PROFESSIONAL

SERIES

IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is

applicable to most vehicles. However, due to the configuration of some vehicles, some functions AND/OR

SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.

Remote Start and Keyless

Entry System

CA6150RX

Owner’s Guide

Table of Contents

Using Your Remote Control ............................................................... 3

Using the Keyless Entry ................................................................... 3

Two Stage Door Unlock (optional) ................................................... 3

Activating Trunk Release (optional) ................................................ 3

Using the Progressive Car Finder Feature...................................... 3

Using the Personal Protection Alarm ............................................... 3

Programmed Transmitter Notification .............................................. 4

Valet Mode ........................................................................................ 4

Eliminating Lock / Unlock Notification Chirps ................................... 4

Using Your Remote Vehicle Starter ................................................. 4

Remote Starting Your Vehicle .......................................................... 4

Remote Start Shutdown ................................................................... 4

Entering Your Vehicle while it is Running via Remote Start ........... 5

Preheating or Precooling the Vehicle’s Interior ............................... 5

User Programmable Run Time / Run Time Extension ...................... 5

Using the “Quick-Stop” Feature ....................................................... 5

Operating the 2 / 3 Hour Start Up Timer Mode ................................ 6

Operating the Daily Start Timer ........................................................ 6

Remote Start Safety Features ......................................................... 7

Transmitter Button Functions ........................................................... 7

Replacing Remote Control Batteries ............................................... 8

Warranty Information........................................................................... 9

Using Your Remote Control

Using the Keyless Entry

The button is used to lock the vehicle's doors, the button is used to unlock the

vehicle's doors. To lock or unlock the doors simply press and release the desired

function button one time. For your convenience, the parking lights will flash once

when the doors are unlocked and twice when the door are locked.

NOTE: The system is defaulted with Silent Choice enabled, which requires a

second press of the or button to activate an audible locking/unlocking

response from the vehicle. If your system is set up for 2 step unlock, a third press

of unlock will activate the audible response.

Using the Progressive Car Finder Feature

Press the button to locate your vehicle. The system will sound 5 times at low

volume, increasing in volume each time the button is pressed.

Using the Personal Protection Alarm (Panic)

Press and hold the button for 3 seconds to activate the personal protection

alarm. During panic mode, the normal function of the transmitter buttons will be

suspended. The transmitter’s and buttons can be used to lock and unlock the

door (if the option is installed). To stop the alarm, press and hold the button on

the transmitter again for 3 seconds. The system will automatically stop after 30

seconds.

Activating AUX 1 (Optional)

If this feature is enabled on your system, pressing the and buttons

simultaneously will activate an optional feature. This feature can be programmed

for a wide range of functions like power window or sunroof automation, please

consult your installing dealer to determine the functionality of your system.

Activating the Trunk Release Feature (Optional)

The button is used to open the trunk of the vehicle. To open the vehicle's trunk

press and hold the button for 3 seconds.

Two Stage Door Unlock (Optional)

If this feature is enabled on your system, pressing the button one time will

unlock only the driver’s door. Press again within three seconds to unlock the

remaining doors.

Valet Mode

Valet Mode is used to disable the system from remote starting. To

enter or exit valet mode simply follow the 4 steps outlined below:

1. Turn the vehicle’s ignition ON.

2. Push and hold the programming/valet button.

3. The LED will turn on solid when valet mode is active

4. Release the programming/valet button.

Programmed Transmitter Notification

As a security precaution each time the vehicle’s ignition is turn on the status LED

light with flash the number of transmitters programmed into the system. This helps

to identify unauthorized transmitters from accessing your vehicle. If you believe an

unauthorized transmitter has been programmed to your system, contact your

installing dealer for assistance.

Eliminating Lock / Unlock Notification Chirps

System lock and unlock notification chirps can be toggled ON or OFF without

entering the programming feature banks.

1. Turn the ignition ON then OFF.

2. Press and release the valet/programming button 3 times. The system

will respond with 1 chirp for ON or 2 chirps for OFF.

