Users Manual
First Edition/ September 2015
Model: ASUS_Z00XS (ZX551ML)
Before you start, ensure that you have read all the safety
information and operating instructions in this User Guide
to prevent injury or damage to your device.
NOTE: For the latest updates and more detailed
information, please visit www.asus.com.
Front features
Receiver
Light sensor
Touch screen
display
Power key
Volume key
Touch keys
P-sensor
Front camera
Side features
NOTE: Pry open the rear cover from the groove.
Audio jack
Micro USB port Speaker
Power key
Record key
Shutter key
Volume key
Strap hole GrooveMicrophone
Rear features
NOTES:
• RemovetherearcovertodisplaythemicroSIM
and microSD card slots.
• ThemicroSIMcardslotsupportsWCDMA,DC-
HSPA,GSM/EDGE,andFDD-LTEnetworkbands.
• ThemicroSDcardslotsupportsmicroSDand
microSDHCcardformats.
Flash
Laser focus
Rear camera
Rear cover
Speaker
Charging your ASUS Phone
To charge your ASUS Phone:
1. ConnecttheUSBconnectorintothepoweradapter’s
USB port.
2. ConnecttheotherendofthemicroUSBcableto
your ASUS Phone.
3. Plugthepoweradapterintoawallsocket.
NOTES:
• Useonlythepoweradapterthatcamewithyour
device.Usingadifferentpoweradaptermay
damage your device.
• UsingthebundledpoweradapterandASUSPhone
signal cable to connect your ASUS Phone to a
poweroutletisthebestwaytochargeyourASUS
Phone.
• Theinputvoltagerangebetweenthewalloutletand
thisadapterisAC100V-240V.Theoutputvoltage
ofthemicroUSBcableis+9V 2A,18W.
IMPORTANT!
• WhenusingyourASUSPhonewhileitispluggedto
apoweroutlet,thegroundedpoweroutletmustbe
near to the unit and easily accessible.
• WhenchargingyourASUSPhonethroughyour
computer, ensure that you plug the micro USB
cabletoyourcomputer’sUSB2.0/USB3.0port.
• AvoidchargingyourASUSPhoneinan
environmentwithambienttemperatureofabove
35oC(95oF).
3
1
2
3. InsertthemicroSIMcard
intothemicroSIMcardslot.
1. Locate the groove at the
bottom of your ASUS Phone.
Installing a micro SIM card
To install a micro SIM card:
2. Pry the cover loose and then
pull the rear cover off.
IMPORTANT: UseonlyamicroSIMcardonyourASUS
Phone.AtrimmedSIMcardmaynotproperlytintoand
may not be detected by your ASUS Phone.
1. Locate the groove at the
bottom of your ASUS Phone.
Installing a microSD card
To install a microSD card:
2. Pry the cover loose and then
pull the rear cover off.
3. InsertthemicroSDcardinto
the microSD card slot.
CAUTION: Do not use sharp tools or solvent on your
device to avoid scratches on it.
IMPORTANT: ThersttimeyoupoweronyourASUS
Phone,youwillseetheWelcomescreen.Touchthe
menu to select your preferred language then touch Next
Step.Followtheonscreeninstructionstosetupyour
ASUS Phone.
Turning your ASUS Phone on or off
PressthepowerkeyattherightsideofyourASUSPhone
topowerthedeviceonortopoweritoff.
Federal Communications Commission
Statement
Thisdevicecomplieswithpart15oftheFCCRules.
Operationissubjecttothefollowingtwoconditions:(1)
Thisdevicemaynotcauseharmfulinterference,and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Changesormodicationsnotexpresslyapprovedbythe
party responsible for compliance could void the user‘s
authority to operate the equipment.
Thisequipmenthasbeentestedandfoundtocomplywith
thelimitsforaClassBdigitaldevice,pursuanttopart15
oftheFCCRules.Theselimitsaredesignedtoprovide
reasonable protection against harmful interference in
aresidentialinstallation.Thisequipmentgenerates,
uses and can radiate radio frequency energy and, if not
installedandusedinaccordancewiththeinstructions,
may cause harmful interference to radio communications.
