User Manual Safety Guide
Safety Instructions
DLT-V4108 Industrial PC
Advantech-DLoG
Safety Instructions DLT-V4108, V01 PN2005410800
1 / 8
Carefully read and comply with the
safety instructions.
Carefully read the accompanying
“DLT-V4108 Quick Start Guide”
Keep all documents for future
reference.
You can find additional information in
the “DLT-V4108 Manual” at
www.advantech-dlog.com, Downloads
-> Products.
Contents
1. Intended use
2. Required qualification
3. Transport, storage
4. Commissioning
5. Handling, operation
6. Maintenance
7. Regulatory information
8. Technical customer support
Design elements in this safety
instructions
This symbol and the keywords indicate hazards
that pose a risk to life and limb:
DANGER / WARNING /
CAUTION
Personal injury.
DANGER: danger that immediately leads to
death or severe injury.
WARNING: danger that can lead to death or
severe injury.
CAUTION: danger that can lead to slight
injuries.
These tips warn you of possible property
damage:
NOTICE: Physical damage
Information about possible physical damage
1
Intended use
DLT-V4108 Industrial PC is a data
communication terminal for using in commercial
environments (e.g. logistics, warehouse,
manufacture site). Any other or additional
usage beyond this shall be deemed as
improper usage. The user/operator of DLT-
V4108 is solely responsible for any resulting
damage. This also applies to any unauthorized
modifications made to this device.
DLT-V4108 is intended to be used either with
the original Advantech-DLoG power cable or an
Advantech-DLoG certified external DC power
supply with 9 to 60 VDC and 5 A.
The maximum system operation temperature is
+50 °C.If need further assistance, please
contact Advantech-DLoG for further information.
Indented use includes the compliance with all
safety instructions and the compliance with the
approved environmental conditions and
specifications for this device.
DLT- V4108 Industrial PC:
is not approved to be used in any EX
zone (potential explosion hazard), on
ships and railed vehicles.
is not approved to be used in any life-
support system or critical safety system
where system malfunction can lead to
direct or indirect endangerment of
human life.
Safety Instructions
DLT-V4108 Industrial PC
2 / 8
Safety Instructions DLT-V4108, V01 PN2005410800
Advantech-DLoG
Only use accessories that have been tested
and approved by Advantech-DLoG for the
respective DLT-V4108. Otherwise, any DLoG
GmbH warranty for this device will be void.
CAUTION
Replaceable Battery.
The DLT-V4108 has an integrated
uninterrupted power supply (UPS). The
battery pack (lithium-ion technology) of the
UPS is located inside of back cover and
couldn’t be changed by user.
RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE.
2
Required qualification
WARNING
Only qualified and skilled personnel may
commission (e.g. electrical installation and
mechanical mounting) and maintain DLT-
V4108. Because of the integrated UPS,
knowledge is required of lithium-ion batteries
and the precautions/safety regulations that
have to be taken with them.
Qualified and skilled personnel referred in
these safety instructions are persons who are
familiar with these processes and have the
corresponding qualifications for their activities,
such as:
Training or instruction in how to switch
on and off, ground, and label power
circuits and devices or systems in
accordance with the current standards
for safety equipment, as well as the
required authorization..
Training or instruction in how to
maintain and use appropriate safety
equipment in accordance with the
current standards for safety equipment.
Training in first aid.
Users of DLT-V4108 industrial PC must be
trained by skilled personnel and instructed
about the operation of the device.
3
Transport / Storage
WARNING
Risk of injury due to weight and sharp-
edged parts.
DLT-V4108 can fall down and cause injuries
due to its weight. The strain relief rail can have
sharp edges and cause cutting injuries
Always hold DLT-V4108 by its housing
with both hands.
Never use the antenna cap as a handle.
It can break due to the weight involved.
Do not hold DLT-V4108 by the strain
relief rail.
Use the assistance of a second person
for installation work.
NOTICE: Physical damage
Protecting touchscreens from damage.
