ASUSTeK Computer X00BD ASUS Phone User Manual

ASUSTeK Computer Inc ASUS Phone Users Manual

Users Manual

E11709
User Guide
15060-82600000
E11709_ZB500KG_UM_Booklet_EU.indd 1 2016-09-12 09:58:56
First Edition/ September 2016
Model: ASUS_X00BD (ZB500KG)
Before you start, ensure that you have read all the
safety information and operating instructions in this
User Guide to prevent injury or damage to your
device.
NOTE: For the latest updates and more detailed
information, please visit www.asus.com.
Front features
Sensor
Touch screen
display
Receiver
Touch keys
Front camera
LED Indicator
E11709_ZB500KG_UM_Booklet_EU.indd 2 2016-09-12 09:58:57
Side features
Audio jack
Micro USB port
Power key
Groove
NOTE: Pry open the rear cover from the groove.
E11709_ZB500KG_UM_Booklet_EU.indd 3 2016-09-12 09:58:57
Rear features
NOTES:
• Removetherearcovertodisplaythedual
micro SIM and microSD card slots.
• ThemicroSIMcardslotssupportWCDMA
and GSM/EDGE network bands.
• ThemicroSDcardslotsupportsmicroSDand
microSDHCcardformats.
NOTES:
• Useonlythepoweradapterthatcamewithyour
device. Using a different power adapter may
damage your device.
• UsingthebundledpoweradapterandASUSPhone
signal cable to connect your ASUS Phone to a
power outlet is the best way to charge your ASUS
Phone.
• Theinputvoltagerangebetweenthewalloutletand
thisadapterisAC100V-240V.Theoutputvoltage
ofthemicroUSBcableisDC5.2V,1A.
IMPORTANT!
• YourASUSPhonecomespartiallychargedbutyou
mustchargeitfullybeforeusingitforthersttime.
Readtheimportantnoticesandcautionsbefore
charging your device.
• WhenusingyourASUSPhonewhileitispluggedto
a power outlet, the grounded power outlet must be
near to the unit and easily accessible.
• WhenchargingyourASUSPhonethroughyour
computer, ensure that you plug the micro USB
cable to your computer’s USB 2.0 / USB 3.0 port.
• AvoidchargingyourASUSPhoneinan
environment with ambient temperature of above
35oC(95oF).
Rear camera
Rear cover
Volume key
Speaker
Camera ash
E11709_ZB500KG_UM_Booklet_EU.indd 4 2016-09-12 09:58:57
Rear features
Charging your ASUS Phone
To charge your ASUS Phone:
1. ConnecttheUSBconnectorintothepower
adapter’s USB port.
2. ConnecttheotherendofthemicroUSBcable
to your ASUS Phone.
3. Plug the power adapter into a wall socket.
NOTES:
• Useonlythepoweradapterthatcamewithyour
device. Using a different power adapter may
damage your device.
• UsingthebundledpoweradapterandASUSPhone
signal cable to connect your ASUS Phone to a
power outlet is the best way to charge your ASUS
Phone.
• Theinputvoltagerangebetweenthewalloutletand
thisadapterisAC100V-240V.Theoutputvoltage
ofthemicroUSBcableisDC5.2V,1A.
IMPORTANT!
• YourASUSPhonecomespartiallychargedbutyou
mustchargeitfullybeforeusingitforthersttime.
Readtheimportantnoticesandcautionsbefore
charging your device.
• WhenusingyourASUSPhonewhileitispluggedto
a power outlet, the grounded power outlet must be
near to the unit and easily accessible.
• WhenchargingyourASUSPhonethroughyour
computer, ensure that you plug the micro USB
cable to your computer’s USB 2.0 / USB 3.0 port.
• AvoidchargingyourASUSPhoneinan
environment with ambient temperature of above
35oC(95oF).
3
1
2
E11709_ZB500KG_UM_Booklet_EU.indd 5 2016-09-12 09:58:57
1. Locate the groove on
thebottom-rightcorner
of your ASUS Phone.
Installing a micro SIM card
To install a micro SIM card:
2. Pry the cover loose
and then pull the rear
cover off.
3. Removethebattery.
CAUTION!
• Donotusesharptoolsorsolventonyourdeviceto
avoid scratches on it.
• UseonlyastandardmicroSIMcardonyourASUS
Phone. A nano to micro SIM adapter or a trimmed
SIMcardmaynotproperlytintoandmaynotbe
detected by your ASUS Phone.
