TEST REPORT OF A 2.4 GHZ LOW POWER RLAN
MINIPCI CARD, BRAND AGERE, TYPE MPCI3A-20/R,
BUILT INTO NOTEBOOK TYPE LATITUDE X200,
BRAND DELL, IN CONFORMITY WITH
CFR 47 PART 15.107, 15.109, 15.205, 15.207 AND
15.209 (2001-5-24)
Test specification(s):
Description of EUT:
Manufacturer:
Brand mark:
Type:
FCC ID:
CFR 47 Part 15 (2001-5-24)
2.4 GHz low power RLAN MiniPCI card
built into notebook type Latitude X200
Agere Systems Nederland B.V.
Agere
MPCI3A-20/R
IMRMPCIDE3
Project number: 02031401.r01
Page 2 of 16
MEASUREMENT/TECHNICAL REPORT
Agere Systems Nederland B.V.
Model : MPCI3A-20/R
FCC ID: IMRMPCIDE3
March 18, 2002
This report concerns (strike out one): Original grant/certification Class 2 change Verification
Equipment type: Direct Sequence Spread Spectrum Transceiver
Deferred grant requested per 47 CFR 0.457(d)(1)(ii) ? Yes No
Report prepared by: Name : D.H. Kruiter, B.Sc. E.E., B.Sc. T.M.
Company name : TNO Certification EPS
Address : Smidshornerweg 18
Postal code/city : 9822 ZG Niekerk
Mailing address : P.O. Box 15
Postal code/city : 9822 TL Niekerk
Country : The Netherlands
Telephone number : + 31 594 505 005
Telefax number : + 31 594 504 804
E-mail : eps@certi.tno.nl
The data taken for this test and report herein was done in accordance with CFR 47 Part 15 and the measurement
procedures of ANSI C63.4-1992. TNO Certification EPS at Niekerk, The Netherlands, certifies that the data is
accurate and contains a true representation of the emission profile of the Equipment Under Test (EUT) on the date
of the test as noted in the test report. I have reviewed the test report and find it to be an accurate description of the
test(s) performed and the EUT so tested.
Date: March 18, 2002 Signature:
P. de Beer
TNO Certification EPS
Test specification(s):
Description of EUT:
Manufacturer:
Brand mark:
Type:
FCC ID:
CFR 47 Part 15 (2001-5-24)
2.4 GHz low power RLAN MiniPCI card
built into notebook type Latitude X200
Agere Systems Nederland B.V.
Agere
MPCI3A-20/R
IMRMPCIDE3
Project number: 02031401.r01
Page 3 of 16
Description of test item
Test item : 2.4 GHz low power RLAN MiniPCI card built into
notebook type Latitude X200, brand Dell
Manufacturer : Agere Systems Nederland B.V.
Brand : Agere
Type : MPCI3A-20/R
Revision : 8U354
Receipt number : 2
Receipt date : March 13, 2002
Applicant information
Applicant's representative : Mr. W. Kerkhof
Company : Agere Systems Nederland B.V.
Address : Zadelstede 1-10
Postal code : 3431 JZ
City : Nieuwegein
PO-box : 755
Postal code : 3430 AP
City : Nieuwegein
Country : The Netherlands
Telephone number : +31 30 609 7534
Telefax number : +31 30 609 7556
Test(s) performed
Location : Niekerk
Test(s) started : March 14, 2002
Test(s) completed : March 17, 2002
Purpose of test(s) : Type approval / certification
Test specification(s) : CFR 47 Part 15.107, 15.109, 15.205, 15.207 and 15.209 (2001-5-24)
Test engineer : P.A.J.M. Robben, B.Sc.E.E.
Project leader : P.A.J.M. Robben, B.Sc.E.E.
Report written by : D.H. Kruiter, B.Sc. E.E., B.Sc. T.M.
Report approved by : P.A.J.M. Robben, B.Sc.E.E.
Report date : March 18, 2002
This report is in conformity with EN 45001.
This report shall not be reproduced, except in full, without the written permission of TNO Physics and Electronics Laboratory.
The test results relate only to the item(s) tested.
Test specification(s):
Description of EUT:
Manufacturer:
Brand mark:
Type:
FCC ID:
CFR 47 Part 15 (2001-5-24)
2.4 GHz low power RLAN MiniPCI card
built into notebook type Latitude X200
Agere Systems Nederland B.V.
Agere
MPCI3A-20/R
IMRMPCIDE3
Project number: 02031401.r01
Page 4 of 16
Table of contents
1 General information..............................................................................................................................................5
1.1 Product description .......................................................................................................................................5
1.2 Related submittal(s) and/or Grant(s).............................................................................................................5
1.3 Tested system details ...................................................................................................................................5
1.4 Test methodology .........................................................................................................................................6
1.5 Test facility ....................................................................................................................................................6
1.6 Product labeling ............................................................................................................................................6
1.7 System test configuration..............................................................................................................................7
1.7.1 Justification ............................................................................................................................................7
1.7.2 EUT exercise software...........................................................................................................................7
1.8 Special accessories ......................................................................................................................................7
1.9 Equipment modifications...............................................................................................................................8
1.10 Configuration of the tested system ............................................................................................................8
1.11 Block diagram(s) of the EUT .....................................................................................................................8
2 Radiated emission data........................................................................................................................................9
2.1 Test results with EUT operating in receive mode on channel 1 ....................................................................9
2.2 Test results with EUT operating in receive mode on channel 6 ..................................................................10
2.3 Test results with EUT operating in receive mode on channel 11 ................................................................11
2.4 Test results with EUT operating in transmit mode on channel 1.................................................................12
2.5 Test results with EUT operating in transmit mode on channel 6.................................................................13
2.6 Test results with EUT operating in transmit mode on channel 11...............................................................14
3 Conducted emission data...................................................................................................................................15
4 List of utilized test equipment.............................................................................................................................16
Test specification(s):
Description of EUT:
Manufacturer:
Brand mark:
Type:
FCC ID:
CFR 47 Part 15 (2001-5-24)
2.4 GHz low power RLAN MiniPCI card
built into notebook type Latitude X200
Agere Systems Nederland B.V.