Protect touchscreens from sharp edges,
impacts, and heavy objects.
If stacking, do not stack higher than
four devices.
Place devices front-to-front in this case.
The VESA mounting point on the rear
side of the device can damage the
touchscreen of another device.
Safety Instructions
DLT-V4108 Industrial PC
Advantech-DLoG
Safety Instructions DLT-V4108, V01 PN2005410800
3 / 8
Use protective material (non-
flammable!) between the devices as a
precaution.
UPS battery pack safety notes
WARNING
Personal injury due to short-circuit, fire,
chemical burns, toxic substances.
The DLT-V4108 has an integrated
uninterrupted power supply (UPS). The battery
pack (lithium-ion technology) of the UPS is
located inside of back cover and couldn’t be
changed by user.
RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE.
The integrated UPS lithium-ion battery packs
can ignite if the DLT-V4108 is handled or
stored improperly (risk of fire), cause chemical
burns or release toxic substances.
Use care when handing the DLT-
V4108.
Do not damage the DLT-V4108;
otherwise lithium-ion battery packs
could be damaged.
Do not allow the DLT-V4108 to come
into contact with fire.
Store the DLT-V4108 in a cool and dry
location and comply with the specified
storage temperature and air humidity.
Provide for sufficient ventilation of the
storage location.
Do not store the device near source of
heat or fire, open flames or heaters.
Do not allow it to come into contact
with fire.
Have suitable fire extinguishers ready
(foam or powder) in accordance with
safety regulations.
4
Commissioning
WARNING
Hazardous voltage, electrical shock from
contact with live parts.
Do not put DLT-V4108 into operation if it is
damaged.
Do not open or modify DLT-V4108.
Only connect or disconnect electrical
connections when the device is in a de-
energized state (electrically dead).
This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not
cause harmful interference, and (2) this
device must accept any interference
received, including interference that may
cause undesired operation.
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in
a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be
determined by turning the equipment off and
Safety Instructions
DLT-V4108 Industrial PC
4 / 8
Safety Instructions DLT-V4108, V01 PN2005410800
Advantech-DLoG
on, the user is encouraged to try to correct
the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver.
Connect the equipment into an outlet on a
circuit
different from that to which the receiver is
connected.
Consult the dealer or an experienced
radio/TV technician for help.
Wireless technology
DLT-V4108 device is intended to transmit RF
energy. To protect humans against RF
exposure and to comply with country-specific
regulations:
This equipment should operate with
minimum distance 20 cm between the
radiator & your body
Make sure that the transmission power
and the radio frequency of DLT-V4108
comply with the regulations for the
respective country where the device is
deployed.
Depending on the country-specific
regulations, the operating
company/importing company may be
required to ensure the settings of
wireless operation are compliant. The
regulatory authorities in the relevant
country can provide information on this.
Observe the applicable regulations for
your deployment location/country with
regard to frequencies and the
maximum permissible transmitting
power. Responsibility for this lies with
the company operating DLT-V4108.
Any changes or modifications which are not
expressly approved by the party responsible for
the compliance can lead to the withdrawal of
the operating license and guarantee for this
device.
Electromagnetic radio frequency energy can
interfere with technical devices.
Do not use DLT-V4108 near
pacemakers.
Before using the device please obtain
information about the use of DLT-
V4108 within certain areas (e.g.
airports, hospitals, etc.) and also about
the respectively applicable regulations
and obtain an approval for the
operation of the device, if necessary.
Important information for mechanical
mounting
WARNING
Observe the manufacturer’s instructions for
the respective application site.
Observe the manufacturer’s
instructions about the installation of
peripheral devices.
This is particularly important when
welding or drilling supporting parts.
Observe the manufacturer’s
instructions for connecting additional
loads, for instance, in conjunction with
an emergency shut-off switch.
Risk of accident due to unstable attachment
of DLT-V4108.
