Manual
PT-PNM6506-BK-C
WIRELESS LASER MOUSE
QUICK SETUP GUIDE
Before using your new product, please read these instructions to prevent any damage.
PACKAGE CONTENTS
• Wireless laser mouse • AA batteries (2)
• Nano receiver • Quick Setup Guide
SYSTEM REQUIREMENTS
• Windows® 10, Windows® 8.1, Windows® 8, Windows® 7, Windows Vista®, or Mac OS 10.X or higher
• One available USB port
FEATURES
• Track-on-Glass Laser Sensor for enhanced tracking
DPI SWITCH
The Power/DPI LED indicator behind the tilt wheel lights up when you plug the mouse into the USB port. The
brightness of the LED indicates the DPI setting in use. There are three dierent settings:
• Bright: 2400 DPI
• Dim: 1600 DPI
• No light: 800 DPI
The default setting is 800 DPI. You can switch between DPI settings by pressing the swtich and cycling through the
DPI settings. In order to save power, the LED only stays on for 10 seconds.
Forward
• Press this button to view the next page in your Internet browser.
Backward
• Press this button to view the previous page in your Internet browser.
Zoom Key (Zoom in /out)
• Press the Zoom key and turn the scroll wheel at the same time to zoom in and out.
Win Key
• Press this button to access the Start screen.
Fi
na
l
fl
at s
i
ze:
371
.
48
×
148
.
08
mm
Final fold size: 123.82 × 148.08 mm
Nano receiver
Connect buttonON/OFF switch
Battery cover
Left button
Right button
Scroll wheel
DPI switch key
DPI LED
Battery status
LED indicator
Backward
Forward
Zoom key
Start menu
SETTING UP YOUR MOUSE
1 Remove the battery cover.
2 Replace the battery cover.
3 Remove the nano receiver.
4 Insert two AA batteries (included) into the battery compartment. Make sure that the + and – signs match the
symbols in the compartment.
5 Turn on the power switch.
DPI switch key
DPI LED
Forward Zoom key
Backward
Pull up
AA batteries
PT-PNM6506-BK-C_15-0678_QSG_V1_EN.ai 1 8/14/2015 6:55:13 PMPT-PNM6506-BK-C_15-0678_QSG_V1_EN.ai 1 8/14/2015 6:55:13 PM
V1
FINAL
FOR PRINT
6 Plug the nano receiver into the USB port on your computer.
7 Test your mouse to make sure that it works with your computer.
8 If the mouse does not work, put it into pairing mode by unplugging and replugging the nano receiver into the USB
port on your computer, then pressing the Connect button on the mouse.
Warning: If you need to travel with your wireless mouse, make sure that you slide the power switch to o.
LED INDICATORS
DPI switch key DPI LED
V1 ENGLISH 15-0678
FUNCTION
Power ON
Pairing
Low battery
When DPI switched
DESCRIPTION
LED is on for 10 seconds
LED blinks. (LED OFF when paired or failed after 10 seconds)
LED blinks for 10 seconds
DPI indicated
STATUS
3 LED
2 LED
1 LED
DESCRIPTION (status will show for ve seconds at power on, or blink status for ve seconds after waking from sleep mode)
80~100% of maximum battery
50~70% of maximum battery
20~40% of maximum battery
Battery status LED indicator
CLEANING YOUR MOUSE
• Wipe the mouse with a damp, lint-free cloth.
SPECIFICATIONS
Mouse:
• Dimensions (L×W×H): 4.96 ×3.24 × 1.76 in.
(12.59 × 8.23 × 4.48 cm)
• Weight: 3.17 oz. (.09 kg)
• Batteries: 2 AA alkaline batteries
• Battery life: 12 months (based on average usage)
• Radio frequency: 2.4 Ghz
• Operating distance: 32.8 feet (10 meters)
• Rating: 3V D.C. - 10 mA
IMPORTANT SAFETY INFORMATION
• This product has no serviceable parts. Use of controls or adjustments of procedures other than this guide may
result in danger.
• DO NOT direct the laser beam at anyone’s eye.
CAUTION: To use this product properly, please read this guide before installing.
DPI switch key
DPI LED
Battery status
LED indicator
TROUBLESHOOTING
My mouse is not working.
• Move your mouse and computer closer together.
• Make sure that your computer meets the system requirements.
• Only use the mouse on a clean, at, non-slippery surface to ensure smooth and accurate cursor action. Avoid using your mouse on
reective, transparent, or metallic surfaces.
• If your mouse stops working:
• Make sure that your mouse and nano receiver are paired by pressing the connect button on the mouse.
• Try connecting your nano receiver into a dierent USB port on your computer.
• Replace the mouse batteries.
LEGAL NOTICES
• This product complies with IEC 60825-1, class 1 laser product.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modications not expressly approved by the party responsible for compliance could void the user’s
authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Radiation Exposure Statement:
The product comply with the FCC portable RF exposure limit set forth for an uncontrolled environment and are safe for intended
operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible
from the user body or set the device to lower output power if such function is available.
ONE-YEAR LIMITED WARRANTY
CONTACT PLATINUM
For customer service, call 1-800-499-3964
The Pt logo is a registered trademark of Best Buy.
PLATINUM is a trademark of Best Buy and its aliated companies. Distributed by Best Buy Purchasing, LLC
©2015 Best Buy. All rights reserved. Made in China
Nano receiver:
• Dimensions (L×W×H): .0.74 × 0.57 × 0.25 in.
(18.9 × 14.5 × 6.25 cm)
• Weight: 0.17 oz. (.005 kg)
• Interface: USB 1.1, 2.0, 3.0