Using Your Remote Control

Remote Starting Your Vehicle

To activate the remote vehicle start function, press and release the button 2 times

within 2 seconds. The system will sound, the parking lights will flash 1 time and the

system will check the vehicle to ensure it is safe to start. If all safety parameters are

correct, the vehicle will start within 5 seconds. The vehicle’s parking lights will turn

on (or flash depending on system settings) as a visual indication that the vehicle has

started and is running.

If your vehicle stalls or does not start, the system will pause 5 seconds, then try 2

more times to start the vehicle (a total of 3 attempts). The system will pause 5

seconds between each start attempt. If the vehicle does not start after the 3rd

attempt, the system will abort the remote vehicle start process.

Remote Start Shutdown

Press and hold the button for 3 seconds to turn the vehicle off.

Preheating or Precooling the Vehicle’s interior

Before exiting the vehicle, set the temperature controls to the desired setting and

operation. After the system starts the vehicle, the heater or air conditioner will

activate and heat or cool the vehicle’s interior to your setting.

Entering the Vehicle while it is Running via Remote Vehicle Start

1. Unlock the vehicle’s doors.

2. Enter the vehicle. DO NOT PRESS THE BRAKE PEDAL!

3. Insert the key into the ignition switch and turn to the ON or RUN

position.

4. Press the brake pedal. The remote vehicle starter will disengage and

the vehicle will operate normally.

Using the “Quick-stop” Feature

If you want to make a short stop and keep your vehicle running (to keep the

interior warm or cool), the quick-stop feature allows you to do this while keeping

your vehicle secure and your keys with you.

To engage quick stop:

1. Stop the vehicle and place the transmission in PARK.

2. With your foot off the brake pedal, press and release the button 2

times within 2 seconds. The LED will flash 3 times to confirm quick

stop is entered.

3. Remove the keys from the ignition and exit the vehicle. Press the

button to lock the vehicle’s doors if desired.

Note: Do not leave children or animals unattended in the vehicle when using the

quick-stop feature.

User Programmable Run Time / Run Time Extension

The system has the ability to allow the user to extend the time the vehicle will be

running under control of the remote start. This will only extend the run time back to

the current run time setting during the current remote start cycle. If your system is

set to run 15 minutes and the time remaining is 4 minutes, extending the run time will

reset the countdown timer to 15 minutes and your vehicle will continue to run for

another 15 minutes. Follow the steps below to extend the vehicle’s run time.

1. The remote start must already be active.

2. Press and release the button 4 times.

3. The system will chirp to confirm that the run time has been reset.

Operating the Daily Start Timer

The system has the ability to start your vehicle based on a 24-hour countdown

timer. This feature requires a two-part activation sequence. From the remote,

pressing both the & buttons together will activate the 24 hour countdown

timer (the vehicle will start 24 hours from this time). Next, When you are finished

operating the vehicle for the day, perform the following steps to complete the

process.

1. Turn the ignition ON/OFF (vehicle must be disarmed).

2. Within 10 seconds, while pressing the brake, press and release the

button twice.

3. The vehicle will emit 2 chirps.

To begin the 2 / 3 hour start up timer mode:

1. Turn the vehicle’s ignition ON then OFF.

2. Press and hold the valet button.

3. Press the button 4 times, the system will chirp 2 times and flash the

parking lights 4 times.

4. Release the valet button.

To exit the 2 / 3 hour start up timer mode:

1. Turn the vehicle’s Ignition ON.

1. Activate the remote vehicle start feature using the remote

control.

Operating the 2 / 3 Hour Start Up Timer Mode

The system has the ability to start the vehicle every 2 or 3 hours for a 48 hour

period. This feature is especially useful in cold climates where the only means to

keep the engine and engine fluids warm is to periodically start the engine. The

default setting is 3 hour, selection between 2 or 3 hour is made in option

programming.

WARNING!

Be certain that the vehicle is outdoors before using this or any remote starting

device. A running engine produces dangerous carbon monoxide fumes which can

be harmful or fatal if prolonged exposure occurs. DO NOT remote start the vehicle

if it is garaged.

Remote Start Safety Features

For safety and security reasons, the system will shutdown or prevent the remote

vehicle starter from activating if any of the following occur:

1. The vehicle hood is open.

2. The brake pedal is pressed prior to turning the ignition key to the ON

position.

