ASUSTeK Computer PU500C Notebook PC User Manual FCC rev
ASUSTeK Computer Inc Notebook PC FCC rev
User manual-FCC_rev
Notebook PC User Manual
December 2012
E7837
2
Notebook PC User Manual
Table of Contents
Chapter 1: Introducing the Notebook PC
About This User’s Manual ................................................................................ 6
Notes for This Manual ....................................................................................... 6
Safety Precautions ............................................................................................. 7
Preparing your Notebook PC .......................................................................11
Chapter 2: Knowing the parts
Top Side ...............................................................................................................14
Bottom Side ........................................................................................................17
Right Side ............................................................................................................19
Left Side ...............................................................................................................21
Front Side ............................................................................................................22
Chapter 3: Getting Started
Power System ....................................................................................................24
Using AC Power ...............................................................................................24
Using Battery Power ......................................................................................26
Battery Care ......................................................................................................26
Powering on the Notebook PC ..................................................................27
The Power-On Self Test (POST) ..................................................................27
Checking Battery Power ...............................................................................29
Charging the Battery Pack ...........................................................................30
Power Options .................................................................................................31
Power Management Modes .......................................................................33
Sleep and Hibernate ......................................................................................33
Thermal Power Control .................................................................................34
Special Keyboard Functions .........................................................................35
Hot Keys .............................................................................................................35
Numeric keypad (on selected models) ...................................................37
Button and Status Indicators .......................................................................38
Button .............................................................................................................38
Status Indicators .............................................................................................39
Notebook PC User Manual
3
Chapter 4: Using the Notebook PC
Pointing Device .................................................................................................42
Using the Touchpad .......................................................................................43
Touchpad Usage Illustrations .....................................................................44
Caring for the Touchpad ..............................................................................47
Memory Card Reader ....................................................................................48
Network Connections .....................................................................................49
Wired Network Connections ......................................................................49
Wireless Network Connections .................................................................51
Bluetooth Wireless Connection (on selected models) ......................55
Instant On ...........................................................................................................57
Appendix
Optional Accessories .....................................................................................A-2
Optional Connections .................................................................................A-2
Operating System and Software ...............................................................A-3
System BIOS Settings ..................................................................................A-4
Troubleshooting ....................................................................................... A-10
Recovery options for your Notebook PC ............................................ A-15
Using Recovery Partition ........................................................................ A-15
Using DVD Recovery (on selected models) ...................................... A-16
DVD-ROM Drive Information (on selected models) ........................ A-18
Blu-ray ROM Drive Information (on selected models) ................... A-20
Internal Modem Compliancy .................................................................. A-21
Declarations and Safety Statements .................................................... A-25
Federal Communications Commission Statement ........................ A-25
FCC Radio Frequency (RF) Exposure Caution Statement ............ A-26
Declaration of Conformity(R&TTE directive 1999/5/EC) .............. A-26
CE Marking ................................................................................................... A-27
IC Radiation Exposure Statement for Canada ................................. A-27
Wireless Operation Channel for Different Domains ...................... A-28
France Restricted Wireless Frequency Bands .................................. A-28
RF Exposure Information (SAR) ............................................................. A-30
Industry Canada statement ................................................................... A-30
4
Notebook PC User Manual
For portable device usage(<20m from body/SAR needed) ....... A-32
For mobile device usage (>20cm/low power) ................................ A-32
UL Safety Notices ....................................................................................... A-33
Power Safety Requirement .................................................................... A-34
TV Notices .................................................................................................... A-34
REACH ........................................................................................................ A-34
Nordic Lithium Cautions (for lithium-ion batteries) ...................... A-35
Optical Drive Safety Information ......................................................... A-36
Service warning label ............................................................................... A-36
CDRH Regulations ..................................................................................... A-36
Macrovision Corporation Product Notice ......................................... A-37
Regional notice for Singapore .............................................................. A-37
CTR 21 Approval(for Notebook PC with built-in Modem) .......... A-38
European Union Eco-label ...................................................................... A-39
Prevention of Hearing Loss .................................................................... A-40
Coating Notice ............................................................................................ A-40
Global Environmental Regulation
Compliance and Declaration ................................................................ A-41
ASUS Recycling/Takeback Services ..................................................... A-41
Regional Notice for United States of America ................................. A-41
Copyright Information .............................................................................. A-42
Limitation of Liability ................................................................................. A-43
Service and Support ................................................................................... A-43
1
Chapter 1:
Introducing the
Notebook PC
6
Notebook PC User Manual
About This User’s Manual
You are reading the Notebook PC User’s Manual. This User’s Manual
provides information regarding the various components in the
Notebook PC and how to use them. The following are major sections
of this User’s Manual:
1. Introducing the Notebook PC
Introduces you to the Notebook PC and this User’s Manual.
2. Knowing the Parts
Gives you information on the Notebook PC’s components.
3. Getting Started
Gives you information on getting started with the Notebook PC.
4. Using the Notebook PC
Gives you information on using the Notebook PC’s components.
5. Appendix
Introduces you to optional accessories and gives additional
information.
The actual bundled operating system and applications differ by
models and territories. There may be differences between your
Notebook PC and the pictures shown in this manual. Please
accept your Notebook PC as being correct.
Notes for This Manual
A few notes and warnings are used throughout this guide, allowing
you to complete certain tasks safely and effectively. These notes have
different degrees of importance as follows:
WARNING! Important information that must be followed for safe
operation.
IMPORTANT! Vital information that must be followed to prevent
damage to data, components, or persons.
TIP: Tips for completing tasks.
NOTE: Information for special situations.
Notebook PC User Manual
7
Safety Precautions
The following safety precautions will increase the life of the
Notebook PC. Follow all precautions and instructions. Except as
described in this manual, refer all servicing to qualified personnel.
Battery safety warning:
DO NOT throw the
battery in fire. DO NOT
short circuit the contacts.
DO NOT disassemble the
battery.
DO NOT leave the
Notebook PC on your lap
or any part of the body
to prevent discomfort
or injury from heat
exposure.
DO NOT expose to dirty
or dusty environments.
DO NOT operate during a
gas leak.
DO NOT expose to
strong magnetic or
electrical fields.
DO NOT expose to or
use near liquids, rain,
or moisture. DO NOT
use the modem during
electrical storms.
DO NOT press or touch
the display panel. Do not
place together with small
items that may scratch or
enter the Notebook PC.
DO NOT place on
uneven or unstable work
surfaces. Seek servicing
if the casing has been
damaged.
DO NOT place or drop
objects on top and
do not shove any
foreign objects into the
Notebook PC.
Disconnect the AC power and remove the battery pack(s) before
cleaning. Wipe the Notebook PC using a clean cellulose sponge
or chamois cloth dampened with a solution of nonabrasive
detergent and a few drops of warm water and remove any extra
moisture with a dry cloth.
8
Notebook PC User Manual
SAFE TEMP: This
Notebook PC should
only be used in
environments with
ambient temperatures
between 5°C (41°F) and
35°C (95°F).
DO NOT carry or cover
a Notebook PC that
is powered on with
any materials that will
reduce air circulation
such as a carrying bag.
DO NOT throw the Notebook PC in municipal waste. This
product has been designed to enable proper reuse of parts
and recycling. The symbol of the crossed out wheeled bin
indicates that the product (electrical, electronic equipment
and mercury-containing button cell battery) should not
be placed in municipal waste. Check local regulations for
disposal of electronic products.
DO NOT throw the battery in municipal waste. The symbol
of the crossed out wheeled bin indicates that the battery
should not be placed in municipal waste.
INPUT RATING: Refer to
the rating label on the
bottom of the Notebook
PC and be sure that your
power adapter complies
with the rating.
Incorrect installation
of battery may cause
explosion and damage
the Notebook PC.
DO NOT use damaged
power cords, accessories,
or other peripherals.
DO NOT use strong
solvents such as
thinners, benzene, or
other chemicals on or
near the surface.
Notebook PC User Manual
9
Transportation Precautions
To prepare the Notebook PC for transport, you should turn it off
and disconnect all external peripherals to prevent damage to
the connectors. The hard disk drive’s head retracts when the power
is turned off to prevent scratching of the hard disk surface during
transport. Therefore, you should not transport the Notebook PC
while the power is still on. Close the display panel and check that it is
latched securely in the closed position to protect the keyboard and
display panel.
The Notebook PC’s surface is easily dulled if not properly cared
for. Be careful not to rub or scrape the Notebook PC surfaces.
Sound Pressure warning
Excessive sound pressure from earphones or headphones can cause
hearing damage or loss. Adjustment of the volume control as well as
the equalizer to settings other than the center position may increase
the earphones or headphones output voltage and the sound
pressure level.
DC Fan warning
Please note that the DC fan is a moving part that may cause DANGER.
Ensure to keep your body from the moving fan blades.
Adapter Information
Input voltage: 100-240Vac
Input frequency: 50-60Hz
Rating output current: 3.42A (65W)
Rating output voltage: 19Vdc
The socket-outlet shall be installed near the equipment and shall
be easily accessible.
10
Notebook PC User Manual
Cover Your Notebook PC
Purchase a carrying bag to protect the Notebook PC from dirt, water,
shock, and scratches.
Charge Your Batteries
If you intend to use battery power, be sure to fully charge your
battery pack and any optional battery packs before going on long
trips. Remember that the power adapter charges the battery pack as
long as it is plugged into the computer and an AC power source. Be
aware that it takes much longer to charge the battery pack when the
Notebook PC is in use.
Airplane Precautions
Contact your airline if you want to use the Notebook PC on the
airplane. Most airlines will have restrictions for using electronic
devices. Most airlines will allow electronic use only between and not
during takeoffs and landings.
There are three main types of airport security devices: X-ray
machines (used on items placed on conveyor belts), magnetic
detectors (used on people walking through security checks),
and magnetic wands (hand-held devices used on people or
individual items). You can send your Notebook PC and diskettes
through airport X-ray machines. However, it is recommended
that you do not send your Notebook PC or diskettes through
airport magnetic detectors or expose them to magnetic wands.
Notebook PC User Manual
11
Preparing your Notebook PC
These are only quick instructions for using your Notebook PC.
Connecting the AC power adapter
A. Connect the AC power cord to the AC/DC adapter.
B. Plug the AC power adapter into an electrical outlet (100V-240V)
C. Plug the DC power connector into your Notebook PC.
12
Notebook PC User Manual
Opening the display panel
A. Hold the base of your Notebook PC then lift up the display
panel with your thumb.
B. Slowly tilt the display panel forward or backward to a
comfortable viewing angle.
Turning the power on
Press the power button.
2
Chapter 2:
Knowing the parts
14
Notebook PC User Manual
Top Side
The keyboard differs for each territory.
The top side may vary in appearance depending on model.
Notebook PC User Manual
15
Camera Indicator
The camera indicator shows when the built-in camera is in
use.
Microphone (Built-in)
The built-in mono microphone can be used for video
conferencing, voice narrations, or simple audio recordings.
Camera
The built-in camera allows picture taking or video
recording. Can be used with video conferencing and other
interactive applications.
Display Panel
The display panel functions the same as a desktop monitor.
