Users Manual for Y 72140 1

Radiometrics Midwest Corporation (815) 293-0772 – info@radiomet.com

Users Manual

Equipment Tested (Company, Model) FCC ID:

DCSI, Y72140-1 PN3Y72140-1

Instructions for Transmitters

1. Mount RF transmitter module on side of structure with the cable going out the bottom of the unit. The

battery should already be connected from the factory.

2. Connect dial encoder.

3. The RF module will “wake up” and detect the dial encoder within one hour and start to transmit

information once an hour thereafter.

4. Each transmission will take approx 0.48 seconds.

NOTE: The RF transmitter module will not start transmitting data until the dial encoder is detected.

NOTE: The RF module will transmit an internally generated dial encoder number once an hour as soon as the

battery is connected.

NOTE: Changes not expressly approved by DCSI could void the user's authority to operate this equipment.