3. The engine is over-reved (tach checking only).

4. Valet mode is active.

Transmitter Button Functions

1 Way

Transmitter

Lock Unlock

Car Find /

Panic

Start Operation Method

Lock X Press and Release

Unlock X Press and Release

Trunk X Push and Hold (3 Sec)

AUX 1 X X Push and Hold (3 Sec)

Car Finder X Press and Release

Panic X Push and Hold (3 Sec)

Remote Start X

Press and Release (1 or 2 times

depending on selectable option)

Remote Start

Shut Down

XPush and Hold (3 Sec)

Run Time

Extention

XPress and Release 4 times.

2 / 3 Hour Start X

Ignition ON/OFF, Press and Hold

Valet Button, Press Start 4 times

Daily Start Timer X X Press Lock + Start

Replacing Remote Control Batteries

1-Way Remote Control:

The batteries (model CR2016) inside each remote control should last approximately

1 year under normal use. When the batteries become weak you will notice the

remote control range (the distance from the vehicle the remote control will work)

deteriorate and the small LED on the remote control will dim. To replace the remote

control batteries:

1. Remove 3 screws and disassemble the halves of the remote control.

2. Remove the old batteries, observing the +/- symbols on the batteries

and replace with new CR2016 batteries.

3. Reassemble the halves of the remote control and install the 3 screws.

4. Test operation of the remote control.

Code Systems, Inc. Limited Lifetime Warranty

Code Systems Inc. (“CODE”) warrants to the ORIGINAL PURCHASER of this CODE vehicle

security product (the “Product”), purchased from an authorized CODE dealer, that (except as

provided below) should this Product under normal use and conditions, be proven defective in

material or workmanship DURING THE LIFETIME OF THE VEHICLE IN WHICH IT WAS ORIGI-

NALLY INSTALLED, such defect(s) will be repaired or replaced (at CODE’s option) without charge

for parts directly related to repairs of the defect(s).

Switches, indicator lights, and transmitter cases are similarly warranted to the original purchaser

for a period of one (1) year from the date of purchase of the Product.

CODE accessories, sold separately, are covered by the applicable warranty accompanying the

accessory.

This warranty is non-transferable, non-assignable and is voided when: (1) the Product is removed

from the vehicle in which it was originally installed; or (2) the vehicle in which the Product was

originally installed is transferred to another party.

This warranty does not apply to any product damaged by accident, physical or electrical abuse,

improper installation, alteration, or use contrary to its intended function, fire, flood, or other

natural acts.

In order for the Product to be repaired or replaced under the terms of this warranty, the defective

Product must be returned to an authorized CODE dealer and accompanied by a copy of the retail

sales receipt. The date of purchase and year, make and model of the vehicle in which the Product

was originally installed must be clearly indicated on the sales receipt.

This warranty is exclusive and CODE MAKES NO OTHER WARRANTIES EXPRESSED OR

IMPLIED. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MER-

CHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE

DURATION OF THIS WRITTEN WARRANTY. IN NO CASE SHALL CODE BE LIABLE FOR ANY

CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER

WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER.

CODE does not warrant that the Product cannot be compromised or circumvented. THE EXTENT

OF CODE’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACE-

MENT PROVIDED ABOVE AND, IN NO EVENT SHALL CODE’S LIABILITY EXCEED THE PUR-

CHASE PRICE PAID BY THE ORIGINAL PURCHASER OF THE PRODUCT WITHOUT INSTAL-

LATION LABOR.

Some states do not allow the exclusion or limitation of incidental or consequential damages, so the

above limitation may not apply to you. This warranty gives you specific legal rights and you may

also have other rights which vary from state to state

Audiovox Electronics Corporation.

Customer Service 1-800-421-3209

WWW.CODE-ALARM.COM

FCC COMPLIANCE

This device complies with Part 15 of the FCC rules and with RSS-210 of

Industry Canada. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including any interference

that may cause undesired operation.

Warning!

Changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

Advance Security R54 Car Alarm Receiver User Manual CA Elite 6 series Install rev A 4 13 09

Advance Security Inc Car Alarm Receiver CA Elite 6 series Install rev A 4 13 09

Contents

user manual 2

Navigation menu

Namespaces

Views

Navigation