Agere
MPCI3A-20/R
IMRMPCIDE3
Project number: 02031401.r01
Page 5 of 16
1 General information
1.1 Product description
The 2.4 GHz low power RLAN MiniPCI card, brand Agere, type MPCI3A-20/R, is designed to operate in the 2.4
GHz ISM frequency band, channels 1 to 11 (2412 MHz to 2462 MHz), as specified by the Federal Communications
Commission in the USA.
The 2.4 GHz low power RLAN MiniPCI card, brand Agere, type MPCI3A-20/R, utilizes Direct Sequence Spread
Spectrum (DSSS) technology.
The 2.4 GHz low power RLAN MiniPCI card, brand Agere, type MPCI3A-20/R, is intended for use in notebooks
with a factory installed integrated antenna. Only antennas, which have been certified by the Federal
Communications Commission for use with this specific 2.4 GHz low power RLAN MiniPCI card, may be connected
to the antenna connector of this device.
1.2 Related submittal(s) and/or Grant(s)
Not applicable.
1.3 Tested system details
Details and an overview of the system and all its components, as it has been tested, can be found in table 1 below.
FCC ID's are stated in this overview where applicable. The EUT is listed in the first row of this table 1.
Description Type number Serial number FCC ID Cable descriptions
2.4 GHz low power RLAN
MiniPCI card MPCI3A-20/R - -
Coaxial antenna cable
connected to a factory installed
integrated antenna, having a
gain of 0.9 dBi
Notebook computer Latitude X200 KR-07J510-36521-218-2068 n.a. (DoC)
Unshielded DC power cord to
AC/DC adapter
Shielded parallel cable to
printer
Dell AC/DC power adapter
100-240 VAC/1.2 Amps to
+20 VDC/2.5 Amps
ADP-50FH, PA-8
family TH-08H051-17971-1CR-1RC7 n.a. (DoC)
Unshielded DC power cord to
notebook computer
Unshielded power cord to AC
mains
Factory installed
integrated antenna, brand
Amphenol KAE, having a
gain of 0.9 dBi
PIFA n.a. n.a. Coaxial antenna cable to EUT
HP DeskJet 895Cxi C6410A ES8B42307H n.a. (DoC)
Unshielded DC power cord to
AC/DC adapter
Shielded parallel cable to
notebook computer
HP AC/DC power adapter
100-240 VAC/1 Amps to
+18 VDC/1.1 Amps
C6409-60014 n.a. n.a. (DoC)
Unshielded DC power cord to
printer
Unshielded power cord to AC
mains
Table 1 - Tested system details overview.
Test specification(s):
Description of EUT:
Manufacturer:
Brand mark:
Type:
FCC ID:
CFR 47 Part 15 (2001-5-24)
2.4 GHz low power RLAN MiniPCI card
built into notebook type Latitude X200
Agere Systems Nederland B.V.
Agere
MPCI3A-20/R
IMRMPCIDE3
Project number: 02031401.r01
Page 6 of 16
1.4 Test methodology
The test methodology used is based on the requirements of CFR 47 Part 15, issue of May 24, 2001, sections
15.107, 15.109, 15.205, 15.207 and 15.209.
The test methods, which have been used, are based on ANSI C63.4: 1992.
Radiated emission tests above 30 MHz were performed at a measurement distance of 3 meters. Below 30 MHz the
radiated emission tests were carried out at measurement distances of 3 and 10 meters. The test results regarding
the radiated emission tests on frequencies below 30 MHz have been extrapolated in order to determine the field
strength of the measured values at measurement distances of 30 and 300 meters (as required by CFR 47 Part 15).
Radiated emission tests on frequencies above 1 GHz were performed with appropriate pre-amplifiers, antennas
and a spectrum analyzer. At frequencies on which radiated emissions were found the level at the input of the pre-
amplifier was reproduced by means of a RF signal generator. The output level of the signal generator was then
increased with the antenna factor in order to obtain the actual field strength value for each individual frequency on
which radiated emissions were found.
1.5 Test facility
The Federal Communications Commission has reviewed the technical characteristics of the test facilities at TNO
Certification EPS, located in Niekerk, 9822 TL Smidshornerweg 18, The Netherlands, and has found these test
facilities to be in compliance with the requirements of CFR 47 Part 15, section 2.948, per October 23, 2000.
The description of the test facilities has been filed at the Office of the Federal Communications Commission. The
facility has been added to the list of those laboratories performing these test services for the public on a fee basis.
The list of all public test facilities is available on the Internet at http://www.fcc.gov.
1.6 Product labeling
In accordance with CFR 47 Part 15.19 (a)(3) the following text shall be placed on a label, which is attached to the
notebook computer (host-system), in which the EUT is built-in:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
The FCC ID of the EUT must be placed on a label, which is attached to the notebook computer (host-system), in
which the EUT is built-in.
