Alpha Comm BS057RQ BLUETOOTH HEADSET User Manual
Alpha Comm Enterprises, Inc. BLUETOOTH HEADSET Users Manual
User Manual
When a call is coming, you can answer it with the ways as
follows:
BS057RQ
Magnetic Bluetooth Headset
User Manual
Specifications
The Headset Status
Note: The two Phones mentioned follows will be called Phone A and B.
In OFF MODE, press and hold MFB for 3 seconds, until you hear
“Power on”, the indicator light turns blue for 1 second, then the
headset will enter into ON MODE. The headset will be connected
automatically(when the headset isn’t connect to any other bt
headsets and the paring list is empty the headset will enter into
pairing mode automatically)
In ON MODE (except call state), press and hold MFB for 3
seconds, until you hear “Power off”, the indicator light turns red for
1 second, then the headset will enter into OFF MODE.
Note:
Headset isn’t connected with any devices within 20 minutes, it will
automatically turn off.
In PAIRED MODE, press and hold volume V- button, and say
the voice tag as soon as you hear the short beep. (Ensure your
phone supports voice dialing function, and you have recorded
the voice tag into your phone. See the user guide of your
phone for instructions.).
Method 1: Press MFB once.
Method 2: Adsorb the magnet together.
Method 3: End the call with your phone.
Shortly press MFB twice to hold on the current call and
answer another one.
Shortly press MFB twice to transfer the call from one to
another.
Shortly press MFB you can hang up the current call and
answer another one.
4. Pairing Your Headset with
a Bluetooth Phone
5.Answering a call
7. Rejecting a call
8.Voice prompt language switching
When you are answering a call, there is another call coming:
Structure Sketch
9.Voice Dialing
Status No. Status
Pairing Mode
Not connected
Standby Mode
Charging Mode
Low voltage state
Call state
Headset performance
The headset can be searched, the
indicator light flashes red and blue alternately.
The headset is not connected with the device;
blue light will flash once each 2 seconds.
The headset is connected with the device, and
not any other operations, blue light will flash
once each 5 seconds.
When in a call, the indicator light flashed blue
once each 10 seconds.
The indicator light turns red while being
charged, and will turn blue automatically
after being fully charged.
When the battery’s voltage below 3.3V, the
indicator light flashed red, the speaker prompt
one time every once in a while.
.
Method 1:
Method 2:
Method 3:
Method 4:
6.Ending a call
Press MFB once.
Separate the earphones, put in ear and
answer(When megnet stay together)
Adsorb the magnet earphone together and
separate them slowly and answer(When enjoy
music)
Answer the call with your phone.
Bluetooth Specification
Bluetooth Profiles Supported
Transmission Power
Operation Range
Frequency Range
Battery
Charging Voltage
Charging Time
Music Playing Time*
Talk Time *
Standby Time *
Dimensions(mm)
Weight
V3.0
HSP.HFP. A2DP. AVRCP
Class 2
Up to 10 Meters
2.402-2.480GHz
Built-in Rechargeable
3.7V /60mAH Lithium Battery
DC4.75-5.25V
About 2 hours
Up to 3.5 hours
Up to 4 hours
Up to 150 hours
L38.5×W6.5×H10.5
About 16 g
*The time mentioned above may vary due to user's operation mode and
device settings.
1.Charging Your Headset
Prior to using the headset for the first time or no use for a long
time, please fully charge the battery.
Approximately 2 hours are required to fully charge the
headset.
The indicator light turns red while being charged, and will turn
blue automatically after being fully charged.
When the headset is running out of battery, the indicator light
will flash red (the headset will switch off automatically when
the battery is drained). Please charge the headset as above
steps in time to prolong the battery's useful life (Charging
indication will be delayed for a few minutes if the headset has
not been used for a long time or the battery is drained).
1.2.
1.3.
1.4.
1.1.
Check the charging device is suit to the headset or not.
Use only the supplied charger to charge the headset, if use
other device may violate the validation or the maintenance
article of this product and may cause danger.
Do not attempt to force open the built-in battery as this could
damage the headset.
Note 1:
Note 2:
Note 3:
Note 4:
Note 5:
Note 6:
2.Turning on the Headset
3.Turning off Headset
Ensure the headset is off, and the distance between your
headset and phone is within 1 meter to activate the Bluetooth
function on the phone.
Press and hold MFB until the indicator light flashes blue and
red alternately and could hear “pairing” as PAIRING MODE.
Search Bluetooth devices (see the user guide of your phone
for instructions).
Select headset “MAGsmart Metallic” from the devices list of
the phone.
Enter paring code “0000”,press confirm and later you could
hear “paired”, then could hear “your phone is connected”.
