Hose Handle RF Kit - Wireless Controller – LV11
Installation Instructions
1. Remove low-voltage wires from central vacuum unit, if connected.
2. Install low-voltage wire jumpers (supplied) to the central vacuum unit. Install the other end of the wire
jumper to the tabs on the LV11 Wireless Receiver labelled “LV”.
3. Mount the LV11 in a suitable location. Ensure the antenna is extended straight up from the top of the
unit. Mount receiver at a minimum distance of 6 feet away from the central vacuum unit in order
to prevent electrical interference of the RF signal from the motor.
4. Insert connector end of the power adapter to the LV11 “9 Vac Input” terminal.
5. Turn power back on to central vacuum unit and plug AC adapter into power source.
6. To program the Hose Handle Transmitter:Press, with a pointed object, the switch located on the top
side of the LV11 Wireless Receiver. Immediately press and hold the right side of the rocker switch
located on the Hose Handle for 1 second. Programming is now complete.
7. Operation of the Transmitter: to turn on the central vacuum unit, press the right side of the rocker
switch located on the Hose Handle. To turn off, press the left side of the rocker switch on the Hose
Handle.
Caution: Disconnect power to central vacuum system before starting
Part Nbr: 980 INS-004 Rev 1.1 April 2005
NOTE: Changes or modifications not expressly approved by Alutron
Modules could void the user's authority to operate the equipment.