The Notebook PC uses a TFT LCD, which provides excellent
viewing like that of desktop monitors. Unlike desktop
monitors, the LCD panel does not produce any radiation
or flickering. Use a soft cloth without chemical liquids (use
plain water if necessary) to clean the display panel.
Air vents
The air vents allow cool air to enter and warm air to exit the
Notebook PC.
WARNING! Ensure that paper, books, clothing, cables,
or other objects do not block any of the air vents or else
overheating may occur.
16
Notebook PC User Manual
Power Button
The power button turns the Notebook PC on and off, and
wakes it up from suspend mode. Press the power button
once to turn on and once to turn off the Notebook PC. The
power button only works when the display panel is opened.
Numeric keypad (on selected models)
The numeric keypad toggles between these two functions:
for numeric input and as pointer direction keys.
For more details, refer to the Numeric keypad section in this
manual.
Keyboard
The keyboard provides full-sized QWERTY keys with a
comfortable travel depth for typing and a palm rest for
both hands. It also comes with special keyboard functions
that can enable hot keys, allow quick access to Windows,
and control multimedia functions. For more details, refer to
Special Keyboard functions under Chapter 3.
Fingerprint scanner (on selected models)
This Notebook PC’s built-in fingerprint scanners uses a
security software that allows you to use your fingerprint as
an identification key.
Touchpad
The touchpad is a pointing device that provides the same
functions as a desktop mouse. A software-controlled
scrolling function is available after setting up the included
touchpad utility to allow easy Windows or web navigation.
Notebook PC User Manual
17
Bottom Side
The bottom side may vary in appearance depending on model.
The battery pack size varies depending on model.
The bottom of the Notebook PC can get very hot. Be careful
when handling the Notebook PC while it is in operation or
recently been in operation. High temperatures are normal during
charging or operation. DO NOT USE on SOFT SURFACES SUCH
AS BEDS OR SOFAS WHICH MAY BLOCK THE VENTS. DO NOT
PUT THE NOTEBOOK PC on YOUR LAP OR OTHER PARTS OF
THE BODY TO AVOID INJURY FROM THE HEAT.
18
Notebook PC User Manual
Air vents
The air vents allow cool air to enter and warm air to exit the
Notebook PC.
WARNING! Ensure that paper, books, clothing, cables,
or other objects do not block any of the air vents or else
overheating may occur.
Audio speakers
The built-in audio speakers allow you to hear audio straight
from the Notebook PC. The audio features of this Notebook
PC are software-controlled.
Notebook PC User Manual
19
Right Side
USB Port (3.0, on selected models / 2.0)
The USB (Universal Serial Bus) port is compatible with USB
3.0, 2.0, or USB 1.1 devices such as keyboards, pointing
devices, cameras, hard disk drives, printers, and scanners
connected in a series up to 4.8Gbits/sec (USB 3.0),
480Mbits/sec (USB 2.0), and 12Mbits/sec (USB 1.1). USB
allows many devices to run simultaneously on a single
computer, with some peripherals acting as additional
plug-in sites or hubs. USB supports hot-swapping of devices
so that most peripherals can be connected or disconnected
without restarting the computer.
HDMI
HDMI Port
HDMI (High-Definition Multimedia Interface) is an
uncompressed all-digital audio/video interface between
an audio/video source and an audio and/or video monitor.
HDMI supports standard, enhanced, or high-definition
video, plus multi-channel digital audio on a single cable. It
transmits all ATSC HDTV standards and supports 8-channel
digital audio, with bandwidth to spare to accommodate
future enhancements or requirements.
Display (Monitor) Output
The 15-pin D-sub monitor port supports a standard VGA-
compatible device such as a monitor or projector to allow
viewing on a larger external display.
20
Notebook PC User Manual
LAN Port
The RJ-45 LAN port with eight pins is larger than the RJ-11
modem port and supports a standard Ethernet cable for
connection to a local network. The built-in connector allows
convenient use without additional adapters.
Power (DC) Input
The supplied power adapter converts AC power to DC
power for use with this jack. Power supplied through this
jack supplies power to the Notebook PC and charges the
internal battery pack. To prevent damage to the Notebook
PC and battery pack, always use the supplied power
adapter.
The adapter may become warm to hot when in use. Ensure
not to cover the adapter and keep it away from your body.
Notebook PC User Manual
21
Kensington® Lock Port
The Kensington® lock port allows the Notebook PC to
be secured using Kensington® compatible Notebook PC
security products. These security products usually include
a metal cable and lock that prevent the Notebook PC to
be removed from a fixed object. Some may also include a
motion detector to sound an alarm when moved.
USB Ports (2.0)
These USB (Universal Serial Bus) ports are compatible
with USB 2.0 or USB 1.1 devices such as keyboards,
pointing devices, cameras, hard disk drives, printers, and
scanners connected in a series up to 12Mbits/sec (USB
1.1) and 480Mbits/sec (USB 2.0). USB allows many devices
to run simultaneously on a single computer, with some
peripherals acting as additional plug-in sites or hubs. USB
supports hot-swapping of devices so that most peripherals
can be connected or disconnected without restarting the
computer.
Left Side
22
Notebook PC User Manual
Headphone output/microphone input combo jack port
This port allows you to connect your Notebook PC to
amplified speakers or headphones. You can also use
this port to connect your Notebook PC to an external
microphone.
Memory Card Reader
Normally an external memory card reader must be
purchased separately in order to use memory cards from
devices such as digital cameras, MP3 players, and mobile
phones. This Notebook PC has a built-in high-speed
memory card reader that can conveniently read from and
write to memory cards.
Front Side
Status Indicators
Status indicators represent various hardware/software
conditions. For detailed information, see Status Indicators in
Chapter 3.
3
Chapter 3:
Getting Started
24
Notebook PC User Manual
Power System
Using AC Power
The Notebook PC power is comprised of two parts, the power
adapter and the battery power system. The power adapter converts
AC power from a wall outlet to the DC power required by the
Notebook PC. Your Notebook PC comes with a universal AC-DC
adapter. That means that you may connect the power cord to any
100V-120V as well as 220V-240V outlets without setting switches
or using power converters. Different countries may require that an
adapter be used to connect the provided US-standard AC power
cord to a different standard. Most hotels will provide universal
outlets to support different power cords as well as voltages. It is
always best to ask an experienced traveler about AC outlet voltages
when bringing power adapters to another country.
You can buy travel kits for the Notebook PC that includes power
and modem adapters for almost every country.
DO NOT connect the AC power cord to an AC outlet prior to
connecting the DC plug to the Notebook PC. Doing so may
damage the AC-DC adapter.
The actual location of the power input differs by models. Refer to
the previous chapter to locate the LAN port.
Notebook PC User Manual
25
Damage may occur if you use a different adapter to power the
Notebook PC or use the Notebook PC’s adapter to power other
electrical devices. If there is smoke, burning scent, or extreme
heat coming from the AC-DC adapter, seek servicing. Seek
servicing if you suspect a faulty AC-DC adapter. You may damage
both your battery pack(s) and the Notebook PC with a faulty
AC-DC adapter.
This Notebook PC may come with either a two or three-prong
plug depending on territory. If a three-prong plug is provided,
you must use a grounded AC outlet or use a properly grounded
adapter to ensure safe operation of the Notebook PC.
THE POWER ADAPTER MAY BECOME WARM TO HOT WHEN IN
USE. BE SURE NOT TO COVER THE ADAPTER AND KEEP IT AWAY
FROM YOUR BODY.
Unplug the power adapter or switch off the AC outlet to
minimize the power consumption when the Notebook PC is not
in use.
26
Notebook PC User Manual
Using Battery Power
The battery pack consists of a set of battery cells housed together.
A fully charged pack will provide several hours of battery life, which
can be further extended by using power management features
through the BIOS setup.
For safety reasons, DO NOT throw the battery in fire, DO NOT
short circuit the contacts, and DO NOT disassemble the battery.
If there is any abnormal operation or damage to the battery
pack caused by impact, turn off the Notebook PC and contact an
authorized service center.
Battery Care
The Notebook PC’s battery pack, like all rechargeable batteries, has
a limit on the number times it can be recharged. The battery pack’s
useful life will depend on your environment temperature, humidity,
and how your Notebook PC is used. It is ideal that the battery be
used in a temperature range between 10˚C and 35˚C (50˚F and
95˚F). You must also take into account that the Notebook PC’s
internal temperature is higher than the outside temperature. Any
temperatures above or below this range will shorten the life of the
battery. But in any case, the battery pack’s usage time will eventually
decrease and a new battery pack must be purchased from an
authorized dealer for this Notebook PC. Because batteries also have
a shelf life, it is not recommended to buy extras for storing.
Notebook PC User Manual
27
To protect the hard disk drive, always wait at least 5 seconds
after turning off your Notebook PC before turning it back on.
DO NOT carry or cover a Notebook PC that is powered on with
any materials that will reduce air circulation such as a carrying
bag.
Before bootup, the display panel flashes when the power is
turned on. This is part of the Notebook PC’s test routine and is
not a problem with the display.
Powering on the Notebook PC
The Notebook PC’s power-on message appears on the screen when
you turn it on. If necessary, you may adjust the brightness by using
the hot keys. If you need to run the BIOS Setup to set or modify
the system configuration, press [f2] upon bootup to enter the BIOS
Setup. Press [esc] and you will be presented with a boot menu with
selections to boot from your available drives.
The Power-On Self Test (POST)
When you turn on the Notebook PC, it will first run through a
series of software-controlled diagnostic tests called the Power-On
Self Test (POST). The software that controls the POST is installed
as a permanent part of the Notebook PC’s architecture. The POST
includes a record of the Notebook PC’s hardware configuration,
which is used to make a diagnostic check of the system. This record
is created by using the BIOS Setup program. If the POST discovers
a difference between the record and the existing hardware, it will
display a message on the screen prompting you to correct the
conflict by running BIOS Setup. In most cases the record should be
correct when you receive the Notebook PC. When the test is finished,
you may get a message reporting “No operating system found” if the
hard disk was not preloaded with an operating system. This indicates
that the hard disk is correctly detected and ready for the installation
of a new operating system.
28
Notebook PC User Manual
If warnings are still given during bootup after running a software
disk checking utility, you should take your Notebook PC in for
servicing. Continued use may result in data loss.
Self Monitoring and Reporting Technology
The S.M.A.R.T. (Self Monitoring
and Reporting Technology)
checks the hard disk drive during
POST and gives a warning
message if the hard disk drive
requires servicing. If any critical
hard disk drive warning is
given during bootup, backup
your data immediately and run
Windows disk checking program.
To run Window’s disk checking
program: click Windows >
select Computer > right-click
a hard disk drive icon > choose
Properties > click the Tools tab >
click Check Now > click Start. You can also select “Scan ... sectors” for
more effective scan and repair but the process will run slower.
Notebook PC User Manual
29
You will be warned when battery power is low. If you continue
to ignore the low battery warnings, the Notebook PC eventually
enters suspend mode (Windows default uses STR).
Screen captures shown here are examples only and may not
reflect what you see in your system.
Checking Battery Power
The battery system implements the Smart Battery standard under
the Windows environment, which allows the battery to accurately
report the amount of charge left in the battery. A fully-charged
battery pack provides the Notebook PC a few hours of working
power. But the actual figure varies depending on how you use the
power saving features, your general work habits, the CPU, system
memory size, and the size of the display panel.