• DO NOT install an empty nano to micro SIM
adapter into the micro SIM card slot to avoid
irreversible damage.
NOTES:
• ThemicroSIMcardslot2isatthelowerpartofthe
micro SIM / micro SD combo card slot.
• BothMicroSIMcardslotssupport2G/3GWCDMA
network bands. But only one micro SIM card can
connectto3GWCDMAserviceatatime.
E11709_ZB500KG_UM_Booklet_EU.indd 6 2016-09-12 09:58:58
4. InsertthemicroSIMcardintooneoftheslots.
CAUTION!
• Donotusesharptoolsorsolventonyourdeviceto
avoid scratches on it.
• UseonlyastandardmicroSIMcardonyourASUS
Phone. A nano to micro SIM adapter or a trimmed
SIMcardmaynotproperlytintoandmaynotbe
detected by your ASUS Phone.
• DO NOT install an empty nano to micro SIM
adapter into the micro SIM card slot to avoid
irreversible damage.
NOTES:
• ThemicroSIMcardslot2isatthelowerpartofthe
micro SIM / micro SD combo card slot.
• BothMicroSIMcardslotssupport2G/3GWCDMA
network bands. But only one micro SIM card can
connectto3GWCDMAserviceatatime.
Micro SIM card
2 / microSD card
combo card slot
Micro SIM card 1
E11709_ZB500KG_UM_Booklet_EU.indd 7 2016-09-12 09:58:58
4. InsertthemicroSDcardintothemicroSDcard
slot.
1. Locate the groove on
thebottom-rightcorner
of your ASUS Phone.
2. Pry the cover loose
and then pull the rear
cover off.
Installing a microSD card
To install a microSD card:
3. Removethebattery.
E11709_ZB500KG_UM_Booklet_EU.indd 8 2016-09-12 09:58:59
FCC Regulations:
Thismobilephonecomplieswithpart15oftheFCC
Rules.Operationissubjecttothefollowingtwo
conditions:(1)Thisdevicemaynotcauseharmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
Thismobilephonehasbeentestedandfoundto
complywiththelimitsforaClassBdigitaldevice,
pursuanttoPart15oftheFCCRules.Theselimits
are designed to provide reasonable protection
against harmful interference in a residential
installation.Thisequipmentgenerates,uses
andcanradiatedradiofrequencyenergyand,
if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installationIfthisequipmentdoescauseharmful
interference to radio or television reception, which
canbedeterminedbyturningtheequipmentoff
and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
- Reorientorrelocatethereceivingantenna.
- Increasetheseparationbetweenthe
equipmentandreceiver.
- Connecttheequipmentintoanoutletona
circuit different from that to which the receiver
is connected.
- Consultthedealeroranexperiencedradio/TV
technician for help.
Caution:Changesormodicationsnotexpressly
approved by the party responsible for compliance
could void the user‘s authority to operate the
equipment.
E11709_ZB500KG_UM_Booklet_EU.indd 9 2016-09-12 09:58:59
RF Exposure Information (SAR)
Thisphoneisdesignedandmanufacturednot
toexceedtheemissionlimitsforexposureto
radiofrequency(RF)energysetbytheFederal
CommunicationsCommissionoftheUnitedStates.
DuringSARtesting,thisdevicewassetto
transmitatitshighestcertiedpowerlevelinall
testedfrequencybands,andplacedinpositions
thatsimulateRFexposureinusageagainstthe
head with no separation, and near the body with
theseparationof10mm.AlthoughtheSARis
determinedatthehighestcertiedpowerlevel,the
actualSARlevelofthedevicewhileoperatingcan
bewellbelowthemaximumvalue.Thisisbecause
the phone is designed to operate at multiple power
levelssoastouseonlythepowerrequiredtoreach
the network. In general, the closer you are to a
wireless base station antenna, the lower the power
output.
Theexposurestandardforwirelessdevices
employing a unit of measurement is known as the
SpecicAbsorptionRate,orSAR.
TheSARlimitsetbytheFCCis1.6W/kg.
ThisdeviceiscompliedwithSARforgeneral
population/uncontrolledexposurelimitsin
ANSI/IEEEC95.1-1992andhadbeentestedin
accordance with the measurement methods and
proceduresspeciedinIEEE1528.
