Honeywell International Inc. Security Base Control Unit 800 13956V1 A TSSC SYSTEM qig

Contents

Quick Install Guide

1
TSSC Installation and Setup Guide
STEP 1 - Installing the Base (TSSBU111011U) Rechargeable
Backup Battery and Power Connector
1.Remove the Base Case Back.
2. Connect the battery connector to the receptacle on the PC board.
3. Insert the Battery Pack into the case.
4. Secure the Battery Pack with the Battery Retainer using the Retaining Screw.
5. Connect the power pack into the power receptacle, looping the power cord as
shown in Detail A.
NOTE: If using the optional wall mount configuration, skip to the Base wall
mounting procedure. If not, complete step 6.
6. Secure the Case Back onto the Base.
NOTE: Do not apply power at this time.
CASE
BACK
RETAINING
SCREW
BASE UNIT
BATTERY
RETAINER
BATTERY
PACK
tssc-016-V0
DETAIL A
Mounting the Base to a Wall (Optional)
To mount the Base to a wall, perform to the following:
IMPORTANT: Record the ACTIVATION KEY number, MAC Address, CRC
number and WPA2 number located on case back prior to wall mounting.
1. Complete steps 1 through 5 of the Installing the Base Rechargeable Backup
Battery and Power Connector paragraph
2. Secure the Mounting Plate to the wall and secure with 4 screws.
3. Install the Tamper Screw as shown.
4. Secure the Base to the Mounting Plate by aligning the slots on the Base and
sliding the unit down until locked in position.
tssc-015-V0
ENGAGE HOOKS
AND SLIDE DOWN
(4)
WALL
MOUNTING
PLATE
WALL
SURFACE
REAR OF
BASE UNIT
SECURE CASE BACK
USING MOUNTING
SCREWS (TYP - 4 PLACES)
TAMPER
SCREW
BATTERY
PACK
STEP 2 - Setting up the Communication Links
Prior to power up of the Base (when directed in the TSSC Installer App), the Ethernet
communications link must be connected to the residence’s router. The connection is from an
Ethernet port on the router to the “ETH0” port on the Base.
IMPORTANT! Under no circumstances should the “ETH1” port ever be connected to the
residence’s router.
tssc-021-V0
BASE
UNIT
TO/FROM
RESIDENCE
ROUTER
ETHERNET
PORT
FOR INSTALLER
USE ONLY
TO POWER
RECEPTACLE
ETH0
ETH1
STEP 3 - Keypad (TSSKP112011U) Mounting
The keypad is designed to be placed on a desk/table top with the stand attached. An optional
mounting plate can be used to mount the keypad to the wall.
Power Connections
Connect the Power Supply Cable into its connector as shown below and route it from the bottom
of the keypad.
IMPORTANT: Do not apply power to the keypad at this time.
Installing Keypad To Desk-Top Stand
1. Place the Keypad face down on a level surface.
2. Connect the battery connector to the receptacle on the PC board.
3. Insert the Battery Pack into the case.
4. Secure the Battery Pack with the Battery Retainer using the Retaining Screw.
5. Install tabs on Desk Stand into appropriate slots as shown and secure with two screws
6. Plug in the power pack to the receptacle.
BATTERY
PACK
POWER
SUPPLY
CABLE
KEYPAD
tssc-011-V1
SLIDE TABS
UP INTO
SLOTS
SLOT
(TYP)
DESK
STAND
SECURE WITH
SCREWS (2)
(TYP)
STEP 4 - Base Registration and Accessing The Installer App
Run TSSC Installer App:
Go to https://portal-test.adtpulse.com/activation and follow the prompts.
Powering the Base
When directed in the TSSC Installer App, plug the power pack into the wall
receptacle to power the Base. During the first 45 seconds of power initialization, TSSC
lights up the CELLULAR, NETWORK and STATUS LEDs one by one slowly in sequence.
After the first 45 seconds, the LEDs chase in a rapid sequence for approximately 30 more
seconds. The POWER LED is always ON while initialization is being executed. When the
LEDs stop chasing and the POWER LED is lit green, the Base is powered up and ready
for the registration process to begin.
NOTE: The BATTERY LED will blink until the battery is fully charged.
NOTE: The NETWORK LED will remain amber until activated.
Radio Activation
Go to https://portal-test.adtpulse.com/activation and follow the prompts.
Ê800-13956V1oŠ
800-13956V1 11/13 Rev. A
EXHIBIT 7B CFS8DLTSSCBASE / 573F-TSSCBASE
PLEASE GO TO THE BOTTOM OF THE NEXT
PAGE FOR FCC / IC AGENCY STATEMENTS.
2
Contacting Technical Support
PLEASE, before you call Technical Support, be sure you:
READ THE INSTRUCTIONS!