However,thereisnoguaranteethatinterferencewillnot
occurinaparticularinstallation.Ifthisequipmentdoes
cause harmful interference to radio or television reception,
whichcanbedeterminedbyturningtheequipment
off and on, the user is encouraged to try to correct the
interferencebyoneormoreofthefollowingmeasures:
- Reorientorrelocatethereceivingantenna.
- Increasetheseparationbetweentheequipmentand
receiver.
- Connecttheequipmentintoanoutletonacircuit
differentfromthattowhichthereceiverisconnected.
- Consultthedealeroranexperiencedradio/TV
technician for help.
Theantenna(s)usedforthistransmittermustnotbeco-
locatedoroperatinginconjunctionwithanyotherantenna
or transmitter.
Thecountrycodeselectionisfornon-USmodelonlyand
isnotavailabletoallUSmodel.PerFCCregulation,all
WiFiproductmarketedinUSmustxedtoUSoperation
channels only.
User Guide
E10512
Power key
CAUTION:
• High-powerradarsareallocatedasprimaryusers
(i.e.priorityusers)ofthebands5250-5350MHzand
5650-5850MHzandthattheseradarscouldcause
interferenceand/ordamagetoLE-LANdevices.
• 5GHzproductforindooruseonly.
Hearing Aid Compatibility Information
(HAC)
YourphoneiscompliantwiththeFCCHearingAid
Compatibilityrequirements.
TheFCChasadoptedHACrulesfordigitalwireless
phones.Theserulesrequirecertainphonetobetested
andratedundertheAmericanNationalStandardInstitute
(ANSI)C63.19-2011hearingaidcompatibilitystandards.
TheANSIstandardforhearingaidcompatibilitycontains
twotypesofratings:
M-Ratings:Ratingforlessradiofrequencyinterferenceto
enableacousticcouplingwithhearingaids.
T-Ratings:Ratingforinductivecouplingwithhearingaids
in telecoil mode.
Notallphoneshavebeenrated,aphoneisconsidered
hearingaidcompatibleunderFCCrulesifitisratedM3
orM4foracousticcouplingandT3orT4forinductive
coupling.Theseratingsaregivenonascalefromone
tofour,wherefouristhemostcompatible.Yourphone
meetstheM4/T4levelrating.
However,hearingaidcompatibilityratingsdon’tguarantee
thatinterferencetoyourhearingaidswon’thappen.
Resultswillvary,dependingonthelevelofimmunity
of your hearing device and the degree of your hearing
loss.Ifyourhearingdevicehappenstobevulnerableto
interference, you may not be able to use a rated phone
successfully.Tryingoutthephonewithyourhearing
deviceisthebestwaytoevaluateitforyourpersonal
needs.
Thisphonehasbeentestedandratedforusewith
hearingaidsforsomeofthewirelesstechnologiesthat
ituses.However,theremaybesomenewerwireless
technologies used in this phone that have not been tested
thefollowingwebaddress:http://www.ic.gc.ca/app/sitt/
reltel/srch/nwRdSrch.do?lang=eng
AdditionalCanadianinformationonRFexposurealsocan
befoundatthefollowingwebaddress:http://www.ic.gc.
ca/eic/site/smt-gst.nsf/eng/sf08792.html
Informations concernant l’exposition aux fréquences
radio (RF)
Lapuissancedesortieémiseparcetappareilsansl
estinférieureàlalimited’expositionauxfréquences
radiod’IndustrieCanada(IC).Utilisezl’appareilsans
ldefaçonàminimiserlescontactshumainslorsdu
fonctionnement normal.
Cepériphériqueaétéévaluéetdémontréconforme
auxlimitesSAR(SpecicAbsorptionRate–Taux
d’absorptionspécique)d’IClorsqu’ilestinstallédans
des produits hôtes particuliers qui fonctionnent dans des
conditionsd’expositionàdesappareilsportables.