TheFCChasgrantedanEquipmentAuthorization
forthismodelphonewithallreportedSARlevels
evaluatedasincompliancewiththeFCCRF
exposureguidelines.SARinformationonthismodel
phoneisonlewiththeFCCandcanbefound
under the Display Grant section of www.fcc.gov/oet/
ea/fccidaftersearchingonFCCID:MSQX00BD.
Forthisdevice,thehighestreportedSARvaluefor
usageagainsttheheadis0.78W/kg,forusagenear
thebodyis1.15W/kg.
E11709_ZB500KG_UM_Booklet_EU.indd 10 2016-09-12 09:58:59
WhiletheremaybedifferencesbetweentheSAR
levels of various phones and at various positions,
theyallmeetthegovernmentrequirements.
SARcomplianceforbody-wornoperationisbased
on a separation distance of 10 mm between the
unitandthehumanbody.Carrythisdeviceat
least10mmawayfromyourbodytoensureRF
exposurelevelcompliantorlowertothereported
level.Tosupportbody-wornoperation,choosethe
belt clips or holsters, which do not contain metallic
components, to maintain a separation of 10 mm
between this device and your body.
RFexposurecompliancewithanybody-worn
accessory, which contains metal, was not tested
andcertied,andusesuchbody-wornaccessory
should be avoided.
Hearing Aid Compatibility (HAC)
regulations for Mobile phones
In2003,theFCCadoptedrulestomakedigital
wireless telephones compatible with hearing aids
and cochlear implants. Although analog wireless
phones do not usually cause interference with
hearing aids or cochlear implants, digital wireless
phones sometimes do because of electromagnetic
energy emitted by the phone’s antenna, backlight,
orothercomponents.Yourphoneiscompliantwith
FCCHACregulations(ANSIC63.19-2011).While
some wireless phones are used near some hearing
devices (hearing aids and cochlear implants), users
maydetectabuzzing,humming,orwhiningnoise.
Some hearing devices are more immune than others
to this interference noise and phones also vary
intheamountofinterferencetheygenerate.The
wireless telephone industry has developed a rating
system for wireless phones to assist hearing device
usersinndingphonesthatmaybecompatiblewith
their hearing devices. Not all phones have been
rated. Phones that are rated have the rating on
E11709_ZB500KG_UM_Booklet_EU.indd 11 2016-09-12 09:58:59
theirboxoralabellocatedonthebox.Theratings
arenotguarantees.Resultswillvarydepending
on the user’s hearing device and hearing loss. If
your hearing device happens to be vulnerable to
interference, you may not be able to use a rated
phonesuccessfully.Tryingoutthephonewithyour
hearing device is the best way to evaluate it for your
personal needs.
Thisphonehasbeentestedandratedforusewith
hearing aids for some of the wireless technologies
that it uses. However, there may be some newer
wireless technologies used in this phone that have
not been tested yet for use with hearing aids. It is
important to try the different features of this phone
thoroughly and in different locations, using your
hearing aid or cochlear implant, to determine if you
hearanyinterferingnoise.Consultyourservice
provider or the manufacturer of this phone for
information on hearing aid compatibility. If you have
questionsaboutreturnorexchangepolicies,consult
your service provider or phone retailer.
M-Ratings:PhonesratedM3orM4meetFCC
requirementsandarelikelytogenerateless
interference to hearing devices than phones that
arenotlabeled.M4isthebetter/higherofthetwo
ratings.
T-Ratings:PhonesratedT3orT4meetFCC
requirementsandarelikelytobemoreusablewith
ahearingdevice’stelecoil(“TSwitch”or“Telephone
Switch”)thanunratedphones.T4isthebetter/
higher of the two ratings. (Note that not all hearing
devices have telecoils in them.)
YourphonemeetstheM3/T3levelrating.
Hearingdevicesmayalsoberated.Yourhearing
device manufacturer or hearing health professional
mayhelpyoundthisrating.Formoreinformation
aboutFCCHearingAidCompatibility,pleasegoto
http://www.fcc.gov/cgb/dro.
E11709_ZB500KG_UM_Booklet_EU.indd 12 2016-09-12 09:58:59
CE RF Exposure Compliance
ThisdevicemeetstheEUrequirements(1999/519/
EC)onthelimitationofexposureofthegeneral
publictoelectromagneticeldsbywayofhealth
protection.
Forbody-wornoperation,thisdevicehasbeen
testedandmeetstheICNIRPguidelinesandthe
EuropeanStandardEN62209-2,forusewith
dedicatedaccessories.SARismeasuredwith
this device at a separation of 0.5 cm to the body,
whiletransmittingatthehighestcertiedoutput
powerlevelinallfrequencybandsofthisdevice.