For further details about the labeling requirements (size, legibility, etc.) as set by the Federal Communications
Commission see CFR 47 Part 15.19 (a)(3), CFR 47 Part 15.19 (b)(2), CFR 47 Part 15.19 (b)(4), CFR 47 Part 2.925
and CFR 47 Part 2.926.
Test specification(s):
Description of EUT:
Manufacturer:
Brand mark:
Type:
FCC ID:
CFR 47 Part 15 (2001-5-24)
2.4 GHz low power RLAN MiniPCI card
built into notebook type Latitude X200
Agere Systems Nederland B.V.
Agere
MPCI3A-20/R
IMRMPCIDE3
Project number: 02031401.r01
Page 7 of 16
1.7 System test configuration
1.7.1 Justification
The system was configured for testing in a typical fashion (as a customer would normally use it).
The justification and manipulation of cables and equipment in order to simulate a worst-case behavior of the test
setup has been carried out as prescribed in ANSI C63.4: 1992.
Tests were performed at the lowest operating frequency (channel 1: 2412 MHz), the operating frequency in the
middle of the specified frequency band (channel 6: 2437 MHz) and the highest operating frequency (channel 11:
2462 MHz). Further details may be found in table 2 below.
Channel Operating frequencies (MHz) Rated output power (dBm) Test performed
1 2412 +15 yes
2 2417 +15 no
3 2422 +15 no
4 2427 +15 no
5 2432 +15 no
6 2437 +15 yes
7 2442 +15 no
8 2447 +15 no
9 2452 +15 no
10 2457 +15 no
11 2462 +15 yes
Table 2 - Specification of channels and rated maximum output power (excluding antenna gain of 0.9 dBi).
The EUT was tested in a notebook computer with a factory installed integrated antenna, having a declared gain of
0.9 dBi, connected to the antenna port. Only radiated emission measurements and conducted emission
measurements on the AC mains connection terminals of the notebook computer were carried out. The results of all
other measurements, as required by CFR 47 Part 15.247, may be found in the "base" test report with reference
number 02031401.r00.
1.7.2 EUT exercise software
The EUT could be enabled to transmit or receive continuously on channels 1 (2412 MHz), 6 (2437 MHz) and 11
(2462 MHz) by means of test software, which was supplied by the manufacturer of the EUT. Furthermore, the
utilized test software also enables various transmission bit-rate settings in the range of 1 Mbit/s, 2 Mbit/s, 5.5 Mbit/s
and 11 Mbit/s.
1.8 Special accessories
No special accessories are used and/or needed to achieve compliance with the appropriate sections of CFR 47
Part 15.
Test specification(s):
Description of EUT:
Manufacturer:
Brand mark:
Type:
FCC ID:
CFR 47 Part 15 (2001-5-24)
2.4 GHz low power RLAN MiniPCI card
built into notebook type Latitude X200
Agere Systems Nederland B.V.
Agere
MPCI3A-20/R
IMRMPCIDE3
Project number: 02031401.r01
Page 8 of 16
1.9 Equipment modifications
No modifications have been made to the equipment in order to achieve compliance with the appropriate sections of
CFR 47 Part 15.
1.10 Configuration of the tested system
Not applicable. See table 1 in section 1.3 of this test report and the test setup photographs, which are available in
an addendum (with reference number 02031401.r06) to this test report.
1.11 Block diagram(s) of the EUT
The block diagram is available as part of the documentation which is to be submitted to the FCC/TCB.
Test specification(s):
Description of EUT:
Manufacturer:
Brand mark:
Type:
FCC ID:
CFR 47 Part 15 (2001-5-24)
2.4 GHz low power RLAN MiniPCI card
built into notebook type Latitude X200
Agere Systems Nederland B.V.
Agere
MPCI3A-20/R
IMRMPCIDE3
Project number: 02031401.r01
Page 9 of 16
2 Radiated emission data
2.1 Test results with EUT operating in receive mode on channel 1
The results of the radiated emission tests, carried out in accordance with CFR 47 Part 15.109 and CFR 47 Part
15.209 with the EUT operating in receive mode on channel 1 (2412 MHz), are depicted in table 3.
