Advance Security TR44 Car Alarm Transceiver User Manual CA Elite 6 series Install rev A 4 13 09
Advance Security Inc Car Alarm Transceiver CA Elite 6 series Install rev A 4 13 09
User manual
1ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
PROFESSIONAL
SERIES
ca 4552
Owner’s Guide
IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is
applicable to most vehicles. However, due to the configuration of some vehicles, some functions AND/OR
SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.
Remote Start System
2 ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
Using Your Remote Vehicle Starter
Remote Starting Your Vehicle
The system WILL NOT start the vehicle if any one of the following
situations exist:
1. The vehicle's hood is opened.
2. The gear shift selector is not in Park.
3. The brake pedal is depressed.
4. Valet Mode is active.
1. To start the vehicle, press and release the button 2 times within 2 seconds. The
vehicle will start and remain running for the pre-programmed 5, 10, 15, 20, 45 or
60 minute run cycle. As a visual indication, the parking lights will flash or remain
on depending on the setting by your installation center.
2. When you arrive at the vehicle, turn the ignition key to the ON position (Do not try
to restart the vehicle), then step on the brake pedal to disengage the remote start.
The vehicle will continue to run, but now on it's own power.
Shutting Down the Remote Start
To shut down the remote start feature from the transmitter press and release the
button 2 times within 2 seconds.
Unlocking the Vehicle (optional)
To unlock the vehicle's doors press and hold the button for 3 seconds anytime
the vehicle is remote started.
Note: Additional parts and/or labor may be necessary, see your installing dealer
for details.
Programmed Transmitter Notification
As a security precaution each time the vehicle’s ignition is turn on the status LED
light with flash the number of transmitters programmed into the system. This helps
to identify unauthorized transmitters from accessing your vehicle. If you believe an
unauthorized transmitter has been programmed to your system, contact your
installing dealer for assistance.
3ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
To begin the 2 / 3 hour start up timer mode:
1. Turn the vehicle’s ignition ON then OFF.
2. Press and hold the valet button.
3. Press the button 4 times, the system will;
a. When set for 3 Hour (default) - flash the parking lights 4 times.
b. When set for 2 Hour - flash the parking lights 2 times.
4. Release the valet button.
To exit the 2 / 3 hour start up timer mode:
1. Turn the vehicle’s Ignition ON.
OR
1. Activate the remote vehicle start feature using the remote
control.
Operating the 2 / 3 Hour Start Up Timer Mode
The system has the ability to start the vehicle every 2 or 3 hours for a 48 hour
period. This feature is especially useful in cold climates where the only means to
keep the engine and engine fluids warm is to periodically start the engine. The
default setting is 3 hour, selection between 2 or 3 hour is made in option
programming.
WARNING!
Be certain that the vehicle is outdoors before using this or any remote starting
device. A running engine produces dangerous carbon monoxide fumes which can
be harmful or fatal if prolonged exposure occurs. DO NOT remote start the vehicle
if it is garaged.
Using the “Quick-stop” Feature
If you want to make a short stop and keep your vehicle running (to keep the
interior warm or cool), the quick-stop feature allows you to do this while keeping
your vehicle secure and your keys with you.
To engage quick stop:
1. Stop the vehicle and place the transmission in PARK.
2. With your foot off the brake pedal, press and release the button 2
times within 2 seconds. The LED will flash 3 times to confirm quick
stop is entered.
3. Remove the keys from the ignition and exit the vehicle. Lock the
vehicle’s doors if desired.
Note: Do not leave children or animals unattended in the vehicle when using the
quick-stop feature.