Pointer over the battery icon without power adapter.
Pointer over the battery icon with
power adapter.
Right-click the battery icon
Left-click the battery icon
Suspend-to-RAM (STR) does not last long when the battery
power is depleted. STR is not the same as power off. STR requires
a small amount of power and will fail and lose data if no power is
available due to complete battery depletion or no power supply
(e.g. removing both the power adapter and battery pack).
30
Notebook PC User Manual
DO NOT leave the battery pack discharged. The battery pack
will discharge over time. If not using a battery pack, it must
continued to be charged every three months to extend recovery
capacity or else it may fail to charge in the future.
The battery stops charging if the temperature is too high or the
battery voltage is too high.
Charging the Battery Pack
Before you use your Notebook PC on the road, you will have to
charge the battery pack. The battery pack begins to charge as
soon as the Notebook PC is connected to external power using the
power adapter. Fully charge the battery pack before using it for the
first time. A new battery pack must completely charge before the
Notebook PC is disconnected from external power. It takes a few
hours to fully charge the battery when the Notebook PC is turned
off and may take twice the time when the Notebook PC is turned on.
The battery status indicator on the Notebook PC turns off when the
battery pack is charged.
The battery starts charging when the charge remaining in
the battery drops below 95%. This prevents the battery from
charging frequently. Minimizing the recharge cycles helps
prolong battery life.
Notebook PC User Manual
31
To protect the hard drive, wait at least 5 seconds after turning off
your Notebook PC before turning it back on.
Power Options
The power switch turns on and
off the Notebook PC or putting
the Notebook PC into sleep
or hibernation modes. Actual
behavior of the power switch
can be customized in Windows
Control Panel “Power Options.”
For other options, such as “Switch
User, Restart, Sleep, or Shut Down,” click the arrowhead next to the
lock icon.
Restarting or Rebooting
After making changes to your operating system, you may be
prompted to restart the system. Some installation processes will
provide a dialog box to allow restart. To restart the system manually,
choose Restart.
32
Notebook PC User Manual
Emergency Shutdown
In case your operating system cannot properly turn off or restart,
there is an additional way to shutdown your Notebook PC:
Hold the power button over 4
seconds.
DO NOT use emergency shutdown while data is being written;
doing so can result in loss or destruction of your data.
Notebook PC User Manual
33
Sleep and Hibernate
Power management settings
can be found in the Windows
> Control Panel > Hardware
and Sound > Power Options. In
Power Options, you can define
Sleep/Hibernate or Shut Down
for closing the display panel or
pressing the power button. Sleep
and Hibernate saves power when your Notebook PC is not in use
by turning off certain components. When you resume your work,
your last status (such as a document scrolled down half way or email
typed half way) will reappear as if you never left. Shut Down will
close all applications and ask if you want to save your work if any are
not saved.
Power Management Modes
The Notebook PC has a number of automatic or adjustable power
saving features that you can use to maximize battery life and lower
Total Cost of Ownership (TCO). You can control some of these
features through the Power menu in the BIOS Setup. ACPI power
management settings are made through the operating system.
The power management features are designed to save as much
electricity as possible by putting components into a low power
consumption mode as often as possible but also allow full operation
on demand.
34
Notebook PC User Manual
Sleep is the same as Suspend-to-
RAM (STR). This function stores
your current data and status in
RAM while many components
are turned off. Because RAM
is volatile, it requires power to
keep (refresh) the data. Click
the Windows button and the
arrowhead next to the lock icon
to see this option. You can also use the keyboard shortcut [Fn F1]
to activate this mode. Recover by pressing any keyboard key except
[Fn]. (NOTE: The power indicator will blink in this mode.)
Hibernate is the same as Suspend-to-Disk (STD) and stores your
current data and status on the hard disk drive. By doing this, RAM
does not have to be periodically refreshed and power consumption
is greatly reduced but not completely eliminated because certain
wake-up components like LAN needs to remain powered. Hibernate
saves more power compared to Sleep. Click the Windows button
and the arrowhead next to the lock icon to see this option. Recover
by pressing the power button. (NOTE: The power indicator will be off
in this mode.)
Thermal Power Control
There are three power control methods for controlling the Notebook
PC’s thermal state. These power control cannot be configured by
the user and should be known in case the Notebook PC should
enter these states. The following temperatures represent the chassis
temperature (not CPU).
• The fan turns on for active cooling when the temperature reaches
the safe upper limit.
• The CPU decreases speed for passive cooling when the temperature
exceeds the safe upper limit.
• The system shut down for critical cooling when temperature ex-
ceeds the maximum safe upper limit.
Notebook PC User Manual
35
The Hot Key locations on the function keys may vary depending
on model but the functions should remain the same. Follow the
icons instead of the function keys.
Special Keyboard Functions
Hot Keys
The following defines the hot keys on the
Notebook PC’s keyboard. The commands
can only be accessed by first pressing and
holding the function key while pressing a
key with a command.
“Z
Z
” Icon (f1): Places the Notebook PC in suspend mode
(either Save-to-RAM or Save-to-Disk depending on sleep
button setting in power management setup).
Radio Tower (f2): Wireless Models Only: Toggles the
internal wireless LAN or Bluetooth (on selected models)
on or o with an on-screen-display. When enabled, the
corresponding wireless indicator will light. Windows
software settings are necessary to use the wireless LAN
or Bluetooth.
Sun Down Icon (f5): Decreases the display brightness
Sun Up Icon (f6): Increases the display brightness
LCD Icon (f7): Toggles the display panel on and o. (On
certain models; stretches the screen area to ll the entire
display when using low resolution modes.)
LCD/Monitor Icons (f8): Toggles between the Notebook
PC’s LCD display and an external monitor in this series:
LCD Only -> CRT Only (External Monitor) -> LCD + CRT
Clone -> LCD + CRT Extend. (This function does not
work in 256 Colors, select High Color in Display Property
Settings.) NOTE: Must connect an external monitor
“before” booting up.
36
Notebook PC User Manual
Crossed-out Touchpad (f9): Toggles the built-in
touchpad LOCKED (disabled) and UNLOCKED (enabled).
Locking the touchpad will prevent you from accidentally
moving the pointer while typing and is best used with an
external pointing device such as a mouse. NOTE: Selected
models have an indicator between the touchpad buttons
will light when the touchpad is UNLOCKED (enabled) and
not light when the touchpad is LOCKED (disabled).
Crossed Speaker Icons (f10): Toggles the speakers on
and o (only in Windows OS)
Speaker Down Icon (f11):
Decreases the speaker volume (only in Windows OS)
Speaker Up Icon (f12):
Increases the speaker volume (only in Windows OS)
fn+A (on selected models):
Toggles the ambient light sensor on or off.
Power4Gear Hybrid (Space Bar): This key toggles
power savings between various power saving modes.
The power saving modes control many aspects of the
Notebook PC to maximize performance versus battery
time. Applying or removing the power adapter will
automatically switch the system between AC mode and
battery mode. You can see the current mode through the
on-screen display (OSD).
Notebook PC User Manual
37
Numeric keypad (on selected models)
A numeric keypad is available on
selected Notebook PC models. You can
use this keypad for numeric input or
as pointer direction keys.
Press to toggle
between using the keypad as number
keys or as pointer direction keys.
38
Notebook PC User Manual
Button
Button and Status Indicators
Power Button
The power button turns on and off the Notebook PC or putting
the Notebook PC into sleep or hibernation modes. Actual
behavior of the power button can be customized in Windows
Control Panel “Power Options.”
The top side may vary in appearance depending on model.
Notebook PC User Manual
39
Status Indicators
Power Indicator
The power indicator lights when the Notebook PC is turned on
and blinks slowly when the Notebook PC is in the Suspend-to-
RAM (Sleep) mode. This indicator is off when the Notebook PC is
turned off or in the Suspend-to-Disk (Hibernation) mode.
Battery Charge Indicator (dual-color)
The dual-color battery charge indicator shows the status of the
battery’s power as follows:
Green on: Battery power is between 95% and 100% (with AC
power).
Orange on: Battery power is less than 95% (with AC power).
Orange Blinking: Battery power is less than 10% (without AC
power).
Off: Battery power is between 10% and 100% (without AC
power).
40
Notebook PC User Manual
Drive Activity Indicator
Indicates that the Notebook PC is accessing one or more storage
device(s) such as the hard disk. The light flashes proportional to
the access time.
Bluetooth / Wireless Indicator
This is only applicable on models with internal Bluetooth (BT)
and built-in wireless LAN. This indicator will light to show that
the Notebook PC’s built-in Bluetooth (BT) function is activated.
When the built-in wireless LAN is enabled, this indicator will also
light. (Windows software settings are necessary.)
4
Chapter 4:
Using the Notebook PC
42
Notebook PC User Manual
DO NOT use any objects in place of your finger to operate the
touchpad or else damage may occur to the touchpad’s surface.
Pointing Device
The Notebook PC’s integrated touchpad pointing device is fully
compatible with all two/three-button and scrolling knob PS/2 mice.
The touchpad is pressure sensitive and contains no moving parts;
therefore, mechanical failures can be avoided. A device driver is still
required for working with some application software.
Left Click
Pointer Movement
Right Click
Notebook PC User Manual
43
Using the Touchpad
The touchpad allows you to use your fingers to move the pointer
around or select onscreen items instead of using a standard mouse.
To use the touchpad, lightly press or tap your finger on the touchpad.
Moving The Pointer
Place your finger in the center of the touchpad and slide in a
direction to move the pointer.
Slide finger forward
Slide finger left
Slide finger backward
Slide finger right
44
Notebook PC User Manual
Press the left pointer button
and release.
Lightly but rapidly strike the
touchpad.
Touchpad Usage Illustrations
Clicking/Tapping - With the pointer over an item, press the left
button or use your ngertip to touch the touchpad lightly, keeping
your nger on the touchpad until the item is selected. The selected
item will change color. The following two examples produce the
same results.
Double-clicking/Double-tapping - These actions allows you to
launch your selected program. Move your nger over the program
that you want to launch, press the left button or tap the pad twice in
rapid succession, and the system launches your selected program.
If the interval between the clicks or taps is too long, the operation
will not be executed. You can set the double-click speed using
the Windows Control Panel “Mouse.” The following two examples
produce the same results.
Press the left button twice
and release.
Lightly but rapidly strike the
touchpad twice.
Tapping
Clicking
Double-
Tapping
Double-
Clicking
Notebook PC User Manual
45
Dragging - Dragging refers to moving an item to another location.
Move your nger over an item, while simultaneously pressing the
left button, move the item to your desired location, then release
the left button. You can also double-tap and hold the item while
dragging it with your nger. The following illustrations produce the
same results.
Hold left button and slide finger
on touchpad.
Lightly strike the touchpad
twice, sliding finger on touchpad
during second strike.
Dragging-Clicking Dragging-Tapping
Two-finger scrolling - Use two ngertips to slide up/down/left/
right on the touchpad to scroll a window up/down/left/right. If your
display window includes several sub-windows, move the pointer on
that pane before scrolling.
Scrolling vertically Scrolling horizontally
46
Notebook PC User Manual
Two-finger tapping - Use two
ngers to tap the touchpad. This
action enable user to show pop-
out menu.