Test results
quasi peak
(dBµV/m)
Test results
average
(dBµV/m)
Test results
peak
(dBµV/m)
Frequency
(MHz)
V H V H V H
Resolution
bandwidth
(kHz)
Quasi peak
limits
(dBµV/m)
Average
limits
(dBµV/m)
Peak
limits
(dBµV/m)
66.600 14.0 7.3 - - - - 120 40.0 - -
71.560 15.6 19.2 - - - - 120 40.0 - -
83.690 22.3 10.0 - - - - 120 40.0 - -
98.300 26.9 22.4 - - - - 120 43.5 - -
229.080 23.7 24.8 - - - - 120 46.0 - -
233.460 25.4 27.6 - - - - 120 46.0 - -
245.750 29.5 32.3 - - - - 120 46.0 - -
260.820 26.6 31.5 - - - - 120 46.0 - -
300.700 31.0 28.8 - - - - 120 46.0 - -
313.480 31.5 39.1 - - - - 120 46.0 - -
325.040 33.0 40.3 - - - - 120 46.0 - -
330.000 27.9 32.9 - - - - 120 46.0 - -
333.020 34.9 38.8 - - - - 120 46.0 - -
391.170 30.4 25.4 - - - - 120 46.0 - -
429.920 35.7 37.7 - - - - 120 46.0 - -
456.410 28.4 26.9 - - - - 120 46.0 - -
480.070 37.0 34.0 - - - - 120 46.0 - -
501.170 35.6 31.3 - - - - 120 46.0 - -
720.110 37.9 32.0 - - - - 120 46.0 - -
732.510 40.9 30.0 - - - - 120 46.0 - -
768.110 37.4 30.7 - - - - 120 46.0 - -
785.870 34.0 30.7 - - - - 120 46.0 - -
816.120 36.8 31.3 - - - - 120 46.0 - -
884.720 35.0 39.9 - - - - 120 46.0 - -
912.900 34.9 33.3 - - - - 120 46.0 - -
983.000 38.8 40.4 - - - - 120 54.0 - -
1056.000 - - n.t. n.t. 41.3 42.8 1000 - 54.0 74.0
1196.000 - - n.t. n.t. 41.5 40.8 1000 - 54.0 74.0
1238.000 - - n.t. n.t. 33.0 41.5 1000 - 54.0 74.0
1333.000 - - n.t. n.t. 42.3 37.4 1000 - 54.0 74.0
1462.000 - - n.t. n.t. 42.9 41.0 1000 - 54.0 74.0
1592.000 - - n.t. n.t. 43.3 38.0 1000 - 54.0 74.0
1732.000 - - n.t. n.t. 38.5 34.1 1000 - 54.0 74.0
1865.000 - - n.t. n.t. 39.9 <30.0 1000 - 54.0 74.0
2208.000 - - n.t. n.t. 40.3 <30.0 1000 - 54.0 74.0
2274.000 - - n.t. n.t. 39.2 <30.0 1000 - 54.0 74.0
Table 3 - Test results with the EUT operating in receive mode on channel 1 (2412 MHz).
Note: Above 1 GHz, all measured values of the spurious emissions with the detector in peak mode are below the applicable limits which are
valid when using an average detector.
Therefore, all spurious emissions above 1 GHz have been measured with the peak detector only (n.t. = not tested).
Note: Field strength values of radiated emissions at frequencies not listed in table 3 are more than 20 dB below the applicable limit.
Test engineer
Signature :
Name : P.A.J.M. Robben, B.Sc.E.E. Date : March 18, 2002
Test specification(s):
Description of EUT:
Manufacturer:
Brand mark:
Type:
FCC ID:
CFR 47 Part 15 (2001-5-24)
2.4 GHz low power RLAN MiniPCI card
built into notebook type Latitude X200
Agere Systems Nederland B.V.
Agere
MPCI3A-20/R
IMRMPCIDE3
Project number: 02031401.r01
Page 10 of 16
2.2 Test results with EUT operating in receive mode on channel 6
The results of the radiated emission tests, carried out in accordance with CFR 47 Part 15.109 and CFR 47 Part
15.209 with the EUT operating in receive mode on channel 6 (2437 MHz), are depicted in table 4.
Test results
quasi peak
(dBµV/m)
Test results
average
(dBµV/m)
Test results
peak
(dBµV/m)
Frequency
(MHz)
V H V H V H
Resolution
bandwidth
(kHz)
Quasi peak
limits
(dBµV/m)
Average
limits
(dBµV/m)
Peak
limits
(dBµV/m)
66.600 14.0 7.3 - - - - 120 40.0 - -
71.560 15.6 19.2 - - - - 120 40.0 - -
83.690 22.3 10.0 - - - - 120 40.0 - -
98.300 26.9 22.4 - - - - 120 43.5 - -
229.080 23.7 24.8 - - - - 120 46.0 - -
233.460 25.4 27.6 - - - - 120 46.0 - -
245.750 29.5 32.3 - - - - 120 46.0 - -
260.820 26.6 31.5 - - - - 120 46.0 - -
300.700 31.0 28.8 - - - - 120 46.0 - -
313.480 31.5 39.1 - - - - 120 46.0 - -
325.040 33.0 40.3 - - - - 120 46.0 - -
330.000 27.9 32.9 - - - - 120 46.0 - -
333.020 34.9 38.8 - - - - 120 46.0 - -
391.170 30.4 25.4 - - - - 120 46.0 - -
429.920 35.7 37.7 - - - - 120 46.0 - -
456.410 28.4 26.9 - - - - 120 46.0 - -
480.070 37.0 34.0 - - - - 120 46.0 - -
501.170 35.6 31.3 - - - - 120 46.0 - -
720.110 37.9 32.0 - - - - 120 46.0 - -
732.510 40.9 30.0 - - - - 120 46.0 - -
768.110 37.4 30.7 - - - - 120 46.0 - -
785.870 34.0 30.7 - - - - 120 46.0 - -
816.120 36.8 31.3 - - - - 120 46.0 - -
884.720 35.0 39.9 - - - - 120 46.0 - -
912.900 34.9 33.3 - - - - 120 46.0 - -
983.000 38.8 40.4 - - - - 120 54.0 - -
1060.000 - - n.t. n.t. 42.6 43.6 1000 - 54.0 74.0
1200.000 - - n.t. n.t. 42.2 36.4 1000 - 54.0 74.0
1333.000 - - n.t. n.t. 42.3 38.0 1000 - 54.0 74.0
1469.000 - - n.t. n.t. 44.0 40.7 1000 - 54.0 74.0
1595.000 - - n.t. n.t. 40.0 37.0 1000 - 54.0 74.0
1739.000 - - n.t. n.t. 40.0 34.6 1000 - 54.0 74.0
1865.000 - - n.t. n.t. 41.4 31.6 1000 - 54.0 74.0
Table 4 - Test results with the EUT operating in receive mode on channel 6 (2437 MHz).
