Technical-Users Manual (statement)_MSQZ00D

Important Notices
Copyright © 2015 ASUSTeK
COMPUTER INC.
All Rights Reserved.
No part of this manual, including the
products and software described in
it, may be reproduced, transmitted,
transcribed, stored in a retrieval
system, or translated into any language
in any form or by any means, except
documentation kept by the purchaser
for backup purposes, without the
express written permission of
ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be
extended if: (1) the product is repaired,
modied or altered, unless such repair,
modication of alteration is authorized
in writing by ASUS; or (2) the serial
number of the product is defaced or
missing.
ASUS PROVIDES THIS MANUAL
“AS IS” WITHOUT WARRANTY
OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT
NOT LIMITED TO THE IMPLIED
WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL ASUS,
ITS DIRECTORS, OFFICERS,
EMPLOYEES OR AGENTS BE
First Edition
January 2015
LIABLE FOR ANY INDIRECT,
SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES
(INCLUDING DAMAGES FOR
LOSS OF PROFITS, LOSS OF
BUSINESS, LOSS OF USE OR DATA,
INTERRUPTION OF BUSINESS
AND THE LIKE), EVEN IF ASUS
HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES
ARISING FROM ANY DEFECT
OR ERROR IN THIS MANUAL OR
PRODUCT.
SPECIFICATIONS AND
INFORMATION CONTAINED IN THIS
MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND
ARE SUBJECT TO CHANGE AT
ANY TIME WITHOUT NOTICE, AND
SHOULD NOT BE CONSTRUED AS
A COMMITMENT BY ASUS. ASUS
ASSUMES NO RESPONSIBILITY OR
LIABILITY FOR ANY ERRORS OR
INACCURACIES THAT MAY APPEAR
IN THIS MANUAL, INCLUDING
THE PRODUCTS AND SOFTWARE
DESCRIBED IN IT.
Products and corporate names
appearing in this manual may or
may not be registered trademarks
or copyrights of their respective
companies, and are used only for
identication or explanation and to
the owners’ benet, without intent to
infringe.
Safety information
ASUS Phone care
• Do not leave your ASUS Phone
exposed to strong sunlight or
excessive heat for a prolonged
period. This may damage it.
• Do not handle your ASUS Phone
with wet hands or expose it to
moisture or liquids of any kind.
Continuous changes from a cold
to a warm environment may lead
to condensation inside your ASUS
Phone, resulting in corrosion and
possible damage.
• If you pack your ASUS Phone in
your suitcase during travel, beware
of damage. Cramming the device
into a suitcase may crack the LCD
display. Remember to switch off
your wireless connection during air
travel.
• Use your ASUS Phone in an
environment with ambient
temperatures between -10 °C (14
°F) and 35 °C (95 °F).
IMPORTANT! To provide
electrical insulation and
maintain electrical safety, a
coating is applied to insulate
the ASUS Phone body except
on the sides where the I/O
ports are located.
The battery
Your ASUS Phone is equipped with
a high performance non-detachable
Li-Ion battery. Observe the following
maintenance guidelines for a longer
battery life:
• Avoid charging in extremely high
or low temperature. The battery
performs optimally in an ambient
temperature of +5 °C to +35 °C.
• Do not remove and replace the
battery with a non-approved
battery.
• Do not remove and immerse the
battery in water or any other liquid.
• Never try to open the battery as it
contains substances that might be
harmful if swallowed or allowed to
come into contact with unprotected
skin.
• Do not remove and short-circuit
the battery, as it may overheat and
cause a re. Keep it away from
jewellery and other metal objects.
• Do not remove and dispose of the
battery in re. It could explode and
release harmful substances into
the environment.
• Do not remove and dispose of
the battery with your regular
household waste. Take it to a
hazardous material collection
point.
• Do not touch the battery terminals.
CAUTION:
• Risk of explosion if battery
is replaced by an incorrect
type.
• Dispose of used
batteries according to the
instructions.
The charger
• Use only the charger supplied with
your ASUS Phone.
• Never pull the charger cord to
disconnect it from the power
socket. Pull the charger itself.
Cleaning and storing
• Your ASUS Phone should
always be handled with care
and protected from dirt, dust and
dampness. To avoid scratches,
never place your ASUS Phone
face down.
• If cleaning is necessary, turn your
ASUS Phone off and wipe carefully
with a soft, slightly damp (not wet)
cloth. Use a cotton swab to clean
the camera lens. Allow your ASUS
Phone to dry completely before
switching it on. Never use solvents
for cleaning.
• If you are not going to use your
ASUS Phone for some time, fully
charge the battery and store your
ASUS Phone in a dry place away
from direct sunlight. Your ASUS
Phone should be switched off
during storage. Recharge every 6
to 12 months.