•Determine that the power supply and/or backup battery are supplying
proper voltages.
•Verify your programming information where applicable.
•Note the proper model number of this product, and the version level (if
known) along with any documentation that came with the product.
•Note your ADT customer number and/or company name.
Having this information handy will make it easier for us to serve you quickly and
effectively.
Technical Support: Contact your ADT Customer Care Representative.
THE LIMITATIONS OF THIS ALARM SYSTEM
While this system is an advanced design security system, it does not offer guaranteed protection against burglary or fire or
other emergency. Any alarm system, whether commercial or residential, is subject to compromise or failure to warn for a
variety of reasons. For example:
•Intruders may gain access through unprotected openings or have the technical sophistication to bypass an alarm
sensor or disconnect an alarm warning device.
•Intrusion detectors (e.g., passive infrared detectors), smoke detectors, and many other sensing devices will not
work without power. Battery-operated devices will not work without batteries, with dead batteries, or if the
batteries are not put in properly. Devices powered solely by AC will not work if their AC power supply is cut off
for any reason, however briefly.
•Signals sent by wireless transmitters may be blocked or reflected by metal before they reach the alarm receiver.
Even if the signal path has been recently checked during a weekly test, blockage can occur if a metal object is
moved into the path.
•A user may not be able to reach a panic or emergency button quickly enough.
•While smoke detectors have played a key role in reducing residential fire deaths in the United States, they may
not activate or provide early warning for a variety of reasons in as many as 35% of all fires, according to data
published by the Federal Emergency Management Agency. Some of the reasons smoke detectors used in
conjunction with this System may not work are as follows. Smoke detectors may have been improperly installed
and positioned. Smoke detectors may not sense fires that start where smoke cannot reach the detectors, such as
in chimneys, in walls, or roofs, or on the other side of closed doors. Smoke detectors also may not sense a fire on
another level of a residence or building. A second-floor detector, for example, may not sense a first-floor or
basement fire. Moreover, smoke detectors have sensing limitations. No smoke detector can sense every kind of
fire every time. In general, detectors may not always warn about fires caused by carelessness and safety hazards
like smoking in bed, violent explosions, escaping gas, improper storage of flammable materials, overloaded
electrical circuits, children playing with matches, or arson. Depending upon the nature of the fire and/or the
locations of the smoke detectors, the detector, even if it operates as anticipated, may not provide sufficient
warning to allow all occupants to escape in time to prevent injury or death
•Passive Infrared Motion Detectors can only detect intrusion within the designed ranges as diagrammed in their
installation manual. Passive Infrared Detectors do not provide volumetric area protection. They do create
multiple beams of protection, and intrusion can only be detected in unobstructed areas covered by those beams.
They cannot detect motion or intrusion that takes place behind walls, ceilings, floors, closed doors, glass
partitions, glass doors, or windows. Mechanical tampering, masking, painting or spraying of any material on the
mirrors, windows or any part of the optical system can reduce their detection ability. Passive Infrared Detectors
sense changes in temperature; however, as the ambient temperature of protected area approaches the
temperature range of 90° to 105°F, the detection performance can decrease.
•Alarm warning devices such as sirens, bells, or horns may not alert people or wake up sleepers if they are located
on the other side of closed or partly open doors. If warning devices sound on a different level of the residence
from the bedrooms, then they are less likely to waken or alert people inside the bedrooms. Even persons who are
awake may not hear the warning if the alarm is muffled from a stereo, radio, air conditioner or other appliance,
or by passing traffic. Finally, alarm warning devices, however loud, may not warn hearing-impaired people or
waken deep sleepers.
•Telephone lines needed to transmit alarm signals from a premises to a central monitoring station may be out of
service or temporarily out of service. Telephone lines are also subject to compromise by sophisticated intruders.
•Even if the system responds to the emergency as intended, however, occupants may have insufficient time to
protect themselves from the emergency situation. In the case of a monitored alarm system, authorities may not
respond appropriately.
•This equipment, like other electrical devices, is subject to component failure. Even though this equipment is
designed to last as long as 10 years, the electronic components could fail at any time.
The most common cause of an alarm system not functioning when an intrusion or fire occurs is inadequate maintenance. This
alarm system should be tested weekly to make sure all sensors and transmitters are working properly.
Installing an alarm system may make one eligible for lower insurance rates, but an alarm system is not a substitute for
insurance. Homeowners, property owners, and renters should continue to act prudently in protecting themselves and continue
to insure their lives and property.
We continue to develop new and improved protection devices. Users of alarm systems owe it to themselves and their loved
ones to learn about these developments.
Recommendations For Proper Protection
The Following Recommendations for the Location of Fire and Burglary Detection Devices Help Provide
Proper Coverage for the Protected Premises.