Note: Above 1 GHz, all measured values of the spurious emissions with the detector in peak mode are below the applicable limits which are
valid when using an average detector. Therefore, all spurious emissions above 1 GHz have been measured with the peak detector only (n.t. =
not tested).
Note: Field strength values of radiated emissions at frequencies not listed in table 4 are more than 20 dB below the applicable limit.
Test engineer
Signature :
Name : P.A.J.M. Robben, B.Sc.E.E.
Date : March 18, 2002
Test specification(s):
Description of EUT:
Manufacturer:
Brand mark:
Type:
FCC ID:
CFR 47 Part 15 (2001-5-24)
2.4 GHz low power RLAN MiniPCI card
built into notebook type Latitude X200
Agere Systems Nederland B.V.
Agere
MPCI3A-20/R
IMRMPCIDE3
Project number: 02031401.r01
Page 11 of 16
2.3 Test results with EUT operating in receive mode on channel 11
The results of the radiated emission tests, carried out in accordance with CFR 47 Part 15.109 and CFR 47 Part
15.209 with the EUT operating in receive mode on channel 11 (2462 MHz), are depicted in table 5.
Test results
quasi peak
(dBµV/m)
Test results
average
(dBµV/m)
Test results
peak
(dBµV/m)
Frequency
(MHz)
V H V H V H
Resolution
bandwidth
(kHz)
Quasi peak
limits
(dBµV/m)
Average
limits
(dBµV/m)
Peak
limits
(dBµV/m)
66.600 14.0 7.3 - - - - 120 40.0 - -
71.560 15.6 19.2 - - - - 120 40.0 - -
83.690 22.3 10.0 - - - - 120 40.0 - -
98.300 26.9 22.4 - - - - 120 43.5 - -
229.080 23.7 24.8 - - - - 120 46.0 - -
233.460 25.4 27.6 - - - - 120 46.0 - -
245.750 29.5 32.3 - - - - 120 46.0 - -
260.820 26.6 31.5 - - - - 120 46.0 - -
300.700 31.0 28.8 - - - - 120 46.0 - -
313.480 31.5 39.1 - - - - 120 46.0 - -
325.040 33.0 40.3 - - - - 120 46.0 - -
330.000 27.9 32.9 - - - - 120 46.0 - -
333.020 34.9 38.8 - - - - 120 46.0 - -
391.170 30.4 25.4 - - - - 120 46.0 - -
429.920 35.7 37.7 - - - - 120 46.0 - -
456.410 28.4 26.9 - - - - 120 46.0 - -
480.070 37.0 34.0 - - - - 120 46.0 - -
501.170 35.6 31.3 - - - - 120 46.0 - -
720.110 37.9 32.0 - - - - 120 46.0 - -
732.510 40.9 30.0 - - - - 120 46.0 - -
768.110 37.4 30.7 - - - - 120 46.0 - -
785.870 34.0 30.7 - - - - 120 46.0 - -
816.120 36.8 31.3 - - - - 120 46.0 - -
884.720 35.0 39.9 - - - - 120 46.0 - -
912.900 34.9 33.3 - - - - 120 46.0 - -
983.000 38.8 40.4 - - - - 120 54.0 - -
1066.000 - - n.t. n.t. 40.8 43.6 1000 - 54.0 74.0
1197.000 - - n.t. n.t. 37.2 36.2 1000 - 54.0 74.0
1327.000 - - n.t. n.t. 43.1 38.0 1000 - 54.0 74.0
1465.000 - - n.t. n.t. 38.1 40.7 1000 - 54.0 74.0
1593.000 - - n.t. n.t. 32.4 37.0 1000 - 54.0 74.0
Table 5 - Test results with the EUT operating in receive mode on channel 11 (2462 MHz).
Note: Above 1 GHz, all measured values of the spurious emissions with the detector in peak mode are below the applicable limits which are
valid when using an average detector. Therefore, all spurious emissions above 1 GHz have been measured with the peak detector only (n.t. =
not tested).
Note: Field strength values of radiated emissions at frequencies not listed in table 5 are more than 20 dB below the applicable limit.
Test engineer
Signature :
Name : P.A.J.M. Robben, B.Sc.E.E.
Date : March 18, 2002
Test specification(s):
Description of EUT:
Manufacturer:
Brand mark:
Type:
FCC ID:
CFR 47 Part 15 (2001-5-24)
2.4 GHz low power RLAN MiniPCI card
built into notebook type Latitude X200
Agere Systems Nederland B.V.
Agere
MPCI3A-20/R
IMRMPCIDE3
Project number: 02031401.r01
Page 12 of 16
2.4 Test results with EUT operating in transmit mode on channel 1.
The results of the radiated emission tests, carried out in accordance with CFR 47 Part 15.205 (restricted bands of
operation) with the EUT operating in transmit mode on channel 1 (2412 MHz), are depicted in table 6.