Cepériphériqueesthomologuépourl’utilisationau
Canada.Pourconsulterl’entréecorrespondantà
l’appareildanslalisted’équipementradio(REL-Radio
EquipmentList)d’IndustrieCanadarendez-voussur:
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.
do?lang=eng
Pour des informations supplémentaires concernant
l’expositionauxRFauCanadarendez-voussur:
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
Caution
(i) thedeviceforoperationintheband5150-5250MHz
is only for indoor use to reduce the potential for
harmfulinterferencetoco-channelmobilesatellite
systems;
(ii) themaximumantennagainpermittedfordevices
intheband5725-5825MHzshallcomplywiththe
e.i.r.p.limitsspeciedforpoint-to-pointandnon
point-to-pointoperationasappropriate.
Avertissement
Leguided’utilisationdesdispositifspourréseauxlocaux
doit inclure des instructions précises sur les restrictions
susmentionnées, notamment:
yetforusewithhearingaids.Itisimportanttotrythe
different features of this phone thoroughly and in different
locations, using your hearing aid or cochlear implant,
todetermineifyouhearanyinterferingnoise.Consult
your service provider or the manufacturer of this phone
forinformationonhearingaidcompatibility.Ifyouhave
questionsaboutreturnorexchangepolicies,consultyour
service provider or phone retailer.
Hearing devices may also be rated. Your hearing device
manufacturer or hearing health professional may help you
ndthisrating.FormoreinformationaboutFCCHearing
AidCompatibility,pleasegotohttp://www.fcc.gov/cgb/dro.
Canada, Industry Canada (IC) Notices
ThisdevicecomplieswithIndustryCanada’slicence-
exemptRSSstandard(s).Operationissubjecttothe
followingtwoconditions:
(1) Thisdevicemaynotcauseinterference;and
(2) Thisdevicemustacceptanyinterference,including
interference that may cause undesired operation of
the device.
LeprésentappareilestconformeauxCNRd'Industrie
Canadaapplicablesauxappareilsradioexemptsde
licence.L'exploitationestautoriséeauxdeuxconditions
suivantes:
(1) l'appareilnedoitpasproduiredebrouillage,et
(2) l'utilisateurdel'appareildoitacceptertoutbrouillage
radioélectrique subi, même si le brouillage est
susceptibled'encompromettrelefonctionnement.
Radio Frequency (RF) Exposure Information
TheradiatedoutputpoweroftheWirelessDeviceis
belowtheIndustryCanada(IC)radiofrequencyexposure
limits.TheWirelessDeviceshouldbeusedinsucha
manner such that the potential for human contact during
normaloperationisminimized.Thisdevicehasbeen
evaluatedforandshowncompliantwiththeICSpecic
AbsorptionRate(“SAR”)limitswheninstalledinspecic
hostproductsoperatedinportableexposureconditions.
Canada’sREL(RadioEquipmentList)canbefoundat
Copyright©2015ASUSTeKCOMPUTERINC.
AllRightsReserved.
YouacknowledgethatallrightsofthisManualremainwithASUS.Any
andallrights,includingwithoutlimitation,intheManualorwebsite,and
shallremaintheexclusivepropertyofASUSand/oritslicensors.Nothing
in this Manual intends to transfer any such rights, or to vest any such
rights to you.
ASUSPROVIDESTHISMANUAL“ASIS”WITHOUTWARRANTYOF
ANYKIND.SPECIFICATIONSANDINFORMATIONCONTAINEDINTHIS
MANUALAREFURNISHEDFORINFORMATIONALUSEONLY,AND
ARESUBJECTTOCHANGEATANYTIMEWITHOUTNOTICE,AND
SHOULDNOTBECONSTRUEDASACOMMITMENTBYASUS.
Prevention of Hearing Loss
Topreventpossiblehearingdamage,donotlistenathigh
volume levels for long periods.
For France, headphones/earphones for this device are
compliantwiththesoundpressurelevelrequirement
laiddownintheapplicableEN50332-1:2013and/or
EN50332-2:2013standardrequiredbyFrenchArticle
L.5232-1.
• DonotdisassembletheASUSPhoneorits
accessories.Ifserviceorrepairisrequired,return
theunittoanauthorizedservicecenter.Iftheunit
isdisassembled,ariskofelectricshockorremay
result.
