MB3 User Manual
iMusicBodyRhythm
OWNER’S MANUAL
TABLE OF CONTENTS
INTRODUCTION
WARNINGS AND CAUTIONS
PACAKAGE CONTENTS
INTENDED USE
PARTS AND DISPLAY INDICATORS
SET UP REQUIREMENTS
SET UP PROCEDURES
INSTRUCTIONS FOR USE
SPECIFICATIONS
TROUBLESHOOTING
CARE AND MAINTENANCE
WARRANTY INFORMATION
EXPLANATION OF SYMBOLS
ELECTROMAGNETIC COMPATIBILITY INFORMATION
SERVICE CENTER INFORMATION
To ensure safety and correct usage of the BodyRhythm, all of the safety and
operating instructions should be read and followed before using it.
INTRODUCTION
Thank you for selecting the i-Music BodyRhythm. The i-Music BodyRhythm is
designed to give you pleasure and fun. The main functions are in the following:
• 5 different auto rhythmic tap modes work without iOS devices. Each of the mode
lasts 15 minutes.
• Drumbeat tap in sync with music rhythm with iOS devices
• Drumbeat tap as what you create with iOS devices
• Share the rhythmic tap with your friends with iOS devices
PACKAGE CONTENTS
• 1 Main Uit
• 1 Power Cord
• 1 Owner’s Manual
• 1 Quick Start Guide
INTENDED USE
TheiMusic BodyRhythm is intended for adult to use in an indoor environment. It is
designed to relieve fatigue and tiredness when you listen to the music.
PARTS AND DISPLAY INDICATORS
1. Main Unit
2. Air Openings
Main unit （Front view）
Main unit （Back view）
1
2
3
4
5
6
7
8
3. Control Panel
4. Zip
5. Power Cord
6. Power Plug
7. Handle Strap
8. DC Jack
SET UP REQUIREMENTS
The iMusic BodyRhythm is designed to be used with the following iPod touch and
iPhone models:
iPhone5
iPhone4S
iPhone4
iTouch 4
iTouch 5
The iOS version of these devices should be V5.0 or later.
IMPORTANT: Any individual who may be pregnant, has a pacemaker, suffers from
diabetes, phlebitis and/or thrombosis, is at an increased risk of developing blood clots,
or who has pins/screws/artificial joints or other medical devices implanted in his/her
body should consult with a physician before using a massaging device designed for
home use.
Safety information
To reduce the risk of electric shock, this product outlet only one way. If the plug
does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a
Control Panel
‘Start’/’Stop’ button to control the BodyRhythm
‘Auto Mode’ button to adjust the different auto rhythmic modes
‘Intensity Level Up’ button to turn up the intensity
‘Intensity Level Down’ button to turn down the intensity
qualified electrician to install a proper outlet. Do not attempt to bypass this safety
feature in any way.
Do not use it an hour before and after mealtime as this may have adverse effects
on the user.
The massager is not intended for persons (including infant and children) with reduced
physical, sensory or mental capabilities or with the lack of experience and
knowledge-unless or for sleeping person.
Do not operate the massager under the following conditions:
Where aerosol products are being used or oxygen is being administered.
Where explosive and /or flammable fumes is present
Excessively humid or dusty environment such as bathroom
Where the temperature is 40 centigrade or higher
Do not expose the massager to heaters, stoves or direct sunlight.
Remove all scarves, neckties, necklaces, and jewelry before using this massager.
Avoid using it under the influence of alcohol or when you are not feeling well.
Close supervision is necessary when the massager is near children, invalids, or disabled
persons.
If you are under medication or with medical conditions, please consult your doctor
before use. Do not use the massager if you are not feeling well.
Do not use outdoors. This massager is intended for household and indoor use only.
If you use it in a cold room, do not increase the room temperature abruptly. It is
recommended that you increase the temperature gradually.
If it is brought into a warm environment from a cold place where it was stored, wait for
one hour before use as there may be water droplets on mechanical parts due to
condensation. Using it under such condition may result in malfunction.
