Alpheus Digital FS-101 Flood / Freeze sensor User Manual
Alpheus Digital Co., Limited. Flood / Freeze sensor Users Manual
Users Manual
Flood/Freeze Sensor
The FS-101’ s is designed to detect pooling water as it makes
contact across the gold probes on the bottom of the
Flood/Freeze Sensor. It also detects the potential of freezing
temperatures that could cause water pipes to burst.
Adding Sensor to the Panel
To add a FS-101 to the panel, set your panel to sensor
learning mode, tamper the sensor by pressing the test button
found on the bottom of the sensor.
Placement
Place FS-101 anywhere you wish to detect a flood or freezing
temperatures. Common locations include: behind a toilet;
under a sink, dishwasher, or fridge; behind a washing machine;
near a water heater; or in a basement.
Testing
To test a FS-101 go to test mode on your panel. Press the
Test/Tamper button on the bottom of the Flood/Freeze
Sensor and hold it for at least 2 seconds. A signal will be sent
to the Panel to notify you the Flood/Freeze Sensor has tested
successfully.
Battery Installation/Replacement
To change the Flood/Freeze Sensor battery, remove the
rubber feet on the bottom of the Flood/Freeze Sensor then
remove the screws and casing. The Flood/Freeze Sensor
requires one CR2450 battery. Be sure to have the + side of the
battery facing you. After the new battery has been replaced in
the compartment, replace the casing, screws and rubber feet
on the bottom of the Flood/ Freeze Sensor.
Specifications
Signal Range: 100 meters open air
Frequency: 345.00 MHz
Supervisory Interval:60mins
Operating Temperature: 0-49℃
Water Proof Rating: IP7
Battery Type: CR2450
FCC COMPLIANCE STATEMENT*
This device complies with FCC Rules and Regulations as Part
15 devices.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired operation.
FCC ID:OC7FS-101
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and
receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician
for help.