Three-finger tapping - Use three
ngers to tap the touchpad. This
action mimics the right-click
function of a mouse.
Three-finger scrolling - Use two ngertips to slide up/down/left/
right on the touchpad to scroll a window up/down/left/right. If your
display window includes several sub-windows, move the pointer on
that pane before scrolling.
Scrolling vertically Scrolling horizontally
Notebook PC User Manual
47
The touchpad responds to movement not to force. There is no
need to tap the surface too hard. Tapping too hard does not
increase the responsiveness of the touchpad. The touchpad
responds best to light pressure.
Caring for the Touchpad
The touchpad is pressure sensitive. If not properly cared for, it can be
easily damaged. Take note of the following precautions.
• Ensure the touchpad does not come into contact with dirt, liquids or
grease.
• Do not touch the touchpad if your ngers are dirty or wet.
• Do not rest heavy objects on the touchpad or the touchpad
buttons.
• Do not scratch the touchpad with your nger nails or any hard
objects.
48
Notebook PC User Manual
Memory Card Reader
This Notebook PC has a single built-in memory card reader slot that
supports SD card formats, and utilizes the internal high-bandwidth
PCI bus.
To prevent data loss, use the Safely Remove Hardware and
Eject Media in the Windows® notication area before removing
the memory card.
Memory card compatibility varies depending on Notebook
PC model and memory card specifications. Memory card
specifications constantly change so compatibility may change
without warning.
Never remove cards while or immediately after reading, copying,
formatting, or deleting data on the card or else data loss may
occur.
The memory card is purchased separately.
SD
Notebook PC User Manual
49
Network Connections
Your Notebook PC allows you to connect to the internet and
other networks using the following wired and wireless network
connections.
Wired Network Connections
This Notebook PC supports wired network connections using
Fast/Gigabit Ethernet (1000 BASE-TX) and Twisted Pair Ethernet
technologies.
When using Fast (1000 BASE-TX) or Gigabit Ethernet, your network
cable must be category 5 or better with twisted-pair wiring. If
you plan on running the interface at 100/1000Mbps, it must be
connected to a 100 BASE-TX/1000 BASE-T hub.
When using Twisted Pair Ethernet (10Base-T), use category 3, 4, or 5
twisted-pair wiring. 10/100 Mbps Full-Duplex is supported on this
Notebook PC but requires connection to a network switching hub
with “duplex” enabled. The software default uses the fastest setting
so no user-intervention is required.
50
Notebook PC User Manual
Using a twisted-pair cable
The cable used to connect the Notebook PC to a host (generally a
Hub or Switch) is called a straight-through Twisted Pair Ethernet
(TPE). The end connectors are called RJ-45 connectors, which are
not compatible with RJ-11 telephone connectors. If connecting two
computers together without a hub in between, a crossover LAN
cable is required (Fast-Ethernet model).
The following illustration shows you how to connect the Notebook
PC to a local area network (LAN).
Network cable with
RJ-45 connectors
Network hub
LAN
Notebook PC
Notebook PC User Manual
51
Wireless Network Connections
Wireless LAN (WLAN)
This Notebook PC’s built-in WLAN is a compact and easy-to-use
wireless Ethernet adapter that implements the IEEE 802.11 standard.
It is capable of fast data transmission rates using Direct Sequence
Spread Spectrum (DSSS) and Orthogonal Frequency Division
Multiplexing (OFDM) technologies on 2.4GHz/5GHz frequencies.
The built-in WLAN is backward compatible with earlier IEEE
802.11 standards. To provide efficient security to your wireless
communication, the optional built-in wireless LAN comes with a
64-bit/128-bit Wired Equivalent Privacy (WEP) encryption and Wi-Fi
Protected Access (WPA) features.
For security concerns, DO NOT connect to an unsecured network;
otherwise, the information transmission without encryption
might be visible to others.
Using the WLAN network connection
1. Turn the Wireless function on,
if necessary, using either of
the following options:
a. Press + until
the wireless LAN icon
and bluetooth icon (on
selected models) are
shown. Click on the WLAN
icon to activate the WLAN
function.
b. Double click the Wireless
Console icon on the
Windows® notification
area and select the WLAN
icon.
Bluetooth icon
WLAN icon
52
Notebook PC User Manual
3. Select the wireless access
point you want to connect
to from the list then click
Connect.
If you cannot nd the
desired access point, click
the Refresh icon on
the upper right corner to
refresh and search in the
list again.
4. When connecting, you may have to enter a password.
5. After a connection has been established, the connection is
shown on the list and you can see the wireless network icon
on the Windows® Notification area.
2. Click the no wireless network
connection icon on the
Windows® Notification area.
Notebook PC User Manual
53
Using Ad-hoc mode and Infrastructure mode
The built-in WLAN in this Notebook PC is also a client adapter that
allows you to use the Ad-hoc and Infrastructure modes when
connecting to a network.
All devices must install optional 802.11 wireless LAN adapters to
use these modes.
Turn on the WLAN function of your Notebook PC before using
the ad-hoc or infrastructure mode
Ad-hoc mode
The ad-hoc mode allows the Notebook PC to connect to
another Notebook PC or desktop PC without the need to setup
an access point. This mode allows you to share files and internet
connection within 30 feet.
To use the ad-hoc mode:
1. Click the wireless network icon on the Windows®
Notification area then click Open Network Sharing Center.
2. In the Network and Sharing Center dialog box, click Setup
a new connection or network.
3. Select Setup a wireless ad hoc (computer-to-computer)
network then click Next.
4. Follow the onscreen instructions to complete the setup
process.
54
Notebook PC User Manual
Infrastructure mode
The Infrastructure mode allows the Notebook PC and other
wireless devices to join a wireless network created by an access
point (sold separately) that provides a central link for wireless
clients to communicate with each other or with a wired network.
To use the infrastructure mode:
1. Click the wireless network icon on the Windows®
Notification area.then click Open Network Sharing Center.
2. In the Network and Sharing Center dialog box, click Setup
a new connection or network.
3. Select Set Up a Network then click Next.
4. Follow the onscreen instructions to complete the setup
process.
Notebook PC User Manual
55
Bluetooth allows you to access other devices such as Notebook PCs,
desktop PCs, tablets, and mobile phones that are also Bluetooth-
enabled. You can facilitate file transfers, use mobile phones as a
hotspot for internet connection, and share internet or network
connections with other devices using a Bluetooth connection.
If your Notebook PC did not come with a built-in Bluetooth, you
need to connect a USB or ExpressCard Bluetooth module to
create a Bluetooth connection.
Using your Bluetooth connection
The following steps can be used to add most Bluetooth devices and
establish a paired connection for data transfers:
Bluetooth Wireless Connection
(on selected models)
1. Turn the Wireless function on,
if necessary, using either of
the following options:
a. Press + until
the wireless LAN icon
and bluetooth icon (on
selected models) are
shown. Click on the
Bluetooth icon to activate
the Bluetooth function.
b. Double click the Wireless
Console icon on the
Windows® Notification
area then click the
Bluetooth icon.
Bluetooth icon
WLAN icon
56
Notebook PC User Manual
2. Right-click on the Bluetooth
icon on the Windows®
Notification area then select
Add a device.
3. Select a Bluetooth-enabled
device from the list then click
Next.
4. Enter the Bluetooth security
code into your device to start
pairing.
5. Click Close to finish adding
the device.
Notebook PC User Manual
57
Instant On
Instant On is a default-enabled feature in your ASUS Notebook PC
that allows you to save battery power while your Notebook PC is on
deep sleep mode (Deep S3). It also shows how long your Notebook
PC can run on standby using these two battery saving modes:
Performance mode and Battery saving mode.
Deep S3 is a technology that lets you save more battery power
while your ASUS Notebook PC is on sleep mode.
The standby time varies according to your Notebook PC's
remaining battery capacity, computer model, configuration, and
operating conditions.
Performance mode
The performance mode is default-
enabled in your Notebook PC. It
allows the system to return to its
last working state in two seconds,
even after your Notebook PC has
entered into deep sleep mode.
58
Notebook PC User Manual
Battery saving mode
The battery saving mode enables
longer standby times, allowing the
battery to last for up to thirty (30)
days or more. When you enable
this function, the system can
return to its last working state in
twelve seconds, four hours after
your Notebook PC has entered
into deep sleep mode.
Using Smart Logon in Instant On
Smart Logon allows you to use face
detection to quickly log in without
entering your username and
password.
To activate this feature, click Smart
Logon then follow the onscreen
instructions.
A
Appendix
A-2
Notebook PC User Manual
Optional Accessories
These items, if desired, come as optional items to complement your
Notebook PC.
USB Hub (Optional)
Attaching an optional USB hub will increase your USB ports and
allow you to quickly connect or disconnect many USB peripherals
through a single cable.
USB Flash Memory Disk
A USB flash memory disk is an optional item that can provide
storage up to several hundred megabytes, higher transfer speeds,
and greater durability. When used in current operating systems, no
drivers are necessary.
USB Floppy Disk Drive
An optional USB-interface floppy disk drive can accept a standard
1.44MB (or 720KB) 3.5-inch floppy diskette.
WARNING! To prevent system failures, use Windows “Safely
Remove Hardware” on the taskbar before disconnecting the USB
floppy disk drive. Eject the floppy disk before transporting the
Notebook PC to prevent damage from shock.
Optional Connections
These items, if desired, may be purchased from third-parties.
USB Keyboard and Mouse
Attaching an external USB keyboard will allow data entry to be more
comfortable. Attaching an external USB mouse will allow Windows
navigation to be more comfortable. Both the external USB keyboard
and mouse will work simultaneously with the Notebook PC’s built-in
keyboard and touchpad.
Printer Connection
One or more USB printers can be simultaneously used on any USB
port or USB hub.
Notebook PC User Manual
A-3
Operating System and Software
This Notebook PC may offer (depending on territory) its customers
the choice of a pre-installed Microsoft Windows operating system.
The choices and languages will depend on the territory. The levels
of hardware and software support may vary depending on the
installed operating system. The stability and compatibility of other
operating systems cannot be guaranteed.
Support Software
This Notebook PC comes with a support disc that provides BIOS,
drivers and applications to enable hardware features, extend
functionality, help manage your Notebook PC, or add functionality
not provided by the native operating system. If updates or
replacement of the support disc is necessary, contact your dealer for
web sites to download individual software drivers and utilities.
The support disc contains all drivers, utilities and software for all
popular operating systems including those that have been pre-
installed. The support disc does not include the operating system
itself. The support disc is necessary even if your Notebook PC came
pre-configured in order to provide additional software not included
as part of the factory pre-install.
A recovery disc is optional and includes an image of the original
operating system installed on the hard drive at the factory. The
recovery disc provides a comprehensive recovery solution that
quickly restores the Notebook PC’s operating system to its original
working state provided that your hard disk drive is in good working
order. Contact your retailer if you require such a solution.
Some of the Notebook PC’s components and features may not
work until the device drivers and utilities are installed.
A-4
Notebook PC User Manual
System BIOS Settings
Boot Device
1. On the Boot screen, select Boot Option #1.
→← : Select Screen
↑↓ : Select Item
Enter : Select
+/— : Change Opt.