• Donotshort-circuitthebatteryterminalswithmetal
items.
Operator access with a tool
IfaTOOLisnecessarytogainaccesstoanOPERATOR
ACCESSAREA,eitherallothercompartmentswithin
thatareacontainingahazardshallbeinaccessible
totheOPERATORbytheuseofthesameTOOL,or
suchcompartmentsshallbemarkedtodiscourage
OPERATORaccess.
ASUS Recycling/Takeback Services
ASUSrecyclingandtakebackprogramscomefromour
commitment to the highest standards for protecting our
environment.Webelieveinprovidingsolutionsforyou
to be able to responsibly recycle our products, batteries,
othercomponentsaswellasthepackagingmaterials.
Please go to http://csr.asus.com/english/Takeback.htm for
detailed recycling information in different regions.
Regional notice for Singapore
ThisASUSPhonecomplies
withIDAStandards.
Proper disposal
Risk of explosion if battery is replaced
by an incorrect type. Dispose of used
batteries according to the instructions.
DONOTthrowthebatteryinmunicipal
waste.Thesymbolofthecrossedout
wheeledbinindicatesthatthebattery
shouldnotbeplacedinmunicipalwaste.
DONOTthrowthisproductinmunicipal
waste.Thisproducthasbeendesigned
to enable proper reuse of parts and
recycling.Thesymbolofthecrossedout
wheeledbinindicatesthattheproduct
(electrical, electronic equipment and
mercury-containingbuttoncellbattery)
shouldnotbeplacedinmunicipalwaste.
Checklocalregulationsfordisposalof
electronic products.
DONOTthrowthisproductinre.DO
NOTshortcircuitthecontacts.DONOT
disassemble this product.
ASUS
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan
Tel: 886228943447
Fax: 886228907698
Declaration
WedeclarethattheIMEIcodesforthisproduct,ASUS
Phone, are unique to each unit and only assigned to this
model.TheIMEIofeachunitisfactorysetandcannot
bealteredbytheuserandthatitcomplieswiththe
relevantIMEIintegrityrelatedrequirementsexpressedin
the GSM standards.
Should you have any questions or comments regarding
this matter, please contact us.
Sincerely yours,
ASUSTeK COMPUTER INC.
Tel:886228943447
Fax:886228907698
Support:http://vip.asus.com/eservice/techserv.aspx
Support for United States:
http://www.asus.com/US/Phones
15060-61700000
CE Mark Warning
CE marking for devices with wireless LAN/
Bluetooth
Thisequipmentcomplieswiththerequirementsof
Directive1999/5/ECoftheEuropeanParliamentand
Commissionfrom9March,1999governingRadioand
TelecommunicationsEquipmentandmutualrecognition
ofconformity.ThehighestCESARvaluesforthedevice
areasfollows:
• 0.343W/Kg(Head)
• 0.432W/Kg(Body)
Thisdeviceisrestrictedforindooruseonlywhen
operatingunder5150MHzto5350MHzoffrequency
range.
For 5GHz WLAN: This equipment may be operated in:
AT BE BG CH CY CZ DE DK
EE ES FI FR GB GR HU IE
IT IS LI LT LU LV MT NL
NO PL PT RO SE SI SK TR
Using GPS (Global Positioning
System) on your ASUS Phone
TousetheGPSpositioningfeatureonyourASUSPhone:
• Ensure that your device is connected to the
InternetbeforeusingGoogleMaporanyGPS-
enabled apps.
• Forrst-timeuseofaGPS-enabledapponyour
device, ensure that you are outdoors to get the
best positioning data.
• WhenusingaGPS-enabledapponyourdevice
inside a vehicle, the metallic component of the car
windowandotherelectronicdevicesmightaffect
the GPS performance.
• Donotremoveandreplacethebatterywithanon-
approved battery.
• Donotremoveandsoakthebatteryinwaterorany
other liquid.
• Nevertrytoopenthebatteryasitcontains
substancesthatmightbeharmfulifswallowedor
allowedtocomeintocontactwithunprotectedskin.
