Accutech Security HWHY-662017 RFID Tag activated by Controllers at Portals of egress and respond per customer needs User Manual CS WWTag
Accutech Security, LLC RFID Tag activated by Controllers at Portals of egress and respond per customer needs CS WWTag
Exhibit D Users Manual per 2 1033 b3
Page 1 of 2
CUT SHEET: Wander Wearable Tag
A Wander Wearable Tag is a stylized form fitting waterproof tag and band worn by a resident or patient. When a resident
or patient enters a Tx Activation Field, the Tag sends a signal to the receiver in the door controller. The door controller
processes this information for an appropriate response (e.g., sounding alarms, locking doors). Door controllers can be an
LC Unit, ES Unit or a LS unit. WW (L) is for LC and ES systems and WW (S) is for LS and IS systems. The WW tags are
warranted for 6 months and have been engineered for greater than 6 months usage and can be activated/deactivated with a
STAD or IDTAD. The WW tag is used with band, part # 100917-5 (5 pack).
ELECTRICAL:
Power: 3.0V lithium battery
MECHANICAL:
Tag Size: 2.25” x 0.625” x 0.875”
Tag Weight: 0.5 ounce
Band Size: 14.25” x 0.95” x 0.25”
Band Weight: 0.25 ounce
OPERATING CHARACTERISTICS:
Transmit Frequency: 418 MHZ
Receive Frequency: 127-137 kHz
FCC ID: JM7-HWHY-662017
Canada IC: 2683A-662017
ATTACHMENT:
WW Tags are attached with a size adjustable silicon band. The
band is designed to resist tearing caused by pulling or chewing on
the band. However, if the band becomes frayed or torn it will need
to be replaced. The band should be replaced periodically for
cleanliness. Tags are typically attached to a wrist or ankle.
MAINTENANCE:
WW Tags are reusable but they must be thoroughly cleaned
and sanitized between applications.
Acceptable cleaning methods:
Antibacterial wipes or Hydrogen peroxide (wipe, do not soak)
In long-term applications, periodically replace the bands and
clean the Tags.
TESTING:
Enter a monitored zone (Alarm may sound)
With an STAD, IDTAD or TTS
STORING:
To preserve battery life and prevent nuisance alarms, WW Tags
should be turned off with an STAD or IDTAD, stored away from
sources of electrical noise, and stored in a metal container with
lid. Extra Tag bands should be stored in a clean and dry
environment.
ENVIRONMENTAL:
Operating Temperature: 32º to 120º Fahrenheit
Access Control Accessory
Tag Model Number: WW (L)
Part Number: 77L017
Tag Model Number: WW (S)
Part Number: 77S017
Band Model Number:
Part Number: 100917-5
800-356-2671 | Accutech | www.AccutechSecurity.com
Page 2 of 2
“
Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate
the equipment”
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts
de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas
produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le fonctionnement
800-356-2671 | Accutech | www.AccutechSecurity.com