INSTRUCTION FOR USE
Use the BodyRhythm without iOS device
Step 1 Preparation
Step 2 Start the BodyRhythm program
Use the BodyRhythm withiOS device
Step1 Preparation
Step2 Set up procedures
Connect the power plug to the electrical outlet Place the BodyRhythm on the shoulder and zip it on
Press the ‘Start/Stop’ button to start/stop program
Press the ‘Mode’ button to adjust intensity of your desired level
Press the ‘Intensity Level Down’ or ‘Intensity Level Up’ button to choose
your desired massage program
Connect the power plug to the electrical outlet Place the BodyRhythm on the shoulder and zip it on
Download the Free BodyRhythm App
Prior to first use, download and install the BodyRhythm App from the App Store. Use keyword search terms
‘BodyRhythm’, ‘iMusic’. Or scan the 2D barcode on the package.
Account Set Up and Registration
Follow the on-screen instructions to register and set up your personal account.
Connect to iOS Device via Bluetooth
Turn Bluetooth “On” under the “Settings” Menu (Settings->General->Bluetooth->On).Wait until the model
name printed on the monitor, (i.e. “BodyRhythm”) and “Not Paired” appear in the Bluetooth Menu,and select
the model name to pair and connect.
Note:
For your maximum safety and comfort, the BodyRhythm are equipped with overheating
protection circuit. After 30 minutes of usage, the units switch off automatically.
Attention:
You can stop the measurement process at any time by pressing the “START/STOP”
button or unplug the Power Cord from the DC Jack.
SAFTY INFORMATION
Do not overload the electrical outlet. Use only the power source as indicated.
Do not use it when your body is wet.
Do not use wet hands to operate the BodyRhythm, orconnect or disconnect the power
plug from the electrical outlet
Do not tamper with the power cord or use it with a damaged cord as this may result in
malfunction and an electric shock.
Do not use the BodyRhythm with other therapeutic equipment or electric blanket, etc.
Do not apply BodyRhythm knobs directly on head, joint of elbows and knees, breasts or
abdomen.
Never remove the plug from the outlet by pulling the power cord, but the plug.
Do not use attachments not recommended by the manufacturer.
The control panel on BodyRhythm is invalid
when it is connected to iOS device.
Open the BodyRhythm App and follow the on
screen instructions on App
Do not operate the BodyRhythm under a blanket, pillow or any other covers.This may
result in a rise in motor temperature and subsequent malfunction or fire.
Do not place the power cord under heavy objects.
Do not operate the BodyRhythm with the air openings blocked. Keep the air openings
free of lint, hair and the like.
Do not perform continuous program on the same spot of your body for more than 5
minutes at a time as this may result in excessive stimulation and adverse effects.
Do not use it if the electrical outlet is loose.
Do not share the BodyRhythm with others to avoid to cross-infection or allergy.
Switch off immediately and disconnect the power cord from the electrical outlet, when:
• Water is accidentally spilled onto the BodyRhythm. This may result in electric shock.
• The massager fell into water.
• Fabric cover is torn and the internal components are exposed.
• Abnormal or severe pain is felt during tapping. Stop usage immediately and consult your doctor.
• Detection of any malfunction or any other abnormal condition during operation
• Power failure. Injury may occur then power is restored unexpectedly.
• Lightning storm.
The BodyRhythm should never be left unattended when plugged in. Unplug from the
outlet when not in use.
Always unplug the BodyRhythm from the electrical outlet, before putting on, after using
and before cleaning.
Use the BodyRhythm only for its intended use as described in this manual.
To disconnect, set all controls to the off position, then remove plug from the outlet.