• Donotremoveandshort-circuitthebattery,asit
mayoverheatandcauseare.Keepitawayfrom
jewelryormetalobjects.
• Donotremoveanddisposeofthebatteryinre.It
couldexplodeandreleaseharmfulsubstancesinto
the environment.
• Donotremoveanddisposeofthebatterywithyour
regularhouseholdwaste.Takeittoahazardous
material collection point.
• Donottouchthebatteryterminals.
NOTES:
• Riskofexplosionifbatteryisreplacedbyan
incorrect type.
• Disposeofusedbatteryaccordingtothe
instructions.
The charger
• UseonlythechargersuppliedwithyourASUS
Phone.
• Neverpullthechargercordtodisconnectitfromthe
powersocket.Pullthechargeritself.
Caution
Your ASUS Phone is a high quality piece of equipment.
Before operating, read all instructions and cautionary
markingsonthe(1)ACAdapter.
• DonotusetheASUSPhoneinanextreme
environmentwherehightemperatureorhigh
humidityexists.TheASUSPhoneperforms
optimallyinanambienttemperaturebetween-10°C
(14°F)and35°C(95°F).
(i) lesdispositifsfonctionnantdanslabande5150-5
250MHzsontréservésuniquementpourune
utilisationàl’intérieuranderéduirelesrisquesde
brouillagepréjudiciableauxsystèmesdesatellites
mobilesutilisantlesmêmescanaux;
(ii) legainmaximald’antennepermis(pourles
dispositifsutilisantlabande5725-5825MHz)doit
seconformeràlalimitedep.i.r.e.spéciéepour
l’exploitationpointàpointetnonpointàpoint,selon
le cas.
CAN ICES-3(B)/NMB-3(B)
ThisClassBdigitalapparatuscomplieswithCanadian
ICES-003.
CetappareilnumériquedelaclasseBestconformeàla
normeNMB-003duCanada.
Thisdeviceanditsantenna(s)mustnotbeco-located
oroperatinginconjunctionwithanyotherantennaor
transmitter,excepttestedbuilt-inradios.
TheCountyCodeSelectionfeatureisdisabledfor
productsmarketedintheUS/Canada.
Cetappareiletsonantennenedoiventpasêtresituésou
fonctionner en conjonction avec une autre antenne ou un
autreémetteur,exceptionfaitesdesradiosintégréesqui
ont été testées.
Lafonctiondesélectiondel’indicatifdupaysest
désactivéepourlesproduitscommercialisésauxÉtats-
UnisetauCanada.
TheICIDforthisdeviceis3568A-Z00XS.
L’identiantIndustrieCanadadecetappareilest:
3568A-Z00XS.
RF Exposure Information (SAR)
Thisdevicehasbeentestedandmeetsapplicablelimits
forRadioFrequency(RF)exposure.
SpecicAbsorptionRate(SAR)referstotherateatwhich
thebodyabsorbsRFenergy.SARlimitsare1.6Watts
perkilogram(overavolumecontainingamassof1gram
oftissue)incountriesthatfollowtheUnitedStatesFCC
limitand2.0W/kg(averagedover10gramsoftissue)
incountriesthatfollowtheCounciloftheEuropean
Unionlimit.TestsforSARareconductedusingstandard
operatingpositionswiththedevicetransmittingatits
highestcertiedpowerlevelinalltestedfrequencybands.
ToreduceexposuretoRFenergy,useahands-free
accessoryorothersimilaroptiontokeepthisdevice
awayfromyourheadandbody.Carrythisdeviceatleast
15mmawayfromyourbodytoensureexposurelevels
remainatorbelowtheas-testedlevels.Choosethebelt
clips,holsters,orothersimilarbody-wornaccessories
whichdonotcontainmetalliccomponentstosupport
operationinthismanner.Caseswithmetalpartsmay
changetheRFperformanceofthedevice,includingits
compliancewithRFexposureguidelines,inamanner
thathasnotbeentestedorcertied,andusesuch
accessories should be avoided.