F1 : General Help
F9 : Optimized Defaults
F10 : Save
ESC : Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
Boot Configuration
Launch PXE OpROM [Disabled]
Driver Option Priorities
Boot Option Priorities
Boot Option #1 [Windows Boot Manag...]
Add New Boot Option
Delete Boot Option
Sets the system boot order
2. Press [Enter] and select a device as the Boot Option #1.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
Boot Configuration
UEFI Boot [Disabled]
PXE ROM [Disabled]
Boot Option Priorities
Boot Option #1 [P0: Hitachi HTS545...]
Boot Option #2 [P2: MATSHITADVD-RA...]
CD/DVD ROM Drive BBS Priorities
Add New Boot Option
Delete Boot Option
Sets the system boot order
Boot Option #1
The BIOS screens in this section are for reference only. The actual
screens may differ by models and territories.
→← : Select Screen
↑↓ : Select Item
Enter : Select
+/— : Change Opt.
F1 : General Help
F9 : Optimized Defaults
F10 : Save
ESC : Exit
Windows Boot Manager (PO: Hitachi HTS727575A9E364)
Disabled
Boot Option #1
Notebook PC User Manual
A-5
Security Setting
To set the password:
1. On the Security screen, select Administrator Password or
User Password.
2. Type in a password and press [Enter].
3. Re-type to conrm the password and press [Enter].
4. Password is then set.
To clear the password:
1. On the Security screen, select Administrator Password or
User Password.
2. Enter the current password and press [Enter].
3. Leave the Create New Password eld blank and press [Enter].
4. Leave the Confirm New Password eld blank and press [Enter].
5. Password is then cleared.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Boot Security Save & Exit
Password Description
If ONLY the Administrator’s password is set,
then this only limits access to Setup and is
only asked for when entering Setup.
If ONLY the user’s password is set, then this
is a power on password and must be entered to
boot or enter Setup. In Setup, the User will
have Administrator rights.
Administrator Password Status NOT INSTALLED
User Password Status NOT INSTALLED
Administrator Password
User Password
HDD Password Status : NOT INSTALLED
Set Master Password
Set User Password
I/O Interface Security
Set Administrator Password.
The password length must be in
the following range:
Minimum length 3
Maximum length 20
Must type with character:
a-z, 0-9
You will be asked to enter the User Password whenever
you power on the Notebook PC (enter BIOS or OS). The
Administrator Password is only asked when you would like to
enter and congure the BIOS settings.
→← : Select Screen
↑↓ : Select Item
Enter : Select
+/— : Change Opt.
F1 : General Help
F9 : Optimized Defaults
F10 : Save
ESC : Exit
A-6
Notebook PC User Manual
I/O Interface Security
To lock the I/O interface:
1. On the Security screen, select I/O Interface Security.
2. Select an interface you would like to lock and click Lock.
The I/O Interface Security settings can only be altered when
you log in with Administrator privilege.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Security
I/O Interface Security
LAN Network Interface [UnLock]
Wireless Network Interface [UnLock]
HD AUDIO Interface [UnLock]
SATA 2nd HDD Interface [UnLock]
USB Interface Security
If Locked, LAN and Card Reader
Interface will be disabled.
LAN Network Interface
Lock
UnLock
→← : Select Screen
↑↓ : Select Item
Enter : Select
+/— : Change Opt.
F1 : General Help
F9 : Optimized Defaults
F10 : Save
ESC : Exit
Notebook PC User Manual
A-7
USB Interface Security
To lock the USB interface:
1. On the Security screen, select I/O Interface Security > USB
Interface Security.
2. Select an interface you would like to lock and click Lock.
The USB Interface Security settings can only be altered when
you log in with Administrator privilege.
If you set USB Interface to [Lock], External Ports and CMOS
Camera will be locked and hidden simultaneously.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Security
USB Interface Security
USB Interface [UnLock]
External Ports [UnLock]
Bluetooth [UnLock]
Card Reader [UnLock]
If Locked, all USB device will
be disabled
USB Interface
Lock
UnLock
→← : Select Screen
↑↓ : Select Item
Enter : Select
+/— : Change Opt.
F1 : General Help
F9 : Optimized Defaults
F10 : Save
ESC : Exit
A-8
Notebook PC User Manual
HDD Password
To set the HDD password:
1. On the Security screen, click Set Master Password, type in a
password and press [Enter].
2. Re-type to confirm the password and press [Enter].
3. Click Set User Password and repeat the previous steps to set
up the user password.
4. Password is then set.
• The HDD Password can only be altered when you log in with
Administrator privilege.
• You have to set Master Password before setting the User
Password.
You will be asked to enter user password first (if there is one),
then HDD user password when you power on the Notebook PC
and cannot enter the operating system if you fail to enter the
correct passwords.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Boot Security Save & Exit
Password Description
If ONLY the Administrator’s password is set,
then this only limits access to Setup and is
only asked for when entering Setup.
If ONLY the user’s password is set, then this
is a power on password and must be entered to
boot or enter Setup. In Setup, the User will
have Administrator rights.
Administrator Password Status NOT INSTALLED
User Password Status NOT INSTALLED
Administrator Password
User Password
HDD Password Status : NOT INSTALLED
Set Master Password
Set User Password
I/O Interface Security
Set HDD Master Password.
*** A d vi sa bl e t o P ow er Cy cl e
System after Setting Hard Disk
Passwords ***
→← : Select Screen
↑↓ : Select Item
Enter : Select
+/— : Change Opt.
F1 : General Help
F9 : Optimized Defaults
F10 : Save
ESC : Exit
Notebook PC User Manual
A-9
Save Changes
If you want to keep your configuration settings, you must save
changes before exiting the BIOS setup utility.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
Save Changes and Exit
Discard Changes and Exit
Save Options
Save Changes
Discard Changes
Restore Defaults
Boot Override
Windows Boot Manager (PO: Hitachi HTS727575A9E364)
P2: MATSHITADVD-RAM UJ8C2 S
Launch EFI Shell from filesystem device
Ex it sy st em se tu p a ft er s av in g
the changes.
→← : Select Screen
↑↓ : Select Item
Enter : Select
+/— : Change Opt.
F1 : General Help
F9 : Optimized Defaults
F10 : Save
ESC : Exit
A-10
Notebook PC User Manual
Troubleshooting
This section presents some common problems and possible
solutions for your Notebook PC.
The optical disc drive is not able to read or write discs.
• Update the BIOS to the latest version and try again.
• If updating the BIOS does not help, try better quality discs and
try again.
• If the problem still exist, contact your local service center and
ask an engineer for assistance.
The system cannot wake up from sleep or hibernate mode.
• Remove upgraded parts such as RAM, hard disk drive (HDD),
WLAN/Bluetooth module if they were installed after purchase.
• Run System Restore to restore the system to its factory default
setting.
• If the problem still persists, try restoring your system using the
system recovery partition function or the recovery DVD.
You must back up all your data to another location before
starting any recovery process.
• If the problem still exists, contact your local ASUS Service Center
for assistance.
The Hotkey function is disabled.
Reinstall the “ATK0100” driver from the driver CD or download it from
the ASUS website.
The built-in camera does not work properly.
• Check “Device Manager”.
• Try reinstalling the webcam driver.
Notebook PC User Manual
A-11
• If the problem is not solved, update the BIOS to the latest
version and try again.
• If the problem still exists, contact your local ASUS service center
for assistance.
Using the battery pack
• Register the Notebook PC for a one-year-warranty via this
website:
http://vip.asus.com/login.aspx
• Do NOT remove the battery pack while using the Notebook
PC with the AC adapter to prevent damage caused by the
accidental power loss. The ASUS battery pack has protection
circuitry to prevent over-charging so it will not damage the
battery pack if it is left in the Notebook PC.
I cannot power ON the Notebook PC.
• Check the power cord connections.
• Check if the battery pack is properly aligned at the notches and
fitted completely into the battery slot.
• If your Notebook PC is connected to the power adapter but does
not load the BIOS (appears as the ASUS logo) or the operating
system, the problem might be in the Notebook PC’s hard disk
drive. Contact your local ASUS Service Center for assistance.
• If your Notebook PC is connected to the power adapter and
shows the BIOS (appears as the ASUS logo) but does not load
the operating system, the problem might be in the Notebook
PC’s hard disk drive. Contact your local ASUS Service Center for
assistance.
Why is the cooling fan always ON and the temperature
high?
• Ensure that the FAN works when the CPU temperature is high
and check whether there is air flow from the main air vent.
A-12
Notebook PC User Manual
• Close some running applications to decrease the system load.
• Check your system for viruses.
•
Try restoring your system using the system recovery partition or the
recovery DVD.
You must back up all your data to another location before doing
the recovery process.
Install an anti-virus software to protect the system from viruses.
When I turn the power ON, my Notebook PC displays this
message: “Open policy file error”.
Reinstall the latest “Power4 Gear” utility which you can download
from the ASUS website.
A blue screen with white text appears after system bootup.
• Remove the additional memory. If an additional memory was
installed after purchase, power OFF, remove the additional
memory, and power ON to see if the problem is due to
incompatible memory.
• Remove software applications. If you have installed software
applications recently, they may not be compatible with your
system. Try to delete them in Windows Safe Mode.
• Check your system for viruses.
• Update the BIOS to the latest version with Easy Flash in
Windows or AFLASH in DOS mode. These utilities and BIOS files
can be downloaded from the ASUS website.
Ensure your Notebook PC does not lose power during the BIOS
flashing process.
•
Try restoring your system using the system recovery partition or the
recovery DVD.
Notebook PC User Manual
A-13
You must back up all your data to another location before doing
the recovery process.
Install an anti-virus software to protect the system from viruses.
Ensure that you install the “Intel INF Update” and “ATKACPI”
drivers first so that hardware devices can be recognized.
• If the problem still exists, contact your local ASUS Service Center
for assistance.
Updating the BIOS.
1. Please verify the Notebook PC’s exact model and download the
latest BIOS file for your model from the ASUS website and save
it in your flash disk drive.
2. Connect your ash disk drive to the Notebook PC and power on
the Notebook PC.
3. From the BIOS Setup program, click Advanced > Start Easy
Flash, then press [Enter].
4. Locate the latest BIOS file and start updating the BIOS.
ASUSTek Easy Flash Utility
[ ]: Switch [ ] : Choose [q] : Exit [Enter]: Enter/Execute
0 EFI <DIR>
FLASH TYPE: Winbond 25X/Q Series
Current BIOS
Platform: P500CA
Version: 100
Build Date: Nov 1 2012
Build Time: 09:53:29
New BIOS
Platform: Unknown
Version: Unknown
Build Date: Unknown
Build Time: Unknown
5. After the BIOS update process, click Exit > Restore Defaults to
restore the system to its default settings.
Version 2.12.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
POST Logo Type [Static]
Start Easy Flash
Play POST Sound [No]
Speaker Volume [4]
Internal Pointing Device [Enabled]
Wake On Lid Open [Enabled]
Power Off Energy Saving [Enabled]
ASUS USB Charger+ in battery mode [Disabled]
Intel Virtualization Technology [Enabled]
Intel AES-NI [Enabled]
VT-d [Enabled]
SATA Configuration
Graphics Configuration
Intel (R) Anti-Theft Technology Configuration
USB Configuration
Network Stack
Press ENTER to run the utility
to select and update BIOS.
