any of the restrictions in any end user license included with the product, such restrictions will not apply to the applicable
open source or free software component.
TERMS AND CONDITIONS FOR USE OF SOFTWARE (“TERMS”) (cont.)
501-2C14501
Pace and are trademarks and/or registered trademarks of Pace plc.
www.pace.com