Use of other accessories which contain metals
maynotensurecompliancewithICNIRPexposure
guidelines.
CE Mark Warning
CE marking for devices with wireless
LAN/ Bluetooth
Thisequipmentcomplieswiththerequirementsof
Directive1999/5/ECoftheEuropeanParliament
andCommissionfrom9March,1999governing
RadioandTelecommunicationsEquipmentand
mutualrecognitionofconformity.ThehighestCE
SARvaluesforthedeviceareasfollows:
• 0.511W/Kg(Head)
• 0.796W/Kg(Body)
E11709_ZB500KG_UM_Booklet_EU.indd 13 2016-09-12 09:58:59
Using GPS (Global Positioning
System) on your ASUS Phone
TousetheGPSpositioningfeatureonyourASUS
Phone:
• Ensurethatyourdeviceisconnectedtothe
InternetbeforeusingGoogleMaporanyGPS-
enabled apps.
• Forrst-timeuseofaGPS-enabledappon
your device, ensure that you are outdoors to
get the best positioning data.
• WhenusingaGPS-enabledapponyour
device inside a vehicle, the metallic component
of the car window and other electronic devices
might affect the GPS performance.
Prevention of Hearing Loss
Topreventpossiblehearingdamage,donotlistenat
high volume levels for long periods.
For France, headphones/earphones for this
device are compliant with the sound pressure level
requirementlaiddownintheapplicableEN50332-
1:2013and/orEN50332-2:2013standardrequired
byFrenchArticleL.5232-1.
E11709_ZB500KG_UM_Booklet_EU.indd 14 2016-09-12 09:58:59
Safety information
ASUS Phone care
• UseyourASUSPhoneinanenvironmentwith
ambienttemperaturesbetween0°C(32°F)and
35°C(95°F).
The battery
YourASUSPhoneisequippedwithahigh
performancedetachableLi-Ionbattery.Observethe
maintenance guidelines for a longer battery life.
• Avoidcharginginextremelyhighorlow
temperature.Thebatteryperformsoptimallyin
anambienttemperatureof+5°Cto+35°C.
• UseonlyASUSbattery.Usingadifferent
battery may cause physical harm/injury and
may damage your device.
• Donotremoveandsoakthebatteryinwateror
anyotherliquid.
• Nevertrytoopenthebatteryasitcontains
substances that might be harmful if swallowed
or allowed to come into contact with
unprotected skin.
• Donotremoveandshort-circuitthebattery,as
itmayoverheatandcauseare.Keepitaway
from jewelry or metal objects.
• Donotremoveanddisposeofthebattery
inre.Itcouldexplodeandreleaseharmful
substances into the environment.
• Donotremoveanddisposeofthebatterywith
yourregularhouseholdwaste.Takeittoa
hazardousmaterialcollectionpoint.
• Donottouchthebatteryterminals.
• Toavoidreorburns,donotdisassemble,
bend, crush, or puncture the battery.
E11709_ZB500KG_UM_Booklet_EU.indd 15 2016-09-12 09:58:59
NOTES:
• Riskofexplosionifbatteryisreplacedbyan
incorrect type.
• Disposeofusedbatteryaccordingtothe
instructions.
The charger
• UseonlythechargersuppliedwithyourASUS
Phone.
• Neverpullthechargercordtodisconnectit
from the power socket. Pull the charger itself.
Caution
YourASUSPhoneisahighqualitypieceof
equipment.Beforeoperating,readallinstructions
andcautionarymarkingsonthe(1)ACAdapter.
• DonotusetheASUSPhoneinanextreme
environment where high temperature or high
humidityexists.TheASUSPhoneperforms
optimally in an ambient temperature between 0
°C(32°F)and35°C(95°F).
• DonotdisassembletheASUSPhoneorits
accessories.Ifserviceorrepairisrequired,
returntheunittoanauthorizedservicecenter.
If the unit is disassembled, a risk of electric
shockorremayresult.
• Donotshort-circuitthebatteryterminalswith
metal items.
Operator access with a tool
IfaTOOLisnecessarytogainaccesstoan
OPERATORACCESSAREA,eitherallother
compartmentswithinthatareacontainingahazard
shallbeinaccessibletotheOPERATORbytheuse
ofthesameTOOL,orsuchcompartmentsshallbe
markedtodiscourageOPERATORaccess.