• Never expose your ASUS Phone
to heat or strong sunlight.
• Never expose your ASUS Phone
to moisture or liquids of any kind.
• Do not place stickers that may
block the keypad or affect
other components such as the
microphone, earpiece, or camera
lens.
WARNING! Failure to follow
these instructions may lead
to serious personal injury and
possible property damage.
Driving safely
Never use handheld phones while
driving. It is an offence, that while
driving, to hold a phone or cradle it
in your neck at any point, during the
setup, making or taking of a phone
call, text message or any other data
related mobile communication. Use of
fully installed car kits are still permitted,
as are the use of alternate handsfree
accessories.
In the interest of safety, we would
recommend the use of a cradle
while using any form of handsfree
accessory.
While driving, we recommend that you
use voicemail wherever possible, and
that you listen to your messages when
you are not in the car. If you must
make a handsfree call when driving,
keep it brief.
Do not place objects, including
both installed or portable wireless
equipment, in the area over the airbag
or in the airbag deployment area. An
airbag inates with great force. If the
airbag inates, serious injury could
result.
Electronic devices
Most modern electronic equipment is
shielded from RF energy.
However, certain electronic equipment
may not be shielded against the RF
signals from your device.
Pacemakers
The Health Industry Manufacturers’
Association recommends that a
minimum separation of six (6”)
inches be maintained between a
phone and a pacemaker to avoid
potential interference with the
pacemaker. These recommendations
are consistent with the independent
research by and recommendations of
Wireless Technology Research.
If you have a pacemaker:
• Always keep your ASUS Phone
more than six inches (15cm) from
your pacemaker when turned on.
• Do not carry your ASUS Phone in
your breast pocket.
• Use the ear opposite the
pacemaker to minimize the
potential for interference.
• If you have any reason to suspect
that interference is taking place,
switch off your ASUS Phone
immediately.
Hearing aids
Some digital phones may interfere
with some hearing aids. In the event of
such interference, call ASUS Customer
Service to discuss alternatives.
Other medical devices
If you use any other personal medical
device, consult the manufacturer
of your device to determine if it is
adequately shielded from external RF
energy. Your physician may be able to
assist you in obtaining this information.
Turn your ASUS Phone off in
healthcare facilities when any
regulations posted in these areas
instruct you to do so.
Hospitals or healthcare facilities may
be using equipment that could be
sensitive to external RF energy.
Vehicles
RF signals may affect improperly
installed or inadequately shielded
electronic systems in motor vehicles.
Check with the manufacturer or
its representative regarding your
vehicle. You should also consult the
manufacturer of any equipment added
to your vehicle.
Posted facilities
Turn your ASUS Phone off where
posted notices so require.
Magnetic media
Magnetic elds generated by mobile
devices may damage data on
magnetic storage media, such as
credit cards, computer discs or tapes.
Do not place your ASUS Phone next to
such media.
You should never expose your ASUS
Phone to strong magnetic elds as this
may cause temporary malfunction.
Other Safety Guidelines
Aircraft
Regulations prohibit using your mobile
device while onboard an aircraft.
Switch off your ASUS Phone before
boarding an aircraft or turn off the
wireless connection.
Blasting areas
To avoid interfering with blasting
operations, turn your ASUS Phone off
when in a ‘blasting area’ or in areas
posted: “Turn off two-way radio.” Obey
all signs and instructions.
Potentially explosive environments
Turn your ASUS Phone off when in
any area with a potentially explosive
environment and obey all signs and
instructions.
Sparks in such areas could cause an
explosion or re resulting in bodily
injury or even death.
Areas with a potentially explosive
environment are often, but not always,
clearly marked. They include fuelling
areas such as gas stations, below
decks on boats, fuel or chemical
transfer or storage facilities, vehicles
using liquied petroleum gas (such
as propane or butane), areas where
the air contains chemicals or articles,
such as grain, dust, or metal powders,
and any other area where you would
normally be advised to turn off your
vehicle’s engine.
Choking
Keep your ASUS Phone away from
children as the SIM card and other
small parts present a choking hazard.
Caution
Your ASUS Phone is a high quality
piece of equipment. Before operating,
read all instructions and cautionary
markings on the (1) AC Adapter.
• Do not use the ASUS Phone
in an extreme environment
where high temperature or high
humidity exists. The ASUS Phone
performs optimally in an ambient
temperature between -15 °C (5 °F)
and 35 °C (95 °F).
• Do not abuse the ASUS Phone.
Avoid striking, shaking, or
subjecting the device to impact.