If the pairing cannot be completed within 5 minutes after the
PAIRING MODE has been activated, the headset will enter
into the STANDBY MODE. Please repeat above steps to do
the pairing again).
Ensure there is no obstruction between your headset and
phone and within effective distance, you can use the headset
freely.
Under the circumstance of power off, once you turn on the
headset again it will connect the paired phone automatically
within operation range. (see the user guide of your phone for
instructions).
4.1.
10.1.
10.2.
10.3.
4.2.
4.3.
4.4.
4.5.
4.6.
4.7.
10.Two-call Handling
1
2
3
4
5
6
Press and hold MFB for 2 seconds to reject the call with beep
”dudu” from headset
In PAIRED MODE, press and hole “Volume –“ for 2 seconds.
And say the voice tag as soon as you hear voice promp”dudu”
(Ensure your phone supports voice dialing function, and you
have recorded the voice tag into your mobile. Please see the
user guide of your mobile for more instructions.)
You can end the call which you are answering with by below
ways:
Bluetooth headset should be used with the compatible devices
which support Bluetooth wireless technology. This allows you the
freedom to make two calls at any time.
Please read this user manual carefully before using the headset,
and also read your device’s user manual regarding the Bluetooth
function, and pay attention to those important safety and
maintenance information.
Please keep the headset away from children.
(1)Speaker
(2)Battery Box
(3)Micro USB charging socket
(4)Volume Key- (V-)/Previous
(5)Multifunction Button (MFB)
(6) Volume Key+ (V+) /Next
(7) Left & Right Magnet
(8)LED Indicator light
(9) Microphone
(10)Connect Wire
A fully charged headset will loose its power automatically
If left unused. It is recommended to charge the headset
each three months.
Do not leave the headset in a too hot or too cold condition
(best between -10℃ and 50℃) which may affect the
headset's operations although it is fully charged.
Do not dispose of the headset into fire or water.
12.Mute
17. Headset Resetting
During a call, press and hold “V+” for 2 seconds the headset will
enter into MUTE MODE. In MUTE MODE, the speaker will sound
“dudu” twice every 10 seconds, press and hold “V+” for 2 seconds
again you could cancel the MUTE MODE.
In standby mode, press and hold “V+” and “V-”, until the red and
blue light flashed twice at the same time, the pairing record on
the headset will be deleted, when all the pairing record is
deleted, after the headset turn on, it couldn’t connected
automatically and enter into pairing mode directly.
In call or playing music state, shortly press V+ or V- once to adjust
the volume. When the volume up to maximum or minimum, you
could hear “du” voice prompt.
In any state, as long as the headset is charging, it will be reset.
Press and hold “V-” or “V+” for 2 seconds to forward the next song
or to backward the last song.
16.Delete Pairing Record On
The Headset
13.Adjusting The Volume
14.Forward/Backward
Press MFB once to PLAY music(paired and standby
condition), press MFB again to PAUSE music.
During playing music with the magnetic earphone
separated, adsorb the magnetic earphone to PAUSE
music.
15.Music Pause /Playing
To disconnect the paired headset from your phone, please turn off the
headset or disconnect the headset from the Bluetooth menu of your
phone. When disconnecting, could hear “Your phone is
disconnected”.
11.The Last Number Redialing
18. Switch between two calls:
19. Disconnecting
Do not use abrasive cleaning solvents to clean the headset.
Do not allow the headset to touch with any sharp objects as
this will cause scratching and damage.
Please keep headset away from high-temperature,
humidity and dust.
20. Disconnecting
Press MFB TWICE to redial the last phone number (when connect
one phone).
Press MFB TWICE to redial the last phone number of the fisrt
phone,press V+ button 2 seconds then you can redial the last phone
number of the second phone(When connect two phones)
Note:
All the above operations have to respect the precondition that Phone supports
Bluetooth hands free profile V1.5 and Phones are running under call holding
function(Network service) from telecom.
Note:
When the magnetic earphone adsorb to PAUSE music while separate to PLAY
music. It’s not suitable to use this function frequently unless delay about 10
seconds. When playing music it’s suggested to use MFB to answer a call, it’s
normal for music keep on playing if use magnetic function to hang up the call
under this circumstance(It’s suggested NOT use magnetic function to hang up
calls in this circumstance)
19.1.
21.1.
21.2.
21.3.
19.2.
When the headset is connected with two phones, during
answering a call from phone A, there is a call coming from
phone B, you could press the MFB TWICE to answer Phone
B, the call from phone A is under the status of waiting.
Re-press the MFB TWICE, you can shift the call from one to
another.
Press MFB shortly, you can end the call you are answering
and transfer to another phone.
Method 1:
Method 2:
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation
Any Changes or modifications not expressly approved by
the party responsible for compliance could void the
user's authority to operate the equipment.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