Test results
quasi peak
(dBµV/m)
Test results
average
(dBµV/m)
Test results
peak
(dBµV/m)
Frequency
(MHz)
V H V H V H
Resolution
bandwidth
(kHz)
Quasi peak
limits
(dBµV/m)
Average
limits
(dBµV/m)
Peak
limits
(dBµV/m)
66.600 19.3 14.6 - - - - 120 40.0 - -
71.590 16.3 7.8 - - - - 120 40.0 - -
83.690 22.3 10.0 - - - - 120 40.0 - -
98.300 27.0 22.2 - - - - 120 43.5 - -
100.230 39.2 12.1 - - - - 120 43.5 - -
229.080 26.3 24.0 - - - - 120 46.0 - -
233.460 26.7 28.3 - - - - 120 46.0 - -
235.750 28.9 22.7 - - - - 120 46.0 - -
260.820 26.4 31.7 - - - - 120 46.0 - -
286.360 30.6 35.1 - - - - 120 46.0 - -
294.910 32.4 35.1 - - - - 120 46.0 - -
300.700 31.0 28.4 - - - - 120 46.0 - -
325.040 35.1 34.7 - - - - 120 46.0 - -
331.320 35.1 33.8 - - - - 120 46.0 - -
480.000 37.8 35.9 - - - - 120 46.0 - -
501.170 35.8 32.3 - - - - 120 46.0 - -
639.250 34.8 27.7 - - - - 120 46.0 - -
732.510 41.0 32.1 - - - - 120 46.0 - -
768.410 36.1 30.7 - - - - 120 46.0 - -
786.420 39.8 34.1 - - - - 120 46.0 - -
816.120 36.1 31.3 - - - - 120 46.0 - -
884.720 34.7 38.3 - - - - 120 46.0 - -
1058.000 - - n.t. n.t. 41.3 42.8 1000 - 54.0 74.0
1200.000 - - n.t. n.t. 41.6 40.9 1000 - 54.0 74.0
1326.000 - - n.t. n.t. 33.3 41.7 1000 - 54.0 74.0
1465.000 - - n.t. n.t. 42.7 37.8 1000 - 54.0 74.0
4825.000 - - n.t. n.t. 40.7 37.0 1000 - 54.0 74.0
7236.000 - - n.t. n.t. 40.3 40.7 1000 - 54.0 74.0
Table 6 - Test results with the EUT operating in transmit mode on channel 1 (2412 MHz).
Note: Radiated emission tests have been performed with all possible transmission bit-rates (1 Mbit/s, 2 Mbit/s, 5.5 Mbit/s and 11 Mbit/s) in
transmit mode. The highest values measured of the spurious emission components are reported by means of table 6.
Note: Above 1 GHz, all measured values of the spurious emissions with the detector in peak mode are below the applicable limits which are
valid when using an average detector. Therefore, all spurious emissions above 1 GHz have been measured with the peak detector only (n.t. =
not tested).
Note: Field strength values of radiated emissions at frequencies not listed in table 6 are more than 20 dB below the applicable limit.
Test engineer
Signature :
Name : P.A.J.M. Robben, B.Sc.E.E.
Date : March 18, 2002
Test specification(s):
Description of EUT:
Manufacturer:
Brand mark:
Type:
FCC ID:
CFR 47 Part 15 (2001-5-24)
2.4 GHz low power RLAN MiniPCI card
built into notebook type Latitude X200
Agere Systems Nederland B.V.
Agere
MPCI3A-20/R
IMRMPCIDE3
Project number: 02031401.r01
Page 13 of 16
2.5 Test results with EUT operating in transmit mode on channel 6.
The results of the radiated emission tests, carried out in accordance with CFR 47 Part 15.205 (restricted bands of
operation) with the EUT operating in transmit mode on channel 6 (2437 MHz), are depicted in table 7.
Test results
quasi peak
(dBµV/m)
Test results
average
(dBµV/m)
Test results
peak
(dBµV/m)
Frequency
(MHz)
V H V H V H
Resolution
bandwidth
(kHz)
Quasi peak
limits
(dBµV/m)
Average
limits
(dBµV/m)
Peak
limits
(dBµV/m)
66.600 19.3 14.6 - - - - 120 40.0 - -
71.590 16.3 7.8 - - - - 120 40.0 - -
83.690 22.3 10.0 - - - - 120 40.0 - -
98.300 27.0 22.2 - - - - 120 43.5 - -
100.230 39.2 12.1 - - - - 120 43.5 - -
229.080 26.3 24.0 - - - - 120 46.0 - -
233.460 26.7 28.3 - - - - 120 46.0 - -
235.750 28.9 22.7 - - - - 120 46.0 - -
260.820 26.4 31.7 - - - - 120 46.0 - -
286.360 30.6 35.1 - - - - 120 46.0 - -
294.910 32.4 35.1 - - - - 120 46.0 - -
300.700 31.0 28.4 - - - - 120 46.0 - -
325.040 35.1 34.7 - - - - 120 46.0 - -
331.320 35.1 33.8 - - - - 120 46.0 - -
480.000 37.8 35.9 - - - - 120 46.0 - -
501.170 35.8 32.3 - - - - 120 46.0 - -
639.250 34.8 27.7 - - - - 120 46.0 - -
732.510 41.0 32.1 - - - - 120 46.0 - -
768.410 36.1 30.7 - - - - 120 46.0 - -
786.420 39.8 34.1 - - - - 120 46.0 - -
816.120 36.1 31.3 - - - - 120 46.0 - -
884.720 34.7 38.3 - - - - 120 46.0 - -
1058.000 - - n.t. n.t. 38.4 42.1 1000 - 54.0 74.0
1198.000 - - n.t. n.t. 35.5 34.0 1000 - 54.0 74.0
1325.000 - - n.t. n.t. 43.3 38.5 1000 - 54.0 74.0
1459.000 - - n.t. n.t. 38.3 34.8 1000 - 54.0 74.0
4874.000 - - n.t. n.t. 38.4 34.9 1000 - 54.0 74.0
7310.000 - - n.t. n.t. 37.1 36.4 1000 - 54.0 74.0
Table 7 - Test results with the EUT operating in transmit mode on channel 6 (2437 MHz).
