ATEK AX620 Wireless keyboard User Manual
ATEK (CHINA) ELECTRONICS COMPANY LIMITED Wireless keyboard Users Manual
ATEK >
User Manual
User Manual
Model NO. AX620
TYPE Wireless keyboard
MP DATE DATE 2017-07-17
Product pictures
classi
ficatio
n
project
Specifications/parameters
project
Specifications/parameters
The
basic
specif
icatio
ns
The keyboard type
Wireless keyboard Language version
103/104/105/106/us/uk/kr/br
The interface type
Keyboard size (long * wide
* high)
450 *141*26.5mm
Connected working
mode
2.4G wireless Keyboard net weight (bare)
500±20g
Receiver size (long * wide *
high)
13.2*14.6*6.5mm
battery
1 AA
Working voltage 1.5V Receiver operating voltage
DC4.5-5.5V
Working current
<3mA Receiver operating current
25mA
Keyboard sleep
current
<0.1mA Receiver sleep current
<3mA
Interface compatibility
USB1.1/2.0/3.0
The key load
55g±7g System compatibility
Windows98/ME/2000/XP/Vista/Win7/Wi
n8/MAC/LINUX/ Android 4.0
Key life
>5000,000
Low voltage alarm
yes
Low voltage alarm
lamp color
red
Alarm voltage
0.9V Distance from the
8-10 m
Electr
ical
para
meter
s
IC model
CX5176 IC model
IC factory,
COMPX TECHNOLOGY CO., LTD IC factory
Working
temperature
0～45℃ Storage temperature
-20～+60℃
Working humidity
20～90% Storage humidity
≤93% (40℃)
1 No need to install USB drive plug and play, strong anti-interference ability, distance more than 10 meters.
2
Code checking method: install the battery and press "ESC" + "+=" at the same time. The red indicator flashes and the receiver
is inserted into the USB connector
FCC WARNING
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable
exposure condition without restriction