When not using the unit, place
the device in a safe place to avoid
damage to the product.
• Do not expose the ASUS Phone to
rain or moisture.
• Do not use unauthorized
accessories.
• Do not disassemble the ASUS
Phone or its accessories. If service
or repair is required, return the unit
to an authorized service center. If
the unit is disassembled, a risk of
electric shock or re may result.
• Do not short-circuit the battery
terminals with metal items.
• Avoid dropping the phone or
battery. If the phone or battery
is dropped, especially on a hard
surface, and the user suspects
damage, take it to a service center
for inspection.
• The phone shall only be connected
to CTIA certied adapters, products
that bear the USB-IF logo or
products that have completed the
USB-IF compliance program.
Operator access with a tool
If a TOOL is necessary to gain access
to an OPERATOR ACCESS AREA,
either all other compartments within
that area containing a hazard shall be
inaccessible to the OPERATOR by
the use of the same TOOL, or such
compartments shall be marked to
discourage OPERATOR access.
An acceptable marking for an electric
shock hazard is (ISO 3864, No. 5036).
Equipment for restricted access
locations
For equipment intended only for
installation in a RESTRICTED ACCESS
LOCATION, the installation instructions
shall contain a statement to this effect.
WARNING: The user needs
to switch off the device
when exposed to areas
with potentially explosive
atmospheres such as petrol
stations, chemical storage
depots and blasting operations.
Federal Communication
Commission Interference
Statement
This device complies with part 15 of
the FCC Rules. Operation is subject
to the following two conditions: (1)
This device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may cause
undesired operation.
This device has been tested and
found to comply with the limits for a
Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits
are designed to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses, and
can radiate radio frequency energy,
and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is
no guarantee that interference will
not occur in a particular installation If
this equipment does cause harmful
interference to radio or television
reception, which can be determined
by turning the equipment off and on,
the user is encouraged to try to correct
the interference by one or more of the
following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between
the equipment and receiver.
• Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.
• Consult the dealer or an
experienced radio/TV technician
for help.
FCC Caution:
Any Changes or modications not
expressly approved by the party
responsible for compliance could void
the user‘s authority to operate the
equipment.
The antenna(s) used for this
transmitter must not be co-located or
operating in conjunction with any other
antenna or transmitter.
NOTE: The country code
selection is for non-US model
only and is not available to all
US model. Per FCC regulation,
all WiFi product marketed in
US must xed to US operation
channels only.
RF Exposure Information
(SAR)
This device meets the government’s
requirements for exposure to radio
waves.
This device is designed and
manufactured not to exceed the
emission limits for exposure to radio
frequency (RF) energy set by the
Federal Communications Commission
of the U.S. Government.
The exposure standard for wireless
device employs a unit of measurement
known as the Specic Absorption
Rate, or SAR. The SAR limit set by
the FCC is 1.6W/kg. Tests for SAR are
conducted using standard operating
positions accepted by the FCC with
the device transmitting at its highest
certied power level in all tested
frequency bands. Although the SAR
is determined at the highest certied
power level, the actual SAR level of
the device while operating can be
well below the maximum value. This
is because the device is designed to
operate at multiple power levels so as
to use only the poser required to reach
the network. In general, the closer you
are to a wireless base station antenna,
the lower the power output.
The highest SAR value for the model
device as reported to the FCC when
tested for use at the ear is 0.52 W/
kg and when worn on the body, as
described in this user guide, is 1.18 W/
kg (Body-worn measurements differ
among device models, depending
upon available accessories and FCC
requirements.)
While there may be differences
between the SAR levels of various
devices and at various positions, they
all meet the government requirement.
The FCC has granted an Equipment
Authorization for this model device
with all reported SAR levels evaluated
as in compliance with the FCC RF
exposure guidelines. SAR information
on this model device is on le with
the FCC and can be found under the
Display Grant section of www.fcc.gov/
oet/ea/fccid after searching on FCC ID:
MSQZ00D.
For body worn operation, this device
has been tested and meets the FCC
RF exposure guidelines for use with an
accessory that contains no metal and
be positioned a minimum of 1cm from
the body. Use of other accessories
may not ensure compliance with FCC
RF exposure guidelines. If you do
not use a body-worn accessory and
are not holding the device at the ear,
position the handset a minimum of
1cm from your body when the device
is switched on.