WARNING! Thisproductmaycontainchemicalsknown
totheStateofCaliforniatocausecancer,birthdefects,
orotherreproductiveharm.Washhandsafterhandling.
E11709_ZB500KG_UM_Booklet_EU.indd 16 2016-09-12 09:59:00
ASUS Recycling/Takeback
Services
ASUS recycling and takeback programs come
from our commitment to the highest standards for
protectingourenvironment.Webelieveinproviding
solutions for you to be able to responsibly recycle
our products, batteries, other components as well
as the packaging materials. Please go to http://
csr.asus.com/english/Takeback.htm for detailed
recycling information in different regions.
Proper disposal
Risk of explosion if battery is replaced
by an incorrect type. Dispose of used
batteries according to the instructions.
DONOTthrowthebatteryinmunicipal
waste.Thesymbolofthecrossedout
wheeled bin indicates that the battery
should not be placed in municipal waste.
DONOTthrowthisproductinmunicipal
waste.Thisproducthasbeendesigned
to enable proper reuse of parts and
recycling.Thesymbolofthecrossedout
wheeled bin indicates that the product
(electrical,electronicequipmentand
mercury-containingbuttoncellbattery)
should not be placed in municipal waste.
Checklocalregulationsfordisposalof
electronic products.
DONOTthrowthisproductinre.DO
NOTshortcircuitthecontacts.DONOT
disassemble this product.
WARNING! Thisproductmaycontainchemicalsknown
totheStateofCaliforniatocausecancer,birthdefects,
orotherreproductiveharm.Washhandsafterhandling.
E11709_ZB500KG_UM_Booklet_EU.indd 17 2016-09-12 09:59:00
EU Declaration of Conformity
We, the undersigned,
Manufacturer:
ASUSTeK COMPUTER INC.
Address:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Authorized representative in Europe:
ASUS COMPUTER GmbH
Address, City:
HARKORT STR. 21-23, 40880 RATINGEN
Country:
GERMANY
declare the following apparatus:
Product name : ASUS Phone
Model name :
ASUS_X00BD
The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:
EMC – Directive 2004/108/EC (until April 19th, 2016) and Directive 2014/30/EU (from April 20th, 2016)
EN 55022:2010+AC:2011
EN 55032:2012+AC:2013
EN 55024:2010
EN 61000-3-3:2013
EN 61000-3-2:2014
R&TTE – Directive 1999/5/EC
EN 300 328 V1.9.1(2015-02)
EN 300 330-1 V1.8.1(2015-03)
EN 300 330-2 V1.6.1(2015-03)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V12.1.1(2015-06)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V7.1.1(2015-12)
EN 301 908-13 V7.1.1(2015-12)
EN 301 893 V1.8.1(2015-03)
EN 62479:2010
EN 62311:2008
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.6.1(2013-08)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-10)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 50360:2001/A1:2012
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
LVD – Directive 2006/95/EC (until April 19th, 2016) and Directive 2014/35/EU (from April 20th, 2016)
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
Ecodesign – Directive 2009/125/EC
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
Regulation (EU) No. 617/2013
RoHS – Directive 2011/65/EU Ver. 160217
CE marking
Equipment Class 1
Signature
Jerry Shen
Printed Name
CEO
Position
Taipei, Taiwan
Place of issue
9/9/2016
Date of issue
2016
Year CE marking was first affixed
(EU conformity marking)
EU Konformitätserklärung
Hiermit erklären wir,
Hersteller:
ASUSTeK COMPUTER INC.