When installing DLT-V4108, please
make sure that no one will be injured if
Safety Instructions
DLT-V4108 Industrial PC
Advantech-DLoG
Safety Instructions DLT-V4108, V01 PN2005410800
5 / 8
the bracket breaks (e.g. because of a
stress fracture).
Alternatively please put appropriate
safety measures in place (e.g. install a
security cable in addition to the
mounting bracket).
Important information for electrical
installation
WARNING
Electrical shock due to lack of
disconnecting device.
DLT-V4108 industrial PCs are not equipped
with disconnecting devices that are
accessible from the outside; they do not have
switches. To enable the device to be quickly
disconnected from the power supply in
emergency situations:
Install an easily accessible
disconnecting device close to the
device.
Make sure that the disconnecting
device disconnects all power supply
lines.
Electrical shock due to insufficient
EMERGENCY shut-off mechanism
If the application site’s EMERGENCY-OFF of
does not switch off DLT-V4108, there is a risk
of causing electrical shock.
Install the application site’s
EMERGENCY-OFF switch and the
DLT-V4108 so that DLT-V4108 is
switched off as well when the
EMERGENCY-OFF switch is operated.
Power supply cable and grounding
WARNING
Electrical shock, fire due to incorrect cable
routing or insufficient grounding.
Use only original Advantech-DLoG
power supply cables; these meet the
specific requirements for low-
temperature flexibility, UV resistance,
oil resistance, etc.
Make sure that the power supply
cables are running without kinks and
securely protected against crushing
and abrading.
DLT-V4108 may only be connected to
a SELV circuit (Safety Extra Low
Voltage).
The DC+ connecting cable must be
protected by a fuse (30 AT max.).
The ignition connecting cable must be
protected by a fuse of the following
type: 5x20 mm T 125 mA L / 250 V, for
example, a Wickmann 195-125 mA /
250 V.
Observe correct voltage range.
Ensure that the power supply cables
are fused correctly.
Read the label on the cable and
connect the power supply cable with
correct polarity.
Cut the power supply cable to the
minimum length. This avoids cables
getting tangled and improves the
quality of power supply.
Connect the power supply cable to a
suitable place. Ensure that the
connecting cable has an adequate
cross section and ampacity at the
connection point.
Safety Instructions
DLT-V4108 Industrial PC
6 / 8
Safety Instructions DLT-V4108, V01 PN2005410800
Advantech-DLoG
Observe the following instructions when
connecting/removing external devices.
Only use accessories that have been
tested and approved by Advantech-
DLoG for the respective DLT-V4108
DLT-V4108 may not be connected to
power supply if external devices are
being connected/ removed (not
applicable for USB devices). Otherwise
considerable damage could be caused
to both DLT-V4108 and the peripheral
devices
Make sure that peripherals with their
own power supply are either switched
on at the same time as DLT-4108 or
after the start of DLT-V4108.
Otherwise, you must ensure that a
backflow from the external device to
DLT-V4108 system cannot take place.
Only power up DLT-V4108 when all
devices have been connected and
DLT-V4108 has been closed correctly
(remember the cable cover!).
Otherwise, you may damage DLT-
V4108.
5
Handling / Operation
NOTICE: Physical damage
Improper operation can cause damage and
downtimes to the DLT-V4108 and to the
connected complete system.
Operators of the DLT-V4108 must be
trained in the handling of the device.
Different temperature and air humidity.
If DLT-V4108 is alternately used between very
different temperature and air humidity condition,
condensation may form on or within DLT-
V4108.
To prevent damaging DLT-V4108, you
will need to wait sufficient time for the
moisture to evaporate before using
DLT-V4108.
Cables
Be sure that nothing rests on power
cable and the cable is not located in
where it can be tripped over or stepped
on.
When you disconnect any cable, pull
on its connector or on its strain relief
loop.
Do not pull on the cable itself. As you
pull out the connector, keep it evenly
aligned to avoid bending any connector
pin.