SPECIFICATONS
Specifications
Product name: BodyRhythm
Model Number: MB3
Voltage Available & Power Consumption:
Auto Timer:
Wireless communication: Bluetooth 3.0
Environment temperature for operation:
Environment humidity for operation:
Environment temperature for storage and transport:
Environment humidity for storage and transport:
Gross Weight: 5.1 Pounds
TROUBLESHOOTING
If you encounter problems with the operation of the Music Massager, please check the
following points to see if they can be rectified. If it still malfunctions or does not work,
please turn off the music massager and remove the power plug from the electrical
outlet.
Do not attempt to fix it yourself. Return the appliance to a service center for
examination and repair.
Problem Possible Cause Solution
The massager
does not work.
Power plug is not securely connected to the
electrical outlet
Check the power plug to ensure it is
securely connected to the electrical
outlet
Electrical outlet is switched off Switch on the electrical outlet
The auto timer function of 30 minutes may have
lapsed.
Start again
The overheat protection device may have been
activated.
Turn off the Switch and unplug the
electrical outlet to cool down the
music massager.
Unsuccessful
connection
between iOS
device and
BodyRhythm
Bluetooth on iOS device is switched off.
Switch on the Bluetooch on iOS
device
The BodyRhythm is abnormal, or Bluethooth
connection is abnormal.
• Check if the BodyRhythm is
switched on and within the
Bluetooth communication
range (5 meters).
• Check if other iOS device is
connected to the BodyRhythm.
If yes, disconnect it.
• Ignore the Bodythm in
Bluetooth list, search it again
and connect it.
CARE AND MAINTENANCE
Keep the massager in dry, shadow and safe places
Unplug the power from the electrical outlet
when not in use.
Note:
The expected useful life of the BodyRhythm is 3 years or 5000 times.
Do not remove cover; there are no serviceable parts inside.
Do not expose this massager to rain or moisture.
Do not expose the massager to heaters, stoves or direct sunlight.
Do not place or store the massager where it can fall or be pulled into a tub or sink.
Do not place in or drop into water or other liquid.
Do not insert any object or flammable material into it. This may result in electric
shock, malfunction or risk of fire.
Do not place the BodyRhythm where children can easily reach
Do not attempt to disassemble the BodyRhythm.
Do not use pins or other metallic fasteners with this appliance. (P)
Do not wind the power cord around it.
Do not crush or fold this massager when storing.
Keep the cord away from heated surfaces.
Do not carry this massager by its power supply cord or use the cord as a handle.
WARRANTY INFORMATION
The iMusicBodyRhythm is warranted to be free from defects inmaterials and
workmanship within one year from the date of purchase when used in accordance
with the provided instructions. The warranty extends only to the end user. We will, at
our option, repair or replace without charge the iMusicBodyRhythm covered by the
warranty. Repair or replacement is our only responsibility and your only remedy
under the warranty.
EXPLANATION OF SYMBOLS
Make sure that the power plug is disconnected
from the electrical outlet.
Use only soft clean cloth to wipe off dust and dirt.
Do not use abrasive cleaning agents to clean the
BodyRhythm
Do not use a damp cloth to clean the control panel.
Symbol for” THE OPERATION GUIDE MUST BE READ”
The sign background colour: blue
The sign graphical symbol: white
Symbol for “WARNING”
Symbol for "GENERAL PROHIBITION SIGN"
Symbol for “TYPE BF APPLIED PARTS” (the main part is the applied parts)
Symbol for “CLASS II equipment“
Symbol for “ENVIRONMENT PROTECTION – Waste electrical products should not be disposed
of with household waste. Please recycle where facilities exist. Check with your local Authority or
retailer for recycling advice”.
Symbol for “MANUFACTURER”
Symbol for “DATE OF MANUFACTURE”
Symbol for “SERIAL NUMBER”
Symbol for “EUROPEAN REPRESENTATIVE”
Symbol for “KEEP DRY”
iMusic is a trademark of iCess Lab Inc.
“Made for iPod” and “Made for iPhone” mean that an electronic accessory has been
designed to connect specifically to iPod, or iPhonerespectively, and has been certified
by the developer to meet Apple performance standards. Apple is not responsible for
the operation of this device or its compliance with safety and regulatory standards.
