Anhui Huami Information Technology XMSH05HM Mi Band 3 User Manual

Anhui Huami Information Technology Co.,Ltd. Mi Band 3

User Manual

Aer the Mi Band is paired successfully, it will begin to track and analyze your
daily activities and sleeping habits.
Press the buon to activate the display.Slide up or down on the screen to
browse your activity data, measure your heart rate, and access many other
features. Slide le or right on the screen to switch the display between different
items.
105g太空梭哑粉，印刷过哑油
折页方式：XX
PANTONG Cool Gray 11C
印刷-连线哑油-模切-折页
17
安徽华米信息科技有限公司
Wuhan_使用说明书_英文版
V1.2
2018.04.11
选择正确的
方向图标拖
动到图纸里
纹理方向
色相正确、印迹牢固、
套印准确、各色套印
不露杂色，套印误差≤ 0.1mm
模切走位≤±0.5mm
69码商品名称SKU编码商品ID 产品型号 料号
图纸提供单位
项目名称
版本号
设计时间
设计师
材质工艺要求
材质要求：
制作工序：
工艺要求：
颜色及专色：
纹理要求：
比例 单位 mm1:1
小米生态链产品包装图纸
XMSH05HM小米手环3M1 69
Mi Band 3 User Manual
Manufactured for: Xiaomi Communications Co., Ltd.
Manufactured by: Anhui Huami Information Technology Co., Ltd.
(a Mi Ecosystem company)
Address: Room 1201, Building A4, National Animation Industry Base, No. 800
Wangjiang West Road, Gaoxin District, Hefei, Anhui, China
For further information, please go to www.mi.com
Mi Fit
1. To download the Mi Fit app, scan the QR code below or search for "Mi Fit" on
the Mi App Store or Apple Store.
QR code for the Mi Fit app
(Android 4.4/iOS 9.0 or later)
04 Pairing the Mi Band with a Smartphone
1. Insert one end of the fitness tracker into the slot from the front of the wristband.
2. Press down on the other end with your thumb to push the fitness tracker into
the slot completely.
02 Installing the Fitness Tracker
2. Open the Mi Fit app, log in to your account and select "Device Pairing", then
follow the pairing instructions to proceed. When the Mi Band starts to vibrate
and the Bluetooth pairing notification appears on the screen, press the buon
to complete the pairing process.
Note: Please make sure Bluetooth connection is activated on your mobile phone.
During the pairing process, please keep the Mi Band near your mobile phone.
For more regulatory information and product certification/compliance logos
related to the Mi Band 3, please go to More -> About on your Mi Band 3.
Note: This diagram is for reference only
Remove the wristband from your wrist, hold on to each end and pull on the
wristband until you see a small gap between the fitness tracker and the wristband.
Use your finger to pop the fitness tracker out of its slot from the front side of the
wristband.
06 Removing the Fitness Tracker
Tighten the wristband around your wrist until there is enough slack to fit about
one finger, then adjust the fit until you find a comfortable position.
Note: Wearing the band too loosely may impact data collection by the heart rate
monitor.
03 Wearing the Mi Band
Read this manual carefully before use, and retain it for future reference
01 Product Overview
Fitness Tracker Wristband Charging Cable
Touchscreen
Button
Heart Rate
Monitor
Slide left/right on the screen to
switch between items
Slide up or down to switch between
different functions
05 Using the Fitness Tracker
Charging
Port
When the Mi Band starts to vibrate, touch the
buon on the wristband to confirm pairing.
My Mi Band did not vibrate
Press the buon on the wristband
to confirm pairing
Disposal and Recycling Information
The symbol signifies that this product has to be disposed
separately from ordinary household wastes at its end of
life. Please kindly be aware that this is your responsibility
to dispose electronic equipment at recycling centers so as
to help conserve natural resources.
This device is in compliance with the essential requirements
and other relevant provisions of Directive 2014/53/EU.
Please charge your Mi Band immediately when the low power indicator is on.
07 Charging the Mi Band 09 Specifications
Name: Mi Band 3
Model: XMSH05HM
Wight of the Fitness Tracker: 8.5 g
Dimensions of the Fitness Tracker: 17.9 x 46.9 x 12 mm
Wristband material: Thermoplastic elastomer
Clasp material: Aluminum alloy
Adjustable length: 155 - 216 mm
Compatible with: Android 4.4/iOS 9.0 or later
Baery capacity: 110mAh
Baery type: Li-Ion polymer baery
Input voltage: DC 5 V
Input current: 250 mA (Max)
IP rating: 5ATM
Operating temperature: -10°C ~ 50°C
Wireless connectivity: Bluetooth 4.2 BLE
Regulatory Notice
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1 . This device may not cause harmful interference, and
2. this device must accept any interference received, including interference that
may cause undesired operation.
FCC ID: 2AC8UXMSH05HM
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.The
devicecan beusedinportable exposureconditionwithoutrestriction.
Please take aention that changes or modification not expressly approved by
the party responsible for compliance could void the user’s authority to operate
the equipment.
08 Important Safeguards
When using the Mi Band to measure your heart rate, please keep your wrist steady.
Mi Band 3 has a water resistance rating of 5ATM. It can be worn in the shower,
swimming pool, or while swimming near the shore. It cannot be used, however,
while siing in a sauna or diving in the ocean.
Underwater operation is not supported for the Mi Band's touch-buon and
touchscreen. Aer the Mi Band has come in contact with water, please use a so
cloth to wipe away excess water from its surface before using the device.
Please keep the area between your wrist and the wristband dry during daily use,
and clean the wristband with water regularly. Please stop using the product
immediately and seek medical assistance if the contact area on your skin begins to
show signs of redness or swelling.