Also, before you connect any cable,
please make sure that both connectors
are correctly oriented and aligned.
Use available strain relief rails.
6
Maintenance
WARNING
Only the manufacturer and its authorized
service centers may:
Conduct repairs.
Carry out modifications.
Replace modules.
Open the device.
Safety Instructions
DLT-V4108 Industrial PC
Advantech-DLoG
Safety Instructions DLT-V4108, V01 PN2005410800
7 / 8
The legal warranty shall apply. It expires if
customer performs measurement on the device
which is only permitted to be performed by the
manufacturer and it’s authorized Service
Centers.
Risk of accident due to unstable attachment
of DLT-V4108.
If the attachment of DLT-V4108 becomes
loose and breaks during operation or
movement, this can lead to severe accidents.
Regularly check whether DLT-V4108 is
firmly seated in the associated holder
(RAM Mount™) and the mounting
screws are not loose.
Hazardous voltage, electrical shock from
contact with live parts when cleaning the
device.
To prevent electrical shock while cleaning the
device:
Switch off DLT-V4108 before cleaning.
Disconnect DLT-V4108 from power
supply.
Disconnect all accessories which are in
connection with DLT-V4108.
NOTICE: Physical damage
Cleaning the touchscreen and housing
Use a neutral glass cleaner without
ammonia or isopropyl alcohol applied
to a lint-free cloth.
Do not apply cleaning agent to the
touchscreen; apply it to the cleaning
cloth
Then wipe off the touchscreen.
Do not use any abrasive glass cleaner
or cloths to clean the touchscreen
which could scratch it.
Never use chemical solvents to clean
the touchscreen.
Do not use acidic or alkaline solutions
to clean or apply on DLT-V4108.
Do not use cleaning agents that
contain ammonia or sulfur (tile cleaners,
for example, contain ammonia) to clean
or apply on DLT-V4108.
7
Regulatory information
Country-specific approvals (EC, US, Canada,
China, etc.
Please observe all country-specific markings on
the device as well as information in the “DLT-
V4108 Manual“ (EC declaration of conformity
etc.).
Recycling information
DLT-V4108 devices that are no
longer being used may not be
disposed of in the regular
residential or domestic waste;
they must be taken to an official
public collection point and
handled by a disposal provider.
Please contact the responsible
authorities in your
country/region to find out about
the applicable regulations for
proper disposal, if necessary.
Safety Instructions
DLT-V4108 Industrial PC
8 / 8
Safety Instructions DLT-V4108, V01 PN2005410800
Advantech-DLoG
8
Technical customer
support
Please contact your distributor, your sales
representative or Advantech-DLoG’s customer
service to receive technical support.
Please have the following information available:
Product name
Serial number
Description of your peripheral
attachments
Description of your software (operating
system, version, application software,
etc.)
A complete description of the problem
The exact wording of any error
messages
Advantech-DLoG Service & Support
Worldwide service and comprehensive support:
https://www.advantech-dlog.com/en/service-
and-support/
E-Mail: helpdesk@advantech-dlog.com
Phone: (+49) 89 / 41 11 91 999
Manufacturer address
Advantech-DLoG
DLoG GmbH
Industriestraße 15
D-82110 Germering
Warranty
The Advantech-DLoG general terms and
conditions of business are applicable to DLT-
V4108 and its accessories (Liability for defects
-> limitation period for claims in relation to
defects). For more details, please refer to
www.advantech-dlog.com.
by DLoG GmbH 2017.
Information in this document is subject to
change – also without prior notice. DLoG
GmbH assumes no liability for technical
inaccuracies, typographic errors or faults in this
document. DLoG GmbH accepts no liability for
damage caused directly or indirectly by the
delivery, performance or use of this document.
RAM® and RAM Mount™ are both trademarks
of National Products Inc., 1205 S. Orr Street,
Seattle, WA 98108.
We recognize all national and international
trademarks and product names.
Document finished on: 04/08/2017
