Advance Bright BTS700 BLUETOOTH PORTABLE SPEAKER User Manual BPS700 IM OP

Advance Bright Limited BLUETOOTH PORTABLE SPEAKER BPS700 IM OP

User Manual

BTS700
available and supports Bluetooth
tMake sure the Bluetooth Speaker is
within range of your Bluetooth device.
Audio is not coming out from the
Bluetooth Speaker after Bluetooth device
successfully paired.
tMake sure the Bluetooth device volume
is set to a comfortable listening level.
Audio is not coming out from the
Bluetooth Speaker after the
non-Bluetooth device connected with
the Micro USB to USB and 3.5 mm splitter
cable.
tMake sure the Micro USB to USB and 3.5
the Bluetooth Speaker and
non-Bluetooth device.
tMake sure the non-Bluetooth device is
set to a comfortable listening level.
tAudio is coming out with abnormal
noise and sound quality. Try to change
up the battery of Bluetooth speaker.
Precautions
1. The radio waves emitted by the
Bluetooth Speaker and Bluetooth
electronics including medical devices.
2. Keep the unit in a cool, dry place.
For more information, please visit
www.yelltowin.com
Designed by Ye!! in Hong Kong
Assembled in China
Package Contents
- BTS700 Portable Bluetooth Speaker
- Micro USB to USB and
3.5 mm splitter cable
- User Manual
Overview
LED Indicators
Indicator Status
RED Charging
GREEN Fully Charged
AUX/ Flashing Pairing Mode
BT BLUE
BLUE Connected /
AUX IN Mode
How to Charge BTS700
1. Plug micro USB Tip from the included
cable to the micro USB slot from
BTS700.
2. Plug USB Tip from the included cable to
USB compatible wall charger with 0.5A
current output(DC 5V, 500mA).
3. When the BTS700 is fully charged,
disconnect the USB Cable.
Note: Approximately 1-2 hours required
for full charge. Battery will last up to 6
hours when connected wirelessly and
up to 10 hours when connected
through Line-in.
Play Audio from Bluetooth Device
1. Switch the Bluetooth Speaker to the
BT mode. The speaker is discoverable
and ready for pairing. The status
indicator blinds blue.
2. On your Bluetooth device, turn on
Bluetooth and scan for devices in its
Bluetooth menu.
3. When the “Ye!!-BTS” appears on the
device list of your Bluetooth device,
select “Ye!!-BTS”. (If a pass code is
requested, enter 1234.) The status
indicator turns solid blue after pairing
is established. The speaker is ready to
play music.
Example: iPad / iPhone / iPod Touch
Press Settings > General > Bluetooth >
Bluetooth ON > Ye!!-BTS > Enter PIN:
1234 > Pair
Example: Android 4.03 Ice Cream
Sandwich Smartphone
Press Settings > Bluetooth ON > Scan >
Ye!!-BTS > Enter PIN: 1234 > Settings >
Check the Media audio box
Reconnecting Bluetooth Device
Keep in mind that the Bluetooth Speaker
Bluetooth feature on your Bluetooth
device, the Bluetooth Speaker will
disconnect from your device. To
reconnect, simply follow the instruction
in the “Play Audio from Bluetooth Device”
section.
Changing Connected Bluetooth Device
1. Disable the Bluetooth function of your
Bluetooth device.
2. The Bluetooth Speaker can now be
device.
3. Following the instructions in the “Play
Audio from Bluetooth Device” section
Play Audio from Non-Bluetooth Device
1. Switch the Bluetooth Speaker to the
AUX IN mode. The status indicator turns
solid blue.
2. Connect the Bluetooth Speaker and
your non-Bluetooth audio device with
the included Micro USB to USB and 3.5
mm splitter cable. The speaker is ready
to play music.
Model No. BTS700 Ye!!-BTS
Output Power 3W
Power Capacity 1,000 mAh
Input Voltage DC 5V / 1A
Charge Time 1 – 2 hours
Playback Time Up to 6 hours
on Bluetooth
Up to 10 hours
on Line-in
Operating Distance up to 33 feet
(10 metres)
Bluetooth Version Bluetooth 3.0
with EDR
Dimensions 61 x 61 x 54 mm
Net Weight 133 g
Troubleshooting
No connection between Bluetooth
Speaker and your Bluetooth device.
tMake sure the Bluetooth Speaker is fully
charged
tMake sure the BT mode is switched on.
tMake sure your Bluetooth device is
Bluetooth Portable Speaker
LED
Indicators
Front View Back View
Micro USB
Power Input /
Line-in
Slide switch
AUX IN mode;
BT mode]
Computer
(not included)
USB Compatible
Wall charger
(not included)
or
C
M
Y
CM
MY
CY
CMY
K
BPS700 IM OP.pdf 1 9/11/2012 11:53:16
811-BTS700-00-W
FCC NOTE：
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS OR CHANGE
TO THIS EQUIPMENT. SUCH MODIFICATIONS OR CHANGE COULD VOID AND
CHANGE ANNTENA WHICH THE MANUFACTURER PROVIDES.
IT IS THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a resi dential installation.
This equipment generates, uses and can radiate radio frequenc y energy and, if not
installed and used in accordance with the in structions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular insta llation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to corr ect the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experien ced radio/TV technician for help.
To maintain compliance with FCC’s RF exposure guidelines, this equipment should be
installed and operated with a minimum distance of 20cm between the radiator and your
body.
