Acoustic Arc AAI-BT1210-00 Bluetooth Headphone User Manual Exhibit 08 Users Manual

Acoustic Arc International Ltd. Bluetooth Headphone Exhibit 08 Users Manual

Exhibit 08 Users Manual

BLUETOOTH HEADPHONE
BT1210US
INSTRUCTION MANUAL
INTRODUCTION
This Bluetooth wireless headphone applies the latest BT 2.1 wireless technology platform that enables you to
enjoy music and video and cell phone handsfree calling anywhere inside or outside your home.
A. PACKAGING
1. Bluetooth stereo headphone
2. 2.5mm to USB charging cable
3. 3.5mm to 3.5mm audio cable
B. FEATURES
1. Bluetooth 2.1 Platform
2. A2DP profile
3. Hands free telephone calling
4. Stereo music
5. Operating distance up to 10 meters
6. Auto Shut-Off
7. Operation time upto 12 hours (median volume level)
C. COMPONENT IDENTIFICATION
D. PAIRING
1. Press the Power button, LED On and hold pressing until LED flashes.
2. Enable your Bluetooth device such as cell phones, tablets or other BT media, and make sure it is at
searching mode.
3. When Bluetooth connection is made, the LED will flash slowly.
4. listen your music or make/take your telephone call on the headphone
E. CHARGING
1. Make sure the headphone is fully charge before initial use.
2. Connect headphone with your PC by the supplied 2.5mm to USB cable for charging.
3. Charging is workable to connect with other power adapter with USB jack at 5V 1A specifications.
4. The charging LED will illuminate when charging is under processing. Charging will be finished when LED
becomes Green.
1. Power LED Indicator
2. Power / Pair / Talk
3. Volume+, Volume -
4. 3.5mm Audio In Jack
5. Volume +2.5mm Charge in Jack
6. Microphone
F. Telephone Call
1. If there is an incoming call when streaming music on headphone, the music will be muted and ring tone will
be heard.
2. Take your call by pressing the Power/Pair/Talk button. Press once again when ending the call. Music will
come out again automatically.
3. To make a call, simply dialing at your cell phone, and talk at the headphone.
*Check the instruction manual for your cell phones, if getting any process different from the above.
G. LINE-IN
1. Connect the headphone with your audio device directly by the supplied 3.5mm cable
2. The Bluetooth wireless music will be by pass after line-in connection is made
H. TECHNICAL SPECIFICATIONS
Carrier Frequency : Blue Tooth 2.1
Battery Capacity : 3.7V 470mA via built-in Lithium
rechargeable battery
Frequency Response
:
20Hz
20KHz
Distortion : 0.5%
S/N Ratio : 65dB (typical)
Channel Separation : 50dB (Typical)
Operation Distance
:
Up to 10 meters (open area)
K. TROUBLE SHOOTING
NO SOUND
Ensure the headphone is charged and with enough power for operation
Ensure the headphone is switch ON.
Ensure BT device is ON.
The volume of speaker is too low, adjust the volume to an appropriate level.
Unable to connect with Blue Tooth device, RESET the headphone by pressing and holding the
Power/Pair/Talk for 12 seconds.
WARNING : Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment. Operation is subject to
the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the
device.
Battery warning:
Caution: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Safety warning:
Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
1. Do not covering the ventilation.
2. No naked flame sources, such as lighted candles, should be placed on the apparatus.
3. Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
4. No objects filled with liquids, such as vases, shall be placed on the apparatus.
5. The apparatus shall not be exposed to dripping or splashing.
6. The On/Off switch is a secondary functional switch and not for disconnection of the mains
supply.
7. Do not dispose of electrical products in the general waste and ensure the used product or batteries are
disposed safely according to your local authority and regulations.
8. No replaceable parts inside, repair work should be carried out by manufacturer or authorized agent.
9. The risks of hearing impairment due to exposure to music or other sounds may be reduced by listening at
lower volumes and for shorter durations.
10. Warning: Listening at high volumes from earphones and headphones can cause hearing loss.
11. Caution: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
FCC STATEMENT:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
IC STATEMENT:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subjectto the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le fonctionnement.
This ClassB digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classeB est conforme à la norme NMB-003 du Canada.
IC: 255A-8003763