FS0
FS1
→← : Select Screen
↑↓ : Select Item
Enter : Select
+/— : Change Opt.
F1 : General Help
F9 : Optimized Defaults
F10 : Save
ESC : Exit
Notebook PC User Manual
A-15
Using the Recovery Partition or the DVD Recovery (for selected
models) allows you to reformat your hard drive and restore your
ASUS Notebook PC to its original factory settings. These recovery
options also enable you to reuse the default settings of your
Notebook PC to make new changes as needed.
Back up all your data before performing system recovery in your
Notebook PC.
You may need to reinstall some software applications after the
recovery process is completed. You may also be required to buy
a new license to reactivate the software.
Do not restart or turn off your Notebook PC during the recovery
process.
Using Recovery Partition
The Recovery Partition is a reserved space in your Notebook PC's
hard disk drive where you can restore the operating system, drivers,
and utilities to their original factory settings. To use this option:
1. Press [f9] during bootup.
2. In the Windows Boot Manager, the system automatically loads
the les for recovery. You can also use the up/down arrow keys
to select Windows 7 or Windows Setup [EMS Enabled], then
press [enter].
3. Read the ASUS Preload Wizard messages then click Next.
4. Select from the following partition options:
Recover Windows to first partition only.
This option deletes only the rst partition and allows you to keep other
partitions, and to create a new system partition as drive “C”.
Recovery options for your
Notebook PC
A-16
Notebook PC User Manual
Recover Windows to entire HD.
This option deletes all partitions from your hard disk drive and
creates a new system partition as drive “C”.
Recover Windows to entire HD with two partitions.
This option deletes all partitions from your hard drive and creates two
new partitions “C” (40%) and “D” (60%).
5. Follow the onscreen instructions to complete the recovery
process.
The Recovery Partition is created at the factory and cannot be
restored if deleted. Take your Notebook PC to an authorized
ASUS service center if you have problems with the recovery
process.
Visit the ASUS website at www.asus.com for updated drivers and
utilities.
Using DVD Recovery (on selected models)
AI Recovery
The AI Recovery is a DVD Recovery process that allows you to back
up les and automatically create your own recovery discs from your
Notebook PC.
Do not restart or turn off your Notebook PC during the recovery
process.
To use the AI Recovery:
1. Click the ASUS icon on your desktop then select Backup and
Restore > AI Recovery Burner.
2. Choose from the following AI Recovery options:
• Backup to DVD/BD.
If you choose this option, insert a blank writable DVD/BD into
the optical drive then click Backup.
Notebook PC User Manual
A-17
Using the Recovery DVD:
1. Insert the Recovery DVD into the optical drive. Your Notebook PC
needs to be powered ON.
2. Restart the Notebook PC and press [Esc] on bootup and select the
optical drive (may be labeled as “CD/DVD”) and press [Enter] to
boot from the Recovery DVD.
3. Select OK to start to restore the image.
4. Select OK to confirm the system recovery.
Restoring will overwrite your hard drive. Ensure to back up all your
important data before the system recovery.
5. Follow the onscreen instructions to complete the recovery
process.
WARNING: DO NOT remove the Recovery disc, unless instructed
to do so, during the recovery process or else your partitions will
be unusable.
Ensure to connect the power adapter to your Notebook PC when
performing system recovery. Unstable power supply may cause
recovery failure.
Visit the ASUS website at www.asus.com for updated drivers and
utilities.
A-18
Notebook PC User Manual
The DVD-ROM drive allows you to view and create your own CDs
and DVDs. You can purchase an optional DVD viewer software to
view DVD titles.
Regional Playback Information
Playback of DVD movie titles involves decoding MPEG2 video, digital
AC3 audio and decryption of CSS protected content. CSS (sometimes
called copy guard) is the name given to the content protection
scheme adopted by the motion picture industry to satisfy a need to
protect against unlawful content duplication.
Although the design rules imposed on CSS licensors are many, one rule
that is most relevant is playback restrictions on regionalized content. In
order to facilitate geographically staggered movie releases, DVD video
titles are released for specific geographic regions as defined in “Region
Definitions” below. Copyright laws require that all DVD movies be
limited to a particular region (usually coded to the region at which it is
sold). While DVD movie content may be released for multiple regions,
CSS design rules require that any system capable of playing CSS
encrypted content must only be capable of playing one region.
The region setting may be changed up to five times using the
viewer software, then it can only play DVD movies for the last
region setting. Changing the region code after that will require
factory resetting which is not covered by warranty. If resetting
is desired, shipping and resetting costs will be at the expense of
the user.
DVD-ROM Drive Information
(on selected models)
Notebook PC User Manual
A-19
Region Definitions
Region 1
Canada, US, US Territories
Region 2
Czech, Egypt, Finland, France, Germany, Gulf States, Hungary, Iceland,
Iran, Iraq, Ireland, Italy, Japan, Netherlands, Norway, Poland, Portugal,
Saudi Arabia, Scotland, South Africa, Spain, Sweden, Switzerland,
Syria, Turkey, UK, Greece, Former Yugoslav Republics, Slovakia
Region 3
Burma, Indonesia, South Korea, Malaysia, Philippines, Singapore,
Taiwan, Thailand, Vietnam
Region 4
Australia, Caribbean (Except US Territories), Central America, New
Zealand, Pacific Islands, South America
Region 5
CIS, India, Pakistan, Rest of Africa, Russia, North Korea
Region 6
China
A-20
Notebook PC User Manual
The Blu-ray ROM Drive allows you to view high definition (HD) videos
and other disc file formats such as DVDs and CDs.
Region Definitions
Region A
North, Central and South American countries, and their territories;
Taiwan, Hong Kong, Macao, Japan, Korea (South and North), South
East Asian countries and their territories.
Region B
European, African, and South West Asian countries and their
territories; Australia and New Zealand.
Region C
Central, South Asian, Eastern European countries and their territories;
China and Mongolia.
Refer to Blu-ray Disc website at www.blu-raydisc.com/en/Technical/
FAQs/Blu-rayDiscforVideo.aspx for more details.
Blu-ray ROM Drive Information
(on selected models)
Notebook PC User Manual
A-21
Internal Modem Compliancy
The Notebook PC with internal modem model complies with
JATE (Japan), FCC (US, Canada, Korea, Taiwan), and CTR21. The
internal modem has been approved in accordance with Council
Decision 98/482/EC for pan-European single terminal connection
to the public switched telephone network (PSTN). However due
to differences between the individual PSTNs provided in different
countries, the approval does not, of itself, give an unconditional
assurance of successful operation on every PSTN network
termination point. In the event of problems you should contact your
equipment supplier in the first instance.
Overview
On 4th August 1998 the European Council Decision regarding the
CTR 21 has been published in the Official Journal of the EC. The CTR
21 applies to all non voice terminal equipment with DTMF-dialling
which is intended to be connected to the analogue PSTN (Public
Switched Telephone Network).
CTR 21 (Common Technical Regulation) for the attachment
requirements for connection to the analogue public switched
telephone networks of terminal equipment (excluding terminal
equipment supporting the voice telephony justified case service)
in which network addressing, if provided, is by means of dual tone
multifrequency signalling.
Network Compatibility Declaration
Statement to be made by the manufacturer to the Notified Body and
the vendor: “This declaration will indicate the networks with which
the equipment is designed to work and any notified networks with
which the equipment may have inter-working difficulties”
A-22
Notebook PC User Manual
Network Compatibility Declaration
Statement to be made by the manufacturer to the user: “This
declaration will indicate the networks with which the equipment
is designed to work and any notified networks with which the
equipment may have inter-working difficulties. The manufacturer
shall also associate a statement to make it clear where network
compatibility is dependent on physical and software switch settings.
It will also advise the user to contact the vendor if it is desired to use
the equipment on another network.”
Up to now the Notified Body of CETECOM issued several pan-
European approvals using CTR 21. The results are Europe’s first
modems which do not require regulatory approvals in each
individual European country.
Non-Voice Equipment
Answering machines and loud-speaking telephones can be eligible
as well as modems, fax machines, auto-dialers and alarm systems.
Equipment in which the end-to-end quality of speech is controlled
by regulations (e.g. handset telephones and in some countries also
cordless telephones) is excluded.
Notebook PC User Manual
A-23
This table shows the countries currently under the CTR21
standard.
Country Applied More Testing
Austria
1
Yes No
Belgium Yes No
Czech Republic No Not Applicable
Denmark
1
Yes Yes
Finland Yes No
France Yes No
Germany Yes No
Greece Yes No
Hungary No Not Applicable
Iceland Yes No
Ireland Yes No
Italy Still Pending Still Pending
Israel No No
Lichtenstein Yes No
Luxemburg Yes No
The Netherlands
1
Yes Yes
Norway Yes No
Poland No Not Applicable
Portugal No Not Applicable
Spain No Not Applicable
Sweden Yes No
Switzerland Yes No
United Kingdom Yes No
A-24
Notebook PC User Manual
This information was copied from CETECOM and is supplied without
liability. For updates to this table, you may visit http://www.cetecom.
de/technologies/ctr_21.html
1 National requirements will apply only if the equipment may use
pulse dialling (manufacturers may state in the user guide that the
equipment is only intended to support DTMF signalling, which
would make any additional testing superfluous).
In The Netherlands additional testing is required for series
connection and caller ID facilities.
Notebook PC User Manual
A-25
Declarations and Safety Statements
Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to
the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the
limits for a class B digital device, pursuant to Part 15 of the Federal
Communications Commission (FCC) rules. These limits are designed
to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
The use of a shielded-type power cord is required in order to
meet FCC emission limits and to prevent interference to the
nearby radio and television reception. It is essential that only
the supplied power cord be used. Use only shielded cables to
connect I/O devices to this equipment. You are cautioned that
changes or modifications not expressly approved by the party
responsible for compliance could void your authority to operate
the equipment.
A-26
Notebook PC User Manual
(Reprinted from the Code of Federal Regulations #47, part 15.193, 1993.
Washington DC: Office of the Federal Register, National Archives and
Records Administration, U.S. Government Printing Office.)
FCC Radio Frequency (RF) Exposure Caution
Statement
Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority
to operate this equipment. “The manufacture declares that
this device is limited to Channels 1 through 11 in the 2.4GHz
frequency by specified firmware controlled in the USA.”
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. To maintain compliance with FCC
RF exposure compliance requirements, please avoid direct contact
to the transmitting antenna during transmitting. End users must
follow the specific operating instructions for satisfying RF exposure
compliance.
Declaration of Conformity
(R&TTE directive 1999/5/EC)
The following items were completed and are considered relevant
and sufficient:
• Essential requirements as in [Article 3]
• Protection requirements for health and safety as in [Article 3.1a]
• Testing for electric safety according to [EN 60950]
• Protection requirements for electromagnetic compatibility in
[Article 3.1b]
• Testing for electromagnetic compatibility in [EN 301 489-1] & [EN
301 489-17]
• Effective use of the radio spectrum as in [Article 3.2]
• Radio test suites according to [EN 300 328-2]
Notebook PC User Manual
A-27
CE Marking
CE marking for devices without wireless LAN/Bluetooth
The shipped version of this device complies with the requirements
of the EEC directives 2004/108/EC “Electromagnetic compatibility”
and 2006/95/EC “Low voltage directive”.