Note: Radiated emission tests have been performed with all possible transmission bit-rates (1 Mbit/s, 2 Mbit/s, 5.5 Mbit/s and 11 Mbit/s) in
transmit mode. The highest values measured of the spurious emission components are reported by means of table 7.
Note: Above 1 GHz, all measured values of the spurious emissions with the detector in peak mode are below the applicable limits which are
valid when using an average detector. Therefore, all spurious emissions above 1 GHz have been measured with the peak detector only (n.t. =
not tested).
Note: Field strength values of radiated emissions at frequencies not listed in table 7 are more than 20 dB below the applicable limit.
Test engineer
Signature :
Name : P.A.J.M. Robben, B.Sc.E.E.
Date : March 18, 2002
Test specification(s):
Description of EUT:
Manufacturer:
Brand mark:
Type:
FCC ID:
CFR 47 Part 15 (2001-5-24)
2.4 GHz low power RLAN MiniPCI card
built into notebook type Latitude X200
Agere Systems Nederland B.V.
Agere
MPCI3A-20/R
IMRMPCIDE3
Project number: 02031401.r01
Page 14 of 16
2.6 Test results with EUT operating in transmit mode on channel 11.
The results of the radiated emission tests, carried out in accordance with CFR 47 Part 15.205 (restricted bands of
operation) with the EUT operating in transmit mode on channel 11 (2462 MHz), are depicted in table 8.
Test results
quasi peak
(dBµV/m)
Test results
average
(dBµV/m)
Test results
peak
(dBµV/m)
Frequency
(MHz)
V H V H V H
Resolution
bandwidth
(kHz)
Quasi peak
limits
(dBµV/m)
Average
limits
(dBµV/m)
Peak
limits
(dBµV/m)
66.600 19.3 14.6 - - - - 120 40.0 - -
71.590 16.3 7.8 - - - - 120 40.0 - -
83.690 22.3 10.0 - - - - 120 40.0 - -
98.300 27.0 22.2 - - - - 120 43.5 - -
100.230 39.2 12.1 - - - - 120 43.5 - -
229.080 26.3 24.0 - - - - 120 46.0 - -
233.460 26.7 28.3 - - - - 120 46.0 - -
235.750 28.9 22.7 - - - - 120 46.0 - -
260.820 26.4 31.7 - - - - 120 46.0 - -
286.360 30.6 35.1 - - - - 120 46.0 - -
294.910 32.4 35.1 - - - - 120 46.0 - -
300.700 31.0 28.4 - - - - 120 46.0 - -
325.040 35.1 34.7 - - - - 120 46.0 - -
331.320 35.1 33.8 - - - - 120 46.0 - -
480.000 37.8 35.9 - - - - 120 46.0 - -
501.170 35.8 32.3 - - - - 120 46.0 - -
639.250 34.8 27.7 - - - - 120 46.0 - -
732.510 41.0 32.1 - - - - 120 46.0 - -
768.410 36.1 30.7 - - - - 120 46.0 - -
786.420 39.8 34.1 - - - - 120 46.0 - -
816.120 36.1 31.3 - - - - 120 46.0 - -
884.720 34.7 38.3 - - - - 120 46.0 - -
1066.000 - - n.t. n.t. 40.7 42.2 1000 - 54.0 74.0
1201.000 - - n.t. n.t. 36.5 34.2 1000 - 54.0 74.0
1327.000 - - n.t. n.t. 43.1 38.1 1000 - 54.0 74.0
1469.000 - - n.t. n.t. 38.5 35.0 1000 - 54.0 74.0
1602.000 - - n.t. n.t. 39.2 33.5 1000 - 54.0 74.0
4825.000 - - n.t. n.t. 40.7 37.0 1000 - 54.0 74.0
7236.000 - - n.t. n.t. 40.3 40.7 1000 - 54.0 74.0
Table 8 - Test results with the EUT operating in transmit mode on channel 11 (2462 MHz).
Note: Radiated emission tests have been performed with all possible transmission bit-rates (1 Mbit/s, 2 Mbit/s, 5.5 Mbit/s and 11 Mbit/s) in
transmit mode. The highest values measured of the spurious emission components are reported by means of table 8.
Note: Above 1 GHz, all measured values of the spurious emissions with the detector in peak mode are below the applicable limits which are
valid when using an average detector. Therefore, all spurious emissions above 1 GHz have been measured with the peak detector only (n.t. =
not tested).
Note: Field strength values of radiated emissions at frequencies not listed in table 8 are more than 20 dB below the applicable limit.
Test engineer
Signature :
Name : P.A.J.M. Robben, B.Sc.E.E.
Date : March 18, 2002
Test specification(s):
Description of EUT:
Manufacturer:
Brand mark:
Type:
FCC ID:
CFR 47 Part 15 (2001-5-24)
2.4 GHz low power RLAN MiniPCI card
built into notebook type Latitude X200
Agere Systems Nederland B.V.