Anschrift:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Bevollmächtigter:
ASUS COMPUTER GmbH
Anschrift des Bevollmächtigten:
HARKORT STR. 21-23, 40880 RATINGEN
Land:
GERMANY
dass nachstehend bezeichnete Produkte
Produktbezeichnung ASUS Phone
Modellbezeichnung:
ASUS_X00BD
mit den nachstehend angegebenen, für das Produkt geltenden Richtlinien/Bestimmungen übereinstimmen:
EMV – Richtlinie 2004/108/EG (bis 19. April 2016) und Richtlinie 2014/30/EU ( ab 20. April 2016)
EN 55022:2010+AC:2011
EN 55032:2012+AC:2013
EN 55024:2010
EN 61000-3-3:2013
EN 61000-3-2:2014
R&TTE – Richtlinie 1999/5/EG
EN 300 328 V1.9.1(2015-02)
EN 300 330-1 V1.8.1(2015-03)
EN 300 330-2 V1.6.1(2015-03)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V12.1.1(2015-06)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V7.1.1(2015-12)
EN 301 908-13 V7.1.1(2015-12)
EN 301 893 V1.8.1(2015-03)
EN 62479:2010
EN 62311:2008
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.6.1(2013-08)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-10)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 50360:2001/A1:2012
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
LVD – Richtlinie 2006/95/EG (bis 19. April 20 16) und Richtlinie 2014/35/EU (ab 20. April 2016)
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
Ökodesign – Richtlinie 2009/125/EG
Verordnung (EG) No. 1275/2008
Verordnung (EG) No. 642/2009
Verordnung (EG) No. 278/2009
Verordnung (EU) No. 617/2013
RoHS – Richtlinie 2011/ 65 /EU Ver. 160217
CE Kennzeichen
Geräteklasse 1
Unterschrift
Jerry Shen
Name
CEO
Position
Taipei, Taiwan
Ort
9/9/2016
Datum
2016
Jahr der Kennzeichenvergabe
(EU Konformitätszeichen)
E11709_ZB500KG_UM_Booklet_EU.indd 18 2016-09-12 09:59:00
UE Declaración de Conformidad
Nosotros, los abajo firmantes,
Fabricante:
ASUSTeK COMPUTER INC.
Dirección:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Representante autorizado en Europa:
ASUS COMPUTER GmbH
Dirección, Ciudad:
HARKORT STR. 21-23, 40880 RATINGEN
País:
GERMANY
Declaramos el siguiente producto:
Nombre del aparato :
ASUS Phone
Nombre del modelo : ASUS_X00BD
El objeto de la declaración descrita anteriormente es conforme con la legislación de armonización pertinente de la Unión:
EMC Directiva 2004/108/CE (hasta el 19 de abril, 2016) y Directiva 2014/30/UE (desde el 20 de abril, 2016)
EN 55022:2010+AC:2011
EN 55032:2012+AC:2013
EN 55024:2010
EN 61000-3-3:2013
EN 61000-3-2:2014
R&TTE – Directiva 1999/5/CE
EN 300 328 V1.9.1(2015-02)
EN 300 330-1 V1.8.1(2015-03)
EN 300 330-2 V1.6.1(2015-03)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V12.1.1(2015-06)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V7.1.1(2015-12)
EN 301 908-13 V7.1.1(2015-12)
EN 301 893 V1.8.1(2015-03)
EN 62479:2010
EN 62311:2008
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.6.1(2013-08)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-10)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 50360:2001/A1:2012
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
LVD Directiva 2006/95/CE (hasta el 19 de abril, 2016) y Directiva 2014/35/UE (desde el 20 de abril, 2016)
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
Diseño Ecológico – Directiva 2009/125/CE
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
Regulation (EU) No. 617/2013
RoHS – Directiva 2011/65/UE Ver. 160217
Marcado CE
Clase de equipo 1
Firma
Jerry Shen
Nombre impreso
CEO
Posición
Taipei, Taiwan
Lugar de emisión
9/9/2016
Fecha de emisión
2016
Año en que se colocó
el marcado CE por primera vez
(marcado CE de conformidad)
DECLARATION UE DE CONFORMITE
Nous, soussignés
Fabricant:
ASUSTeK COMPUTER INC.
Adresse:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Représentant autorisé en Europe:
ASUS COMPUTER GmbH
Adresse, ville:
HARKORT STR. 21-23, 40880 RATINGEN
Pays:
GERMANY
Déclarons l’appareil suivant:
Nom du produit :
ASUS Phone
Nom du modèle :
ASUS_X00BD
L’objet de la déclaration décrit ci-dessus est conforme avec la législation d’harmonisation de l’Union applicable
Directive CEM 2004/108/CE (jusqu’au 19 avril 2016) et la directive 201 4/30/UE (à partir du 20 avril 2016)
EN 55022:2010+AC:2011
EN 55032:2012+AC:2013
EN 55024:2010
EN 61000-3-3:2013
EN 61000-3-2:2014
Directive R&TTE 1999/5/CE
EN 300 328 V1.9.1(2015-02)
EN 300 330-1 V1.8.1(2015-03)
EN 300 330-2 V1.6.1(2015-03)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V12.1.1(2015-06)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V7.1.1(2015-12)
EN 301 908-13 V7.1.1(2015-12)
EN 301 893 V1.8.1(2015-03)
EN 62479:2010
EN 62311:2008
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.6.1(2013-08)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-10)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 50360:2001/A1:2012
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
Directive LVD 2006//125/CE (jusqu’au 19 avril 2016) et la directive 2014/34/UE (à partir du 20 avril 2016)
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
Directive écoconception 2009/125/CE
Regulation (CE) No. 1275/2008
Regulation (CE) No. 642/2009
Regulation (CE) No. 278/2009
Regulation (UE) No. 617/2013
Directive RoHS 2011/65/UE Ver. 160217
Marquage CE
Equipement de classe 1
Signature
Jerry Shen
Nom en caractères d’imprimerie
CEO
Position
Taipei, Taiwan
Lieu de délivrance
9/9/2016
Date d'Emission
2016
Année où commence l’apposition
du marquage CE
(Marquage UE de conformité)
E11709_ZB500KG_UM_Booklet_EU.indd 19 2016-09-12 09:59:01
Declaração CE de Conformidade
Nós, os abaixo-assinados,
Fabricante:
ASUSTeK COMPUTER INC.