4 ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
Transmitter Button Functions
1 Button Transmitter Start / Aux Operation Method
Unlock X
Press and Hold - During
remote start only
Remote Start X
Press and Release (1 or 2
times depending on
selectable option)
Remote Start Shut Down X
Press and Release (1 or 2
times depending on
selectable option)
Valet Mode
Valet Mode is used to disable the system from remote starting. To
enter or exit valet mode simply follow the 4 steps outlined below:
1. Turn the vehicle’s ignition ON.
2. Push and hold the programming/valet button.
3. The LED will turn on solid when valet mode is active
4. Release the programming/valet button.
2 Way Transmitter Notifications
FUNCTION BEEPS / LED FLASHES
Activation 1 Beep / Flash
Confirm Remote Start 4 Beeps / Flashes (repeats 3 times)
Remote Start Running 1 Flash per 3 seconds for duration run time
Remote Start Shutdown 1 Long Beep / Long Flash (repeats 3 times)
Low Battery 3 Beeps / Flashes when button is pressed
5ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
Replacing Remote Control Batteries
1 Way Remote Control:
The batteries (model CR2016) inside each remote control should last approximately
1 year under normal use. When the batteries become weak you will notice the
remote control range (the distance from the vehicle the remote control will work)
deteriorate and the small LED on the remote control will dim. To replace the remote
control batteries:
1. Unsnap and disassemble the halves of the remote control.
2. Remove the old batteries, observing the +/- symbols on the batteries
and replace with new CR2016 batteries.
3. Reassemble the halves of the remote control.
4. Test operation of the remote control.
2 Way Remote Control:
The battery (model CR2032) inside each remote control should last approximately
10 months under normal use. When the battery become weak you will notice the
remote control range (the distance from the vehicle the remote control will work)
deteriorate and the small LED on the remote control will dim. To replace the remote
control battery:
1. Remove 3 screws and disassemble the halves of the remote control.
2. Remove the old battery, observing the +/- symbols on the battery
and replace with a new CR2032 battery.
3. Reassemble the halves of the remote control and install the 3 screws.
4. Test operation of the remote control.
6 ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
Code Systems, Inc. Limited Lifetime Warranty
Code Systems Inc. (“CODE”) warrants to the ORIGINAL PURCHASER of this CODE vehicle
security product (the “Product”), purchased from an authorized CODE dealer, that (except as
provided below) should this Product under normal use and conditions, be proven defective in
material or workmanship DURING THE LIFETIME OF THE VEHICLE IN WHICH IT WAS ORIGI-
NALLY INSTALLED, such defect(s) will be repaired or replaced (at CODE’s option) without charge
for parts directly related to repairs of the defect(s).
Switches, indicator lights, and transmitter cases are similarly warranted to the original purchaser
for a period of one (1) year from the date of purchase of the Product.
CODE accessories, sold separately, are covered by the applicable warranty accompanying the
accessory.
This warranty is non-transferable, non-assignable and is voided when: (1) the Product is removed
from the vehicle in which it was originally installed; or (2) the vehicle in which the Product was
originally installed is transferred to another party.
This warranty does not apply to any product damaged by accident, physical or electrical abuse,
improper installation, alteration, or use contrary to its intended function, fire, flood, or other
natural acts.
In order for the Product to be repaired or replaced under the terms of this warranty, the defective
Product must be returned to an authorized CODE dealer and accompanied by a copy of the retail
sales receipt. The date of purchase and year, make and model of the vehicle in which the Product
was originally installed must be clearly indicated on the sales receipt.
This warranty is exclusive and CODE MAKES NO OTHER WARRANTIES EXPRESSED OR
IMPLIED. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MER-
CHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE
DURATION OF THIS WRITTEN WARRANTY. IN NO CASE SHALL CODE BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER
WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER.
CODE does not warrant that the Product cannot be compromised or circumvented. THE EXTENT
OF CODE’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACE-
MENT PROVIDED ABOVE AND, IN NO EVENT SHALL CODE’S LIABILITY EXCEED THE PUR-
CHASE PRICE PAID BY THE ORIGINAL PURCHASER OF THE PRODUCT WITHOUT INSTAL-
LATION LABOR.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation may not apply to you. This warranty gives you specific legal rights and you may
also have other rights which vary from state to state
7ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
8 ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
Audiovox Electronics Corporation.
Customer Service 1-800-421-3209
WWW.CODE-ALARM.COM
FCC COMPLIANCE
This device complies with Part 15 of the FCC rules and with RSS-210 of
Industry Canada. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including any interference
that may cause undesired operation.
Warning!
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
