ADEMCO 5802 PENDANT TRANSMITTER
INSTALLATION AND SETUP GUIDE
FCC ID: CFS8DL5802-1
FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference (2) This device must
accept any interference received, including interference that may cause undesired
operation.
IC: 573F-58021
Specifications Unit Dimensions: 2-1/4” (57mm) x 1-1/2” (38mm) x 1/2” (12.7mm)
LED: Lights when unit transmits.
REFER TO THE INSTALLATION INSTRUCTIONS FOR THE RECEIVER/CONTROL WITH WHICH THIS DEVICE IS
USED FOR WARRANTY INFORMATION AND FOR DETAILS REGARDING THE LIMITATIONS OF THE ENTIRE ALARM
SYSTEM.
About The 5802:
The ADEMCO 5802 is a pendant-style
Emergency wireless transmitter that may
be worn around the neck or carried in a
pocket or purse. Pressing the button on
the transmitter (for at least one second)
will send an alarm signal to the control
receiver. The 5802 is intended for use
only with wireless alarm systems that
support 5800 series devices.
The control receiver’s response to the
5802 signal can be set for either 24-hour
audible alarm or 24hour silent alarm by
appropriate programming of the control
receiver.
The 5802 is powered by a non-replaceable
Lithium battery designed to provide long
life. The entire 5802 should be replaced
When a low battery condition is indicated
by the control unit.
Programming The Serial Number:
The 5802 has a unique identification code
(serial number) permanently assigned
during manufacture. The control system is
required to “learn” the transmitter’s serial
number during installation of the system.
Note: During the “learning” procedure, two
transmissions must be sent (by pressing the
button). Allow at least 8-seconds between
transmissions.
All 5802 transmitters shall be programmed
as “BR” type units (i.e., unsupervised
“Button RF”). See the control unit’s
Installation Instructions for further details
regarding possible zone responses and
programming.