Recommendations for Smoke and Heat Detectors
With regard to the number and placement of smoke/heat detectors, we subscribe to the recommendations
contained in the National Fire Protection Association's (NFPA) Standard #72 noted below.
Early warning fire detection is best achieved by the installation of fire detection equipment in all rooms and
areas of the household as follows: For minimum protection a smoke detector should be installed outside of
each separate sleeping area, and on each additional floor of a multi-floor family living unit, including
basements. The installation of smoke detectors in kitchens, attics (finished or unfinished), or in garages is
not normally recommended.
For additional protection the NFPA recommends that you install heat or smoke detectors in the living room,
dining room, bedroom(s), kitchen, hallway(s), attic, furnace room, utility and storage rooms, basements and
attached garages.
In addition, we recommend the following:
•Install a smoke detector inside every bedroom where a smoker sleeps.
•Install a smoke detector inside every bedroom where someone sleeps with the door partly or
completely closed. Smoke could be blocked by the closed door. Also, an alarm in the hallway
outside may not wake up the sleeper if the door is closed.
•Install a smoke detector inside bedrooms where electrical appliances (such as portable heaters, air
conditioners or humidifiers) are used.
•Install smoke detectors at both ends if the hallway is more than 40 feet (12 meters) long.
•Install smoke detectors in any room where an alarm control is located, or in any room where alarm
control connections to an AC source or phone lines are made. If detectors are not so located, a fire
within the room could prevent the control from reporting a fire or an intrusion.
Regulatory Agency Statements
FEDERAL COMMUNICATIONS COMMISSION STATEMENTS
The user shall not make any changes or modifications to the equipment unless authorized by the Installation
Instructions or User's Manual. Unauthorized changes or modifications could void the user's authority to operate
the equipment.
CLASS B DIGITAL DEVICE STATEMENT
This equipment has been tested to FCC requirements and has been found acceptable for use. The FCC requires
the following statement for your information:
This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict
accordance with the manufacturer's instructions, may cause interference to radio and television reception. It has
been type tested and found to comply with the limits for a Class B computing device in accordance with the
specifications in Part 15 of FCC Rules, which are designed to provide reasonable protection against such
interference in a residential installation. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• If using an indoor antenna, have a quality outdoor antenna installed.
• Reorient the receiving antenna until interference is reduced or eliminated.
• Move the radio or television receiver away from the receiver/control.
• Move the antenna leads away from any wire runs to the receiver/control.
• Plug the receiver/control into a different outlet so that it and the radio or television receiver are on different
branch circuits.
• Consult the dealer or an experienced radio/TV technician for help.
INDUSTRY CANADA CLASS B STATEMENT
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
FCC / IC STATEMENT
This device complies with Part 15 of the FCC Rules, and RSS210 of Industry Canada. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause undesired operation.
Cet appareil est conforme à la partie 15 des règles de la FCC & de RSS 210 des Industries Canada. Son
fonctionnement est soumis aux conditions suivantes: (1) Cet appareil ne doit pas causer d’interférences nuisibles.
(2) Cet appareil doit accepter toute interférence reçue y compris les interférences causant une réception
indésirable.
This Control Complies With NFPA Requirements For Temporal Pulse Sounding
Of Fire Notification Appliances
Recommendations for Proper Intrusion Protection
For proper intrusion coverage, sensors should be located at every possible point of entry to
a home or premises. This would include any skylights that may be present, and the upper
windows in a multi-level building.
In addition, we recommend that radio backup be used in a security system. This will
ensure that alarm signals can be sent to the alarm monitoring station in the event that
the telephone lines are out of order (alarm signals are normally sent over the phone lines,
if connected to an alarm monitoring station).
Specifications
Base Unit:
Physical:
Dimensions: 8.5” W x 6” H x 1.875” D
Electrical:
Voltage Input: P/N 300-05763V1: 110 VAC input/9 VDC output
2.5A, 2-prong
24-Hour Backup Battery: P/N TSSBU111061U: Rechargeable Backup
Battery: Nickel-metal hydride battery pack rated
at 7.2 Vdc, 3700mA
Communication:
Formats Supported: 4-Digit Contact ID
Keypad:
Physical:
Dimensions: 6.69” W x 5.36” H x 0.875” D
Electrical:
Voltage Input: P/N 300-05763V1: 110 VAC input/9 VDC output
2.5A, 2-prong
24-Hour Backup Battery: P/N TSSKP112061U: Rechargeable Backup
Battery: 7.2V, 6xAAA, 6x600mAH, NiMH
WARRANTY INFORMATION
For the latest warranty information, please visit:
www.honeywell.com/security/hsc/resources/wa
ADT Security Services, Inc.
1501 Yamato Road
Boca Raton, FL 33431
Copyright © 2013 ADT Security Services

Navigation menu
