HD-7
© 2007 American Standard Inc.
LIFETIME™ 5' X 32" IA-LHO/RHO
WHIRLPOOLS BY AMERICAN STANDARD
HIGH GLOSS ACRYLIC
LIFETIME™ 5’ X 32”IA-LHO / RHO
Comfortable bathing design with form-tted backrest
and molded-in armrests
❏ Model# 2425L-LHO Built-In Integral Apron
Left Hand Drain Outlet (specify color)
❏ Model# 2425L-RHO Built-In Integral Apron
Right Hand Drain Outlet (specify color)
• Acrylic with berglass reinforcement
• Lifetime Overow Drain for maximum
water depth
• Integral apron with removable access panel
• Integral three-sided, tiling / water
retention ange
• 1.4 HP self-draining pump/motor with dry
run seal
• Eight ow adjustable jets including:
Two adjustable Ideal Flow Comfort Jets™
Six adjustable Comfort Jets™
• Two silent air volume controls
• Side-mounted On/Off control
• Designed with undermount installation option
• Complete factory installed and tested
whirlpool system
❏ Model# 2425LC-LHO Built-In Integral Apron
Left Hand Drain Outlet (specify color)
❏ Model# 2425LC-RHO Built-In Integral Apron
Right Hand Drain Outlet (specify color)
• Same as above with the EverClean™ whirlpool
system. The EverClean™ antimicrobial system
incorporates AlphaSan®, a patented
antimicrobial agent manufactured right into the
circulation system components, which
suppresses the growth of unsightly algae,
fungus, mold and mildew.
Nominal Dimensions:
60” x 32” x 21-1/2”
(1524 x 813 x 546mm)
Compliance Certications -
Meets or Exceeds the Following Specications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
SEE REVERSE FOR ROUGHING-IN DIMENSIONS
AND PRODUCT SPECIFICATIONS
Components Required:
❏ Bath Filler*: (specify nish)
❏ Bath Drain: 1599.205.XXX (specify color)
OR 1599.500.020 (white only)
Custom Accessories Available:
❏ E-Z-Install™ Whirlpool Heater - EZHEAT-100
Revised 7/07
For color/nish availability and other faucet choices, please
see the Product Selector and Pricing Guide.
NOTE: E-Z-Install™ Whirlpool Heater is designed to
maintain water temperature during operation. It will not heat
cold water to desired bathing temperature.
* See American Standard Faucet Selector
AlphaSan® is a registered trademark of Milliken & Co.
HD-8
© 2007 American Standard Inc.
LIFETIME™ 5' X 32" IA-LHO/RHO
WHIRLPOOLS BY AMERICAN STANDARD
HIGH GLOSS ACRYLIC
Revised 7/07
NOTES:
BATH CAN BE INSTALLED EITHER ABOVE OR BELOW FLOOR LINE AS PIER, ISLAND, OR PENINSULA TYPE INSTALLATION. SUPPORT OF
BATH BY SUMP BEDDING. SUPPORT AND ENCLOSING MATERIAL BY OTHERS.
■ REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH WHIRLPOOL FOR ADDITIONAL INFORMATION.
FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT FOR ALL SUPPORTS.
IMPORTANT: Dimensions of xtures are nominal and may vary within the range of tolerances established by ANSI Standard Z124.1
These measurements are subject to change or cancellation. No responsibility is assumed for use of superseded or voided leaet.
CUT OUT IN FLOOR
FOR DRAIN
60"
(1524mm)
32"
(813mm)
7-1/2"
(191mm)
10-1/2"
(267mm)
3"
(76mm)
6"
(152mm)
13-1/2"
(343mm)
32"
(813mm)
16"
(406mm)
21-1/2"
(546mm)
20-1/2"(H)
(521mm)
19-1/8"(A)
(486mm)
DIMENSIONS OF FIXTURES ARE NOMINAL AND MAY VARY WITHIN THE RANGE
OF TOLERANCES ESTABLISHED BY ANSI STANDARDS Z124.1 AND A112.19.7.
C/L OF
OVERFLOW
GENERAL SPECIFICATIONS FOR 2425L WHIRLPOOL
WHIRLPOOL ELECTRICAL SPECIFICATIONS
PUMP 1.4 HP, 9.7 AMPS,120V.
60 x 32 x 20-1/2 (1524 x 813 x 521mm)
92 Lbs. (42 Kg.)
675 Lbs. (306 Kg.)
70 Gal. (265 L.)
39 Gal. (148 L.)
42 x 22 (1067 x 559mm)
53 x 25-1/2 (1346 x 648mm)
17-1/2 (445mm)
51 Lbs./Sq.Ft. (247 Kgs./Sq.m)
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
WHIRLPOOL MIN. OPERATING VOL.
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
Model 2425L-LHO Shown