ThehighestFCCSARvaluesforthedeviceareas
follows:
• 0.46W/Kg(Head)
• 1.16W/Kg(Body)
TheFCChasgrantedanEquipmentAuthorizationfor
thisdevicewithallreportedSARlevelsevaluatedasin
compliancewiththeFCCRFexposureguidelines.SAR
informationonthisdeviceisonlewiththeFCCandcan
be found under the Display Grant section of www.fcc.gov/
oet/ea/fccidaftersearchingonFCCID:MSQZ00XS.
CE RF Exposure Compliance
ThisdevicemeetstheEUrequirements(1999/519/EC)
onthelimitationofexposureofthegeneralpublicto
electromagneticeldsbywayofhealthprotection.
Forbody-wornoperation,thisdevicehasbeentestedand
meetstheICNIRPguidelinesandtheEuropeanStandard
EN62209-2,forusewithdedicatedaccessories.SARis
measuredwiththisdeviceataseparationof1.5cmto
thebody,whiletransmittingatthehighestcertiedoutput
powerlevelinallfrequencybandsofthisdevice.Useof
otheraccessorieswhichcontainmetalsmaynotensure
compliancewithICNIRPexposureguidelines.
Safety information
ASUS Phone care
• UseyourASUSPhoneinanenvironmentwith
ambienttemperaturesbetween-10°C(14°F)and
35°C(95°F).
The battery
YourASUSPhoneisequippedwithahighperformance
non-detachableLi-Ionbattery.Observethemaintenance
guidelines for a longer battery life.
• Donotremovethenon-detachableLi-onbatteryas
thiswillvoidthewarranty.
• Avoidcharginginextremelyhighorlowtemperature.
Thebatteryperformsoptimallyinanambient
temperatureof+5°Cto+35°C.
ZenTalk Fans Forum
(http://www.asus.com/zentalk/global_forward.php)
EC Declaration of Conformity
We, the undersigned,
Manufacturer:
ASUSTeK COMPUTER INC.
Address:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Authorized representative in Europe:
ASUS COMPUTER GmbH
Address, City:
HARKORT STR. 21-23, 40880 RATINGEN
Country:
GERMANY
declare the following apparatus:
Product name :
ASUS Phone
Model name :
ASUS_Z00XS
conform with the essential requirements of the following directives:
2004/108/EC-EMC Directive
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55013:2001+A1:2003+A2:2006
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
1999/5/EC-R&TTE Directive
EN 300 328 V1.9.1
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V5.2.1(2011-05)
EN 301 908-2 V5.2.1(2011-07)
EN 301 893 V1.6.1(2011-11)
EN 50360:2001
EN 62479:2010
EN 62311:2008
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.4.1(2002-08)
EN 301 489-4 V1.4.1(2009-05)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-9 V1.4.1(2007-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-09)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 301 908-13 V6.2.1
EN 300 330-1 V1.7.1
EN 300 330-2 V1.5.1
2006/95/EC-LVD Directive
EN 60950-1: 2006 / A12: 20 11
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
2009/125/EC-ErP Directive
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
Regulation (EU No. 617/2013
2011/65/EU-RoHS Directive Ver. 140331
CE marking
Declaration Date: 20/09/2015
Year to begin affixing CE marking: 2015
Position : CEO
Name : Jerry Shen
Signature : __________
(EC conformity marking)
0682
EC Declaração de Conformidade
Nós, os abaixo assinados,
Fabricante:
ASUSTeK COMPUTER INC.