CE marking for devices with wireless LAN/ Bluetooth
This equipment complies with the requirements of Directive 1999/5/
EC of the European Parliament and Commission from 9 March, 1999
governing Radio and Telecommunications Equipment and mutual
recognition of conformity.
IC Radiation Exposure Statement for Canada
This equipment complies with IC radiation exposure limits set forth
for an uncontrolled environment. To maintain compliance with IC
RF exposure compliance requirements, please avoid direct contact
to the transmitting antenna during transmitting. End users must
follow the specific operating instructions for satisfying RF exposure
compliance.
Operation is subject to the following two conditions:
• This device may not cause interference and
• This device must accept any interference, including interference
that may cause undesired operation of the device.
To prevent radio interference to the licensed service (i.e. co-channel
Mobile Satellite systems) this device is intended to be operated
indoors and away from windows to provide maximum shielding.
Equipment (or its transmit antenna) that is installed outdoors is
subject to licensing.
A-28
Notebook PC User Manual
Wireless Operation Channel for Different Domains
N. America 2.412-2.462 GHz Ch01 through CH11
Japan 2.412-2.484 GHz Ch01 through Ch14
Europe ETSI 2.412-2.472 GHz Ch01 through Ch13
France Restricted Wireless Frequency Bands
Some areas of France have a restricted frequency band. The worst
case maximum authorized power indoors are:
• 10mW for the entire 2.4 GHz band (2400 MHz–2483.5 MHz)
• 100mW for frequencies between 2446.5 MHz and 2483.5 MHz
Channels 10 through 13 inclusive operate in the band 2446.6 MHz to
2483.5 MHz.
There are few possibilities for outdoor use: On private property or on
the private property of public persons, use is subject to a preliminary
authorization procedure by the Ministry of Defense, with maximum
authorized power of 100mW in the 2446.5–2483.5 MHz band. Use
outdoors on public property is not permitted.
In the departments listed below, for the entire 2.4 GHz band:
• Maximum authorized power indoors is 100mW
• Maximum authorized power outdoors is 10mW
Departments in which the use of the 2400–2483.5 MHz band is
permitted with an EIRP of less than 100mW indoors and less than
10mW outdoors:
01 Ain 02 Aisne 03 Allier
05 Hautes Alpes 08 Ardennes 09 Ariège
11 Aude 12 Aveyron 16 Charente
24 Dordogne 25 Doubs 26 Drôme
32 Gers 36 Indre 37 Indre et Loire
41 Loir et Cher 45 Loiret 50 Manche
55 Meuse 58 Nièvre 59 Nord
Notebook PC User Manual
A-29
60 Oise 61 Orne
63 Puy du Dôme 64 Pyrénées Atlantique
66 Pyrénées Orientales 67 Bas Rhin
68 Haut Rhin 70 Haute Saône
71 Saône et Loire 75 Paris
82 Tarn et Garonne 84 Vaucluse
88 Vosges 89 Yonne
90 Territoire de Belfort 94 Val de Marne
This requirement is likely to change over time, allowing you to use
your wireless LAN card in more areas within France. Please check
with ART for the latest information (www.arcep.fr)
Your WLAN Card transmits less than 100mW, but more than
10mW.
A-30
Notebook PC User Manual
RF Exposure Information (SAR)
This device meets the government’s requirements for exposure to
radio waves. This device is designed and manufactured not to exceed
the emission limits for exposure to radio frequency (RF) energy set
by the Federal Communications Commission of the U.S. Government.
The exposure standard employs a unit of measurement known as
the Specific Absorption Rate, or SAR. The SAR limit set by the FCC
is 1.6 W/kg. Tests for SAR are conducted using standard operating
positions accepted by the FCC with the EUT transmitting at the
specified power level in different channels.
The highest SAR value for the device as reported to the FCC is 0.79
W/kg when placed next to the body.
Industry Canada statement
This device complies with RSS-210 of the Industry Canada Rules.
Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
Ce dispositif est conforme à la norme CNR-210 d’Industrie
Canada applicable aux appareils radio exempts de licence. Son
fonctionnement est sujet aux deux conditions suivantes: (1) le
dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce
dispositif doit accepter tout brouillage reçu, y compris un brouillage
susceptible de provoquer un fonctionnement indésirable.
Notebook PC User Manual
A-31
Caution:
(i) the device for operation in the band 5150-5250 MHz is only for
indoor use to reduce the potential for harmful interference to co-
channel mobile satellite systems;
(ii) the maximum antenna gain permitted for devices in the bands
5250-5350 MHz and 5470-5725 MHz shall comply with the e.i.r.p.
limit; and
(iii) the maximum antenna gain permitted for devices in the band
5725-5825 MHz shall comply with the e.i.r.p. limits specified for
point-to-point and non point-to-point operation as appropriate.
(iv) Users should also be advised that high-power radars are
allocated as primary users (i.e. priority users) of the bands
5250-5350 MHz and 5650-5850 MHz and that these radars could
cause interference and/or damage to LE-LAN devices.
Avertissement:
Le guide d’utilisation des dispositifs pour réseaux locaux doit inclure
des instructions précises sur les restrictions susmentionnées,
notamment :
(i) les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont
réservés uniquement pour une utilisation à l’intérieur afin de
réduire les risques de brouillage préjudiciable aux systèmes de
satellites mobiles utilisant les mêmes canaux;
(ii) le gain maximal d’antenne permis pour les dispositifs utilisant les
bandes 5 250-5 350 MHz et 5 470-5 725 MHz doit se conformer à
la limite de p.i.r.e.;
(iii) le gain maximal d’antenne permis (pour les dispositifs utilisant
la bande 5 725-5 825 MHz) doit se conformer à la limite de p.i.r.e.
spécifiée pour l’exploitation point à point et non point à point,
selon le cas.
(iv) De plus, les utilisateurs devraient aussi être avisés que les
utilisateurs de radars de haute puissance sont désignés
utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les
bandes 5 250-5 350 MHz et 5 650-5 850 MHz et que ces radars
pourraient causer du brouillage et/ou des dommages aux
dispositifs LAN-EL.
A-32
Notebook PC User Manual
For portable device usage(<20m from body/SAR
needed)
Radiation Exposure Statement:
The product comply with the Canada portable RF exposure limit
set forth for an uncontrolled environment and are safe for intended
operation as described in this manual. The further RF exposure
reduction can be achieved if the product can be kept as far as
possible from the user body or set the device to lower output power
if such function is available.
Déclaration d’exposition aux radiations:
Le produit est conforme aux limites d’exposition pour les appareils
portables RF pour les Etats-Unis et le Canada établies pour un
environnement non contrôlé.
Le produit est sûr pour un fonctionnement tel que décrit dans ce
manuel. La réduction aux expositions RF peut être augmentée si l’
appareil peut être conservé aussi loin que possible du corps de l’
utilisateur ou que le dispositif est réglé sur la puissance de sortie la
plus faible si une telle fonction est disponible.
For mobile device usage (>20cm/low power)
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed
and operated with minimum distance 20cm between the radiator &
your body.
Déclaration d’exposition aux radiations:
Cet équipement est conforme aux limites d’exposition aux
rayonnements IC établies pour un environnement non contrôlé. Cet
équipement doit être installé et utilisé avec un minimum de 20 cm
de distance entre la source de rayonnement et votre corps.
Notebook PC User Manual
A-33
UL Safety Notices
Required for UL 1459 covering telecommunications (telephone)
equipment intended to be electrically connected to a
telecommunication network that has an operating voltage to
ground that does not exceed 200V peak, 300V peak-to-peak, and
105V rms, and installed or used in accordance with the National
Electrical Code (NFPA 70).
When using the Notebook PC modem, basic safety precautions
should always be followed to reduce the risk of fire, electric shock,
and injury to persons, including the following:
• DO NOT use the Notebook PC near water, for example, near
a bath tub, wash bowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool.
• DO NOT use the Notebook PC during an electrical storm. There
may be a remote risk of electric shock from lightning.
• DO NOT use the Notebook PC in the vicinity of a gas leak.
Required for UL 1642 covering primary (nonrechargeable) and
secondary (rechargeable) lithium batteries for use as power sources
in products. These batteries contain metallic lithium, or a lithium
alloy, or a lithium ion, and may consist of a single electrochemical
cell or two or more cells connected in series, parallel, or both, that
convert chemical energy into electrical energy by an irreversible or
reversible chemical reaction.
• Do not dispose the Notebook PC battery pack in a fire, as
they may explode. Check with local codes for possible special
disposal instructions to reduce the risk of injury to persons due
to fire or explosion.
• Do not use power adapters or batteries from other devices to
reduce the risk of injury to persons due to fire or explosion. Use
only UL certified power adapters or batteries supplied by the
manufacturer or authorized retailers.
A-34
Notebook PC User Manual
Power Safety Requirement
Products with electrical current ratings up to 6A and weighing more
than 3Kg must use approved power cords greater than or equal to:
H05VV-F, 3G, 0.75mm
2
or H05VV-F, 2G, 0.75mm
2
.
REACH
Complying with the REACH (Registration, Evaluation, Authorization,
and Restriction of Chemicals) regulatory framework, we publish
the chemical substances in our products at ASUS REACH website at
http://csr.asus.com/english/REACH.htm.
TV Notices
Note to CATV System Installer—Cable distribution system should be
grounded (earthed) in accordance with ANSI/NFPA 70, the National
Electrical Code (NEC), in particular Section 820.93, Grounding of
Outer Conductive Shield of a Coaxial Cable – installation should
include bonding the screen of the coaxial cable to the earth at the
building entrance.
Notebook PC User Manual
A-35
Nordic Lithium Cautions (for lithium-ion batteries)
CAUTION! Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended
by the manufacturer. Dispose of used batteries according to the
manufacturer’s instructions. (English)
ATTENZIONE! Rischio di esplosione della batteria se sostituita in
modo errato. Sostituire la batteria con un una di tipo uguale o
equivalente consigliata dalla fabbrica. Non disperdere le batterie
nell’ambiente. (Italian)
VORSICHT! Explosionsgefahr bei unsachgemäßen Austausch der
Batterie. Ersatz nur durch denselben oder einem vom Hersteller
empfohlenem ähnlichen Typ. Entsorgung gebrauchter Batterien
nach Angaben des Herstellers. (German)
ADVARSELI! Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering.
Udskiftning må kun ske med batteri af samme fabrikat og type. Levér
det brugte batteri tilbage til leverandøren. (Danish)
VARNING! Explosionsfara vid felaktigt batteribyte. Använd
samma batterityp eller en ekvivalent typ som rekommenderas
av apparattillverkaren. Kassera använt batteri enligt fabrikantens
instruktion. (Swedish)
VAROITUS! Paristo voi räjähtää, jos se on virheellisesti asennettu. Vaihda
paristo ainoastaan laitevalmistajan sousittelemaan tyyppiin. Hävitä
käytetty paristo valmistagan ohjeiden mukaisesti. (Finnish)
ATTENTION! Il y a danger d’explosion s’il y a remplacement incorrect
de la batterie. Remplacer uniquement avec une batterie du mêre
type ou d’un type équivalent recommandé par le constructeur.