Endereço:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Representante autorizado na Europa:
ASUS COMPUTER GmbH
Endereço, cidade:
HARKORT STR. 21-23, 40880 RATINGEN
País:
GERMANY
declaramos o seguinte aparelho:
Nome do produto:
ASUS Phone
Nome do modelo:
ASUS_X00BD
O objeto da declaração acima descrito está em conformidade com a legislação de harmonização da União aplicável:
EMC Diretiva 2004/108/CE (até 19 de abril de 2016) e Diretiva 2014/30/UE (a partir de 20 de abril de 2016)
EN 55022:2010+AC:2011
EN 55032:2012+AC:2013
EN 55024:2010
EN 61000-3-3:2013
EN 61000-3-2:2014
R&TTE – Diretiva 1999/5/CE
EN 300 328 V1.9.1(2015-02)
EN 300 330-1 V1.8.1(2015-03)
EN 300 330-2 V1.6.1(2015-03)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V12.1.1(2015-06)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V7.1.1(2015-12)
EN 301 908-13 V7.1.1(2015-12)
EN 301 893 V1.8.1(2015-03)
EN 62479:2010
EN 62311:2008
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.6.1(2013-08)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-10)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 50360:2001/A1:2012
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
LVD Diretiva 2006/95/CE (até 19 de abril de 2016) and Diretiva 2014/35/UE (a partir de 20 de abril de 2016)
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
EcoEcodesign – Diretiva 2009/125/CE
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
Regulation (EU) No. 617/2013
RoHS – Diretiva 2011/65/UE Ver. 160217
Marcação CE
Classe de equipamento 1
Assinatura
Jerry Shen
Nome impresso
CEO
Posição
Taipei, Taiwan
Local de emissão
9/9/2016
Data de emissão
2016
Ano marcação CE foi aposta por primeira vez
(Marcação CE de conformidade)
Declaraţie de conformitate UE
Subsemnatul,
Producător :
ASUSTeK COMPUTER INC.
Adresă:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Reprezentant autorizat în Europa:
ASUS COMPUTER GmbH
Adresă, Oraş:
HARKORT STR. 21-23, 40880 RATINGEN
Ţară:
GERMANIA
declară următorul aparat:
Nume Produs :
ASUS Phone
Nume Model :
ASUS_X00BD
Obiectul declarației descris mai sus este în conformitate cu legislația relevantă de armonizare a Uniunii :
CEM – Directiva 2004/108/CE (până în 19 Aprilie 2016) şi Directiva 2014/30/UE (până în 20 Aprilie 2016)
EN 55022:2010+AC:2011
EN 55032:2012+AC:2013
EN 55024:2010
EN 61000-3-3:2013
EN 61000-3-2:2014
R&TTE – Directiva 1999/5/CE
EN 300 328 V1.9.1(2015-02)
EN 300 330-1 V1.8.1(2015-03)
EN 300 330-2 V1.6.1(2015-03)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V12.1.1(2015-06)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V7.1.1(2015-12)
EN 301 908-13 V7.1.1(2015-12)
EN 301 893 V1.8.1(2015-03)
EN 62479:2010
EN 62311:2008
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.6.1(2013-08)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-10)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 50360:2001/A1:2012
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
LVD – Directiva 2006/95/CE (până în 19 Aprilie 2016) şi Directiva 2014/35/UE (până în 20 Aprilie 2016)
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
Ecodesign – Directiva 2009/125/CE
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
Regulation (EU) No. 617/2013
RoHS – Directiva 2011/65/UE Ver. 160217
Marcajul CE
Echipament Clasa 1
Semnătură
Jerry Shen
Nume
CEO
Funcţie
Taipei, Taiwan
Locul emiterii
9/9/2016
Data emiterii
2016
Anul în care Marcajul CE a fost aplicat pentru
prima oară
(Marcaj de conformitate UE )
E11709_ZB500KG_UM_Booklet_EU.indd 20 2016-09-12 09:59:01
EU Uygunluk Beyanı
Biz, bu imza altındakiler
Üretici:
ASUSTeK COMPUTER INC.