Please note that the use of this accessory with iPod, or iPhone may affect wireless
performance. iPhone, and iPod touch are trademarks of Apple Inc., registered in the
U.S. and other countries.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth
EC REP
47 Spenlow House Bermondsey London SE16 4SJ
SIG, Inc. and any use of such marks by iCess Lab Inc. is under license. Other
trademarks and trade names are those of their respective owners.
IMPORTANT INFORMATION REQUIRED BY THE FCC
This device complies with Part 15 of the FCC Rules. Its operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Changes or modifications not expressly approved by iCess Lab Inc. would void the
user’s authority to operate the product.
Note: This product has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This product generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is noguarantee that interference will not
occur in a particular installation. If this product does causeharmful interference to
radio or television reception, which can be determined by turning theequipment off
and on, the user is encouraged to try to correct the interference by one or more ofthe
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver isconnected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC ID: ZRYMB3
OTHER STANDARDS AND COMPLIANCES
The Neck and Shoulder Massager corresponds to the following standards:
IEC 60601-1:2006 (Medical electrical equipment – Part 1: General requirements for
basic safety and essential performance);
IEC 60601-1-2:2007 (Medical electrical equipment – Part 1-2: General requirements
for basic safety and essential performance – Collateral Standard: Electromagnetic
compatibility–Requirements and tests);
IEC 60601-1-6:2006 (Medical electrical equipment – Part 1-6: General requirements
for basic safety and essential performance – Collateral Standard: Usability);
IEC 60601-1-11:2010 (Medical electrical equipment – Part 1-11: General
requirements for basic safety and essential performance– Collateral Standard:
Requirements for medical electrical equipment and medical electrical systems used in
the home healthcare environment)
ELECTROMAGNETIC COMPATIBILITY INFORMATION
Table 1
For all ME EQUIPMENT and ME SYSTEMS
Guidance and manufacture’s declaration - electromagnetic emissions
The Neck and Shoulder Massageris intended for use in the electromagnetic environment specified below.
The customer or the user of the monitor should assure that it is used in such an environment.
Emissions test
Compliance
Electromagnetic environment - guidance
RF emissions
CISPR 11 Group 1 The Neck and Shoulder Massager uses RF energy only for its internal function. Therefore, its RF
emissions are very low and are not likely to cause any interference in nearby electronic equipment.
RF emissions
CISPR 11 Class B
The monitor is suitable for use in all establishments, including domestic establishments and those
directly connected to the public low-voltage powersupply network that supplies buildings used for
domestic purposes.
Harmonic emissions
IEC 61000-3-2 Class A
Voltage fluctuations/flicker emissions
IEC 61000-3-3 Complies
Table 2
For all ME EQUIPMENT and ME SYSTEMS
Guidance and manufacturer’s declaration - electromagnetic immunity
The Neck and Shoulder Massager is intended for use in the electromagnetic environment specified below. The customer or the user of the Neck and Shoulder Massager
should assure that it is used in such an environment.
IMMUNITY test
IEC 60601test level
Compliance level
Electromagnetic environment - guidance
Electrostatic discharge (ESD)
IEC 61000-4-2
± 6 kV contact
± 8 kV air
± 6 kV contact
± 8 kV air
Floors should be wood, concrete or ceramic tile.
Iffloors are covered with synthetic material,
therelative humidity should be at least 30 %.
Electrical fast transient/burst
IEC 61000-4-4 ± 2 kV for power supply lines ± 2 kV for powersupply lines
Mains power quality should be that of a typical
commercial or hospital environment.
Surge
IEC 61000-4-5
± 1 kV line(s) toline(s)
± 2 kV line(s) to earth
± 1 kV line(s) toline(s)
± 2 kV line(s) to earth
Mains power quality should be that of a
typicalcommercial or hospital environment.