Mettre au rebut les batteries usagées conformément aux instructions
du fabricant. (French)
ADVARSEL! Eksplosjonsfare ved feilaktig skifte av batteri.
Benytt samme batteritype eller en tilsvarende type anbefalt
av apparatfabrikanten. Brukte batterier kasseres i henhold til
fabrikantens instruksjoner. (Norwegian)
(Japanese)
ВНИМАНИЕ! При замене аккумулятора на аккумулятор иного
типа возможно его возгорание. Утилизируйте аккумулятор в
соответствии с инструкциями производителя. (Russian)
A-36
Notebook PC User Manual
Service warning label
INVISIBLE LASER RADIATION WHEN OPEN. DO NOT STARE INTO
BEAM OR VIEW DIRECTLY WITH OPTICAL INSTRUMENTS.
CDRH Regulations
The Center for Devices and Radiological Health (CDRH) of the
U.S. Food and Drug Administration implemented regulations
for laser products on August 2, 1976. These regulations apply to
laser products manufactured from August 1, 1976. Compliance is
mandatory for products marketed in the United States.
Use of controls or adjustments or performance of procedures
other than those specified herein or in the laser product
installation guide may result in hazardous radiation exposure.
CD-ROM Drive Safety Warning
CLASS 1 LASER PRODUCT
Optical Drive Safety Information
Laser Safety Information
To prevent exposure to the optical drive’s laser, do not attempt
to disassemble or repair the optical drive by yourself. For your
safety, contact a professional technician for assistance.
Notebook PC User Manual
A-37
Macrovision Corporation Product Notice
This product incorporates copyright protection technology that
is protected by method claims of certain U.S.A. patents and other
intellectual property rights owned by Macrovision Corporation and
other rights owners. Use of this copyright protection technology
must be authorized by Macrovision Corporation, and is intended
for home and other limited viewing uses only
unless otherwise
authorized by Macrovision Corporation
. Reverse engineering or
disassembly is prohibited.
Regional notice for Singapore
This ASUS product complies with IDA Standards.
Complies with
IDA Standards
DB103778
A-38
Notebook PC User Manual
CTR 21 Approval
(for Notebook PC with built-in Modem)
Danish
Dutch
English
Finnish
French
German
Greek
Italian
Portuguese
Notebook PC User Manual
A-39
Spanish
Swedish
European Union Eco-label
This Notebook PC has been awarded the EU Flower label, which
means that this product has the following characteristics:
1. Decreased energy consumption during use and stand-by
modes.
2. Limited use of toxic heavy metals.
3. Limited use of substances harmful to the environment and
health.
4. Reduction of the use of natural resources by encouraging
recycling.
5. Designed for easy upgrades and longer lifetime through
providing compatible spare parts such as batteries, power
supplies, the keyboard, the memory, and if available the CD drive
or DVD drive.
6. Reduced solid waste through takeback policy.
For more information on the EU Flower label, please visit the
European Union Eco-label website at http://www.ecolabel.eu.
A-40
Notebook PC User Manual
ENERGY STAR complied product
ENERGY STAR is a joint program of the U.S.
Environmental Protection Agency and the U.S.
Department of Energy helping us all save money
and protect the environment through energy
efficient products and practices.
All ASUS products with the ENERGY STAR logo
comply with the ENERGY STAR standard, and the power management
feature is enabled by default. The monitor and computer are
automatically set to sleep after 15 and 30 minutes of user inactivity.
To wake your computer, click the mouse or press any key on the
keyboard. Please visit http://www.energy.gov/powermanagement
for detail information on power management and its benefits to the
environment. In addition, please visit http://www.energystar.gov for
detail information on the ENERGY STAR joint program.
Energy Star is NOT supported on Freedos and Linux-based
products.
Prevention of Hearing Loss
To prevent possible hearing damage, do not listen at high volume
levels for long periods.
Coating Notice
IMPORTANT! To provide electrical insulation and maintain electrical
safety, a coating is applied to insulate the device except on the areas
where the I/O ports are located.
Notebook PC User Manual
A-41
Global Environmental Regulation Compliance and
Declaration
ASUS follows the green design concept to design and manufacture
our products, and makes sure that each stage of the product
life cycle of ASUS product is in line with global environmental
regulations. In addition, ASUS disclose the relevant information
based on regulation requirements.
Please refer to http://csr.asus.com/english/Compliance.htm for
information disclosure based on regulation requirements ASUS is
complied with:
Japan JIS-C-0950 Material Declarations
EU REACH SVHC
Korea RoHS
Swiss Energy Laws
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our commitment
to the highest standards for protecting our environment. We believe
in providing solutions for you to be able to responsibly recycle our
products, batteries, other components as well as the packaging
materials. Please go to http://csr.asus.com/english/Takeback.htm for
detailed recycling information in different regions.
Regional Notice for United States of America
A-42
Notebook PC User Manual
Copyright Information
No part of this manual, including the products and software
described in it, may be reproduced, transmitted, transcribed, stored
in a retrieval system, or translated into any language in any form
or by any means, except documentation kept by the purchaser
for backup purposes, without the express written permission of
ASUSTeK COMPUTER INC. (“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO
THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS,
ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR
ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS,
LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL
OR PRODUCT.
Products and corporate names appearing in this manual may or
may not be registered trademarks or copyrights of their respective
companies, and are used only for identification or explanation and to
the owners’ benefit, without intent to infringe.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL
ARE FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT
TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT
BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES
THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS
AND SOFTWARE DESCRIBED IN IT.
Copyright © 2012 ASUSTeK COMPUTER INC. All Rights Reserved.
Notebook PC User Manual
A-43
Limitation of Liability
Circumstances may arise where because of a default on ASUS’ part
or other liability, you are entitled to recover damages from ASUS.
In each such instance, regardless of the basis on which you are
entitled to claim damages from ASUS, ASUS is liable for no more
than damages for bodily injury (including death) and damage to real
property and tangible personal property; or any other actual and
direct damages resulted from omission or failure of performing legal
duties under this Warranty Statement, up to the listed contract price
of each product.
ASUS will only be responsible for or indemnify you for loss, damages
or claims based in contract, tort or infringement under this Warranty
Statement.
This limit also applies to ASUS’ suppliers and its reseller. It is the
maximum for which ASUS, its suppliers, and your reseller are
collectively responsible.
UNDER NO CIRCUMSTANCES IS ASUS LIABLE FOR ANY OF
THE FOLLOWING: (1) THIRD-PARTY CLAIMS AGAINST YOU FOR
DAMAGES; (2) LOSS OF, OR DAMAGE TO, YOUR RECORDS OR DATA;
OR (3) SPECIAL, INCIDENTAL, OR INDIRECT DAMAGES OR FOR ANY
ECONOMIC CONSEQUENTIAL DAMAGES (INCLUDING LOST PROFITS
OR SAVINGS), EVEN IF ASUS, ITS SUPPLIERS OR YOUR RESELLER IS
INFORMED OF THEIR POSSIBILITY.
Service and Support
Visit our multi-language web site at http://support.asus.com
A-44
Notebook PC User Manual
EC Declaration of Conformity
We, the undersigned,
Manufacturer: ASUSTeK COMPUTER INC.
Address, City: 4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Country: TAIWAN
Authorized representative in Europe: ASUS COMPUTER GmbH
Address, City: HARKORT STR. 21-23, 40880 RATINGEN
Country: GERMANY
declare the following apparatus:
Product name : Notebook PC
Model name : PU500C, PRO500C, E500C
conform with the essential requirements of the following directives:
2004/108/EC-EMC Directive
EN 55022:2010
EN 61000-3-2:2006+A2:2009
EN 55013:2001+A1:2003+A2:2006
EN 55024:2010
EN 61000-3-3:2008
EN 55020:2007+A11:2011
1999/5/EC-R &TTE Directive
EN 300 328 V1.7.1(2006-10)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V5.2.1(2011-05)
EN 301 908-2 V5.2.1(2011-07)
EN 301 893 V1.6.1(2011-11)
EN 302 544-2 V1.1.1(2009-01)
EN 302 623 V1.1.1(2009-01)
EN 300 330-1 V1.7.1(2010-02)
EN 300 330-2 V1.5.1(2010-02)
EN 50360:2001
EN 62479:2010
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.4.1(2002-08)
EN 301 489-4 V1.4.1(2009-05)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-9 V1.4.1(2007-11)
EN 301 489-17 V2.1.1(2009-05)
EN 301 489-24 V1.5.1(2010-09)
EN 302 326-2 V1.2.2(2007-06)
EN 302 326-3 V1.3.1(2007-09)
EN 301 357-2 V1.4.1(2008-11)
EN 50385:2002
EN 62311:2008
2006/95/EC-LVD Directive
EN 60950-1 / A11:2009
EN 60950-1 / A12:2011
EN 60065:2002 / A2:2010
EN 60065:2002 / A12:2011
2009/125/EC-ErP Directive
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
2011/65/EU-RoHS Directive
Ver.
CE marking
Declaration Date: Oct. 01, 2012
Year to begin affixing CE marking:2012
Position : CEO
Name : Jerry Shen
Signature :
__________
(EC conformity marking)
EC Declaration of Conformity
We, the undersigned,
Manufacturer: ASUSTeK COMPUTER INC.
Address, City: 4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Country: TAIWAN
Authorized representative in Europe: ASUS COMPUTER GmbH
Address, City: HARKORT STR. 21-23, 40880 RATINGEN
Country: GERMANY
declare the following apparatus:
Product name : Notebook PC
Model name : PU500C, PRO500C, E500C
conform with the essential requirements of the following directives:
2004/108/EC-EMC Directive
EN 55022:2010
EN 61000-3-2:2006+A2:2009
EN 55013:2001+A1:2003+A2:2006
EN 55024:2010
EN 61000-3-3:2008
EN 55020:2007+A11:2011
1999/5/EC-R &TTE Directive
EN 300 328 V1.7.1(2006-10)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V5.2.1(2011-05)
EN 301 908-2 V5.2.1(2011-07)
EN 301 893 V1.6.1(2011-11)
EN 302 544-2 V1.1.1(2009-01)
EN 302 623 V1.1.1(2009-01)
EN 300 330-1 V1.7.1(2010-02)
EN 300 330-2 V1.5.1(2010-02)
EN 50360:2001
EN 62479:2010
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.4.1(2002-08)
EN 301 489-4 V1.4.1(2009-05)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-9 V1.4.1(2007-11)
EN 301 489-17 V2.1.1(2009-05)
EN 301 489-24 V1.5.1(2010-09)
EN 302 326-2 V1.2.2(2007-06)
EN 302 326-3 V1.3.1(2007-09)
EN 301 357-2 V1.4.1(2008-11)
EN 50385:2002
EN 62311:2008
2006/95/EC-LVD Directive
EN 60950-1 / A11:2009
EN 60950-1 / A12:2011
EN 60065:2002 / A2:2010
EN 60065:2002 / A12:2011
2009/125/EC-ErP Directive
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
2011/65/EU-RoHS Directive Ver. 121001
CE marking
Declaration Date: Feb. 01, 2013
Year to begin affixing CE marking:2013
Position : CEO
Name : Jerry Shen
Signature : __________
(EC conformity marking)