continued on the next page
The maximum SAR value when using
the headset for each frequency band is
listed below:
Band Position SAR 1g
(W/kg)
GSM850
Head 0.33
Body (1.0cm
Gap) 0.57
Hotspot
(1.0cm Gap) 1.15
GSM1900
Head 0.22
Body (1.0cm
Gap) 0.32
Hotspot
(1.0cm Gap) 0.66
WCDMA II
Head 0.39
Body (1.0cm
Gap) 0.57
Hotspot
(1.0cm Gap) 0.67
WCDMA V
Head 0.33
Body (1.0cm
Gap) 0.57
Hotspot
(1.0cm Gap) 0.57
LTE 2
Head 0.30
Body (1.0cm
Gap) 0.51
Hotspot
(1.0cm Gap) 0.56
Band Position SAR 1g
(W/kg)
LTE 4
Head 0.52
Body (1.0cm
Gap) 1.18
Hotspot
(1.0cm Gap) 1.23
LTE 5
Head 0.29
Body (1.0cm
Gap) 0.37
Hotspot
(1.0cm Gap) 0.38
LTE 7
Head 0.13
Body (1.0cm
Gap) 0.26
Hotspot
(1.0cm Gap) 0.26
LTE 17
Head 0.24
Body (1.0cm
Gap) 0.45
Hotspot
(1.0cm Gap) 0.45
2.4G
WLAN
Head 0.48
Body (1.0cm
Gap) 0.38
Hotspot
(1.0cm Gap) 0.38
Bluetooth
Head N/A
Body (1.0cm
Gap) N/A
Hotspot
(1.0cm Gap) N/A
Hearing Aid Compatibility
(HAC)
This phone has been tested and
rated for use with hearing aids for
some of the wireless technologies
that it uses. However, there may be
some newer wireless technologies
used in this phone that have not
been tested yet for use with hearing
aids. It is important to try the different
features of this phone thoroughly
and in different locations, using your
hearing aid or cochlear implant, to
determine if you hear any interfering
noise. Consult your service provider
or the manufacturer of this phone
for information on hearing aid
compatibility. If you have questions
about return or exchange policies,
consult your service
To determine the compatibility of a WD
and a particular hearing aid, simply
add the numerical part of the hearing
aid category (e.g. M2/T2=2) with the
numerical part of the WD emission
rating (e.g., M3=3) to arrive at the
system classication for this particular
combination of WD and hearing aid. A
sum of 5 would indicate that the WD
and hearing aid would provide normal
use, and a sum of 6 or greater would
indicate that the WD and hearing aid
would provide excellent performance.
A category sum of less than 4 would
likely result in a performance that is
judged unacceptable by the hearing
aid user.
WHAT IS HEARING AID
COMPATIBILITY?
The Federal Communications
Commission has implemented rules
and a rating system designed to
enable people who wear hearing
aids to more effectively use these
wireless telecommunications devices.
The standard for compatibility of
digital wireless phones with hearing
aids is set forth in American National
Standard Institute (ANSI) standard
C63.19. There are two sets of ANSI
standards with ratings from one to
four (four being the best rating): an
“M” rating for reduced interference
making it easier to hear conversations
on the phone when using the hearing
aid microphone, and a “T” rating
that enables the phone to be used
with hearing aids operating in the
telecoil mode thus reducing unwanted
background noise.
HOW WILL I KNOW WHICH
WIRELESS PHONES ARE HEARING
AID COMPATIBLE?
The Hearing Aid Compatibility rating is
displayed on the wireless phone box.
A phone is considered Hearing Aid
Compatible for acoustic coupling
(microphone mode) if it has an “M3” or
“M4” rating. A digital wireless phone is
considered Hearing Aid Compatible for
inductive coupling (telecoil mode) if it
has a “T3” or “T4” rating.
The tested M-Rating and T-Rating for
this device (FCC ID: MSQZ00D) are
M3 and T3.
HOW WILL I KNOW IF MY
HEARING AID WILL WORK WITH A
PARTICULAR DIGITAL WIRELESS
PHONE?
You’ll want to try a number of wireless
phones so that you can decide which
works the best with your hearing aids.
You may also want to talk with your
hearing aid professional about the
extent to which your hearing aids are
immune to interference, if they have
wireless phone shielding, and whether
your hearing aid has a HAC rating.
ASUS
Address: 4F, No. 150 Li-Te Road,
Peitou, Taipei, Taiwan
Tel: 886228943447;
Fax: 886228907698
Declaration
We declare that the IMEI codes
for this product, Z00D, are unique
to each unit and only assigned to
this model. The IMEI of each unit
is factory set and cannot be altered
by the user and that it complies with
the relevant IMEI integrity related
requirements expressed in the GSM
standards.
Should you have any questions or
comments regarding this matter,
please contact us.
Sincerely yours,
ASUSTeK COMPUTER INC.
Tel: 886228943447
Fax: 886228907698
Email: http://vip.asus.com/eservice/
techserv.aspx
15060-53600000

Navigation menu