Morada:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Representante autorizado na Europa:
ASUS COMPUTER GmbH
Morada, Cidade:
HARKORT STR. 21-23, 40880 RATINGEN
País:
GERMANY
declaramos que o seguinte produto:
Nome do Produto :
ASUS Phone
Modelo : ASUS_Z00XS
se encontra em conformidade com as exigências essenciais das seguintes directrizes :
2004/108/EC-EMC Directiva
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55013:2001+A1:2003+A2:2006
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
1999/5/EC-R&TTE Directiva
EN 300 328 V1.9.1
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V5.2.1(2011-05)
EN 301 908-2 V5.2.1(2011-07)
EN 301 893 V1.6.1(2011-11)
EN 50360:2001
EN 62479:2010
EN 62311:2008
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.4.1(2002-08)
EN 301 489-4 V1.4.1(2009-05)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-9 V1.4.1(2007-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-09)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 301 908-13 V6.2.1
EN 300 330-1 V1.7.1
EN 300 330-2 V1.5.1
2006/95/EC-LVD Directiva
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
2009/125/EC-ErP Directiva
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
Regulation (EU) No. 617/2013
2011/65/EU-RoHS Directiva Ver. 150326
Marca de CE
Data da declaração: 20/08/2015
Ano para começar a aposição da marca CE: 2015
Posição : CEO
Nome : Jerry Shen
Assinatura : __________
(Marca de Conformidade EC)
0682
EC Declaratie de Conformitate
Noi, subsemnații,
Producător
:
ASUSTeK COMPUTER INC.
Adresă:
Strada PEITOU Nr 150, Li-TE etaj 4, TAIPEI 112, TAIWAN
Reprezentant autorizat în Europa:
ASUS COMPUTER GmbH
Adres
ă
, Ora
ș
:
Strada HARKORT Nr 21-23, RATINGEN 40880
Ț
ar
ă
:
Germania
declarăm c ă următorul aparat:
Nume produs: ASUS Phone
Nume model: ASUS_Z00XS
este conform cu cerințele esențiale ale următoarelor directive:
Directiva 2004/108/EC-EMC
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55013:2001+A1:2003+A2:2006
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
Directiva 1999/5/EC-R&TTE
EN 300 328 V1.9.1
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V5.2.1(2011-05)
EN 301 908-2 V5.2.1(2011-07)
EN 301 893 V1.6.1(2011-11)
EN 50360:2001
EN 62479:2010
EN 62311:2008
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.4.1(2002-08)
EN 301 489-4 V1.4.1(2009-05)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-9 V1.4.1(2007-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-09)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 301 908-13 V6.2.1
EN 300 330-1 V1.7.1
EN 300 330-2 V1.5.1
Directiva 2006/95/EC-LVD
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
Directiva 2009/125/EC-ErP
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
Regulation (EU) No. 617/2013
Directiva 2011/65/EU-RoHS Ver. 150326
Însemnul CE
Data declarației: 20/08/2015
Anul aplicării �nsemnului CE: 201 5
Poziția: CEO
Nume: Jerry Shen
Semnătura:
__________
(Însemnul de conformitate EC)
0682
EC Uygunluk Beyanı
Biz, bu imza altındakiler
Üretici:
ASUSTeK COMPUTER INC.
Adres, Şehir:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Avrupa’daki Yetkili:
ASUS COMPUTER GmbH
Adres, Şehir:
HARKORT STR. 21-23, 40880 RATINGEN
Ülke:
ALMANYA
Aşağıdaki ürünün:
Ürün adı :
ASUS Phone
Model adı :
ASUS_Z00XS
Aşağıdaki direktiflerin gereksinimlerine uyduğunu deklare ederiz:
2004/108/EC-EMC Direktifi
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55013:2001+A1:2003+A2:2006
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
1999/5/EC-R&TTE Direktifi
EN 300 328 V1.9.1
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V5.2.1(2011-05)
EN 301 908-2 V5.2.1(2011-07)
EN 301 893 V1.6.1(2011-11)
EN 50360:2001
EN 62479:2010
EN 62311:2008
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.4.1(2002-08)
EN 301 489-4 V1.4.1(2009-05)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-9 V1.4.1(2007-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-09)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 301 908-13 V6.2.1
EN 300 330-1 V1.7.1
EN 300 330-2 V1.5.1
2006/95/EC-LVD Direktifi
EN 60950-1: 2006 / A12: 20 11
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
2009/125/EC-ErP Direktifi
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
Regulation (EU) No. 617/2013
2011/65/EU-RoHS Direktifi Ver. 150326
CE işareti
Deklarasyon Tarihi: 20/08/2015
CE İşaretinin Eklendiği Yıl: 2015
Pozisyon : CEO
İsim : Jerry Shen
İmza : __________
(EC uygunluk işareti)
0682
