Aerielle ATBPA6V100 FM Transmitter User Manual XRAA Guide

XM Satellite Radio Limited Consumer Warranty

Delphi Product and Service Solutions (“Delphi”) warrants all XM Satellite Radio Products sold by Delphi (“Products”) to be free

of defects in material and workmanship, subject to the following conditions. The duration of Delphi’s warranty with respect to

Delphi XM Satellite Radio Products is limited to one (1) year from the date of sale to the original consumer purchaser. No other

express warranties are made with respect to any Product. All implied warranties, including warranties of merchantability and

fitness for a particular purpose are limited to the warranty period set forth above. This warranty is not transferable and applies

only to the original consumer purchaser of the Product. Delphi will, as its sole obligation under this warranty, replace or repair,

at its option, any Product that does not conform to this warranty. Under no circumstances will Delphi be liable for any incidental

the first thirty (30) days after the date of purchase, you must return the defective Product with the original receipt to the original

place of purchase. To obtain warranty service during the remainder of the warranty period, you must contact Delphi by phone at

1.877.GO DELPHI (1.877.463.3574) or by fax at 1.866.790.3675. When contacting Delphi by fax, please include a letter

detailing your complaint and provide a daytime phone number where you can be reached. If further clarification or additional

information is required from Delphi, you may call Delphi at 1.877.GO DELPHI (1.877.463.3574). If warranty service is needed at

any time during the warranty period, the purchaser will be required to furnish a sales receipt/proof of purchase indicating the

for the repair of any Product. How state law relates to the warranty: Some states do not allow limitations on how long implied

warranties last, or the exclusion or the limitation of incidental or consequential damages. So the above limitations or exclusions

may not apply to you. This warranty gives you specific legal rights. You may also have other rights that may vary from state to

This device complies with part 15 of the FCC rules and regulations.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

Signal Format Standard FM Stereo Format, 38KHz subcarrier

Signal-to-Noise Ratio* >60dB

Designed by Aerielle Group International, Inc. ©2003.

www.aerielle.com

Made in China.

Before You Begin

Insert the right angle Power connector at the end of the XM Roady Audio Adaptor cable into the plug on the

Roady receiver identified by a 6V icon.

Insert the right angle Audio connector at the end of the XM Roady Audio Adaptor cable into the plug on the

Roady receiver identified by a speaker icon.

Changing the Transmitting Frequency

The XM Roady Audio Adaptor allows you to change the XM Satellite Radio broadcast signal to an FM frequency

and output the sound to your vehicle radio via an FM station. You may experience some interference if a local

FM station is broadcasting at the same frequency. Try all eight available frequencies on your vehicle’s FM radio

to avoid using a channel that is receiving a good quality local FM signal. Once you have determined which

frequency is not being used by a local FM station, change your FM modulator frequency using the two switches

Auto-On/Auto-Off Feature

The XM Roady Audio Adaptor will automatically switch on when an XM Satellite Radio signal is detected. The

XM Roady Audio Adaptor will also automatically switch off when the Roady is turned off.

finding an available FM frequency on which to operate your XM Roady Audio Adaptor. This is not fault with XM

reception or with the XM Roady Audio Adaptor. In many instances your XM Roady Audio Adaptor may override

the FM broadcast signal.