Adres:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Avrupa’daki Yetkili:
ASUS COMPUTER GmbH
Adres, Şehir:
HARKORT STR. 21-23, 40880 RATINGEN
Ülke:
ALMANYA
Aşağıdaki ürünleri beyan ediyoruz :
Ürün adı :
ASUS Phone
Model adı : ASUS_X00BD
Yukarıda belirtilen beyanın konusu birlik yasalarına göre uygundur:
EMC – Direktif 2004/108/EC 19 Nisan 2016’ya kadar ve Direktif 2014/30/EU 20 Nis an 2016
EN 55022:2010+AC:2011
EN 55032:2012+AC:2013
EN 55024:2010
EN 61000-3-3:2013
EN 61000-3-2:2014
R&TTE – Direktifi 1999/5/EC
EN 300 328 V1.9.1(2015-02)
EN 300 330-1 V1.8.1(2015-03)
EN 300 330-2 V1.6.1(2015-03)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V12.1.1(2015-06)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V7.1.1(2015-12)
EN 301 908-13 V7.1.1(2015-12)
EN 301 893 V1.8.1(2015-03)
EN 62479:2010
EN 62311:2008
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.6.1(2013-08)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-10)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 50360:2001/A1:2012
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
LVD – Direktifi 2006/95/19 Nisan 2016’ya kadar ve Direktif 2014/35/EU 20 Nisan 2016
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
Ecodesign – Direktif 2009/125/EC
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
Regulation (EU) No. 617/2013
RoHS – Direktifi 2011/65/EU Ver. 160217
CE işareti
Ekipman Sınıfı 1
İmza
Jerry Shen
Basılı Ad
CEO
Pozisyonu
Taipei, Taiwan
Sürüm yeri
9/9/2016
Sürüm tarihi
2016
CE işaretinin ilk eklendiği yıl
(EU uygunluk işareti)
E11709_ZB500KG_UM_Booklet_EU.indd 21 2016-09-12 09:59:01
Copyright©2016ASUSTeKCOMPUTERINC.
AllRightsReserved.
YouacknowledgethatallrightsofthisManualremainwithASUS.
Any and all rights, including without limitation, in the Manual or
website,andshallremaintheexclusivepropertyofASUSand/orits
licensors. Nothing in this Manual intends to transfer any such rights,
or to vest any such rights to you.
ASUSPROVIDESTHISMANUAL“ASIS”WITHOUTWARRANTY
OFANYKIND.SPECIFICATIONSANDINFORMATION
CONTAINEDINTHISMANUALAREFURNISHEDFOR
INFORMATIONALUSEONLY,ANDARESUBJECTTOCHANGE
ATANYTIMEWITHOUTNOTICE,ANDSHOULDNOTBE
CONSTRUEDASACOMMITMENTBYASUS.
ASUS
Address: 4F, No.150 Li-Te Rd., Peitou, Taipei,
Taiwan
Tel: 886228943447
Fax: 886228907698
Declaration
WedeclarethattheIMEIcodesforthisproduct,ASUS
Phone,areuniquetoeachunitandonlyassignedto
thismodel.TheIMEIofeachunitisfactorysetand
cannot be altered by the user and that it complies
withtherelevantIMEIintegrityrelatedrequirements
expressedintheGSMstandards.
Shouldyouhaveanyquestionsorcommentsregarding
this matter, please contact us.
Sincerely yours,
ASUSTeK COMPUTER INC.
Tel:886228943447
Fax:886228907698
Support:http://vip.asus.com/eservice/techserv.aspx
ZenTalk Fans Forum
(http://www.asus.com/zentalk/global_forward.php)
E11709_ZB500KG_UM_Booklet_EU.indd 22 2016-09-12 09:59:01

Navigation menu