Agere
MPCI3A-20/R
IMRMPCIDE3
Project number: 02031401.r01
Page 15 of 16
3 Conducted emission data
The (worst-case) results of the conducted emission tests at the 110 Volts AC mains connection terminals of the
notebook computer in which the EUT is built-in, carried out in accordance with CFR 47 Part 15.107 and CFR 47
Part 15.207 with the EUT operating in transmit and/or receive mode on channels 1 (2412 MHz), 6 (2437 MHz) and
11 (2462 MHz) while utilizing all possible transmission bit-rates (1 Mbit/s, 2 Mbit/s, 5.5 Mbit/s and 11 Mbit/s), are
depicted in table 9.
Measurement results
dB(µV)
Neutral
Measurement results
dB(µV)
Line 1
Limits
dB(µV)
Margin
(dB)
Neutral
Margin
(dB)
Line 1
Frequency
(MHz)
QP QP QP QP QP
Result
0.511 34.4 35.0 48.0 -13.6 -13.0 PASS
0.600 34.5 33.3 48.0 -13.5 -14.7 PASS
0.685 34.5 31.5 48.0 -13.5 -16.5 PASS
5.121 36.4 34.6 48.0 -11.6 -13.4 PASS
5.555 36.4 34.2 48.0 -11.6 -13.8 PASS
5.642 35.0 31.1 48.0 -13.0 -16.9 PASS
10.095 34.6 34.6 48.0 -13.4 -13.4 PASS
10.443 34.6 34.9 48.0 -13.4 -13.1 PASS
10.531 34.5 35.1 48.0 -13.5 -12.9 PASS
10.964 34.7 35.0 48.0 -13.3 -13.0 PASS
11.310 35.1 35.1 48.0 -12.9 -12.9 PASS
11.398 35.1 35.0 48.0 -12.9 -13.0 PASS
11.486 34.9 35.1 48.0 -13.1 -12.9 PASS
11.573 35.1 34.8 48.0 -12.9 -13.2 PASS
11.662 35.3 34.6 48.0 -12.7 -13.4 PASS
11.835 35.4 34.1 48.0 -12.6 -13.9 PASS
11.923 35.1 34.7 48.0 -12.9 -13.3 PASS
12.097 35.1 34.1 48.0 -12.9 -13.9 PASS
12.185 35.1 33.9 48.0 -12.9 -14.1 PASS
12.273 34.7 33.6 48.0 -13.3 -14.4 PASS
Table 9 - Test results with the EUT operating in transmit/receive mode.
Note: Disturbance voltage values of conducted emissions at frequencies not listed in table 9 are more than 20 dB below the applicable limit.
Test engineer
Signature :
Name : P.A.J.M. Robben, B.Sc.E.E.
Date : March 18, 2002
Test specification(s):
Description of EUT:
Manufacturer:
Brand mark:
Type:
FCC ID:
CFR 47 Part 15 (2001-5-24)
2.4 GHz low power RLAN MiniPCI card
built into notebook type Latitude X200
Agere Systems Nederland B.V.
Agere
MPCI3A-20/R
IMRMPCIDE3
Project number: 02031401.r01
Page 16 of 16
4 List of utilized test equipment
Inventory number Description Brand Type
12471 Biconical antenna 20MHz-200MHz EATON 94455-1
12473 Log-per antenna 200-1000MHz EATON 96005
12476 Antenna mast EMCO TR3
12477 Antenna mast 1-4 mtr Poelstra --
12482 Loop antenna EMCO 6507
12483 Guidehorn EMCO 3115
12484 Guidehorn EMCO 3115
12488 Guidehorn 18 - 26.5 GHz EMCO RA42-K-F-4B-C
12533 Signalgenerator MARCONI 2032
12559 Digital storage oscilloscope Le Croy 9310M
12561 DC Power Supply 20A/70V DELTA SM7020D
12567 Plotter HP 7440A
12605 calibrated dipole 28MHz-1GHz Emco 3121c
12608 HF milliwattmeter Hewlett Packard HP435a
12609 Power sensor 10MHz-18GHz Hewlett Packard HP8481A
12636 Polyester chamber Polyforce --
12640 Temperature chamber Heraeus VEM03/500
13664 Spectrum analyzer HP HP8593E
13078 Preamplifier 0.1 GHz - 12 GHz Miteq AMF-3D-001120-35-14p
13452 Digital multi meter HP 34401A
13526 Signalgenerator 20 GHz Hewlett & Packard 83620A
13594 Preamplifier 10 GHz - 25 GHz Miteq AMF-6D-100250-10p
13886 Open Area testsite Comtest --
14051 Anechoic room Comtest --
14450 2.4 GHz bandrejectfilter BSC XN-1783
15633 Biconilog Testantenna Chase CBL 6111B
15667 Measuring receiver R&S ESCS 30
99045 DC Power Supply 3A/30V DELTA E030/3
99055 Non-conducting support NMi --
99061 Non-conducting support 150cm NMi --
99068 Detector N-F/BNC-F Radiall R451576000
99069 Cable 5m RG214 NMi --
99071 Cable 10m RG214 NMi --
99076 Bandpassfilter 4 - 10 GHz Reactel 7AS-7G-6G-511
99077 Regulating trafo RFT LTS006
99112 Tripod Chase --
99136 Bandpassfilter 10 - 26.5 GHz Reactel 9HS-10G/26.5G-S11

Navigation menu