Voltage dips, shortinterruptions
and voltage variations on power
supply input lines
IEC 61000-4-11
<5 % UT(>95 % dip in UT)
for 0.5 cycle
40 % UT(60 % dip in UT)
for 5 cycles
70 % UT(30 % dip in UT)
for 25 cycles
<5 % UT(>95 % dip in UT)
for 5 s
<5 % UT(>95 % dip in UT)
for 0.5 cycle
40 % UT(60 % dip in UT)
for 5 cycles
70 % UT(30 % dip in UT)
for 25 cycles
<5 % UT(>95 % dip in UT)
for 5 s
Mains power quality should be that of a typical
commercial or hospital environment. If the user of
the monitor requires continued operation during
power mains interruptions, it is recommended thatthe
monitor be powered from an uninterruptiblepower
supply or a battery.
Power frequency(50/60 Hz)
magnetic field
IEC 61000-4-8
3 A/m 3 A/m
Power frequency magnetic fields should be at
levels characteristic of a typical location in a
typicalcommercial or hospital environment.
Note: UT is the a.c. mains voltage prior to application of the test level.
Table 3
For ME EQUIPMENT and ME SYSTEMS that are not LIFE-SUPPORTING
Guidance and manufacturer’s declaration - electromagnetic immunity
The Neck and Shoulder Massager is intended for use in the electromagnetic environment specified below. Thecustomer or the user of the Neck and Shoulder Massager
should assure that it is used in such an environment.
IMMUNITY test
IEC 60601 test level
Compliance level
Electromagnetic environment - guidance
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
3 Vrms 150
kHz to 80 MHz
3 V/m 80 MHz
to 2.5 GHz
3 V
3 V/m
Portable and mobile RF communications equipmentshould be used no closer to
any part of the monitor,including cables, than the recommended
separationdistance calculated from the equation applicable to thefrequency of
the transmitter.
Recommended separation distance:
d 1.2 P
d 1.2 P 80 MHz to 800 MHz
d 2.3 P 800 MHz to 2.5 GHz
Where P is the maximum output power rating of the transmitter in watts (W)
according to the transmitter manufacturer and d is the recommended
separationdistance in meters (m).
Field strengths from fixed RF transmitters, as determined byan electromagnetic
site survey, a should be less than thecompliance level in each frequency range.
bInterference may occur in the vicinity of equipmentmarked with the following
symbol:
Note 1 At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people.
a) Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio
broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic
site survey should be considered. If the measured field strength in the location in which the monitor is used exceeds the applicable RF compliance level above, the
monitor should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as re-orienting or relocating
the monitor.
b) Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
Table 4
For ME EQUIPMENT and ME SYSTEMS that are not LIFE-SUPPORTING
Recommended separation distances between portable and mobile RF communications equipment and the Neck and Shoulder Massager
The Neck and Shoulder Massager is intended for use in an electromagnetic environment in which radiated RF disturbancesare controlled. The customer or the user of
the Neck and Shoulder Massager can help prevent electromagnetic interferenceby maintaining a minimum distance between portable and mobile RF communications
equipment (transmitters) and the monitor asrecommended below, according to the maximum output power of the communications equipment.
Rated maximum output
power of transmitter
W
Separation distance according to frequency of transmitter
m
150 kHz to 80 MHz
d1.2
ඥ
80 MHz to 800 MHz
d 1.2
ඥ
800 MHz to 2,5 GHz
d 2.3
ඥ
0.01
0.12
0.12
0.23
0.1
0.38
0.38
0.73
1
1.2
1.2
2.3
10
3.8
3.8
7.3
100
12
12
23
For transmitters rated at a maximum output power not listed above, the recommended separation distanced in meters (m) can be
determined using the equation applicable to the frequency of the transmitter, where P is the maximum output power rating of the transmitter in watts (W) according to
the transmitter manufacturer.
Note 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
Note 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people.
Service Center
iCess Labs, Inc.
723 N shoreline Blvd., Mountain View, CA 94043, U.S.A
1－855－816－7705 www.iMusicBodyRhythm.com
